LAZBOY LZ6200 User manual

Comfort. It's what we do.
Touchscreen Control
Model LZ6200
10 Function Universal Remote Control
With Touchscreen Keypad
Installation Guide
TM
95 x 190mm
27
ECP will repair or replace the defective parts and return
them at ECP's cost by a shipping method selected by
ECP. When contacting ECP to obtain an RMA,
Purchaser may request expedited return shipping at
Purchaser's cost.
THIS WARRANTY IS NOT TRANSFERABLE, AND,
TO THE MAXIMUM EXTENT PERMITTED BY
APPLICABLE LAW, IS IN LIEU OF ALL OTHER
WARRANTIES, REPRESENTATIONS AND
CONDITIONS, EXPRESS OR IMPLIED,
STATUTORY OR OTHERWISE, INCLUDING BUT
NOT LIMITED TO THE IMPLIED WARRANTIES OF
MERCHANTABILITY AND FITNESS FOR A
PARTICULAR PURPOSE. NO OTHER PERSON OR
REPRESENTATIVE IS AUTHORIZED TO MAKE
ANY OTHER WARRANTY ON BEHALF OF ECP OR
ASSUME FOR ECP ANY OTHER LIABILITY IN
CONNECTION WITH THE SALE OF THIS
PRODUCT. IN NO EVENT WILL ECP BE LIABLE
FOR ANY DAMAGES, INCLUDING BUT NOT
LIMITED TO INCIDENTAL, SPECIAL OR
CONSEQUENTIAL DAMAGES ARISING OUT OF
THE USE OR INABILITY TO USE THE PRODUCT,
INCLUDING DAMAGES DUE TO ECP'S
NEGLIGENCE.
THIS WARRANTY GIVES YOU SPECIFIC LEGAL
RIGHTS, AND YOU MAY ALSO HAVE OTHER
RIGHTS WHICH VARY FROM STATE TO STATE
AND COUNTRY TO COUNTRY.
La-Z-Boy is a registered trademark of
La-Z-Boy Incorporated and is
used under license by:
©2008 Elexa Consumer Products
6200 N. Hiawatha Ave, 8th Floor,
Chicago, IL 60646
F820-7360-0000

This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received,
including interference that may cause undesired
operation.
Modifications not expressly approved by the
manufacturer could void the user's authority to operated
the equipment under FCC rules.
1
PRODUCT DIAGRAM
2
1 2 3
4
7
5
8
0
6
9
P P
TV
Enter
REC
Menu
SHIFT
Page
Learn
Smart
AUX1
VCR
AUX1
CD AUD AMP
T V DVD SAT
CBL
Toggle
Subtitle
USB
AV 1
Smart Smart Smart
1 2 34 5 6
1
6
7
8-13
34-38 39
40
2
3
4
5
14-19
20-26
27-33
41
42
43
44
45
46
47
48

23. -Numeric key no.8.
24. -Scrolls up thru menus and guides.
25. -Numeric key no.9.
26. -Brings up the menu screen.
27. -Scrolls left thru menus and guides.
28. -allows you to control the input source when in TV
mode.
29. -Numeric key no.0.
30. -Allows access to the OK function when scrolling
thru menus & guides.
31. -Stereo. Switches the TV to stereo mode on some
TV models equipped with this feature.
32. -Picture in Picture. This allows you to access the
picture in picture feature of your TV.
33. -Scrolls right thru menu and guides.
34. -Enter function for some Special AV equipment.
35. -Allows access to the toggle function from PIP back
to normal picture.
36. -Select viewing aspect ratio for TV.
37. -Scrolls down thru menus and guides.
38. -Allows you access to the subtitle feature of your
DVD player or closed caption feature of your SAT
or CABLE.
39. -Page scroll key. Allows you to turn to the next page
of the LCD screen. Each device has 3 pages of
screens to scroll thru.
40. -Changes the channels forward when in TV, DVR,
Satellite or Cable mode.
41. -Changes the channels backward when in TV, DVR,
Satellite or Cable mode.
42. -Increase the volume of the device. Normally used in
TV mode.
43. -Decreases the volume of the device. Normally used
in TV mode.
44. -Exits on screen menu's and guides and returns you
to the previous on screen selection.
45. -Allows you to return to the previously selected
channel in TV, SAT, or CABLE mode.
46. -Turns devices for remote's current mode on or off.
47. -Allows you to turn the volume on or off when in
TV mode.
48. -Brings up the guide screen when in SAT or cable
mode.
4
KEY FUNCTION DESCRIPTIONS
1.
2.
3.
4. -Programs your VCR. Also programs one auxiliary
device using the shift key.
5. -Programs your cable device. Also programs one
additional auxiliary device using the shift key.
nd
6. -Allows you to program a 2 tier of components into
the TV, DVD, SAT, VCR, CBL. Can also allow you
to access secondary functions of certain devices.
7. -Allows you to program a sequence of steps such as
turn on your TV, turn on your DVD player, turn on
your home theater receiver, and press play on your
DVD player to watch a movie. All in sequence. Each
smart key can program up to 20 steps, use shift then
nd
smart 1. smart 2 or smart 3 to access a 2 tier of
smart keys. I "-" will pop up when the smart key is
being learned.
8. -Numeric key no.1.
9. -Rewind when in VCR mode, scan back when in
DVD, CD & DVR mode.
10. -Numeric key no.2.
11. -Access the play feature when in VCR, DVD, CD &
DVR mode.
12. -Numeric key no.3.
13. -Fast forward when in VCR mode, scan forward
when in DVD, CD & DVR mode.
14. -Numeric key no.4.
15. -Record when in VCR, DVR & DVD mode.
16. -Numeric key no.5.
17. -Pause when in VCR, DVD, CD & DVR mode.
18. -Numeric key no.6.
19. -Stop key when in VCR, DVD, CD & DVR mode.
20. -Numeric key no.7.
21. -Sleep. Allows you to set a timer to turn off the TV
on some TV models equipped with this feature.
22. -Switches the television back to regular viewing
mode.
-Programs your TV. Also programs your CD device
using the shift key.
-Programs your DVD Player. Also programs your
Audio receiver using the shift key.
-Programs your satellite receiver. Also programs
your AMP/ Home Theater Receiver using the shift
key
3
SHIFT
AUX1
VCR
CD
T V
AUD
DVD
AMP
SAT
AUX2
CBL
Smart
1 4
Smart
2 5
Smart
3 6
4
REC
9
Menu
8
2
3
1
5
7
TV
6
0
Page
Subtitle
P P
AV 1
Enter
Toggle

5
Congratulations on the purchase of your La-Z-Boy
Universal Remote Control, a state of the art product
which integrates several infra-red devices to deliver
complete A/V control at the tip of your fingers.
Before operating your remote please read through this
manual carefully and save it for future reference.
This package contains the following:
- One LZ6200 Touchscreen Remote Control.
- One Installation Guide.
- One Quick Reference Guide.
- One Infra-red Device Code List.
One LZ100 Charging Cradle.
- One Nickel Metal Hydride Battery Pack.
- One Power Adaptor.
- One USB Cable.
La-Z-Boy has evolved throughout their 75 year history
to become America's Number 1 furniture brand.
The new line of La-Z-Boy Universal Remote Controls
represents the perfect marriage of relaxation, comfort,
ease of use, quality and convenience when watching
television in your favorite La-Z-boy!
The La-Z-Boy Difference:
- Bilingual Consumer hotline available 24 hours/day,
7 days/week.
- Easy to follow quick reference guide.
- Comfortable rubber grips.
- Built in find feature Never lose your remote again.
- On-line programming with on-line tutorial.
- Rechargeable batteries.
- Charging cradle/Docking station.
-
6
Table of Contents
Product Diagram/Key Function Descriptions Page 2
Introduction/Package Contents Page 5
Table of Contents Page 6
Getting Started Page 7
Battery Installation & charging cradle
Information Page 8
How to find the Remote Page 10
How to set up your La-z-boy remote Page 11
oBy code entry
oBy code search
oBy Learning
oBy PC setup
How to operate your La-z-boy Remote Page 19
How to mute your La-z-boy Remote Page 19
Punch Though Page 20
Macro Power Page 22
How to Program the Smart Keys Page 23
Maintenance Page 24
Troubleshooting Page 25
Warranty Page 26

7
GETTING STARTED
A few helpful hints on terms used in this manual.
LR: La-Z-Boy Universal Remote Control
LED: The BLUE indicator light that flashes with an
infra-red command to your equipment.
Backlighting: The backlighting on the LCD
screen/keypad of your La-z-boy remote. Backlighting
turns on each time a key is pressed and will turn off 8
seconds after the last key is released.
Battery Low: If the battery meter located on the
bottom right corner of the LCD screen appears and
shows an empty battery, the battery pack needs to be
recharged. Place your LR on to the charging
cradle/docking station. The blue LED indicator blinks
continuously, and turns off when charging is complete.
Shift: The shift key allows you to access a second tier
of components with your remote. Please follow the
instructions in this manual.
LCD Screen: Your LR is equipped with a touchscreen
LCD display. Each programmed device has 3 pages to
scroll thru for access to all functions. Please use the
page scroll key located in the lower right hand corner of
the LCD screen, as indicated in this manual.
8
1. HOW TO INSTALL BATTERIES
- Take off the battery case cover,
then connect the battery connector
into the remote unit.
CAUTION ON BATTERY
- Be sure to use only the
rechargeable nickel metal-hydride
(Ni-MH) battery pack that is
supplied with the remote controller.
- When loading, be sure to properly attach the
rechargeable battery cable connector to the remote
control socket.
- Be sure to properly dispose of the rechargeable battery
pack in accordance with the guidelines (regulations)
for your local area.
REPLACING THE BATTERIES
The batteries in the Remote control
are Nickel Metal Hydride (Ni-MH)
batteries. It is advised to change the
batteries when the operation of your
LR becomes unreliable and is
unable to hold a charge.
If you want to order new batteries,
please contact customer service.
(1-888-229-1459)
Warning:
Replace the batteries only with an original LR battery
pack; otherwise the warranty is no longer valid and a
hazardous situation could occur.
1
2
1
2

910
1.1. HOW TO CHARGE BATTERIES
When it is first unpacked, the supplied battery pack is not
fully charged. Be sure to fully charge it before usage for a
minimum of 12 hours.
Connect with AC Adapter
Connect the AC adapter to the
charging terminal. The red
LED indicator on the cradle
will illuminate.
Resting on the Cradle
Put the remote unit on the
docking charger. Be sure to
align the contacts properly.
The blue LED indicator will
blink continuously to indicate
the LR is charging.
NOTES:
- When charging the remote control, be sure to
always use the suppliedAC adapter.
- Do not try to charge devices other than the
remote control with the supplied AC adapter.
This could damage the AC adapter or the
connected device.
1.2. HOW TO FIND THE REMOTE
- Press find key on the charging cradle. The red LED
indicator will flash 4 times.
- Your LR will emit a continous series of beep tones.
- Press any key on the LR once it is located to turn off
the beep tones. Note, the LR will emit a series of beep
tones for 60 seconds if no key is pressed and then turn
off.

1211
2. HOW TO SET UP YOUR LA-Z-BOY
REMOTE (LR)
2.1. By entering Device Code
You may setup your La-Z-Boy Remote (LR) by the
following code entering instructions.
2.1.1. Turn on your device (e.g. TV).
2.1.2. Refer to the LR Infra Red DEVICE CODE LIST;
look up the 4-digit Device Code which
corresponds to the brand of your A/V equ ipment.
If there are more than one Device Code listed
under your brand, try from the first code.
2.1.3. Press a desired Device Mode Key (e.g. TV).
Device name icon is displayed with a frame.
2.1.4. Hold down "CHANNEL+"and "VOLUME-"on
the LR simultaneously for 2 seconds until you hear
2 beep tones. The blue LED indicator lights
continuously.
2.1.5. Use the number keys 0-9 to enter your 4-digit
Device Code. The blue LED flashes twice if successful.
Then try the function keys (e.g. TV) on the LR. If your
device (e.g. TV) responds to your activated function
correctly, you have entered the right Device Code.
Otherwise, repeat the above setup with the next available
Device Code until your device (e.g. TV) responds to your
activated function, and most keys work correctly.
* Simply repeat the above procedures to enter the
Device Codes for your VCR, SAT, DVD and other
Devices. (Remember to press a correct Device Mode
Key in step 2.1.3 above). For set up of secondary
devices, press "SHIFT" followed by the desired
device key then follow steps 2.1.4-2.1.5 above.
Suggestion:
- If you cannot find a correct Device Code for your
equipment, refer to the section that follows: How To
Set Up The LR - By Searching Through the Library.
- For future reference it is recommended to make a note
of your Device Codes on the label provided at the
bottom of the charging cradle after setting up your LR
correctly.
2.2.By Searching Through the Library
If you cannot identify a correct Device Code for your
equipment from the Device Code list, you may search
through the code library:-
2.2.1. Turn on your device manually (e.g. TV).
2.2.2. Press a desired Device Mode Key (e.g. TV).
Device name icon is displayed with a frame.
2.2.3. Hold down "CHANNEL+"and "VOLUME-"on
the LR simultaneously for 2 seconds until you hear
2 beep tones. The blue LED indicator lights
continuously.
2.2.4. Enter a corresponding Search Code from following
table. The blue LED indicator should flash twice
and go out immediately.
(e.g. press TV device mode key, then press
"CHANNEL+"and "VOLUME-", and enter The TV
Search Code 0001.) The blue LED indicator should flash
twice and go out immediately.
2.2.5. Press the same desired device mode key again as in
step 2 above. (e.g. TV)
2.2.6. Hold down "CHANNEL+"and "VOLUME-"
together simultaneously again for 2 seconds until
you hear 2 beep tones. The blue LED indicator
lights continuously.
DEVICE
TYPE:
SEARCH
CODE:
TV
0001
VCR/
LASER
DISC
0002
SAT
0003
CABLE
0004
DVD
0005
AUDIO
0006
CD
0007
HOME
THEATER
0008

1413
2.2.7. Aim the LR at your device (e.g. TV); press the
""(power) key repeatedly every 1-2 seconds
until the device has been turned off. The blue
LED indicator will blink once each time you press
the " " (power) key to indicate your remote is
scrolling thru the code library. Once your device
has been turned off, immediately press the same
device mode key (e.g. TV) to lock in the search
code and the blue LED indicator will flash 3 times
and go out immediately.
* Simply repeat the above setup procedures to search
the Device Code for your VCR, SAT, DVD and other
Devices. (Remember to press a correct Device Mode
Key and correct Search Code in step 2.2.2-2.2.7 above).
* For set up of secondary devices, press "SHIFT"
followed by the desired device key then follow steps
2.2.3-2.2.7 above.
Note:
- The search process can take several minutes due to
the number of codes stored in the library.
- You cannot search through the code library for
DVR devices. This code must be entered
manually from the device code list.
Important:
During set up mode, the blue LED indicator will blink six
times and the set up procedure will be terminated if any
of the following conditions occur;
- No key has been pressed for more than 8 seconds.
- An invalid code number has been entered.
- An invalid key (not a numeric key) has been pressed.
You can press Smart 1, Smart 2 or Smart 3 to exit the
search mode at any time. The blue LED indicator will
blink six times to indicate your remote has exited the
search procedure.
....
....
Important:
When searching through the Library for some older
devices, if the power on/off function of your device is
not infra-red controlled you need to follow steps 2.2.2 to
2.2.6 above and start searching:
- Press " " (power) key and another important
function key alternately until your device responds to
the expected function, press the same device mode
key (e.g. TV) to lock in the code.
- Press " " (power) key & "CHANNEL+" alternately,
or;
- Press " " (power) key & "1" alternately.
Note:
- Each time you press the " " (power) key, the LR
will skip to the next code and send out a POWER
signal trying to turn off your device.
- If you failed to stop pressing the " " (power) key in
step 7 above and lock in the
code.
- If the blue LED indicator flash 6 times after you
pressed the " " (power) key, you are already at the
last code of the library.
- Besides device keys, " " (power) key and " "
(mute) key, all keys can be operated if the remote has
entered search mode.
time when your device has been turned off, turn on
your device again immediately. Before the blue LED
indicator goes out, press " " (mute) on the LR to skip
backward. Repeat the

15 16
3. HOW TO SET UP YOUR LA-Z-BOY
REMOTE (LR)
By Learning Commands
Your LR is equipped with learning capability. This
allows you to "teach" your LR certain functions from
your original equipment remote. Please follow the steps
below.
3.1. Press the desired device mode key (e.g. TV). The
device name icon is displayed with a frame.
3.2. Hold down "CHANNEL+"and "VOLUME-"on
the LR simultaneously for 2 seconds until to hear
2 beep tones. The blue LED indicator lights
continuously.
3.3. Enter the learning code "0", "0", "0", "0". The blue
LED indicator flashes once and then stays lit
continuously. The LR is now ready to learn
commands. An icon " " will also appear at the
bottom of the screen.
3.4. Place the LR and your device remote on a flat
surface, aimed at each other 1-3 inches apart.
3.5. Press a desired key once and release on the LR
which you want to learn the command. The blue
LED indicator will flash once on your LR and
stays lit continuously.
3.6. Press and keep holding the key on your original
equipment remote which you want to learn for a
few seconds.
3.7. When the blue LED indicator flashes twice and
stays lit continuously, the command has been
learned successfully and you can release t h e k e y
on your original equipment remote. If the blue
LED indicator flashes six times, it shows an error
in the learning process. Adjust the position of both
remotes and repeat from step 3.5 again.
3.8 Repeat from step 3.5 to learn other key functions,
or press the same device mode key on step 3.1 (e.g.
TV) to terminate the learning mode, the blue LED
indicator will flash twice and then go out
immediately.
Note:
- On step 3.5 if no key is selected for more that 8
seconds, the blue LED indicator will flash six times
and the learning mode will exit automatically.
- On step 3.6, if no other remote signal is received for
more than 8 seconds, the blue LED indicator flashes
six times and stays lit continuously, you need to select
a desired key again for learning as in step 3.5 on your
LR.
- Each function key will hold one command only, a new
command to be learned will automatically erase and
replace the previous one.
- If the device mode indicators flash three times during
the transference of signals, the maximum 100
commands memory bank is full, press the same
device key again to resume normal operation.
- All device mode keys, as well as the SHIFT, Smart 1,
Smart 2 and Smart 3 keys cannot be used for
learning functions.
Learn

1817
4. HOW TO SET UP YOUR LA-Z-BOY
REMOTE (LR)
By Teaching a dual signal
If you found a learned programmed key only works
occasionally, your device remote may contain dual
signals. Try the following steps to learn this command:
4.1. Follow the steps from 3.1 to 3.4.
4.2. Press a desired key once on your LR which you
want to learn the command.
4.3. Press and keep holding the key on your original
equipment remote which you want to learn for a few
seconds.
4.4. When the blue LED indicator flashes twice and then
stays lit continuously, the command has been
learned successfully and you can release the key on
your original equipment remote.
4.5. Press the same key on step 4.2 once on the your LR
again.
4.6. Press and keep holding the same key on your device
remote on step 4.3 until the blue LED indicator
flashes twice and then stays lit continuously. The
dual signal command has been learned successfully.
4.7. Repeat from step 4.2 to learn another key's dual
signal, or press the same device mode key on step
4.1 (e.g. TV) to terminate the learning mode. The
blue LED indicator will flash twice and go out
immediately.
Note:
- On step 4.2 or 4.5 if no key is selected for more than 8
seconds, the blue LED indicator will flash six times
and the learning mode will exit automatically.
- On step 4.3 or 4.6, if no IR signal is received for more
than 8 seconds, the blue LED indicator will flash six
times and stay lit, and you need to select a desired key
again for learning as in step 4.2 or 4.5.
5. HOW TO SET UP YOUR LA-Z-BOY
REMOTE (LR)
By PC SETUP
- Connect your LR to your PC via a USB connection.
- An icon showing " " will appear at the bottom of
the LCD screen.
- Press next to
continue.
5.2. Destination
confirmation
screen
- Press next to
continue.
5.3. Completion and
launch screen
- Press finish to
complete the
installation.
- Click "launch LR
online" to
immediately start
up the software.
- Visit www.lazboyremotes.com .
- Select "support", then "code download".
- Click the LR online image on the screen to download
the software interface.
5.1. A welcome screen
will pop up
USB

2019
6. OPERATING THE LA-Z-BOY
REMOTE (LR)
Normal Operation
6.3. The backlit keypad of the LR will turn OFF if no
key is pressed for 8 seconds.
6.4. Your LR controls up to 10 devices. Press each
device key directly to select the first 5. Press the
"SHIFT" key and then a device key to select
another 5. When accessing a device programed with
the shift key the device icon will change to indicate
the new device (i.e. when using shift then TV, the
device icon will change from TV to CD.)
6.5. To enable / disable the key tones sound, press and
hold "CHAN+" and " " keys on the remote
simultaneously for 2 seconds until the blue LED
indicator flashes. If it flashes once, the "beep"
sound is enabled, if it flashes twice, the "beep"
sound is muted.
6.1. Once you have setup up the LR for your A/V
equipment, it works like your original remote
controls. To operate, just aim it at your equipment,
and press any key to illuminate the display. Then
press an appropriate device mode key. You will hear
a beep tone as confirmation of key touch.
6.2. Use the shift button when attempting to access
secondary devices. Please refer to the Key
Function Description. After you press the "SHIFT"
key all functions will stay in shift mode. Press shift
again to exit this mode.
7. PUNCH THROUGH
You can activate certain functions like TV volume to be
operated in other modes such as SAT. This is referred to
as punch through. Please refer to the following
procedure for activating this function.
7.1. To activate the Punch through Channel setting:
7.1.1. Press and hold "CHANNEL+"and "VOLUME-"
keys on the remote simultaneously for 2 seconds
until you hear two beep sounds. The blue LED
indicator lights continuously.
7.1.2. Enter the punch through code "1", "1", "1", "0".
The blue LED indicator will flash once and lights
continuously.
7.1.3. Press desired device mode key. (e.g. TV)
7.1.4. Press "CHANNEL+" key.
7.1.5. Press desired channel code device mode key (e.g.
SAT).
7.1.6. The blue LED indicator will flash twice and
setting punch through mode will exit if the setting
is activated.
7.1.7. Example: SAT channel is activated on TV mode.
7.2. To deactivate the Punch through Channel
setting:
7.2.1. Press and hold "CHANNEL+"and "VOLUME-"
keys on the remote simultaneously for 2 seconds
until you hear two beep tones. The blue LED
indicator light continuously.
7.2.2. Enter the punch through code "1", "1", "1", "0".
The blue LED indicator will flash once and light
continuously.
7.2.3. Press desired device mode key. (e.g. TV)
7.2.4. Press "CHANNEL-" key.
7.2.5. The blue LED indicator will flash twice and
setting punch through mode will exit if the setting
is deactivated.
7.2.6. Example: Punch through Channel is deactivated in
TV device mode.

21 22
Note:
- If the same device mode key is pressed twice during
the activation process (7.1), the blue LED indicator
will flash six times, indicating the punch through
mode will exit and the punch through status will
remain unchanged.
- Setting channel in punch through mode will activate
both the "CHANNEL+"and "VOLUME-"key.
7.3. To activate the Punch through Volume setting:
7.3.1. Hold down "CHANNEL+"and "VOLUME-"keys
on the remote simultaneously for 2 seconds until
you hear two beep tones. The blue LED indicator
lights continuously.
7.3.2. Enter the punch through code "1", "1", "1", "0".
The blue LED indicator will flash once and light
continuously.
7.3.3. Press desired device mode key. (e.g. TV)
7.3.4. Press "VOLUME+" key.
7.3.5. Press desired device mode key (e.g. SAT)
7.3.6. The blue LED indicator will flash twice and
setting punch through mode will exit if the setting
is activated.
7.3.7. Example: SAT volume is activated on TV mode.
7.4. To deactivate the Punch through Volume
setting:
7.4.1. Hold down "CHANNEL+"and "VOLUME-"keys
on the remote simultaneously for 2 seconds two
beep sound. The blue LED indicator lights
continuously.
7.4.2. Enter the punch through code "1", "1", "1", "0".
The blue LED indicator will flash once and light
continuously.
7.4.3. Press desired device mode key. (e.g. TV)
7.4.4. Press "VOLUME-" key.
7.4.5. The blue LED indicator will flash twice and
setting punch through mode will exit if the setting
is deactivated.
7.4.6. Example: Punch through volume is deactivated in
TV device mode.
Note:
Setting volume in punch through mode will activate the
"VOLUME+", "VOLUME-" and " " keys.
8. MACRO POWER
The Macro Power allows you to turn a second device on
or off at the same time. Follow the steps below to activate
this function.
8.1. To activate the Macro Power setting:
8.1.1. Hold down "CHANNEL+"and "VOLUME-"keys
on the remote simultaneously for 2 seconds until
you hear two beep tones. The blue LED indicator
lights continuously.
8.1.2. Enter the macro power code "1", "1", "2", "0". The
blue LED indicator will flash once and light
continuously.
8.1.3. Press desired device mode key. (e.g. TV)
8.1.4. Press desired device mode key. (e.g. SAT)
8.1.5. The blue LED indicator will flash twice and
setting Macro power mode will exit if the setting
is activated.
8.1.6. Example: SAT Macro power is activated on TV
mode.
8.2. To deactivate the Macro Power setting:
8.2.1. Hold down "CHANNEL+"and "VOLUME-"keys
on the remote simultaneously for 2 seconds until
you hear two beep tones. The blue LED indicator
lights continuously.
8.2.2. Enter "1", "1", "2", "0" Macro power code. The
blue LED indicator will flash once and light
continuously.
8.2.3. Press desired device mode key. (e.g. TV)
8.2.4. Press " " key.
8.2.5. The blue LED indicator will flash twice and
setting Macro power mode will exit if the setting
is activated.
8.2.6. Example: Macro power is deactivated on TV
device mode.

2423
9. PROGRAM SMART KEYS
You can program a sequence of steps into your LR such
as turn on your TV, turn on your DVD player, turn on
your home theater receiver and press play on your DVD
payer to watch a movie. All in sequence. You can also
program a time delay in the sequence. Each smart key
can program up to 20 steps. Please refer to the following
procedure.
9.1. Hold down "CHANNEL+"and "VOLUME-"keys
on the remote simultaneously for 2 seconds until
you hear two beep tones. The blue LED indicator
lights continuously.
9.2. Enter the smart code "0", "0", "0", "9". The blue
LED indicator will flash once and light
continuously. An icon " " will appear at the
bottom of the LCD screen.
9.3. Press desired Smart key. (e.g. Smart 1)
9.4. Press a command from the corresponding device
mode and the blue LED indicator will flash once
each time you press a key.
9.5. Press and hold the command if you want to setup
the transmission period of this command (MAX
delay is 60 seconds).
9.6. Repeat 9.4 to 9.5 until you finish the whole
program and press the same SMART key (e.g.
SMART 1) to store the program.
9.7. To program another smart, repeat 9.1 to 9.6 above.
Note:
- The LR comes with 6 SMART programs - Smart 1,
Smart 2, Smart 3, Smart 4 (Shift + Smart 1), Smart 5
(Shift + Smart 2), Smart 6 (Shift + Smart 3) each with
a maximum of 20 steps.
- On step 9.4, if 20 steps have been entered, the setup is
saved automatically. Your LR will exit the smart key
programming mode.
Smart
- On step 9.4, if no key is selected for more than 8
seconds, the blue LED indicator will flash six times
and the smart key programming mode will exit
automatically.
- To operate a programmed smart key sequence, aim
your LR at the equipment. Press and release the
SMART key you have programmed.
10. RESET TO FACTORY DEFAULT
10.1. Hold down "CHANNEL+"and "VOLUME-"keys
on the remote simultaneously for 2 seconds until
you hear two beep tones. The blue LED indicator
lights continuously.
10.2. Enter the reset code "9", "9", "9", "9". The blue
LED indicator goes out immediately. All settings
are now cleared to factory default setting.
If your remote control is locked up for any reason,
you can reset it by pressing the reset button inside
the battery compartment. Please refer to below
illustration.
11. MAINTENANCE
- Do not expose your LR to dust, strong sunlight,
humidity, high temperature or mechanical shock.
- Be sure to use only the rechargeable nickel metal-
hydride (Ni-MH) battery pack that is supplied
with the remote controller.
- Do not use corrosive or abrasive cleaners on your
LR.
- Keep the unit dust free by wiping it with a soft dry
cloth.
- Do not disassemble your LR; it contains no user-
serviceable parts.
10.3.

2625
12. TROUBLESHOOTING
Q. My LR does not work at all!
A. Check your A/V device, if the device's main switch is turned off, your
LR can not operate your device.
A. Check if your battery pack is connected properly and has been
charged for a minimum of 12 hours. For details, please refer to section
1.
A. Check whether you have pressed the correct device mode key for your
device.
Q. If several Device Codes are listed under the brand of my A/V
device, how can I select the correct Device Code?
A. To seek the correct Device Code for you're A/V device, test the code
one by one until most keys work properly.
Q. My A/V equipment responds to only some of the commands.
A. You have set a code for which only some commands work properly
but some do not. Try other codes until most keys work properly or go
through the “By searching through the library” in section 3. Or you
may learn the functions from the original remote control (Please refer
to section 4). You can also set up the LR unit by inputting the AV
device model number from your computer after downloading the
software interface from the La-Z-Boy website
www.lazboyremotes.com. Please refer to section 6
Q. My combo device i.e. VCR/DVD can not be programmed using
the codes provided.
A. Try programming the devices individually i.e. first your VCR with the
VCR codes from the code list and then the DVD with the DVD Codes
from the code list. Or you can teach the LR by learning the functions
from the original remote control.
Q. I do not hear the beep tones when pressing keys on my remote.
A. You may have the keypad set to mute. Follow the steps in section 6.5.
Q. Some function keys on the remote do not operate your device.
A. Make sure the LR is set to the correct mode (ie TV)
A. The remote may not contain the code for your device. Try learning
the codes you need from your original equipment remote. Follow the
steps in section 4.
Q. I have a new home theater device and I can not find the code thru
code search and code entry.
A. Follow the How To Set Up Your La-Z-Boy Remote Thru PC Set Up in
section 5. This online interface is updated regularly with new codes.
Q. I am having difficulty accessing the online programming feature.
A. Make sure the internet connection is active
A. Make sure your LR is connected to your computer through the USB
cord provided
A. Make sure your computer meets the following system requirements:
IBM compatible with windows 98SE, 2000, ME, XP,Vista.
For help with set up call 1-888-229-1459 or visit
www.lazboyremotes.com for an on-line tutorial.
One Year Limited Warranty:
Elexa Consumer Products, Inc. ("ECP") warrants to the
original retail purchaser ("Purchaser") that the La Z
TM
Boy Touchscreen Control LZ6200 (the "Product") will
be free of defects in materials or workmanship under
normal use for one (1) year from the date of purchase
(the "Warranty Period").
For the Purchaser only, if the Product fails to perform as
specified during the Warranty Period due to defective
parts or faulty workmanship, ECP will repair or replace
the defective or damaged parts of the Product. Normal
wear and tear is not covered, nor is abnormal use, misuse,
mishandling, faulty installation, improper shipping,
damage caused by disasters such as fire, flood or
earthquake, neglect, accident or tampering. This
warranty covers only normal use in the United States and
Canada.
To obtain warranty service during the Warranty Period,
contact ECP Customer Service by telephone [phone]-
1459 between the hours of 12am and 11:59pm, or email
[email protected] for instructions on
sending damaged parts and documentation and for a
Return Material Authorization number (RMA). Products
returned to ECP for repair or replacement without
authorization will be returned to you at your expense.
All warranty claims must be accompanied by a legible
copy of the original receipt showing date and particulars
of purchase. The RMA number must be clearly written
on the side of the shipping container in which you return
the Product or defective parts. Unless otherwise
instructed by us, the Product must be sent freight prepaid
to the following address:
Elexa Consumer Products, 6200 N. Hiawatha Ave,
Chicago IL 60646
