LBX instruments INC-R User manual

LBX INC-R Refrigerated Incubator
Please read the User Manual carefully before use, and follow all operating and safety instructions!
user manual
english

2
User Manual
LBX INC-R Refrigerated Incubator
Preface
Users should read this Manual carefully, follow the instructions and procedures, and beware of all the cautions
when using this instrument.
Service
If help is needed, you can always contact your dealer or Labbox via www.labbox.com (declare an incident).
Please, provide the customer service representative with the following information:
•Serial number
•Description of the problem
•Your contact information
Warranty
This instrument is guaranteed to be free from defects in materials and workmanship under normal use and
service, for a period of 24 months from the date of invoice. The warranty is extended only to the original
purchaser. It shall not apply to any product or parts which have been damaged on account of improper
installation, improper connections, misuse, accident or abnormal conditions of operation.
For claim under the warranty, please contact your supplier.

3
Structural Features
1. The case is constructed from high-quality cold-rolled steel plate with a plastic coating on the surface.
2. Mirror-stainless working room, easy to clean, and with adjustable shelves.
3. Equipped with a Micro-Computer Temperature Controller and an Automatic defrosting system, along
with a large LCD screen.
4. Includes a temperature limited alarm system, over-temperature electric cutoff, and a timing function.
5. Utilizes an R134A compressor and fans.
6. Features double doors, with the inner door made of mirror stainless steel and a silicon seal, while the
outer door is magnetic silicon.
7. Includes a 50mm diameter test hole.
Product Specifications
Model
INCR-070-001
INCR-150-001
Voltage
220 –240V; 50Hz/60Hz
Temperature Range
0 –65 ºC
Temperature Motion
± 0.5 ºC
Temperature Uniformity
± 1.5 ºC
Cryogen
R134a (ca. 180 g)
R134a (ca. 200 g)
Power
800 W
1000 W
Inner Chamber Size
35 x 41.5 x 50 cm
40 x 49 x 75 cm
Exterior Size
56 x 57 x 103 cm
62 x 64 x 129 cm
Inner Chamber Temperature Distribution Map
Temperature
Point
Temperature
(ºC)
Temperature
Point
Temperature
(ºC)
①
36.63
⑤
36.91
②
36.93
⑥
36.86
③
37.50
⑦
36.88
④
37.33
⑧
36.64
⑨
37.15

4
Temperature Graph
Note: The specifications mentioned above have been tested in a 25 ºC environment.
Working Conditions
1. Ambient temperature: 5 –32 ºC (if the set temperature ≦10 ºC, ambient ≦28 ºC).
2. Humidity: ≦80 % RH.
3. Air Pressure: 80 –106 Kpa.
4. Ensure that the incubator remains stable (avoid shaking movements) and is not exposed to corrosive air.
5. Avoid exposure to light and maintain a controlled temperature environment.
6. Maintain a clear distance from dust, install the equipment horizontally, and ensure there is adequate
space between the equipment and the wall.
Safety Information
1. Upon receiving the equipment, to prevent compressor damage due to extended transportation, please
allow the machine to stand still for one day before use. Ensure equipment safety by installing external
protection and supplying power as required.
2. Avoid testing flammable, combustible, poisonous, or corrosive materials.
3. Install the equipment horizontally.
4. Disassembly and repair of the equipment should only be carried out by trained personnel.
5. If adding additional equipment to the chamber with a power consumption exceeding 2A, connect the
power externally; do not use the equipment's internal power.
6. When the chamber temperature is ≧50 ºC, refrain from setting low-temperature settings to ensure the
compressor's long-term usability.
7. Prior to operating the equipment, all users must read this manual.
Operation Cautions
1. There is a test hole at the top of the incubator. If you need to add additional equipment inside the
chamber, please use this hole.
2. If there is no need for U.V. light, turn off the U.V. lamp to avoid affecting the temperature.
3. Before activating the cooling function, dry the chamber for 1 hour at 50 ºC.
4. The chamber utilizes a vertical air circulation system. Do not overload the shelves with materials; the test
material should occupy less than 1/3 of each shelf.
5. When the test environment exceeds 35 ºC or the set temperature is above 50 ºC, refrain from setting the
low-temperature option.
6. Clean the chamber and the machine's surface with pure water. When the machine is not in use, please
disconnect the power supply, ensuring both the interior and exterior are clean and dry.

5
Controller Operation Instructions
1. Controller Specifications
•Temperature setting range: 0.0 –60.0 ºC
•Timer setting range: 0 –99 minutes 59 seconds
•Display error: < 0.5 %
•Sensor: PT100
2. Panel Instructions
3. Temperature-Time Operation
Example: setting the temperature to 30 ºC. Once reached, stop the instrument 5 hours later (T = 30 ºC; timer =
5 hours).
1. Click the set button to enter the temperature setting mode and set the temperature to 30 ºC using the up
and down keys.
2. Click the set button to enter the timer setting mode, change the hours from “0” to “5” using the up and
down keys. Once you need to set the minutes, follow the same steps.
When the timer is set to “0”, it means there is no timing function, and the incubator runs continuously.
When the timer is not set to “0”, once the inner chamber temperature reaches the set temperature, the
timer will start. When the time expires, the machine will stop. When it stops, the light will turn on, and the
buzzer will sound for 30 seconds. Press the down key for 4 seconds, and the system will start working
again. When the buzzer sounds, press any key to stop the sound.
3. Illumination: click the illumination button to turn it on and click it again to turn it off.

6
4. Inner Chamber Specification Setting
Press the set button for more than 3 seconds, and the screen will display “LC.”Change the number to “3”using
the up and down keys, then click the set button again to access the parameters. By clicking the set button, you
can navigate through the parameters in the following table and modify each specification. Press the set button
for 3 seconds to exit the settings; the specifications will be saved automatically. If no button is pressed for 30
seconds, it will exit the settings automatically without saving the specifications.
Internal Parameters
Parameter
Name / Function
(Range)
Factory Specification
Lc
Password: “Lc=3”allows to modify the specification.
P--
Proportional band: time-proportional adjustment function: decreasing P
heats quickly, increasing P reduces over-adjustment.
(2.0 –25.0)
15.0
AL--
Over-temperature display error alarm: When “PV < SP+Al”, the buzzer
will sound, and refrigeration will be activated.
(0.0 –20.0)
3.0 ºC
CT--
Compressor operating delay: compressor delay protection time, operates
twice after a time >= cT minutes.
(0.0 –10.0 min)
3 min
Up--
Heating refrigeration backlash: in manual mode, when “PV >= SP+uP”
and the compressor delay time is up, the compressor will start.
(-50.0 –50.0)
0.2
Dn--
Cooling refrigeration backlash: in manual mode, when “PV <= SP+dn,”
the compressor will shut down.
(-51.0 –uP-0.1）
0
T--
Control cycle
(1 –60 sec)
5
P--
Proportional band
(1.0 –measurement
value)
35
I--
Integration time
(1 –1000 sec)
200
d--
Differential time
(1 –1000 sec)
200
Pb--
“0”adjustment: sensor zero display error adjustment. Pb = actual
temperature-display number.
(-9.9 –9.9)
0.0
Pk--
Full adjustment: sensor full error adjustment. PK = 1000 * (actual
temperature-display number) / meter test number.
(-999 –999)
0
Note:
1. To ensure precise results, you can adjust P (within the range of 10.0 –20.0), but generally, it should
not require any changes. Please use the factory specifications.
2. If there is a display error, typically, you should adjust Pb and not PK.

7
Check Ambient Temperature
Press the set button for more than 3 seconds; it will display “LC.”Change it to “18”using the up and down keys.
Click the set button, and the screen will show the ambient temperature. Press the set button for 3 seconds to exit
this screen, and the specification will be saved automatically. If no button is pressed for 30 seconds, it will exit
the settings automatically and will not retain the specification.
Parameter
Name
Function
(Range)
Factory Value
Lc-
Password
When “LC=18”is displayed, it is possible to
check the ambient temperature.
Hd-
Ambient Temperature
Compressor Operating Mode and Frost-Related Parameters
Press the set button for more than 3 seconds; it will display “LC”. Change it to “123”using the up and down
keyboard. Click the set button to check the internal parameter value. Press the SET key to change parameters,
use the up and down arrows to modify each parameter value, and then click the SET button for more than 3
seconds to exit this screen; the specification will be saved automatically. If no button is pressed for 30 seconds, it
will exit the settings automatically and will not retain the specification.
Parameter
Function
(Range)
Factory Value
Lc
“Lc=123”allows to view and modify each parameter.
S-H
When the "ambient temp.-SH" is greater than the temperature setting
value, the compressor operates in the normally open mode. Conversely,
the compressor shuts off.
Note: when “S-H=50.0”, the compressor does not operate.
(-20.0 –50.0)
40.0
Ft-
Fan delay: stops the fan when there is frost; after frost melts, the fan
delays for Ft seconds before starting.
(0 –99 s)
50 s
dt1
SP ≤15 ºC frost interval 1
(0 –250 hours)
12 hours
Hs1
Frost melting output 1
(0 –250 s)
60 s
dt2
15 ºC < SP ≤30 ºC frost interval 2
(0 –250 hours)
12 hours
Hs2
Frost melting output 2
(0 –250 s)
55 s
HA
Automatic compressor operation: 1 is for automatic compressor control
based on ambient temperature, and 0 is for controlling the compressor
using uP and dn.
(0 –1)
1
cH
Frosting and evaporator switching options: 0 for frosting, 1 for evaporator
switching.
(0 –1)
0

8
Fault Analysis
Problem
Cause Analysis
Solution
Power button is not lighting up
No power
Inspect the plug
Broken fuse
Change the fuse
Temperature controller displays
“□□□□”
Broken sensor
Change the sensor
Broken controller
Change the controller
Evaporator frost or chamber with
frost
Frequent opening of the door
during low-temperature tests
If the temperature exceeds 50
degrees, dry the chamber and
reduce the frequency of opening
the door
Poor seal on the left hole
Inject rubber into the inner hole
Door left open
Close the door
Difficulty in reducing the
temperature
Evaporator frost
Dry the chamber
Environment temperature too high
Lower the environmental
temperature
Malfunctioning fan
Check the fuse and the fan
Compressor not working
Replace the compressor
Compressor working, but
refrigeration is not
Check the cryogen
Check for ice or oil blockages
Mixed specifications
Ensure correct settings and restart
Continuous increase in temperature
Evaporator frost
Dry the chamber
Abnormal knocking
Loose circulation fans
Inspect and adjust
Loose condenser, fan and
compressor
Inspect and adjust, or contact with
your supplier
Poor temperature evenness
Hot sample
Reduce the sample quantity
Evaporator frost and wind
blockage
Dry the chamber and restart
Controller instability
Power mismatch
Change the power source
Voltage instability
Ensure voltage stability
Difficulty in raising the temperature
Over-temperature setting too low
Correct the temperature setting
Meter setting too low
Set the temperature correctly
Meter heating director on, but
without input function
Change the meter
Meter heating, but the heater does
not work
Change the heater
Fan does not work
Change the fan or fuse
Broken sensor
Change the sensor
Temperature exceeds the set value
Incorrect meter setting
Reset and refer to the manual
Heater working, but does not stop
Replace the controller

9
