Labconco Protector 3390000 User manual

ProtectorBenchtop Evidence
Drying Cabinets
Models
3390000
3390001

Copyright © 2018 Labconco Corporation. The information contained in this manual and the
accompanying products are copyrighted and all rights reserved by Labconco Corporation. Labconco
Corporation reserves the right to make periodic design changes without obligation to notify any person
or entity of such change.
Returned or Damaged Goods
Do not return goods without the prior authorization from Labconco. Unauthorized returns will not be
accepted. If your shipment was damaged in transit, you must file a claim directly with the freight
carrier. Labconco Corporation and its dealers are not responsible for shipping damages.
The United States Interstate Commerce Commission rules require that claims be filed with the delivery
carrier within fifteen (15) days of delivery.
Limitation of Liability
The disposal and/or emission of substances used in connection with this equipment may be governed by
various federal, state, or local regulations. All users of this equipment are required to become familiar
with any regulations that apply in the user’s area concerning the dumping of waste materials in or upon
water, land, or air and to comply with such regulations. Labconco Corporation is held harmless with
respect to user’s compliance with such regulations.
Contacting Labconco Corporation
If you have questions that are not addressed in this manual, or if you need technical assistance, contact
Labconco’s Customer Service Department or Labconco’s Product Service Department at 1-800-821-
5525 or 1-816-333-8811, between the hours of 7:30 a.m. and 5:30 p.m., Central Standard Time.
Part #3390700, Rev. D
ECO L479
Warranty
Labconco Corporation provides a warranty to the original buyer for the repair or replacement of
parts and reasonable labor as a result of normal and proper use of the equipment with compatible
chemicals. Broken glassware and maintenance items, such as filters, gaskets, light bulbs, finishes
and lubrication are not warranted. Excluded from warranty are products with improper
installation, erratic electrical or utility supply, unauthorized repair and products used with
incompatible chemicals.
The warranty for Protector®Benchtop Evidence Drying Cabinets will expire one year from date
of installation or two years from date of shipment from Labconco, whichever is sooner. Warranty
is non-transferable and only applies to the owner (organization) of record.
Buyer is exclusively responsible for the set-up, installation, verification, decontamination or
calibration of equipment. This limited warranty covers parts and labor, but not transportation and
insurance charges. If the failure is determined to be covered under this warranty, the dealer or
Labconco Corporation will authorize repair or replacement of all defective parts to restore the unit
to operation. Repairs may be completed by 3rd party service agents approved by Labconco
Corporation. Labconco Corporation reserves the rights to limit this warranty based on a service
agent’s travel, working hours, the site’s entry restrictions and unobstructed access to serviceable
components of the product.
Under no circumstances shall Labconco Corporation be liable for indirect, consequential, or
special damages of any kind. This warranty is exclusive and in lieu of all other warranties
whether oral, or implied.

T
TA AB BL LE E O OF F C CO ON NT TE EN NT TS S
CHAPTER 1: INTRODUCTION 1
CHAPTER 2: PREREQUISITES 2
Space Requirements 2
Clearance 2
Location Requirements 3
Exhaust Requirements 3
Electrical Requirements 3
CHAPTER 3: GETTING STARTED 4
Unpacking the cabinet 4
Preparing the Evidence Drying Cabinet for Operation 5
Initial Operation 6
CHAPTER 4: PERFORMANCE FEATURES AND SAFETY
PRECAUTIONS 7
Directional Airflow 8
Optional Evidence Prefilters 9
Prefilters 9
HEPA Filters 9
Blower 10
Cabinet Air Intake and Exhaust 10
Ultraviolet (UV) Lamp 10
Safety Precautions 11-12
CHAPTER 5: USING THE CABINET 13
Fan/UV Light Switch 13
UV Security Lock 13
Filter System Light 13
Shelf Operation 14
Drying in the Cabinet 15-16

CHAPTER 6: MAINTAINING THE CABINET 17
Routine Maintenance Schedule 17
Service Operations 18
Door Evidence Prefilter Replacement 18
Door Prefilter Replacement 18
Cabinet Evidence Prefilter Replacement 19
Cabinet Prefilter Replacement 19
Granular Activated Carbon and HEPA Filter Replacement 20
Changing the UV Lamp 21
Resetting a Circuit Breaker 22
Setting the Speed Control 22
CHAPTER 7: TROUBLESHOOTING 23-24
APPENDIX A: COMPONENTS 25
APPENDIX B: DIMENSIONS 26
APPENDIX C: SPECIFICATIONS 27
APPENDIX D: ACCESSORIES 28-29

Product Service 1-800-522-7658
1
C
Ch ha ap pt te er r 1 1: :
I
In nt tr ro od du uc ct ti io on n
Congratulations on the purchase of a Labconco Protector Evidence Drying
Cabinet. The cabinet is designed to protect you, and the room environment
from biohazardous aerosols and offensive odors while drying evidence. The
Protector Series cabinet is the result of years of experience in manufacturing
laboratory equipment, and users like you suggested many of its features to us.
The Evidence Drying cabinet models offer many unique features to enhance
performance and flexibility. To take full advantage of them, please acquaint
yourself with this manual and keep it handy for future reference. If you are
unfamiliar with how evidence drying cabinets operate, please review Chapter
4: Performance Features and Safety Precautions before you begin using the
cabinet. Even if you are an experienced cabinet user, please review Chapter
5: Using the Cabinet; it describes the cabinet’s features so that you can use it
efficiently.
This manual and other technical information is available in PDF format
at our website: www.labconco.com.

Product Service 1-800-522-7658
2
C
Ch ha ap pt te er r 2 2: :
P
Pr re er re eq qu ui is si it te es s
Before you install the evidence drying cabinet, you need to plan the site for
installation. Examine the location where you intend to install the cabinet.
You must be certain that the area is level and of solid construction. In
addition, a source of electrical power must be located near the installation
site.
Carefully read this chapter to learn:
Location requirements.
Electrical power requirements.
Exhaust requirements.
Service utility requirements.
Space requirements.
Refer to Appendix C: Specifications, for complete cabinet electrical and
environmental conditions, specifications and requirements.
Space Requirements
The dimensions for the evidence drying cabinet are shown in Appendix B:
Dimensions.
Clearance
A minimum clearance of at least 6 inches (150 mm) is suggested on the top
of the cabinet for service. There should be 36 inches (914 mm) clearance at
the front of the cabinet to allow the door to swing open without hitting any
obstructions.

Chapter 2: Prerequisites
Product Service 1-800-522-7658
3
Location Requirements
Note: The cabinet is equipped with leg levelers to ease level cabinet
installation. It should be located on a flat surface for proper cabinet
alignment and door operation.
Exhaust Requirements
If you intend to connect the cabinet to the optional Exhaust Connection Kit,
first examine the location to ensure that it accommodates the cabinet’s
exhaust duct. The area directly above the cabinet’s exhaust port should be
clear of structural elements, water and utility lines, or other fixed
obstructions. There should be enough clearance to accommodate a 5-inch
diameter duct. For further information about the cabinet’s exhaust system
requirements, please refer to Appendix D: Accessories.
Electrical Requirements
The evidence drying cabinet models have the following electrical
requirements:
Model #
Requirements
33900-00
115 VAC, 60 Hz, 6 Amps
33900-01
230 VAC, 50/60 Hz, 3 Amps
Note: An outlet with a circuit breaker rated at 10 amps for 115 volt
models (5 amps for 230 volt models) should be located as close as possible
to the right rear side of the cabinet. Power cords supplied with the
Evidence Drying cabinet are 3 meters (10 feet) long.
Table 2-1

Product Service 1-800-522-7658
4
C
Ch ha ap pt te er r 3 3: :
G
Ge et tt ti in ng g S St ta ar rt te ed d
Now that the installation site is properly planned, you are ready to inspect
and install the Protector evidence drying cabinet. This chapter covers how to:
Unpack and move the cabinet.
Install the cabinet.
Connect the electrical supply source.
Tools required for installation the cabinet include two 1/2" wrenches, a flat-
blade screwdriver, a #2 Phillips screwdriver, , scissors, or a box knife.
Note: The cabinet weighs approximately 250 lbs. (114 kg). The shipping
pallet allows for lifting with a mechanical lift truck or floor jack. If you must
lift the product manually, use at least three (3) persons and follow safe-lifting
guidelines.
Unpacking the Cabinet
Carefully remove the outer carton and inspect the cabinet for damage that
may have occurred in transit. If the cabinet is damaged, notify the delivery
carrier immediately and retain the entire shipment intact for inspection by the
carrier.
Note: United States Interstate Commerce Commission rules require that
claims be filed with the delivery carrier within fifteen (15) days of delivery.
Do not return goods without the prior authorization of Labconco.
Unauthorized returns will not be accepted.
If the cabinet was damaged in transit, you must file a claim directly with the
freight carrier. Labconco Corporation and its dealers are not responsible for
shipping damages.

Chapter 3: Getting Started
Product Service 1-800-522-7658
5
Do not discard the carton or packing material for the cabinet until all of the
components have been checked, installed and tested.
The cabinet is secured to the pallet using four (4) bolts. To remove the
cabinet, remove four (4) bolts from underneath top skid boards that are
holding the cabinet to the skid. You do not need to save these bolts and
washers. In the clear plastic bag inside the cabinet, are four (4) leg levelers.
Screw these into the holes the bolts came out of before removing the cabinet
from the pallet.
The cabinet is now ready to be removed from the pallet.
After removing the cabinet from the pallet, carefully remove plastic wrapping
around the cabinet, and open the cabinet door. Locate the two transport
brackets attached to the face of the cabinet liner. Using a #2 Phillips
screwdriver, remove the screws securing the brackets, discard the brackets,
and reinstall the screws.
Preparing the Evidence Drying Cabinet for
Operation
After the evidence drying cabinet has been removed from its pallet and
positioned in its final location, you must:
1. Remove the tie and/or tape securing the door, and the filters on top of
the unit.
2. Ensure that the transport brackets have been removed from the front
of the cabinet liner.
Note: The following are located in a box in the cabinet:
User’s Manual
UV Security Lock Key(s) (model #s 34000-00, -04 only)
Power Cord
Product Registration Card
If you did not receive one or more of the components listed for the
cabinet, or if any of the components are damaged, contact Labconco
Corporation immediately for further instructions.
3. Using a step ladder, remove the tape and/or packaging material
around the top of the unit.
4. Plug the power cord into the back of the cabinet, and then into an
appropriate outlet. Install the Key into the UV Security lock on the
upper panel on those models equipped with a UV light.

Chapter 3: Getting Started
Product Service 1-800-522-7658
6
Initial Operation
Prior to use with evidence, you should perform the following operational
tests to ensure the cabinet is operating properly:
Airflow Smoke Pattern Test
With the cabinet fan ON, introduce smoke (from a cigarette,
chemical smoke stick, etc.) into the prefilter at the bottom of
the door. The smoke should flow directly into the cabinet, and
then into the upper prefilter located at the top of the cabinet
liner. The smoke should move from the door to the intake
prefilter in approximately 5 seconds or less. If the smoke does
not flow as described, see the “Adjusting the Fan Speed”
section of Chapter 6.
UV Light and Interlock Tests
With the door closed, turn the “Fan/UV Light” switch to “UV”
and the “UV Security Keylock to “ON”. The UV light will
then turn on. Open the door, and the UV light will turn off.
Close the door, and the UV light should relight. Turn the UV
Security Keylock to the “OFF” position, and the UV light will
turn off. If the UV light does not work as described, call
Labconco’s Product Service Department at 1-800-522-7658 or
816-333-8811.

Product Service 1-800-522-7658
7
C
Ch ha ap pt te er r 4 4: :
P
Pe er rf fo or rm ma an nc ce e F Fe ea at tu ur re es s a an nd d
S
Sa af fe et ty y P Pr re ec ca au ut ti io on ns s
The Protector evidence drying cabinet operates using the following
principles:
Directional airflow.
Prefiltration of large particulates by an inlet prefilter (in the door) and
an exhaust prefilter (in the top of the liner).
Filtration and retention of particulates by a High Efficiency
Particulate Air (HEPA) filter.
Adsorption of organic (odorous) chemicals by a granular activated
carbon filter.
The major components in the cabinet are:
The prefilters
The blower to force air through the cabinet
The HEPA filter
The granular activated carbon filter

Chapter 4: Performance Features and Safety Precautions
Product Service 1-800-522-7658
8
Directional Airflow
Directional airflow plays a critical role in evidence drying cabinet
performance. Air is drawn into the inlet prefilter, located on the bottom of the
door. The filtered air then flows upward through the liner, passing over the
evidence to be dried. Before leaving the liner, the air then passes through the
exhaust prefilter, that is designed to protect the HEPA filter from large
particulates, and may be removed to examine it for the collection of evidence.
The air is pressurized by the blower, and then forced through the HEPA and
carbon filters, to remove biohazardous particulates and odorous chemicals,
respectively. This is illustrated in Figure 4-1.
Figure 4-1

Chapter 4: Performance Features and Safety Precautions
Product Service 1-800-522-7658
9
Optional Evidence Prefilters
Optional Evidence Prefilters can be fitted on the inside (cabinet side) of the
door prefilter (located on the front of the door) and cabinet prefilter (located
on the inside top of the liner). These thin prefilters are designed for single-
use, to be removed after the evidence has dried. After removal, the Evidence
Prefilters can be examined for trace evidence, or stored with the evidence in a
sealed bag for future reference. See Appendix A for reorder part numbers.
Prefilters
Both the door prefilter (located on the front of the door) and cabinet prefilter
(located on the inside top of the liner) are disposable, polyester particulate
filters. Both filters have a Minimum Efficiency Reporting Value (MERV) of
11, meaning they remove 65-79% of particles 1.0-3.0 microns in size, and
more than 85% of particles 3.0-10 microns in size. See Appendix A for
reorder part numbers.
HEPA Filters
HEPA filters are disposable, dry-type particulate filters. The filter material or
media is typically made of borosilicate microfibers formed into a thin sheet,
in a process similar to the production of paper. This sheet is folded, or pleated
to increase its surface area. The pleats are held in place by aluminum
diffusers or by beads of glue that add rigidity to the media pack. The pack is
then set into a frame, and sealed as shown in Figure 4-2.
The HEPA filter manufacturer establishes the efficiency of the filter by
challenging it with an aerosol of known particle size. The number of particles
that penetrate the filter are quantified, and this establishes the efficiency of
the filter. The filters used in the evidence drying cabinets are at least 99.99%
efficient in removing particles 0.3 micron.
Note: The HEPA filter media is very fragile. DO NOT touch the media.
If you think the media of a HEPA filter is damaged, DO NOT USE THE
CABINET. Call Labconco’s Product Service Department at 1-800-522-7658
or 816-333-8811.
Note: HEPA Filters are only effective against particulate material. Gases
will pass through the filter.
Figure 4-2
Polyurethane seal
Between media pack
and filter frame
Filter frame
Filter media pack –
A continuous sheet
of filter media

Chapter 4: Performance Features and Safety Precautions
Product Service 1-800-522-7658
10
Blower
The blower assembly pulls room air into the intake prefilter on the front of
the door, through the liner and exhaust prefilter, and then forces it through the
HEPA and granular activated carbon filter. The evidence drying cabinet uses
a motorized, backward curved fan for quiet, energy efficient operation.
Cabinet Air Intake and Exhaust
In order to operate properly, the air intake at the bottom of the door, the
exhaust prefilter area in the top of the liner, and the top surface of the
activated carbon filter must be unobstructed. Blocking or restricting any of
these areas, or allowing the prefilters to become excessively loaded with dust
can adversely affect the performance of the cabinet.
Ultraviolet (UV) Lamp
The optional UV lamp generates a primary wavelength of light of 254nm. A
secondary emission is in the visible (blue) wavelength, resulting in the
characteristic blue color while operating. UV light with a wavelength of 254
nm is biocidal, primarily by creating thymine dimers in DNA. These dimers
prevent the correct transcription of the DNA into RNA, resulting in cellular
death or viral inactivation. In order to be effective, the UV light must directly
strike the nucleic acid, and its effectiveness can be diminished or negated by
dissolved proteins or metals, or by other UV-opaque substances protecting
the target nucleic acid.
Because of its limitations, UV light should be used as an adjunct to good
surface disinfection practices. In order to get optimum performance from the
UV light, it should be replaced after 6,000 hours of operation or less, and the
exterior surface of the lamp should be kept clean and free of dust.
Note: UV irradiation is absorbed by the tempered safety glass of the door.
Independent research has shown that the level of UV irradiation on the
outside of the cabinet’s door is equal to background radiation levels.
Note: The UV sensitivity of a target organism varies, depending on the UV
output of the lamp, the genus and species of the organism, the medium the
agent is suspended in, etc. Contact the Health and Safety Officer at your
facility for UV light use and recommendations.

Chapter 4: Performance Features and Safety Precautions
Product Service 1-800-522-7658
11
Safety Precautions
For all models:
NEVER expose ANY EVIDENCE, plastic or coated materials to ultraviolet
(UV) radiation. Never bypass the UV safety interlock that only allows the
UV light to work when the door is closed. UV exposure to the skin is
hazardous and can result in serious eye or skin injury.
Ensure that the cabinet is connected to electrical service in accordance with
local and national electrical codes. Failure to do so may create a fire or
electrical hazard. Do not remove or service any electrical components
without first disconnecting the cabinet from electrical service.
NEVER use this cabinet as a chemical storage cabinet.
When handling evidence, or working in the cabinet, always wear appropriate
personnel protective equipment.
NEVER attempt to dry evidence containing flammable gases or solvents in
the cabinet. An open flame should NOT be used in the cabinet.
HEPA filters only remove particulate matter. Operations generating volatile
toxic chemicals are prohibited. The media of the filter is fragile and should
not be touched. Avoid puncturing the HEPA filter during installation or
normal operation. If you suspect that a HEPA filter has been damaged, DO
NOT use the cabinet; contact Labconco at 800-821-5525 or 816-333-8811 for
further information.
The HEPA filters in the cabinet will gradually accumulate airborne
particulate matter from the items placed in the cabinet. The rate of
accumulation will depend upon the cleanliness of the air, operating time and
the nature of items being dried in the cabinet.
Do not operate the cabinet without all of the appropriate filters in place. If an
odor is detected coming out of the granular activated carbon, it needs to be
replaced.
The weight limit for the fold down shelves is 15 lbs (6.8 kg), and the floor of
the cabinet and lower storage area is 20 lbs (9.1 kg).
When surface disinfecting the cabinet:
Always wear appropriate personnel protective equipment.
NEVER use high pressure water to clean the liner; this practice could
generate biohazardous aerosols.
NEVER spray disinfectants into the blower intake at the top of the
liner; this may damage the blower.
Avoid splashing the disinfecting solution on skin or clothing.
Ensure adequate room ventilation.
Carefully follow the disinfectant’s safety instructions.

Chapter 4: Performance Features and Safety Precautions
Product Service 1-800-522-7658
12
Always dispose of disinfecting solutions in accordance with local and
national laws.
DO NOT allow bleach or disinfectants with high concentrations of
free chlorine to contact the stainless steel components of the
cabinet for a long period of time. Free chlorine will corrode
stainless steel after extended contact.
When handling used filters or prefilters, always wear appropriate personnel
protective equipment.

Product Service 1-800-522-7658
13
C
Ch ha ap pt te er r 5 5: :
U
Us si in ng g t th he e C Ca ab bi in ne et t
Fan/UV Light Switch
The cabinet Fan/UV Light switch is located on the upper front of the cabinet,
as shown in Figure 5-1. Turning the switch to the “Fan” position starts the
blower, drawing air into through the cabinet. Turning the switch to the “UV
On” position will allow the UV light to turn on when the door is closed and
the UV Security lock is in the “ON” position.
UV Security Lock
The UV security lock, located to the right of the Fan/UV Light switch, allows
the user to lockout the UV, preventing its operation. Before evidence is
loaded into the cabinet, it is recommended that the lock be turned to the
“OFF” position, and the key removed. This will prevent the accidental
activation of the UV light while evidence is drying. The key should be stored
in a convenient, secure location, known to all of the users to prevent its loss.
Recommended locations include hanging from the bar at the top of the liner,
or in the lower storage area.
Filter System Light
The Filter System Light will illuminate if the differential pressure across the
filters becomes excessive. If lit, first inspect or replace the two prefilters. If lit
with clean prefilters, replace the HEPA filter.
NOTE: If the Filter System Light illuminates during use, finish the drying of
the evidence in the cabinet, and then correct the problem before using the
cabinet again.

Chapter 5: Using The Cabinet
Product Service 1-800-522-7658
14
Shelf Operation
The three drying shelves on the left side wall can be positioned horizontally
to dry small pieces of evidence, or swung down, against the left side wall of
the liner, if needed. To position the shelves in the up (horizontal) position:
1. Pivot the desired shelf until it is above horizontal (the frame of the
shelf is higher than the retaining clip on the back wall of the liner.
2. Push the shelf back all the way.
3. Slowly lower the shelf to a horizontal position, ensuring that the
frame of the shelf engages the retaining clip on the back wall of the
liner. The shelf is now ready to use.
To fold the shelf down (vertical position):
1. Lift up on the rear frame of the shelf, to release it from the rear
retaining clip.
2. Pull the shelf towards the front of the liner.
3. Allow the shelf to swing down into a vertical position.
Figure 5-1

Chapter 5: Using The Cabinet
Product Service 1-800-522-7658
15
Drying in the Cabinet
Start-up
Turn off UV light and turn the UV Security switch to “OFF”. Remove
the key, and store it in a safe place.
Turn the switch to “Fan”.
Check the condition of the prefilters. If your protocol requires the use
of evidence prefilters, ensure a new set of both door and cabinet
prefilters has been properly installed, according to the instructions in
Chapter 6: Maintaining Your Cabinet. Note if the Filter System light
is on.
Wash hands and arms thoroughly with germicidal soap.
Wear a long sleeved lab coat with knit cuffs and over-the-cuff rubber
gloves. Use protective eyewear. Wear a protective mask if
appropriate.
Wipe-Down
Open the door to its full open position.
Wipe down the interior surfaces of the cabinet with 70% ethanol, or a
suitable disinfectant, and allow to dry.
CAUTION: Do not use bleach on the stainless steel liner. Use
disinfectants compatible with stainless steel.
Loading Evidence
Load the evidence so that air flows around all surfaces of it. Do not
overload the cabinet. Do not place objects directly against the side
walls.
Do not obstruct the intake prefilter (bottom of the door) or the exhaust
air discharge, on top of the cabinet.
Large objects should not be placed close together.
Slowly close the door and use a padlock (not supplied), or secure it
with a chain of custody seal.

Chapter 5: Using The Cabinet
Product Service 1-800-522-7658
16
Unloading Evidence
Wear a long sleeved lab coat with knit cuffs and over-the-cuff rubber
gloves. Use protective eyewear. Wear a protective mask if
appropriate.
Carefully remove objects in the cabinet. Evidence that was considered
biohazardous when loaded should be handled as biohazardous. If your
protocol required the use of evidence prefilters, remove them now and
store them appropriately.
Wipe-Down
Wear a long sleeved lab coat with knit cuffs and over-the-cuff rubber
gloves. Use protective eyewear. Wear a protective mask if
appropriate.
Wipe down the interior surfaces of the cabinet with 70% ethanol, or a
suitable disinfectant, and allow to dry.
Inspect and clean the prefilters at the bottom of the door, and at the
top of the liner.
Dispose of rubber gloves appropriately, and have lab coat laundered
properly.
Wash hands and arms thoroughly with germicidal soap.
Shutdown
Close the door. If UV disinfection is desired, insert the UV Security
Lock Key, and turn it to the “ON” position. Turn the Fan/UV Light
switch to “UV”. The UV light will light.
Turn the UV Light off after an appropriate disinfection time, typically
1-8 hours.
Shutdown
Close the door and push the switch to the center “Off” position.
