Leader Fox STC-8108LC User manual
Instructions for using
LI-ION battery charger
KunShan ST Electronics CO., LTD, NO. 198, HuaTao Road, QianDeng, KunShan, China –
www.stchargers.com
Connector type
GW battery DLG battery
Charger description
Model –STC –8108LC
Input –220-240VAC, 50Hz, 140W
DC output –36V/3A
-Use the charger for charging rechargeable Li-Ion 36V batteries.
-The charger is protected against return current
-The charger is protected against reversing poles
-The charger is protected against over-voltage
-The charger is protected against short circuit
Charger use
-Connect the charger with battery carefully and plug the charger into a socket
-The charger uses constant current and voltage.
-Charging battery to full capacity may last for 4 –8 hours.
-Disconnect the charger at first after the battery recharging and disconnect the battery then only.
-Two LEDs, green and red, light up after the charger is connected to the mains.
-The charging process starts after the battery is connected and both LEDs light-up red.
-One LED is green again after the battery is 100% recharged.
Warning
-Keep charger away from children and pets.
-Charge the battery in a dry environment to avoid short-circuit damage.
-Do not cover the battery or the charger at charging up.
-Do not leave the battery connected to the power source constantly .
-Use the charger only to charge the battery.
-Do not disassemble or modify the battery cover.
-Do not throw the battery into fire or expose it to extreme temperatures.
-Do not use the charger when it is visibly damaged. It may lead to its destruction.
-Do not use solder for direct connection of the battery or cables, because bursting or inflammation
may occur.
-Do not try to deform the charger or modify it in any way.
-Do not expose the charger to impacts or vibrations.
-Do not insert metallic objects into the charging socket, because overheating, bursting or
inflammation may occur.
-Contact your seller in case of uncertainties or suspicious behaviour of the charger
Enjoy many pleasant and safe kilometres on your new electric bicycle.
Your Leader Fox Team
