Skil PWRCORE 20 BY519702 User manual

1-877-SKIL-999 OR www.skil.com
For Customer Service
Pour le service à la clientèle
Servicio al cliente
WARNING: To reduce the risk of injury, the user must read and understand the
Owner’s Manual before using this product. Save these instructions for future reference.
AVERTISSEMENT : Afin de réduire les risques de blessure, l’utilisateur doit lire et
comprendre le guide d’utilisation avant d’utiliser cet article. Conservez le présent guide
afin de pouvoir le consulter ultérieurement.
ADVERTENCIA : Para reducir el riesgo de lesiones, el usuario debe leer y comprender
el Manual del operador antes de utilizar este producto. Guarde estas instrucciones para
consultarlas en caso sea necesario.
Owner’s Manual
Guide d’utilisation
Manual del propietario
Lithium 20V Battery with
PWRAssistTM Mobile Charging
Bloc-piles au Lithium de 20 V Avec
Chargeur Portatif PWRAssist™
Batería de Litio de 20 V Con
Carga Móvil PWRAssist™
Model/ Modelo/ Modèle: BY519702

2
TABLE OF CONTENTS
Safety Instructions ...............................3-6
Symbols .......................................7-12
Get to Know Your Battery...........................13
Specications ....................................13
Operating Instructions ..........................14-16
Maintenance...................................17-18
Battery Care ......................................18
Battery Disposal ..................................19
Limited Warranty of SKIL Battery Pack.............20-21

3
SAFETY INSTRUCTIONS
WARNING Read all safety warnings, instructions,
illustrations and specications. Failure to
follow all instructions listed below may result in electric shock, re
and/or serious injury.
SAVE ALL WARNINGS AND INSTRUCTIONS FOR
FUTURE REFERENCE.
The term “power tool” in the warnings refers to your mains-operated
(corded) power tool or battery-operated (cordless) power tool.
Work area safety
Keep work area clean and well lit. Cluttered or dark areas invite
accidents.
Do not operate power tools in explosive atmospheres, such as
in the presence of ammable liquids, gases or dust. Power tools
create sparks which may ignite the dust or fumes.
Electrical safety
Do not expose power tools to rain or wet conditions. Water
entering a power tool will increase the risk of electric shock.
Battery tool use and care
Recharge only with the charger specied by the manufacturer.
A charger that is suitable for one type of battery pack may create a
risk of re when used with another battery pack.
Use power tools only with specically designated battery
packs. Use of any other battery packs may create a risk of injury
and re.
When battery pack is not in use, keep it away from other metal
objects, like paper clips, coins, keys, nails, screws or other
small metal objects, that can make a connection from one
terminal to another. Shorting the battery terminals together may
cause burns or a re.

4
Under abusive conditions, liquid may be ejected from the
battery; avoid contact. If contact accidentally occurs, ush with
water. If liquid contacts eyes, additionally seek medical help.
Liquid ejected from the battery may cause irritation or burns.
Do not use a battery pack or tool that is damaged or modied.
Damaged or modied batteries may exhibit unpredictable behaviour
resulting in re, explosion or risk of injury.
Do not expose a battery pack or tool to re or excessive
temperature. Exposure to re or temperature above 265 °F may
cause explosion.
Follow all charging instructions and do not charge the battery
pack or tool outside the temperature range specied in the
instructions. Charging improperly or at temperatures outside the
specied range may damage the battery and increase the risk of
re.
Service
Have your power tool serviced by a qualied repair person
using only identical replacement parts. This will ensure that the
safety of the power tool is maintained.
Never service damaged battery packs. Service of battery packs
should only be performed by the manufacturer or authorized service
providers.
Specic Safety Rules
Before using battery, read all instructions and cautionary
markings on (1) battery charger, (2) battery pack, and (3)
product using battery.
Risk of re and burns. Do not recharge, disassemble, heat
above 100 °C (212 °F), or incinerate. Keep battery out of reach
of children and in original package until ready to use.

5
Battery tools do not have to be plugged into an electrical
outlet; therefore, they are always in operating condition. Be
aware of possible hazards when not using your battery tool or
when changing accessories.
Do not place battery tools or their batteries near re or heat.
Charge battery pack within the required temperature range.
Store charger and battery pack in locations where temperature
is within the recommended storage temperature range. This is
important to prevent serious damage to the battery cells.
Do not crush, drop or damage the battery pack. Do not use a
battery pack or charger that has been dropped or received a
sharp blow. A damaged battery is subject to explosion. Properly
dispose of a dropped or damaged battery immediately.
Do not insert battery pack in charger if battery pack case is
cracked. Using damaged battery pack may result in electric shock
or re.
Batteries vent hydrogen gas and can explode in the presence
of a source of ignition such as a pilot light. To reduce the risk
of serious personal injury, never use any cordless product in the
presence of open ame. An exploded battery can propel debris and
chemicals. If exposed, ush with water immediately.
Do not recharge battery in damp or wet environment. Do not
expose charger to rain or snow. Water entering battery charger
may result in electric shock or re.
Do not store outside or in vehicles.
Do not store battery pack in charger. Battery pack stored in
charger over a long period of time could lead to battery pack
damage and re.

6
Battery leakage may occur under extreme usage or temperature
conditions. Avoid contact with skin and eyes. The battery liquid
is caustic and could cause chemical burns to tissues. If liquid comes
in contact with skin, wash quickly with soap and water. If the liquid
contacts your eyes, ush them with water for a minimum of 10
minutes and seek medical attention.
Do not let gasoline, oils, petroleum-based products, etc. come
in contact with plastic parts. They contain chemicals that can
damage, weaken or destroy plastic.
Do not touch the uninsulated portion of output connector or
uninsulated battery terminal. There is a risk of electric shock.
Replace battery pack if a substantial drop in operating time per
charge is observed. Battery pack may be nearing the end of its
life.

7
SYMBOLS
Safety Symbols
The purpose of safety symbols is to attract your attention to
possible dangers. The safety symbols and the explanations with
them deserve your careful attention and understanding. The
symbol warnings do not, by themselves, eliminate any danger. The
instructions and warnings they give are no substitutes for proper
accident prevention measures.
WARNING Be sure to read and understand all safety
instructions in this Owner’s Manual, including
all safety alert symbols such as “DANGER,” “WARNING,” and
“CAUTION” before using this tool. Failure to following all instructions
listed below may result in electric shock, re, and/or serious
personal injury.
The denitions below describe the level of severity for each
signal word. Please read the manual and pay attention to these
symbols.
This is the safety alert symbol. It is
used to alert you to potential personal
injury hazards. Obey all safety
messages that follow this symbol to
avoid possible injury or death.
DANGER DANGER indicates a hazardous
situation which, if not avoided, will
result in death or serious injury.
WARNING WARNING indicates a hazardous
situation which, if not avoided, could
result in death or serious injury.

8
CAUTION
CAUTION, used with the safety alert
symbol, indicates a hazardous situation
which, if not avoided, will result in
minor or moderate injury.
Damage Prevention and Information Messages
These inform the user of important information and/or instructions
that could lead to equipment or other property damage if they are
not followed. Each message is preceded by the word “NOTICE”, as
in the example below:
NOTICE: Equipment and/or property damage may result if these
instructions are not followed.
WARNING The operation of any power
tools can result in foreign
objects being thrown into your eyes, which can
result in severe eye damage. Before beginning
power tool operation, always wear safety goggles
or safety glasses with side shields and a full face
shield when needed. We recommend a Wide Vision
Safety Mask for use over eyeglasses or standard
safety glasses with side shields. Always use eye
protection which is marked to comply with ANSI
Z87.1.

9
SYMBOLS (CONTINUED)
IMPORTANT: Some of the following symbols may be used on
your tool. Please study them and learn their meaning. Proper
interpretation of these symbols will allow you to operate the tool
better and more safely.
Symbol Name Designation/Explanation
V Volts Voltage (potential)
A Amperes Current
Hz Hertz Frequency (cycles per
second)
W Watt Power
kg Kilograms Weight
min Minutes Time
s Seconds Time
Wh Watt-hours Battery capacity
Ah Ampere-Hours Battery capacity
Ø Diameter Size of drill bits, grinding
wheels, etc.
n0No load speed Rotational speed, at no load
n Rated speed Maximum attainable speed
…/min
Revolutions or
reciprocation per
minute
Revolutions, strokes,
surface speed, orbits, etc.
per minute
0Off position Zero speed, zero torque...

10
Symbol Name Designation/Explanation
1,2,3,…
I,II,III, Selector settings
Speed, torque or position
settings. Higher number
means greater speed
Innitely variable
selector with off
Speed is increasing from 0
setting
Arrow Action in the direction of
arrow
Alternating current Type or a characteristic of
current
Direct current Type or a characteristic of
current
Alternating or direct
current
Type or a characteristic of
current
Class II tool Designates Double
Insulated Construction tools.
Earthing terminal Grounding terminal
Li-ion RBRC seal Designates Li-ion battery
recycling program
Ni-Cad RBRC seal Designates Ni-Cad battery
recycling program
Read manual symbol Alerts user to read manual

11
Symbol Name Designation/Explanation
Wear eye protection
symbol
Always wear safety goggles
or safety glasses with side
shields and a full face shield
when operating this product.
SYMBOLS (CERTIFICATION INFORMATION)
IMPORTANT: Some of the following symbols for certication
information may be used on your tool. Please study them and learn
their meaning. Proper interpretation of these symbols will allow you
to operate the tool better and more safely.
Symbol Designation/Explanation
This symbol designates that this tool is listed by
Underwriters Laboratories.
This symbol designates that this tool is recognized
by Underwriters Laboratories.
This symbol designates that this tool is listed by
Underwriters Laboratories, to United States and
Canadian Standards.
This symbol designates that this tool is listed by
the Canadian Standards Association.

12
Symbol Designation/Explanation
This symbol designates that this tool is listed by
the Canadian Standards Association, to United
States and Canadian Standards.
This symbol designates that this tool is listed by
the Intertek Testing Services, to United States and
Canadian Standards.
This symbol designates that this tool complies to
NOM Mexican Standards.
This symbol designates that this tool is listed by
the California Energy Commission.

13
GET TO KNOW YOUR BATTERY
PWRCORE 20™ Lithium Battery Pack
Fig. 1
Fuel
Gauge
USB On/Off Button
Battery-
Indicator
Button
Battery-Release
Button
USB Port
SPECIFICATIONS
Model No. SKIL BY519702
Battery Capacity 2Ah
Charger input 120V, 60Hz AC only
Battery Voltage 20 V
USB output 5V 1A
Recommended
Charging
Temperature
Normal Charging:
41°F (5°C) ~ 104°F (40°C)
Recommended
Storage Temperature 32°F (0°C) ~104°F (40°C)
WARNING The batteries listed above can be charged
with SKIL SC535801,QC536001 chargers.
NOTICE: Use of chargers or battery packs not sold by SKIL will
void the warranty.

14
OPERATING INSTRUCTIONS
WARNING To reduce the risk of re, personal injury,
and product damage due to a short
circuit, never immerse your charger or battery pack in uid
or allow a uid to ow inside them. Corrosive or conductive
uids, such as seawater, certain industrial chemicals, and
bleach or bleach-containing products, etc, can cause a short
circuit.
When to Charge the Battery Pack
It is not necessary to run down the battery pack charge before
recharging. The Lithium-Ion battery can be charged at any time
and will not develop a “memory” when charged after only a partial
discharge.
Remove the battery pack from the tool when it is convenient for you
and your job.
“Top off” the battery pack charge by charging it for a time before
starting a big job or use for a long period.
How to Charge the Battery Pack
NOTICE: The Lithium battery pack
is shipped partially charged.
Before using it the rst time, fully
charge the battery pack.
a. Charge the battery pack with the
correct charger.
b. Connect the charger to a power
supply. The red Defect Indicator
and the green Normal Charging
Indicator will both shine for one
second and then go out, indicating that the charger self-inspection
is completed.
Fig. 2
Attach

15
c. Align the raised ribs of the battery pack with the slot in the
charger.
d. Insert the battery pack into the charger (Fig. 2).
e. The charger will communicate with the battery pack to evaluate
the condition of the battery pack.
f. The charger will charge the battery automatically.
Please refer to the charger manual for detailed charging operation.
NOTICE: If the battery pack cannot accept a charge, the contacts
of the charger or battery pack may be contaminated. Clean the
contacts of the charger or battery pack (e. g. by inserting and
removing the battery several times or scrubbing with a cotton swab
and alcohol), replace a new charger or replace the battery pack, as
required.
Defective Battery Pack
If the charger detects a problem, the red Defect Indicator will begin
ashing. Remove and re-insert the battery pack in the charger. If
the Defect Indicator ashes a second time, try charging a different
battery pack.
a. If a different battery pack charges normally, have the rst
defective battery pack serviced by an Authorized SKIL Service
Station.
b. If a different battery pack also indicates “defective,” the charger
may be defective. Have the charger serviced by an Authorized
SKIL Service Station.

16
USB Port (Fig. 3)
The battery pack has a USB port,
which can provide 5V 1A output
when the battery is not depleted.
a. Connect an appropriate device
to the battery (cell phone, etc.)
with a standard USB cable.
b. Depress the USB on/off button
to activate the discharging
function at the USB port. During
the discharging, the fuel gauge will ash green.
WARNING Do not use the battery pack to charge or
power another device when the battery
pack is charging. Discharging and charging in the same
time may cause damage to the battery pack and possible
personal injury.
Fuel Gauge
The four LEDs on the battery comprise the Fuel Gauge, indicating
the current battery capacity when the battery-indicator button is
depressed.
The rst LED of the fuel gauge will ash green when the charge
level of the battery is low. Recharge the battery pack as needed.
To Attach/Detach Battery Pack
Follow the instructions in the Owner’s Manual for the individual SKIL
tool.
Fig. 3
USB Port
USB On/Off Button

17
MAINTENANCE
Service
WARNING Maintenance performed by unauthorized
personnel may result in misplacing of
internal wires and components which could cause serious
hazard. We recommend that all tool service be performed by a
SKIL Factory Service Center or Authorized SKIL Service Station.
General Maintenance
WARNING When servicing, use only identical
replacement parts. Use of any other parts
could create a hazard or cause product damage.
Periodically inspect the entire product for damaged, missing, or
loose parts such as screws, nuts, bolts, caps, etc. Tighten securely
all fasteners and caps and do not operate this product until all
missing or damaged parts are replaced. Please contact customer
service or an authorized service center for assistance.
WARNING To avoid serious personal injury, always
remove the battery pack from the charger/
tool when cleaning or performing any maintenance.
Cleaning
WARNING The tool may be cleaned most effectively with
compressed dry air. Always wear safety
goggles when cleaning tools with compressed air. Do not
attempt to clean by inserting pointed objects through openings.
WARNING Certain cleaning agents and solvents
damage plastic parts. Some of these are:
gasoline, carbon tetrachloride, chlorinated cleaning solvents,
ammonia and household detergents that contain ammonia.

18
Storage
Store the tool indoors in a place that is inaccessible to children.
Keep away from corrosive agents.
BATTERY CARE
WARNING When batteries are not in the tool or
charger, keep them away from metal
objects. For example, to protect terminals from shorting DO NOT
place batteries in a tool box or pocket with nails, screws, keys, etc.
Fire or injury may result.
DO NOT PUT BATTERIES INTO FIRE OR EXPOSE TO HIGH
HEAT. They may explode.

19
BATTERY DISPOSAL
WARNING Do not attempt to disassemble the battery
or remove any component projecting from
the battery terminals. Fire or injury may result. Prior to disposal,
protect exposed terminals with heavy insulating tape to prevent
shorting.
Lithium-Ion Batteries: If equipped with a lithium-ion battery,
the battery must be collected, recycled or disposed of in an
environmentally sound manner.
The EPA certied RBRC Battery Recycling
Seal on the lithium-ion (Li-ion) battery
indicates Chervon North America is voluntarily
participating in an industry program to collect
and recycle these batteries at the end of their
useful life, when taken out of service in the
United States or Canada. The RBRC program
provides a convenient alterative to placing used
Li-ion batteries into the trash or the municipal
waste stream, which may be illegal in your
area.
Please call 1-800-8-BATTERY for information
on Li-ion battery recycling and disposal bans/
restrictions in your area, or return your batteries
to a SKIL Service Center for recycling. Chervon
North America’s involvement in this program
is part of our commitment to preserving our
environment and conserving our natural
resources.

20
LIMITED WARRANTY OF SKIL CONSUMER TOOLS
2 YEAR LIMITED WARRANTY- LEGAL
Chervon North America, Inc. ("Seller") warrants to the original
purchaser only, that all SKIL consumer BATTERIES AND CHARGERS
will be free from defects in material or workmanship for a period of two
years from date of purchase.
Product registration can be completed online at www.Registermyskil.
com. Original purchasers should also retain their receipt as proof of
purchase.
Notwithstanding the foregoing, if a SKIL consumer portable power
tool is used for industrial, professional or commercial purposes, the
foregoing warranty will apply for a duration of ninety days, regardless of
registration.
SELLER’S SOLE OBLIGATION AND YOUR EXCLUSIVE REMEDY
under this Limited Warranty and, to the extent permitted by law, any
warranty or condition implied by law, shall be the repair or replacement
of parts, without charge, which are defective in material or workmanship
and which have not been misused, carelessly handled, or repaired
by persons other than Seller or Authorized Service Station. To make
a claim under this Limited Warranty, you must return the complete
product, transportation prepaid, to any SKIL Factory Service Center or
Authorized Service Station. For Authorized SKIL Power Tool Service
Stations, please visit www.Registermyskil.com or call 1-877-SKIL-999
(1-877-754-5999).
THIS LIMITED WARRANTY DOES NOT APPLY TO ACCESSORY
ITEMS SUCH AS CIRCULAR SAW BLADES, DRILL BITS.
ANY IMPLIED WARRANTIES APPLICABLE TO A PRODUCT SHALL
BE LIMITED IN DURATION EQUAL TO THE DURATION OF THE
EXPRESS WARRANTIES APPLICABLE TO SUCH PRODUCT, AS
SET FORTH IN THE FIRST PARAGRAPH ABOVE. SOME STATES
IN THE U.S., SOME CANADIAN PROVINCES DO NOT ALLOW
LIMITATIONS ON HOW LONG AN IMPLIED WARRANTY LASTS,
SO THE ABOVE LIMITATION MAY NOT APPLY TO YOU.
