leahua LH-C043 Led Spider User manual

Add：A1 Building The Sixth Industrial Zone Zhu Gang Road Hongxing Shijing Town Baiyun
District Guangzhou China.
Tel：[phone] Fax：[phone]
LH-C043 Led Spider rgbw moving head
User Manual
This manual contains important information.
Please read before operating fixture.

1
www.leahualight.com
1 SECURITY TIPS
WARNING!!! To reduce the risk of fire, electric shock, or
injury to persons, follow these important safety instructions:
non-professionals, not to disassemble the light arbitrarily and
lighting accessories inside.
rated voltage range: AC110V-120V/60Hz or AC200V-240V / 50HZ
(to be selected).
not beam irradiate the flammable materials, flammable materials
and the lamp should be maintained at least 1M over the distance.
lamps used in ambient temperature: -15 ℃-40 ℃, the highest
temperature of the surface of the lamp: 60 ℃.
to keep away from the liquid substance and humid environment.
before using the lights must ensure the good grounding, can not
install charging and remove any parts.
the installation of lamps, must be fixed screw fasteners with
additional security cable and regular inspection.
lamps consecutive working hours is not recommended more than
10 hours.
should stop using the lights in time when happens unusual
conditions during the process
lamp parts of the rotation, external accessories and paste parts
should be regular inspected, such as the emergence of loose and
rock, should be reinforced in a timely manner to prevent the
accident.
lamps adopt strong winds to refrigerate, it is easy to accumulate the
dust, so you have to clean it weekly especially the cooling air
opening, otherwise the dust will plug leading to poor light

2
www.leahualight.com
2 TECHNOLOGY REFERENCE
POWER SUPPLIE
Input power:AC100-240V 50/60 Hz
LED:8PCS 10W 4in1 RGBW Cree LED
DMX channel:11/37channels
Movement: Pan/Tilt: X :540degree, Y1 :120degree, Y2 :120degree
Control mode:DMX512/Master-Slave/Auto run/ sound
Display: LCD display
Beam angle:3degree
Pan/tilt speed:3 selectable for High, medium and low speed
WEIGHT&SIZE
N.W: 9kgs
G.W:11kgs
size: 32*41*28CM
Packing size:51*38*38CM

3
www.leahualight.com
3 Board Instruction
Main menu:
1
DMX address
A001—A512 address code
2
Channel Mode
11CH , 37CH channel selection
3
Show Mode
Sound ,Auto ,effect select
4
Slave Mode
Master , Slave , main machine and
shoose
5
Black Out
Yes , NO . standby mode
6
Sound State
ON , OFF .programmable starts
off
7
Sound Sense
The acoustic sensitivity (0close-100
The most sensitive )
8
Pan Inverse
YES ,NO Instead Level
9
Tilt1 Inverse
YES ,NO Vertical Reverse
10
Tilt2 Inverse
YES ,NO Vertical Reverse
11
Back Light
ON ,OFF , Background Light
Switch
12
Auto Test
Automatic Test
13
Fixture Time
0—9999 Use Time Machine
14
Firmware Version
V104
15
Defaults
YES ,NO Restore factory settings
16
System Reset
YES ,NO Reset

4
www.leahualight.com
4 DMX CHANNEL SHEET
11 Channel Mode:
Channel
DMX
Value
Function
1
000 - 255
X axis moving 00---6300
2
000 - 255
Y1 axis moving 00---1850
3
000 - 255
Y2 axis moving 00---1850
4
000-255
Dimmer(0-100%)
5
000-9
Shutter closed
010-245
Strobe effect slow to fast
246-255
Shutter open
6
000-255
R(ALL)
7
000-255
G(ALL)
8
000-255
B(ALL)
9
000-255
W(ALL)
10
000-007
Empty
008-017
R1,2,3,4
018-027
R5,6,7,8
028-037
G1,2,3,4
038-047
G5,6,7,8
048-057
B1,2,3,4
058-067
B5,6,7,8
068-077
W1,2,3,4
078-087
W5,6,7,8
088-097
R(ALL)
098-107
G(ALL)
108-117
B(ALL)
118-127
W(ALL)
128-255
MacroColorLine(Slow from slow to
fast)
11
000-255
LED Auto Play Speed(Slow to Fast)

5
www.leahualight.com
37 Channel Mode:
Channel
DMX Value
Function
1
000 - 255
X axis moving 00---6300
2
000 - 255
Y1 axis moving 00---1850
3
000 - 255
Y2 axis moving 00---1850
4
000-255
Dimmer(0-100%)
5
000-9
Shutter closed
010-245
Strobe effect slow to fast
246-255
Shutter open
6
000-255
Red1
7
000-255
Green1
8
000-255
Blue1
9
000-255
White1
10
000-255
Red2
11
000-255
Green2
12
000-255
Blue2
13
000-255
White2
14
000-255
Red3
15
000-255
Green3
16
000-255
Blue3
17
000-255
White3
18
000-255
Red4
19
000-255
Green4
20
000-255
Blue4
21
000-255
White4
22
000-255
Red5
23
000-255
Green5
24
000-255
Blue5
25
000-255
White5
26
000-255
Red6
27
000-255
Green6

6
www.leahualight.com
28
000-255
Blue6
29
000-255
White6
30
000-255
Red7
31
000-255
Green7
32
000-255
Blue7
33
000-255
White7
34
000-255
Red8
35
000-255
Green8
36
000-255
Blue8
37
000-255
White8
5 DIFFICULTY RESOLUTION
The following is a list of problems and resolution, and other
malfunction preparing work should be professionally qualified staff to
deal with.
1. Bulb not working
a) Check whether approaching the service life of light bulbs, then
change it
b) Check whether bulbs circuitry leak, loss or connect poorly
2. Beam appears bleak
a) The bulbs maybe approach the service life, then change it, or
the optical components are unclean.
b) Bulbs have accumulation of dust, so the bulbs and other parts
inside the lamp should be cleaned and maintained in regular
period.
3. Computer lamp work intermittently
a) Check whether the fan process naturally and become dirty

7
www.leahualight.com
b) Check inner temperature-response control plug is off
c) Check whether the circuitry is good
4. The computer lamp not controlled by controller during lighting
a) Check numeral starting address and the connection of
communication control circuit
b) The corresponding channel button of controller is open or not
c) Check whether the fuse on power supply input jack is broken
off
6 AFTER SERVICE
1. Our company offer technical consultation to customers for ever.
2. If the machine is wrong and need repairmen, please truthfully fill in
the related content and feedback us the problems timely, as well as
we have to improve the product.
3. In addition to the lamp, also matching accessories are as follows：
accessories：Power line 1 piece Optional parts：(customers）

8
www.leahualight.com

Warranty Card
Name Model Production Purchase
Description: These must be truthfully fill, seal by the end-user and
point-of-sale, or else the warranty will not work (warranty period and
terms, see the following)
warranty period：one year since purchase warranty terms：1、If fail
when using the product in normal state, you can made under the
provisions of the warranty, show the warranty card and purchase
bills(copy), and enjoy free maintenance service in a specific service
center or the manufacturer.
2. The following will be the implementation of paid service:
(1)Without the effective warranty card
(2)There’s blank, alter and no point-of-sale name
(3)Fail caused by unresistance
(4)Fail caused by transportation or unloading
(5)Fail caused by not operate by manual
(6)Fail caused by disassemble without unauthorized
(7)Fail caused by using the unauthorized control system
Note:
Based on our company continue to improve the product, the statement
containing data may have changed, and will not notice the change any
more. Company retains its right to change specifications related when
product is improved. Thanks for your understanding.
