Leaptronix LA-100P User manual

LA-100P User’s Manul

1-1 Product Overview
1-2 Safety & Caution
1-3 Specifications and Characteristics of Product
1-4 Standard Accessories of LA Series
1-5 Optional Accessories
2-1 Inspection before Installation
2-2 Places for Placement
2-3 Specifications of Input Power Supply
2-4 Use of Standby Fuse
2-5 Connection of LA System
2-6 Switch Test
3-1 Instructions on Front Panel
3-2 Instructions on Side Interface
3-3 Instructions on Rear Panel
4-1 Quick View for Operations
4-2 starting up System Power Supply
4-3 Setting Channel Quantity and Titles
4-4 Adjusting the level of Channels
4-5 Setting the Trigger State of Channels
4-6 Executing Trigger Signal Capture
Chapter One: Product Instructions....................01
Chapter Two: Installation of Instrument...........06
Chapter Three: Instructions on Instrument Panel...10
Chapter Four: Operation Instructions................25
LA-100P User’s Manul
Contents

LA-100P User’s Manul
Contents
4-7 Observing the Wave Form of Capture Signal
4-8 Save and Load of Wave Form
4-9 Power off LA System
5-1 Installation of PC-LINK
5-2 Operations of PC-LINK
5-3. Observing Signal Wave Form
5-4. Exit Operations:
6-1 Capture of Simple
6-2 Capture of Specific Events
6-3 Details of Signal Analysis
6-4 Setup of Advance or Delay Trigger
6-5 Save of Test Results
6-6 State Test
6-7 Remote Control
7-1 Calibration Manner
8-1 Maintenance by Users
8-2 Sending the Instrument for Repair
8-3 Elimination of Operation and Use Problems
Chapter Five: Use of PC-LINK..........................38
Chapter Six: Application Example.....................48
Chapter Seven: Instrument calibration...............55
Chapter Eight: Repair & Maintenance...............56

LA-100P User’s Manul
Instructions on Warranty of Logic Analyzer
Leaptronix provides its manufactured and sold products with a
one-year warranty on the parts and assembly dating from the delivery
date. In event of a defect merging during the warranty period,
Leaptronix will provide data for free and repair the products suffering
from a defect; however, disposable data are beyond the warranty
scope.
To share the service provided by this warranty, customers should, in
the beginning of the warranty period, make Leaptronix it known to
Leaptronix through following manners and conduct proper
arrangement for the smooth realization of services:
(1) To fill in the product warranty with complete content and deliver it
to Leaptronix through fax.
(2) To inform personnel in Leaptronix's service center of the complete
contents of various items in the product warranty through a
telephone call.
In case of a occurrence of warranty event, a customer should be liable
to pack the product suffering from a defect properly and to deliver it
to a agent or distributor service center designated by Leaptronix, with
freight born on him or herself. In case that the customer is in a
country the same as the service center of Leaptronix, Leaptronix will
be liable to pay the back freight of product. Otherwise, the customer
needs to pay all freight, duty, tax and any other expense.
This warranty is not applied to defects, invalidation or damage caused
by any improper use, and improper or insufficient maintenance and
attention. During the warranty period, Leaptronix shall not provide
services to customers under following circumstances:
(1) Damages caused by personnel on behalf of Leaptronix during
installation, repair or services
(2) Damages caused by improper use or connection with incompatible
equipment
(3) Any damage or functional abnormality caused by a use of
disposable data not provided by Leaptronix
(4) Any amendment or combination with other products which results
in the fact that difficulty or time of service-providing thereby rises
This warranty is provided by Leaptronix. Leaptronix shall bear any
responsibility for any sale or resale bearing a specific purpose.
Repairing or replacing products suffering from defects is a
supplementary measure of Leaptronix to protect the rights and
interests of customers during the warranty period. Leaptronix shall
bear no any responsibility for any indirect, particular, accidental or
consequential damage, no matter whether a pre-reminder is available
or not.

LA-100P User’s Manul
Instructions on Warranty on Consumptive
Accessories of Logic Analyzer
Parts or subassemblies beyond the main machine itself and external
box are all consumptive accessories and therefore are not in the
warranty scope. It is necessary for a customer to check whether there
is any defect of parts and subassemblies within 30 days dating from
the purchase date and, if any abnormality, to deliver the product to an
agent designated for marketing with the part or subassembly attached
so as to replace it with a new one.
List of Consumptive Parts or Subassemblies
● 8CH Data Pod
(Including rainbow strand group)
● 8CH Lead Set
● Test Probe ● USB A to B Cable

LA-100P User’s Manul
Chapter One: Product Instructions
-1-
1-1 Product Overview
Since its establishment in 1980, Leaptronix has been devoting itself
to the record and measurement of IC, with the goal to provide
manufactures with a perfect R & D environment and superior
measuring instruments. Considering the measuring need of various
products in digital era, our company has intensified the combination
with various industries and established a measuring instrument
business group (Leaptronix), providing digital system with the most
important and basic instruments, i.e. the series products of logic
analyzer. The LA-100P is one of the representative of products of
the Test & Measurement.
The LA-100P is 32 channels, 250MHz timing, 100 state Logic
Analyzer. It help minimize the risk by providing the most reliable,
accurtate data captre and the most complete view of system
behavior, These products are ideally suited for you on hardwae &
software debug, parametric and mixed signal testing and complex
debugging. Moreover, their compact size and ability to connect to a
PC make it an ideal solution for use at remote sites.

LA-100P User’s Manul
Chapter One: Product Instructions
-2-
1-2 Safety and Precautions
All operations, maintenance and repair services should be subject to
following safety precautions; our company shall bear no
responsibility to any unpredictable phenomenon resulting from an
improper use of this instrument while failing to follow the
precautions presented in this manual.
1. Please confirm advance to the use of power supply that a correct
input AC voltage has been adopted and that a correct fuse has
been installed. Specific standards and specifications are shown in
the instructions of the product.
2. Before turning on the instrument, you must connect the
protective earth terminal of the instrument to the protective
conductor of the mains power cord. You must not negate to
protective action by using an extension card (power cable)
without a protective conductor (grounding). Grounding one
conductor of a two-conductor outlet is not suffieient protection.
3. Only fuses with the required rated current, voltage, and specified
type should be used.
4. Do not operate or use this product beside any flammable gas or
fumes.
5. It is prohibited to use this product with its shell dismantled, or to
adjust or replace internal parts so as to avoid improper motions
of instrument and unnecessary dangers.
WARNING!
This sign means that attention should be paid to
dangers may happen and that personal injuries will
possibly happen in case that the operator fails to operate correctly
or to follow the procedure. Under his circumstance, the operator
should not continue with the operation with a exception that he or
she indeed knows the operation procedure.
CAUTION!
The Caution sign demotes a hazard. It calls attention
to an operating procedure, practice, or the like, which,
if not corretly performed or adhered to, could result in damage to or
destruction of part of the product. Do not proceed beyond a
Caution symbol until the indicated conditions are fully understood
or met.

LA-100P User’s Manul
Chapter One: Product Instructions
-3-
1-3 Specifications and Characteristics of Product
Items Specifications
Time sequence analysis (frequency capture)
State analysis (external clock)
Bandwidth
Channel
MEMORY
TRIGGER
Threshold Range
Maximum Input Voltage
Impedance
Temperature
Data Skew(Channel to Channel)
Interface
Power
Dimension
RAM Size
Storage Depth per Channel
Condition
Channels
Pre/Post Trigger
Trigger Levels
Continue Trigger
Range
Acuracy
Operating
Storage
Power Source
Normal consumed power
Max Power Dissipation
(Length x Width x Height)
250MHz～25Hz(4ns～40ms)
100MHz～1Hz(10ns～1sec)
100MHz
8CH x 4(0～31)
2M Bytes
512kbits x 32CH
Pattern / Edge / AND / OR
Trigger Counter 1~255
32CH
YES
YES
Trigger out YES(TTL Level)
Pulse Width Trigger YES
Bus Analysis YES
Glitch Capture YES
3 (Edge or Pattern)
-4V～+4V
±50mV
±30V
100KΩshunted by 10pF
0℃～45℃(32℉～113℉)
-40℃～75℃(-56℉～167℉)
2ns typical, ±4ns MAX
AC:90～240V,50～60Hz
AC 250V/2.0A
18.0W
20.0W
USB 2.0
31cm x 9cm x 15cm
Weight 3.8kg
Power Dissipation
Fuse

LA-100P User’s Manul
Chapter One: Product Instructions
-4-
1-4 Standard Accessories of LA Series Products
NO
01
02
03
04
06
07
08
09
Title of Accessories
CD
Warranty Card
USB 2.0 Cable
Lead Set
Qty
1
1
Main Unit 1
Test Probe
10
Packaging Confirmation
Form
11
05
User's manual
4sets
(32CH)
4sets
(32CH)
1
1
1
AC power cord 1
1
Data Pod
Chinese Operation Edition
Remark
Including,line,
connecting software,
drive program, manual
Three-wire type
List out the packing
subassemblies of product
1
package 36 pieces
Including rainbow
strand group

LA-100P User’s Manul
Chapter One: Product Instructions
-5-
1-5 Selection of Accessories
● 8CH Data Pod
(Including rainbow strand group)
● 8CH Lead Set
● Test Probe ● USB A to B Cable

LA-100P User’s Manul
Chapter Two: Installation of Instrument
-6-
2-1 Inspection Advance to Installation
1. Although the instruments has undergone a precise test and
inspection ahead of the delivery, customers are also expected,
after unfolding the box, to confirm whether there is any
abnormality advance to use so as to confirm whether there is any
damage occurring during the delivery. After that, the product can
be used if no problem found.
2. Customers should, based on the accessory tables of various
machine types, check whether the items and quantity of
accessories in the package are correct and complete and, if not,
present the problem to our company or our local distributor
immediately for a disposal.
2-2 Places for Placement and Use
1. This instrument is formed a circulatory heat elimination system
through the fans and air holes on shell. Therefore, it should be
placed at a ventilated place. In addition, it is prohibited to block
the circulatory heat elimination holes.
2. Environmental temperature for operations and use: 0℃～45℃
3. During the operations of this product, there may be an
electromagnetic field occurring and instruments placed near it
will possibly affect one another during operations. In case of the
latter phenomenon, please keep a distance between this
instrument and any other instrument larger than 10cm. It is also
required to use it at a place far away from any high magnetic
field or interference.
2-3 Specifications of Input Power Supply
1. Advance to connecting AC power supply, please confirm the
adopted AC power supply meets the specifications of the input
voltage accepted by this instrument. The input voltage of
instrument is shown in the literal instructions on the backboard.
2. Specifications of the input voltage can be used by this instrument
are AC 90～240V, 50/60Hz.
Caution: Please confirm whether the input voltage adopted by this
instrument is in line with its specifications of voltage first.

LA-100P User’s Manul
Chapter Two: Installation of Instrument
-7-
2-4 Use of Standby Fuse
In case of a need of the standby fuse, please confirm the
specifications of fuse first:
•Specifications of the adopted fuse should be 220V/2Amp.
•The product has already been enclosed with a standard fuse in the
fuse base.
Caution: Buying a new fuse to replace the original one should follow
the standard specifications, or it may lead to the damage of
instrument.
2-5 Connection of LA System
2-5-1 Connecting Sequence of LA System
(1)LA main unit →(2)Data Pod(Including rainbow strand group)
→(3)Lead Set →(4)Test Probe
Connecting Relation of system is as bellow:
※Caution: Please do not place the Lead Set on the port the LA main
unit directly to avoid the damage of the LA.
※In event of any fracture or damage, it is necessary to send the
product to the manufacturer for a repair or replacement.
(1)
(2)
(3)
(4)

LA-100P User’s Manul
Chapter Two: Installation of Instrument
-8-
2-5 Connection of LA System
2-5-2 Instructions on Subassemblies
•Data Pod (including high-density rainbow cable)
→ Connect the Data Pod to the LA
main unit.
•Lead Set
The Single-pin of the
signal and graound leads
can be connected directly
to the target system.
※Caution: Please do not place the signal captureing windings on the
port terminal of main LA machine directly so as to avoid the
damage of main LA machine.
※In event of any fracture or damage, it is necessary to send the
product to the manufacturer for a repair or replacement.
→ → Connector plugs into
the socket of data pod.

LA-100P User’s Manul
Chapter Two: Installation of Instrument
-9-
2-6 Self-Test
1. It is required to insert one terminal of
power line on AC-in position at left side
of LA and another terminal on the AC
power socket.
2. Pressing down "1" on the AC power
switch to switch from "0" to "1".
3. And then pressing down the
orange-yellow power switch
on the upper part of front panel
of LA, and then the product will be under on state; the red LED
indicator light will lighten; buzzer will give a sound lasting for one
minute; LA will undergo a self-test of system. Finally, it will enter
into the initialization frame shown as bellow, indicating the
completion of on-state test.
4. While shutting down the machine, press down the power switch
for 2-3s and then loosen it, and the system will shut down after
storing the data.
← AC Power Switch
← Power Socket
Moudel : Logic Analyzer 100MHz/4ns
Version : 1.01
Date : 06 / 12 / 01
System Test...PASS
Memorys Test...PASS
Load Boot...PASS
Press any key to contiune

LA-100P User’s Manul
Chapter Three: Instructions on Instrument Panel
-10-
3-1 Instructions on Front Panel
12345
6
7
8
9
1011
LA-100P
Trigger Out
5V
0

LA-100P User’s Manul
Chapter Three: Instructions on Instrument Panel
-11-
3-1 Instructions on Front Panel
Item
Display Function
Hot keys F1～F6
Menus
Capture
Direction key
Rotary Encoder
Trigger key
Character key
Function Description
Signal input port
It is a system display zone, displaying wave form,
information and functions.
They are detailed hot keys of system and their
adjustment should be made through the connection
with primary function-control keys on the panel.
Such keys include Channel, Change Page,
Auto-Scale, Cursors, File, Utility, Main delays,
Grid and Logic levels.
Such keys include three capture manner hot keys
(Single, Auto-store and Run/Stop) and wave form
erase hot key.
It is the key acting as a power switch.
It is used to control the wave form through
left-right move, zooming up & down, and to
set Sample Rate.
It can be used to make left-right and bottom-top
motions of various items.
It is used to choose between Int/Ext Clock
and setup of Triggering state.
It is used to realize figure input and literal
editing functions.
It can provide 4 sets of signal input ports.
Power-control key
NO.
10
1
2
3
4
5
6
7
8
9
Trigger Out
It can send out a " (rising) signal" to
provide to another set machine. It can be
adopted during a synchronous action.
11

LA-100P User’s Manul
Chapter Three: Instructions on Instrument Panel
-12-
3-1 Instructions on Front Panel
3-1-1 Instructions on Menus (Project) Control Key
1. Channel setup key: in event of a need to set a channel,
pressing down the channel key. There are 6 functional
boxes at right side of LCD which can be used in correspondence
with hot keys F1～F6. Functions of these hot keys are as follows:
Channel
On/Off
Disp Value
On/Off
Reorder
0<一 一>31
Name
On/Off
Bus
Exit
S0
CK:4ns 100ns
Delay : 0ps
Name : GRAYWANG
－Channel on/off: to set the on or off state of various channels.
－Bus: to set bus.
－Display of numerical value: to display numerical values on
wave forms. Such item can be set as on or off state.
－In order of precedence 0～31: to conduct the order and display
various channels and their names (CH0～CH31)
－Name on/off: to switch between the display state and
non-display state of channel names. When it is on, such names
will be displayed completely; when it is off, no even one such
name can be displayed. As shown in above diagram, motion
state is on and "On" is in red.
－Exit: to set functions for the exit channel.

LA-100P User’s Manul
Chapter Three: Instructions on Instrument Panel
-13-
3-1 Instructions on Front Panel
3-1-1 Instructions on Menus (Project) Control Key
2. It is a key to switch page.
a. In case that the quantity of channels or bus displayed on the
screen is bigger than 16, pressing down this key will switch to
the second page, that is, to display signals beyond these 16
channels; if pressing down again, will switch back to the
original.
b. If use together with the "Utility", can also realize the switch of
functional frame.
c. If use together with "Trigger", can also realize the switch of
functional frame.
3. Automatic adjustment key: it is for automatic search
function, search for the capture signal wave forms under existing
state and, after the search, give out a "bi" sound and automatically
display on LCD. This needs 3-5 second to show the results.
4. It is a key to realize setup of cursor. Pressing this key
can display cursor T (there are 7 vertical cursors, i.e. A-F) and
display the time interval among various groups, i.e A～B,A～T,
B～T C～D,C～T,D～T,E～F,E～T,F～T, shown with a unit of
ns/us/ms.
※Press key "A←→B" in cooperation, and it will display that B is a
full line, which indicates that B is under the enable state; "←" and
"→"can move cursor B and change the time interval between
B～A and B～T; pressing it for another time, and it will display
cursor C and C is under a intelligent state; "←" and "→" can move
cursor C and change the time interval between C～D and C～T.
※Press key "＜" to make cursor T to be enable the axis and the
fame to face left; while press "＞" ,and the frame will go to right;
pressing "Λ" and "Ⅴ" will make the frame wave form switch to a
zooming-in and zooming-out state respectively.
※Pressing the cursor-setup key can return to T cursor frame. At
this time, it can be used together with the our direction keys to
make the switch among left, right, zooming-in and zooming-out.

LA-100P User’s Manul
Chapter Three: Instructions on Instrument Panel
-14-
3-1 Instructions on Front Panel
3-1-1 Instructions on Menus (Project) Control Key
5. It is a file-setup key.
After pressing down this key, F1～F4 can be used as hot functions
for file management.
- Load Setting: It possesses 5 space items for choice. The
precondition is that there must be system setup data
stored, only under this circumstance, setup can be read
and used.
- Save Setting: there are 5 space items can be used to store
the system setup data.
- Load Waveform: there are 5 space items can be used to
read the stored system setup and signal wave form data.
- Save Waveform: there are 5 space items can be used to
store system setup data and those capture signal wave
form data.
- It is used to return to the primary frame.
File

LA-100P User’s Manul
Chapter Three: Instructions on Instrument Panel
-15-
3-1 Instructions on Front Panel
3-1-1 Instructions on Menus (Project) Control Key
6. General Key:
Press this key to use its functions according to F1, F2, F3, F4, and
F5 functions.
- a. Brightness: it can be used to adjust the brightness of
LCD; there are two manners to adjust such brightness, i.e.
"++" and "- -".
b.Display Mode Waveform: it can set the screen display in
a wave form or in literal. (If used together with "Change
Page", it can also be used to switch page.
- B/W (black or white color of LCD background): it is used
to set the color of LCD.
- PC-Link: it can be applied to send the capture signal wave
form to PC via USB2.0 interface for magnification,
observation and printing. Please refer to Chapter Five for
the details of computer link.
- RAM Size: it can be used with rotary encodor to adjust
the volume of memory.
- Language (setup of interface language): it can be applied
to select the language used in the operating interface.
- It can realize the function to return to the primary frame.
