L0428R - ROLLING CODE PROGRAMMER AND ANALYZER
Features
L0428R programmer is equiped with a 433.92 MHz radio-receiver (Receiver 1) in order to get the codified signals from
Leb electronics transmitters. The unit can be equipped with an extra radio-receiver (Receiver 2) with different frequency
(e.g. 868,35 MHz).
Use of the device
The electronic unit is intended for the following uses :
 Verify operating status of SMARTY, TPW4/TPK4. TSAW4N transmitters
 Codify SMARTY, TPW4/TPK4 transmitters.
Limitations to use
 L0428R programmer operates correctly only with SMARTY, TPW4/TPK4. TSAW4N transmitters
 Secret Key System works only with Leb electronics receiver RSK4/RPSK4
 It is possible to verify codes of transmitters (installation code and Tx code) only with the original L0428R programmer that was
used to program transmitter. No other L0428R than the original one can do it.
General specifications
Power supply: 9V alkaline battery
Operating range: 1 m of distance approx. from transmitter
Operating temperature range : from +10 to +50 °C
Dimensions: 94 x 180 x 39 mm
Weight: 220 gr
Installation codes: 4096 max.
Transmitter codes: 4096 max. for installation

4
ENGLISH
1 2
4 5
7 8
CLR 0
3
6
9
F1
F2 F3
Secret Key
I
A
B
D C
Programmer components
Description A- Liquid crystal display B- Membrane keyboard C- Jack socket for the
Programming cable to Tx (E).
D- Connector for RS232 .
Keyboard 0 - 9 : Digit keys : Next menu : Previous menu F1 : Enter or exit from the main menu F3 : ON / OFF display backlight
: ON / OFF programmer
CLR : Erase the last number /
Return to the previous menu
: Enter in the menu or confirm data
: Not used
: Not used F2 : Not used
I
E

5
ENGLISH
L0428R - Operation
Preliminary operations
Battery replacing
Turn off the programmer. Unscrew the two screws on the front side of the housing and remove the cover. Replace the battery
respecting the polarity of the connector. Place the cover of the housing as in origin.
Programming cable connection
To program Leb electronics transmitters, insert the plug of the programming cable into the socket C.
Turning on the programmer
To turn on the programmer, press the following key:
The display will show "0428R Analyzer SECRET KEY" and programmer is ready to program Leb electronics remotes in SECRET
KEY mode.
To switch to programming in FIXED CODE mode, press F2. Display will show “0428R Analyzer FIXED CODE MODE”.
To turn off the programmer, press again
Radio-receiver selection
The unit operates with 433.92 MHz Receiver 1. To select the optional Receiver 2, press the key 2and verify that “ RECEIVER 2 “ is
displayed. To restore operation with Receiver 1 press the key 1 and verify that “ RECEIVER 1 “ is displayed.
SECRET KEY MODE PAGE 6
FIXED CODE MODE PAGE 13
I
I

6
ENGLISH
Operations
Attention: In order to avoid undesired signals, the operating range has been reduced to 1 m of distance.
The programmer operations consist of 4 menus.
Menu 1 To codify transmitters in order to store them manually into receiver of
a selected installation.
Menu 2
To codify a transmitter in order to store it automatically in a selected
installation. This feature is very useful when in need to store a new
code in the receiver without going onto the installation.
Menu 3
To codify a transmitter in order to replace (and cancel) a selected
stored transmitter code. This feature is very useful when in need to
remove and replace a code in the receiver without going onto the in-
stallation.
Menu 4 To set automatic power off and automatic backlight of display.
To select the desired menu, do the following:
 Turn on the programmer
 Press the F1 key
 Scroll the menus through the keys.
and
4 SETTING
3 REMOTE CODE
REPLACING
2 REMOTE AUTO
STORING
1 MANUAL
STORING
SECRET KEY MODE

7
ENGLISH
Menu 1 - Description
 To codify a transmitter in order to insert it manually in the receiver of a selected installation.
1 MANUAL
STORING
Press key Insert unique installation code (from 1 to 4095) assigned
to the specific installation.. Example shows installation code
73. Installation code of remote and Rx must be the same
Press key The programmer displays the first transmitter code
available in the installation 73. In the example transmitter
code 63 will be used.
Press key The programmer is ready to codify the transmitter.
(plug connector E into programmer and radio transmit-
ter)
Press key Led of remote will blink.
The transmitter has been now programmed. The program-
mer is ready to codify a new transmitter with code 64.
Press key The transmitter has been programmed. The programmer is
ready to codify a new transmitter with code 65. Keep doing
untill you have done all your remotes.
Press CLR key Return to the main menu. Transmitter have to be stored
manually as in instructions manual of RSK4/RPSK4.
1 - 1 INSTALLATION
73
1 - 2 CODE TX
63
READY
INST=73 TX=63
PROGRAMMED
INST=73 TX=64
PROGRAMMED
INST=73 TX=65
1 MANUAL
STORING
SECRET KEY MODE

8
ENGLISH
Menu 2 - Description
 To codify a transmitter in order to insert it automatically (just with a simple push on the remote) into an installation
This function will be used when you must insert a new code in the receiver without a manual action on it.
Press the key Insert unique installation code (from 1 to 4095) assigned
to the specific installation. Example shows installation code
73. Installation code of remote and Rx must be the same.
Press the key The programmer displays the first transmitter code
available in installation 73. In the example transmitter
code 63 will be used .
Press the key The programmer is ready to codify the transmitter.
(plug connector E into programmer and radiotransmit-
ter)
Press the key Led of remote will blink.
The transmitter has been programmed. The programmer is
ready to codify a new transmitter with code 65.
Press the key The transmitter has been programmed. The programmer is
ready to codify a new transmitter with code 65. Keep doing
untill you have done all your remotes.
Press the CLR key Return to the main menu. During the first transmission
(*) by the installation, the new remote will be automati-
cally stored.
2 - 1 INSTALLATION
73
2 - 2 CODE TX
63
READY
INST=73 TX=63
PROGRAMMED
INST=73 TX=64
PROGRAMMED
INST=73 TX=65
2 REMOTELY AUTO
PROGRAMMING
2 REMOTE AUTO
STORING
(*) Only for the first 10 pushes on the new remote
SECRET KEY MODE

9
ENGLISH
Menu 3 - Description
 To codify a transmitter in order to replace (and cancel) an already stored transmitter code.
REPLACING BY KNOWING THE CODE OF REMOTE TO BE REPLACED
Press key Insert unique installation code (from 1 to 4095) assigned
to the specific installation.. Example shows installation code
73. Installation code of remote and Rx must be the same.
Press key The display shows the first transmitter code available in
installation n.73 to be assigned to remote. Example shows
transmitter code 53.
Press key DIGIT 0 IN ORDER TO PROCEED TO SELECTION OF
TRANSMITTER CODE TO BE REPLACED
Press key Digit transmitter code you want to replace Example shows
code 52.
Press key The programmer is ready to codify the new transmitter.
(plug connector E into programmer and radiotransmit-
ter)
Press key
Led of remote will blink.
The new transmitter has been programmed. During the
first transmission (*) by the installation, the old remote
will be automatically cancelled and replaced.
3 - 1 INSTALLATION
73
3 - 2 CODE TX
53
3 - 3 POSITION?
0
READY
INST=73 TX=53
3 - 4 CODE?
52
3 REMOTE CODE
REPLACING
3 REMOTE CODE
REPLACING
SECRET KEY MODE
(*) Only for the first 10 pushes on the new remote

10
Press key Insert unique installation code (from 1 to 4095) assigned
to the specific installation.. Example shows installation code
73. Installation code of remote and Rx must be the same.
Press key The display shows the first transmitter code available in
installation n.73 to be assigned to remote. Example shows
transmitter code 52.
Press key Insert the memory position (from 1 to 1000) in RX where
the code to be replaced is stored. In this example position 3
has been selected (refer also to page 10)
Menu 3 - Description
 To codify a transmitter in order to replace (and cancel) an already stored transmitter code.
REPLACING BY KOWING THE POSITION IN THE RECEIVER OF REMOTE TO BE REPLACED
Press key The programmer is ready to codify the new transmitter.
(plug connector E into programmer and radiotransmit-
ter)
Press key
Led of remote will blink.
The new transmitter has been programmed. During the
first transmission (*) by the installation, the old remote
will be automatically cancelled and replaced.
3 - 1 INSTALLATION
73
3 - 2 CODE TX
52
3 - 3 POSITION?
3
READY
INST=73 TX=52
3 REMOTE CODE
REPLACING
3 REMOTE CODE
REPLACING SECRET KEY MODE
(*) Only for the first 10 pushes on the new remote
This procedure is not advisable, being not very easy to know position of transmitters in RSK4/RPSK4.
When possibile, follow previous procedure as illustrated at page 10.
ENGLISH

11
ENGLISH
I
Menu 4 - Description 4 SETTING
 Manual POWER OFF: To turn on or turn off the programmer, you must press
 Automatic POWER OFF: After 3minutes of non operation, programmer will switch off.
 Automatic BACKLIGHT: When you press any key, the display backlight goes on for 15 seconds.
 Manual BACKLIGHT: To turn on or turn off the display backlight, you must press the F3 key.
Press key Choose the desired operating mode (automatic or manual)
through the keys. The example shows automatic
setting
Press key Choose the desired operating mode (automatic or manual)
through the keys. The example shows manual
setting.
Press CLR key Return to the main menu.
4 - 1 POWER OFF
AUTOMATIC
4- 2 BACKLIGHT
MANUAL
4 SETTINGS
and
and
SECRET KEY MODE
I

12
Checking transmitter operating status
It is possible to check transmitter operating status of each transmtter, in order to know installation code and transmitter code (you
might want to take note of them for future reference) as follow:
Switch on programmer and wait for display to show “Analyzer L0428R SECRET KEY”
While the display shows “Analyzer L0428R SECRET KEY” press key of SMARTY TPW4/TPK4 transmitter to check and verify that
following message is displayed:
INST=73 shows Installation code
TX=41 shows Transmitter code
Press CLR key and wait for display to show “Analyzer L0428R SECRET KEY”
Repeat operations as above for new checkings
RECEIVED!
INST=73 TX=41
SECRET KEY MODE
ENGLISH

13
Operations (in Fixed Code mode)
After switching on the programmer, press F2 Key to select FIXED CODE. “Analyzer 0428R FIXED CODE MODE”
Attention: In order to avoid undesired signals, the operating range has been reduced to 1 m of distance.
The programmer operations consist of 3 menus:
Menu 1 To codify all 4 channels of SMARTY, TPW4/TPK4. Any time you
codify a transmitter, the code will increases by 1 (max 1023)
Menu 2 To codify all 4 channels of SMARTY, TPW4/TPK4. Code will not
increase and will stay the same for all new remotes codified.
Menu 3 To set automatic switching off and automatic back-light of the
display.
3 SETTING
1 INCREMENTAL
TX CODE
2 STATIC
TX CODE
To select the desired menu, do the following:
 Press the F1 key
 Scroll the menus through keys.
 Press CLR key to quit menu
FIXED CODE MODE
and
ENGLISH

14
Press key Enter a remote control code (from 1 to 1023) at your
choice. Installation code 854 has been selected in the
example.
Press key Select the transmission standard by means of the keys 
and . STANDARD SUGGESTED 4.
Press key The programmer is ready to codify the transmitter.(plug
connector E into programmer and radiotransmitter)
Press key Led of remote will blink four times. The transmitter has
been codified. Programmer is ready to codify a new
transmitter with code number increased by 1 (max 1023).
Press key CLR Go back to main menu.
1 - 1 CODE TX
854
1 - 2 STANDARD 1
READY
854
PROGRAMMED
855
1 INCREMENTAL
PROGRAMMING
1 INCREMENTAL
TX CODE
Menù 1 - Description
FIXED CODE MODE
ENGLISH

15
Press key Enter a remote control code (from 1 to 1023) at your
choice. Installation code 277 has been selected in the
example.
Press key Select the transmission standard by means of the keys 
and . STANDARD SUGGESTED 4.
Press key The programmer is ready to codify the transmitter.
(plug connector E into programmer and
radiotransmitter)
Press key Led of remote will blink four times.The transmitter has
been codified. Programmer is ready to codify a new
transmitter with same code number.
Press key CLR Go back to main menu.
1 - 1 CODE TX
277
1 - 2 STANDARD 1
READY
277
PROGRAMMED
277
2 STATIC
TX CODE
2 STATIC
TX CODE
Menù 2 - Description
FIXED CODE MODE
ENGLISH

16
I
Menu 3 - Description 3 SETTING
 Manual POWER OFF: To turn on or turn off the programmer, you must press
 Automatic POWER OFF: After 3minutes of non operation, programmer will switch off.
 Automatic BACKLIGHT: When you press any key, the display backlight goes on for 15 seconds.
 Manual BACKLIGHT: To turn on or turn off the display backlight, you must press the F3 key.
Press key Choose the desired operating mode (automatic or manual)
through the keys. The example shows automatic
setting
Press key Choose the desired operating mode (automatic or manual)
through the keys. The example shows manual
setting.
Press CLR key Return to the main menu.
4 - 1 POWER OFF
AUTOMATIC
64- 2 BACKLIGHT
MANUAL
4 SETTINGS
and
and
FIXED CODE MODE
I
ENGLISH

17
L0428R - Checking operating status and cloning with SMARTY, TPW4/TPK4 FIXED CODE MODE
It is possible to check transmitter operating status of each transmtter, in order to know transmitter code (you might want to
take note of them for future reference) as follow:
Switch on programmer, press F2 Key to select FIXED CODE. “Analyzer L0428R FIXED CODE MODE”
While display shows “Analyzer L0428R FIXED CODE MODE” press key of SMARTY TPW4/TPK4 or TSAW4N transmitter to
check and verify that following message is displayed:
Press CLR key and wait for display to show “Analyzer L0428R FIXED CODE MODE”
Repeat operations as above for new checkings
682 CH 3
12 3 4 5 6 7 8 9 10 11 12
A
B
C D
2 E
Picture 1 (valid for 12-bit codes)
A- Binary combination with 10 bits of the code
B- Binary combination with 2 bits of the channel
C- Decimal combination with 4 digits of the code
D- Indication of the operating channel
E- Selection of the channel to be codified on new remote
Picture 2 (valid for 20-bit codes)
F, G, H, I, L - Binary combination with 20 bits of the code
M- Decimal combination with 5 digits of the code
N- Selection of the channel to be codified on new remot.
2
15937
12 3 4 56 7 8 9 10 11 12
13 14 15 16 17 18 19 20
F
I
G H
M
L
N
ENGLISH

18
L0428R - cloning with SMARTY, TPW4/TPK4 FIXED CODE MODE
Codifying a transmitter SMARTY, TPW4/TPK4 through cloning of a code
 Switch on programmer, press F2 Key to select FIXED CODE. “Analyzer L0428R FIXED CODE MODE”
While display shows “Analyzer L0428R FIXED CODE MODE” press key of transmitter to be copied and verify that following
message is displayed:
With keys and , select the channel of transmitter SMARTY, TPW4/TPK4 to be codified with source. The indication of the
channel is displayed in positions E (pic. 1) or N (pic. 2).
Insert the 3-pole connector of the programming cable into remote. Press key and check that led on remote blinks for about 1
sec. (end of the operation).
Do not push any button on remote while codifying!
682 CH 3
12 3 4 5 6 7 8 9 10 11 12
A
B
C D
2 E
Picture 1 (valid for 12-bit codes)
A- Binary combination with 10 bits of the code
B- Binary combination with 2 bits of the channel
C- Decimal combination with 4 digits of the code
D- Indication of the operating channel
E- Selection of the channel to be codified on new remote
Picture 2 (valid for 20-bit codes)
F, G, H, I, L - Binary combination with 20 bits of the code
M- Decimal combination with 5 digits of the code
N- Selection of the channel to be codified on new remot.
2
15937
12 3 4 56 7 8 9 10 11 12
13 14 15 16 17 18 19 20
F
I
G H
M
L
N
ENGLISH

19
NOTES
ENGLISH

20
