Lectron CCS1 to Tesla Adapter User manual

CCS1 to Tesla Adapter
USER MANUAL

This charging adapter allows Tesla owners to access CCS1 fast chargers.
In the Box
Product Introduction
Important Information
Page 1
1 x CCS1 to Tesla adapter
1. WARNING: Read this document before using the CCS1 to Tesla Adapter.
Failure to follow any of the instructions or warnings in this document can
result in fire, electrocution, serious injury or death.
2. This adapter is intended only to be used with Tesla vehicles. Do not
use it for any other purpose.
3. Do not use the CCS1 to Tesla Adapter if it is defective, appears
cracked, broken, damaged or fails to operate.
4. Do not open, disassemble, or modify the CCS1 to Tesla Adapter.
Contact Lectron Customer Support for any repairs at
[email protected]

Page 2
5. Do not disconnect the CCS1 to Tesla Adapter while the vehicle is
charging.
6. Protect the CCS1 to Tesla Adapter from any water or moisture.
7. Handle with care whenever moving or transporting it. Store in a safe
location.
8. Do not damage the CCS1 to Tesla Adapter with sharp objects.
9. Only use in temperatures between -22 °F and 122 °F.
10. Do not clean with detergent or cleaning solvents.
11. Do not use if it is damaged or corroded in any way. Inspect before
each use.
Note: Not all Tesla models support CCS adapters. To confirm whether
yours is compatible, on your Tesla touchscreen select:
Controls Software Add vehicle information CCS adapter
support: Enabled.
Before You Use
Warning: Do not store the CCS1 to Tesla Adapter outside of the storage
temperature range.
Voltage
Outer box weatherproof rating
Operating temperature
Storage temperature
500V DC
IP44
-22 °F to + 122 °F
-40 °F to + 185 °F

Page 3
Introduction to Parts
CCS1 port Tesla plugInsert stopper
Charging time may vary according to charging station power, ambient
temperature, and battery temperature.
If the temperature of the adapter reaches 180 °F, the vehicle will reduce
the charging power. If the temperature reaches 185 °F, the charging will
shut off.
Charging Time

Page 4
1. Open the Tesla charge port.
Connecting the Adapter
2. Insert the CCS1 charging cable into the CCS1 port on the adapter.
It will click firmly in place.

Page 5
Charging
Time Remaining
35 min
104 mi
125 kW 522 mi/hr +5 mi
3. Insert the adapter into the Tesla charge port and wait for the vehicle
to signal that it has accepted the charger with a pulsating green "T"
light next to the charge port (the touchscreen also shows the
real-time charging status).
Note: The insert stopper on the adapter will keep it from being
inserted too far and damaging the vehicle's charge port.
4. Begin charging according to the charging station's guidelines. Check
your Tesla touchscreen to make sure it's charging.
Note: Make sure that the adapter and CCS1 charging cable are firmly
connected, and that the adapter is plugged into the Tesla charge
port.
Charging
Time Remaining
35 min
104 mi
125 kW 522 mi/hr +5 mi
Insert stopper

Page 6
Removing the Adapter
1. Hold both the charger handle and the adapter and securely pull them
out of the Tesla charge port.
Note: Do not press the unlock button on the handle while pulling it
out of the charge port.
3. Press the unlock button on the handle and safely remove the adapter.
Note: Only remove the adapter from the charge port once charging is
completed.
1
2

Page 7
Troubleshooting
Specifications
My Tesla is not charging. What’s wrong?
• Check to make sure your Tesla supports a CCS adapter. On the
touchscreen select: Controls Software Add vehicle information
CCS adapter support: Enabled.
• Check to make sure the adapter and CCS1 charging cable are firmly
connected, and that the adapter is plugged into the Tesla charge
port.
• Try unplugging and re-inserting both the charging cable and the
adapter.
• Check the charging status on both the CCS1 charger and your Tesla
touchscreen.
• If your car has been in an accident, Tesla may restrict or disable the
use of a CCS1 adapter.
• If your Tesla is still not charging, email our customer service at
[email protected].
Rated value:
Insulation resistance:
Withstand voltage:
Shell:
EV connector:
Dimensions:
IP rating:
Operating temp:
Storage temp:
300A 500V DC
>5MΩ (DC 500V)
2000V AC/5s
Thermoplastic
CCS1 to Tesla
4.8(L) x 3(W) x 5.2(W) in
IP44
-22 °F to 122 °F
-40 °F to 185 °F

Get More Support
www.ev-lectron.com
Made in China
Scan the QR code below or email us at [email protected].
