led pro Neon-Flex 2 Series User manual

Neon-Flex Series 2
User Manual
www.ledpro.eu [email protected]

Contents
1) Introduction P1
2) Product overview P2
3) Installation Guide P4
4) P6
5)
Mounting product
P9
Electrical connections
6) P12
DIY connector assembly instruction
www.ledpro.eu [email protected]

User Manual | page 1
Horizontal Bending
class 2
Class 2
ELECTRICAL
68
I gressn
Rating
LM-80
Rating
Impact UV
Protected
Corrosion
Resistant
Dirt
Resistant
Saltwater
Resistant
B
One bin only
This user manual is intended to cover as
much detail as possible for this product,
and great care has been taken to ensure
this and the accuracy of the information
contained within, however should
additional information or clarication be
required that is not covered within this
manual or associated data sheets, or if
there are any uncertainties regarding the
installation and operation of this product,
Distributor MUST be contacted before
any work is carried out on the xture or
associated products.
FAILURE TO COMPLY WITH THIS
MANUAL AND LOCAL ELECTRICAL
AND CONSTRUCTION REGULATIONS
MAY RESULT IN SERIOUS INJURY
OR EVEN DEATH - ALWAYS ISOLATE
POWER BEFORE WORKING ON
ELECTRICAL PRODUCTS AND ENSURE
ADEQUATE MEASURES ARE TAKEN TO
MECHANICALLY SUPPORT FIXTURES AT
ALL TIMES.
1.Introuduction
Traditional glass neon has been the mainstay of commercial lighting for decades,
providing a rich, vibrant source of light for commercial buildings and signs. Despite
its attractive features it has numerous drawbacks, including the large amount of
energy it requires, the extremely high voltage power supplies, and being hand
drawn glass it is extremely fragile. Neon-Flex overcomes all of these drawbacks by
combining the energy efciency of high output SMD LEDs encased in a UV and
chemical resistant PVC that acts to diffuse the light
mimicking the effect of neon.
Unlike neon, however, Neon- Flex can be shaped and bent by anyone without the
need for special tools or skills, the low voltage 24V DC alternative can be cut every
50 - 130mm (depending on model) and can operate of a plug in power supply.Unlike
traditional neon - It is not just available in mono colors, with RGB Neon-Flex cable
of producing up to 16 million color variations, the new Dynamic DMX version
expands further on this and allows for exciting color chasing effects.
LED Neon-Flex can be divided with different bending direction between horizontal
& vertical, also the shape and emitting beam angle are not the same.
Vertical Bending
Printed Circuit Board
Outer sleeve
PVC
Spine
Printed Circuit Board
Outer sleeve
PVC
Spine
Printed Circuit Board
Outer sleeve
PVC
Spine
www.ledpro.eu [email protected]

User Manual version 1 | page 2
Emission surface along the top
- Flat rectangular emission surface with 1 -degree beam angle20
- 12cm bend diameter
- Available in static colours including white in CCT ranging from 2200 - 6500K
(please refer to our online data sheets for the exact color range)
- Color options include RGB, RGBW, DW and Pixel
- DMX/RDM, DALI and 0-10V control options
BEAM
ANGLE
1°20 10W/m
POWER
450
lm/m
6500K
LUMEN
420
lm/m
2200K
COLOUR
TEMP
2200K
- 6500K
COLOUR
RENDER
CRI>80
(WHITE)
RGB N/A
MIN.
BENDING
DIA
12cm
MIN.
LENGTH
8.3 cm3
MAX.
LENGTH
20m
CONTROLS
DMX/RDM
RGB
COLOUR
OPTIONS
DW PIXEL
RGBW
Top Flat Shape
Bending lines of light in white or colour,
with light emissions from the top
BEAM
ANGLE
1°20 10W/m
POWER
550
lm/m
6500K
LUMEN
480
lm/m
2200K
COLOUR
TEMP
2200K
- 6500K
COLOR
RENDER
CRI>80
MIN.
BENDING
DIA
8cm
MIN.
LENGTH
8.3 cm3
MAX.
LENGTH
20m
LUMEN
Emission surface along the top
- Flat rectangular emission surface with 1 -degree beam angle20
- 8cm bend diameter
- Available in static colors including white in CCT ranging from 2200 - 6500K
(please refer to our online data sheets for the exact color range)
-Color options include , , andred green blue lemon yellow
- DALI and 0-10V control optionsdimmer
- Mini version available in mono onlyis
Top Flat Mini Shape
Bending lines of light in white or color,
with light emissions from the top
2.Product Overview
16 5mm.
16 5mm.
13 5mm.
13 5mm.
Silicone circle
Waterproof Treatment
Silicone circle
Waterproof Treatment
!Move off waterproof treatment without warranty
www.ledpro.eu [email protected]

User Manual version 1 | page 3
Flat rectangular emission surface with 1 -degree beam angle20
- 8/12cm bend diameter, dependant on variant
- Available in static colors including white in CCT ranging from 2200 - 6500K
(please refer to our online data sheets for the exact colour range)
- Color options include RGB, RGBW, DW and Pixel
- DMX/RDM, DALI and 0-10V control options
BEAM
ANGLE
1°20 515W- W
POWER
380
lm/m
6500K
LUMEN
340
lm/m
2200K
COLOUR
TEMP
2200 -K
6500K
COLOR
RENDER
CRI>80
(WHITE)
RGB N/A
MIN.
BENDING
DIA 8cm
(MONO)
DIA 12cm
(RGB)
MIN.
LENGTH
8.3 cm3
MAX.
LENGTH
15m
CONTROLS
DMX/RDM
RGB
COLOR
OPTIONS
DW PIXEL
RGBW
- Emission surface to the side
- Rounded emission surface with 270-degree beam angle
- 8/12cm bend diameter, dependant on variant
- Available in static colors including white in CCT ranging from 2200 - 6500K
(please refer to our online data sheets for the exact colour range)
- Color options include RGB, RGBW, DW and Pixel
- DMX/RDM, DALI and 0-10V control options
BEAM
ANGLE
270°
MIN.
BENDING
DIA 8cm
(MONO)
DIA 12cm
(RGB)
MIN.
LENGTH
MAX.
LENGTH
DMX/RDM
CONTROLS
Side Flat Shape
Bending lines of light in white or color,
with light emissions from the Side
O
10cm
12 5.cm
16 67.cm
Side Round Shape
Visually dramatic effects with a wider beam angle
light emission surface
515W- W
POWER
380
lm/m
6500K
LUMEN
340
lm/m
2200K
COLOUR
TEMP
2200 -K
6500K
RENDER
CRI>80
(WHITE)
RGB N/A
RGB
COLOR
OPTIONS
DW PIXEL
RGBW
515W- W
POWER
302
lm/m
6500K
LUMEN
280
lm/m
2200K
COLOR
TEMP
2200 -K
6500K
COLOR
RENDER
CRI>80
(WHITE)
RGB N/A
RGB
COLOR
OPTIONS
DW PIXEL
RGBW
20m
10m
8.3 cm3
15m
10cm
12 5.cm
16 67.cm 20m
10m
21mm
11.5mm
29mm
15.5mm
11.5mm
Option
Option
Silicone circle
Waterproof Treatment
Silicone circle
Waterproof Treatment
!Move off waterproof treatment without warranty
!Move off waterproof treatment without warranty
www.ledpro.eu [email protected]

User Manual version 1 | page 4
This product left the place of manufacture in perfect condition.
In order to maintain this condition and for safe operation, the user must always follow
the instructions and safety warnings described in this user manual.
Safety Warning!
General
- This product must be installed by a qualied and competent professional.
- When working on the xture, heat resistant gloves should be worn to provide
adequate user protection.
- Do not work on the product with wet hands.
- Always disconnect the power supply before attempting to maintain or service
the equipment.
- Always operate the equipment as described in this user manual.
- Do not stand close to the equipment and stare directly into the LED light source.
- Make sure that all parts of the equipment are kept clean and free of dust which
should be carried out as part of a maintenance cycle that’s appropriate for the
installation location of the product.
- When transferring the product, it is advisable to use the original packaging in
which the product left the factory.
- Shields, lenses, ultraviolet screens and pressure release valves should be
changed if they have become damaged to such an extent that their
effectiveness is impaired.
- The lamp (LED) should be changed if it has become damaged or thermally
deformed.
- The power supply (PSU), DMX/RDM driver and LED drivers should be changed if
they fail to operate.
Installation
- A minimum distance of 0.5m must be maintained between the equipment and
any combustible surface. The mounting surface must not be combustible.
- Always ensure the supporting structure is a at and solid surface and can support
the weight of the product and any additional wind or shear force. The supporting
structure must be capable for the installation of luminaires, and advice must be
taken from an appropriately qualied and competent person to verify proposed
mounting positions and surfaces.
- Always make sure that the equipment is installed securely and ensure all safety
anchors are installed.
- The product must be installed within well-ventilated areas.
- The Earth wire MUST ALWAYS be connected.
- Local electrical and building regulations must be followed. If in doubt, please
contact support.distributor
- Avoid shaking or strong impacts to any part of the equipment.
- Always make sure that the power and data connections are connected correctly
and securely. If there is any malfunction of the equipment, contact your local
distributor immediately.
- This xture should not be buried.
3 Installation Guide.
This user manual is intended to cover as
much detail as possible for this product,
and great care has been taken to ensure
this and the accuracy of the information
contained within, however should
additional information or clarication be
required that is not covered within this
manual or associated data sheets, or if
there are any uncertainties regarding the
installation and operation of this product,
Distributor MUST be contacted before
any work is carried out on the xture or
associated products.
FAILURE TO COMPLY WITH THIS
MANUAL AND LOCAL ELECTRICAL
AND CONSTRUCTION REGULATIONS
MAY RESULT IN SERIOUS INJURY
OR EVEN DEATH - ALWAYS ISOLATE
POWER BEFORE WORKING ON
ELECTRICAL PRODUCTS AND ENSURE
ADEQUATE MEASURES ARE TAKEN TO
MECHANICALLY SUPPORT FIXTURES AT
ALL TIMES.
Caution, risk of electric shock
The light source and other
electronic components
contained in this luminaire
shall only be replaced by
y or an approvedour distributor
service agent.
www.ledpro.eu [email protected]

User Manual version 1 | page 5
Specic Installation
- Although this product does not generate a great amount of heat, it is
recommended that you do not cover or conceal it.
- Do not route the product through walls, doors, windows, or building structures.
- Do not roll out the product onto rough surfaces or over sharp corners. This will
scratch the PVC optics and damage the nish of the product.
- Do not use the product if:
The outer PVC jacket is damaged
There are loose electrical connections
The wires are visible without insulation.
- Do not secure the product with staples, nails, or alike that might damage the
insulation or PVC material.
- Do not install the product on/in places where it is subject to continuous exing.
- Do not operate/run the product in temperatures exceeding 45C or 113F.
- Do not operate the product over the specied voltage or LED life degradation
will be greatly increased.
- Do not leave any part of the product unsecured.
- Constant movement over time from weather can cause damage.
- Do not reverse polarity when connecting from both ends. This will damage the
internal PCB. Always test connections with a multi-meter before applying power.
- Do not energise the product whilst in packaging.
- The product can be cut only where marked. Look for the “Dotted Line” or
“Scissor Mark”. A cut section must have the appropriate IP rated capex
accessory to maintain IP ratings.
- Cutting outside of the specied mark will damage the light.
- Do not cut while the LED ex neon is connected to power.
- Do not install in human inhabited pools.
- Must always be used with an electrical isolation transformer providing SELV
(safety extra low voltage).
This user manual is intended to cover as
much detail as possible for this product,
and great care has been taken to ensure
this and the accuracy of the information
contained within, however should
additional information or clarication be
required that is not covered within this
manual or associated data sheets, or if
there are any uncertainties regarding the
installation and operation of this product,
Distributor MUST be contacted before
any work is carried out on the xture or
associated products.
FAILURE TO COMPLY WITH THIS
MANUAL AND LOCAL ELECTRICAL
AND CONSTRUCTION REGULATIONS
MAY RESULT IN SERIOUS INJURY
OR EVEN DEATH - ALWAYS ISOLATE
POWER BEFORE WORKING ON
ELECTRICAL PRODUCTS AND ENSURE
ADEQUATE MEASURES ARE TAKEN TO
MECHANICALLY SUPPORT FIXTURES AT
ALL TIMES.
Caution, risk of electric shock
The light source and other
electronic components
contained in this luminaire
shall only be replaced by
y or an approvedour distributor
service agent.
- Do not cut off the cable wire between the waterproof treatment and connector.
www.ledpro.eu [email protected]

User Manual version 1 | page 6
4. Mounting Product
L is a highly durable product but must be installed in accordance to the picturesED neon ex
shown below, which indicate the minimum bending parameters as well as the correctly
bending direction for each specic variant of .model
Top Flat and Top Flat Mini
LED neon ex must be installed by at least 2 people, who can support the product in various
locations as shown. During installation, care should be taken to ensure the bending
radius of is not exceeded.ex
Ø80mm
Light direction
Light prole Minimum bending direction
Top  at
Bend vertically only
Minimum bending direction
Top at mini
Light emitting surface
Light emitting surface
Ø80mm
Ø120mm
Ø120mm
Top  at
Light direction
Light emitting surface
Light emitting surface
Bend vertically only
Top at mini
16.5mm
16.5mm
13.5mm
13.5mm
Light prole
www.ledpro.eu [email protected]

User Manual version 1 | page 7
L is a highly durable product but must be installed in accordance to the picturesED Neon ex
shown below, which indicate the minimum bending parameters as well as the correctly
bending direction for each specic variant of model
Side Flat and Side Round
L must be installed by at least 2 people, who can support the product in variousED neon ex
locations as shown. During installation, care should be taken to ensure the bending
radius of is not exceeded.ex
General D NOTSO
The images give indication as to what
is not acceptable as an intended
installation or during installation of
other xing methods.
Light prole Minimum bending direction
Light prole Minimum bending direction
Side Round
×××
Bend horizontal only
Bend horizontal only
Side at Side at
Ø120mm
Light emitting surface
Light emitting surface
Light emitting surface
Light emitting surface
Side Round
Light direction
Light direction
11.5mm
21mm
11.5mm
29mm Ø120mm
www.ledpro.eu [email protected]

User Manual version 1 | page 8
Aluminum prole
Installation surface
Screw
(Wood or concrete wall)
Installation direction
Installation direction Installation direction
Press the Neon-Flex into mounted aluminum channel in one direction.
Mount the cable junction in hermetic enclosure like
waterproof junction box in outdoor application.
Waterproof
connector or
junction box
Incorrect installation like below picture could lead to light failure.
<100mm
>100m
m
>10mm
>10mm
Do not bend against light terminals;
otherwise it will lead to failure of
connector waterproof.
Pull
>10mm
Ensure the feeding cable not bear force,
keep the head10mm in natural loose.
Power Supply
General Mounting
LED neon ex can be fastened to surfaces using appropriate accessories available from
distributor. Please refer to data sheets or contact technical support for a copy. The use
of glues and resins as xing agents should be avoided. Use of glues and resins may
invalidate the warranty of the product, unless it’s use is agreed in writing by distributor
as part of a detailed project specication.
The images indicate one type of xing available in the accessories range. The different
xings serve obvious purposes, however when in doubt technical support should be
contacted.
Quantities of accessories and xings are dependent on the type and its effect on the
variant ex it’s being used with. Care should be taken to ensure drooping is avoided,
and to ensure that neon ex is fastened adequately to avoid stresses on product itself.
The aluminum mounting piece of IP67 front connector and end cap should keep
at least10mm space apart from aluminum channel when making installation.
www.ledpro.eu [email protected]

5 DIY connector assembly instruction.
Max 0m1
Silicone Rubber
Locate the cutting mark on the side of the LED Neon Flex.
This will be designated by a vertical dashed line.
Using LED neon cutter, make an even cut through exactly on the mark.
If you are off the mark the product can be damaged.
The correct cutting way, R= 90
R>90 or R<90 , is incorrect°
Wave cutting is incorrect
1.Place the anti-skidding clip on
the very end of the tubing with
the 2 tiny tabs that are pointing
inwards still touching the end of
the material and crimp in place.
2.Line up the aluminum
mounting piece so the screw
holes face the plug and slide on
over the anti-skidding clip.
Aluminum mounting piece
Anti-skidding Clip
5.Carefully insert the pins of the front connector
into the gap you created behind the PCB.
PCB
LED
4.Put 100% clear silicone
on the surface of rubber
Rubber gasket
3.Insert the rubber gasket along the
slit into the pin of the front connector
6.Screw the front connector
to the aluminum mounting
piece.
7.Check the connection to ensure it is tight and that there
are no gaps between the Neon Flex tube and the front connector.
Top at DIY screw front connector kit instructions
Top at DIY screw End cap kit instruction
Blank end
Anti-skidding clip Aluminum mounting piece
Rubber gasket Screw
Silicone Rubber
Rubber gasket
User Manual version 1 | page 9
End Cap
Front Connector
LED Neon ex
R
L
24V
+
BUSI
R
L
24V
+
Cutting mark
gasket
www.ledpro.eu [email protected]

Side at DIY screw front connector kit instructions
The correct cutting way, R= 90
R>90 or R<90 , is incorrect°
Wave cutting is incorrect
LED Neon ex
Anti-skidding Clip
1.Place the anti-skidding clip on
the very end of the tubing with
the 2 tiny tabs that are pointing
inwards still touching the end of
the material and crimp in place.
2.Line up the aluminum
mounting piece so the screw
holes face the plug and slide on
over the anti-skidding clip.
Aluminum mounting piece
R
L
24V
+
BUSI
L
24V
Cutting mark
R
+
R
L
24V
+
Rubber gasket
6.Screw the front connector
to the aluminum mounting
piece.
5.Carefully insert the pins of the front connector
into the gap you created behind the PCB.
5.Carefully insert the pins of the front connector
into the gap you created behind the PCB.
7.Check the connection to ensure it is tight and that there
are no gaps between the Neon Flex tube and the front connector.
User Manual version 1 | page 10
Screw
Blank end
Rubber gasket
Anti-skidding clip Aluminum mounting piece
Side at DIY screw end cap kit instruction
Rubber gasket
Silicone Rubber
Silicone Rubber
End Cap
Front Connector
PCB
4.Put 100% clear silicone
on the surface of rubber
3.Insert the rubber gasket along the
slit into the pin of the front connector
gasket
www.ledpro.eu [email protected]

The correct cutting way, R= 90
R>90 or R<90 , is incorrect°
Wave cutting is incorrect
BUSI
Cutting mark
R
L
24V
+
R
+
L
24V
R
L
24V
+
L
24V
R
L
24V
+
Side Round DIY screw front connector kit instructions
LED Neon ex
Anti-skidding Clip
1.Place the anti-skidding clip on
the very end of the tubing with
the 2 tiny tabs that are pointing
inwards still touching the end of
the material and crimp in place.
2.Line up the aluminum
mounting piece so the screw
holes face the plug and slide on
over the anti-skidding clip.
Aluminum mounting piece
Rubber gasket
6.Screw the front connector
to the aluminum mounting
piece.
5.Carefully insert the pins of the front connector
into the gap you created behind the PCB.
5.Carefully insert the pins of the front connector
into the gap you created behind the PCB.
7.Check the connection to ensure it is tight and that there
are no gaps between the Neon Flex tube and the front connector.
User Manual version 1 | page 11
Screw
Blank end
Rubber gasket
Anti-skidding clip Aluminum mounting piece
Side Round DIY screw end cap kit instruction
Rubber gasket
Silicone Rubber
Silicone Rubber
PCB
Front Connector End Cap
4.Put 100% clear silicone
on the surface of rubber
3.Insert the rubber gasket along the
slit into the pin of the front connector
gasket
www.ledpro.eu [email protected]

User Manual version 1 | page 12
6. Electrical Connections
moulded. There are two options available for all versions, these are bare end cables
or plugs.
Bare end cables come with a standard length which can vary pending the
manufacturing process, therefore it is recommended to ensure the feeder cable is
long enough to reach the cable entry point of , where connections can be made.ex
Plugs are designed for “plug-and-play” type installations, whereas the installer would
ensure female sockets are available at each start location, with the male typeex
connector then plugging into this female type socket. Female sockets are
available as separate items.
Note that custom feed cable lengths are available upon special request.
L is a high-powered product, which requires a detailed electrical design toED neon ex
ensure equal balancing of loads across drivers and power supplies. Reference can be
made to the various data sheets for specic variants, that indicate the operating voltage
and the wattage per metre. Technical support is on hand to assist with control and power
design. operates at 24Vdc unless otherwise stated in specic data sheets orProduct
product labels. Care should be taken to ensure the operating voltage is constant
(constant voltage). A maximum volt drop of 5% is allowed (for example at 24Vdc, the
maximum voltage drop would be 1.2V meaning a delivered voltage of 22.8V to the
xture.
Providing with an extensive range of power supplies, LED Drivers, SPI pixel
gateways and various DC-DC transformers which allow installers to overcome volt
drop issues, as well as various control options such as stand-alone DMX interfaces to
multi-universe video matrix type products. also has an in-house designWe
and engineering team that can deliver such systems, please contact support for more
information.
Below is a guide which indicates the number of cores and the connections they relate
to. Each manufactured length of will have a factory tted label which indicatesex
the correct cores to use, as well as the colour of each specic core and its associated
connection. The below guide is in black and white for clarity, and reference should
always be made to the label on the product itself as sometimes, the cable colours may
vary pending manufacturing processes or for custom orders. If in doubt, or if the label
is missing, contact support for assistance before connecting to power.
End(bare end cable and plug)
Side(bare end cable and plug)
Bottom(bare end cable and plug)
Mono RGB RGBW
Turnable White Pixel SPI Dynamic Pixel DMX -1
Red - 24V+
Black - Gnd
Green - Green
Red - Red
Black - Blue
Yellow - 24V+
Red - 24V+
White - Cold white
Black - Warm white
Red - 24V+
Yellow - Data
Black - Gnd
Red - Red
Green - Green
Black - Blue
White - White
Yellow - 24V+
Red - 24V+
Black - Gnd
Yellow - Data
Green - Address
L is manufactured to order, meaning that the appropriate power feeds areED neon ex
Dynamic Pixel DMX -2
Red - 24V+
Yellow - DMX +
Green- Address
White - Gnd
Blue - DMX-
www.ledpro.eu [email protected]

90-264V AC
24V output
Class 2 Power Supply
Connection Length
Each model of neon ex has the max. length in the connection with power supply.
Maximum individual length with one power end feed : 10m
When it approach to the max. length, that means it need to be power
Maximum individual length with both power end feed : 20m
Customized Length
Waterproof Power supply
Non-waterproof Power supply
both ends. The details for connection please check as follow.
User Manual version 1 | page 13
www.ledpro.eu [email protected]
