Ledco V1-W User manual

+
V1-W L ED RF Dim mer
Uin: 12-24 VDC
Iout : Max.3 A
Out put
V+
V-
Input
Remote function
Dimension
Feature
Model No.: V1-W+ RM1
1 channels constant voltage/6-key remote/Step-less dimming/Wireless remote 30m distance
Single Color LED Controller Kit
User Manual Ver 1.0.2 Page 1
V1-W+ RM1 Single Color LED Controller Kit
14.00 mm
60.00 mm
Note: Before the first use,
please remove the protective film on the battery.
CR2032 Battery
47.00 mm
100.00 mm
8.00 mm
10% brightness for small night light
Brightness+
50% brightness
On/Off
Brightness-
30s
30s Turn off light after 30s, long press 2s will turn off light after 60s.
Brightness+/-:
Short press 10 levels, long press 1-6s for continuous 256 levels adjustment.
RM1 LED Remote Input and Output
Operation temperature
Case temperature (Max.)
Environment
IP20
IP rating
Ta: -30
O
C ~ +55
O
C
T c: +85
O
C
Output signal RF 2.4GHz( )
Working voltage 3VDC CR2032( )
Working current ＜5mA
Standby current ＜2μA
Standby time 2 years
Remote distance 30m(Barrier-free space)
Safety and EMC
EMC standard (EMC) EN301 489,EN 62479
Radio Equipment(RED) EN300 328
Certification CE,EMC,LVD,RED
EN60950
Safety standard(LVD)
Technical Parameters
Dimming data
Dimming range
RF 2.4GHz
30m(Barrier-free space)
4096 (2^12) levels
0 -100%
Input signal
Control distance
Dimming gray scale
500Hz (default)
PWM Frequency
Dimming cur ve Logarithmic
Warranty and Protection
5 years
Protection Reverse Polarity
Warranty
V1-W LED Receiver Input and Output
Output type Constant voltage
Output power Max. 75W
Output voltage 12-24VDC
Input voltage 12-24VDC
30s
● 1 channel constant voltage single color LED mini RF controller.
● 3A per channel, output connect with 5 meters LED strip, max output power 75W.single color
● Adopt 2.4GHz wireless technology, remote distance up to 30m.
● 4096 levels 0-100% dimming smoothly without any flash.

1. The product shall be installed and serviced by a qualified person.
2. The product is non-waterproof. Please avoid the sun and rain.
3. Good heat dissipation will prolong the working life of the controller. Please ensure good ventilation.
4. Please check if the output voltage of any power supplies used comply with the working voltage of the
product.
5. Ensure all wire connections and polarities are correct and secure before applying power to avoid any
damages to the LED lights.
6. If a fault occurs please return the product to your supplier. Do not attempt to fix this product by yourself.
Safety information
Malfunctions analysis & troubleshooting
Malfunctions
Causes Troubleshooting
Uneven intensity
between front and
rear,with voltage drop
1. Output cable is too long.
2. Wire diameter is too small.
3. Overload beyond power supply capability.
4. Overload beyond controller capability.
1. Reduce cable or loop supply.
2. Change wider wire.
3. Replace higher power supply.
4. Add power repeater.
No response
from the remote
1. The battery has no power.
2. Beyond controllable distance.
3. The controller did not match the remote.
1. Replace batter y.
2. Reduce remote distance.
3. Re-match the remote.
1. No power.
2. Wrong connection or insecure.
1. Check the power.
2. Check the connection.
No light
Wiring diagram
User Manual Ver 1.0.2 Page 2
V1-W+ RM1 Single Color LED Controller Kit
Dimming remote
+
-
Power Supply
12-24VDC
Constant Voltage
AC100-240V
5m single color LED strip
+
V1 -W L ED R F Di mm er
Uin :12-2 4VDC
Iou t: Max. 3A
Outp ut
V+
V-
Inpu t
Match:
Switch off the power, then switch on power again, immediately short press on/off key 3 times on the remote.
The light blinks 3 times means match is successful.
Delete:
Switch off the power, then switch on power again, immediately short press on/off key 5 times on the remote.
The light blinks 5 times means all matched remotes were deleted.
Match guide
