User Manual

Page 2 of 20 Intimidator™ Spot LED 350 User Manual (Rev. 6)
TABLE OF CONTENTS
1. Before You Begin................................................................................3
What Is Included ...........................................................................................3
Unpacking Instructions..................................................................................3
Claims...................................................................................................................3
Text Conventions ..........................................................................................3
Symbols........................................................................................................3
Document Information...................................................................................3
Product at a Glance.......................................................................................4
Safety Notes .................................................................................................4
2. Introduction.........................................................................................5
Product Overview..........................................................................................5
Product Dimensions......................................................................................6
3. Setup...................................................................................................7
AC Power......................................................................................................7
Fuse Replacement.................................................................................................7
Power Linking........................................................................................................8
Mounting.......................................................................................................9
Orientation.............................................................................................................9
Rigging..................................................................................................................9
4. Operation ..........................................................................................10
Control Panel Operation..............................................................................10
Menu Map...................................................................................................10
Configuration (DMX)....................................................................................11
Starting Address ..................................................................................................11
DMX Personalities................................................................................................11
DMX Channel Assignments and Values.......................................................12
14-CH..................................................................................................................12
DMX Channel Assignments and Values (cont.)............................................13
8-CH....................................................................................................................14
Configuration (Standalone)..........................................................................15
Sound-Active Mode..............................................................................................15
Automatic Mode...................................................................................................15
Manual Pan/Tilt Operation....................................................................................15
Pan/Tilt Angle Range...........................................................................................15
Display................................................................................................................15
Master/Slave Mode..............................................................................................16
Reset Software............................................................................................16
Password Channel ......................................................................................16
Changing Gobos.........................................................................................17
5. Technical Information ......................................................................18
Product Maintenance ..................................................................................18
Returns.......................................................................................................19
Contact Us..................................................................................................19
6. Technical Specifications..................................................................20

Intimidator™ Spot LED 350 User Manual (Rev. 6) Page 3 of 20
1.BEFORE YOU BEGIN
What Is
Included
•Intimidator™ Spot LED 350
•Hanging Bracket with Mounting
Hardware
•Power Cord
•Warranty Card
•Quick Reference Guide
Unpacking
Instructions
Carefully unpack the product immediately and check the container to make sure all the
parts are in the package and are in good condition.
Claims
If the box or the contents (the product and
included accessories) appear damaged from
shipping, or show signs of mishandling, notify the carrier immediately, not CHAUVET®.
Failure to report damage to the carrier immediately may invalidate your claim. In
addition, keep the box and contents for inspection.
For other issues, such as missing components or parts
, damage not related to shipping,
or concealed damage, file a claim with CHAUVET® within 7 days of delivery.
Text
Conventions
Convention
Meaning
1~512
A range of values
50/60
A set of values of which only one can be chosen
Settings
A menu option not to be modified
Menu > Settings
A sequence of menu options to be followed
<ENTER>
A key to be pressed on the product’s control panel
ON
A value to be entered or selected
Symbols
Symbol Meaning
Critical installation, configuration, or operation information. Not
following these instructions may make the product not work, cause
damage to the product, or cause harm to the operator.
Important installation or configuration information. The product
may not function correctly if this information is not used.
Useful information.
Document
Information
The information and specifications contained in this document are subject to change
without notice. CHAUVET® assumes no responsibility or liability for any errors or
omissions that may appear in this manual.
CHAUVET® reserves the right to update the
existing document or to create a new document to correct any errors or omissions.
You can download the latest version of this document from www.chauvetlighting.com.
© Copyright 2013 CHAUVET®. All rights reserved.
Electronically published by CHAUVET® in the United States of America
Author
Date
Editor
Date
A. Leon 04/02/13 D. Couppe 4/3/13

Page 4 of 20 Intimidator™ Spot LED 350 User Manual (Rev. 6)
Product at a
Glance
Use on Dimmer
x
Auto Programs
P
Outdoor Use
x
Auto-ranging Power Supply
P
Sound-Activated
P
Replaceable Fuse
P
DMX
P
User-Serviceable
x
Master/Slave
P
Duty Cycle
x
Safety Notes
These notes include important information about the mounting, usage, and maintenance
of this product; read before using the product.
•This product is not intended for permanent installation.
•Always connect the product to a grounded circuit to avoid the risk of electrocution.
•Always disconnect the product from power before cleaning or replacing the fuse.
•Avoid direct eye exposure to the light source while the product is on.
•Make sure the power cord is not crimped or damaged.
•Never disconnect the product from power by pulling or tugging on the cord.
•If mounting the product overhead, always secure to a fastening device using a
safety cable.
•Make sure there are no flammable materials close to the product when operating.
•
Do not touch the product’s housing when operating because it may be very hot.
•Always make sure that the voltage of the outlet to which you are connecting the
product is within the range stated on the decal or rear panel of the product.
•The product is for indoor use only! (IP20) To prevent risk of fire or shock, do not
expose the product to rain or moisture.
•Always install the product in a location with adequate ventilation, at least 20 in
(50 cm) from adjacent surfaces.
•Be sure that no ventilation slots on the product’s housing are blocked.
•Never connect the product to a dimmer.
•Make sure to replace the fuse with another of the same type and rating.
•Never carry the product from the power cord or any moving part. Always use the
hanging/mounting bracket or the handles.
•The maximum ambient temperature (Ta) is 104° F (40° C). Do not operate the
product at higher temperatures.
•In the event of a serious operating problem, stop using the product immediately.
•Never try to repair the product. Repairs carried out by unskilled people can lead to
damage or malfunction. Please contact the nearest authorized technical assistance
center.
•Keep this User Manual for future use. If you sell the product to another user, be
sure to give this document to the next owner.

Intimidator™ Spot LED 350 User Manual (Rev. 6) Page 5 of 20
2.INTRODUCTION
Product Overview
Control Panel and
Button Menu
DMX Out
Safety Loop
Fuse Holder
DMX In
Power In
Power Out

Page 6 of 20 Intimidator™ Spot LED 350 User Manual (Rev. 6)
Product Dimensions

Intimidator™ Spot LED 350 User Manual (Rev. 6) Page 7 of 20
3.SETUP
AC Power
The Intimidator™ Spot LED 350 has an auto-
ranging power supply and it can work with
an input voltage range of 100~240 VAC, 50/60 Hz.
To determine the product’s power requirements (circuit breaker, power outlet, and
wiring), use the current value listed on the label affixed to the product’s back panel, or
refer to the product’s specifications chart. The listed current rating indicates the
product’s average current draw under normal conditions.
Always connect the product to a protected circuit
(circuit breaker or fuse). Make
sure the product has
an appropriate electrical ground to avoid the risk of
electrocution or fire.
Never connect the product to
a rheostat (variable resistor) or dimmer circuit, even
if the rheostat or dimmer channel serves only as a 0 to 100% switch.
Fuse
Replacement
Disconnect the product from power before replacing the fuse.
1. Disconnect the product from power.
2. Using a Phillips #2-head screwdriver, unscrew the fuse holder
cap from the housing.
3. Remove the blown fuse.
4. Replace with a fuse of the same type and rating.
5. Screw the fuse holder cap back in place and reconnect power.
Always replace a blown fuse with another of the same type and rating.

Page 8 of 20 Intimidator™ Spot LED 350 User Manual (Rev. 6)
Power Linking
The product provides power linking via the IEC outlet located in the back of the unit.
Power Linking
Diagram
You can power link up to 3 Intimidator™ Spot LED 350 units on 120 VAC or up to 7
Intimidator™ Spot LED 350 units on 230 VAC.
The power linking diagram shown above corresponds to the North American
version of the product ONLY! If using the product
in other markets, you must
consult with the local CHAUVET® distributor as power linking connectors and
requirements may differ in your country or region.
1st Product
2nd Product
3rd Product
Other products

Intimidator™ Spot LED 350 User Manual (Rev. 6) Page 9 of 20
Mounting
Before mounting the product
, read and follow the safety recommendations indicated in
the Safety Notes.
Orientation
The Intimidator™ Spot LED 350
may be mounted in any position; however, make sure
adequate ventilation is provided around the product.
Rigging
•Before deciding on a location for the product, always make sure there is easy
access to the product for maintenance and programming purposes.
•Make sure that the structure or surface onto which you are mounting the product
can support the product’s weight. See the Technical Specifications
for weight
information.
•When mounting the product overhead, always use a safety cable.
Mount the
product securely to a rigging point, whether an elevated platform or a truss.
•When rigging the product onto a truss, you should use a mounting clamp of
appropriate weight capacity.
•When power linking multiple products, you must always consider the length of the
power linking cable and mount the products close enough for the cable to reach.
•The rubber feet also serve as floor supports. When mounting the product
on the
floor, make sure that the product and cables are away from people and vehicles.
Mounting Diagram
Rubber Feet (x4)
Safety Loop
Attachment Point
Bracket
Attachment (x2)

Page 10 of 20 Intimidator™ Spot LED 350 User Manual (Rev. 6)
4.OPERATION
Control Panel
Operation
To access the control panel functions, use the four buttons located underneath the
display.
Button
Function
<MODE/ESC>
Press to find an operation mode or to back out of the current menu
option
<UP> Press to scroll up the list of options or to find a higher value
<DOWN>
Press to scroll down the list of options or to find a lower value
<ENTER>
Press to activate a menu option or a selected value
Menu Map
Mode Programming Steps Description
DMX Mode
001~512
Sets the DMX starting address
Operation
Modes
SLAv (Son) Slave operating mode
NASL (SLoU) Automatic mode, Slow program
NAFA (FASt) Automatic mode, Fast program
NStS (SrUn)
Sound-Active mode
Pan
Normal Pan
PAn
Normal Pan operation
Inverse Pan r PAn Inverse Pan operation
Tilt
Normal Tilt
tiL
Normal Tilt operation
Inverse Tilt r tiL Inverse Tilt operation
Display
Normal
Display
diS Change the LCD display text position
Inverse
Display r diS
Channel Mode
14-Channel
Mode 14CH Selects the DMX personality
8-Channel
Mode 8CH
Manual Pan
Range
Pan 540
PA54
Select Pan angle rangePan 360 PA36
Pan 180 PA18
Manual Tilt
Range
Tilt 270 Ti27 Select Tilt angle range
Tilt 180
Ti18
Tilt 90 Ti 9
Reset
rESt
Resets fixture
Load
LoAd
Load factory defaults

Intimidator™ Spot LED 350 User Manual (Rev. 6) Page 11 of 20
Configuration
(DMX)
Set the product in DMX mode to control with a DMX controller.
1. Connect the product to a suitable power outlet.
2. Turn the product on.
3. Connect a DMX cable from the DMX output of the DMX controller to the DMX input
socket on the product.
Starting Address
When selecting a starting DMX address, always consider the number of DMX channels
the selected DMX mode uses. If you
choose a starting address that is too high, you could
restrict the access to some of the product’s channels.
The Intimidator™ Spot LED 350 uses up to 14 DMX channels in its 14-channel DMX
mode, which defines the highest configurable address to 499.
If you are not familiar with the DMX protocol,
download the DMX Primer from
www.chauvetlighting.com.
To select the starting address, do the following:
1. Press <MODE/ESC> repeatedly until 001 shows on the display.
2. Press <ENTER>.
3. Use <UP> or <DOWN> to select the starting address.
4. Press <ENTER>.
DMX
Personalities
The Intimidator™ Spot LED 350 has two DMX personalities, an 8-channel
personality and
a 14-channel personality.
To choose which DMX personality to use, follow the steps below:
1. Press <MODE/ESC> repeatedly until either 14CH (to choose the 14-channel
personality) or 8CH (to choose the 8-channel personality) shows on the display.
2. Press <ENTER>.

Page 12 of 20 Intimidator™ Spot LED 350 User Manual (Rev. 6)
DMX Channel Assignments and Values
14-CH
Channel Function Value Setting
1
Pan
000 ó255
0–540°
2
Fine Pan
000 ó255
Fine control of panning
3
Tilt
000
ó
255
0–270°
4
Fine Tilt
000 ó255
Fine control of tilting
5
Speed
000 ó255
Pan/Tilt speed (fast to slow)
6 Color Wheel
000 ó006
White
007 ó013
Yellow
014 ó020
Pink
021 ó027
Green
028 ó034
Red
035 ó041
Light Blue
042 ó048
Kelly Green
049
ó
055
Orange
056 ó063
Dark Blue
064 ó070
White + Yellow
071 ó077
Yellow + Pink
078 ó084
Pink + Green
085 ó091
Green + Red
092 ó098
Red + Light Blue
099 ó105
Light Blue + Kelly Green
106 ó112
Kelly Green + Orange
113 ó119
Orange + Dark Blue
120 ó127
Dark Blue + White
128 ó191
Color cycling rainbow with increasing speed
192 ó255
Reverse color cycling rainbow with increasing
speed
7 Gobo Wheel
064 ó071
Gobo 7 shake, from slow to fast
072 ó079
Gobo 6 shake, from slow to fast
080 ó087
Gobo 5 shake, from slow to fast
088 ó095
Gobo 4 shake, from slow to fast
096 ó103
Gobo 3 shake, from slow to fast
104 ó111
Gobo 2 shake, from slow to fast
112
ó
119
Gobo 1 shake, from slow to fast
120 ó127
Open
128 ó191
Cycle effect with increasing speed
192 ó255
Reverse cycle effect with increasing speed

Intimidator™ Spot LED 350 User Manual (Rev. 6) Page 13 of 20
DMX Channel Assignments and Values (cont.)
14-CH (cont.)
Channel Function Value Setting
8 Gobo Rotation
000 ó063
Indexing
064 ó147
Rotation effect with increasing speed
148 ó231
Reverse rotation effect with increasing speed
232 ó255
Gobo bounce
9 Prism
000 ó007
Open
008 ó012
Prism on
013 ó130
Prism rotation with increasing speed
131 ó247
Reverse prism rotation with increasing speed
248 ó255
Prism effect
10
Focus
000
ó
255
Motor focus, zoom out to zoom in
11
Dimmer
000 ó255
0–100%
12 Shutter
000 ó003
Closed
004 ó007
Open
008 ó076
Strobe effect with increasing speed
077 ó145
Pulse strobe
146 ó215
Random shutter
216 ó255
Open
13 Control Functions
000 ó007
No function
008 ó015
Blackout while pan/tilt moving
016 ó023
Blackout while moving color wheel
024 ó031
Blackout while moving gobo wheel
032 ó039
Disable blackout while pan/tilt/moving color wheel
040 ó047
Disable blackout while pan/tilt/moving gobo wheel
048 ó055
Disable blackout while moving all options
056
ó
095
No function
096 ó103
Reset pan
104 ó111
Reset tilt
112 ó119
Reset color wheel
120 ó127
Reset gobo wheel
128 ó135
Reset gobo rotation
136 ó143
Reset prism
144 ó151
Reset focus
152 ó159
Reset all channels
160 ó255
No function
14 Movement Macros
000 ó007
No function
008 ó023
Automatic movement 1
024 ó039
Automatic movement 2
040 ó055
Automatic movement 3
056 ó071
Automatic movement 4
072
ó
087
Automatic movement 5
088 ó103
Automatic movement 6
104 ó119
Automatic movement 7
120 ó135
Automatic movement 8
136 ó151
Sound-active movement 1
152 ó167
Sound-active movement 2
168 ó183
Sound-active movement 3
184 ó199
Sound-active movement 4
200 ó215
Sound-active movement 5
216 ó231
Sound-active movement 6
232 ó247
Sound-active movement 7
248 ó255
Sound-active movement 8

Page 14 of 20 Intimidator™ Spot LED 350 User Manual (Rev. 6)
8-CH
Channel Function Value Setting
1
Pan
000 ó255
0–540°
2
Tilt
000 ó255
0–270°
3 Color Wheel
000 ó006
White
007 ó013
Yellow
014 ó020
Pink
021 ó027
Green
028 ó034
Red
035 ó041
Light Blue
042 ó048
Kelly Green
049 ó055
Orange
056 ó063
Dark Blue
064 ó070
White + Yellow
071 ó077
Yellow + Pink
078 ó084
Pink + Green
085 ó091
Green + Red
092 ó098
Red + Light Blue
099
ó
105
Light Blue + Kelly Green
106 ó112
Kelly Green + Orange
113 ó119
Orange + Dark Blue
120 ó127
Dark Blue + White
128 ó191
Color cycling rainbow with increasing speed
192 ó255
Reverse color cycling with increasing speed
4 Gobo Wheel
064 ó071
Gobo 7 shake, from slow to fast
072 ó079
Gobo 6 shake, from slow to fast
080 ó087
Gobo 5 shake, from slow to fast
088 ó095
Gobo 4 shake, from slow to fast
096 ó103
Gobo 3 shake, from slow to fast
104 ó111
Gobo 2 shake, from slow to fast
112 ó119
Gobo 1 shake, from slow to fast
120 ó127
Open
128 ó191
Cycle effect with increasing speed
192 ó255
Reverse cycle effect with increasing speed
5 Gobo Rotation
000 ó063
Indexing
064 ó147
Rotation effect with increasing speed
148
ó
231
Reverse rotation effect with increasing speed
232 ó255
Gobo bounce
6 Prism
000 ó007
Open
008 ó012
Prism on
013 ó130
Prism rotation with increasing speed
131 ó247
Reverse prism rotation with increasing speed
248 ó255
Prism effect
7
Focus
000
ó
255
Motor focus, zoom out to zoom in
8 Shutter
000 ó003
Closed
004 ó007
Open
008 ó076
Strobe effect with increasing speed
077 ó145
Pulse strobe
146 ó215
Random shutter
216 ó255
Open

Intimidator™ Spot LED 350 User Manual (Rev. 6) Page 15 of 20
Configuration
(Standalone)
Set the product in one of the standalone modes to control without a DMX controller.
1. Connect the product to power.
2. Turn the product on.
Never connect a product that is operating in any standalone mode (either
Automatic or Sound-Active)
to a DMX string connected to a DMX controller.
Product
s in standalone mode may transmit DMX signals that could interfere with
the DMX signals from the controller.
Sound-Active
Mode
To enable the Sound-Active mode, do the following.
1. Press <MODE/ESC> repeatedly until one of the following shows on the display:
NASl, NAFA, NStS, SLAv
2. Press <UP> or <DOWN> to select NStS.
3. Press <ENTER>.
The product will only respond to low frequencies of music (bass and drums).
Automatic Mode
To enable the Automatic mode:
1. Press <MODE/ESC> repeatedly until one of the following shows on the display:
NASl, NAFA, NStS, SLAv
2. Press <UP> or <DOWN> to select NASl (for a slow light show) or NAFA (for a fast
light show).
3. Press <ENTER>.
Manual Pan/Tilt
Operation
To select whether you want the Intimidator™ Spot LED 350 to operate with normal
panning or inverted panning, do the following.
1. Press <MODE/ESC> repeatedly until PAn shows on the display.
2. Press <UP> or <DOWN> to select normal pan operation (PAn) or inverse pan
operation (r PAn).
3. Press <ENTER>.
To select whether you want the Intimidator™
Spot LED 350 to operate with normal tilting
or inverted tilting, do the following:
1. Press <MODE/ESC> repeatedly until tiL shows on the display.
2. Press <UP> or <DOWN> to select normal pan operation (tiL) or inverse pan
operation (r tiL).
3. Press <ENTER>.
Pan/Tilt Angle
Range
You are able to select the range for the pan and tilt angles on the Intimidator™ Spot
LED 350 to achieve the effect you like.
To select which pan angle range to use, do the following.
1. Press <MODE/ESC> repeatedly until PA54 shows on the display.
2. Press <UP> or <DOWN> to select 540° (PA54), 360° (PA36), or 180° (PA18).
3. Press <ENTER>.
To select which tilt angle range to use, do the following.
1. Press <MODE/ESC> repeatedly until Ti27 shows on the display.
2. Press <UP> or <DOWN> to select 270° (Ti27), 180° (Ti18), or 90° (Ti 9).
3. Press <ENTER>.
Display
You are able to flip the LED display for easy readability in any mounting situation.
To select your display angle:
1. Press <MODE/ESC> repeatedly until diS shows on the display.
2. Press <UP> or <DOWN> to select normal display mode (diS) or inverse display
mode (r diS).
3. Press <ENTER>.

Page 16 of 20 Intimidator™ Spot LED 350 User Manual (Rev. 6)
Master/Slave
Mode
The Master/Slave mode allows a single Intimidator™ Spot LED 350 unit (the “master”) to
control the actions of one or more Intimidator™ Spot LED 350
units (the “slaves”)
without the need of a DMX controller. The master unit will be set to operate in either
Automatic or Sound-Active mode, while the slave units will be set to operate in Slave
m
ode. Once set and connected, the slave units will operate in unison with the master
unit.
Configure the units as indicated below.
Slave units:
1. Press <MODE/ESC> repeatedly until SLAvshows on the display.
2. Press <ENTER> to accept.
3. Set the DMX address to 001.
4. Connect the DMX input of the first slave unit to the DMX output of the master unit.
5. Connect the DMX input of the subsequent slave units to the DMX output of the
previous slave unit.
6. Finish setting and connecting all the slave units.
Master unit:
1. Set the master unit to operate in either Automatic or Sound-Active mode.
2. Make the master unit the first unit in the DMX daisy chain.
•Configure
all the slave units before connecting the master unit to the DMX
daisy chain.
•
Never connect a DMX controller to a DMX string configured for Master/Slave
operation because the controller
may interfere with the signals from the
master unit.
•Do not connect more than 31 slave units to the master unit.
Reset Software
To reset the software on the Intimidator™ Spot LED 350, do the following:
1. Press <MODE/ESC> repeatedly until rESt shows on the display.
2. Press <ENTER>.
The product will reset all settings in the software to the default
factory settings.
Password
Channel
The Intimidator™ Spot LED 350 contains a password-
protected mode which allows you
to calibrate and troubleshoot any small issues you may have during normal operation.
In order to access this mode, do the following:
1. Press and hold <MODE/ESC> for at least 10 seconds.
2. Use the <UP> and <DOWN> buttons to enter the password: 2323.
3. Press <ENTER>.
In this mode there are several options for adjustment:
Parameter Programming Steps Description
Pan Adjust P128 Manually adjust the pan angle
Tilt Adjust t128 Manually adjust the tilt angle
Gobo Wheel Adjust G128 Manually adjust the gobo wheel
Color Wheel Adjust C128 Manually adjust the color wheel
Focus Adjust F128 Manually adjust the focus
Prism Adjust L000 Manually adjust the prism
Lamp Brightness Adjust d000 Manually adjust the starting
brightness of the lamp

Intimidator™ Spot LED 350 User Manual (Rev. 6) Page 17 of 20
Changing
Gobos
To change the gobos in the Intimidator™ Spot LED 350
, do not remove the gobo wheel.
Simply:
1. Turn off and disconnect product from power outlet.
2. Place the product on a flat, level surface with the front facing up.
3. Access the gobo plate by
removing the cover on the moving head. By hand,
gently pry up the right side, then push right with the indented handles.
NOTE: If you expose the driver board, you are on the wrong side of the
head. Replace the cover immediately
and remove the cover on the
opposite side of the moving head.
4. Rotate the gobo wheel until the gobo that needs replacing is accessible.
5. Separate the g
obo holder assembly away from the gobo wheel by pushing it
forward and up. Be careful not to push the gobo out of the gobo plate.
6. Extract the gobo holder by pulling it backwards out of the product.
7. On a flat surface, remove the expansion ring that holds th
e gobo in place and
remove the gobo from the gobo plate.
8. Insert a new gobo and hold it in place with the expansion ring.
9. To re-
insert the new gobos, slide the tip of the gobo holder under the pressure
plate near the center of the gobo wheel.
10. Push the gobo
holder assembly inwards. DO NOT force the gobo holder into
the gobo wheel slot. Slightly move the holder from side-to-
side if needed to get
it to seat properly. If correctly installed, the bottom of the holder will be flush
with the gobo wheel.
11. Push cover back into position.
Gobo Replacement Diagram
Gobo Wheel Detail Views
Expansion Ring
Gobo Holder
Assembly
Gobo Holder Removal
Easy-access Panel
Gobo

Page 18 of 20 Intimidator™ Spot LED 350 User Manual (Rev. 6)
5.TECHNICAL INFORMATION
Product
Maintenance
Dust build up reduces light output performance and can cause overheating. This can
lead to reduction of the light source’s life.
To maintain optimum performance and
minimize wear, you should clean your lighting products at least twice a month. However,
be aware that usage and environmental conditions could be contributing factors to
increase the cleaning frequency.
To clean the product, follow the instructions below:
•Unplug the product from power.
•Wait until the product is at room temperature.
•Use a vacuum (or dry compressed air) and a soft brush to remove dust collected on
the external surface/vents.
•Clean all glass/transparent surfaces with a mild soap solution, ammonia-free glass
cleaner, or isopropyl alcohol.
•Apply the solution directly to a soft, lint free cotton cloth or a lens cleaning tissue.
•Softly drag any dirt or grime to the outside of the glass/transparent surface.
•Gently polish the glass/transparent surfaces until they are free of haze and lint.
Always dry the glass/transparent surfaces carefully after cleaning them.

Intimidator™ Spot LED 350 User Manual (Rev. 6) Page 19 of 20
To return a product or request support:
•In the U.S., contact CHAUVET® World Headquarters (see below).
•In the UK or Ireland, contact CHAUVET® Europe Ltd. (see below).
•In any other country, DO NOT contact CHAUVET®. Contact your distributor. See
www.chauvetlighting.com for distributors outside the U.S., United Kingdom, or
Ireland.
Outside the U.S., United Kingdom, or Ireland, contact your distributor and follow
their instructions on how to return CHAUVET® products to them. Visit our website
for contact details.
Returns
Call the corresponding CHAUVET®
Technical Support office and request a Return
Merchandise Authorization (RMA) number before shipping the product. Be prepared to
provide the model number, serial number, and a brief description of the cause for the
return.
You must send the merchandise pr
epaid, in its original box, and with its original packing
and accessories. CHAUVET® will not issue call tags.
Clearly label the package with the RMA number. CHAUVET®
will refuse any product
returned without an RMA number.
Write the RMA number on a properly affixed label. DO NOT write the RMA
number
directly on the box.
Before sending the product, clearly write
the following information on a piece of paper
and place it inside the box:
•Your name
•Your address
•Your phone number
•The RMA number
•A brief description of the problem
Be sure to pack the product
properly. Any shipping damage resulting from inadequate
packaging will be your responsibility. FedEx packing or double-boxing are
recommended.
CHAUVET®
reserves the right to use its own discretion to repair or replace
returned product(s).
Contact Us
World Headquarters
CHAUVET®
General Information
Address: 5200 NW 108th Avenue
Sunrise, FL 33351
Voice: [phone]
Fax: [phone]
Toll free: [phone]
United Kingdom & Ireland
CHAUVET® Europe Ltd.
General Information
Address: Unit 1C
Brookhill Road Industrial Estate
Pinxton, Nottingham, UK
NG16 6NT
Voice: [phone]
Fax: [phone]
Technical Support
Voice: [phone] (Press 4)
Fax: [phone]
Email: [e-mail]
Technical Support
Email: [e-mail]
World Wide Web
www.chauvetlighting.com
World Wide Web
www.chauvetlighting.co.uk

Page 20 of 20 Intimidator™ Spot LED 350 User Manual (Rev. 6)
6.TECHNICAL SPECIFICATIONS
Dimensions and
Weight
Length
Width
Height
Weight
10.6 in (268 mm)
13.4 in (340 mm)
15.4 in (392 mm)
22.7 lbs (10.3 kg)
Note: Dimensions in inches rounded to the nearest decimal digit.
Power
Power Supply Type
Range
Voltage Selection
Switching (internal)
100~240 V, 50/60 Hz
Auto-ranging
Parameter
120 V, 60 Hz
230 V, 50 Hz
Consumption
272 W
285 W
Operating
2.2 A
1.2 A
Power linking units
3 units
7 units
Fuse
F 3 A, 250 V
F 3 A, 250 V
Power I/O
US/Worldwide
UK/Europe
Power input connector
IEC
IEC
Power output connector
Edison
IEC
Power Cord plug
Edison (US)
Local plug
Light Source
Type
Power
Lifespan
LED
75 W
50,000 hours
Color
Quantity
Current
White
1
17 A
Photo Optic
Parameter
Illuminance (12°)
9490 lx
Zoom angle
12-17º
Strobe Rate
0–20 Hz
Pan & Tilt
540°
270°
Pan/Tilt Ranges
540°, 360°, 180°
Pan
270°, 180°, 90°
Tilt
Gobo Size
24 mm outside
20 mm image
1.1 mm thickness
Thermal
Maximum External Temp.
Cooling System
104° F (40° C)
Convection
DMX
I/O Connectors
Connector Type
Channel Range
3-pin XLR
Sockets
8, 14
Ordering
Product Name
Item Code
Item Number
Intimidator™ Spot LED 350
08010463
INTSPOTLED350
