Ledj RGBWAUV User manual

Intense 9HEX10 LED Slim Par
9 x 10W six-colour LEDs
(RGBWAUV)
User Manual
Order code:
LEDJ254A (Black Housing)
LEDJ254AZ (White Housing)
Convection
cooled,
no fan!

www.prolight.co.uk Intense 9HEX10 LED Slim Par User Manual 2
Safety advice
WARNING
FOR YOUR OWN SAFETY, PLEASE READ THIS USER MANUAL
CAREFULLY BEFORE YOUR INITIAL START-UP!
• Beforeyourinitialstart-up,pleasemakesurethatthereisnodamagecausedduringtransportation.
• Shouldtherebeanydamage,consultyourdealeranddonotusetheequipment.
• Tomaintaintheequipmentingoodworkingconditionandtoensuresafeoperation,itisnecessary
fortheusertofollowthesafetyinstructionsandwarningnoteswritteninthismanual.
• Pleasenotethatdamagescausedbyusermodicationstothisequipmentarenotsubjecttowarranty.
IMPORTANT:
The manufacturer will not accept liability for any resulting damages caused by the non-observance
of this manual or any unauthorised modication to the equipment.
OPERATING DETERMINATIONS
Ifthisequipmentisoperatedinanyotherway,thanthosedescribedinthismanual,theproductmaysufferdamageand
thewarrantybecomesvoid.Incorrectoperationmayleadtodangere.g:short-circuit,burnsandelectricshocksetc.
Donotendangeryourownsafetyandthesafetyofothers!
Incorrectinstallationorusecancauseseriousdamagetopeopleand/orproperty.
CAUTION!
KEEP THIS EQUIPMENT
AWAY FROM RAIN,
MOISTURE AND LIQUIDS
CAUTION!
TAKE CARE USING
THIS EQUIPMENT!
HIGH VOLTAGE-RISK
OF ELECTRIC SHOCK!!
• Neverletthepowercablecomeintocontactwithother
cables.Handlethepowercableandallmainsvoltage
connectionswithparticularcaution!
• Neverremovewarningorinformativelabelsfromtheunit.
• Donotopentheequipmentanddonotmodifytheunit.
• Donotconnectthisequipmenttoadimmerpack.
• Donotswitchtheequipmentonandoffinshortintervals,
asthiswillreducethesystem’slife.
• Onlyusetheequipmentindoors.
• Donotexposetoammablesources,liquidsorgases.
• Alwaysdisconnectthepowerfromthemainswhen
equipmentisnotinuseorbeforecleaning!Onlyhandle
thepower-cablebytheplug.Neverpullouttheplugby
pullingthepower-cable.
• Makesurethattheavailablemainssupplyvoltageis
between100~240VAC,50/60Hz.
• Makesurethatthepowercableisnevercrimpedor
damaged.Checktheequipmentandthepowercable
periodically.
• Iftheequipmentisdroppedordamaged,disconnectthe
mainspowersupplyimmediatelyandhaveaqualied
engineerinspecttheequipmentbeforeoperatingagain.

• Iftheequipmenthasbeenexposedtodrastic
temperatureuctuation(e.g.aftertransportation),
donotconnectpowerorswitchitonimmediately.
Thearisingcondensationmightdamagetheequipment.
Leavetheequipmentswitchedoffuntilithasreached
roomtemperature.
• Ifyourproductfailstofunctioncorrectly,stopuse
immediately.Packtheunitsecurely(preferablyinthe
originalpackingmaterial),andreturnittoyourProLight
dealerforservice.
• Onlyusefusesofsametypeandrating.
• Repairs,servicingandpowerconnectionmustonlybe
carriedoutbyaqualiedtechnician.THISUNITCONTAINS
NOUSERSERVICEABLEPARTS.
• Thislightingxtureisforprofessionaluseonly-itis
notdesignedfororsuitableforhouseholduse.The
productmustbeinstalledbyaqualiedtechnicianin
accordancewithlocalterritoryregulations.Thesafetyof
theinstallationistheresponsibilityoftheinstaller.The
xturepresentsrisksofsevereinjuryordeathduetore
hazards,electricshockandfalls.
• Warning!RiskGroup2LEDproductaccordingto
EN62471.Donotviewthelightoutputwithoptical
instrumentsoranydevicethatmayconcentratethebeam.
• WARRANTY:Oneyearfromdateofpurchase.

www.prolight.co.uk Intense 9HEX10 LED Slim Par User Manual 3
Product overview & technical specications
Poweredby9x10WRGBWAUVLEDswithinacompact,die-castchassisthe
Intense9HEX10providesasmoothwashofvibrantcolour.Featuring6-in-
1colourLEDsthisxtureadvancesfromstandardRGBcolourmixingwith
theadditionofwhiteforpastelshades,amberforrich,warmtonesandUV
forintensehues.Theconvectioncooledchassisensuressilentrunningand
featuresmountingpointsfortheoptionalbarndoor/gelframekit
(LEDJ253A-Black/LEDJ253AZ-White).
•9x10W6-in-1colourLEDs(RGBWAUV)
•Beamangle:25°(eldangle:35°)
•2244Lux@2m(fullon)
•4.2kHzrefreshrate
•DMXchannels:2/3/3/4/4/5/6/8
or10selectable
•Staticcolour,colourchange,colour
fade,autorun,soundactiveand
master/slavemodes
•0-100%dimmingwithvariablestrobe
•Bracketallowsformultipleriggingand
oorstandingapplications
•4pushbuttonmenuwithLEDdisplay
•IECpowerinput/outputsockets
•3-pinXLRinput/outputsockets
•Convectioncooled
•OptionalBarnDoor/GelFrame
(LEDJ253A-Black/LEDJ253AZ-White)
Intense 9HEX10 LED Slim Par
Specications Intense 9HEX10
Powerconsumption 98W
Powersupply 100~240V,50/60Hz
Fuse T1.5A250V
Dimensions 295x260x93mm
Weight 2.6kg
Ordercode LEDJ254A(BlackHousing)
LEDJ254AZ(WhiteHousing)
93mm
260mm
295mm
01-Bracket
02-Brackettighteningknobs
03-Earthpoint
04-LEDdisplay
05-Functionbuttons
06-Safetybondpoint
07-DMXinputsocket
08-DMXoutputsocket
09-IECpowerinputsocket
10-IECpoweroutputsocket
11-FuseT1.5A250V
Inthebox:1 x xture,
1 x power cable &
1 x user manual
INTENSE 9HEX10 LED SLIM PAR
www.prolight.co.uk
MODE ENTER UP DOWN
DMX INPUT DMX OUTPUTPOWER INPUT
100~240V, 50/60Hz
FUSE: T1.5A 250V
POWER OUTPUT
09 10
03
02 02
11
01
07
01
08
05
06
04
0m 1m 2m 3m 4m 5m
25° - Lux 8650 2244 978
25°
559 375

www.prolight.co.uk Intense 9HEX10 LED Slim Par User Manual 4
Operating instructions
DMX channel mode:
OperatinginaDMXcontrolmodeenvironmentgivestheuserthegreatestexibilitywhenitcomesto
customisingorcreatingashow.Inthismodeyouwillbeabletocontroleachindividualtraitofthexture
andeachxtureindependently.
ToaccesstheDMXchannelmode,pressthe“MODE”buttonontherearoftheunittoshowd001
ontheLEDdisplay.Nowusethe“UP”and“DOWN”buttonstosetthedesiredDMXaddress.Nowpress
the“ENTER”buttontochooseoneofthe6,8or10DMXchannelmodes,pressthe“ENTER”buttonto
conrmthesetting.
Toexitoutofanyoftheaboveoptions,pressthe“MODE”button.
Channel Value Function
1 000-255 Masterdimmer(0-100%)
2
000-255colourmacro
000-016 Red
017-033 Green
034-050 Blue
051-067 White
068-084 Amber
085-101 UV
102-118 Yellow(R-255,G-200,A-255)
119-135 Cyan(G-255,B-255)
136-152 Lavender(R-170,B-210)
153-169 Brightgreen(G-255,A-180)
170-186 Magenta(R-255,B-90,UV-255)
187-203 Turquoise(G-255,B-180,UV-255)
204-220 Orange(R-200,A-200)
221-237 Coolwhite(R-70,G-190,B-255,A-200)
238-255 Warmwhite(R-230,G-255,B-255,A-255,W-255)
2 channel mode:

www.prolight.co.uk Intense 9HEX10 LED Slim Par User Manual 5
Operating instructions
Channel Value Function
1 000-255 Red(0-100%)
2000-255 Green(0-100%)
3000-255 Blue(0-100%)
Channel Value Function
1 000-255 Masterdimmer(0-100%)
2000-255 Flash(speed0-100%,1Hz-20Hz)
3000-004 Blackout
005-010 Red
011-015 Green
016-020 Blue
021-025 White
026-030 Amber
031-035 UV
036-040 Yellow(R-255,G-200,A-255)
041-045 Cyan(G-255,B-255)
046-050 Lavender(R-170,B-210)
051-055 Brightgreen(G-255,A-180)
056-060 Magenta(R-255,B-90,UV-255)
061-065 Turquoise(G-255,B-180,UV-255)
066-070 Orange(R-200,A-200)
071-075 Coolwhite(R-70,G-190,B-255,A-200)
076-080 Warmwhite(R-230,G-255,B-255,A-255,W-255)
081-150 Colourjumpingspeed
Slowest(081)changesevery8secs
Fastest(150)changesevery0.3secs
151-220 Colourfadingspeed
Slowest(151)changesevery8secs
Fastest(220)changesevery0.3secs
221-255 Soundcontrol(micsensitivity)
3 channel mode:
3 channel mode:
Channel Value Function
1 000-255 Red(0-100%)
2000-255 Green(0-100%)
3000-255 Blue(0-100%)
4 000-255 White(0-100%)
Channel Value Function
1 000-255 Red(0-100%)
2000-255 Green(0-100%)
3000-255 Blue(0-100%)
4 000-255 Amber(0-100%)
Channel Value Function
1 000-255 Red(0-100%)
2000-255 Green(0-100%)
3000-255 Blue(0-100%)
4 000-255 White(0-100%)
5 000-255 Amber(0-100%)
Channel Value Function
1 000-255 Red(0-100%)
2000-255 Green(0-100%)
3000-255 Blue(0-100%)
4 000-255 White(0-100%)
5 000-255 Amber(0-100%)
6 000-255 UV(0-100%)
4 channel mode: 4 channel mode:
5 channel mode: 6 channel mode:

www.prolight.co.uk Intense 9HEX10 LED Slim Par User Manual 6
Channel Value Function
1 000-255 Masterdimmer(0-100%)
2000-255 Red(0-100%)
3000-255 Green(0-100%)
4 000-255 Blue(0-100%)
5 000-255 White(0-100%)
6 000-255 Amber(0-100%)
7 000-255 UV(0-100%)
8 000 Nofunction
001-041 Program1-Staticcolour
042-083 Program2-6colourfade
084-125 Program3-Multicolourfade
126-167 Program4-Multicolourillusion
168-209 Program5-6colourchange
210-241 Program6-Multicolourchange
242-255 Soundactive
9(Staticcolour
selectionwhen
channel8is
001-041)
000 Blackout
001-016 Red
017-033 Green
034-050 Blue
051-067 White
068-084 Amber
085-101 UV
102-118 Yellow(R-255,G-200,A-255)
119-135 Cyan(G-255,B-255)
136-152 Lavender(R-170,B-210)
153-169 Brightgreen(G-255,A-180)
170-186 Magenta(R-255,B-90,UV-255)
187-203 Turquoise(G-255,B-180,UV-255)
204-220 Orange(R-200,A-200)
221-237 Coolwhite
(R-70,G-190,B-255,A-200)
238-255 Warmwhite(R-230,G-255,B-255,
A-255,W-255)
000-255 Programspeed
whenchannel8is001-241
000-255 Soundsensitivity(0-31)
whenchannel8is242-255
10 000-255 Strobe(slow-fast)
10 channel mode:
Channel Value Function
1 000-255 Red(0-100%)
2000-255 Green(0-100%)
3000-255 Blue(0-100%)
4 000-255 White(0-100%)
5 000-255 Amber(0-100%)
6 000-255 UV(0-100%)
7 000-255 Masterdimmer(0-100%)
8 000-255 Strobe(slow-fast)
8 channel mode:

www.prolight.co.uk Intense 9HEX10 LED Slim Par User Manual 7
Built-in program mode:
Toaccessthebuilt-inprogrammodepress“MODE”untilthedisplayshowsPr.01ontheLEDdisplay.
Usethe“UP”and“DOWN”buttonstoselectaprogramfromPr.01~Pr.06.
Pressthe“ENTER” buttontoconrmthesetting.
Tochangethespeedoftheselectedprogrampressthe“ENTER” buttonandthenusethe“UP”and
“DOWN”buttonstoselectanyvaluefromSP00~SP99.Pressthe“ENTER” buttontoconrmthe
setting,thenusethe“UP”and“DOWN”buttonstoselectandvaluefromF500~F599forthe
strobefeature.Pressthe“ENTER” buttontoconrmthesetting.
InPr.01youareabletosetaspecicstaticcolour.WheninPr.01pressthe“ENTER” buttonand
thenusethe“UP”and“DOWN”buttonstogothroughthestaticcolours.Pressthe“ENTER” buttonto
conrmthesetting,thenusethe“UP”and“DOWN”buttonstoselectandvaluefromF500~F599
forthestrobefeature.Pressthe“ENTER” buttontoconrmthesetting.
Toexitoutofanyoftheaboveoptions,pressthe“MODE”button.
Static colour mode:
Toaccessthestaticcolourmodepress“ENTER”untilColrshowsontheLEDdisplay.
Pressthe“ENTER” buttonandtheLEDdisplaywillshowr.225.Nowusethe“UP”and“DOWN”
buttonstoselectthebrightnessbetweenr.000~r.255.Pressthe“ENTER” buttonandrepeatfor
green,blue,white,amberandUV.
Value: 000 - 255 (000 = low, 255 = high)
Toexitoutofanyoftheaboveoptions,pressthe“MODE”button.
Master/slave mode:
Tosetthemasterunit,pressthe“MODE”buttonontherearofthemasterunitthenselectyour
desiredprogram(soundactive,auto,staticcolouroroneofthebuilt-inprograms).
Tosettheotherunitsinslavemode,pressthe“MODE”buttonontherearoftheunittoshowSLAU
ontheLEDdisplayandpressthe“ENTER”buttontoconrmthesetting.Theunitswillnowrunin
sequencewiththemasterunit.
Toexitoutofanyoftheaboveoptions,pressthe“MODE”button.
PleaseensurethatallslaveunitsaresettothesameDMXchannelmodeasthemasterunit.
Operating instructions
Pr.01 Staticcolour
Pr.02 6colourfade
Pr.03 Multicolourfade
Pr.04 Multicolourillusion
Pr.05 6colourchange
Pr.06 Multicolourchange
1.--r-Red
2.--g-Green
3.--b-Blue
4.--u-White
5.--A-Amber
6.--I-UV
7.-rg-Orange
8.-rg-Green/Yellow
9..-rb-BrightPink
10.rb-RosePink
11.gb-LightBlue
12.ru-SalmonPink
13.gu-PastelGreen
14.bu-PastelBlue
15.uu-WarmWhite
16.cu-Fullon(White)
Programs: Static colours:

www.prolight.co.uk Intense 9HEX10 LED Slim Par User Manual 8
Sound active mode:
Toaccessthesoundactivemode,pressthe“MODE”buttonontherearoftheunittoshowSU00
ontheLEDdisplay.Nowpressthe“ENTER”buttonandusethe“UP”and“DOWN”buttonstosetthe
soundsensitivitylevelfromSU.00~SU.31andpressthe“ENTER”buttontoconrmthesetting.
Value: 00 - 31 (00 = low, 99 = high)
Toexitoutofanyoftheaboveoptions,pressthe“MODE”button.
Auto mode:
Toaccesstheautomodepress“ENTER”untilthedisplayshowsAutoontheLEDdisplay.
Thexturewillnowrunthroughitsbuiltinprograms.NOTE:Theusercansetupthespeedandash
speedforPr.02~Pr.06underthebuiltinprogramsmode.Changingthisherewillthentakeeffect
whenrunningautomode.
Toexitoutofanyoftheaboveoptions,pressthe“MODE”button.
NOTE:
Thisxturehasathermalprotectionfunction.Thexturewillautomaticallyenterintoaself-protection
stateandtheLEDdisplaywillash“-rt-”ifthethermalprotectionisactivated.Switchoffthe
xtureandleavetocooldown.Shouldtheproblemreoccurpleasecontactyourlocaldealerfor
serviceandsupport.
Operating instructions
Built-inprogram Pr.01Staticcolour
Pr.026colourfade
Pr.03Multicolourfade
Pr.04Multicolourillusion
Pr.056colourchange
Pr.06Multicolourchange
SP00~SP99(speed)
F500~F599(ash)
Staticcolourmode r.000~r.255R
g.000~g.255G
b.000~b.255B
u.000~u.255W
A.000~A.255A
I.000~I.255UV
Automode AUTO
Slavemode SLAV
Soundactivemode SU00~SU31
DMXmode 2CH,3CH,3CH,4CH,4CH,
5CH,6CH,8CH,10CH
Addresssetting A001~A512
Menusystem

www.prolight.co.uk Intense 9HEX10 LED Slim Par User Manual 9
Setting the DMX address:
TheDMXmodeenablestheuseofauniversalDMXcontroller.Eachxturerequiresa“startaddress”
from1-512.Axturerequiringoneormorechannelsforcontrolbeginstoreadthedataonthechannel
indicatedbythestartaddress.Forexample,axturethatoccupiesoruses7channelsofDMXandwas
addressedtostartonDMXchannel100,wouldreaddatafromchannels:100,101,102,103,104,105
and106.Chooseastartaddresssothatthechannelsuseddonotoverlap.E.g.thenextunitinthe
chainstartsat107.
DMX 512:
DMX(DigitalMultiplex)isauniversalprotocolusedasaformofcommunicationbetweenintelligent
xturesandcontrollers.ADMXcontrollersendsDMXdatainstructionsformthecontrollertothexture.
DMXdataissentasserialdatathattravelsfromxturetoxtureviatheDATA“IN”andDATA“OUT”
XLRterminalslocatedonallDMXxtures(mostcontrollersonlyhaveadata“out”terminal).
DMX linking:
DMXisalanguageallowingallmakesandmodelsofdifferentmanufacturestobelinkedtogether
andoperatefromasinglecontroller,aslongasallxturesandthecontrollerareDMXcompliant.
ToensureproperDMXdatatransmission,whenusingseveralDMXxturestrytousetheshortest
cablepathpossible.TheorderinwhichxturesareconnectedinaDMXlinedoesnotinuencethe
DMXaddressing.Forexample;axtureassignedtoaDMXaddressof1maybeplacedanywherein
aDMXline,atthebeginning,attheend,oranywhereinthemiddle.Whenaxtureisassigneda
DMXaddressof1,theDMXcontrollerknowstosendDATAassignedtoaddress1tothatunit,
nomatterwhereitislocatedintheDMXchain.
DATA cable (DMX cable) requirements (for DMX operation):
ThisxturecanbecontrolledviaDMX-512protocol.TheDMXaddressissetonthebackoftheunit.
YourunitandyourDMXcontrollerrequireastandard3-pinXLRconnectorfordatainput/output,
seeimagebelow.
Also remember that DMX cable must be daisy chained and cannot be split.
DMX setup
FurtherDMXcablescanbe
purchasedfromallgoodsound
andlightingsuppliersor
ProLightConceptsdealers.
Pleasequote:
CABL10 – 2m
CABL11 – 5m
CABL12 – 10m

www.prolight.co.uk Intense 9HEX10 LED Slim Par User Manual 10
Notice:
Besuretofollowthediagramsbelowwhenmakingyourowncables.Donotconnectthecables
shieldconductortothegroundlugorallowtheshieldconductortocomeincontactwiththeXLRs
outercasing.Groundingtheshieldcouldcauseashortcircuitanderraticbehaviour.
Special note:
Line termination:
Whenlongerrunsofcableareused,
youmayneedtouseaterminatoron
thelastunittoavoiderraticbehaviour.
Using a cable terminator will decrease
the possibilities of erratic behaviour.
(3-pin - Order ref: CABL9O, 5-pin - Order ref: CABL89)
5-pin XLR DMX connectors:
Somemanufacturesuse5-pinXLRconnectorsfordatatransmissioninplaceof3-pin.5-pinXLRxtures
maybeimplementedina3-pinXLRDMXline.Wheninsertingstandard5-pinXLRconnectorsintoa
3-pinlineacableadaptormustbeused.Thediagrambelowdetailsthecorrectcableconversion.
Terminationreducessignaltransmission
problemsandinterference.Itisalways
advisabletoconnectaDMXterminal,
(resistance120Ohm1/4W)betweenpin2
(DMX-)andpin3(DMX+)ofthelastxture.
5-pin XLR (socket)
Pin 1: GND (screen)
Pin 2: Signal (-)
Pin 3: Signal (+)
Pin 4: N/C
Pin 5: N/C
3-pin XLR (socket)
Pin 1: GND (screen)
Pin 2: Signal (-)
Pin 3: Signal (+)
3-pin XLR (socket)
Pin 1: GND (screen)
Pin 2: Signal (-)
Pin 3: Signal (+)
5-pin XLR (socket)
Pin 1: GND (screen)
Pin 2: Signal (-)
Pin 3: Signal (+)
Pin 4: N/C
Pin 5: N/C
DMX setup

www.prolight.co.uk Intense 9HEX10 LED Slim Par User Manual 11
WEEE notice
Correct Disposal of this Product
(Waste Electrical & Electronic Equipment)
(Applicable in the European Union and other European countries
with separate collection systems)
Thismarkingshownontheproductoritsliterature,indicatesthatitshouldnotbedisposedof
withotherhouseholdwastesattheendofitsworkinglife.Topreventpossibleharmtothe
environmentorhumanhealthfromuncontrolledwastedisposal,pleaseseparatethisfromother
typesofwastesandrecycleitresponsiblytopromotethesustainablereuseofmaterialresources.
Householdusersshouldcontacteithertheretailerwheretheypurchasedthisproduct,ortheir
localgovernmentofce,fordetailsofwhereandhowtheycantakethisitemforenvironmentally
saferecycling.
Businessusersshouldcontacttheirsupplierandcheckthetermsandconditionsofthe
purchasecontract.Thisproductshouldnotbemixedwithothercommercialwastesfordisposal.

www.prolight.co.uk Intense 9HEX10 LED Slim Par User Manual 12
Optional accessories
Pleasecontactyourlocalretailertopurchasetheseaccessories.
Tokeepup-to-dateonthelatestaccessoriesandproductrangeadditions
pleasevisitwww.prolight.co.uk
Optional barn door/gel frame
Order code: LEDJ253A
