ledlenser XP30R User manual

XP30R
MANUAL

2
XP30R manual V.01_01.2023
Thank you
We are delighted that you have chosen one of
our products.
You will find safety and operating instructions
in this instruction manual to make you familiar
with your new product.
It must be read carefully before using the
product. Please keep the User Manual in
a safe place and always hand it over if the
product is given to a third party.
The User Manual also helps you get the maxi-
mum use out of the product, provides answers
to your questions and helps to avoid incorrect
operation. Therefore, please particularly
follow the warnings and safety instructions
and dispose of the lamps, batteries as well as
packaging material properly.

3
Table of contents
1. General information
2. Delivery scope
3. Safety instructions
4. Changing batteries and charging
5. Basic functions
6. Boost function
7. Strobe function
8. Remote mode
9. Temperature monitoring
10. Battery management and backup mode
11. Stand-mounting
12. Fault diagnosis
13. Technical data of the lamp
14. Instructions regarding disposal
15. Other information
XP30R manual V.01_01.2023
1. General information
Product information
The Ledlenser XP30R is a searchlight and may
be used only for the purposes of illumination. The
lamp is also equipped with a light source that
cannot be replaced by the user.
Please register your lamp using the enclosed
registration card to get an extended guarantee, to
check the authenticity of the lamp, and to be able to
get innovations for product improvements.
Charger and battery are excluded from the guaran-
tees beyond the statutory warranty.
Information about this manual
Carefully read the manual before using the
lamp and follow all the safety instructions and
warnings.
The manual includes the following signs and
signal words:
• General list
‣Instructions for safety instructions and
warnings
1. Action / Step
⇢Result of an action
WARNING indicates a potentially hazardous
situation, which can lead to death or a severe
injury if not avoided.
CAUTION indicates a potentially hazardous
situation, which can lead to moderate or minor
injury if not avoided.
ATTENTION indicates a situation, which can lead
to material damage if not avoided.

4
2
3
XP30R manual V.01_01.2023
2. The delivery scope of this product includes:
• XP30R Searchlight
• Hard shell case
• Li-ion battery
• Charging station
• Carry strap
• Remote
• Universal mount
• Manual
• Registration card
The lamp may be used only with the following
rechargeable batteries (battery pack).
• Compatible rechargeable batteries supplied by
or ocially acquired from Ledlenser
Delivery scope
General safety instructions 3. Carefully read the following safety instructions
before using the product.
WARNING – Risk of injury
Keep the lamp out of the hands of children or
persons aected by medication, drugs, physical/
mental disabilities or illnesses because there is a
risk of an injury to the eyes as well as an accident.
‣Do not let children play with the lamp.
‣Persons with disabilities should use the lamp
only under the supervision or instructions of a
responsible persons.
CAUTION – Risk of injury
Do not use the lamp if it is damaged, do not repair,
open, or modify it since it can damage the lamp or
endanger persons.
‣Take damaged lamps out of operation or have
them repaired professionally.

5
XP30R manual V.01_01.2023
CAUTION – Risk of blinding by glare
The starting blinding eect of the lamp can
temporarily restrict the vision and cause afterim-
ages, which can lead to irritations, disabilities or
accidents.
‣Do not look directly into the light beam or shine
the beam in the eyes of others.
‣Do not direct the light beam on people/animals
‣Do not use the lamp under the influence
of drugs, medication, or alcohol since the
reactivity of the eyes and the capacity to act is
reduced.
‣If a light beam hits the eyes, close them and
turn the head away from the light beam.
CAUTION – Fire and risk of burns
The lamp is classified in risk group 2 (medium risk)
under the IEC 62471 standard and is thus beyond
the ‘Free Group’. There is a risk of retina damage due
to optical radiation (blue light 400nm to 780nm).
CAUTION – Fire and risk of burns
The lamp generates heat during use.
‣Do not operate the lamp unattended.
‣Do not cover the lamp during operation since
this can lead to a heat build-up.
‣Maintain a distances of at least 2 m between
the lamp and the flammable surfaces.
‣Do not touch hot lamp, if required, let it cool
down.
‣Close the protective cover of the lamp during
transport and disable the remote operation so
that the lamp is not accidentally switched on.
ATTENTION – Damage to the lamp
Use the lamp
‣only at ambient temperatures of -20 °C to
+40 °C,
‣do not bring it in contact with salt water,
‣protect against intense heat and wet,
‣do not use or store with the battery cover open.
VWARNING – Risk of explosion / injurying
The batteries and button cells can explode due
to improper use, leaking battery acid can cause
chemical burns.
Do not store the batteries and button cells
‣within the reach of children,
‣protect against heat (e.g., sunlight), heat build-
up, wet, or dirt,
‣do not throw in a fire,
‣do not use in explosive areas,
‣do not open, damage, or short circuit.
‣If not in use for a long time, remove the batter-
ies from the lamp and charge regularly only in
the charging station supplied (every 3 months).

6
4
a)
b)
c)
Click
d)
e) Hold
XP30R manual V.01_01.2023
ATTENTION – Damage to the batteries
Batteries may be charged only at temperatures of
10 °C to 40 °C, otherwise they can be damaged and
no longer work.
‣Charge the batteries only within the given tem-
perature limits.
4. IInserting the battery
1. Fold up the safety lever of the battery cover (Fig.
4a).
2. Fold down the battery cover (Fig. 4b).
3. Slide in the battery from above (Fig. 4c).
⇢The battery locks into the proper position
with an audible snap.
4. Close the battery cover.
Removing the battery
1. Fold up the safety cable of the battery cover
(Fig. 4a).
2. Fold down the battery cover (Fig. 4b).
3. Press the red locking button (Fig. 4d) on the bat-
tery and simultaneously pull up the battery and
out from the battery compartment (Fig. 4e).
4. Charge the battery or insert new battery (Fig. 4c).
5. Lift up the battery cover and close the safety
lever.
ATTENTION - Environmental protection
Defective batteries must be disposed of in accord-
ance with the country’s legislation, as they can be
dangerous for the environment.
In order to get more information regarding the
operation and safety of the battery and the charging
station, please scan the following QR code or visit
www.ledlenser.com:
Changing batteries and charging

7
5
f)e)
Hold
b)a)
d)
On
Hold> 2s
c)
XP30R manual V.01_01.2023
Basic functions 5. Switching on the lamp
1. Lift up the safety cover (Fig. 5a).
2. Briefly press the main switch (Fig. 5b).
⇢The lamp starts in the operating mode,
which is preselected over the mode switch
button (refer chapter Mode Switch).
⇢The battery capacity display shows the
current charging state (Fig. 5c).
3. Close the safety cover.
Switching o the lamp
1. Lift up the safety cover (Fig. 5a).
2. Keep the main switch pressed (Fig. 5d) until the
bar display (Fig. 5c) goes out.
3. Close the safety cover.
Fixing the carry strap
Attach the two hooks of the carry strap (Fig. 5f) on
the two mounting brackets located on the upper
side of the product (Fig. 5e).

8
On
100%
90%
80%
70%
60%
50%
40%
30%
20%
10%
g)
XP30R manual V.01_01.2023
Battery capacity display
If the lamp is switched on, the remaining battery
capacity is displayed via a 10-step LED bar display
(1 bar = 10%) on the upper side of the device (Fig.
5g).

9
Mode 1
Mode 0
Remote-Mode
O
i)
j)
Mode 2
Mode 3
Mode 4
Mode 5
h)
Brightness setting
XP30R manual V.01_01.2023
Mode Switch
The mode switch button (Fig. 5 h) oers six switch
positions with which remote control (mode 0 –
remote mode, Fig. 5i) can be activated and five
dierent brightness levels (Fig. 5j) from mode 1
(weak) to mode 5 (strong) can be selected.
If the lamp is switched on and the mode switch is
in position 1 (mode 0, Fig. 5h/i), the lamp does not
light up since it is in remote mode.
Details for coupling with remote control and the
operating functions provided can be found in
Chapter 8.

10
6
7
8
c) Boost = 10s
2x Click
b)a)
On
1x Click
1x Click
b)a)
c)
Pos. 1
Blue Blink
XP30R manual V.01_01.2023
Strobe function
Boost function
Remote mode
6. In boost mode, the lamp lights up with the maxi-
mum brightness for 10 sec. The boost mode can
be activated only in the switched on state (but not
in strobe mode).
Boost function
1. Switch on the lamp as per Chapter 5.
2. Lift up the safety cover as required (Fig. 6a).
3. Briefly press the main switch 2 times (Fig. 6b).
⇢The boost mode starts (Fig. 6c).
⇢After ten seconds, the lamp switches back
to the previous light function.
4. The boost mode can be stopped at any time by
briefly pressing the main switch.
7. In strobe mode, the lamp emits quick flashes with
changing frequency and thus generates a discon-
certing blinding eect for an emergency.
WARNING – Risk of injury
The strobe function of the lamp can have negative
eects on people with photosensitive epilepsy.
This can result in accidents and injuries.
‣Use the strobe mode only in an emergency and
in consultation.
Strobe function
1. Activate the strobe function in the switched on
state by pressing the switch behind the end of
the handle (Fig. 7).
⇢The switch locks.
2. End the strobe function again by pressing the
rear switch.
8. For the first use of the remote control for light
control, the remote control must be linked with
the lamp.
Linking the lamp for the first time
1. Lift up the safety cover (Fig. 8a).
2. Switch on the lamp by briefly pressing the
main switch (Fig. 8b).
3. Switch the lamp to remote mode (position 1)
with the mode switch button (Fig. 8c).
⇢The blue status LED on the lamp blinks
(Fig. 8c), to signal that the lamp is ready for
linking with the remote control.
4. Within the next 10 sec, keep the + and –
buttons of the remote control simultaneously
pressed for 2 sec (Fig. 8d).
⇢Upon successful connection, the blue status
LED remains lit up.

11
d)
Mode 1
Mode 1 Mode 5
g) 2xClick
+1xClick
h)
+1xClick
On
i)
Mode 5
Hold >2s
f)e)
Hold >1sec
1xClick OFF2xClick <1sec
Boost = 10 s
j)
Hold = 2sec
On
<1 sec 2x Click
On
k)
l)
XP30R manual V.01_01.2023
⇢The main functions of the lamp can be con-
trolled only via the remote control now.
Ending remote mode
1. Lift up the safety cover (Fig. 8e).
2. Keep the main switch pressed for at least 2
sec (Fig. 8f).
⇢The blue status LED is no longer lit.
Switching on lamp in remote mode
1. Switch on the lamp as required by briefly
pressing the main switch (Fig. 8b).
2. Press the on/o buttons (Fig. 8g) of the remote
control 2 times quickly one after the other.
⇢When switching on the lamp for the first
time, the lowest brightness level (mode 1)
is activated and when restarting in standby
mode, the last selected mode is activated.
Switching between the lighting levels.
1. Press the +button (Fig. 8 h) multiple times to
switch from a lower mode (weak light) to a
higher mode (strong light).
2. Press the – button (Fig. 8 h) multiple times to
switch from a higher mode (strong light) to a
lower mode (weak light).
Boost function
1. Press the +button (Fig. 8j) 2 times within 1
second quickly and consecutively to activate
the boost function.
2. Press the on/o button once to end the boost
function.
Activating standby mode
Keep the on/o button (Fig. 8k) pressed for at
least 2 sec.
Ending standby mode
Press the on/o button (Fig. 8l) 2 times within 1
second quickly and consecutively.
If the lamp is not operated for 8 hours in the
standby mode, the lamp switches o completely
and can also no longer be switched on by remote
control.
In order to use the lamp again in remote mode,
briefly press the main switch of the lamp once
(Fig. 8b).
The remote control has a display of the battery
status (Fig. 8 m). Replace the battery (1x lithium
CR2032, 3 V) if needed.
Continuous Blue Light
Standby mode ON
Standby mode OFF

12
9
m)
n) o) p) q)
Green Red
>10% <10%
XP30R manual V.01_01.2023
WARNING – Risk of swallowing the button
cells
Keep small batteries and button cells that can be
swallowed out of reach of children. Swallowing
can lead to severe injuries (burns, perforation of
soft parts) or death within 2 hours.
‣If batteries have been swallowed or inserted,
please consult a doctor immediately.
Battery change by remote control
1. Unscrew the 2 screws, if present (Fig. 8n).
2. Pull out the slide compartment (Fig. 8o).
3. Remove the battery from the compartment
(Fig. 8p) and dispose of the battery properly.
4. Insert new battery with the – pole upwards and
completely reinsert the slide compartment in
the remote control (Fig. 8q).
5. Screw in the 2 screws again.
9. The XP30R is equipped with a temperature mon-
itoring system and active cooling system, which
permanently monitors the temperature of the
lamp as well as the battery.
If needed, the lamp adds a fan or lowers the max-
imum light intensity. Thus, it is always ensured
that the product is operated within the permitted
temperature limits of the components.
10. At 30% remaining battery capacity, the bar display
blinks continuously.
⇢The lamp automatically switches to mode
2 and can also no longer be switched to a
stronger light level.
⇢The strobe mode and the boost mode can
no longer be used.
From a 10% remaining battery capacity, the
lamp automatically switches to backup mode. It
prevents a sudden switching o of the lamp and
makes sure that the user continues to have the
light available with a weak battery.
⇢In this mode, the lamp can only be used in
the lowest brightness level (mode 1).
Temperature monitoring
10 Battery management and backup mode
< 30%
< 10%
Mode 1
Blink

13
11
12 Fault diagnosis
Mode 2
Mode 1
<30% <10%
XP30R manual V.01_01.2023
11. On the lower side of the lamp is a thread for
mounting on all stands with 3/8”-16 UNC thread
(Fig. 11).
CAUTION – Risk of fire
If the distance kept from flammable objects is too
short, they can catch fire.
‣Maintain 2 m distance from objects.
ATTENTION - Damage to the lamp
If the stand falls down, the lamp can be damaged.
‣Make sure that the stand is set up stably.
Stand-mounting
12. Possible faults, causes and measures
Fault Status display Cause and measure
Lamp cannot
be switched
on / Lamp
goes o dur-
ing operation
No response
on the bar
display
Battery discharging:
‣Check charging station
on the battery and charge
the battery as required.
Battery detection failed:
‣Remove the battery and
then insert it again.
‣Try to switch on the lamp.
Temperature limits of the
battery are exceeded:
‣Make sure that you are
using the battery within
the external temperature
limits of -20°C - 40°C.
Please note that the battery
additionally heats up during
operation.
‣Restart the lamp after a
waiting period of approx.
10 min.

14
13 Technical data of the lamp
XP30R manual V.01_01.2023
Fault Status display Cause and measure
Fault
Lamp cannot
be switched
on / Lamp
goes o dur-
ing operation
2 bars of the
battery status
display blink 5
times consec-
utively
Temperature limits of the
lamp are exceeded
‣Make sure that you are
using the lamp within
the external temperature
limits of -20°C - 40°C.
Please note that the lamp can
additionally intensively heat
up during operation due to
heat build-up.
‣Restart the lamp after a
waiting period of approx.
10 min.
If the fault should continue, contact Ledlenser customer support.
13. Technical data of the lamp
Light mode Boost
Luminous flux
(lm)1
>32.000 I 24.000 I 15.500 I 8.500 I 4.000 I 500
Beam distance
(m)1
>2.000 I 1.900 I 1.500 I 1.100 I 800 I 500
Run time
(h)1
-I 0,5 I 0,75 I 1,25 I 2,5 I >16
Battery 18 V, 5 Ah, 90 Wh
Charging time
(min) 80
Weight g/oz
(incl. battery) 3480 /122,7
Size
(mm) W 307 x H 212 x D 180
IP class IP 54
1) depending on the selected operating mode

15
14 Instructions regarding disposal
XP30R manual V.01_01.2023
14. Dispose of defective batteries according to the na-
tional directives because the batteries can endanger
the environment.
The crossed out waste bin indicates the obligation
for disposal of old electrical and electronic
devices separately from the household waste.
For one thing, these devices contain valuable raw
materials, and for another, they can also contain
harmful substances.
Separate disposal avoids endangering the
environment and health and helps to conserve
resources by recycling raw materials.
Free return via local collection and return systems
as well as other collection points is possible.
All distributors with a retail space* of ≥ 400 m²
for electrical devices (or with ≥ 800 m² total retail
space*, which oer electrical devices in addition
to foodstus multiple times in a calendar year or
permanently or regularly each year) are obliged to
take back an old device (same type of device with
essentially the same function) directly or locally,
free of charge, upon submission of such devices.
Up to 3** old devices (max 25 x 25 x 25 cm) per
device type can also be returned locally free of
charge without a prior purchase in retail store or
at a return system.
Each end user is responsible for deleting personal
data on old devices.
Provided it can be done non-destructively, remove
the discharged batteries carefully, following
the usage instructions and dispose of them
separately.
For further information, see www.ledlenser.com.
* In case of sale using remote means of com-
munication, the storage and dispatch areas are
considered as retail space
** Unlimited number in some countries
15. Other information, tutorials and accessories are
stated on our website. Simply scan the QR code
below or visit www.ledlenser.com.
15 Other information
XP30R
i

16
Ledlenser GmbH & Co. KG
Kronenstr. 5-7, 42699 Solingen, Deutschland (Germany)
Phone [phone] Fax [phone]
[e-mail]
ledlenser.com
XP30R manual V.01_01.2023
