LEDLux Centralina TC423 User manual

Programmable Time Led Controller Instruction Manual Page 1 of 8
TC423 Programmable Time Led Controller
Instruction manual

Programmable Time Led Controller Instruction Manual Page 2 of 8
Contents
1.Product constitute………………………………………………………………………………………………2
2.Work statements instruction……………………………………………………………………………………2
3.Technical parameters……………………………………………………………………………………………2
4.Product description………………………………………………………………………………………………2
5.Interface instruction………………………………………………………………………………………………3
6.Function instructions……………………………………………………………………………………………4
7.Typical application………………………………………………………………………………………………7
8.Warning……………………………………………………………………………………………………………7

Programmable Time Led Controller Instruction Manual Page 3 of 8
1.Product constitute
1.Time programmable controller
It is the core of product, after setting, can operate without PC;
2. USB line
Using when connected with computer.
3. Disk
Contains the install software of computer, software operation
instruction and product manuals;
4. Paper manual
Include product operation of the details, but does not contain
software operating instructions;
5. Packing box
Exquisite packaging cassette with pearl cotton can prevent
products are extrusion bad in transport.
2.Work statements instruction
Indicator
state description
Power indicator
The power indicator light is lit, explain the power supply is normal; The
power indicator not bright, if the controller is not normal, then explain
controller power supply have problems;
Signal indicator
When press the button, the signal indicator will blink.
3. technical parameters
3.1 Working temperature :-20-60℃
3.2 Supply voltage : AC90-230V
3.3 static power：< 0.5W
3.4 net weight：200g
3.5 gross Weight：300g
3.6 External dimension：150MM*78.5MM*26MM
3.7 Packing dimension：185MM*180MM*54.8MM
3.8 Output: 5 channels
3.9 Max load current：1A/CH , 5CH
3.10 Output: Five CMOS drain- open output
3.11 Connecting Mode: Common anode
4.Product description
There is an upper computer in the programmable time controller to make the load output change over
time, the customer may customize schedule mode they want through the upper PC. Then through the
USB port to download required schedule to the controller.The upper PC in addition to the function of
editing schedule mode ,it also can be setup time for the controller because of synchronous clock function
of upper host .If user want to see the schedule mode effect after editing , they can use fast sowing
function of upper . Because there is no delete function of the upper host ,so the mode name display space

Programmable Time Led Controller Instruction Manual Page 4 of 8
will come into blank as long as you execute delete .This controller can control load of led changing effect
no more than five channels .And it can be used in the occasion of the plant lights, light box advertising, the
stage, home decoration, etc.
5.Interface instruction
5.1 Input interface
①②
①RESET：It is the reset button, when the controller crash, can touch this key to reset.
②USB：It is USB signal joint entrance, when epistatic machine model after editing, can through the
USB line to download to the controller.
5.2 Output interface
①CH1: It is the load output first channel negative pole;
②CH2: It is the load output second channel negative pole;
③CH3: It is the load output third channel negative pole;
④CH4: It is the load output 4th channel negative pole;
⑤CH5: It is the load output 5th channel negative pole;
⑥V+: It is the load output positive pole DC240V;(AC220 whole flow)
⑦⑧ AC+/AC-: It is AC input pole;(Input AC90V to 230 V )
6.Function instructions
There are two kinds of modes like energy saving mode and setup mode in this controller , and also

Programmable Time Led Controller Instruction Manual Page 5 of 8
there are four buttons such as "Menu", "Enter", "+", "-" in it.
6.1Power saving mode
When the controller in the situation of setup mode without any key press in 30 seconds , the screen
background light will be closed, and if within 30 seconds there is still no any key press, the controller will
go into the energy saving mode .
When the controller is in the energy saving mode, the first line of the screen shows that the current
date and mode; the second line displays the current time.
Energy saving mode is as shown in figure 1:
Figure 1
6.2 Setup mode
①Press "Menu" button in the main menu, it will enter into the time display interface.
The first line of the time display interface shows the current time or date and mode, it will
automatically switch every two seconds .
The second line shows that "[Menu]", press "Enter" button to access the main menu interface.
Time display interface is as shown in figure 2:
Figure 2
②When press "Enter" button in the time display interface , or "Menu" button in the submenu of the
main Menu , it will go into the main Menu.
The first line shows the location of " [Menu] "in the main Menu of the display .
The second line of the display shows "1. Mode", "2. Setup" or "3, Run", that you can switch each
mode by pressing the key "+" and "-" .
Press "Enter" button,it will access the corresponding setting mode ; and press the "Menu" button to
return to the time display interface .
The main menu display is as shown in figure 3:
Figure 3
③Select "1. Mode" in the main menu and press "Enter" button to go into the mode choice options .
The first line of the display shows the location of "【Mode】" in mode selection status .
The second line shows that the name of mode choice such as: "Mode11" .
Press the "+" or "-" key to choose mode , and save the selection mode ; Press the "Menu" button to
return to the main menu.
The mode choice of display is as shown in figure 4:
0
3
-
0
7
-
2
2
M
o
d
e
1
0
0
:
0
0
:
0
0
0
3
-
0
7
-
2
2
M
o
d
e
1
【
M
e
n
u
】
【
M
e
n
u
】
1
.
M
o
d
e

Programmable Time Led Controller Instruction Manual Page 6 of 8
Figure 4
④Select "2. Setup" in the main menu and press "Enter" button to go into the Setting menu ;
The first line of the screen shows the location of "【Setup】" in the setting menu status .
The second line of the display shows "1. Time" and "2. Date" or "3. Sound", you can select setting
object through the key "+" or "-" .
Press "Enter" button to access the corresponding Settings, and click "Menu" button to return to the
main Menu.
Setting menu is as shown in figure 5:
Figure 5
I．In the status of setting menu , choose "1. Time" and press "Enter" button, it will enter into time
setting mode;
The first line of the screen shows the location of "【Time】" in the time setting status .
The second line of display shows the setting time ": hour: minute : second", for instance ,
"11:16:56" is the current setting time .
Press "Enter" button to choose every setting number ( hour / minute /second ), as you seen ,in
editing state , the selected area will be flashing .
Press the key "+" to add 1 , when the number reach maximum , it will return around to the
minimum value ;
Press the key "-" to reduce 1 ,when the number reach minimum , it will be back to the maximum
value .
Press the "Menu" button to save and return to the setting menu .
Setting mode displays as shown in figure 6:
Figure 6
II．In the status of setting menu , choose "2.Date" and press "Enter" button, it will enter into date
setting mode;
The first line of the screen shows the location of "【Time】" in the date setting status .
The second line of display shows the setting date " year - month - day " , for instance "13-01-01" is
the current setting date .
Press "Enter" button to choose every setting number ( year / month / day), as you seen ,in editing
state , the selected area will be flashing .
Press the key "+" to add 1 , when the number reach maximum , it will return around to the
minimum value ;
Press the key "-" to reduce 1 ,when the number reach minimum , it will be back to the maximum
【
M
o
d
e
】
M
o
d
e
1
1
【
S
e
t
u
p
】
1
.
T
i
m
e
【
T
i
m
e
】
1
1
：
1
6
：
5
6

Programmable Time Led Controller Instruction Manual Page 7 of 8
value .
Press the "Menu" button to save and return to the setting menu .
Setting mode displays as shown in figure 7:
Figure 7
III．In the status of setting menu , choose " 3 .Sound " and press "Enter" button, it will enter into
sound setting mode ;
The first line of the screen shows the location of "【sound】" in the sound setting status .
The second line of the display shows "OPEN" or "CLOSE" which means the situation of sound
setting .
Press the key "+" or "-" to switch voice close or open ;
Press "Menu" button to return to the setting menu .
Sound Setting is as shown in figure 8:
Figure 8
⑤In the status of main menu , choose " 3.Run " and press "Enter" button, it will enter into run menu;
The first line of the screen shows the location of "【Run】" in the run menu .
The second line of the display shows "Start " or " Stop " which means the on/off situation of the
controller .
Press the key "+" or "-" to start or shut down .
Press "Enter" button to execute user's option; and press the "Menu" button to return to the main
Menu .
Run menu displays as shown in figure 9:
Figure 9
7. Typical application
【
D
a
t
e
】
1
3
-
0
1
-
0
1
【
S
o
u
n
d
】
O
P
E
N
【
R
u
n
】
S
t
a
r
t

Programmable Time Led Controller Instruction Manual Page 8 of 8
8.Warning
1.Power supply voltage of this product is from AC90V to 230 V
2.When it is downloading mode , you should firstly power on the controller , and then connect usb line to
the controller and computer ;
3.The power cord shall not be mutual attached in order to avoid short circuit .
4.Warranty of this product is one year, in this period we guarantee replacement or repairing with no
charge, but exclude the situation of artificial damaged or overload working.
