LEDLux Lucci 178195 User manual

Installation Instructions
1 | P a g e v 1 . 1 ( 0 6 / 2 0 2 0 )
HANDY LIGHT BAR
SKU# 178195, 178196, 178197
Rated Voltage 5V DC, 1A
Thank you for purchasing this quality Lucci product. To ensure correct function and safety, please read and follow all
instructions carefully before assembly, installation and use of this luminaire. Please keep the instructions for future
reference.
Warranty
•This luminaire is covered by a 12 month warranty from the date of purchase. Please retain proof of purchase.
•Warranty will be void if there is any damage due to improper usage or modification to the luminaire.
•Failure to comply with the instructions in this manual may increase the risk of damage or injury and will void warranty.
Installation Requirements
•Select a suitable location for this luminaire:
- This luminaire is not waterproof.
- This luminaire is suitable for indoor use only.
- Keep away from liquids, dusty, humid, direct sun light, cooking areas or hot areas.
•Lay out all the components on a smooth surface and make sure there are no components missing.
If parts are missing, return the complete luminaire to the place of purchase for inspection or replacement.
•Check whether the luminaire has been damaged during transport. Do not operate/install any luminaire which
appears damaged in any way. Return the complete luminaire to the place of purchase for inspection, repair or
replacement.
Operation Directions
Operation
1. Use the ‘On/Off’ switch to turn the luminaire on/off or to the motion sensing mode as below:
a. Long press the On/Off switch for 3 seconds then the luminaire will be permanently on;
b. Short press the On/Off switch once again then the luminaire will enter the motion sensing mode (Indicator
will flash once in green);
NOTE: Motion sensing mode – The luminaire will be turned on automatically when any motion is detected. It will
be turned off after 20 seconds if no motion is detected. (NOTE: The luminaire will only be activated when the
ambient light < 10lux)
c. Short press the On/Off switch again then the luminaire will be permanently off.
2. Strong magnet is provided on the back of the luminaire. Stick the back of the luminaire on the metal surface of the
desired location.
NOTE: There is a metal bar provided with ‘3M’ adhesive tape in case no metal surface is found on the desired
location. Ensure the surface is smooth, dry and clean before applying the ‘3M’ adhesive tape.
Charging
Plug the provided USB cable in the charging port and connect the USB cable to computer/laptop or power adaptor to
charge the luminaire. The charging indicator will be red under charging and will be green when fully charged.
NOTE: Please ensure an appropriate power adaptor is used for charging according to the rated input (5V DC, 1A) of this
luminaire.

Installation Instructions
2 | P a g e v 1 . 1 ( 0 6 / 2 0 2 0 )
Safety Tips and Warnings
•This luminaire is NOT a toy. Keep out of reach of small children.
•Always ensure the power is OFF and the luminaire has cooled down before performing any maintenance, cleaning or
adjustment to the luminaire.
•Young children should be supervised to ensure that they do not play with the luminaire.
•Select a suitable location away from liquids and hazards.
•Ensure that the luminaire does not come in contact with corrosive chemicals/solvents or abrasive cleaners etc.
•To clean, wipe with a damp clean cloth. Never soak the luminaire with water.
•The luminaire includes a built-in Li-ion battery, which is non-replaceable. The luminaire will need to be discarded once
the battery reaches its end of life. Contact your local council to safely dispose of equipment with batteries.
Specifications
SKU # 178195 178196 178197
Colour SILVER
Rated Voltage 5V DC, 1W 5V DC, 3W 5V DC, 5W
LED Specs Cool white, 4000K, 80 lumen Cool white, 4000K, 180 lumen Cool white, 4000K, 300 lumen
Motion Sensor
Specs
PIR Sensor
Detection range & angle: Max.6M, 120 degree
Recommend installation height: 1.5 – 2M
Activate when ambient light < 10lux
Battery
Built-in rechargeable Li-ion
battery, Non-replaceable,
650mAh
Built-in rechargeable Li-ion
battery, Non-replaceable,
1000mAh
Built-in rechargeable Li-ion
battery, Non-replaceable,
1000mAh
Weight 0.1kg 0.2kg 0.3kg
Dimensions L: 120mm W: 40mm
H: 18mm
L: 300mm W: 40mm
H: 18mm
L: 600mm W: 40mm
H: 18mm
On/Off Switch
USB charging port
Indicator / motion sensor
Metal bar with 3M
adhesive tape
