LEDone Distribution Inc L401 User manual

IMPORTANT SAFEGUARDS
When using electrical equipment, basic safety precautions should always be followed
including the following:
READ AND FOLLOW ALL SAFETY INSTRUCTIONS
1. To reduce the risk of electrical shock, turn off power supply before installation or
servicing.
2. This luminaire must be installed in accordance with the NEC or your local electrical
code. If you are not familiar with these codes and requirements, consult a qualified
electrician.
3. If NEMA photo control is installed refer to NEMA Receptacle section for instructions.
4. Verify the availability of necessary tools and incidental material.
527
134
330 260
458
102
L401/L402
L403/L404
TO INSTALL:
STEP 1:
Unfasten the stainless steel latches.
See Figure 1.
STEP 2:
Open the power door. Power door will
securely hang. See Figure 2.
STEP 3:
Slide fixture on to pole through opening on
the rear of housing and through splashguard.
See Figure 3.
STEP 4:
To level fixture, use bubble level located
inside housing. Adjust leveling of fixture
from side to side. To level from front to back,
slide pole to different step in upper housing.
Each step changes the angle in 2.5° degree
increments. See Figure 3.
Tilt: Stopping at the step marked “0”
provides no tilt. Stopping at the step marked
”+5" provides maximum tilt.
LUMINAIRE INSTALLATION
Latches 1
2
Power Door
Splashguard
Adjustment
Steps
Mounting
Bracket
3
Mounting Bracjet
Bolts
Installation Instructions

4
STEP 5:
Once desired position is achieved,
tighten mountingboltstotheappropriate
torquevaluesspecifiedinTORQUE
VALUEStabletotheleft.
IMPORTANT :DO NOT exceed these
torque levels on the mount bolts.
Exceeding recommended torque value
resulting in excessive deformation of
mounting bracket will causes tripping of
mount hardware which could lead to an
unsafe mounting condition.
STEP 6:
Reference Electrical Connections section
for completing electrical connections.See
Figure 4.
Step 7:
Close the housing cover and fasten the
two stainless steel latches. See Figure 5.
Step 8:
If luminaire is furnished with photocontrol
receptacle, install the photocontrol or
shorting.See Figure 6.
TORQUE VALUES
Pipe
Pipe Size Pipe Position Bolt Torque
Required (in-lbs)
Bolt Torque
Required (N-m)
+5.0 degrees tilt 200 22
+2.5 degrees tilt 200 22
0 degrees (no tilt) 200 22
-2.5 degrees tilt 200 22
-5.0 degrees tilt 200 22
+5.0 degrees tilt 200 22
+2.5 degrees tilt 200 22
0 degrees (no tilt) 200 22
-2.5 degrees tilt 200 22
-5.0 degrees tilt 200 22
1-3/4 IN O.D.
(44.45mm)
2-3/4 IN O.D.
(60.3mm)
Make the following Electrical Connections to the terminal block:
1. For 120/277V/347/480 connect the black fixture lead to the
voltage supply position of the terminal block .
2. For 120/277V/347/480 connect the white fixture lead to the
neutral supply position of the terminal block .
3. Connect the green or green/yellow ground lead to the
green wire position of the terminal block.
4. If Dimming is an option; connect the violet dimming
positive lead to the supply dimming positive lead.
5. If Dimming is an option; connect the grey dimming
negative lead to the supply dimming negative lead
5
Latches
L N G
Photocontrol
