LED72 - PRODUCT INFORMATION
V 16.291.17
TECHNICAL SPECIFICATION
PART CODE LED72-12V-IP20-30K LED72-24V-IP20-30K
IP RATING IP20 IP20
INPUT VOLTAGE 12V DC 24V DC
WATTAGE 7.2W / m 7.2W / m
WIDTH 10mm 10mm
HEIGHT 2mm 2mm
LUMEN 3000K 500lm / m 500lm / m
CRI >80 >80
LED CHIP SIZE 5050 5050
LEDS PER METRE 30 30
CUTTING INCREMENT 50mm 50mm
BEAM ANGLE 120º 120º
OPERATING TEMP. -10º to 45ºC -10º to 45ºC
DIMMABLE Yes, with compatible dimmer interface or dimmable LED driver. Yes, with compatible dimmer interface or dimmable LED driver.
AVERAGE ILLUMINATION** 30000 hours 30000 hours
WARRANTY 3 years 3 years
RoHS

0116 246 1188
WWW.LEDRIDGE.CO.UK
V 16.291.17
0116 246 1188
WWW.LEDRIDGE.COM
LED72 - PRODUCT INFORMATION
WARNING! Read this section before any installation work is carried out.
All work should be carried out as per our instructions. Failure to do so may
damage the unit and other products associated with it and void any warranty.
INSTALLATION
All work involving electrical components should be carried out
by a competent qualied electrical professional in accordance to
NICEIC and IET BS 7671 wiring regulations and any local by laws.
Ensure all mains power is turned off before starting any installation
or maintenance; and remains off for the duration of installation or
maintenance.
Waste electrical products should not be disposed of in domestic waste.
Please check with your Local Authority or retailer for recycling advice.
We are only able to offer advice and installation instruction on our own
products, we are unable to offer individual advice on other manufactures
products. You are required and responsible for ensuring that the
specication of this product is compatible with other products from other
manufactures.
Please ensure that all products used in your installation are complete,
correct and compatible before starting any installation. Failure to do so
may result in damaged products, our warranty does not cover damage
caused by or to any other manufactures products.
IF IN DOUBT CONTACT US: 0116 246 1188
This LED tape is NOT mains voltage. Do not exceed the LED ribbons
maximum voltage.
You must use 12V DC LED drivers for 12V LED tape or 24V DC LED
drivers for 24V LED tape. You should check the correct LED driver is
used before starting installation, incorrect drivers may damage the LED
tape beyond repair. You can nd the voltage of your LED tape printed
on the strip.
Your LED driver will have a maximum load. Do not put more load through
the LED driver than the maximum load. Our LED drivers maximum load
are rated by wattage.
To calculate the minimum wattage of your LED driver for your LED tape
use the following this equation:
Wattage of
LED tape per
Metre
X
Total Length
of LED Tape in
Metres
=
Total
Wattage
Required of
LED Driver
e.g 14.4 X 2 = 28.8W
Ensure your LED drivers maximum load is greater than Total Wattage
Required of LED Driver from the above equation.
VOLTAGE, DRIVERS & MAXIMUM LOAD
MOUNTING SURFACE
LED tape is not designed to be attached directly to a non conductive
surface such as wood, brick, paper, plaster or plastic. Doing so may
reduced the life of the LED.
It is recommended to use aluminum backing on all LED tape. Other
options are available but please contact us for advice.
On some materials the self adhesive strip may require additional
adhesive. We recommend a grab adhesive.
CORNERS & BENDS
LED tape is exible, however it will not make 90º bends. Trying to force
the LED tape to make these bends may damage the LED circuit board,
causing some or all LEDs to stop working. To make 90º beds you should
create a link between two LED tapes.
IP rated tape will have reduced exibility compared to non IP rated tape.
CUTTING
You must always cut LED tape along the cut points. The cut point is
indicated by the scissor mark.
When cutting IP rated ribbon you should ensure a good heat shrink is
applied to maintain the IP rating of the ribbon. Failure to do so will result
in reduced or no IP rated protection.
Cutting the LED tape anywhere else other than along the cut point will
stop the LED tape working.
MAXIMUM RUN LENGTH
The maximum run length of 12V LED tape is 5 metres, 24V LED tape is
10 metres. The maximum length of a y lead is 10 metres. You should
not exceed these lengths in one continuous run. Doing so may cause
voltage drop and result in reduced brightness.
To create longer runs, wire multiple lengths in parallel to the LED driver.
IP PROTECTION
IP20 & IP33 LED tape can be installed in dry environments and has no
water rated protection.
IP65 & IP67 LED tape can be installed in moderate wet environments
and has splash water protection.

0116 246 1188
WWW.LEDRIDGE.CO.UK
0116 246 1188
WWW.LEDRIDGE.COM
LED72 - PRODUCT INFORMATION
V 16.291.17
3. Fix the Aluminium strip to the surface.
The aluminium strip can be xed into place with either screws or
using a grab adhesive.
When xing with screws you will need to drill your own holes
where you require them.
Ensure the grab adhesive is dry before continuing your installation.
1. Ensure all mains power is turned off.
2. Ensure the surface where your LED tape and aluminium are to
be installed are clean and dry.
4. Remove the 3M backing of the LED tape.
5. With the adhesive side of the LED tape facing the aluminium
strip, x the LED tape to the aluminum strip.
NOTE: You may need our red tape (sold separately) in humid,
damp or wet prone environments for added strength. Fix this to
the aluminium strip before xing the LED tape.
6. Connecting the LED driver to the mains Please refer to your
individual driver instructions for installation as different drivers
may require different installation methods.
It is recommended to install the LED driver via an switch fuse
isolator tted with the correct fuse depending on the LED driver
used. (See your driver specication for this information).
NOTE: Ensure the LED driver has a clearance and air ow
to prevent overheating (see your driver specication for this
information).
7. Connecting the LED driver to LED tape. Please refer to your
individual driver instructions to ensure your connections are
correct to the driver being used.
It is recommended to make the connection using an in-line crimp.
8. Once all wiring is completed and made safe turn on mains
power.
(+) WHITE
(-) WHITE
WITH
BLACK
TACKER
RED (+)
BLACK (-)
LED DRIVER
12V / 24V
NEUTRAL
LIVE
FUSE
LED DRIVER
BLUE
BROWN
NEUTRAL
LIVE
230V 230V
INSTALLING WITHOUT DIMMING INTERFACE

0116 246 1188
WWW.LEDRIDGE.CO.UK
V 16.291.17
0116 246 1188
WWW.LEDRIDGE.COM
LED72 - PRODUCT INFORMATION
3. Fix the Aluminium strip to the surface.
The aluminium strip can be xed into place with either screws or
using a grab adhesive.
When xing with screws you will need to drill your own holes
where you require them.
Ensure the grab adhesive is dry before continuing your installation.
1. Ensure all mains power is turned off.
2. Ensure the surface where your LED tape and aluminium are to
be installed are clean and dry.
4. Remove the 3M backing of the LED tape.
5. With the adhesive side of the LED tape facing the aluminium
strip, x the LED tape to the aluminum strip.
NOTE: You may need our red tape (sold separately) in humid,
damp or wet prone environments for added strength. Fix this to
the aluminium strip before xing the LED tape.
6. Connecting the LED driver to the mains. Follow the diagram on
installation of LED driver to mains. Please refer to your individual
driver instructions for installation as different drivers may require
different installation methods.
It is recommended to install the LED driver via an switch fuse
isolator tted with the correct fuse depending on the LED driver
used. (See your driver specication for this information).
NOTE: Ensure the LED driver has a clearance and air ow
to prevent overheating (see your driver specication for this
information).
7. Connecting the LED driver to dimming interface. Please
refer to your individual driver instructions and dimming interface
instructions.
It is recommended to make the connection using an in-line crimp.
9. Once all wiring is completed and made safe turn on mains
power.
(+) WHITE
(- )WHITE
WITH
BLACK
TACKER
RED (+)
BLACK (-)
DIMMING INTERFACE
NEUTRAL
LIVE
FUSE
LED DRIVER
BLUE
BROWN
NEUTRAL
LIVE
230V 230V
INSTALLING WITH DIMMING INTERFACE
DIMMING INTERFACE
DIMMER
SWITCH
0-10V
TO LED
TO
DRIVER
8. Connecting the LED tape to dimming interface. Please refer to
your individual dimmer interface instructions.
It is recommended to make the connection using an in-line crimp.

0116 246 1188
WWW.LEDRIDGE.CO.UK
0116 246 1188
WWW.LEDRIDGE.COM
LED72 - PRODUCT INFORMATION
V 16.291.17
LIMITED PRODUCT WARRANTY
This product is sold with a 3 year extended warranty, effective for 36 months from the date of purchase as of 1st August 2016, purchases before this
date are covered by a 2 year standard warranty, effective for 24 months from the date of purchase.
1.1 Subject to the conditions set out below the Seller (Ledridge Lighting) warrants that the Goods will correspond with their written specication
(if any) at the time of delivery and will be free from material defects in materials and workmanship for a period as stated above from the date of
purchase or for such longer period as the Seller (in its absolute discretion) may determine. The warranty does not apply to consumable items
included with or in the product, which may have a reduced or no warranty period.
1.2 The warranty given in clause 1.1 above is given by the Seller strictly subject to the following conditions:
1.2.1 The Seller shall be under no liability in respect of any defect in the Goods arising from any drawing design specication or other information
supplied by the Buyer or their agents.
1.2.2 The Seller shall be under no liability in respect of any defect arising from fair wear and tear, willful damage, negligence, abnormal working
conditions or water damage where the product has limited or no water protection and installed in the incorrect environment, failure to follow the
Seller’s instructions (whether oral or written), misuse or alteration or repair of the goods without the Seller’s approval.
1.2.3 The Seller shall be under no liability under the warranty given in 1.1 above (or any other warranty condition or guarantee) if the total price for
the Goods has not been paid by the due date for payment.
1.2.4 The warranty given in 1.1 above does not extend to any Goods, parts, materials or equipment not manufactured by the Seller in respect of
which the Buyer shall only be entitled to the benet of any such warranty or guarantee as is given by the manufacturer thereof the Seller.
1.3 Any claim by the Buyer which is based on any defect in the quality or condition of the Goods shall be notied to the Seller within 7 days from
the date of delivery of the Goods or within a reasonable time after discovery of the defect or failure. If delivery is not refused and the Buyer does not
notify the Seller accordingly, the Buyer shall not be entitled to reject the Goods and the Seller shall have no liability for such defect or failure and the
Buyer shall be bound to pay the price of the Goods.
1.4 Any repair, replacement or refund or any monies made by the Seller to the Buyer shall not under any circumstances be deemed to be an
admission of any liability on the part of the Seller.
1.5 All liabilities of the Seller to the Buyer determined by the Court of Law as not having been excluded hereunder shall be limited in total to the total
price of the Goods as shown on the Seller’s invoice.
1.6 To obtain warranty service, the original proof of purchase will be required.
1. Lumen outputs are depicted at the maximum level during testing under optimal conditions. Actual levels may vary depending on a number of external factors outside of our control.
2. While we do our best to maintain colour consistency this may vary between batches. When ordering repeat items the item supplied may not be from the same batch as previous purchases and
so may have slight variation in colour rendering. All purchases made at the same time will be supplied from LED ribbon of the same batch.
3. Average illumination times are based on LED chip brightness reduction to 70% of the original brightness under optimal conditions. External factors, such as; but not limited to, heat may decrease
illumination lifetime. Illumination time does not reect the expected life span of the LED ribbon, which are covered by warranty.
