Leetro MPC8530S User manual

MPC8530S Hardware Manual
V1.0
Feb 2017

2
1、Mounting Size
2、Interfaces
3、Pin Definitions
Group
Pin
Definition

3
POW
24V-IN
Power Supply, DC 24V+ (Input)
GND
Power Supply, DC GND (Inpout)
X_AXIS
PULX
X-axis Pulse
DIRX
X-axis Direction
5V
Power Supply, DC 5V+
Y_AXIS
PULY
Y-axis Pulse
DIRY
Y-axis Direction
5V
Power Supply, DC 5V+
Z_AXIS
PULZ
Z-axis Pulse
DIRZ
Z-axis Direction
5V
Power Supply, DC 5V+
LASER
GND
Laser GND
DA1
Laser Power Control ONE
DA2
Laser Power Control TWO
LAS1
Laser On/Off Control ONE
LAS2
Laser On/Off Control TWO
X_LIM
GND
Limit GND (24V)
ORGX
X-axis Original (Home)
EL-X
X-axis Limit-
EL+X
X-axis Limit+
Y_LIM
GND
Limit GND (24V)
ORGY
Y-axis Original (Home)
EL-Y
Y-axis Limit-
EL+Y
Y-axis Limit+
Z_LIM
GND
Limit GND (24V)
ORGZ
Z-axis Original (Home)
EL-Z
Z-axis Limit-
EL+Z
Z-axis Limit+
IN
IN1
Signal Input ONE, Pedal
IN2
Signal Input TWO, Uncapping Protection
IN3
Signal Input THREE, Water Chilling
GND
Input GND (DC 24V)
OUT
OUT1
Signal Output ONE,Air-blow
OUT2
Signal Output TWO, WORK END
OUT3
Signal Output THREE
OUT4
Signal Output FOUR
GND
GND (DC 24V)
OUT
24V-OUT
Power Supply, 24V+ (Output)
GND
Power Supply, GND (Output)
PE
PE ,Earth Ground;
PE
PE, Earth Ground;
COM
Communication Port for Operation Panel
USB1
USB Master, to Flash Memory Disk

4
USB2
USB Slave, to the PC
NET
LAN port, to the PC/Router
4、Circuit Diagram
Make sure PE with the Earth Ground
24V-OUT is the output port. It is not for input!!!

5
PAD05S-C/E Installation dimension drawing
Installation dimension drawing：
installation diagram：
