Lefroy Brooks R1-4010 Assembly instructions

INSTALLATION, OPERATING & MAINTENANCE INSTRUCTIONS
R1-4010
CROSS HANDLE WALL SEQUENTIAL BASIN MIXER ROUGH,
TO SUIT K1-1310

2
Contents
Dimensions 3
InstalLation Procedure 4
Parts List 5
Fault Finder 6
Safety Tips, Care and Maintenance 7
Guarantee 8

Protective
cap
8 1/4"
4 9/16" Ø5/8"
4 1/2"
9 1/16"
3 13/16"
6 1/8"
1 3/4"
9"
10 1/16"
1 3/4"
4 5/8"~ 5 1/4"
(210mm)
(115.61m) (Ø15.88mm)
(114.3mm)
(230mm)
(96.8mm)
(155.8mm)
(44mm)
(228mm)
(255.6mm)
(45mm)
(118~134mm)
3
Dimensions in Inches (& Millimetres)
Whilst every effort is made to ensure accuracy, design and dimensions are subject to change without
notice as part of the company’s product development process.

3
12
Wall surface
4 5/8”~5 1/4”
(118mm~134mm)
Welding
4
Steps 1-3
InstallationProcedure
Lefroy Brooks always recommends that plumbing products be installed by a licensed professional.
Shut off main water supply before installation.
1Install valve body onto internal wall.
2Before installation, make sure that the distance between where the back plate is going to fix on
to and the front wall surface is 118~134mm.
3Connect hot and cold water supply to valve body by soldering.

2
4
5
8
7
6
9
10
1
3
11
12
1 Protective cap (038009)
2 Sleeve (035524)
3 Adjusting ring (104283)
4 Sequential cartridge (507970N)
5 Body (061932W)
6 Screw (075022)
7 Fixing plate (120268)
8 Screw (008013)
9 Screw (008003)
10 Protective cap (038007)
11 Wrench (031238)
12 Allen key (031000)
5
PartsList Exploded view

6
FaultFinder
Fault Cause Rectification
Drips from spout. Gasket is misfitted or damaged. Check for gasket placement.
Leaks around handle. Cartridge has come loose or
damaged.
Tighten/reinstall the cartridge or
replacement the cartridge if it is
damaged.

7
SafetyTips,CareandMaintenance
Safety Tips
If you are soldering during faucet installation,remove cartridges, seats, gaskets and washers prior to
applying flame, otherwise you will void the warranty.
Cover drain openings to avoid losing small parts.
When cutting or soldering pipe, use safety glasses to protect your eyes.
Important Points
Prior to beginning installation. turn off the cold and hot water lines and open the old faucet to release
built-up pressure.
Overtightening nuts may cause damage.
Wrap all threaded connections with pipe tape available at your local plumbing supply store.
Always wrap in a clockwise direction. The fittings should be installed by a state-licenced plumber.
Please note:
When there is a difference in water pressure between hot and cold supplies to the mixing valve, the
pressures should be equalized by a plumber in accordance with best practice and legislation.
Maintenance
Your new bathroom faucet is designed for years of trouble-free performance. Keep it looking new by
cleaning it periodically with a soft cloth. Avoid abrasive cleaners, wire wool and harsh chemicals as
these will dull the finish and void your warranty.
Routine Maintenance
The frequency and extent of attention required will vary according to prevailing site and operational
conditions, however a 12 monthly maintenance schedule is recommended.
If the product has operated satisfactorily for some time, but performance has been degraded, please
check the Fault Finder section to identify the problem.
Maintenance Check List
 s 7ORNORDAMAGEDSEALSANDWASHERS
 s $AMAGEDSEALFACES
 s 4HREADWEAR
 s )NCORRECTADJUSTMENT
 s #OMPONENTFAILURE
 s $EBRISORLIMESCALEBUILDUP

8
