Legend MSS-KREC-54AC Manual

Safe Operation &
Maintenance Instructions
ATTENTION!
Safe Operation & Maintenance Instructions must be followed.
MSS-KREC-54AC
legendpower.com.au
legendpower.co.nz
Safe Operation &
Maintenance Instructions
14.4V Cable Cutter
In support of our policy of continuous product improvement we reserve the right to change materials and specications without notice. Drawings, where used, are not to scale. All
dimensions are in millimetres and sizes given are approximate. Where possible, technical MSDS data sheets are made available on the website. All products should be installed and used
in accordance with manufacturer’s instructions provided. Warning: products may be the subject of registered designs and patents. Refer to website for terms and conditions on warranty.

1
In support of our policy of continuous product improvement we reserve the right to change materials and specications without notice. Drawings, where used, are not to
scale. All dimensions are in millimetres and sizes given are approximate. Where possible, technical MSDS data sheets are made available on the website. All products
should be installed and used in accordance with manufacturer’s instructions provided. Warning: products may be the subject of registered designs and patents. Refer
to website for terms and conditions on warranty.
Thank you for using MSS products. This manual must be read
carefully prior to operating this product. Special attention should be paid
to the section “Safety Instructions”. Damages and injuries caused by
improper use of this product are NOT included in our warranty. We
would like to remind you to work safely and to keep this manual on hand.
Safety Instructions
WARNING
ATTENTION
Follow ALL instructions to ensure safety.
This product is NOT an insulator
and cannot be used near energized
conductors.
Do not use this tool on glass, plastic,
wood or any other materials which
could shatter. Do not exceed
equipment ratings.
Always wear safety goggles when
operating this product. Projectiles or
hydraulic uid can cause serious
injuries.
Read all instructions, warnings, and
cautions carefully. Follow all safety
precautions to avoid personal injury
or property damage.




Safety Instructions
 Follow ALL instructions to ensure safety.
WARNING
ATTENTION

Read all instructions, warnings, and
cautions carefully. Follow all safety
precautions to avoid personal injury
or property damage.
Thank you for using KuDos® products. This manual must be read
carefully prior to operating this product. Special attention should be paid
to the section “Safety Instructions”. Damages and injuries caused by
improper use of this product are NOT included in our warranty. We
would like to remind you to work safely and to keep this manual on hand.
Always wear safety goggles when
operating this product. Projectiles or
hydraulic fluid can cause serious
injuries.
This product is NOT an insulator and
cannot be used near energized
conductors.
Do not use this tool on glass, plastic,
wood or any other materials which
could shatter. Do not exceed
equipment ratings.
1

2
In support of our policy of continuous product improvement we reserve the right to change materials and specications without notice. Drawings, where used, are not to
scale. All dimensions are in millimetres and sizes given are approximate. Where possible, technical MSDS data sheets are made available on the website. All products
should be installed and used in accordance with manufacturer’s instructions provided. Warning: products may be the subject of registered designs and patents. Refer
to website for terms and conditions on warranty.
1. Safety Instruction ........................................................................................1
2. Table of Contents .......................................................................................2
3. Safety Instruction. .......................................................................................3
4. Product Description. ....................................................................................4
5. Operate Instruction ....................................................................................5
7. Battery Charging. ......................................................................................7
8. Maintenance ...............................................................................................8
9. Trouble Shooting. ........................................................................................9
10. Warranty Information.............................................................................10
Contents

3
In support of our policy of continuous product improvement we reserve the right to change materials and specications without notice. Drawings, where used, are not to
scale. All dimensions are in millimetres and sizes given are approximate. Where possible, technical MSDS data sheets are made available on the website. All products
should be installed and used in accordance with manufacturer’s instructions provided. Warning: products may be the subject of registered designs and patents. Refer
to website for terms and conditions on warranty.
Safety Instructions
Work Area Safety
Electrical Safety
Personal Safety
1. Keep the area around the tool
clean and free of obstructions.
2. Keep the area free of ammables
which could ignite while using this
tool.
3. Children and bystanders should
stay clear of the work area to
ensure safety
1. Use only the specied battery
charger for the battery.
2. Use only the designated battery
pack with this tool.
3. Children and bystanders should
stay clear of the work area to
ensure safety
4. Avoid electrical shock. Do not
touch grounded metal
conductors while operating
this tool.
5. Do not use this tool in wet
conditions. Store this tool in a
dry place.
6. Do not drop or in any way abuse
or disassemble the battery pack
or charger.
1. Stay alert while using this tool to
prevent serious injury. Do not use
under the inuence of drugs,
alcohol or medicine.
2. Do not wear loose hair or clothes
that can get caught in the tool
while operating.
3. To reduce the risk of injury, wear
non-conductive gloves and
non-skid safety-shoes. Always
wear protective eyewear.
4. Make sure the tool switch is OFF
or the tool locked before inserting
the battery pack.
5. After servicing the tool, remove
adjusting keys or wrenches from
any moving parts of the tool
before use.
6. Work safely. Maintain your balance
and do not reach while operating
the tool.

4
In support of our policy of continuous product improvement we reserve the right to change materials and specications without notice. Drawings, where used, are not to
scale. All dimensions are in millimetres and sizes given are approximate. Where possible, technical MSDS data sheets are made available on the website. All products
should be installed and used in accordance with manufacturer’s instructions provided. Warning: products may be the subject of registered designs and patents. Refer
to website for terms and conditions on warranty.
Product Description: MSS-KREC-54AC
Specications:
Height: 338 (H)mm
Weight: 3.4 kgs (including battery)
Drive unit: 14.4V DC Motor
Charger (GS/CE):
Charger:
Input voltage:
230V Single Phase AC
Input frequency: 50-60Hz
Input current: 21.75 VA
Battery Specications:
Brand: MAKITA
Type: lithium-ion (Li-ion)
Capacity: 3.0 Ah
Output Voltage: 14.4V
Input Frequency: 50-60 Hz
Model No.: MSS-BL1430B
Model No.: MSS-ACH-18LI-ION
Input Voltage: 230V
Charging per battery:
Approx.
30min <3.0Ah>
Accessories:
Plastic carrying case
2x 14.4V / 3.0Ah Li-ion Battery, 230V Charger
Cutting Capacity: (Max. Cable diameter)
Nonferrous 54mm
CU Strand 54mm (max)
AL Strand 54mm (max)
Charger Specications:
NOTE: DO NOT CUT STEEL

5
In support of our policy of continuous product improvement we reserve the right to change materials and specications without notice. Drawings, where used, are not to
scale. All dimensions are in millimetres and sizes given are approximate. Where possible, technical MSDS data sheets are made available on the website. All products
should be installed and used in accordance with manufacturer’s instructions provided. Warning: products may be the subject of registered designs and patents. Refer
to website for terms and conditions on warranty.
Operating Instructions
1. Install the charged battery by sliding it into the base of the tool handle until it
clicks into place. The battery should be secured and unmoveable.
2. Take a look at the operation of tool switch system.
There are 3 settings: Move to left (Forward),
Middle (Neutral), Move to right (Reverse).
When the tool is not in use or is idle,
it should rest in the central position. Now the
Picture it shows the cutter stay in Neutral.
5
When the switch to the right, the blade goes backward.
When the switch to the left, the blade goes forward.
Operating Instructions
1. Install the charged battery by sliding it into the base of the tool handle until it clicks
into place. The battery should be secured and unmoveable.
2. Take a look at the operation of tool switch system.
There are 3 settings: Move to left (Forward),
Middle (Neutral), Move to right (Reverse).
When the tool is not in use or is idle,
it should rest in the central position. Now the
Picture it shows the cutter stay in Neutral.
When the switch to the right, the blade goes backward.
When the switch to the left, the blade goes forward.

6
In support of our policy of continuous product improvement we reserve the right to change materials and specications without notice. Drawings, where used, are not to
scale. All dimensions are in millimetres and sizes given are approximate. Where possible, technical MSDS data sheets are made available on the website. All products
should be installed and used in accordance with manufacturer’s instructions provided. Warning: products may be the subject of registered designs and patents. Refer
to website for terms and conditions on warranty.
3. Please find below diagram regarding on the safety switch.
The safty switch need to be press in the same time when you press the
trigger to make the blade moving, once the blade move, then the finger
press on the safety switch can be remove.
4. When the tool is sitting idly or once you are finished with it, put the tool
switch in the central position.
ATTENTION




Keep your fingers away from edge of the
moving blade when feeding it into the
gear mechanism. The switch may have
moved from the NEUTRAL position. 
6
3. Please nd below diagram regarding on the safety switch.
The safty switch need to be press in the same time when you press the
trigger to make the blade moving, once the blade move, then the nger
press on the safety switch can be remove. Picture it shows the cutter stay in Neutral.
4. When the tool is sitting idly or once you are nished with it, put the tool
switch in the central position.
ATTENTION
Keep your ngers away from edge of the
moving blade when feeding it into the
gear mechanism. The switch may have
moved from the NEUTRAL position.




Safety Instructions
 Follow ALL instructions to ensure safety.
WARNING
ATTENTION

Read all instructions, warnings, and
cautions carefully. Follow all safety
precautions to avoid personal injury
or property damage.
Thank you for using KuDos® products. This manual must be read
carefully prior to operating this product. Special attention should be paid
to the section “Safety Instructions”. Damages and injuries caused by
improper use of this product are NOT included in our warranty. We
would like to remind you to work safely and to keep this manual on hand.
Always wear safety goggles when
operating this product. Projectiles or
hydraulic fluid can cause serious
injuries.
This product is NOT an insulator and
cannot be used near energized
conductors.
Do not use this tool on glass, plastic,
wood or any other materials which
could shatter. Do not exceed
equipment ratings.
1

7
In support of our policy of continuous product improvement we reserve the right to change materials and specications without notice. Drawings, where used, are not to
scale. All dimensions are in millimetres and sizes given are approximate. Where possible, technical MSDS data sheets are made available on the website. All products
should be installed and used in accordance with manufacturer’s instructions provided. Warning: products may be the subject of registered designs and patents. Refer
to website for terms and conditions on warranty.
1. After removing the battery from the power tool, insert it into the battery
charger. The red indicator will light up and indicate the battery is charging.
2. The green light comes on after approx. 120 mins when the battery is fully
charged.(From battery being completely at)
3. Remove the battery from the charger and install into the handle of the power
tool sliding it into the base of the tool handle until it clicks into place. The
battery should be secured and unmoveable.
4. The charger will not operate effectively if overheated. Allow 10 minutes to
cool down between charges if charging consecutive batteries.
Battery Charging
ATTENTION
DO NOT dispose of this battery in a re
orotherwise abuse the battery.
DO NOT short circuit battery output
terminals
DO NOT disassemble or modify the
battery. This may lead to short circuiting
the battery cells causing personal injury
or damage to the battery.




Safety Instructions
 Follow ALL instructions to ensure safety.
WARNING
ATTENTION

Read all instructions, warnings, and
cautions carefully. Follow all safety
precautions to avoid personal injury
or property damage.
Thank you for using KuDos® products. This manual must be read
carefully prior to operating this product. Special attention should be paid
to the section “Safety Instructions”. Damages and injuries caused by
improper use of this product are NOT included in our warranty. We
would like to remind you to work safely and to keep this manual on hand.
Always wear safety goggles when
operating this product. Projectiles or
hydraulic fluid can cause serious
injuries.
This product is NOT an insulator and
cannot be used near energized
conductors.
Do not use this tool on glass, plastic,
wood or any other materials which
could shatter. Do not exceed
equipment ratings.
1

8
In support of our policy of continuous product improvement we reserve the right to change materials and specications without notice. Drawings, where used, are not to
scale. All dimensions are in millimetres and sizes given are approximate. Where possible, technical MSDS data sheets are made available on the website. All products
should be installed and used in accordance with manufacturer’s instructions provided. Warning: products may be the subject of registered designs and patents. Refer
to website for terms and conditions on warranty.
After use, look for burrs or dents in the blade. If burrs exist they can be
removed with a at grinding stone. Clean, sharp blades will provide better
and safer performance and put less strain on the tool.
The plastic housing can be kept clean with a soft soap cloth. Use a
lubricant to clean the blades if necessary.
Keep the handle dry and free of grease at all times.
Do NOT let the tool drop to the ground or into the carrying case to avoid
damage to internal parts ot to the plastic housing.
Store in a cool, dry area. Do NOT keep this product in places with high
temperatures, high humidity, or direct sunlight.
Inform Legend Power Systems authorized distributors in case of any abnormalities or
malfunctions of the product.
DO NOT DISASSEMBLE OR ATTEMPT TO REPAIR THIS TOOL.
Disassembly of this tool beyond changing the moving blade and gear
guides will void the warranty. (One year from purchase)
Maintenance
ATTENTION
DO NOT CUT THROUGH STEEL OR ANY
CONDUCTORS THAT CONTAIN STEEL.




Safety Instructions
 Follow ALL instructions to ensure safety.
WARNING
ATTENTION

Read all instructions, warnings, and
cautions carefully. Follow all safety
precautions to avoid personal injury
or property damage.
Thank you for using KuDos® products. This manual must be read
carefully prior to operating this product. Special attention should be paid
to the section “Safety Instructions”. Damages and injuries caused by
improper use of this product are NOT included in our warranty. We
would like to remind you to work safely and to keep this manual on hand.
Always wear safety goggles when
operating this product. Projectiles or
hydraulic fluid can cause serious
injuries.
This product is NOT an insulator and
cannot be used near energized
conductors.
Do not use this tool on glass, plastic,
wood or any other materials which
could shatter. Do not exceed
equipment ratings.
1

9
In support of our policy of continuous product improvement we reserve the right to change materials and specications without notice. Drawings, where used, are not to
scale. All dimensions are in millimetres and sizes given are approximate. Where possible, technical MSDS data sheets are made available on the website. All products
should be installed and used in accordance with manufacturer’s instructions provided. Warning: products may be the subject of registered designs and patents. Refer
to website for terms and conditions on warranty.
The Cable cannot be cut:
A. Tool Blades are worn or damaged. The blades must be replaced. Tools with
worn or damaged blades might cause property damage or even personal
injuries.
B. Applied cable is over-specication. Please check the specication table. The
circuit breaker will need to be reset.
C. The blade might be deformed by uneven distribution after cutting an
off-center cable.
Charging Lamp does not light up:
A. Dust, etc. has entered the battery cartridge. Clean the battery to remove any
obstructions.
B. Battery cartridge is overheating. Allow the cartridge to cool before
conditioning.
Even fully charged, the cutting capacity is reduced:
A. Life of the battery has expired. Replace the battery with a new battery
pin MSS-BL1430B
B. Deterioration of the blade. Replace the blade with a new blade.
Tool does not operate:
A. Battery cartridge is not charged. Charge the battery cartridge.
B. The battery contacts are dirty. Clear the battery contacts of dirt or debris.
C. The circuit breaker has been actuated. Push the reset pin to reset the circuit
breaker back to its original position
D. The OFF lock is not fully depressed. Make sure it is fully depressed and
reset the circuit breaker if necessary.
Trouble - Shooting

10
In support of our policy of continuous product improvement we reserve the right to change materials and specications without notice. Drawings, where used, are not to
scale. All dimensions are in millimetres and sizes given are approximate. Where possible, technical MSDS data sheets are made available on the website. All products
should be installed and used in accordance with manufacturer’s instructions provided. Warning: products may be the subject of registered designs and patents. Refer
to website for terms and conditions on warranty.
This product is warrantied against defects in materials and workmanship
for one year.
This warranty is subject to the following exclusions and limitations:
1. This warranty does not cover damages to products which are
not installed, operated, used and maintained in accordance with
written instructions.
2. This warranty does not cover products that have been worn out,
damaged by improper storage, damaged or otherwise altered, or
from disassembly or attempted disassembly by parties other than
Legend Power Systems or its authorized service representatives.
3. This warranty does not cover damages caused by the use of
components not manufactured or authorized by Legend Power Systems,
acts of God, accidents, or use in a manner for which they are not
intended.
Receipt and warranty card are required for warranty services.
If the tool is found to be defective, in our sole judgement, Legend Power
Systems will either repair or replace the defective product or part.
Warranty

11
In support of our policy of continuous product improvement we reserve the right to change materials and specications without notice. Drawings, where used, are not to
scale. All dimensions are in millimetres and sizes given are approximate. Where possible, technical MSDS data sheets are made available on the website. All products
should be installed and used in accordance with manufacturer’s instructions provided. Warning: products may be the subject of registered designs and patents. Refer
to website for terms and conditions on warranty.
Replace any worn or damaged parts immediately.
- Contact Legend Power Systems ASAP to book in a repair/service
Do NOT attempt to disassemble or repair the product.
MSS hydraulic tools must be serviced by a qualied technician.
Contact your Legend Power Systems representative for more
information.
ATTENTION!
Do not dispose of batteries or electrical appliances as unsorted municipal waste.
Use separate collection facilities*. If electrical appliances are disposed of in landlls or
dumps, hazardous substances can leak into the groundwater and damage the public’s health
and well-being.
*Contact your local government for information regarding the collection systems available.
