HaloScape™Kit

Instruction Manual

Cat No. RGLKVSPBL4

1 Speciﬁcations

Cat No RGLKVSPBL4

Supply Voltage 240V~ 50Hz

Power Supply Output Rating 20.4 VA , 12Vac

Lamp Type/Power G4 Halogen 5W

IP rating IP44

Mounting Plastic Stake

Wiring connection Jaw Lock connector

Housing Material/Finish Plastic UV Stabilised Black

2 Installation

PLEASE READ ALL INSTRUCTIONS CAREFULLY BEFORE INSTALLING YOUR HPM GARDEN LIGHTS

The Geo Spotlight Kit will need to be assembled prior to installation. Carefully remove and identify all the xture parts from their protective packaging

and lay them out in front of you.

There should be:

• 4 x spotlights (also sold individually cat. number RGLVSPLBL)

• 4 x locking plugs

• 4 x stakes

• 4 x 5W halogen globes already inserted into the light xture (see ‘Globe Replacement’ instructions inside).

RGLKVSPBL4

Geo Spotlight Kit – 5W black nish

3 Cable Layout

HPM strongly recommends that you limit Individual cable lengths to 15 metres,

otherwise lights may get progressively dimmer towards the end of the cable

(voltage drop).

HPM HaloScape™ cable (Cat RGLHSC15) is the only type of cable you can use

for HaloScape™lights.

If you wish to add additional HaloScape™Spotlights to this kit you will require

another transformer to provide additional output terminals for your cable.

You may also require more HPM HaloScape™cable.

Warranty

Legrand warrants this product for a period of 1 year from the date of purchase.

These goods come with guarantees that cannot be excluded under the Australian

and New Zealand Consumer Laws. You are entitled to a replacement or a refund for

a major failure and for compensation for any other reasonably foreseeable loss or

damage. You are also entitled to have the goods repaired if the goods fail to be of

acceptable quality and the failure does not amount to a major failure.

See the Warranty card enclosed with this product for further details.

LE10571AAA HPML1824

5 Maintenance/cleaning

To prolong the life of your Gardenlights HPM recommends the following:

• Install away from salty or corrosive environments

• Install away from highly fertilised areas

• Do not sudmerse in treated water such as chlorinated pools

To keep your lights looking new, keep lenses free of dust and residue by wiping occasionally with a dry cloth, or warm soapy water if necessary.

If using soapy water, ensure that you thoroughly dry your light after cleaning.

4 Choosing a suitable transformer

The total wattage of your garden lights must not exceed the rating of the transformer. If you wish to add more lights to your garden, your must add

another transformer. When choosing a suitable transformer, always refer to the voltage rating of the transformer.

If, for instance you select 4 lights of 5 watts each (4 x 5 = 20 watts) a transformer rated 20 watts or greater is suitable. If the total wattages of the lights

you choose exceed the rating of the transformer, a larger (or additional) transformer will be needed.

You may decide to mix light styles (Courtyard, walk, down, spot, coach, up, hanging, edge, stone, step lights) of different wattages. In this case simply

add a transformer suitable for the total wattage.

1. This product must be installed and used as per these instructions.

2. This product contains no serviceable parts and no attempt should be made to repair this product. If the product is faulty it should be discarded.

3. This product is not suitable for installation in hazardous and/or corrosive areas.

4. Electrical installations periodically receive transient over voltages. This product has been designed to minimise the effect of such voltages on connected

equipment. It may not give full protection for extreme over-voltage transients such as those resulting from a close lighting strike.

5. This product utilises intellectual property in the form of registered designs, trademarks, and/or patents. Such intellectual property remains the property

of Legrand in all cases.

6. Legrand reserves the right to modify the specication of this product at any time.

7. This product has been designed to operate in ambient temperatures: -5°C to 25°C occasionally reaching 35°C.
