Leica iCON gps 30
User Manual
Version 1.1
English

Introduction
Congratulations on the purchase of the Leica iCON gps 30.
This manual contains important safety directions as well as instructions for
setting up the product and operating it. Refer to "1 Safety Directions" for fur-
ther information.
Read carefully through the User Manual before you switch on the product.
The content of this document is subject to change without prior notice. Ensure
that the product is used in accordance with the latest version of this docu-
ment.
Updated versions are available for download at the following Internet address:
https://myworld.leica-geosystems.com > myDownloads.
The model and serial number of your product are indicated on the type plate.
Always refer to this information when you need to contact your agency or
Leica Geosystems authorised service centre.
•Windows is a registered trademark of Microsoft Corporation in the United
States and other countries
All other trademarks are the property of their respective owners.
This manual applies to the Leica iCON gps 30 GNSS instrument. Where there
are differences between the various instruments they are clearly described.
Name Description/Format
Leica iCON gps 30
Quick Guide
Provides an overview of the instru-
ment together with technical data
and safety directions. Intended as a
quick reference guide.
ü ü
Leica iCON gps 30
User Manual
In order to operate the instrument
to a basic level all instructions
required are contained in the User
Manual. Provides an overview of the
instrument together with technical
data and safety directions.
-ü
Refer to the following resources for all iCON gps 30 documentation/
software:
•Leica USB documentation card
•https://myworld.leica-geosystems.com
myWorld@Leica Geosystems (https://myworld.leica-geosystems.com)
offers a wide range of services, information and training material.
With direct access to myWorld, you are able to access all relevant services
whenever it is convenient for you.
Purchase
☞
Product identication
Trademarks
Validity of this
manual
Available
documentation
2

Service Description
myProducts Add all products that you and your company own
and explore your world of Leica Geosystems: View
detailed information on your products and update
your products with the latest software and keep up-
to-date with the latest documentation.
myService View the current service status and full service his-
tory of your products in Leica Geosystems service
centres. Access detailed information on the services
performed and download your latest calibration cer-
ticates and service reports.
mySupport Create new support requests for your products that
will be answered by your local Leica Geosystems
Support Team. View the complete history of your
support requests and view detailed information on
each request in case you want to refer to previous
support requests.
myTraining Enhance your product knowledge with Leica Geosys-
tems Campus - Information, Knowledge, Training.
Study the latest online training material on your
products and register for seminars or courses in
your country.
myTrustedServices Add your subscriptions and manage users for Leica
Geosystems Trusted Services, the secure software
services, that assist you to optimise your workow
and increase your efciency.
3

Table of Contents
1 Safety Directions 5
1.1 General Introduction 5
1.2 Denition of Use 6
1.3 Limits of Use 6
1.4 Responsibilities 6
1.5 Hazards of Use 7
1.6 Electromagnetic Compatibility (EMC) 10
1.7 FCC Statement, Applicable in U.S. 12
1.8 ISED Statements (EN/FR), Applicable in Canada 13
2 Description of the System 14
2.1 Overview 14
2.2 System Components 14
2.3 Power Concept 15
2.4 Container Contents 16
2.5 Accessories 16
3 Operation 17
3.1 Guidelines for Correct Results with GNSS Surveys 17
3.2 Batteries 17
3.2.1 Operating Principles 17
3.2.2 Changing the Battery 17
3.3 Equipment Setup as a Real-Time Rover 18
3.4 Holder and Clamp for Field Controller 19
4 Care and Transport 20
4.1 Transport 20
4.2 Storage 20
4.3 Cleaning and Drying 20
5 Technical Data 22
5.1 Tracking Characteristics iCON gps 30 22
5.2 Accuracy 22
5.3 Technical Data 23
5.4 Conformity to National Regulations 24
5.4.1 Dangerous Goods Regulations 25
6 Software Licence Agreement 26
Appendix A Firmware Upgrade 27
Appendix B Pin Assignments and Sockets 28
4 Table of Contents

1 Safety Directions
1.1 General Introduction
The following directions enable the person responsible for the product, and
the person who actually uses the equipment, to anticipate and avoid opera-
tional hazards.
The person responsible for the product must ensure that all users understand
these directions and adhere to them.
Warning messages are an essential part of the safety concept of the instru-
ment. They appear wherever hazards or hazardous situations can occur.
Warning messages...
•make the user alert about direct and indirect hazards concerning the use
of the product.
•contain general rules of behaviour.
For the users‘ safety, all safety instructions and safety messages shall be
strictly observed and followed! Therefore, the manual must always be available
to all persons performing any tasks described here.
DANGER, WARNING, CAUTION and NOTICE are standardised signal words for
identifying levels of hazards and risks related to personal injury and property
damage. For your safety, it is important to read and fully understand the fol-
lowing table with the different signal words and their denitions! Supplement-
ary safety information symbols may be placed within a warning message as
well as supplementary text.
Type Description
DANGER Indicates an imminently hazardous situation
which, if not avoided, will result in death or
serious injury.
WARNING Indicates a potentially hazardous situation or
an unintended use which, if not avoided,
could result in death or serious injury.
CAUTION Indicates a potentially hazardous situation or
an unintended use which, if not avoided,
may result in minor or moderate injury.
NOTICE
Indicates a potentially hazardous situation or
an unintended use which, if not avoided,
may result in appreciable material, nancial
and environmental damage.
☞Important paragraphs which must be
adhered to in practice as they enable the
product to be used in a technically correct
and efcient manner.
Description
About warning
messages
Safety Directions 5

1.2 Denition of Use
•Measuring raw data using carrier phase and code signal from GNSS satel-
lites.
•Computing with software.
•Recording measurements.
•Recording GNSS and point related data.
•Carrying out measurement tasks using various GNSS measuring tech-
niques.
•Data communication with external appliances.
•Use of the product without instruction.
•Use outside of the intended use and limits.
•Disabling safety systems.
•Removal of hazard notices.
•Opening the product using tools, for example screwdriver, unless this is
permitted for certain functions.
•Modication or conversion of the product.
•Use after misappropriation.
•Use of products with recognisable damage or defects.
•Use with accessories from other manufacturers without the prior explicit
approval of Leica Geosystems.
•Inadequate safeguards at the working site.
•Controlling of machines, moving objects or similar monitoring application
without additional control and safety installations.
1.3 Limits of Use
Suitable for use in an atmosphere appropriate for permanent human habita-
tion: not suitable for use in aggressive or explosive environments.
WARNING
Working in hazardous areas, or close to electrical installations or sim-
ilar situations
Life Risk.
Precautions:
▶Local safety authorities and safety experts must be contacted by the per-
son responsible for the product before working in such conditions.
The following advice is only valid for battery charger, power adapter and car
adapter.
Suitable for use in dry environments only and not under adverse conditions.
1.4 Responsibilities
Leica Geosystems AG, CH-9435 Heerbrugg, hereinafter referred to as Leica
Geosystems, is responsible for supplying the product, including the User
Manual and original accessories, in a safe condition.
Intended use
Reasonably
foreseeable misuse
Environment
☞
Environment
Manufacturer of the
product
6 Safety Directions

The person responsible for the product has the following duties:
•To understand the safety instructions on the product and the instructions
in the User Manual.
•To ensure that it is used in accordance with the instructions.
•To be familiar with local regulations relating to safety and accident pre-
vention.
•To inform Leica Geosystems immediately if the product and the applica-
tion becomes unsafe.
•To ensure that the national laws, regulations and conditions for the oper-
ation of the product are respected.
•To ensure that the radio modem is not operated without the permission
of the local authorities on frequencies and/or output power levels other
than those specically reserved and intended for use without a specic
permit. The internal and external radio modems have been designed to
operate on frequency ranges and output power ranges, the exact use of
which differs from one region and/or country to another.
1.5 Hazards of Use
DANGER
Risk of electrocution
Because of the risk of electrocution, it is dangerous to use poles, levelling
staffs and extensions in the vicinity of electrical installations such as power
cables or electrical railways.
Precautions:
▶Keep at a safe distance from electrical installations. If it is essential to
work in this environment, rst contact the safety authorities responsible
for the electrical installations and follow their instructions.
WARNING
Lightning strike
If the product is used with accessories, for example masts, staffs, poles, you
may increase the risk of being struck by lightning.
Precautions:
▶Do not use the product in a thunderstorm.
WARNING
Distraction/loss of attention
During dynamic applications, for example stakeout procedures, there is a
danger of accidents occurring if the user does not pay attention to the envir-
onmental conditions around, for example obstacles, excavations or trafc.
Precautions:
▶The person responsible for the product must make all users fully aware of
the existing dangers.
Person responsible
for the product
Safety Directions 7

WARNING
Inadequate securing of the working site
This can lead to dangerous situations, for example in trafc, on building sites
and at industrial installations.
Precautions:
▶Always ensure that the working site is adequately secured.
▶Adhere to the regulations governing safety, accident prevention and road
trafc.
WARNING
Incorrect fastening of the external antenna
Incorrect fastening of the external antenna to vehicles or transporters poses
the risk of the equipment being broken by mechanical inuence, vibration or
airstream. This may result in accident and physical injury.
Precautions:
▶Attach the external antenna professionally. The external antenna must be
secured additionally, for example by use of a safety cord. Ensure that the
mounting device is correctly mounted and able to carry the weight of the
external antenna (>1 kg) safely.
WARNING
Improper disposal
If the product is improperly disposed of, the following can happen:
•If polymer parts are burnt, poisonous gases are produced which may
impair health.
•If batteries are damaged or are heated strongly, they can explode and
cause poisoning, burning, corrosion or environmental contamination.
•By disposing of the product irresponsibly you may enable unauthorised
persons to use it in contravention of the regulations, exposing themselves
and third parties to the risk of severe injury and rendering the environ-
ment liable to contamination.
Precautions:
▶The product must not be disposed with household waste.
Dispose of the product appropriately in accordance with
the national regulations in force in your country.
Always prevent access to the product by unauthorised
personnel.
Product-specic treatment and waste management information can be
received from your Leica Geosystems distributor.
WARNING
Improperly repaired equipment
Risk of injuries to users and equipment destruction due to lack of repair
knowledge.
Precautions:
▶Only authorised Leica Geosystems Service Centres are entitled to repair
these products.
8 Safety Directions

CAUTION
Not properly secured accessories
If the accessories used with the product are not properly secured and the
product is subjected to mechanical shock, for example blows or falling, the
product may be damaged or people can sustain injury.
Precautions:
▶When setting up the product, make sure that the accessories are correctly
adapted, tted, secured, and locked in position.
▶Avoid subjecting the product to mechanical stress.
WARNING
Inappropriate mechanical inuences to batteries
During the transport, shipping or disposal of batteries it is possible for inap-
propriate mechanical inuences to constitute a re hazard.
Precautions:
▶Before shipping the product or disposing it, discharge the batteries by the
product until they are at.
▶When transporting or shipping batteries, the person in charge of the
product must ensure that the applicable national and international rules
and regulations are observed.
▶Before transportation or shipping, contact your local passenger or freight
transport company.
WARNING
Exposure of batteries to high mechanical stress, high ambient temper-
atures or immersion into uids
This can cause leakage, re or explosion of the batteries.
Precautions:
▶Protect the batteries from mechanical inuences and high ambient tem-
peratures. Do not drop or immerse batteries into uids.
WARNING
Short circuit of battery terminals
If battery terminals are short circuited e.g. by coming in contact with jewellery,
keys, metallised paper or other metals, the battery can overheat and cause
injury or re, for example by storing or transporting in pockets.
Precautions:
▶Make sure that the battery terminals do not come into contact with
metallic objects.
Safety Directions 9

WARNING
Battery pack of the signal transmitter may get hot after prolonged use.
Risk of burning injuries.
Precautions:
▶Avoid touching the hot battery pack.
▶Allow the battery pack to cool down before removing it.
For the AC/DC power supply and the battery charger:
WARNING
Electric shock due to use under wet and severe conditions
If unit becomes wet it may cause you to receive an electric shock.
Precautions:
▶If the product becomes humid, it must not be used!
▶Use the product only in dry environments, for example in buildings or
vehicles.
▶Protect the product against humidity.
For the AC/DC power supply and the battery charger:
WARNING
Unauthorised opening of the product
Either of the following actions may cause you to receive an electric shock:
•Touching live components
•Using the product after incorrect attempts were made to carry out repairs.
Precautions:
▶Do not open the product!
▶Only Leica Geosystems authorised service centres are entitled to repair
these products.
1.6 Electromagnetic Compatibility (EMC)
The term Electromagnetic Compatibility is taken to mean the capability of the
product to function smoothly in an environment where electromagnetic radi-
ation and electrostatic discharges are present, and without causing electro-
magnetic disturbances to other equipment.
WARNING
Electromagnetic radiation
Electromagnetic radiation can cause disturbances in other equipment.
Precautions:
▶Although the product meets the strict regulations and standards which
are in force in this respect, Leica Geosystems cannot completely
exclude the possibility that other equipment may be disturbed.
Description
10 Safety Directions

CAUTION
Use of the product with accessories from other manufacturers. For
example eld computers, personal computers or other electronic equip-
ment, non-standard cables or external batteries
This may cause disturbances in other equipment.
Precautions:
▶Use only the equipment and accessories recommended by Leica Geosys-
tems.
▶When combined with the product, they meet the strict requirements stip-
ulated by the guidelines and standards.
▶When using computers, two-way radios or other electronic equipment,
pay attention to the information about electromagnetic compatibility
provided by the manufacturer.
CAUTION
Intense electromagnetic radiation. For example, near radio transmit-
ters, transponders, two-way radios or diesel generators
Although the product meets the strict regulations and standards which are in
force in this respect, Leica Geosystems cannot completely exclude the possib-
ility that function of the product may be disturbed in such an electromagnetic
environment.
Precautions:
▶Check the plausibility of results obtained under these conditions.
CAUTION
Electromagnetic radiation due to improper connection of cables
If the product is operated with connecting cables attached at only one of their
two ends, for example external supply cables, interface cables, the permitted
level of electromagnetic radiation may be exceeded and the correct function-
ing of other products may be impaired.
Precautions:
▶While the product is in use, connecting cables, for example product to
external battery, product to computer, must be connected at both ends.
Safety Directions 11

WARNING
Use of product with radio or digital cellular phone devices
Electromagnetic elds can cause disturbances in other equipment, in installa-
tions, in medical devices, for example pacemakers or hearing aids and in air-
crafts. Electromagnetic elds can also affect humans and animals.
Precautions:
▶Although the product meets the strict regulations and standards which
are in force in this respect, Leica Geosystems cannot completely exclude
the possibility that other equipment can be disturbed or that humans or
animals can be affected.
▶Do not operate the product with radio or digital cellular phone devices in
the vicinity of lling stations or chemical installations, or in other areas
where an explosion hazard exists.
▶Do not operate the product with radio or digital cellular phone devices
near to medical equipment.
▶Do not operate the product with radio or digital cellular phone devices in
aircrafts.
▶Do not operate the product with radio or digital cellular phone devices for
long periods with the product immediately next to your body.
☞This warning also applies when using products with Bluetooth.
1.7 FCC Statement, Applicable in U.S.
☞The greyed paragraph below is only applicable for products without
radio.
WARNING
This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to part 15 of the FCC rules.
These limits are designed to provide reasonable protection against harmful
interference in a residential installation.
This equipment generates, uses and can radiate radio frequency energy and,
if not installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no guaran-
tee that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on,
the user is encouraged to try to correct the interference by one or more of
the following measures:
•Reorient or relocate the receiving antenna.
•Increase the separation between the equipment and the receiver.
•Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
•Consult the dealer or an experienced radio/TV technician for help.
Radios, digital cellular
phones or products
with Bluetooth
12 Safety Directions

CAUTION
Changes or modications not expressly approved by Leica Geosystems for
compliance could void the user's authority to operate the equipment.
Model: iCG30 Art.No.: 878651
Equip. No.: 8729268 S.No.: XXXXXX
Power: 7.4 V --- nominal / 0.5 A max.
Leica Geosystems AG
CH-9435 Heerbrugg
Manufactured: 2019
Made in Switzerland
FCC ID: RFD-SAGG04P
R202-SMF096
IP66
IP68
IC: 3177A-SAGG04P
19106_001
005044_002
005044
_002
Made in China
Type: GEB212
2ICR19/66
Art. No.: 772806
7.4V /2.6Ah
10A 19Wh XXXXXXXX-XXXXXX
A/S:[phone]
Leica Geosystems AG, CH-9435 Heerbrugg
Li-Ion Battery
5A/130 C
S. No.:10412 전지
Manufactured by Huizhou Longji Electronics Co., Ltd.
1.8 ISED Statements (EN/FR), Applicable in Canada
WARNING
This Class (B) digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe (B) est conforme à la norme NMB-003
du Canada.
Canada Compliance Statement
This device contains licence-exempt transmitter(s)/receiver(s) that comply
with Innovation, Science and Economic Development Canada’s licence-
exempt RSS(s). Operation is subject to the following two conditions:
1.This device may not cause interference.
2.This device must accept any interference, including interference that
may cause undesired operation of the device.
Canada Déclaration de Conformité
L’émetteur/récepteur exempt de licence contenu dans le présent appareil
est conforme aux CNR d’Innovation, Sciences et Développement économique
Canada applicables aux appareils radio exempts de licence. L’exploitation est
autorisée aux deux conditions suivantes:
1.L’appareil ne doit pas produire de brouillage;
2.L’appareil doit accepter tout brouillage radioélectrique subi, même si
le brouillage est susceptible d’en compromettre le fonctionnement.
CAUTION
Changes or modications not expressly approved by Leica Geosystems for
compliance could void the user's authority to operate the equipment.
Labelling iCON gps 30
Labelling internal
battery GEB212
Safety Directions 13

2 Description of the System
2.1 Overview
19115_001 ba
a Antenna iCON
iCG30
bCC70/CC80 Field
Controller
2.2 System Components
The iCON gps 30 represents the so called instrument.
Component Description
Integrated antenna Receiving signals from a GNSS (Global Navigation
Satellite System).
Bluetooth To wireless pair with iCON eld controller
Battery The battery compartment holds the GEB212 battery
for power supply.
LEDs Indication of power, Bluetooth and signal reception.
LEMO-1 connector Serial by RS232 or USB communication.
5/8" Whitworth
thread
Mounting the instrument for observation.
19116_001
a
b
d
e
f
c
g
a Lemo connector
b5/8" Whitworth thread,
for instrument mount-
ing
c Tracking LED
d Bluetooth LED
e Power LED
f ON/OFF key
g Battery compartment
Do not open the instrument or remove any connector as this action impairs
the protection against water, dust and sand. Open the instrument for battery
handling without exception in dry and clean conditions only.
Description
The iCON gps 30 instrument has Light Emitting Diode indicators. They indicate
the basic instrument status.
General
Main components
Interface
☞
LED indicators
14 Description of the System

Diagram
19117_001
ab c
a Tracking LED (TRK)
b Bluetooth LED (BT)
c Power LED (PWR)
Description of the LEDs
IF the is THEN
TRK LED off No satellites are tracked.
green ash-
ing
Fewer than four satellites are tracked, a pos-
ition is not yet available.
green Enough satellites are tracked to compute a
position.
red iCON gps 30 instrument is initialising.
BT LED green Bluetooth is in data mode and ready for
connecting.
blue Bluetooth has connected.
blue ashing Data is being transferred.
iCON gps 30
PWR LED
off Power is off.
green Power is 100% - 20%.
red Power is 20% - 5%.
red ashing Power is low (<5%). The remaining time for
which enough power is available depends on
the type of measurement, the temperature
and the age of the battery.
2.3 Power Concept
Use the batteries, chargers and accessories recommended by Leica Geosys-
tems to ensure the correct functionality of the instrument.
Power for the instrument can be supplied internally only.
Internal power supply: One battery (GEB212) ts into the instrument.
•On: The instrument turns on as soon as the power supply is connected
and the power key is pressed.
•Off: To turn off the instrument push either the power key or disconnect
the power supply.
If an instrument connected to a low powered external battery continues to
operate, total discharge of the battery can occur.
General
Power options
On/Off behaviour
Total discharge
Description of the System 15

2.4 Container Contents
19120_001
b
f
e
d
c
a
a Antenna iCON gps 30
bUSB ash drive
c Manual and USB documentation card
d CC70/CC80 Field Controller
e Extra battery for CC70/CC80 Field Controller*
f GEB212 battery
* Optional accessory
2.5 Accessories
Extra equipment such as cables and universal pole holders are listed in the
setup sections. Any further description of accessories is not part of this
manual.
Refer to the Leica iCON gps 30 Equipment List.
Container for iCON
gps 30 instrument
and accessories
Description
16 Description of the System

3 Operation
3.1 Guidelines for Correct Results with GNSS Surveys
Successful GNSS measurements require undisturbed satellite signal reception.
For kinematic use, be sure to select measurement positions with best satellite
reception possible. Use the instrument in location which is free of obstruc-
tions such as trees, buildings or mountains for best measurement results.
Centre the instrument precisely over the target positions.
3.2 Batteries
3.2.1 Operating Principles
•The battery must be charged before using it for the rst time because it is
delivered with an energy content as low as possible.
•The permissible temperature range for charging is from 0 °C to
+40 °C/+32 °F to +104 °F. For optimal charging, we recommend charging
the batteries at a low ambient temperature of +10 °C to +20 °C/+50 °F to
+68 °F if possible.
•It is normal for the battery to become warm during charging. Using the
chargers recommended by Leica Geosystems, it is not possible to charge
the battery once the temperature is too high.
•For new batteries or batteries that have been stored for a long time
(> three months), it is effectual to make only one charge/discharge cycle.
•For Li-Ion batteries, a single discharging and charging cycle is sufcient.
We recommend carrying out the process when the battery capacity indic-
ated on the charger or on a Leica Geosystems product deviates signic-
antly from the actual battery capacity available.
•The batteries can be operated from −20 °C to +55 °C/−4 °F to +131 °F.
•Low operating temperatures reduce the capacity that can be drawn; high
operating temperatures reduce the service life of the battery.
3.2.2 Changing the Battery
19121_001
2
3
4a 4b
6a
6c
8
6b
Undisturbed satellite
signal reception
Centred instrument
First-time use/
charging batteries
Operation/
discharging
Insert and remove the
battery on the iCON
gps 30 step-by-step
Operation 17

1. Turn iCON gps 30 over to gain access to the battery compartment.
2. Open the battery compartment by pushing the slide fastener in the
direction of the arrow with the open-lock symbol.
3. Pull out the battery housing. The battery is attached to the housing.
4. Hold the battery housing and pull the battery from the battery
housing.
5. A polarity of the battery is displayed inside the battery housing. This
is a visual aid to assist in placing the battery correctly.
6. Place the battery onto the battery housing, ensuring that the con-
tacts are facing outward. Click the battery into position.
7. Place the battery housing with the inserted battery back into the
battery compartment of the instrument.
8. Close the battery compartment by pushing the slide fastener in the
direction of the arrow with the close-lock symbol.
3.3 Equipment Setup as a Real-Time Rover
The equipment setup is used for real-time rover with extended periods of use
in the eld.
Connections are made to the GNSS iCG30 antenna and eld controller. The
eld controller is xed to the pole with the GHT63. Connection between the
iCON gps 30 instrument and the eld controller is made through Bluetooth.
•The antenna is mounted directly using screw tting.
•Carbon bre poles are used. They can be replaced with their aluminium
equivalent without any change to these instructions.
19609_001
a
b
h
e
c
d
g
f
a iCON gps 30 instrument
bPole
c Pole clamp
d Holder for Field Controller
e Battery GEB212
f CC70/CC80 Field Controller
g Battery for Field Controller
h USB data storage device
Cellular modem available on the CC70/CC80 Field controller.
Setting up the Equipment
1. Insert the battery into the iCON gps 30 Smart Antenna.
Use
Description
☞
Real-time rover setup
with iCON gps 30
☞
Real-time rover setup
step-by-step
18 Operation

2. Screw iCON gps 30 Smart Antenna onto the top of the telescopic
pole.
3. Ensure that the compression lock is not clamped.
4. Extend the telescopic pole and ensure that the snap-lock clicks into
its position. The snap-lock ensures that there is no slipping of the
telescopic pole.
5. Clamp the compression lock. The compression lock maintains
straightness.
6. Fix the holder to the clamp with the tightening screw. Before tight-
ening, ensure that the holder is at a comfortable working height and
angle. It can be achieved by sliding the clamp along the pole and
rotating the holder about the clamp. Tighten the tightening screw.
7. Insert the battery into the eld controller.
8. Clip the eld controller onto the holder and lock into position.
9. Turn on the antenna and the controller.
10. Run the data collection or stakeout application of the iCON eld
software
☞Refer to the Leica iCON Field software manual for further informa-
tion.
3.4 Holder and Clamp for Field Controller
010936_002
d
f
a
g
h
e
b
c
Clamp
a Tightening screw
bPole clamp
c Clamping bolt
Holder
d Mounting arm
e Locking lever
f Mounting brackets (side)
g Mounting brackets (bottom)
h Holder for stylus
Holder for iCON CC70/
CC80
Operation 19

4 Care and Transport
4.1 Transport
Never carry the product loose in a road vehicle, as it can be affected by shock
and vibration. Always carry the product in its container and secure it.
For products for which no container is available use the original packaging or
its equivalent.
When transporting the equipment in the eld, always make sure that you
•either carry the product in its original container,
•or carry the tripod with its legs splayed across your shoulder, keeping the
attached product upright.
When transporting the product by rail, air or sea, always use the complete ori-
ginal Leica Geosystems packaging, container and cardboard box, or its equival-
ent, to protect against shock and vibration.
When transporting or shipping batteries, the person responsible for the
product must ensure that the applicable national and international rules and
regulations are observed. Before transportation or shipping, contact your local
passenger or freight transport company.
4.2 Storage
Respect the temperature limits when storing the equipment, particularly in
summer if the equipment is inside a vehicle. Refer to "5 Technical Data" for
information about temperature limits.
•Refer to "5 Technical Data" for information about storage temperature
range.
•Remove batteries from the product and the charger before storing.
•After storage recharge batteries before using.
•Protect batteries from damp and wetness. Wet or damp batteries must be
dried before storing or use.
•A storage temperature range of 0 °C to +30 °C / +32 °F to +86 °F in a dry
environment is recommended to minimize self-discharging of the battery.
•At the recommended storage temperature range, batteries containing a
40% to 50% charge can be stored for up to one year. After this storage
period the batteries must be recharged.
4.3 Cleaning and Drying
•Use only a clean, soft, lint-free cloth for cleaning. If necessary, moisten
the cloth with water or pure alcohol. Do not use other liquids; these may
attack the polymer components.
Dry the product, the container, the foam inserts and the accessories at a tem-
perature not greater than 40 °C/104 °F and clean them. Remove the battery
Transport in a road
vehicle
Transport in the eld
Shipping
Shipping, transport of
batteries
Product
Li-Ion batteries
Product and
accessories
Damp products
20 Care and Transport
