Leica Geosystems DD Series User manual

Leica Detection DD Series
Locators & Accessories
User Manual
Version 1.0
English

Introduction
Congratulations on the purchase of a Leica Detection product.
This manual contains important safety directions as well as instructions for set-
ting up the product and operating it. Refer to "1 Safety Directions" for further
information.
Read carefully through the User Manual before you switch on the product.
The model and serial number of your product are indicated on the type plate.
Always refer to this information when you need to contact your agency or
Leica Geosystems authorised service centre.
•
Bluetooth
®is a registered trademark of Bluetooth SIG, Inc.
All other trademarks are the property of their respective owners.
This manual applies to the Leica Detection DD series locators, DA series trans-
mitters and Detection accessories. Differences between the models are marked
and described.
Name Description/Format
Leica DD220/
DD230 Series
Locators &
Accessories
Quick Guide
Provides an overview of the product together with
technical data and safety directions. Intended as a
quick reference field guide.
ü ü
Leica DD220/
DD230 Series
Locators &
Accessories
User Manual
All instructions required in order to operate the
product to a basic level are contained in the User
Manual. Provides an overview of the product
together with technical data and safety directions.
ü
Refer to the following resources for all Leica DD220/DD230
documentation/software:
•the Leica USB documentation card
•https://myworld.leica-geosystems.com
myWorld@Leica Geosystems (https://myworld.leica-geosystems.com) offers
a wide range of services, information and training material.
With direct access to myWorld, you are able to access all relevant services
whenever it is convenient for you.
Service Description
myProducts Add all products that you and your company own
and explore your world of Leica Geosystems: View
detailed information on your products and update
your products with the latest software and keep up-
to-date with the latest documentation.
Purchase
Product identification
Trademarks
Validity of this
manual
Available
documentation
2

Service Description
myService View the current service status and full service his-
tory of your products in Leica Geosystems service
centres. Access detailed information on the services
performed and download your latest calibration cer-
tificates and service reports.
mySupport Create new support requests for your products that
will be answered by your local Leica Geosystems
Support Team. View the complete history of your
support requests and view detailed information on
each request in case you want to refer to previous
support requests.
myTraining Enhance your product knowledge with Leica Geosys-
tems Campus - Information, Knowledge, Training.
Study the latest online training material on your
products and register for seminars or courses in your
country.
myTrustedServices Add your subscriptions and manage users for Leica
Geosystems Trusted Services, the secure software
services, that assist you to optimise your workflow
and increase your efficiency.
3

Table of Contents
1 Safety Directions 6
1.1 General 6
1.2 Definition of Use 6
1.3 Limits of Use 7
1.4 Responsibilities 7
1.5 Hazards of Use 8
1.5.1 General 8
1.5.2 Using the Product with a Signal Transmitter 12
1.6 Electromagnetic Compatibility EMC 13
1.7 FCC Statement, Applicable in U.S. 14
2 Description of the System 17
2.1 System Information 17
2.2 System Components 17
2.3 Locator Components 18
2.4 Signal Transmitter Components 18
2.5 Li-Ion Battery Pack 18
3 Operation of the Locator 20
3.1 Keyboard 20
3.2 Turning On / Turning Off 20
3.3 Display Screens 20
3.3.1 The Customisation Screens 20
3.3.2 The Locate Screen 22
3.3.3 The Depth Estimation Screens 23
3.4 Locator Menu 26
3.4.1 Access and Navigation 26
3.4.2 Menu Options 27
3.5 Search Modes 30
4 Operation of the Transmitter 34
4.1 Keyboard 34
4.2 Turning On / Turning Off 34
5 Applications 35
5.1 How to Pinpoint a Utility 35
5.2 How to Trace a Utility 36
5.3 How to Conduct a Sweep Search 36
5.4 Using the Transmitter in Induction Mode 38
5.4.1 General Information 38
5.4.2 Induction Mode: Nulling-Out Method 39
5.4.3 Induction Mode: Parallel-Sweep Method 40
5.4.4 Induction Mode: Radial-Sweep Method 41
5.5 Using the Transmitter in Connection Mode 42
5.5.1 General Information 42
5.5.2 Direct Connection Mode 43
5.5.3 Connection Mode: 131 kHZ Cable-Wrap Technique 44
5.6 How to Use the Trace Rod 46
5.6.1 General Information 46
5.6.2 Locating a Utility Using the Trace Rod 47
5.7 How to Use the Transmitter Clamps 50
5.7.1 General Information 50
5.7.2 Using a Transmitter Clamp to connect to Cable Utilities 50
5.8 How to Use the Property Plug Connector 51
5.8.1 General Information 51
4 Table of Contents

5.8.2 Locating a Utility Using the Property Plug Connector 51
5.9 How to Use the Sondes 52
5.9.1 General Information 52
6 Estimating Depth and Current of a Utility 55
6.1 Utility Line Depth 55
6.2 Sonde Depth 56
6.3 Depth Code Information 56
6.4 Utility Current Measurement 57
7 Connectivity 58
7.1 Locator Bluetooth Connectivity 58
7.2 Locator USB Connectivity 60
7.3 Transmitter USB Connectivity 60
8 Locator Memory and GPS 62
8.1 Internal Memory 62
8.2 Internal GPS 62
8.3 Point of Interest 62
9 Batteries 64
9.1 Operating Principles 64
9.2 Charging the Li-Ion Battery Pack 64
10 Functional Checks 67
10.1 Locator Health Check 67
10.2 Calibration Verification 68
10.3 Locator Fault Codes 70
10.4 Functional Check of the Transmitter 70
10.5 Functional Check of the Trace Rod 71
10.6 Functional Check of the Sonde 72
11 Care and Transport 74
11.1 Transport 74
11.2 Storage 74
11.3 Cleaning and Drying 74
12 Technical Data 75
12.1 Conformity to National Regulations 75
12.2 Transmitter Technical Data 75
12.3 Locator Technical Data 76
12.4 Conductive Rod Technical Data 79
12.5 Property Plug Connector Technical Data 79
Appendix A Time Zone Offsets 81
Table of Contents 5

1 Safety Directions
1.1 General
The following directions enable the person responsible for the product, and the
person who actually uses the equipment, to anticipate and avoid operational
hazards.
The person responsible for the product must ensure that all users understand
these directions and adhere to them.
Warning messages are an essential part of the safety concept of the instru-
ment. They appear wherever hazards or hazardous situations can occur.
Warning messages...
•make the user alert about direct and indirect hazards concerning the use
of the product.
•contain general rules of behaviour.
For the users‘ safety, all safety instructions and safety messages shall be
strictly observed and followed! Therefore, the manual must always be available
to all persons performing any tasks described here.
DANGER, WARNING, CAUTION and NOTICE are standardised signal words for
identifying levels of hazards and risks related to personal injury and property
damage. For your safety, it is important to read and fully understand the fol-
lowing table with the different signal words and their definitions! Supplemen-
tary safety information symbols may be placed within a warning message as
well as supplementary text.
Type Description
DANGER Indicates an imminently hazardous situation
which, if not avoided, will result in death or
serious injury.
WARNING Indicates a potentially hazardous situation or
an unintended use which, if not avoided,
could result in death or serious injury.
CAUTION Indicates a potentially hazardous situation or
an unintended use which, if not avoided,
may result in minor or moderate injury.
NOTICE
Indicates a potentially hazardous situation or
an unintended use which, if not avoided,
may result in appreciable material, financial
and environmental damage.
☞Important paragraphs which must be adhered
to in practice as they enable the product to
be used in a technically correct and efficient
manner.
1.2 Definition of Use
The products are intended to be used for the following applications:
General
•Detection and localisation of underground utilities: metallic cables and
pipes.
Description
About warning
messages
Intended use
6 Safety Directions

Locator
•Detection and localisation of utilities with the use of approved accessories
or a signal transmitter.
•Estimation of the depth of an underground utility, or accessory.
Locator with Bluetooth:
•Data communication with external appliances.
Locator with Internal Memory:
•Recording and storage of product usage.
Locator with GPS:
•Localisation, recording and storage of product usage.
•Use of the product without instruction.
•Use outside of the intended use and limits.
•Disabling safety systems.
•Removal of hazard notices.
•Opening the product using tools, for example screwdriver, unless this is
permitted for certain functions.
•Modification or conversion of the product.
•Use after misappropriation.
•Use of products with recognisable damages or defects.
•Use with accessories from other manufacturers without the prior explicit
approval of Leica Geosystems.
•Inadequate safeguards at the working site.
1.3 Limits of Use
Suitable for use in an atmosphere appropriate for permanent human habita-
tion: not suitable for use in aggressive or explosive environments.
WARNING
Working in hazardous areas, or close to electrical installations or simi-
lar situations.
Life Risk.
Precautions:
▶Local safety authorities and safety experts must be contacted by the per-
son responsible for the product before working in such conditions.
1.4 Responsibilities
Leica Geosystems AG, CH-9435 Heerbrugg, hereinafter referred to as Leica
Geosystems, is responsible for supplying the product, including the user man-
ual and original accessories, in a safe condition.
Reasonably
foreseeable misuse
Environment
Manufacturer of the
product
Safety Directions 7

The person responsible for the product has the following duties:
•To understand the safety instructions on the product and the instructions
in the user manual.
•To ensure that it is used in accordance with the instructions.
•To be familiar with local regulations relating to safety and accident preven-
tion.
•To inform Leica Geosystems immediately if the product and the application
becomes unsafe.
•To ensure that the national laws, regulations and conditions for the opera-
tion of the product are respected.
1.5 Hazards of Use
1.5.1 General
CAUTION
Dropping, misusing, modifying, storing the product for long periods or
transporting the product
Watch out for erroneous measurement results.
Precautions:
▶Periodically carry out test measurements and perform the field adjust-
ments indicated in the User Manual, particularly after the product has been
subjected to abnormal use as well as before and after important measure-
ments.
DANGER
Because of the risk of electrocution, it is dangerous to use the product in the
vicinity of electrical installations such as power cables or electrical railways.
Precautions:
▶Keep at a safe distance from electrical installations. If it is essential to
work in this environment, first contact the safety authorities responsible
for the electrical installations and follow their instructions.
WARNING
Working on or near live electrical utilities may cause you to receive an electric
shock.
Precautions:
▶Do not exceed equipment’s recommended ratings and instructions of use.
▶Inspect equipment’s cables and accessories for damage, do not use if
faulty.
▶Do not work on electrically live power utilities unless you are properly
qualified.
▶Use personal protective equipment rated for the utilities voltage and cur-
rent.
▶Familiarise yourself with National and Work regulations governing safety
and accident prevention.
Person responsible
for the product
8 Safety Directions

WARNING
Distraction/loss of attention
During dynamic applications, for example stakeout procedures, there is a dan-
ger of accidents occurring if the user does not pay attention to the environ-
mental conditions around, for example obstacles, excavations or traffic.
Precautions:
▶The person responsible for the product must make all users fully aware of
the existing dangers.
WARNING
The absence of a positive indication does not guarantee the non-existence of a
utility.
Utilities without a detectable signal may be present.
The locators can only locate non-metallic utilities such as plastic pipes, typically
used by the water and gas utilities, with the use of appropriate accessories.
Precautions:
▶Always excavate with care.
WARNING
Depth reading on locator might differ from actual depth of utility
When taking a depth reading, the depth is calculated as distance to the centre
of a utility or to a sonde within the utility. Depending on the diameter of a util-
ity, the depth reading might differ from the actual depth of the utility. This
specifically applies when the signal for depth estimation is produced by a
sonde lying in a large-diameter pipe or duct.
Precautions:
▶Always take into account allowances for the diameter of a utility.
WARNING
Inadequate securing of the working site.
This can lead to dangerous situations, for example in traffic, on building sites
and at industrial installations.
Precautions:
▶Always ensure that the working site is adequately secured.
▶Adhere to the regulations governing safety, accident prevention and road
traffic.
Safety Directions 9

CAUTION
Inappropriate mechanical influences to batteries
During the transport, shipping or disposal of batteries it is possible for inappro-
priate mechanical influences to constitute a fire hazard.
Precautions:
▶Before shipping the product or disposing of it, discharge the batteries by
running the product until they are flat.
▶When transporting or shipping batteries, the person in charge of the prod-
uct must ensure that the applicable national and international rules and
regulations are observed.
▶Before transportation or shipping contact your local passenger or freight
transport company.
WARNING
A hazardous signal can be present at the transmitter output when used in con-
nection mode and on the attached accessories and live utility itself.
Precautions:
▶Take care when handling exposed or non-insulated connections. Notify
others who may be working on or around the utility.
WARNING
Exposure of batteries to high mechanical stress, high ambient tempera-
tures or immersion into fluids
This can cause leakage, fire or explosion of the batteries.
Precautions:
▶Protect the batteries from mechanical influences and high ambient temper-
atures. Do not drop or immerse batteries into fluids.
WARNING
Short circuit of battery terminals
If battery terminals are short circuited e.g. by coming in contact with jewellery,
keys, metallised paper or other metals, the battery can overheat and cause
injury or fire, for example by storing or transporting in pockets.
Precautions:
▶Make sure that the battery terminals do not come into contact with metal-
lic objects.
10 Safety Directions

WARNING
Unauthorised opening of the product
Either of the following actions may cause you to receive an electric shock:
•Touching live components
•Using the product after incorrect attempts were made to carry out repairs
Precautions:
▶Do not open the product!
▶Only Leica Geosystems authorised service centres are entitled to repair
these products.
WARNING
Improper disposal
If the product is improperly disposed of, the following can happen:
•If polymer parts are burnt, poisonous gases are produced which may
impair health.
•If batteries are damaged or are heated strongly, they can explode and
cause poisoning, burning, corrosion or environmental contamination.
•By disposing of the product irresponsibly you may enable unauthorised
persons to use it in contravention of the regulations, exposing themselves
and third parties to the risk of severe injury and rendering the environment
liable to contamination.
Precautions:
▶The product must not be disposed with household waste.
Dispose of the product appropriately in accordance with
the national regulations in force in your country.
Always prevent access to the product by unauthorised
personnel.
Product-specific treatment and waste management information can be
received from your Leica Geosystems distributor.
WARNING
Improperly repaired equipment
Risk of injuries to users and equipment destruction due to lack of repair knowl-
edge.
Precautions:
▶Only Leica Geosystems authorised service centres are entitled to repair
these products.
Safety Directions 11

1.5.2 Using the Product with a Signal Transmitter
DANGER
Clipping a transmitter clamp around a live utility
When a transmitter clamp is clipped around a live utility, a hazardous signal
might be present on the utility or at the transmitter plug connector, causing
you to receive an electric shock.
Precautions:
▶Do not clip a transmitter clamp around live utilities that have impaired or
no insulation.
▶Always ensure that the transmitter plug connector is connected to the
transmitter before you clip the transmitter clamp around a live utility.
DANGER
Connecting the cable set of the transmitter to a live utility
Connecting the cable set of the transmitter directly to a live utility can cause
you to receive an electric shock.
Precautions:
▶Never connect the cable set of the transmitter directly to a live electrical
utility.
DANGER
Power output of signal transmitter
The signal transmitter can output potentially lethal voltages!
Precautions:
▶Take care when using the maximum power output of the signal transmitter.
▶Take care when handling exposed or non-insulated connections, including
the transmitter’s cable set, the earth pin and the connection to the utility.
▶Notify others who may be working on or around the utility.
WARNING
Removing the battery pack of the signal transmitter
Removing the battery pack of the signal transmitter might cause you to receive
an electric shock.
Precautions:
▶Switch the signal transmitter off and remove any cable set or accessories
from the connection socket before removing the battery pack.
WARNING
Battery pack of the signal transmitter may get hot after prolonged use.
Risk of burning injuries.
Precautions:
▶Avoid touching the hot battery pack.
▶Allow the battery pack to cool down before removing it.
12 Safety Directions

1.6 Electromagnetic Compatibility EMC
The term Electromagnetic Compatibility is taken to mean the capability of the
product to function smoothly in an environment where electromagnetic radia-
tion and electrostatic discharges are present, and without causing electromag-
netic disturbances to other equipment.
WARNING
Electromagnetic radiation
Electromagnetic radiation can cause disturbances in other equipment.
Precautions:
▶Although the product meets the strict regulations and standards which are
in force in this respect, Leica Geosystems cannot completely exclude the
possibility that other equipment may be disturbed.
CAUTION
Use of the product with accessories from other manufacturers. For
example field computers, personal computers or other electronic equip-
ment, non-standard cables or external batteries
This may cause disturbances in other equipment.
Precautions:
▶Use only the equipment and accessories recommended by Leica Geosys-
tems.
▶When combined with the product, they meet the strict requirements stipu-
lated by the guidelines and standards.
▶When using computers, two-way radios or other electronic equipment, pay
attention to the information about electromagnetic compatibility provided
by the manufacturer.
CAUTION
Intense electromagnetic radiation. For example, near radio transmit-
ters, transponders, two-way radios or diesel generators
Although the product meets the strict regulations and standards which are in
force in this respect, Leica Geosystems cannot completely exclude the possibil-
ity that function of the product may be disturbed in such an electromagnetic
environment.
Precautions:
▶Check the plausibility of results obtained under these conditions.
Description
Safety Directions 13

CAUTION
Electromagnetic radiation due to improper connection of cables
If the product is operated with connecting cables attached at only one of their
two ends, for example external supply cables, interface cables, the permitted
level of electromagnetic radiation may be exceeded and the correct functioning
of other products may be impaired.
Precautions:
▶While the product is in use, connecting cables, for example product to
external battery, product to computer, must be connected at both ends.
WARNING
Use of product with radio or digital cellular phone devices
Electromagnetic fields can cause disturbances in other equipment, in installa-
tions, in medical devices, for example pacemakers or hearing aids and in air-
craft. It can also affect humans and animals.
Precautions:
▶Although the product meets the strict regulations and standards which are
in force in this respect, Leica Geosystems cannot completely exclude the
possibility that other equipment can be disturbed or that humans or ani-
mals can be affected.
▶Do not operate the product with radio or digital cellular phone devices in
the vicinity of filling stations or chemical installations, or in other areas
where an explosion hazard exists.
▶Do not operate the product with radio or digital cellular phone devices
near to medical equipment.
▶Do not operate the product with radio or digital cellular phone devices in
aircraft.
▶Do not operate the product with radio or digital cellular phone devices for
long periods with the product immediately next to your body.
1.7 FCC Statement, Applicable in U.S.
☞The greyed paragraph below is only applicable for products without
radio.
14 Safety Directions

WARNING
This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to part 15 of the FCC rules.
These limits are designed to provide reasonable protection against harmful
interference in a residential installation.
This equipment generates, uses and can radiate radio frequency energy and,
if not installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no guaran-
tee that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on,
the user is encouraged to try to correct the interference by one or more of
the following measures:
•Reorient or relocate the receiving antenna.
•Increase the separation between the equipment and the receiver.
•Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
•Consult the dealer or an experienced radio/TV technician for help.
CAUTION
Changes or modifications not expressly approved by Leica Geosystems for
compliance could void the user's authority to operate the equipment.
13297_001
Labelling
DD220/DD230
Safety Directions 15

13298_001
Labelling DA series
transmitters
16 Safety Directions

2 Description of the System
2.1 System Information
Locators are used to detect buried conductive utilities that emit an electromag-
netic signal. Such a signal is generated as an electrical current passes through
the utility.
Signal transmitters are used to apply a distinct signal to utilities with the fol-
lowing intention:
•To improve the detection success.
•To trace the route of a utility.
•To make a depth or current measurement.
Accessories are used with the locator and transmitter to localise the position
of utilities, including some that are non-metallic.
The locators and transmitters described within this manual greatly facilitate the
search process and help to reduce the dangers and costs associated with utility
strikes. However, electromagnetic location depends on the utilities being con-
ductive (metallic) and emitting a signal as current passes through them.
☞Keep in mind that a locator on its own cannot detect all utilities. Take
care when excavating. We recommend that you adopt a safe system
which includes the planning of the search process in advance, the use
of utility maps, the use of locators and transmitters, and the use of
safe digging practices.
2.2 System Components
The delivered components depend on the package ordered.
ab
cdefg
13299_001
a Locator
bTransmitter
c Transmitter Cable Set Extension
d Property Plug Connector
e Transmitter Clamps
f Sondes
g Trace Rod (non-metallic utility tracer)
General description
☞
Available system
components
Description of the System 17

2.3 Locator Components
a
b
d
e
f
c
13300_001
a Display
bLocator keyboard
c USB port
d Trigger
e Battery compartment
f Locator foot (wear part)
2.4 Signal Transmitter Components
013301_001
b
c
a
d
e
f
a Accessory compartment
bConnection socket
c Battery compartment and USB
port
d Signal transmitter keyboard
e Speaker
f Induction arrow
2.5 Li-Ion Battery Pack
The Li-Ion battery pack is delivered with an energy content as low as possible
and needs to be woke up prior to use.
To wake up the Li-Ion battery pack, do the following:
1. Connect the charger plug into the charge
jack on the battery pack.
14479_001
Description of
components DD220/
DD230 locators
Description of
transmitter
components
Li-Ion battery pack
18 Description of the System

2. Plug the connector into a suitable power
source.
14480_001
12/24 V
100-240 V
☞The battery pack should be fully charged before use.
☞Result:
The small LED next to the charge jack flashes at a fast rate to indi-
cate the wake up process, then flashes at a slower rate to indicate
that the battery pack is active and charging.
☞Applicable to the DD220/DD230 locators and DA Signal Transmitters.
Description of the System 19

3 Operation of the Locator
3.1 Keyboard
13302_001
Function key
Press and release to change the search mode.
Depth Estimation key
Press and release to take a depth reading.
Menu key
Press and hold to display the Locator main menu or to return back to
the locate screen.
Press and release to select a menu option.
Left navigation key
Press and release to select the previous menu option.
Right navigation key
Press and release to select the next menu option.
3.2 Turning On / Turning Off
Press and hold the trigger to turn on and operate the locator.
Release the trigger to turn off the locator.
13303_001
3.3 Display Screens
3.3.1 The Customisation Screens
The customisation screens are displayed only for the first time the locator is
put into operation. The screens allow you to set the locator to your regional
preferences.
DD220/DD230 locator
keyboard
Turning on and off
the DD220/DD230
Set the regional
preferences
20 Operation of the Locator
