Leica V-LUX 20 User manual

LEICA V-LUX 20
Instructions

2 3
Quick start guide Table of Contents
The battery is not charged
when the camera is
shipped. Charge the
battery and set the Clock
before use.
When you do not use the
card (optional), you can
record or play back pictures
on the built-in memory (→14).
Charge the battery
Insert the battery and
the card
Turn on the power
Set REC/PLAY switch
to
Set the mode dial to
Press the shutter button and take pictures
Press halfway
(press lightly to focus)
Press fully
(press the button all the
way to record)
■To play back the pictures
Previous Next
1.Set REC/PLAY switch
to .
2.Select the picture you
want to view.
Before use
Before use.............................................. 6
Read first.......................................................6
To prevent damage, malfunctions,
and faults.......................................................7
About GPS ....................................................8
Scope of delivery/Accessories............. 8
Names of parts....................................... 9
Cursor button ................................................9
Preparations
Charging the battery ........................... 10
Guidelines for number of recordable
pictures and recording time......................... 11
Inserting and removing the card
(optional)/the battery........................... 13
Picture save destination
(cards and built-in memory) ........................14
Remaining battery and memory capacity....14
Setting the Clock ................................. 15
To change time setting ................................17
Setting the menu ................................. 18
Menu type ...................................................19
Using the [SETUP] menu ............... 20
[CLOCK SET]/ [BEEP]/ [VOLUME]/
[CUST.SET MEM.] .................................20
[LCD MODE]/ [DISPLAY SIZE]/
[GUIDE LINE]/ [HISTOGRAM] ..........21
[REC AREA]/ [ECONOMY]..........22
[AUTO REVIEW]/ [ZOOM RESUME]/
[NO.RESET] ..........................................23
[RESET]/ [USB MODE]/
[VIDEO OUT]/ [TV ASPECT].............24
[HDMI MODE]/ [HDTV Link]..............25
[VERSION DISP.]/ [FORMAT]/
[LANGUAGE].........................................26
[O.I.S. DEMO].......................................27
Basics
Basic shooting operation ................... 28
Taking still pictures ......................................28
Recording motion pictures ..........................28
Holding the camera.....................................29
Mode dial.....................................................29
Taking pictures with automatic
settings................................................. 30
About Happy colors.....................................32
Face Detection and Face Recognition........32
AF Tracking .................................................32
Taking pictures with your own
settings................................................. 33
Align focus for desired composition ............34
Orientation detection function .....................34
Taking pictures with zoom.................. 35
[i.ZOOM]......................................................37
[DIGITAL ZOOM] ...................................38
Viewing your pictures
[NORMAL PLAY] .................................. 39
Deleting pictures ................................. 40
To delete multiple (up to 50) or
all pictures ...................................................41

4 5
Table of Contents (Continued)
Application (Record)
Changing recording information
display .................................................. 42
Taking pictures with flash................... 43
Taking close-up pictures .................... 45
‘Tele macro’ function.............................45
[MACRO ZOOM].....................................46
Positioning camera and subject
within the accessible range for
focusing................................................ 47
Taking pictures with self-timer........... 48
Taking pictures with Exposure
Compensation...................................... 49
Taking picture series with
automatically changing exposure
([AUTO BRACKET]) ............................. 50
Taking pictures with automatically
changing aspect ratios
[MULTI ASPECT].................................. 51
Using a pre-set aperture to determine
the depth of field
[APERTURE-PRIORITY] Mode............ 52
Using a pre-set shutter speed to
determine the rendition of moving
subjects
[SHUTTER-PRIORITY] Mode............... 53
Using a pre-set aperture/shutter speed
combination to achieve full control of
the exposure
[MANUAL EXPOSURE] Mode ............. 54
Register your own settings and record
[CUSTOM] Mode .................................. 55
[CUST.SET MEM.] ..............................55
[CUSTOM] ..................................................56
Taking pictures according to the scene
[SCENE MODE].................................... 57
[PORTRAIT]/ [SOFT SKIN]/
[TRANSFORM]/
[SELF PORTRAIT].................................58
[SCENERY]/ [PANORAMA ASSIST]/
[SPORTS] ..............................................59
[NIGHT PORTRAIT]/
[NIGHT SCENERY]/ [FOOD]/
[PARTY] .................................................60
[CANDLE LIGHT]/ [BABY]/ [PET]/
[SUNSET] ..............................................61
[HIGH SENS.]/
[HI-SPEED BURST]...............................62
[FLASH BURST]/ [STARRY SKY] .....63
[FIREWORKS]/ [BEACH]/ [SNOW]/
[AERIAL PHOTO]/ [PIN HOLE] .........64
[FILM GRAIN]/ [HIGH DYNAMIC] .....65
[PHOTO FRAME] ..................................66
Registering commonly used scenes
[MY SCN MODE] .................................. 67
Taking motion pictures ....................... 68
Recordable time on 2 GB SD memory
card ............................................................70
Recording with the Face Recognition
function
[FACE RECOG.] ................................... 72
Registering face pictures ............................73
Editing or deleting information about
registered persons .....................................75
Automatically register face pictures ...........76
Setting recognition sensitivity......................77
Recording the place of recording with
GPS....................................................... 78
[GPS SETTING] ..........................................79
Change the recorded place name
information ..................................................81
Changing the display of location name
information ..................................................82
Using GPS to set the Clock ........................83
Useful features for travel
[TRAVEL MODE] .................................. 84
[TRAVEL DATE]....................................84
[LOCATION] ................................................85
[WORLD TIME] ....................................86
Using the [REC] menu......................... 88
[PICTURE SIZE]...................................88
[QUALITY]/ [ASPECT RATIO]/
[INTELLIGENT ISO] .............................89
[SENSITIVITY]......................................90
[WHITE BALANCE] ..............................91
[FACE RECOG.]/ [AF MODE] .........92
[PRE AF]/ [METERING MODE].......94
[I.EXPOSURE]/
[MIN. SHTR SPEED] ............................95
[BURST]/ [I.RESOLUTION].............96
[DIGITAL ZOOM]/
[COLOR EFFECT]/ [PICT.ADJ.]......97
[STABILIZER]/ [AUDIO REC.].........98
[AF ASSIST LAMP]/
[RED-EYE REMOVAL]/
[CLOCK SET] .......................................99
Using the [MOTION PICTURE]
menu................................................... 100
[REC QUALITY]/
[CONTINUOUS AF]/
[WIND CUT]........................................100
Taking/viewing clipboard pictures
[CLIPBOARD] Mode .......................... 101
Taking clipboard pictures...........................101
Viewing clipboard pictures .......................102
Zoom Mark ................................................103
[CLIPBOARD] menu .................................103
Using Quick menu............................. 104
Entering Text...................................... 105
Application (View)
Viewing as list (Multi Playback/
Calendar Playback) ........................... 106
Watching motion pictures/
still pictures with audio..................... 107
Different playback methods
[PLAYBACK MODE]........................... 108
[SLIDE SHOW] ...................................109
[GPS AREA PLAY].............................. 111
[TRAVEL PLAY] .................................. 112
[CATEGORY PLAY] ............................ 114
[FAVORITE PLAY] .............................. 115
Using the [PLAYBACK] menu .......... 116
[CALENDAR]/ [TITLE EDIT].......... 116
[PLACE-NAME EDIT] ......................... 117
[TEXT STAMP] ................................... 118
[RESIZE].............................................120
[CROPPING]/ [LEVELING] ...........121
[ASPECT CONV.]/
[ROTATE DISP.]..................................122
[FAVORITE] ........................................123
[PRINT SET] ....................................... 124
[PROTECT].........................................125
[FACE REC EDIT]...............................126
[COPY]................................................127
Connecting with other devices
Keep the recorded still pictures and
motion pictures ................................. 128
Dubbing playback pictures via
AV cab 130................................................128
Using with your PC............................ 129
Copying still pictures and
motion pictures .........................................129
Printing............................................... 132
Printing multiple pictures...........................133
Print with date and text..............................134
Making print settings on camera ...............135
Viewing on TV screen ....................... 136
Viewing on a TV with HDMI Socket ..........137
HDTV Link (HDMI) ....................................138
Others
List of LCD monitor displays............ 140
In recording ...............................................140
In playback................................................141
Message displays.............................. 142
Q&A Troubleshooting ...................... 144
Usage cautions and notes................ 151
User License Agreement for Location
Name data.................................................153
Recording picture/time capacity...... 162
Leica Academy .................................. 164
Leica on the Internet ......................... 164
Leica information service ................. 165
Leica Customer Service.................... 165

6 7
Before use
■Do a test shot first!
Check first to see if you can take pictures
and record sounds (motion pictures/still
pictures with audio) successfully.
■We will not compensate for failed/
lost recording or for direct/indirect
damage.
Leica will not provide compensation even
if damage is caused by faults with camera
or card.
■Carefully observe copyright laws.
• Recording of pre-recorded tapes or
discs or other published or broadcast
material for purposes other than your
own private use may infringe copyright
laws. Even for the purpose of private
use, recording of certain material may
be restricted.
■Avoid shocks, vibration, and pressure.
• Avoid exposing the camera to strong
vibration or shock; e.g. dropping or
hitting the camera, or sitting down with
the camera in your pocket. (Attach
hand strap to avoid dropping camera.
Hanging any items other than the
supplied hand strap from the camera
can apply pressure against it.)
• Do not press the lens or the LCD
monitor.
■Do not get the camera wet or insert
foreign objects.
This camera is not waterproof.
• Do not expose the camera to water,
rain, or seawater.
(If camera gets wet, wipe with a soft,
dry cloth. Wring cloth thoroughly first if
wet with seawater, etc.)
• Avoid exposing the lens and the
sockets to dust or sand, and do not
allow liquids to leak into gaps around
buttons.
■Avoid condensation caused by sudden
changes in temperature and humidity.
• When moving between places of
different temperature or humidity, place
camera into a plastic bag and allow to
adjust to conditions before use.
• If the lens clouds up, turn off the
camera and leave for about two hours
to allow camera to adjust to conditions.
• If the LCD monitor clouds up, wipe with
a soft, dry cloth.
Read first To prevent damage, malfunctions, and faults
■Lens
• If lens is dirty:
Images may appear slightly white if lens
is dirty (fingerprints, etc.).
Turn the power on, hold the extracted
lens barrel with your fingers, and gently
wipe the lens surface with a soft, dry
cloth.
• Do not leave the lens exposed to direct
sunlight.
Camera ON/OFF switch
Do not touch the lens
cover, as this may
damage lens. Be careful
when removing camera
from bag, etc.
■When using a tripod or monopod
• Do not apply excessive force or use
screws with a damaged thread. (This
may damage the camera, the tripod
thread, or the label.)
• Ensure that the tripod is stable. (Refer
to the tripod instructions.)
■When transporting
Turn off the camera.
Please also refer to ‘Usage cautions and
notes’ (→151).
■Certain pictures cannot be played
back.
• Pictures edited on a computer
• Pictures taken or edited on a different
camera
(Pictures taken or edited on this camera
may also not be able to be played back
on other cameras)
■Software on the DVD supplied
The following actions are prohibited:
• Making duplicates (copying) for sale
or rent
• Copying onto networks
LCD monitor characteristics
Extremely high precision technology is employed to produce the LCD monitor screen.
However there may be some dark or bright spots (red, blue or green) on the screen.
This is not a malfunction.
The LCD monitor screen has more than 99.99% effective pixels with
a mere 0.01% of the pixels inactive or always lit. The spots will not be
recorded on pictures on the built-in memory or a card.
Grip area
Unit temperature
The surface of the camera (especially the grip area, etc.), the battery
and memory card may become warm during use.
This does not cause a problem with the performance or quality of the
camera.

8 9
Names of parts
Before use (Continued)
Accessories
Scope of delivery
Cursor button
[MENU/SET]
(menu display/set/finish) (→18)
Left cursor button (◄)
• Self-timer (→48)
Down cursor button (▼)
• Macro Mode (→45)
• AF Lock (AF Tracking) (→32, 92)
Tripod thread
Card/Battery door (→13)
Release lever (→13)
Hand strap eyelet
We recommend
using the supplied
hand strap to
avoid dropping
the camera.
Camera ON/OFF switch
(→15)
Shutter button (→30)
Mode dial (→29)
Flash (→43)
Self-timer indicator (→48)/
AF Assist Lamp (→99)
Lens barrel
Lens (→7)
Zoom lever
(→35)
Microphone (→68, 98)
GPS antenna (→78)
Speaker (→20, 107)
LCD monitor
(→6, 21, 42, 140, 146)
REC/PLAY switch
(→28)
[EXPOSURE] button
(→52, 53, 54)
Status indicator (→78)
[DISPLAY] button (→42)
Q.MENU (Quick setting →104)/
Delete button (→40)
Motion picture button (→68)
Up cursor button (▲)
• Exposure Compensation (→49)
• Auto bracket (→50)
• Multi Aspect (→51)
• White Balance fine adjustment
(→91)
Right cursor button (►)
• Flash (→43)
●In this manual, the button that is used is shaded or indicated by▲▼◄►.
HDMI socket
(→137, 138)
[AV OUT/
DIGITAL]
socket
(→129, 132, 136)
■About the camera’s location name
information
Before using the camera, read “User
License Agreement for Location Name
data”. (→153)
■The GPS function can be used even
when the camera’s power is off.
When [GPS SETTING] is [ON], the GPS
function works to check your current
position periodically even if the camera’s
power is OFF.
• When turning off the camera’s power in
an airplane, hospital or other restricted
area, set [GPS SETTING] to or
[OFF]. (→79)
• When [GPS SETTING] is [ON], power
will drain from the battery even if the
camera’s power is OFF.
■Recording location information
• Recording location names and
landmarks (such as building names)
are current as of February 2010. These
will not be updated.
• Depending on the country or area,
limited location name and landmark
information may be available.
■Positioning
Because the positions of the GPS
satellites are constantly changing,
depending on the recording location
and conditions, it may not be possible
to position such satellites accurately, or
positioning discrepancy may occur.
■When using in another country
• GPS may not work in China or in the
border regions of countries neighboring
China. (Current as of February 2010)
• Some countries or regions may
regulate the use of GPS or related
technology. Because this camera
has a GPS function, before taking
it into another country, check with
the embassy or your travel agency
whether there are any restrictions on
bringing cameras with a GPS function.
About GPS Order No.
Rechargeable battery
BP-DC7-U 18 702
BP-DC7-E 18 701
Battery charger
BC-DC7-U 423-082.001-010
BC-DC7-E 423-082.001-012
Mains cable
EU/AS 423-068.801-019
UK 423-068.801-020
J 423-068.801-022
AUS 423-068.801-023
TW 424-025.002-000
(delivery differs
depending on markets)
Wrist strap 423-082.001-014
CD with instr. PDF 423-082.001-016
DVD with software 423-082.001-018
USB cable 423-082.001-020
AV cable 423-082.001-022
Battery case 423-082.001-024
Button template for
Canada / Taiwan
423-082.805-003
(For cameras sold
in the U.S., Canada,
Taiwan and Japan)
Short instructions 93 289 -295
(delivery differs
depending on markets)
Warranty Card 439-399.100-026
Notes:
• Cards are optional. You can record or play
back pictures on the built-in memory when you
are not using a card.
• Check that all items belonging to the scope of
delivery are included before using the camera.
• The items and their shape may differ
depending on the country or area where the
camera was purchased.
• The battery pack is called either battery pack
or battery in the text.
• The battery charger is called either battery
charger or charger in the text.
• Please dispose of all packaging appropriately.
Order No.
Leather case 18 700
HDMI mini cable-E 14 491
Mini tripod 14 320
Tabletop tripod 14 110
Ball and Socket head 14 100

10 11
Charging the battery
Always charge before first use! (not sold pre-charged)
■About batteries that you can use with this unit
It has been found that counterfeit battery packs which look very similar to the
genuine products are made available to purchase in some markets. Some of
these battery packs are not adequately protected with internal protection to
meet the requirements of appropriate safety standards. There is a possibility
that these battery packs may lead to fire or explosion. Please be advised that
we are not liable for any accident or failure occurring as a result of use of a
counterfeit battery pack. To ensure that safe products are used we recommend
that a genuine Leica battery pack is used.
•Use the dedicated charger and battery.
•The camera has a function for distinguishing batteries which can be used
safely. The dedicated battery supports this function. The only batteries suitable
for use with this camera are genuine LEICA BP-DC7 batteries (→8). (Batteries
which do not support this function cannot be used). Leica cannot in any way
guarantee the quality, performance or safety of batteries which have been
manufactured by other companies and are not genuine Leica products.
Insert the battery terminals and attach the battery
to the charger
Ensure [LEICA] faces outwards.
1
2
Connect the charger to the
electrical outlet
●Plug-in type ●Inlet type
Battery
(model-specific)
Charger
(model-specific)
• The AC
cable does
not fit
entirely into
the AC input
terminal. A gap will remain.
Charging light
([CHARGE])
On: Charging in progress
(approx. 130 min. if fully
depleted)
Off: Charging complete
If light is flashing:
• Charging may take longer
than normal if battery
temperature is too high or
too low (charging may not be
completed).
• Battery/charger connector is
dirty. Clean with a dry cloth.
Detach the battery after charging is
completed
Guidelines for number of recordable pictures and recording time
Figures may be reduced if flash, zoom, or [LCD MODE] are used frequently; or in colder
climates.
The number of recordable pictures and the recording time will also be reduced if the GPS
function is operating.
■Recording still pictures
Number of recordable pictures Approx. 300 pictures By CIPA standard
Recording time Approx. 150 min
●Recording conditions by CIPA standard
• CIPA is an abbreviation of [Camera & Imaging
Products Association].
• [PROGRAM AE] Mode
• [GPS SETTING] is set to [OFF]
• Temperature: 23 °C (73.4 °F)/Humidity: 50%
when LCD monitor is on.∗
• Using a 32 MB SD Memory Card.
• Using the supplied battery.
• Starting recording 30 seconds after the
camera is turned on. (When the Optical
Image Stabilizer function is set to [AUTO].)
• Recording once every 30 seconds with full
flash every second recording.
• Rotating the zoom lever from Tele to Wide or
vice versa in every recording.
• Turning the camera off every 10 recordings
and leaving it until the temperature of the
battery decreases.
∗The number of recordable pictures decreases
when [LCD MODE] is used.
Number reduced if intervals are longer – e.g. to approx. one quarter for 2-minute
intervals under the above conditions.
■Viewing pictures
Playback time About 300 minutes
The number of recordable pictures or available recording time may vary slightly according
to battery and usage conditions.

12 13
Charging the battery (Continued) Inserting and removing the card (optional)/
the battery
●The time required for charging varies depending on conditions of battery usage.
Charging takes longer at high or low temperatures and when the battery has not been
used for some time.
●Battery will be warm during charging and for some time thereafter.
●Battery will run out if not used for long periods of time, even after being charged.
●Charge the battery with the charger indoors (10 °C - 35 °C (50 °F - 95 °F)).
●Do not leave any metal items (such as clips) near the contact areas of the power plug.
Otherwise, a fire and/or electric shocks may be caused by short-circuiting or the
resulting heat generated.
●Frequently charging up the battery is not recommended. (Frequently charging up the
battery reduces its maximum usage time and can cause it to expand.)
●Do not disassemble or modify the charger.
●If available battery power is significantly reduced, battery is reaching end of lifespan.
Please purchase a new battery.
●The battery charger is in the standby condition when the AC power is supplied.
The primary circuit is always “live” as long as the battery charger is connected to an
electrical outlet.
●When charging:
• Remove any dirt on connectors of charger and battery with dry cloth.
• Keep at least 1 m (3 feet 4 inches) away from AM radio (may cause radio
interference).
• Noises may be emitted from inside of charger, but this is not a fault.
• After charging, remove the charger from the wall socket, and then remove the battery
from the charger (up to 0.1 W consumed if left in place).
●Do not use a damaged or dented battery (especially with damaged terminals) as this
can cause faults.
Set the camera ON/OFF switch to OFF
Slide to the [OPEN] position
and open the lid
[OPEN] [LOCK]
Release lever
Completely insert battery
and card
• Battery: Push in until the lever is locked
• Memory card: Push in until it clicks
Close lid
Slide to the [LOCK] position.
■To remove
•To remove battery: •To remove card:
move lever in
direction of arrow.
Lever press down in
center.
●Always use genuine Leica batteries.
●If you use other batteries, we cannot guarantee the quality of this product.
●Remove battery from camera after use.
• Store the battery in the supplied case (→8).
●Memory cards can be damaged if they are not inserted all the
way until they click into place.
●To remove the card or battery, turn the camera off and wait until
the Leica logo on the LCD monitor goes off. (Failure to wait may
cause the camera to malfunction and may damage the card or
recorded data.)
●Keep the Memory Card out of reach of children to prevent swallowing.
Charged battery (check orientation)
Card (check orientation: terminals face
LCD)
Do not
touch
terminal
Lever

14 15
Inserting and removing the card (optional)/
the battery (Continued) Setting the Clock (The Clock is not set when the
camera is shipped.)
Remaining battery and memory capacity
Pictures remaining (→162)
Displayed when no card is inserted (pictures will be saved to built-in
memory)
Remaining battery capacity
(flashes red)
If the battery mark flashes red, recharge or replace battery. (→10)
When in operation
(Card) or (Built-in memory) are illuminated red.
While the light remains lit, an operation is taking place, such as picture writing, reading,
deletion or formatting. While the light is lit, do not turn off the power or remove battery
or card (this can cause data loss or damage). Do not subject the camera to vibrations,
impact, or static electricity. Should any of these cause camera operation to be terminated,
attempt to perform the operation again.
Picture save destination (cards and built-in memory)
Pictures will be saved to a card if one is inserted, or to the built-in memory if not.
■Built-in memory (approx. 15 MB)
●Pictures may be copied between cards and the built-in memory (→127).
●The access time for the built-in memory may be longer than the access time for a card.
●Clipboard pictures (→101) are saved to built-in memory.
●[QVGA] in [REC QUALITY] can only be available to record motion pictures in the built-
in memory.
■Compatible memory cards (optional)
The following SD standard-based cards
Type of Card Capacity Notes
SD memory
cards
8 MB – 2 GB • Can be used with devices compatible with the respective
formats.
• Before using SDXC memory cards, check your computer
and other devices support this type of card.
• Cards in capacities not listed at left are not supported.
SDHC memory
cards
4 GB - 32 GB
SDXC memory
cards
48 GB - 64 GB
●Please reformat the card with this camera if it has already been formatted with a
computer or another device. (→26)
●If the write-protect switch is set to ‘LOCK’, the card cannot be used to
record or delete pictures, and it cannot be formatted.
●It is recommended that you copy important pictures to your computer (as
electromagnetic waves, static electricity, or faults may cause data to be
damaged).
Turn on the power
The power is turned on.
Press [MENU/SET] while the
message is displayed
Press ▲▼ to select the language,
and press [MENU/SET]
• The [PLEASE SET THE CLOCK] message
appears. (This message does not appear in
Playback Mode.)
Press [MENU/SET]
Press ◄► to select the items
(year, month, day, hour, minute,
display order or time display
format), and press ▲▼ to set
Select the
setting
item
Select either [24HRS] or [AM/
PM] for the time display format.
Select the display order for the
day, month, and year ([M/D/Y],
[D/M/Y], or [Y/M/D]).
Change
the values
and
settings
• To cancel →Press .
• When set to [AM/PM], 0:00 midnight is AM 12:00,
and 0:00 noon is PM 12:00.
Press [MENU/SET]
Press [MENU/SET]
• To return to the previous screen, press .
Set REC/PLAY switch to before turning on the power.
REC/PLAY switch
Switch
(LOCK)
(Continued on the next page)

16 17
Setting the Clock (Continued)
If automatically correcting time of day, select [YES]
• To manually set date and time →select [NO].
• To return to the previous screen, press .
When [PLEASE SET THE HOME AREA] is displayed, press
[MENU/SET]
Set your home area
City or area
name Current time
Difference from GMT (Greenwich Mean Time)
The current time and home area are set.
• [GPS SETTING] turns [ON]. (→79)
■About automatic time correction
(→83)
●Failure to set the date and time will cause the date/time to be improperly printed when
printing pictures at a digital photo center or when using [TEXT STAMP].
●Year can be set between 2000 and 2099.
●After the time has been set, the date can be printed correctly even if the date is not
displayed on the camera screen.
To change time setting
When resetting date and time, select [CLOCK SET] from the [SETUP] menu.
• Clock settings will be saved for approx. 3 months even after battery is removed,
provided a fully-charged battery was installed in the camera for 24 hours beforehand.
• Using the GPS function, you can make settings to automatically correct the current
time. (→83)
Select [CLOCK SET] from the [REC] menu or [SETUP] menu
(→20)
Set the date and time (Perform steps and on the previous page.)
Press [MENU/SET]
■To set local time at travel destination
[WORLD TIME] (→86)

18 19
Settings display may vary according to items.
Menu items displayed vary according to mode dial setting.
Setting the menu
Menu type
■To restore default settings
[RESET] (→24)
Bring up the menu
Each item’s
background
color changes
when it is
selected
Select the [SETUP] menu
Highlight Select and return
to menu items
Background
color
changes
Select the item
Page
(Zoom lever can
be used to switch
to next screen.)
Item
Select the setting
Settings
Selected
setting
Close the menu
• When the REC/PLAY switch is set
to , menu can be closed with a
half-press of the shutter button.
Refer to the following procedures to operate menus such as the [SETUP] menu, [REC]
menu, [TRAVEL MODE] menu and [PLAYBACK] menu.
(Example) While in [PROGRAM AE] Mode (→33), change [LCD MODE] on the [SETUP]
menu. (REC/PLAY switch: set to ; mode dial: set to )
Shutter
button
REC/PLAY switch
Camera ON/OFF switch
Mode dial
[REC] menu (REC/PLAY switch: )
[MOTION PICTURE] menu (REC/PLAY switch: )
Changing picture preferences (→88 - 100)
• Displays such as white balance, sensitivity, aspect ratio, and resolution.
[TRAVEL MODE] menu (REC/PLAY switch: )
Categorize your travel pictures (→84 - 87)
• You can set the GPS settings, Travel Date settings and more.
[SETUP] menu (REC/PLAY switch: )
Making the camera more convenient to use (→20 - 27)
• Displays settings for ease of use such as adjusting the Clock and changing the
Beep sounds.
[PLAYBACK MODE] menu (REC/PLAY switch: )
Viewing recorded pictures (→108 - 115)
• Choose a playback type to see Slide Shows or just your favorite pictures.
• When [FAVORITE] (→123) is not set, [FAVORITE PLAY] is not displayed.
[PLAYBACK] menu (REC/PLAY switch: )
Using your pictures (→116 - 127)
• Displays settings for using the pictures you have taken, including protecting,
cropping, and handy settings for printing your pictures (DPOF).
