Leica M 10 User manual

LEICA M 10
Instructions

EN
114
FOREWORD
Dear Customer,
Leica would like to thank you for purchasing the Leica M10 and to
congratulate you on your choice. With this unique digital 35mm
system camera, you have made an excellent choice.
We wish you a great deal of pleasure and success using your new
camera. In order to make best use of all the opportunities, we
recommend that you first read these instructions.
Your Leica Camera AG
Meaning of the different categories of information
in these instructions
Note:
Additional information
Important:
Failure to observe the instructions may result in damage to the
camera, the accessories or the pictures.
Attention:
Failure to observe the instructions may cause personal injury
FOR US ONLY:
This is a Class B product based on the standard of the Voluntary Control Council
for Interference from Information Technology Equipment (VCCI). If this is used
near a radio or television receiver in a domestic environment, it may cause radio
interference. Install and use the equipment according to the instruction manual.
FCC Note:
This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential instal-
lation. This equipment generates, uses, and can radiate radio frequency energy
and, if not installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no guarantee
that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be deter-
mined by turning the equipment off and on, the user is encouraged to try to
correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which
the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
Foreword

EN
115
FCC Caution:
To assure continued compliance, follow the attached installation instructions and
use only shielded interface cables with ferrite core when connecting to computer
or peripheral devices. Any changes or modifications not expressly approved by
the party responsible for compliance could void the user’s authority to operate
this equipment.
Declaration of Conformity
Trade Name: LEICA
Model No.: 3656
Responsible party/
Support contact: Leica Camera Inc.
1 Pearl Count, Unit A
Allendale, New Jersey 07401
Tel.: [phone]
Fax: [phone]
[email protected]
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) This device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that
may cause undesired operation.
3656
Tested to Comply
With FCC Standards
FOR HOME OR OFFICE USE
Contains FCC ID: N5A3656
This transmitter must not be co-located or operated in conjunction with any other
antenna or transmitter. This equipment complies with FCC radiation exposure lim-
its set forth for an uncontrolled environment and meets the FCC radio frequency
(RF) Exposure Guidelines. This equipment is tested for specific absorption ratio
(SAR) and complies with FCC/IC radiation exposure limits set forth for an uncon-
trolled environment. This device complies with FCC/IC SAR limit of 1.6 W/kg. For
body worn operation, this equipment has been tested and meets the FCC/ IC RF
exposure guidelines when used with the Leica Camera AG accessories
supplied or designated for this product that have no metallic component in the
assembly. Use of other accessories may not ensure compliance with FCC/IC RF
exposure guidelines.
For Canada only:
CAN ICES-3 (B)/NMB-3(B)
This device complies with RSS-210 of the IC Rules. Operation is subject to the
following two conditions:
(1) This device may not cause harmful interference,
(2) This device must accept any interference received,
including interference that may cause undesired operation of the device.
This equipment complies with IC radiation exposure limits set forth for an
uncontrolled environment and meets RSS-102 of the IC radio frequency
(RF) Exposure rules. This equipment is tested for specific absorption ratio
(SAR) and complies with FCC/IC radiation exposure limits set forth for an
uncontrolled environment. This device complies with FCC/IC SAR limit
of 1.6 W/kg. For body worn operation, this equipment has been tested
and meets the FCC/IC RF exposure guidelines when used with the Leica
Camera AG accessories supplied or designated for this product that have
no metallic component in the assembly. Use of other accessories may not
ensure compliance with FCC/IC RF exposure guidelines.

EN
116
Package contents/Accessories/Spare parts
SCOPE OF DELIVERY
Before using your camera for the first time, please check that the
accessories supplied are complete.
a. Carrying strap
a. Camera bayonet cover
a. Lithium ion battery Leica BP-SCL5
a. Leica BC-SCL5 charger, incl. mains cable (EU, US) and car
charging cable
a. Cover for accessory shoe
Attention:
Store small parts (such as the cover for the accessory shoe) as
follows:
– out of reach of children (swallowing can result in suffocation!)
– in a place where they will not be lost, e.g. in the places in the
camera packaging designed for this purpose
Subject to changes in design and production.
ACCESSORY
For an up-to-date list and description of the lenses and accessories
available for your camera, please consult the Leica Camera AG
website at:
www.leica-camera.com
Important:
Use only the accessories specified and described in these instruc-
tions and/or by Leica Camera AG with the Leica M10.
SPARE PARTS Order No.
Camera bayonet cover ........................................................ 16060
Camera carrying strap ........................................................ 24023
Lithium ion battery BP-SCL5................................................24003
Battery charger BC-SCL5 (incl. mains cable for US
[423-116.001-020] and EU [423-116.001-005],
others depending on local market), car charging cable......... 24002
Cover for accessory shoe, Plastic (black)............420-300.001-035

EN
117
Notes
• Leica is constantly working on developing and optimizing your
camera. As digital cameras have many functions that are purely
controlled electronically, some of these improvements and en-
hancements to the functions can be installed on your camera at
a later date. To do this, Leica releases what are known as firm-
ware updates. Cameras are always supplied from the factory
with the latest firmware. But you can download it from our web-
site and transfer it to your camera: If you register as an owner
on the Leica Camera website, you will be informed by newsletter
when a firmware update is available.
Further information on registration and on firmware updates for
your camera and on any changes or additions to the details in
this manual can be found on our website under "Customer Ser-
vice" at: https://owners.leica-camera.com
• The information in these instructions refers to an earlier firm-
ware version. Instructions and explanations of changes due to
different firmware versions can also be found in the “Customer
area”.
• You can find out which firmware version your camera is fitted
with (also see p. 199) as follows:
Select menu item Camera information, and
• You will find the relevant number in the sub-menu on the
right-hand side of the Camera Firmware line.
• You can find specific country-related approvals for this camera
model as follows:
In the same Camera Information sub-menu (see previous note),
select Information on regulations.
• The relevant approval symbols can be found on several pages
of the relevant sub-menu.
• The production date of your camera can be found on the
stickers in the warranty card and/or on the packaging. The date
is written as follows: Year/Month/Day
• Before using your camera for the first time, please check that
the accessories supplied are complete.

EN
118
INHALT
FOREWORD ........................................................................................ 114
SCOPE OF DELIVERY ......................................................................... 116
ACCESSORY ....................................................................................... 116
SPARE PARTS ..................................................................................... 116
WARNING MESSAGES........................................................................ 122
LEGAL INFORMATION........................................................................ 122
Disposal of electrical and electronic equipment .............................123
PART DESIGNATIONS......................................................................... 124
QUICK START GUIDE ..............................................................126
PREPARATIONS.................................................................................. 126
TAKING PHOTOGRAPHS .................................................................... 126
VIEWING PICTURES ........................................................................... 127
DELETING PICTURES ......................................................................... 127
DETAILED INSTRUCTIONS .....................................................128
PREPARATIONS.................................................................................. 128
ATTACHING THE CARRYING STRAP ..................................................128
CHARGING THE BATTERY .................................................................128
CHANGING THE BATTERY/MEMORY CARD ......................................132
LEICA M LENSES .............................................................................135
Attaching the lens .........................................................................137
Detaching the lens ........................................................................137
THE MOST IMPORTANT SETTINGS/ CONTROLS .............................. 138
TURNING THE CAMERA ON AND OFF...............................................138
SHUTTER RELEASE BUTTON.............................................................139
Serial exposures............................................................................140
SHUTTER SPEED SETTING DIAL .......................................................141
MENU CONTROL..............................................................................142
PRESETS............................................................................................. 146
CAMERA DEFAULT SETTINGS ...........................................................146
Menu language..............................................................................146
Date and time ...............................................................................146
Auto power off ..............................................................................148
Monitor/viewfinder settings ..........................................................148
Table of Contents

EN
119
EXPOSURE BASIC SETTINGS.............................................................150
LENS TYPE DETECTION....................................................................150
Manual lens type/focal length entry ..............................................150
FILE FORMAT ...................................................................................152
JPG SETTINGS..................................................................................152
Resolution.....................................................................................152
Contrast, focus, color saturation....................................................153
Black & white photography ............................................................153
WHITE BALANCE..............................................................................154
ISO SENSITIVITY ..............................................................................156
BRIGHT-LINE VIEW AND RANGE FINDER ..........................................158
IMAGE FIELD SELECTOR ..................................................................159
MONITOR.........................................................................................160
Setting the brightness ...................................................................160
INFO screen..................................................................................160
LIVE VIEW MODE .............................................................................160
Exposure simulation ......................................................................161
Additional display options..............................................................161
RANGE MEASUREMENT ...................................................................164
With the optical range finder..........................................................164
With the monitor image in Live View mode.....................................165
Marking of clearly focused subjects ..............................................166
EXPOSURE METERING AND CONTROL.............................................167
Exposure metering displays ...........................................................167
Exposure Metering Methods..........................................................168
Selecting the Live View metering methods.....................................168
Exposure modes............................................................................169
Aperture priority............................................................................169
Exposure compensation ................................................................170
Automatic bracketing ....................................................................172
Manual exposure setting ...............................................................174
The B setting/The T function .........................................................174
Values above and below the metering range ..................................175
Table of Contents

EN
120
Table of Contents
REVIEW MODE ................................................................................... 176
Viewing other pictures/Scrolling in the memory ............................177
Enlarging/Selecting the trimming/
Simultaneously viewing several reduced pictures ...........................178
Create recordings .........................................................................180
Deleting Images ............................................................................180
ADDITIONAL FUNCTIONS.................................................................. 182
FLASH MODE ..................................................................................182
TAKING PHOTOGRAPHS WITH THE SELF-TIMER................................188
INTERVAL PICTURE SERIES ..............................................................188
MARKING THE PICTURE FILES FOR COPYRIGHT PROTECTION..........189
RECORDING THE LOCATION WITH GPS ............................................190
USER/APPLICATION-SPECIFIC PROFILES.........................................192
RESETTING ALL CUSTOM SETTINGS ................................................193
FORMATTING THE MEMORY CARD...................................................193
FOLDER MANAGEMENT ...................................................................194
WIRELESS DATA TRANSMISSION AND REMOTE CONTROL
OF THE CAMERA..............................................................................196
TRANSFERRING DATA TO A COMPUTER ...........................................198
WORKING WITH DNG RAW DATA ......................................................198
INSTALLING FIRMWARE UPDATES....................................................199
PRECAUTIONS AND CARE INSTRUCTIONS ..........................200
GENERAL PRECAUTIONS ................................................................... 200
MONITOR.........................................................................................201
SENSOR ..........................................................................................201
CONDENSATION ..............................................................................201
CARE INSTRUCTIONS ........................................................................ 202
FOR THE CAMERA............................................................................202
FOR LENSES....................................................................................202
FOR THE BATTERY............................................................................203
FOR THE CHARGER..........................................................................204
FOR MEMORY CARDS......................................................................204
CLEANING THE SENSOR/DUST DETECTION ....................................206
STORAGE ............................................................................................ 208

EN
121
Table of Contents
TROUBLESHOOTING...............................................................208
APPENDIX................................................................................210
VIEWFINDER DISPLAYS ..................................................................... 210
MONITOR DISPLAYS .......................................................................... 212
WHEN TAKING A PICTURE ................................................................212
IN PLAYBACK MODE ........................................................................214
FOR MENU CONTROL ......................................................................215
MENU OPTIONS...............................................................................216
INDEX.......................................................................................218
TECHNICAL DATA....................................................................220

EN
122
Warnings / Legal notices
WARNING MESSAGES
• Modern electronic components react sensitively to electrostatic
discharge. As people can easily pick up charges of tens of thou-
sands of volts, by walking on synthetic carpets for example, a
discharge can occur when you touch your camera, particularly if
it is placed on a conductive surface. If only the camera housing
is affected, this discharge is harmless to the electronics. Howev-
er, despite built-in safety circuits, outer contacts such as those
in the accessory shoe should not be touched if at all possible for
safety reasons. We therefore recommend that you always use
the relevant cover if you are not using a viewfinder or flash unit.
• For any cleaning of the contacts, do not use an optical micro-fi-
ber cloth (synthetic); use a cotton or linen cloth instead! Before
touching the contacts, you can make sure you discharge any
electrostatic charge by deliberately touching a heating or water
pipe (conductive, grounded material). You can also avoid soiling
and oxidization of the contacts by storing your camera in a dry
place with the lens or bayonet cover fitted.
• Use only the recommended accessories to prevent faults, short
circuits or electric shock.
• Do not attempt to remove parts of the body (covers); qualified
repairs can be carried out only at authorized service centers.
LEGAL INFORMATION
• Please ensure that you observe copyright laws. The recording
and publication of pre-recorded media such as tapes, CDs, or
other published or broadcast material may contravene copyright
laws.
• This also applies to all of the software supplied.
• The SD logo is a registered trademark.
• Other names, company and product names referred to in these
instructions are trademarks or registered trademarks of the
respective companies.

EN
123
Disposal of electrical and electronic equipment
(Applies within the EU, and other European countries
with segregated waste collection systems)
This device contains electrical and/or electronic components and
must therefore not be disposed of in general household waste!
Instead, it should be disposed of at a recycling collection point
provided by the local authority. This costs you nothing. If the device
contains standard or rechargeable batteries, these must be re-
moved first and also be disposed of in line with relevant regula-
tions.
Further information on the subject is available from your local
administration, your local waste collection company, or in the store
where you purchased this device.
Declaration of Conformity (DoC)
Hereby, “Leica Camera AG” declares that this product is in compliance with the
essential requirements and other relevant provisions of Directive 2014/53/EU.
Customers can download a copy of the original DoC to our R&TTE products from
our DoC server:
www.cert.leica-camera.com
In case of further questions, please contact:
Leica Camera AG, Am Leitz-Park 5, 35578 Wetzlar, Germany
This product is intended for general consumer. (Category 3)
This product on purpose to connect to access point of 2.4 GHz WLAN.
The CE identification of our products documents compliance
with the fundamental requirements of the applicable EU
directives.

Part Designations
EN
124
PART DESIGNATIONS
Illustrations in the front and rear cover pages
Front view
1Lens release button
2Eyelets for the carrying strap
3Focus button
4Range finder viewing window
5Brightness sensor1
6Viewfinder viewing window
7Self-timer LED
8Image field selector
9Bottom cover locking point
1 Leica M lenses with viewfinder attachment cover the brightness sensor.
Information about functions with these and other lenses can be found under
"Displays/In the viewfinder”, and "Leica M lenses".
Top view
10 ISO dial with detent positions for
–A- Automatic shutter ISO sensitivity
–100 - 6400 ISO settings
–M ISO - for higher sensitivities
11 Index for ISO setting
12 Fixed ring
a. Index for distance setting
b. Depth of field scale
c. Red index button for changing lenses
13 Aperture setting ring
14 White index point for aperture setting
15 Lens hood
16 Focusing dial
a. Recessed grip
17 Main switch with detent positions for camera switched on (y)
and off
18 Shutter release button
a. Thread for cable release
19 Shutter speed dial with detent positions for
–A- Automatic shutter speed control
Shutter speeds 1 /4000 - 8s (inc. intermediate values)
–B- Long-time exposure
– - Flash sync speed (1⁄180s)
20 Accessory shoe

EN
Part Designations
125
Rear view
21 LED for indicating picture mode/recording data
22 MENU button
– To call up the FAVORITES menu or the SETUP menu if no
function is assigned to the former
– To leave the FAVORITES and SETUP menus, and the sub-
menus
23 PLAY button
– To switch the (permanent) view mode on and off
– To return to full-screen display
24 LV button for turning live view mode on and off
25 Wifi aerial (not visible)
26 Brightness sensor for monitor
27 Viewfinder eyepiece
28 Setting dial
– For navigating in the menus
– For setting the selected menu options/functions
– For setting an exposure compensation value
– For enlarging/reducing pictures viewed
– To scroll through saved images
29 Direction pad
– For navigating in the menus
– For setting the selected menu options/functions
– To scroll through saved images
– To approach the desired picture section when using
Gray card
30. Center button
– To call up the status display
– For applying menu settings
– For displaying settings/data when taking a picture
– For displaying picture data during picture review
31 Monitor
Bottom view
(bottom cover fitted)
32 Locking toggle for bottom cover
33 Tripod thread A ¼, DIN 4503 (¼“)
34 Bottom cover
(Bottom cover removed)
35 Memory card slot
36 Battery compartment
37 Battery locking slider

EN
126
Quick Start Guide
QUICK START GUIDE
You will need the following items:
– Camera
– Battery
– Memory card (not supplied)
– Charger and mains cable
PREPARATIONS
1. Charge the battery (see p. 128)
2. Insert the battery (see p. 132)
3. Insert the memory card (see p. 132)
4. Attach the lens (see p. 137)
5. Turn on the camera (see p. 138)
6. Set the menu language (see p. 146)
7. Set the date and time (see p. 146)
8. Format the memory card, if necessary (see p. 193)
TAKING PHOTOGRAPHS
9. Set the shutter speed setting dial to A(see p. 141)
10. Set the subject focus (see p. 158)
11. Turn on exposure metering (see p. 139)
12. Correct the exposure, if necessary (see p. 141)
13. Release the shutter (see p. 139)

EN
127
Quick Start Guide
VIEWING PICTURES
The camera is preset to display the last picture automatically for a
short time (see p. 176).
Switching on permanent view mode (possible at any time):
Press the PLAY button (see p. 176)
Viewing other pictures:
Press the left or right side of the direction pad.
Enlarging pictures:
Turn the setting wheel to the right.
DELETING PICTURES
(only possible within PLAY)
Press the MENU button to call up the delete menu.
Details of this process can be found on p. 180.

EN
128
Preparations
DETAILED INSTRUCTIONS
PREPARATIONS
ATTACHING THE CARRYING STRAP
CHARGING THE BATTERY
Charger
A
C
D
B
ASocket for power cable
BSocket for car charging
cable
CCHARGE LED
D80% LED
EF
EContacts
FLatches

EN
129
Preparations
Battery
The camera is powered by a lithium ion battery.
• The green LED marked
CHARGE starts flashing to confirm that charging is in progress.
As soon as the battery has charged to at least 4/5 of its capaci-
ty, the yellow LED marked 80% also lights up. When the battery
is fully charged, the green LED also changes from flashing to
continuously lit.
Note:
The 80% LED lights up after around 2 hours due to the charging
characteristics.
The charger should be disconnected from the mains when charging
is complete. There is therefore no risk of overcharging.

EN
130
Preparations
Attention:
• Only the battery type specified and described in this manual
(BP-SCL5; Order No. 24003), or battery types specified and
described by Leica Camera AG, may be used in this camera.
• These batteries may only be used in the units for which they are
designed and may only be charged exactly as described below.
• Using this battery contrary to the instructions and using
non-specified battery types can result in an explosion under
certain circumstances!
• The batteries must not be exposed to heat or sunlight for pro-
longed periods, or to humidity or moisture. Likewise, the batter-
ies must not be placed in a microwave oven or a high-pressure
container as this results in a risk of fire or explosion!
• A safety valve in the battery guarantees that any excess pres-
sure caused by improper handling is discharged safely. Only the
charger specified and described in this manual (BC-SCL5; Order
No. 24002) is to be used. The use of other chargers not ap-
proved by Leica Camera AG can cause damage to the batteries
and, in extreme cases, can cause serious or life-threatening
injuries.
• The charger supplied should be used exclusively for charging this
battery type. Do not attempt to use it for other purposes.
• The car charging cable supplied must never be connected while
the charger is connected to the mains.
• Ensure that the mains outlet used for charging is freely accessi-
ble.
• The battery and charger must not be opened. Repairs may only
be carried out by authorized service centers.
You will find the date of manufacture on the device itself.
The format is: week/year

EN
131
Preparations
Notes:
• The battery should be charged before the camera is used for the
first time.
• The battery must have a temperature of 10°-30°C to be charged
(otherwise the charger will not turn on, or will turn off again).
• Lithium ion batteries can be charged at any time, regardless of
their current charge level. If a battery is only partly discharged
when charging starts, it is charged to full capacity faster.
• The batteries warm up during the charging process. This is nor-
mal and not a malfunction.
• If the two LEDs on the charger flash rapidly (2Hz) after starting
charging, this indicates a charging error (e.g. maximum charging
time exceeded, voltages or temperatures outside the permitted
ranges, or short circuit). In this case, disconnect the charger
from the mains and remove the battery. Ensure that the above
temperature conditions are met and then restart the charging
process. If the problem persists, please contact your dealer, the
Leica office in your country or Leica Camera AG.
• A new battery only reaches its full capacity after it has been fully
charged and – by use in the camera - discharged again 2 or 3
times. This discharge procedure should be repeated every 25
cycles. To ensure a maximum service life of the battery, it should
not be exposed to constant extremes of temperature
(e.g. in a parked car in the summer or winter).
• Even when used under optimum conditions, every battery has a
limited service life! After several hundred charging cycles, this
becomes noticeable as the operating times get significantly
shorter.
• The battery should be replaced after a maximum of four years,
as its performance deteriorates and reliable operation can no
longer be guaranteed, particularly in cold conditions.
• Defective batteries should be disposed of according to the re-
spective instructions (see p. 123).
• The replaceable battery supplies another back-up battery that is
built into the camera, ensuring uninterrupted operation of the
internal clock and calendar for up to 2 months. If this back-up
battery becomes discharged it must be recharged by inserting
the replaceable main battery. Once the replaceable battery has
been inserted, the full capacity of the back-up battery is recov-
ered after about one or two days. This process does not require
the camera to be turned on.

EN
132
Preparations
CHANGING THE BATTERY/MEMORY CARD
Turn the camera off using the main switch 16.
Important:
Do not open the bottom cover or remove the memory card or
battery while the red LED 21 at the bottom right next to the
monitor 31 is flashing, indicating picture recording and/or data
saving to the card. Otherwise the unsaved (or not completely
saved) picture data may be lost.
Removing the bottom cover
Inserting the battery
Removing the battery
