Leica CS30 LTE User manual

Leica CS30 LTE
User Manual
Version 1.0
English

Introduction
Congratulations on the purchase of the Leica CS30 LTE.
This manual contains important safety directions as well as instructions for
setting up the product and operating it. Refer to 1 Safety Directions for fur-
ther information.
Read carefully through the User Manual before you switch on the product.
The content of this document is subject to change without prior notice. Ensure
that the product is used in accordance with the latest version of this docu-
ment.
The content of this document is subject to change without prior notice. Ensure
that the product is used in accordance with the latest version of this docu-
ment.
Updated versions are available for download at the following Internet address:
https://myworld.leica-geosystems.com > myDownloads.
The model and serial number of your product are indicated on the type plate.
Always refer to this information when you need to contact your agency or
Leica Geosystems authorised service centre.
•Windows® is a registered trademark of Microsoft Corporation in the
United States and other countries
•SD Logo is a trademark of SD-3C, LLC.
•Bluetooth® is a registered trademark of Bluetooth SIG, Inc.
All other trademarks are the property of their respective owners.
This manual applies to the CS30 LTE eld controller. Differences between the
various models are marked and described.
Name Description/Format
CS30 LTE Quick
Guide
Provides an overview of the product
together with technical data and
safety directions. Intended as a
quick reference guide.
ü ü
CS30 LTE User
Manual
All instructions required in order to
operate the product to a basic level
are contained in the User Manual.
Provides an overview of the product
together with technical data and
safety directions.
-ü
Purchase
☞
Product identication
Trademarks
Validity of this
manual
Available
documentation
2

Name Description/Format
Leica Captivate
Technical Reference
Manual
Overall comprehensive guide to the
product and apps. Included are
detailed descriptions of special soft-
ware/hardware settings and soft-
ware/hardware functions intended
for technical specialists.
-ü
Refer to the following resources for all CS30 LTE documentation/soft-
ware:
•the Leica USB documentation card
•https://myworld.leica-geosystems.com
On the last page of this manual, you can nd the address of Leica Geosystems
headquarters. For a list of regional contacts, please visit
http://leica-geosystems.com/contact-us/sales_support.
myWorld@Leica Geosystems (https://myworld.leica-geosystems.com)
offers a wide range of services, information and training material.
With direct access to myWorld, you are able to access all relevant services
whenever it is convenient for you.
Service Description
myProducts Add all products that you and your company own
and explore your world of Leica Geosystems: View
detailed information on your products and update
your products with the latest software and keep up-
to-date with the latest documentation.
myService View the current service status and full service his-
tory of your products in Leica Geosystems service
centres. Access detailed information on the services
performed and download your latest calibration cer-
ticates and service reports.
mySupport Create new support requests for your products that
will be answered by your local Leica Geosystems
Support Team. View the complete history of your
support requests and view detailed information on
each request in case you want to refer to previous
support requests.
myLearning Welcome to the home of Leica Geosystems online
learning! There are numerous online courses – avail-
able to all customers with products that have valid
CCPs (Customer Care Packages).
myTrustedServices Add your subscriptions and manage users for Leica
Geosystems Trusted Services, the secure software
services, that assist you to optimise your workow
and increase your efciency.
Leica Geosystems
address book
3

Service Description
mySmartNet HxGN SmartNet is the GNSS correction service built
on the world’s largest reference station network,
enabling GNSS-capable devices to quickly determine
precise positions in the range of one to two centi-
metre accuracy. The service is provided 24/7 by a
highly-available infrastructure and professional sup-
port team with more than 10 years of experience
reliably delivering the service.
myDownloads Downloads of software, manuals, tools, training
material and news for Leica Geosystems products.
4

Table of Contents
1 Safety Directions 6
1.1 General Introduction 6
1.2 Denition of Use 6
1.3 Limits of Use 7
1.4 Responsibilities 7
1.5 Hazards of Use 8
1.6 Electromagnetic Compatibility (EMC) 12
2 Description of the System 15
2.1 Overview 15
2.2 Terminology 15
2.3 System Concept 15
2.3.1 Power Concept 15
2.3.2 Data Storage Concept 15
2.4 Container Contents 16
2.5 CS Components 18
3 User Interface 20
3.1 Operating Principles 20
3.2 Home Screen 20
3.3 LED Indicators on CS30 LTE 21
4 Operation 23
4.1 Equipment Setup 23
4.1.1 Replacing the Display Foil on the CS 23
4.1.2 Install USB Drivers 23
4.2 Batteries 25
4.2.1 Operating Principles 25
4.2.2 Changing the Battery 25
4.2.3 Charging the Battery 26
4.3 Power Functions 26
4.4 Working with the Memory Device 26
4.4.1 Working with the SD, microSD Card and Nano SIM Card 26
4.4.2 Working with a USB Memory Stick 28
5 Care and Transport 29
5.1 Transport 29
5.2 Storage 29
5.3 Cleaning and Drying 29
6 Technical Data 31
6.1 CS30 LTE 31
6.2 Conformity to National Regulations 32
7 Software Licence Agreement/Warranty 61
Table of Contents 5

1 Safety Directions
1.1 General Introduction
The following directions enable the person responsible for the product, and
the person who actually uses the equipment, to anticipate and avoid opera-
tional hazards.
The person responsible for the product must ensure that all users understand
these directions and adhere to them.
Warning messages are an essential part of the safety concept of the instru-
ment. They appear wherever hazards or hazardous situations can occur.
Warning messages...
•make the user alert about direct and indirect hazards concerning the use
of the product.
•contain general rules of behaviour.
For the users‘ safety, all safety instructions and safety messages shall be
strictly observed and followed! Therefore, the manual must always be available
to all persons performing any tasks described here.
DANGER, WARNING, CAUTION and NOTICE are standardised signal words for
identifying levels of hazards and risks related to personal injury and property
damage. For your safety, it is important to read and fully understand the fol-
lowing table with the different signal words and their denitions! Supplement-
ary safety information symbols may be placed within a warning message as
well as supplementary text.
Type Description
DANGER Indicates an imminently hazardous situation
which, if not avoided, will result in death or
serious injury.
WARNING Indicates a potentially hazardous situation or
an unintended use which, if not avoided,
could result in death or serious injury.
CAUTION Indicates a potentially hazardous situation or
an unintended use which, if not avoided,
may result in minor or moderate injury.
NOTICE
Indicates a potentially hazardous situation or
an unintended use which, if not avoided,
may result in appreciable material, nancial
and environmental damage.
☞Important paragraphs which must be
adhered to in practice as they enable the
product to be used in a technically correct
and efcient manner.
1.2 Denition of Use
•Remote control of product
•Data communication with external appliances
•Recording measurements
•Computing with software
Description
About warning
messages
Intended use
6 Safety Directions

•Use of the product without instruction
•Use outside of the intended use and limits
•Disabling safety systems
•Removal of hazard notices
•Opening the product using tools, for example screwdriver, unless this is
permitted for certain functions
•Modication or conversion of the product
•Use after misappropriation
•Use of products with recognisable damage or defects
•Use with accessories from other manufacturers without the prior explicit
approval of Leica Geosystems
•Inadequate safeguards at the working site
•Controlling of machines, moving objects or similar monitoring application
without additional control and safety installations
1.3 Limits of Use
Suitable for use in an atmosphere appropriate for permanent human habita-
tion. Not suitable for use in aggressive or explosive environments.
WARNING
Working in hazardous areas, or close to electrical installations or sim-
ilar situations
Life Risk.
Precautions:
▶Local safety authorities and safety experts must be contacted by the per-
son responsible for the product before working in such conditions.
The following advice is only valid for battery charger, power adapter and dock-
ing station.
Suitable for use in dry environments only and not under adverse conditions.
1.4 Responsibilities
Leica Geosystems AG, CH-9435 Heerbrugg, hereinafter referred to as Leica
Geosystems, is responsible for supplying the product, including the User
Manual and original accessories, in a safe condition.
Reasonably
foreseeable misuse
Environment
☞
Environment
Manufacturer of the
product
Safety Directions 7

The person responsible for the product has the following duties:
•To understand the safety instructions on the product and the instructions
in the User Manual
•To ensure that it is used in accordance with the instructions
•To be familiar with local regulations relating to safety and accident pre-
vention
•To inform Leica Geosystems immediately if the product and the applica-
tion become unsafe
•To ensure that the national laws, regulations and conditions for the oper-
ation of the product are respected
•To ensure that the radio modem is not operated without the permission
of the local authorities on frequencies and/or output power levels other
than those specically reserved and intended for use without a specic
permit. The internal and external radio modems have been designed to
operate on frequency ranges and output power ranges, the exact use of
which differs from one region and/or country to another.
1.5 Hazards of Use
DANGER
Risk of electrocution
Because of the risk of electrocution, it is dangerous to use poles, levelling
staffs and extensions in the vicinity of electrical installations such as power
cables or electrical railways.
Precautions:
▶Keep at a safe distance from electrical installations. If it is essential to
work in this environment, rst contact the safety authorities responsible
for the electrical installations and follow their instructions.
WARNING
Distraction/loss of attention
During dynamic applications, for example stakeout procedures, there is a
danger of accidents occurring if the user does not pay attention to the envir-
onmental conditions around, for example obstacles, excavations or trafc.
Precautions:
▶The person responsible for the product must make all users fully aware of
the existing dangers.
Person responsible
for the product
8 Safety Directions

WARNING
Inadequate securing of the working site
This can lead to dangerous situations, for example in trafc, on building sites
and at industrial installations.
Precautions:
▶Always ensure that the working site is adequately secured.
▶Adhere to the regulations governing safety, accident prevention and road
trafc.
CAUTION
Not properly secured accessories
If the accessories used with the product are not properly secured and the
product is subjected to mechanical shock, for example blows or falling, the
product may be damaged or people can sustain injury.
Precautions:
▶When setting up the product, make sure that the accessories are correctly
adapted, tted, secured, and locked in position.
▶Avoid subjecting the product to mechanical stress.
WARNING
Lightning strike
If the product is used with accessories, for example masts, staffs, poles, you
may increase the risk of being struck by lightning.
Precautions:
▶Do not use the product in a thunderstorm.
Safety Directions 9

DANGER
Risk of being struck by lightning
If the product is used with accessories, for example on masts, staffs, poles,
you may increase the risk of being struck by lightning. Danger from high
voltages also exists near power lines. Lightning, voltage peaks, or the touching
of power lines can cause damage, injury and death.
Precautions:
▶Do not use the product in a thunderstorm as you can increase the risk of
being struck by lightning.
▶Be sure to remain at a safe distance from electrical installations. Do not
use the product directly under or close to power lines. If it is essential to
work in such an environment contact the safety authorities responsible
for electrical installations and follow their instructions.
▶If the product has to be permanently mounted in an exposed location, it is
advisable to provide a lightning conductor system. A suggestion on how to
design a lightning conductor for the product is given below. Always follow
the regulations in force in your country regarding grounding antennas and
masts. These installations must be carried out by an authorised specialist.
▶To prevent damages due to indirect lightning strikes (voltage spikes)
cables, for example for antenna, power source or modem should be pro-
tected with appropriate protection elements, like a lightning arrester.
These installations must be carried out by an authorised specialist.
▶If there is a risk of a thunderstorm, or if the equipment is to remain
unused and unattended for a long period, protect your product addition-
ally by unplugging all systems components and disconnecting all connect-
ing cables and supply cables, for example, instrument - antenna.
WARNING
Inappropriate mechanical inuences to batteries
During the transport, shipping or disposal of batteries it is possible for inap-
propriate mechanical inuences to constitute a re hazard.
Precautions:
▶Before shipping the product or disposing it, discharge the batteries by the
product until they are at.
▶When transporting or shipping batteries, the person in charge of the
product must ensure that the applicable national and international rules
and regulations are observed.
▶Before transportation or shipping, contact your local passenger or freight
transport company.
WARNING
Exposure of batteries to high mechanical stress, high ambient temper-
atures or immersion into uids
This can cause leakage, re or explosion of the batteries.
Precautions:
▶Protect the batteries from mechanical inuences and high ambient tem-
peratures. Do not drop or immerse batteries into uids.
10 Safety Directions

WARNING
Short circuit of battery terminals
If battery terminals are short circuited e.g. by coming in contact with jewellery,
keys, metallised paper or other metals, the battery can overheat and cause
injury or re, for example by storing or transporting in pockets.
Precautions:
▶Make sure that the battery terminals do not come into contact with
metallic objects.
For the AC power supply:
WARNING
If unit is not connected to ground, death or serious injury can occur.
Precautions:
▶To avoid electric shock power cable and power outlet must be grounded.
The following advice is only valid for battery charger, power adapter and dock-
ing station.
WARNING
Electric shock due to use under wet and severe conditions
If unit becomes wet it may cause you to receive an electric shock.
Precautions:
▶If the product becomes humid, it must not be used!
▶Use the product only in dry environments, for example in buildings or
vehicles.
▶Protect the product against humidity.
The following advice is only valid for battery charger, power adapter and dock-
ing station.
WARNING
Unauthorised opening of the product
Either of the following actions may cause you to receive an electric shock:
•Touching live components
•Using the product after incorrect attempts were made to carry out repairs
Precautions:
▶Do not open the product!
▶Only Leica Geosystems authorised service centres are entitled to repair
these products.
☞
☞
Safety Directions 11

WARNING
Improper disposal
If the product is improperly disposed of, the following can happen:
•If polymer parts are burnt, poisonous gases are produced which may
impair health.
•If batteries are damaged or are heated strongly, they can explode and
cause poisoning, burning, corrosion or environmental contamination.
•By disposing of the product irresponsibly you may enable unauthorised
persons to use it in contravention of the regulations, exposing themselves
and third parties to the risk of severe injury and rendering the environ-
ment liable to contamination.
Precautions:
▶The product must not be disposed with household waste.
Dispose of the product appropriately in accordance with
the national regulations in force in your country.
Always prevent access to the product by unauthorised
personnel.
Product-specic treatment and waste management information can be
received from your Leica Geosystems distributor.
WARNING
Improperly repaired equipment
Risk of injuries to users and equipment destruction due to lack of repair
knowledge.
Precautions:
▶Only authorised Leica Geosystems Service Centres are entitled to repair
these products.
1.6 Electromagnetic Compatibility (EMC)
The term Electromagnetic Compatibility is taken to mean the capability of the
product to function smoothly in an environment where electromagnetic radi-
ation and electrostatic discharges are present, and without causing electro-
magnetic disturbances to other equipment.
WARNING
Electromagnetic radiation
Electromagnetic radiation can cause disturbances in other equipment.
Precautions:
▶Although the product meets the strict regulations and standards which
are in force in this respect, Leica Geosystems cannot completely
exclude the possibility that other equipment may be disturbed.
Description
12 Safety Directions

CAUTION
Use of the product with accessories from other manufacturers. For
example eld computers, personal computers or other electronic equip-
ment, non-standard cables or external batteries
This may cause disturbances in other equipment.
Precautions:
▶Use only the equipment and accessories recommended by Leica Geosys-
tems.
▶When combined with the product, they meet the strict requirements stip-
ulated by the guidelines and standards.
▶When using computers, two-way radios or other electronic equipment,
pay attention to the information about electromagnetic compatibility
provided by the manufacturer.
CAUTION
Intense electromagnetic radiation. For example, near radio transmit-
ters, transponders, two-way radios or diesel generators
Although the product meets the strict regulations and standards which are in
force in this respect, Leica Geosystems cannot completely exclude the possib-
ility that function of the product may be disturbed in such an electromagnetic
environment.
Precautions:
▶Check the plausibility of results obtained under these conditions.
CAUTION
Electromagnetic radiation due to improper connection of cables
If the product is operated with connecting cables attached at only one of their
two ends, for example external supply cables, interface cables, the permitted
level of electromagnetic radiation may be exceeded and the correct function-
ing of other products may be impaired.
Precautions:
▶While the product is in use, connecting cables, for example product to
external battery, product to computer, must be connected at both ends.
Safety Directions 13

WARNING
Use of product with radio or digital cellular phone devices
Electromagnetic elds can cause disturbances in other equipment, in installa-
tions, in medical devices, for example pacemakers or hearing aids and in air-
crafts. Electromagnetic elds can also affect humans and animals.
Precautions:
▶Although the product meets the strict regulations and standards which
are in force in this respect, Leica Geosystems cannot completely exclude
the possibility that other equipment can be disturbed or that humans or
animals can be affected.
▶Do not operate the product with radio or digital cellular phone devices in
the vicinity of lling stations or chemical installations, or in other areas
where an explosion hazard exists.
▶Do not operate the product with radio or digital cellular phone devices
near to medical equipment.
▶Do not operate the product with radio or digital cellular phone devices in
aircrafts.
▶Do not operate the product with radio or digital cellular phone devices for
long periods with the product immediately next to your body.
14 Safety Directions

2 Description of the System
2.1 Overview
0021682_001
CS30
2.2 Terminology
CS is a collective term describing the various models of the multi-purpose eld
controller which is used with GNSS and TS instruments.
2.3 System Concept
2.3.1 Power Concept
Use the batteries, chargers and accessories recommended by Leica Geosys-
tems to ensure the correct functionality of the instrument.
Power supply
Internally by GEB260 battery, OR
Externally by GEV288 power supply, OR
Externally by CCS02 docking station
If an external power supply is connected and the internal battery is inserted,
then the external power is used. The internal battery is charged.
2.3.2 Data Storage Concept
Device Description
microSD card All eld controllers have a microSD card slot tted as stand-
ard. A microSD card can be inserted and removed. Available
capacity: 256 GB.
USB stick All eld controllers have an USB type A and type C port tted
as standard.
Internal
memory
All eld controllers have an internal memory tted as stand-
ard. Available capacity: 64 GB.
☞While other microSD cards can be used, Leica Geosystems recom-
mends to only use Leica microSD cards and is not responsible for
data loss or any other error that can occur while using a non-Leica
card.
System components
CS general descrip-
tion
General
Power options
Memory device
Description of the System 15

Removing the SD card or USB stick while the eld controller is turned on can
cause loss of data. Only remove the SD card or USB stick or unplug connect-
ing cables when the eld controller is switched off.
Data can be transferred in various ways.
SD cards can directly be used in an OMNI drive as supplied by Leica Geosys-
tems. Other PC card drives can require an adaptor.
2.4 Container Contents
0021683_001
d
a
b
c
e
f
g
h
i
j
k
l
m
n
o
p
q
a GHT63 clamp
b Manuals and USB documentation card
c GEB212, GEB260 (spare battery for CS30 LTE) or GEB331 batteries
d Antenna
e GAT18, GAT27 or GAT28 mobile antenna
f GAT21, GAT25 or GAT26 radio antenna
g Field controller with holder or tablet
h Tribrach
i Height hook
j USB stick
k Cables
l Antenna
m Stylus
n SD cards
o GAD34 arm 3 cm
p TNC QN-adapter
q Allen key and adjustment tool
☞
Transfer data
☞
Container for GS
instrument and
accessories 1/2
16 Description of the System

0014961_002
a
b
c
i
d
e
h
f
g
j
j
a GHT36 base for telescopic rod
b Antenna arm
c GFU RTK modem
d GAD32 telescopic rod
e GAT1 or GAT2 radio antennas
f GEB212, GEB260 (spare battery for CS30 LTE) or GEB331 batteries
g GRT146 or GRT247 carrier
h GAD33 arm
i GHT58 tripod bracket for GFU
j External battery
Container for GS
instrument and
accessories 2/2
Description of the System 17

0014955_002
a h
i
j
k
l
b
c
d
e
f
g
a Field controller with holder
b Antenna
c CRP15, quick release adaptor for quick mounting and demounting the
GS18 to the pole without screwing
d GAT25, GAT26, GAT27 or GAT28 antenna
e Stylus
f GHT63 clamp
g USB stick
h GAT1 or GAT2 radio antennas
i Antenna arm
j microSD card including adapter or SD card
k Manual & USB documentation card
l GEB212, GEB260 (spare battery for CS30 LTE) or GEB331 batteries
2.5 CS Components
0021684_001
a
bf
g
e
c
d
h
i
a Light sensor
b Microphone
c Power LED
d Charging LED
e WiFi - GNSS - 4G, pass-
through connectors to
external antenna
f Docking contact pins
g DC jack for power cable
h USB type C
i USB type A
Container for GS
instrument and
accessories
Upside and sides of
CS30 LTE
18 Description of the System

0021685_001
a
h
d
f
b
i
c
g
j
k
e
a Battery LED indicator
b Battery
c Camera
d LED ash
e nanoSIM card slot
f microSD card slot
g Card holder
h Docking contact pins
i Card slot
j Battery lock
k Speaker
0021686_001
a
c
b
d
e
a Power key
b P1, function key 1
c P2, function key 2
d Kensington lock
e DC Jack
Key Function
Power key Power on.
If the eld controller is already on:
•Activate sleep mode when held for 2 s.
•Turns the eld controller off when held
for 5 s.
P1, function
key 1
Increase the screen brightness.
To increase the screen brightness by one
level, press the key once.
To increase the screen brightness to max-
imum, press and hold the key.
P2, function
key 2
Decrease the screen brightness.
Todecrease the screen brightness by one
level, press the key once.
Todecrease the screen brightness to min-
imum, press and hold the key.
Underside of CS30
LTE
Left side of CS30 LTE
Keys
Description of the System 19

3 User Interface
3.1 Operating Principles
The user interface is operated by the touch screen with nger or supplied
stylus. The workow is the same for keyboard and touch screen entry, the
only difference lies in the way information is selected and entered.
Operation by touch screen
Information is selected and entered on the screen using the supplied stylus.
Operation Description
To select an item Tap on the item.
To start the edit mode in editable
elds
Tap on the editable eld.
To highlight an item or parts of it for
editing
Drag the supplied stylus from the
left to the right.
To accept data entered into an edit-
able eld and exit the edit mode
Tap on the screen outside of the
editable eld.
To open a context-sensitive menu Tap on the item and hold for 2 s.
3.2 Home Screen
From the home screen, you can view the device status and access the applica-
tions.
At the bottom of the home screen is
the status bar, which contains the
notication area, the status area and
the display area.
The shortcut panel is at the bottom.
The shortcut panel can be custom-
ized.
Using apps
The main screen shows all included apps. Double-click to open an app. Right-
click Angle X to close an app.
Fix the app to the start menu/start screen
1. Right-click the application item on the left.
2. Set Fix to start screen to on.
3. The app icon or tile will appear in the right area.
Fix the application to the taskbar
1. Right-click an app item in the start menu.
2. Select Pin to taskbar.
Keyboard and touch
screen
Home screen
20 User Interface
