Leicke DJ R Series User manual

Bluetooth-Speaker DJ Roxxx
"Partybox Aurora"
Product number: EP18240
Manual

Congratulations on the purchase of your new device. You have selected a high-quality
product. Before attempting to use this device, please check the packaging and make sure
the following items are contained in the package:
Number of
Name
Note
1
Bluetooth-Speaker
integrated battery
1
Adapter
DC 9V 1.5A
1
AUX cable
3.5mm
1
Remote control
-
1
User's manual
-
Frequency
50Hz-20KHz
Power
80W
Speaker
6.5”X2 + 1.5”X1
Supported audio format
MP3, WAV files
SD / TF card
up to 32 GB
Sensitivity
80db
Bluetooth version
V5.0
Bluetooth transmission range
≤ 10m
Bluetooth usage current
< 30mA
Bluetooth stand-by current
< 15mA
Bluetooth transmission frequency
2.4GHz-2.480GHz
Bluetooth frequency band
UHF
Bluetooth transmission rate
24Mbps
Max. transmission
2.42 mW
Stand-by usage
Up to 40 h
Charging voltage
DC 9V / 1500mA
Battery capacity
7.4V 10000mAh
PACKAGE CONTENTS
TECHNICAL DETAILS
Pieces

Working temperature
-10~40°C
Max. playtime
Up to 8h
Size, Net Weight
24*25*63cm, 6kg
Compatible with tablets, smartphones, PCs, notebooks which have Bluetooth or AUX
output.
1. Do not expose the device to dripping or splashing liquid.
2. Do not place objects filled with liquid on the unit.
3. Do not block the ventilation openings.
4. When using a high output signal, do not turn the volume up to maximum to avoid
distortion.
COMPATIBILTY
CAUTION
FUNCTION PANEL

1
POWER
ON/OFF the power of the Whole product.
2
MODE
Switch USB/AUX//FM/TF/BT. (when BT connected,
press"Mode" button for 3 seconds to disconnect the BT.and re-
enter the matching state for another phone).
3
MIC-PRI
Press the button, the display show" on" machine come into
microphone priority status, and press again "MIC PRI" the
display show" off, microphone priority closed.
4
MENU
When using microphone, press the “MENU ” to switch
the MIC /ECHO VOL, and rotate Multi vol to adjust the MIC /
Echo vol.
H 00~H 30 MIC VOL ( From 0 to 30)
E 00~E 30 ECHO VOL (From 0 to 30)
5
LIGHT
Transfer different light mode.
6
Short press is the previous song or radio station.
7
Press the play button to pause and continue playing.
8
Short press is the next song or radio station.
9
MULTI. VOL
Adjust the volume of the machine.
10
MIC 1/2
microphone jack
11
AUX
Connect the smart device( mobile phone / tablet) with the
machine by an AUX-IN cable.
12
TF interface
directly insert TF card to play.
13
USB
interface
Insert the USB disk into the USB mode.
14
DC-9V
For the 9V/1.5A adapter to charge the machine.
15
LED
When Charging, it shows in red, and once full charge, the light
will turn into green.
1. Press the MODE button to switch to Bluetooth mode.
2. Mobile phone open the Bluetooth and search”EP18240”, click on the connection, after
connect successful, you can enjoy wonderful music.
1. When the TF card or U disk is inserted, the machine automatically switches to music
playback mode.
2. Press the pause/Play button to pause, press again to continue playing.
3. Press Music Last song/Next Song to switch music.
4. Press the MODE key to switch music / USB / TF / AUX /FM/ Bluetooth function.
1. press the MODE button to switch to FM model.
2. Long Press play button to automatically search for the station. After the station is
completed, the station will automatically save it.
3. Press Last song/Next Song keys to switch radio stations.
4. Press the MODE key to switch other functions.
INTERFACE DESCRIPTION
BLUETOOTH MODE
MUSIC MODE
FM-MODE

You can record the sound source when you connect a microphone. It is possible to store
the recordings on USB KEY or a TF card. If both a USB and TF card are inserted, then
USB will be priority.
-Press the REC button on the remote to start recording.
-Press the REC play button to play your recording
1. Turn on the power and insert the microphone into the microphone hole.
2. Prompt into the microphone for amplification.
3. Wireless microphone requires external module and wireless microphone.
When the battery is charging, the battery indicator show in red, after full charge the indicator
show in Green. When in low battery, the battery icons on the LED screen will keep flashing,
please charge in time.
Under Bluetooth Mode, long press the “ PLAY/PAUSE’ button for three seconds on either
speaker, it will start TWS auto pairing, With a “DUDU” Sound indicate successfully paired.
Open the Bluetooth of the Phone and search the Bluetooth pairing name, after paired
successfully, one speaker will become left channel, and other become right channel.
Long press the “ mode” Button to auto shutdown.
REC Function ( Control by remote)
Microphone operation
Charging
TWS Function
REMOTE INSTRUCTIONS

1. Mute: Press this button to mute the music.
2. MODE: Switch mode to FM/BT.
3. REC: Record your Voice from the Microphone.
4. CH-: Last channel / previous Song
5. : Repeat a single or all tracks.
6. Digit 0-9: Change the song that was saved on the USB stick/ TF card.
7. REC Play: Play your recorded Voice.
8. VOL+: Turn up the volume.
9. SCAN: Longpress in FM mode to scan the channel. Press briefly to pause the music.
10. CH+: Next channel / Next song.
11. VOL-: Turn down the volume.
12. LED: Press this key to switch the speaker lighting on/off.
For your own safety and so that you can enjoy our product for a long time, please observe
the following safety instructions:
• Do not expose this product to a wet environment or high temperatures. It must not
stand in the rain or fall.
• To reduce the risk of electronic shock or fire, do not remove the case cover, but
consult a qualified electrician.
• In the rare event of a malfunction, do not attempt to repair the unit yourself. Contact
a certified service technician for proper diagnosis and repair.
• If fragments or liquids fall into the equipment box, turn off the power immediately. It
must not be used again until it has been checked by qualified personnel.
• The device should be placed on a horizontal, flat and solid surface with good
ventilation.
• Do not install the unit in or near a place where it may come into contact with rain,
moisture or other liquids.
• If the battery is incorrectly replaced, an explosion may occur. Please replace it with
a battery of the same or equivalent type.
• To avoid an accidental charging, the original adapter of this product must be used to
charge the battery. If the accident or machine damage is caused by other original
adapters, the warranty is void.
• To avoid battery explosion, do not install the unit in areas of extreme heat, fire or in
areas exposed to direct sunlight.
SAFETY NOTES

Our obligation to inform you according to the battery law
In connection with the sale of batteries or the delivery of devices containing batteries, we are
obliged to inform you of the following:
As the end user, you are legally obliged to return used batteries. You can return used
batteries that we carry or have carried in our range as new batteries to our dispatch
warehouse (dispatch address) free of charge. The symbols shown on the batteries have the
following meaning:
The symbol of the crossed-out dustbin means that the battery must not be disposed of in the
household waste.
must not be disposed of in the household waste.
Pb = Battery contains more than 0.004% lead by mass.
Cd = battery contains more than 0.002 mass percent cadmium
Hg = Battery contains more than 0.0005% mercury by mass. Please
observe the above instructions.
LEICKE GmbH herewith declares that the device complies with the RED
2014/53/EU and Rohs 2011/65/EC Annex II 2015/863 &
2017/2102regulations. The declaration of conformity. can be found at
www.leicke.com. Go to the product you bought and look at downloads.
www.leicke.com/de/products/EP18240
Please contact us in case of questions!
PRODUCTION & WHOLESALE
LEICKE GmbH
Stöhrerstraße 17
04347 Leipzig
Germany
Web: www.leicke.com
Mail: inf[email protected]
DISPOSAL
DECLARATION OF CONFORMITY
Contact
