Leightronix MINI-T-NX User manual

© 2007-2018 LEIGHTRONIX, INC. All Rights Reserved.
This information is subject to change without notice.
MINI-T-NXTM, WinLGXTM, Total Backup TM, Total ImportTM, and PRO-BUSTM are trademarks of
LEIGHTRONIX, INC.
LEIGHTRONIX, INC.
1125 N Cedar Rd
Mason, MI 48854
www.leightronix.com
Ph: [phone]
Fax: [phone]
Email: [e-mail]

LEIGHTRONIX, INC.
Page 1
2018-06-08
WinLGX ver. 6.0.1.48
TABLE OF CONTENTS
INTRODUCTION.............................................................................................................15
SAFETY INSTRUCTIONS .................................................................................................16
MINI-T-NXCONTROLLER FEATURES/SPECIFICATIONS ...................................................17
CONTROL FEATURES ....................................................................................................18
LIMITS ON CONTROL OF DVD PLAYERS..........................................................................20
AUTOMATIC POWER SAVING FEATURES...................................................................... 20
PLAYBACK OF COMMERCIAL MOVIES .......................................................................... 20
PLAYBACK OF YOUR OWN DVDS............................................................................... 20
DVD PLAYER/RECORDER CONTROL METHODS............................................................ 21
SUPPORTED DVD PLAYERS AND RECORDERS............................................................. 21
SLIDE FILE SPECIFICATIONS...........................................................................................22
MPEG FILE SPECIFICATIONS.........................................................................................23
MINI-T-NX MPEG RECORDER OPTION SPECIFICATIONS.............................................. 23
ENCODING A BACKGROUND AUDIO FILE ...................................................................... 25
CREATING MPEG FILES WITH NON-LEIGHTRONIX SOURCES..................................... 26
MINI-T-NXFRONT PANEL ............................................................................................27
KEYPAD .................................................................................................................. 27
DISPLAY.................................................................................................................. 27
LEDS..................................................................................................................... 30
MINI-T-NXREAR PANEL..............................................................................................31
CONTROLLER INSTALLATION & CONFIGURATION.................................................33
ABOUT THIS SECTION....................................................................................................33
PACKING LIST ...............................................................................................................33
MINI-T-NXINSTALLATION OVERVIEW ............................................................................34
CONNECTING SIGNAL WIRING........................................................................................35
CONFIGURING ETHERNET NETWORK HOST MANAGEMENT ..............................................37
CONNECTING MINI-T-NX TO AN EXISTING ETHERNET NETWORK.................................... 37
CONNECTING MINI-T-NX DIRECTLY TO A PCVIA ETHERNET.......................................... 37
CONFIRMING ETHERNET NETWORK CONFIGURATION .................................................... 38
TURNING THE MINI-T-NXON/OFF ..............................................................................39
CONFIGURING FRONT PANEL SETTINGS .........................................................................39
ENTERING PASSWORD.............................................................................................. 39
EDITING IP ADDRESS................................................................................................ 40
EDITING SUBNET MASK............................................................................................. 40

Page 2
LEIGHTRONIX, INC.
WinLGX ver. 6.0.1.48
2018-06-08
EDITING GATEWAY ADDRESS.....................................................................................41
SOFTWARE INSTALLATION & CONFIGURATION......................................................43
ABOUT THIS SECTION....................................................................................................43
WINLGXMINIMUM SYSTEM REQUIREMENTS...................................................................44
INSTALLING WINLGXSOFTWARE...................................................................................44
ADDING /DELETING MINI-T-NXLOCATIONS IN THE SITE MANAGER .................................46
CONNECTING TO YOUR MINI-T-NXSERVER/CONTROLLER.............................................48
CREATING NEW MINI-T-NXIMAGE FILES.......................................................................51
CONFIGURING WINLGX................................................................................................52
ABOUT THE MAIN WINDOW COMPONENTS...................................................................52
CONFIGURING THE MAIN WINDOW COMPONENTS .........................................................57
SETTING USER ACCOUNT RIGHTS (INCLUDING WINLGX PASSWORD CHANGES).............. 61
CHANGING FRONT PANEL PASSWORD ........................................................................65
CONFIGURING SITE INFORMATION,CLOCK,UPDATING FIRMWARE,AND REBOOTING .........66
CREATING TEMPLATES FOR EXPORTING/PRINTING SCHEDULES .....................................68
CONFIGURING PAGE LAYOUTS FOR SCHEDULES PRINTED FROM WINLGX......................70
CONFIGURING PRINTER AND PAPER SETTINGS FOR SCHEDULES PRINTED FROM WINLGX 71
CONFIGURING USER-DEFINED SCHEDULE COLUMNS ....................................................72
SETTING WINLGX VIEWING AND COMMUNICATION PREFERENCES .................................75
Application Tab ................................................................................................................75
Resource Library Tab.......................................................................................................77
Color/Schedules Tab........................................................................................................78
Color/Control Panel Tab...................................................................................................79
Color/Other Tab ...............................................................................................................79
Event Editor Tab ..............................................................................................................80
Resource View Tab..........................................................................................................82
Schedule Tab...................................................................................................................84
CONFIGURING MINI-T-NX SYSTEM’S SWITCHER PROPERTIES.......................................85
CONFIGURING MINI-T-NX IRPORT PROPERTIES .........................................................88
CONFIGURING MPEG RECORDING PRESETS FOR RECORDER OPTION............................ 90
EDITING INTERNAL MPEG PLAYER AND RECORDER DEVICE RESOURCES.......................91
MPEG Player ...................................................................................................................92
MPEG Recorder Option ...................................................................................................93
CREATING EXTERNAL DEVICE RESOURCES .................................................................95
DVD Device Resources....................................................................................................96
Tape Device Resources...................................................................................................98
Switch Resources...........................................................................................................100
GPI Output Device Resources .......................................................................................102
CREATING LIBRARY RESOURCES.............................................................................. 104

LEIGHTRONIX, INC.
Page 3
2018-06-08
WinLGX ver. 6.0.1.48
Tape and DVD Library Resources .................................................................................106
Switch Library Resources ..............................................................................................108
MPEG Library Resources ..............................................................................................110
MPEG Loop Library Resources .....................................................................................115
Slide Library Resources.................................................................................................119
Slide Show Library Resources.......................................................................................122
MPEG File/Slide Playlist Library Resources...................................................................126
SOFTWARE OPERATION............................................................................................129
ABOUT THIS SECTION..................................................................................................129
PERFORMING GENERAL WINLGXOPERATIONS............................................................130
OPENING AND LOGGING INTO WINLGX ......................................................................130
DISPLAYING WINLGX VERSION NUMBER ...................................................................132
PRINTING SCHEDULES FROM WINLGX.......................................................................133
EXPORTING SCHEDULES INTO MICROSOFT EXCEL®OR A COMMA DELIMITED FORMAT .....134
LOGGING OUT OF WINLGX.......................................................................................135
EXITING WINLGX....................................................................................................136
OPENING MINI-T-NXIMAGE FILES ..............................................................................137
OPENING A SAVED IMAGE FILE .................................................................................137
OPENING AN IMAGE FILE AS NEW..............................................................................138
RECEIVING IMAGE FILES FROM THE CONNECTED MINI-T-NX SERVER/CONTROLLER(S)...139
ASSOCIATING MINI-T-NX IMAGE FILES WITH WINLGX................................................140
SAVING MINI-T-NXIMAGE FILES.................................................................................140
SCHEDULING EVENTS .................................................................................................142
ABOUT SCHEDULE WINDOW COMPONENTS................................................................142
Controller Tabs ..............................................................................................................142
Channel Output Tabs ....................................................................................................142
Day Tabs.......................................................................................................................142
WinLGX-LT Tab.............................................................................................................144
Channel and Day/WinLGX-LT Tab Configurations ........................................................145
Schedule Columns.........................................................................................................145
SCHEDULING/EDITING/DELETING ALL EVENTS ............................................................147
Scheduling an Event on a Day/Channel Output Event Window.....................................147
Scheduling an Event on the WinLGX-LT Event Window ...............................................149
Copying/Cutting/Pasting an Event .................................................................................150
Editing an Event ............................................................................................................150
Deleting an Event ..........................................................................................................150
Replacing Library Resource Events...............................................................................152
Inserting Library Resource Events .................................................................................154
SCHEDULING/EDITING DEVICE RESOURCES................................................................156
DVD Device Resources .................................................................................................156
Tape Device Resources.................................................................................................158

Page 4
LEIGHTRONIX, INC.
WinLGX ver. 6.0.1.48
2018-06-08
Switch Device Resources...............................................................................................160
GPI Output Device Resources .......................................................................................162
Internal MPEG Player Device Resource.........................................................................164
Internal MPEG Recorder Device Resources ..................................................................168
SCHEDULING/EDITING LIBRARY RESOURCES.............................................................. 172
Tape and DVD Library Resources..................................................................................172
Switch Library Resources...............................................................................................174
Slide Library Resources .................................................................................................176
Slide Show Library Resources .......................................................................................178
MPEG Library Resources...............................................................................................180
MPEG Loop Library Resources......................................................................................183
MPEG File/Slide Playlist Resources...............................................................................186
EDITING PROGRAM INTERVALS................................................................................. 187
Filling Schedule Switchback Intervals with MPEG/Slide Library Resources....................187
Manually Changing Switchback Inputs for Program Intervals .........................................188
CHECKING SCHEDULE AND LIBRARY RESOURCES FOR MISSING MPEG FILES ............... 190
SENDING MINI-T-NXIMAGE FILES...............................................................................191
USING CONTROL PANEL TO PERFORM IMMEDIATE DEVICE AND SWITCH ACTIONS ...........192
STOP/START A SCHEDULE....................................................................................... 193
PERFORMING FORCED SWITCHES AND VIEWING SWITCHER STATUS ............................ 193
DISPLAYING PROGRAMMING THROUGH THE “PREVIEW”OUTPUT................................... 194
CONTROLLING INTERNAL MPEG PLAYER .................................................................. 194
Queuing a File................................................................................................................195
Looping an MPEG File...................................................................................................197
Playing a File..................................................................................................................198
Queuing the Next File.....................................................................................................198
Displaying a Slide with Audio from an MPEG File ..........................................................198
Stopping a File ...............................................................................................................199
Pausing an MPEG File...................................................................................................199
Creating a Library Clip Resource....................................................................................199
CONTROLLING INTERNAL MPEG RECORDER ............................................................. 201
CONTROLLING EXTERNAL DEVICES........................................................................... 205
IR or PRO-BUS-Controlled Devices (VCRs, DVD, ¾”, 8mm, Beta SP, and HI-8mm Players)
.......................................................................................................................................205
GPI Output Devices........................................................................................................206
MANAGING DIGITAL FILE STORAGE...............................................................................208
GETTING STARTED.................................................................................................. 208
MANAGING VIDEOS AND SLIDES ............................................................................... 209
MANAGING SLIDES: UPLOADING TO THE MINI-T-NX AND AUTHORIZING FOR DISPLAY ... 211
RETRIEVING LOG FILES................................................................................................214
Event Log Files ..............................................................................................................214
System Log Files............................................................................................................215

LEIGHTRONIX, INC.
Page 5
2018-06-08
WinLGX ver. 6.0.1.48
FIRMWARE/SOFTWARE UPDATES.................................................................................219
UPDATING MINI-T-NX CONTROLLER FIRMWARE.........................................................219
UPDATING WINLGX SOFTWARE ...............................................................................221
TROUBLESHOOTING ..................................................................................................223
PARTS REPLACEMENT.................................................................................................223
CONTACTING LEIGHTRONIXTECHNICAL SUPPORT....................................................223
WARRANTY.................................................................................................................. 224
DECLARATION OF STANDARDS CONFORMITY .....................................................225
FCC NOTICE..............................................................................................................225
APPENDIX A: TOTAL BACKUP...................................................................................226
OPENING &LOGGING INTO TOTAL BACKUP...................................................................226
SELECTING STORAGE LOCATIONS FOR MINI-T-NXINFORMATION..................................227
PERFORMING AN IMMEDIATE BACKUP...........................................................................229
PERFORMING SCHEDULED BACKUPS............................................................................229
RESTORING MINI-T-NXINFORMATION.........................................................................230
APPENDIX B: TOTAL IMPORT.................................................................................... 231
APPENDIX C: PRO-BUS INTERFACE CONNECTIONS.............................................234
SET SWITCHES...........................................................................................................234
ASSIGN INTERFACE AN ADDRESS..............................................................................234
CONFIGURE INTERFACE TO SEND CONTROL COMMANDS..............................................235
ATTACH PRO-BUS TO CORRESPONDING DEVICE ........................................................235
CONNECT PRO-BUS TO CONTROLLER AND OTHER PRO-BUS INTERFACES.................235
APPENDIX D: COPYRIGHT STATEMENTS ...............................................................236
WHITSOFT SLIMFTPD................................................................................................236
THE PHP LICENSE,VERSION 3.0.................................................................................236
GDSTATEMENT .........................................................................................................238
IJPEG STATEMENT ....................................................................................................238
FREETYPE STATEMENT............................................................................................238
GLOSSARY...................................................................................................................239
INDEX............................................................................................................................243

Page 6
LEIGHTRONIX, INC.
WinLGX ver. 6.0.1.48
2018-06-08
LIST OF TABLES AND ILLUSTRATIONS
ILLUSTRATION 1, MINI-T-NX MPEG RECORDER DEFAULT RECORDING PRESETS....................23
TABLE 1, HARD DRIVE STORAGE CAPACITIES AT SELECTED CBRS..........................................24
ILLUSTRATION 2, MINI-T-NX FRONT PANEL....................................................................................27
ILLUSTRATION 3, MINI-T-NX BIOS DATE STATUS SCREEN...........................................................27
ILLUSTRATION 4, MINI-T-NX SERIAL NUMBER AND FIRMWARE VERSION STATUS SCREEN....27
ILLUSTRATION 5, MINI-T-NX DISPLAY VERSION STATUS SCREEN..............................................28
ILLUSTRATION 6, MINI-T-NX FIRMWARE DATE STATUS SCREEN ................................................28
ILLUSTRATION 7, MINI-T-NX IP ADDRESS STATUS SCREEN ........................................................28
ILLUSTRATION 8, MINI-T-NX SITE ID STATUS SCREEN..................................................................28
ILLUSTRATION 9, MINI-T-NX SCHEDULE STATUS SCREEN...........................................................29
ILLUSTRATION 10, MINI-T-NX SWITCHER STATUS SCREEN.........................................................29
ILLUSTRATION 11, MINI-T-NX MPEG RECORDER STATUS SCREEN ............................................29
ILLUSTRATION 12, MINI-T-NX MPEG PLAYER STATUS SCREEN...................................................29
TABLE 2, MINI-T-NX FRONT PANEL LEDS .......................................................................................30
ILLUSTRATION 13, MINI-T-NX REAR PANEL....................................................................................31
FIGURE 1, EXAMPLE OF MINI-T-NX SYSTEM..................................................................................34
ILLUSTRATION 14, MINI-T-NX BOOTWARE SCREEN......................................................................36
ILLUSTRATION 15, MINI-T-NX BOOT PROGRESS SCREENS.........................................................36
TABLE 3, ETHERNET LED INDICATORS AND DESCRIPTIONS.......................................................38
ILLUSTRATION 16, MINI-T-NX PASSWORD ENTRY SCREEN.........................................................39
ILLUSTRATION 17, MINI-T-NX CONFIGURATION MENU SCREEN..................................................39
TABLE 4, EDITING IP ADDRESS FROM FRONT PANEL..................................................................40
TABLE 5, EDITING SUBNET MASK FROM FRONT PANEL ..............................................................40
TABLE 6, EDITING GATEWAY ADDRESS FROM FRONT PANEL....................................................41
ILLUSTRATION 18, LEIGHTRONIX HTML INDEX PAGE...................................................................44
ILLUSTRATION 19, “CONTROLLER SITE MANAGER” WINDOW .....................................................46
ILLUSTRATION 20, “ADD NEW” WINDOW ........................................................................................47
ILLUSTRATION 21, “ADD NEW” WINDOW ........................................................................................48
ILLUSTRATION 22, “SITE MANAGER” WINDOW ..............................................................................49
ILLUSTRATION 23, “SAVE AS” WINDOW .........................................................................................51
ILLUSTRATION 24, WINLGX MAIN WINDOW...................................................................................52
ILLUSTRATION 25, MENU BAR.........................................................................................................53
TABLE 7, MENU BAR ITEMS .............................................................................................................53
ILLUSTRATION 26, MAIN TOOLBAR.................................................................................................55

LEIGHTRONIX, INC.
Page 7
2018-06-08
WinLGX ver. 6.0.1.48
TABLE 8, TOOLBAR ITEMS...............................................................................................................55
ILLUSTRATION 27, “VIEW” MENU ....................................................................................................57
ILLUSTRATION 28, SCHEDULE COLUMNS SELECTION MENU.....................................................58
ILLUSTRATION 29, RESIZING SCHEDULE COLUMN......................................................................59
ILLUSTRATION 30, "SELECT DESTINATION FOLDER" WINDOW...................................................60
ILLUSTRATION 31, “USER ACCOUNTS” WINDOW ..........................................................................61
TABLE 9, USER CONTROL AND CONFIGURATION RIGHTS ..........................................................63
TABLE 10, USER FILE ACCESS RIGHTS.........................................................................................64
ILLUSTRATION 32, “SET FRONT PANEL PASSWORD” WINDOW ..................................................65
ILLUSTRATION 33, “CONTROLLER” WINDOW ................................................................................66
ILLUSTRATION 34, “EXPORT/PRINT TEMPLATES” WINDOW.........................................................68
ILLUSTRATION 35, “PAGE SETUP” WINDOW..................................................................................70
ILLUSTRATION 36, EXAMPLE OF A SCHEDULE HEADER .............................................................70
ILLUSTRATION 37, “PRINT SETUP” WINDOW .................................................................................71
ILLUSTRATION 38, EXAMPLE OF SCHEDULE WITH USER DEFINED FIELDS..............................72
ILLUSTRATION 39, “USER DEFINED DATA” WINDOW....................................................................72
ILLUSTRATION 40, “EDIT FIELD OPTIONS” WINDOW ....................................................................73
ILLUSTRATION 41, “ADD MENU ITEM” WINDOW ............................................................................73
ILLUSTRATION 42, “EDIT MENU ITEM” WINDOW ............................................................................74
ILLUSTRATION 43, MENU ITEM DELETE CONFIRMATION BOX.....................................................74
ILLUSTRATION 44, “APPLICATION” TAB..........................................................................................75
ILLUSTRATION 45, "RESOURCE LIBRARY" TAB.............................................................................77
ILLUSTRATION 46, “COLOR/SCHEDULES” TAB ..............................................................................78
ILLUSTRATION 47, “COLOR/CONTROL PANEL” TAB WINDOW .....................................................79
ILLUSTRATION 48, EXAMPLE OF EVENT PROPERTIES WINDOW ...............................................80
ILLUSTRATION 49, “EVENT EDITOR” TAB WINDOW.......................................................................81
ILLUSTRATION 50, “RESOURCE VIEW” TAB WINDOW ..................................................................82
ILLUSTRATION 51, “SCHEDULE” TAB WINDOW .............................................................................84
ILLUSTRATION 52, MINI-T-NX INTERNAL SWITCHER WINDOWS .................................................85
ILLUSTRATION 53, MINI-T-NX “SYSTEM CONFIGURATION VIEW” IR PORT WINDOWS ..............88
TABLE 11, IR PORT CONFIGURATION OPTIONS............................................................................88
ILLUSTRATION 54, MINI-T-NX “SYSTEM CONFIGURATION VIEW” INTERNAL MPEG RECORDER
WINDOWS.........................................................................................................................................90
ILLUSTRATION 55, “DEVICES” WINDOW.........................................................................................91
ILLUSTRATION 56, MPEG RECORDER PROPERTIES....................................................................93
ILLUSTRATION 57, NEW DEVICE PROPERTIES.............................................................................95

Page 8
LEIGHTRONIX, INC.
WinLGX ver. 6.0.1.48
2018-06-08
ILLUSTRATION 58, DVD DEVICE EVENT PROPERTIES WINDOW.................................................96
TABLE 12, DVD DEVICE PROPERTIES ............................................................................................96
ILLUSTRATION 59, TAPE DEVICE EVENT PROPERTIES WINDOW ...............................................98
TABLE 13, TAPE DEVICE PROPERTIES...........................................................................................98
ILLUSTRATION 60, SWITCH EVENT PROPERTIES WINDOW.......................................................100
TABLE 14, SWITCH EVENT PROPERTIES .....................................................................................100
ILLUSTRATION 61, GPI EVENT PROPERTIES WINDOW ..............................................................102
TABLE 15, GPI EVENT PROPERTIES.............................................................................................102
ILLUSTRATION 62, “LIBRARY VIEW” WINDOWS ...........................................................................104
ILLUSTRATION 63, NEW LIBRARY RESOURCE WINDOWS .........................................................105
ILLUSTRATION 64, EXAMPLE OF DVD LIBRARY RESOURCE PROPERTIES..............................106
TABLE 16, IR OR PRO-BUS-CONTROLLED LIBRARY RESOURCE PROPERTIES .......................106
ILLUSTRATION 65, EXAMPLE OF SWITCH LIBRARY RESOURCE PROPERTIES........................108
TABLE 17, SWITCH LIBRARY RESOURCE PROPERTIES.............................................................109
ILLUSTRATION 66, MPEG LIBRARY RESOURCE PROPERTIES...................................................110
TABLE 18, MPEG LIBRARY RESOURCE PROPERTIES.................................................................111
ILLUSTRATION 67, “SELECT FILE” WINDOW ................................................................................111
ILLUSTRATION 68, “FILE PROPERTIES” WINDOW .......................................................................112
ILLUSTRATION 69, MPEG LOOP LIBRARY RESOURCE PROPERTIES........................................115
TABLE 19, MPEG LOOP LIBRARY RESOURCE PROPERTIES......................................................115
ILLUSTRATION 70, “SELECT FILE” WINDOW ................................................................................116
ILLUSTRATION 71, “FILE PROPERTIES” WINDOW .......................................................................117
ILLUSTRATION 72, MPEG LOOP CALCULATOR............................................................................117
ILLUSTRATION 73, SLIDE LIBRARY RESOURCE PROPERTIES...................................................119
TABLE 20, SLIDE LIBRARY RESOURCE PROPERTIES.................................................................120
ILLUSTRATION 74, “SELECT SLIDE” WINDOW ..............................................................................120
ILLUSTRATION 75, SLIDE SHOW LIBRARY RESOURCE PROPERTIES.......................................122
TABLE 21, SLIDE SHOW LIBRARY RESOURCE PROPERTIES.....................................................123
ILLUSTRATION 76, “USER LIST” WINDOW ....................................................................................124
ILLUSTRATION 77, PLAYLIST LIBRARY RESOURCE PROPERTIES.............................................126
ILLUSTRATION 78, “PLAYLIST EDITOR” WINDOW ........................................................................126
TABLE 22, PLAYLIST LIBRARY RESOURCE PROPERTIES...........................................................127
ILLUSTRATION 79, “MINI-T-NX SITE MANAGER” WINDOW...........................................................130
ILLUSTRATION 80, ABOUT WINLGX WINDOW..............................................................................132
ILLUSTRATION 81, “SELECT EXPORT/PRINT TEMPLATE” WINDOW ...........................................133
ILLUSTRATION 82, “SAVE AS” WINDOW .......................................................................................134

LEIGHTRONIX, INC.
Page 9
2018-06-08
WinLGX ver. 6.0.1.48
ILLUSTRATION 83, “SELECT EXPORT/PRINT TEMPLATE” WINDOW ..........................................135
ILLUSTRATION 84, WINLGX EXIT DIALOG BOX ...........................................................................136
ILLUSTRATION 85, OPEN IMAGE FILE WINDOW .........................................................................138
ILLUSTRATION 86, OPEN IMAGE FILE AS NEW WINDOW ..........................................................139
ILLUSTRATION 87, IMAGE STATUS WINDOW ..............................................................................139
ILLUSTRATION 88, “SAVE AS” WINDOW .......................................................................................141
ILLUSTRATION 89, SCHEDULE WINDOW .....................................................................................142
ILLUSTRATION 90, WINLGX-LT TAB EVENT WINDOW.................................................................144
TABLE 23, CONTROLLER TAB CONFIGURATIONS.......................................................................145
TABLE 24, SCHEDULE COLUMNS .................................................................................................145
ILLUSTRATION 91, DAY/CHANNEL OUTPUT EVENT PROPERTIES BOX ....................................148
ILLUSTRATION 92, WINLGX-LT EVENT PROPERTIES BOX.........................................................149
ILLUSTRATION 93, DELETE DIALOG BOX.....................................................................................151
ILLUSTRATION 94, PLAYLIST DELETE DIALOG BOX...................................................................152
ILLUSTRATION 95, "REPLACE" BUTTON ON EVENT PROPERTIES WINDOW............................153
ILLUSTRATION 96, "FIND AND REPLACE" WINDOW....................................................................154
ILLUSTRATION 97, "INSERT" BUTTON ON EVENT PROPERTIES WINDOW ...............................155
ILLUSTRATION 98, DVD DEVICE EVENT PROPERTIES WINDOW...............................................156
TABLE 25, EDITABLE DVD DEVICE PROPERTIES........................................................................156
ILLUSTRATION 99, TAPE DEVICE EVENT PROPERTIES WINDOW.............................................158
TABLE 26, EDITABLE TAPE DEVICE PROPERTIES......................................................................158
ILLUSTRATION 100, SWITCH DEVICE EVENT PROPERTIES WINDOW ......................................160
TABLE 27, EDITABLE SWITCH DEVICE EVENT PROPERTIES.....................................................160
ILLUSTRATION 101, GPI OUTPUT DEVICE EVENT PROPERTIES WINDOW...............................162
TABLE 28, EDITABLE GPI OUTPUT DEVICE EVENT PROPERTIES .............................................162
ILLUSTRATION 102, MPEG PLAYER EVENT PROPERTIES WINDOW.........................................164
TABLE 29, EDITABLE MPEG PLAYER EVENT PROPERTIES .......................................................164
ILLUSTRATION 103, MPEG RECORDER EVENT PROPERTIES WINDOW...................................168
TABLE 30, EDITABLE MPEG RECORDER EVENT PROPERTIES .................................................169
ILLUSTRATION 104, “ADD TO LIBRARY FOLDER” WINDOW........................................................169
ILLUSTRATION 105, EXAMPLE OF DVD EVENT PROPERTIES WINDOW ...................................172
TABLE 31, EDITABLE TAPE AND DVD LIBRARY EVENT PROPERTIES.......................................172
ILLUSTRATION 106, SWITCH EVENT PROPERTIES WINDOW ....................................................174
TABLE 32, EDITABLE SWITCH EVENT PROPERTIES...................................................................174
ILLUSTRATION 107, JPEG SLIDE EVENT PROPERTIES WINDOW..............................................176
TABLE 33, EDITABLE JPEG SLIDE LIBRARY EVENT PROPERTIES............................................176

Page 10
LEIGHTRONIX, INC.
WinLGX ver. 6.0.1.48
2018-06-08
ILLUSTRATION 108, JPEG SLIDE SHOW EVENT PROPERTIES WINDOW..................................178
TABLE 34, EDITABLE JPEG SLIDE SHOW LIBRARY EVENT PROPERTIES.................................178
ILLUSTRATION 109, MPEG LIBRARY EVENT PROPERTIES WINDOW ........................................180
TABLE 35, EDITABLE MPEG LIBRARY EVENT PROPERTIES.......................................................180
ILLUSTRATION 110, MPEG LOOP EVENT PROPERTIES WINDOW .............................................183
TABLE 36, EDITABLE MPEG LOOP LIBRARY EVENT PROPERTIES............................................183
ILLUSTRATION 111, PLAYLIST EVENT PROPERTIES WINDOW ..................................................186
ILLUSTRATION 112, DIGITAL LIBRARY RESOURCE DRAGGED INTO SCHEDULE PROGRAM
INTERVAL ........................................................................................................................................187
ILLUSTRATION 113, DIGITAL LIBRARY RESOURCE APPLY TO ALL SWITCHBACKS OPTION ..188
ILLUSTRATION 114, "CHANNEL SWITCHBACK EDITOR"..............................................................188
ILLUSTRATION 115, SYNCED SCHEDULE.....................................................................................190
ILLUSTRATION 116, “SEND IMAGE” STATUS BOX........................................................................191
ILLUSTRATION 117, CONTROL PANEL WINDOW .........................................................................192
ILLUSTRATION 118, CONTROL PANEL DEVICE SORTING MENU................................................193
ILLUSTRATION 119, SWITCH CONTROL PANEL FOR INTERNAL SWITCHER.............................193
ILLUSTRATION 120, SWITCHING TO THE “PREVIEW” OUTPUT...................................................194
ILLUSTRATION 121, MPEG PLAYER CONTROL PANEL................................................................194
ILLUSTRATION 122, “SELECT FILE” VIDEO WINDOW ..................................................................195
ILLUSTRATION 123, “FILE PROPERTIES” WINDOW .....................................................................196
ILLUSTRATION 124, QUEUED MPEG VIDEO FILE PROPERTIES.................................................196
ILLUSTRATION 125, “SELECT FILE” SLIDE WINDOW ...................................................................197
ILLUSTRATION 126, QUEUED JPEG SLIDE...................................................................................197
ILLUSTRATION 127, MPEG FILE COUNTER...................................................................................198
ILLUSTRATION 128, QUEUED AND CURRENTLY PLAYING FILES...............................................198
ILLUSTRATION 129, MPEG FILE COUNTER WITH FRAME NUMBER DISPLAYED ......................199
ILLUSTRATION 130, MPEG PLAYER CLIP CREATION PANEL......................................................199
ILLUSTRATION 131, “SELECT FILE” WINDOW ..............................................................................200
ILLUSTRATION 132, “ADD TO LIBRARY FOLDER” WINDOW ........................................................201
ILLUSTRATION 133, MPEG RECORDER CONTROL PANEL..........................................................201
ILLUSTRATION 134, “ADD TO LIBRARY FOLDER” WINDOW ........................................................203
ILLUSTRATION 135, “MPEG INGEST” WINDOW ............................................................................204
ILLUSTRATION 136, EXAMPLE OF A PRO-BUS-CONTROLLED DEVICE CONTROL PANEL.......205
ILLUSTRATION 137, CONTROL PANEL: GPI DEVICE CONTROL..................................................206
ILLUSTRATION 138, STORAGE MANAGER WINDOW...................................................................208
ILLUSTRATION 139, STORAGE MANAGER COPY DIALOG BOX..................................................209

LEIGHTRONIX, INC.
Page 11
2018-06-08
WinLGX ver. 6.0.1.48
ILLUSTRATION 140, SELECT LOCAL SLIDE STORAGE AREA.....................................................211
ILLUSTRATION 141, SELECT SLIDE USER FOLDER....................................................................212
ILLUSTRATION 142, TRANSFER SLIDE TO USER FOLDER .........................................................212
ILLUSTRATION 143, SLIDE SHOW AUTHORIZE AND ENABLE OPTIONS ...................................213
ILLUSTRATION 144, "SELECT CONTROLLER LOG FILE" WINDOW ............................................214
ILLUSTRATION 145, EXAMPLE OF EVENT LOG FILE...................................................................215
ILLUSTRATION 146, “SYSTEM” TAB ON THE “SELECT CONTROLLER LOG FILE” WINDOW .....216
ILLUSTRATION 147, EXAMPLE OF LOG FILE ...............................................................................217
ILLUSTRATION 148, CONTROLLER WINDOW ..............................................................................219
ILLUSTRATION 149, “CHOOSE CONTROLLER FIRMWARE FILE” WINDOW ...............................220
ILLUSTRATION 150, “CONTROLLER” WINDOW WITH SELECTED MINI-T-NX FIRMWARE FILE 221
ILLUSTRATION 151, FILE PATH FIELD FOR MINI-T-NX TOTAL BACKUP.....................................226
ILLUSTRATION 152, “MINI-T-NX TOTAL BACKUP” WINDOW........................................................227
ILLUSTRATION 153, BACKUP PATH WINDOW..............................................................................228
ILLUSTRATION 154, “BACKUP SCHEDULER” WINDOW...............................................................229
ILLUSTRATION 155, “RESTORE” WINDOW ...................................................................................230
ILLUSTRATION 156, TOTAL IMPORT MAIN WINDOW...................................................................231
ILLUSTRATION 157, TOTAL IMPORT DVD “SOURCE” PANEL ......................................................232
ILLUSTRATION 158, TOTAL IMPORT "SETTINGS" PANEL WITH SELECTABLE VIDEO BIT RATE232
ILLUSTRATION 159, TOTAL IMPORT "DESTINATION" PANEL......................................................233
ILLUSTRATION 160, PRO-BUS INTERFACE ..................................................................................234
TABLE 37, PRO-BUS ADDRESS CONFIGURATION.......................................................................234
ILLUSTRATION 161, PRO-BUS DAISY CHAIN................................................................................235

Page 12
LEIGHTRONIX, INC.
WinLGX ver. 6.0.1.48
2018-06-08
ABOUT THIS MANUAL
New users are recommended to follow this manual in order, as each
section builds on the information introduced in previous sections. Check
the glossary in the back of this manual for quick explanations of
unfamiliar terms. An index has also been included for your convenience.
First Time Install Checklist
Not sure where to start? The following checklist provides the bare bones steps necessary
to get your MINI-T-NX system up and running.

TASK
Install MINI-T-NX System (for an overview, refer to the MINI-T-NX Installation
Quick Guide):
1. Connect MINI-T-NX signal wiring (see “Connecting Signal Wiring,” on page
35).
Route video/audio sources to switcher input connectors.
Route destinations (such as a modulators and preview monitor) to switcher
output connectors.
Set up video/audio sources to receive MINI-T-NX control commands via
PRO-BUS or integrated IR as appropriate.
2. Connect MINI-T-NX to an Ethernet TCP/IP network (see “Configuring
Ethernet Network Host Management,” on page 37).
3. Enter TCP/IP addresses into MINI-T-NX front panel (see “Configuring Front
Panel Settings,” on page 39).
Install & Configure MINI-T-NX Control Software, WinLGX (for an overview, refer to
the WinLGX Installation & Configuration Quick Guide):
4. Load WinLGX software on a PC workstation (see “Installing WinLGX
Software,” on page 44).
5. Add your MINI-T-NX’s IP address to the “Locations” database (see “Adding /
Deleting MINI-T-NX Locations in the Site Manager,” on page 46). If the “Add
new controller” dialog box does not display your MINI-T-NX server’s serial
number, check your IP address and network connections and try again.
6. Log into WinLGX (see “Connecting to Your MINI-T-NX Server/Controller,” on
page 48). If the “Add new MINI-T-NX” dialog box does not display your MINI-
T-NX’s serial number, check your IP address and network connections and try
again.
7. Create user accounts and assign rights (see “Setting User Account Rights
(Including WinLGX Password Changes)” on page 61).

LEIGHTRONIX, INC.
Page 13
2018-06-08
WinLGX ver. 6.0.1.48

TASK
8. Set time zone and clock (see “Configuring Site Information, Clock, Updating
Firmware, and Rebooting,” on page 66).
9. Configure the MINI-T-NX’s system properties (see “Configuring MINI-T-NX
System’s Switcher Properties,” on page 85) and IR ports (see “Configuring
MINI-T-NX IR Port Properties,” on page 88).
10.Configure the following device properties:
Internal (see “
Configuring MPEG Recording Presets,” on page 90 and “Editing Internal
MPEG Player and Recorder Device Resources,” on page 91)
External (see “Creating External Device Resources,” on page 95)
11.Check PRO-BUS interface, IR port, and switcher wiring by sending a
command to each device from the control panel as follows:
a. Select a device controlled by a PRO-BUS interface, or IR port in the left-
hand “Device” column on the control panel window.
b. Send a command to the selected device from the “Device control” section
of the control panel and ensure the device itself responds accordingly (see
“Using Control Panel to Perform Immediate Device and Switch Actions,”
on page 192).
NOTE: To check video quality, switch your device to an output
connected to a monitor.
12.Upload slides to the MINI-T-NX user folders through the WinLGX Storage
Manager window and enable/authorize for display in slide shows (see
“Managing SLIDES: Uploading to the MINI-T-NX and Authorizing for Display,”
on page 211 or for an overview, refer to the WinLGX Slide Management
Quick Guide).
NOTE: Slides are displayed through the WinLGX schedule or control
panel.
13.Pre-program any device and switch resources under the “Library” tab (see
“Creating Library Resources,” on page 104).
14.Save your system configuration settings and resources in a MINI-T-NX image
file (see “Saving MINI-T-NX Image Files,” on page 140).

Page 14
LEIGHTRONIX, INC.
WinLGX ver. 6.0.1.48
2018-06-08

TASK
Use WinLGX to Control MINI-T-NX System (for an overview, refer to the WinLGX
Scheduling Quick Guide):
15.If not already open, load a MINI-T-NX image file (see “Opening MINI-T-NX
Image Files,” on page 137).
16.Control MINI-T-NX system through either of the following:
Create & execute a schedule.
Immediately control devices through control panel.

MINI-T-NX
Introduction
LEIGHTRONIX, INC.
Page 15
2018-06-08
WinLGX ver. 6.0.1.48
INTRODUCTION
The LEIGHTRONIX MINI-T-NX combines digital video server technology, DVD and VCR
control, video/audio switching, and digital video messaging in one rack-mountable chassis.
The MINI-T-NX provides fullyintegrated digital video playback and an MPEG recorder
option, while providing support for your legacy equipment. Provided with the MINI-T-NX is
WinLGX, a software application with a programmable database of events for unattended,
automated control. When the MINI-T-NX “sees” a match between the current day and
time and a programmed event, the event is executed.
Your LEIGHTRONIX MINI-T-NX Controller is designed to be used in a host of different
applications, including the following scenarios:
AUTOMATED PROGRAM BROADCASTING AND DIGITAL VIDEO MESSAGING
MINI-T-NX Controllers are intended for use throughout the cable television and
broadcast industry for automated program broadcasting. Common industry
branches include low-power television (LPTV), master-antenna television (MATV),
and locally originated cable television channels such as public access, educational
access, government access, and leased access.
In addition, MINI-T-NX Controllers may be used for private in-house networks, as
found in hospitals, hotel and resort channels, or corporate and manufacturing
communications channels. With MINI-T-NX Controllers, these institutions would be
able to automatically feed programming, video signals such as character generators,
and JPEG slides to the desired channel at the proper time.
UNATTENDED PROGRAM RECORDING
MINI-T-NX Controllers are well suited for use in satellite and network recording.
With a MINI-T-NX Controller, you are able to switch to the proper satellite at the
desired time in order to capture the programming you need for your operations.
MINI-T-NX Controllers may also be used for playback verification and program
archiving.
TIMED EVENT SWITCHING
MINI-T-NX Controllers are designed to accommodate complex switching tasks, such
as Syndex Switching, channel wild-card switching, and channel sharing. This
expands the flexibility of your channels and your programming opportunities.
Perform Syndex Switching by scheduling your MINI-T-NX to switch syndicated
programming to only the channels with the corresponding syndication rights. Use
your MINI-T-NX to switch a different satellite signal to a channel in a process known
as channel sharing or perform wild-card sharing by switching to any available source
on a channel.

MINI-T-NX
Introduction
Page 16
LEIGHTRONIX, INC.
WinLGX ver. 6.0.1.48
2018-06-08
SAFETY INSTRUCTIONS
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with dry cloth.
7. Do not block any ventilation openings. Install in accordance with the manufacturer’s
instructions.
8. Do not install near any heat sources such as radiators, heat registers, stoves, or other
apparatus (including amplifiers) that produce heat.
9. Do not defeat the safety purpose of the grounding-type plug. A grounding-type plug
has two blades and a third grounding prong. The third prong is provided for your
safety. If the provided plug does not fit into your outlet, consult an electrician for
replacement of the obsolete outlet.
10.Protect the power cord from being walked on or pinched particularly at the plugs,
convenience receptacles, and the point where they exit from the apparatus.
11.Only use attachments/accessories specified by the manufacturer.
12.Unplug this apparatus during lightning storms or when unused for long periods of time.
13.Refer all servicing to qualified service personnel. Servicing is required when the
apparatus has been damaged in any way, such as power-supply cord or plug is
damaged, liquid has been spilled or objects have fallen into the apparatus, the
apparatus has been exposed to rain or moisture, does not operate normally, or has
been dropped.
14.When the apparatus is turned off, certain components in the power supply and system
board remain energized. In order to remove all electrical power from the apparatus,
unplug the power cord from the MAINS socket outlet.
WARNING
To reduce the risk of electric shock, do not expose this apparatus to
rain or moisture.
WARNING
This apparatus must be connected to a MAINS socket outlet with a
protective earthing connection.

MINI-T-NX
Introduction
LEIGHTRONIX, INC.
Page 17
2018-06-08
WinLGX ver. 6.0.1.48
MINI-T-NX CONTROLLER FEATURES/SPECIFICATIONS
NOTE: In no event shall LEIGHTRONIX be liable for any damages whatsoever
resulting from loss of use, data, or profits, whether or not advised of the
possibility of damage, and on any theory of liability, arising out of or in
connection with the use or performance of the MINI-T-NX Controller and
WinLGX software.
FEATURE
SPECIFICATIONS
Dimensions
1.75"H X 19.00"W X 8.25"D
Weight, without carton or
cables
8 lbs.
Display
2 X 24 character vacuum fluorescent display
Keypad
Four pushbuttons which allow password protected front
panel status and configuration
Power
12VDC regulated input with locking coaxial power
connector
External AC power adapter accepts 100–240VAC @
50–60Hz
AC power consumption 25 watts @ 120VAC
Product Safety Certifications
Certified and listed as:
Audio, Video and Similar Electronic Apparatus Safety
Requirements ANSI/UL 60065, 7th edition
Audio, Video and Similar Electronic Apparatus Safety
requirements CAN/CSA C22.2 No. 60065:03, 1st
edition
Compliance
FCC Part 15
Internal Clock
Temperature compensated crystal oscillator
Battery-backed time and date
Internal Memory
Type:
Internal battery-backed memory
Data integrity verified
Stores the following:
IP address
Subnet mask
Gateway
Time clock parameters
User login and rights information
Schedule information sent to MINI-T-NX

MINI-T-NX
Introduction
Page 18
LEIGHTRONIX, INC.
WinLGX ver. 6.0.1.48
2018-06-08
FEATURE
SPECIFICATIONS
Up to 300 JPEG slides
Ethernet Network Host
Management
Remote Support: Dial-up Networking
Network Support Interface:
Eight-position, eight-conductor RJ-45 modular jack,
10/100 BASE-T, unshielded twisted pair, Ethernet
Ethernet_II frame type
Protocol: TCP/IP
Services: Telnet
Maximum simultaneous network connections: four
Logging: internal
Firmware
Updateable via Ethernet
Cycle redundancy check (CRC) verified at time of
reprogram
WinLGX Software
Compatible with Windows®2000/XP operating systems
Control modes:
Drag and drop event scheduling with error/conflict
reporting
System control panel for immediate control
Schedule event capacity: 3000
Library holds up to 2000 resources
CONTROL FEATURES
FEATURE
SPECIFICATIONS
Internal MPEG File Storage
250 GB hard drive
Internal Switcher
8x2 internal switcher, includes:
7 external video/audio inputs for source switching
Input 8 internally tied to MPEG Player
Output 1: external video/audio output for on-air display
Output 2: external video/audio output shared by the
internal MINI-T-NX MPEG Recorder and the “Preview”
video/audio ports on the rear panel of the MINI-T-NX.
Programming on any input scheduled for MPEG
recording or manually switched to Output 2, labeled
“Rec/Prev” in WinLGX, will display on a monitor
connected to the “Preview” ports.
NOTE: Output 2 cannot be scheduled to display
