INSTRUCTIONS FOR USE
LEITZ SHREDDERS
IQ OFFICE PRO P6+ / P5+ / P5 / P4
ةيبرعلا 100

www.leitz.com
For service addresses, go to www.leitz.com
Specifications
Model IQ Office Pro P6+ IQ Office Pro P5+ IQ Office Pro P5 IQ Office Pro P4
Cut level P6 P5 P5 P4
Sheet Capacity 5 sheets (80 gsm) 7 sheets (80 gsm) 15 sheets (80 gsm) 20 sheets (80 gsm)
Duty Cycle 240 mins on / 60 mins o 240 mins on / 60 mins o 240 mins on / 60 mins o 240 mins on / 60 mins o
Bin Size 30 litres 30 litres 30 litres 30 litres
Volts / Hz 220-240V AC / 50Hz 220-240V AC / 50Hz 220-240V AC / 50Hz 220-240V AC / 50Hz
Amperage 2.3A 2.3A 2.3A 2.3A

IQOceProP6+:>5
IQOceProP5+:>7
IQOceProP5:>15
IQOceProP4:>20
IQOceProP6+:≤5
IQOceProP5+:≤7
IQOceProP5:≤15
IQOceProP4:≤20

4
• Only use the unit for its intended purpose.
• The unit must only be connected to a supply voltage
corresponding to the electrical rating shown on the unit.
• Unit should be connected to a socket outlet near the equipment
that is easily accessible.
• Do not connect multiple adaptors or use with an extension
cable.
• Failure to follow these instructions could result in damage/injury
and will invalidate your guarantee.
• Do not attempt to service or repair the unit yourself.
• If recycling, separate paper and credit card shreds.
• Do not use this unit if the cable or plug have been damaged.
• Care should be taken when moving equipment to avoid any
unleveled surfaces.
• Please read all the safety information and the instructions.
The manufacturer is not liable for cases of material damage or
personal injury caused by incorrect handling or non compliance
with the safety instructions. In such cases, the warranty will be
voided.
• The device is intended for use indoors. Never use outdoors.
• Keep the device away from moisture.
• Be vigilant at all times, and always be careful what you are
doing. Do not use electrical equipment if you are lacking in
concentration or awareness, or are under the influence of drugs,
alcohol or medication. Even a moment of inattentiveness can
lead to serious and injuries when using electrical equipment.
• Do not attempt to open, modify or repair the device. Do not
drop, puncture, break or expose to high pressure.
• Alterations to the device and technical modifications are not
permitted.
• Check the device and cable (and if applicable, the adapter) for
any damage before use. If there is any visible damage, a strong
odour, or excessive overheating of components, unplug all the
components immediately and stop using the device.
• Shredder must be disconnected from power source, if not used
for an extended period of time.
• Do not use spray cleaners or spray lubricants as these may
present a risk of flash fire.
Never bypass the safety interlock (strictly forbidden &
dangerous, especially when unit is connected to a power source)
The following symbol which is
found on the product indicates
you could be seriously hurt or
killed if you open the machine.
DO NOT OPEN.
WARNING
Please read and keep these
important safety instructions
For hints & tips or troubleshooting guide, please visit
www.leitz.com
Overview
a Indicator panel
b Pull-out bin
c Bin viewing window
d Safety symbols
e Paper feed slot
f On/O switch
g Casters
Warning:
Sharp edges, do NOT touch cutters
Warning:
Moving parts, do NOT touch cutters
f
e
c
b
a
d
g
Fit casters
Castors have been provided on this model to allow you easily
change location of the shredder.
1. Turn the shredder upside down.
2. Place one castor in the location hole in each corner.
3. Push the castor into position (you will feel a positive click when
they are in position).
4. Return the shredder to upright position.

555
Keep loose jewellery clear
Ties and loose clothing hazard
No credit cards
Warning symbols
Keep long hair clear
Do not reach into opening
This equipment is not intended for use by children
No CDs
Manual feed slot capacity
Indicator Panel Icon Colour
Power On
BUTTON
White Press and
release to turn on
shredder.
Reserve BUTTON Press and hold to
manually remove
paper.
Shredding
in operation
INDICATOR
Blue Constantly
illuminated –
unless in Power
Save mode.
Cooling Down
INDICATOR
Red Illuminates when
shredder is cooling
Auto jam
clearance
INDICATOR
Red Flashes when
motor is in reverse
Bin full
INDICATOR
Red Illuminates when
bin is full
Door open
INDICATOR
Red illuminates when
door is open
Operation
1. Remove the shredder from the packaging and place the bin
inside the shredder housing. Put the casters in place and plug
the power cord into the rear of the shredder.
2. Connect the shredder to an appropriate mains supply.
Ensure the on/o switch is in the ‘on’ position. The blue
shredder in operation icon will flash every 3 seconds.
3. To commence shredding press and release the button. The
flashing icon changes to a solid blue light. You are now able
to shred.
4. Insert paper to be shredded into the feed slot ‘e’.
While paper is being shredded the blue shredder in operation
icon will remain illuminated.
Note: Make sure the paper to be inserted is neatly stacked.
If the paper thickness is within the shredder’s capacity, the
motor will start and your documents will be shredded. The
cutters will stop once the shredding process is complete.
5. If the paper thickness is greater than the shredder’s capacity
the auto reverse icon will flash red and the motor will run in
reverse.
6. If this happens, remove some of the sheets from the paper
stack and re-try. The shredder will automatically start and allow
the paper to be shredded.
7. If the shredder is left in shredder operational mode for
more than 15 minutes without being used the shredder will
automatically switch o in order to save power.
Warning: Do NOT under any circumstances use any
metal objects (scissors, letter openers, etc.) in an attempt
to clear the entry.
Quiet shredding
This shredder has been designed with quiet shredding technology.
This allows you to shred with peace of mind you will not disturb
others.
Do not use spray cleaners or spray lubricants as these
may present a risk of flash fire
Operation time
When the shredder is used continuously for 120 minutes or more
the shredder may overheat. If this occurs the overheat icon will
illuminate red.
When the shredder is ready to be used again the red overheat icon
will go out. This will take approx. 60 minutes.
To resume shredding, press the On button and start feeding
documents into the feed slot.
Rare occasions of jamming
Should the paper jam not clear, press and hold the button
for 2 seconds, then press and hold the button for 2 seconds.
Repeat until the jam has cleared. Please do not alternate between
the Reverse and Forward functions quickly as this may damage
the motor.
Reverse function
1. Should you wish to reverse the shredding direction whilst
shredding a document a reverse function has been fitted for
your convenience.
2. By pressing and holding the reverse button the cutters will
change direction allowing the retrieval of the document being
shredded.
3. The reverse function will only run whilst is being pressed.
When the reverse button has been released the shredder will
revert to ready mode.
No aerosols

6
Bin full
When the bin is full the shredder will not function and the bin full
symbol will illuminate and flash red.
When this happens you must empty the bin.
Pull out the bin to empty.
Once the bin is empty, push it back in and press the On button to
resume shredding.
WARNING: The shredder bin must be fully pushed
closed for the machine to operate.
• Empty the shredder bin when it is full otherwise the
shredder’s performance will be adversely aected.
Operating the shredder with a full shredder bin can
result in paper jamming in the cutters, which will
increase the machine’s noise level.
• Do not force down shredder paper in the bin using
your feet.
Troubleshooting
If the paper shredder will not start, please check the following:
1. Is the machine plugged in correctly?
2. Is the switch pushed to the position?
3. Is the machine jammed with paper?
4. Has the motor overheated?
5. Is the shredder bin fully pushed in?
6. Is the shredder door closed?
Door open
If the door is opened during shredding as a safety precaution the
shredder will instantly stop, and the door open symbol on the
indicator panel will flash red.
To resume shredding, shut the door and press the button.
WARNING
• The shredder DOOR must be fully pushed closed for the
machine to operate.
IQ Office Pro P6+/P5+/P5/P4 shredding capability
CAN shred the following:
• IQ Office Pro P6+: 5 sheets
IQ Office Pro P5+: 7 sheets
IQ Office Pro P5: 15 sheets
IQ Office Pro P4: 20 sheets
• Stapled paper, 25mm within the corner
• 26/6 and 24/6 or smaller staples
• Small sized paper
• IQ Office Pro P6+: 5 sheets
IQ Office Pro P5+: 7 sheets
IQ Office Pro P5: 15 sheets
IQ Office Pro P4: 20 sheets
• Paperclipped paper, 25mm within the corner
• Capable of shredding small/medium paperclips
(max. wire thickness = 0.9 mm)
• >80/100gsm paper
Thick paper or card
<200gsm
Multiple folded sheets
(A3 sheets folded in half).
Glossy paper or a sheet
covered with print on both
sides.
CANNOT shred the following:
Magazines or other
documents bound by
multiple staples or clips.
Adhesive labels.
Large clips. Check the
length of the paperclip is
not longer than 32mm.
Heavy duty staples. Check
the staple leg length is not
greater than 6mm.
Plastic sheets, laminated
documents, plastic
folders.
CDs & DVDsNo aerosols No oil
Bound documents
Bulldog clips Credit cards
