Lemo 0F Series User manual

©2003 LEMO USA, Inc. 9/03
If you have any
questions or
require customer
assistance, please
contact us directly
at [phone]. LEMO USA, Inc.
635 Park Court, Rohnert Park, CA 94928
P.O. Box 2408, Rohnert Park, CA 94927-2408
[phone] • [phone] • fax: [phone]
www.LEMOusa.com • e-mail: [email protected]
2.3 For shielded cables, put the shield braid over the rear of the con-
nector. Cut off possible surplus. Use a band-it tie wrap to fix the
braid in place (See below for recommended tie-wrap and banding
tool).
600-061 A30199 ACDBS100
600-057 A31189 AXCL0Z
Part number
GLEN-AIR®TIE-DEX®AXON®
FF
F
321
FGN
14±0.5
3±0.2 1
Crimp
2
3
Tie wrap
Heat
1. Cable preparation
First, place the heatshrink boot ➀on the cable. Strip the
individual conductors according to the indicated dimensions and
flare the shield braid.
2. Cable termination
2.1 Fix the appropriate positioner in the crimping tool and set the
selector to the number corresponding to the conductor AWG as
indicated on the positioner label. Fit conductor into contact ➁and
make sure it is visible through the inspection hole in the crimp
barrel. Open crimping tool then push contact fully into positioner
and complete one crimping cycle. Remove from crimping tool and
check that conductor is secure in contact and shows in inspection
hole.
2.2 Slide the assembly into the connector shell ➂.
Arrange the contacts according to the marking, then push them
into the insulator, make sure the contacts are in place by gently
pulling on the cable. Fill up the back of the cabling chamber with
compound RTV silicone.
2.4 Put the heatshrink boot in place and heat gently until it retracts.
Banding tool
Tie wrap

©2003 LEMO USA, Inc. 9/03
If you have any
questions or
require customer
assistance, please
contact us directly
at [phone]. LEMO USA, Inc.
635 Park Court, Rohnert Park, CA 94928
P.O. Box 2408, Rohnert Park, CA 94927-2408
[phone] • [phone] • fax: [phone]
www.LEMOusa.com • e-mail: [email protected]
2.3 For shielded cables, put the shield braid over the rear of the
connector. Cut off possible surplus. Use a band-it tie wrap to
fix the braid in place (See below for recommended tie-wrap and
banding tool).
600-061 A30199 ACDBS100
600-057 A31189 AXCL0Z
Part number
GLEN-AIR®TIE-DEX®AXON®
Assembly instructions for 0F to 5F series
Series TL
0F
1F
2F
3F
4F
5F
414
414
414
414
414
414
3
3
2
2
3
1
1
FGN
PHN
PEN
L±0.5
T±0.2 1
Crimp
2
Crimp
2
3
3
Tie wrap
Tie wrap
Heat Heat
1. Cable preparation
First place the heatshrink boot ➀on
the cable. Strip the cable according to
dimensions of the table, then flare the
shield braid.
2. Cable termination
2.1 Fix the appropriate positioner in the crimping tool and set the
selector to the number corresponding to the conductorAWG as
indicated on the positioner label. Fit conductor into contact ➁
and make sure it is visible through the inspection hole in the
crimp barrel.
Open crimping tool then push contact fully into positioner and
complete one crimping cycle. Remove from crimping tool and
check that conductor is secure in contact and shows in inspec-
tion hole.
2.2 Slide the assembly into the connector shell ➂.
Arrange the contacts according to the marking, then push them
into the insulator, make sure the contacts are in place by gen-
tly pulling on the cable.
2.4 Put the heatshrink boot in place and heat gently until it retracts.
0F - 5F
Banding tool
Tie wrap
