LENCO DVD-30K User manual

DVD-30K
COMPACT
DIGITAL AUDIO
COMPACT
DIGITALAUDIO
POWER
DVD-30K
USB
OPEN/CLOSE
L/R

Remote Control
Table of Contents…………………………...………………………1-2
Remote Control…………………………...…………………………3
Front And Back Panel…………………….….…….……………….4
Chapter 1 Basic Operation…………………….….…….…………5
1. Turn On the TV and MPEG 4 DVD Player…………………….………..……………5
2. Place a disc onto the tray.………………………………………………………………5
3. Play the disc……………………………………………………………………………5-6
a) Menu Play (compatible with MPEG 4, DVD, SVCD, VCD2.0 discs)…………5-6
b) Title Play (compatible with MPEG 4 and DVD discs only)………………………6
c) Sequence Play (compatible with MPEG 4, DVD, SVCD, VCD, DTS-CD,
HD-CD, WMA, MP3/JPEG discs)………………………………………………… 6
d) Program Play (compatible with MPEG 4, DVD, SVCD, VCD, CD, DTS-CD,
HD-CD, WMA, MP3/JPEG discs)………………………………………………….6
Chapter 2 Additional Operation…………………………………7-11
1. Selecting Tracks (compatible with MPEG 4, DVD, SVCD, VCD, CD, DTS-CD,
HD-CD, WMA, MP3/JPEG discs)………………………………………………………….7
2. Skipping Tracks (compatible with MPEG 4, DVD, SVCD, VCD, CD, DTS-CD,
HD-CD, WMA, MP3/JPEG discs)………………………………………………………….7
3. Multi Speeds Fast Motion Playback (compatible with MPEG 4, DVD, SVCD, VCD,
CD, DTS-CD, WMA, MP3/JPEG discs)………………………………………… …….7-8
4. Multi speed Slow Motion Playback (compatible with MPEG 4, DVD, SVCD, VCD,
CD, DTS-CD, HD-CD, WMA, MP3/JPEG discs)…………………………………………8
5. USB CD Ripping…………………………………………………………………………..8
6. Decoding function and Encoding from CD/MP3-CD to USB……………………………..8
7. Repeat Feature (compatible with MPEG 4, DVD, SVCD, VCD, CD, DTS-CD, HD-CD,
WMA, MP3/JPEG discs)…………………………………………………………………..8-9
8. Display Feature (OSD) (compatible with MPEG 4, DVD, SVCD, VCD, CD,
DTS-CD, WMA, MP3/JPEG discs)………………………………………………………9
9. Time Feature (compatible with MPEG 4, DVD, SVCD, VCD, CD, DTS-CD,
HD-CD discs)……………………………………………………………….……………9-10
10. Language (compatible with MPEG 4, DVD, SVCD discs)………………………10
11. Subtitle (Sub-T) (compatible with MPEG 4, DVD, SVCD discs)………………10
12. Angle function. (compatible with MPEG 4 and DVD discs)……………………….10
13. TV System (compatible with MPEG 4, DVD, SVCD, VCD, CD, DTS-CD, HD-CD,
WMA, MP3/JPEG discs)………………………………………………………………10-11
14. Mute Feature (compatible with MPEG 4, DVD, SVCD, VCD, CD, DTS-CD,
HD-CD, WMA, MP3/JPEG discs))……………………………………………………….11
1

Remote Control
15. Zoom In/Out the Video Image (compatible with MPEG 4, DVD, SVCD, VCD,
JPEG discs)…………………………………………………………………………….….11
16. Repeat a Specific Segment (compatible with MPEG 4, DVD, SVCD, VCD, CD,
DTS-CD, HD-CD, WMA, MP3 discs)…………………...………………………………11
17 Volume control (compatible with MPEG 4, DVD, SVCD, VCD, CD, DTS-CD, HD-CD,
WMA, MP3/JPEG discs)……………………………………………………………………11
Chapter 3 Playing WMA, MP3 and JPEG discs…………..12-13
Chapter 4 Setup Menu System………………………………14-18
1. General Steps of Setup Menu……………………………………………………………..14
2. Setup Items Introduction. ……………………………………………………………..14-16
a) System Setup………………………………………………………………..14-16
b) Language Setup…………………………………………………………………16
c) Audio Setup…………………………………………………………..………….16
d) Video Setup…….………………………………………………………………..17
e) Speaker Setup…………………………………………………………………..17
f) Digital Setup…………………………………………………………………17-18
Chapter 5 Specification of the MPEG 4 DVD player…………19
1. Types of disc that the MPEG 4 DVD player can play…………………………19
2. LED illustration…………………………….…..…………………………...……………19-20
2

Remote Control
Remote Control
1.POWER
2.ANGLE
3.SUB/COPY
4.TITLE
5.MENU
6.VOL-
7.ENTER
8.LEFT KEY
9.PBC
10.PLAY/PAUSE
11.STOP
12.FWD
13.REV
14.NUMBER KEYS
15.CLEAR
16.PROG
17.REPEAT
18.RETURN
19.N/P
20.L/R
21.OPEN/CLOSE
22.LANGUAGE
23.OSD
24.KARAOKE
25.MUTE
26.UP KEY
27.VOL+
28.RIGHT KEY
29.SETUP
30.DOWN KEY
31.STEP
32.PREV
33.NEXT
34.GOTO
35.ZOOM
36.RAN
37.A-B
38.RESET
39.SLOW
40.IS/PS
3

Front And Back Panel
Front Panel
1.POWER 6.MIC1/2OUTPUT
2. USB 7. PLAY/PAUSE /STOP / NEXT / PREV
3.MIC1/2VOL 8.L/R
4.CDDOOR 9.OPEN/CLOSE
5.LEDDISPLAY
Back panel
1. Y;Cb/Pb;Cr/Pr OUTPUT 5.S-VIDEOOUTPUT
2.VIDEOOUTPUT 6.OPTICALOUTPUT
3.AUDIO2.1CHOUTPUT 7.SCARTOUTPUT
4. COAXIAL OUTPUT
8. POWER
4

Basic Operation
Chapter 1 Basic Operation
1. Turn On the TV and MPGE 4 DVD Player
Press the Power button on the player or on the remote control, and “READ” appears on the
TV screen. If there is no disc in the MPEG 4 DVD player, “No disc” will be displayed on both
the TV screen and the LED.
2. Place a disc onto the tray.
Press the Open / Close button on the remote control or on the front panel of the MPEG 4
DVD player, and “OPEN” appears on the screen. Then place a disc gently onto the tray with
the disc’s label facing up (double-sided discs have content on both sides, so you can place
either side up), and press the Open / Close button again to close the disc tray, “CLOSE”
appears and the player starts to read. Then the disc starts playing automatically. (Note: For
some certain discs, the Play or Enter button should be pressed to start playing.)
3. Play the disc.
The contents of each disc menu vary according to how the disc is authorized and what
features are included. The disc menu will be shown for you to select, when Menu button is
pressed. Also PLAY and PAUSE functions can be switched with the Pause button on the
remote control. Moreover, such as Menu play, Title play, Sequence play etc., these different
play modes are offered.
a) Menu Play (compatible with MPEG 4, DVD, SVCD, VCD2.0 discs)
I. Press Menu Button
zTV screen displays the DVD Root Menu when a MPEG 4 or DVD disc is
loaded.
zWhen a SVCD or VCD 2.0 disc is loaded, SVCD or VCD 2.0 menu will be
displayed on the screen (when Menu Play is off).
zThe default setup of Menu Play is on when a SVCD or VCD2.0 disc is loaded.
II. When a MPEG 4 or DVD disc is loaded, you can press Arrow buttons to highlight
the menu item you want to choose; As a SVCD or VCD2.0, you can press Numeric
buttons to select a track to play.
III. Press Enter or Play button, the disc will play as the highlighted.
IV. Return when playing: When a MPEG 4 or DVD disc is playing, press Menu button,
and you can return to Root Menu; As SVCD, VCD2.0, and Menu Play is on, press
Title button, you can return to the menu.
Notes:
Press Title button to select the Menu Play on/off.
V. Stop
1) When you press Stop button for the first time, the player turns into the quasi
stop state. At the same time the OSD appears “Stop”. When press the Stop
button twice, it will return to the Menu.
2) As quasi stop state, the MPEG 4 DVD player remembers where you stopped,
when you start playing the disc again, the player continues playing from where
you stopped.
5

Basic Operation
3) As stop state, when you press Play, the player enters sequence playback mode.
zFor the protection of the disc, before you press Open / Close button to eject the
disc tray when playing, please press Stop button at first. After taking out the
disc, press Open / Close again to close the tray.
zIf you’re not going to use the MPEG 4 DVD player for a long time, be sure to
remove the electronic plug.
b) Title Play (compatible with MPEG 4 and DVD discs only)
I. During MPEG 4 and DVD playback, press Title button to display the disc title
contents of the MPEG 4 and DVD discs.
II. Press the Arrow buttons to highlight the title you want, and press Enter; Also you
can press numeric buttons to choose.
III. The MPEG 4 DVD player starts to play the chapter 1 from the chosen title.
c) Sequence Play (compatible with MPEG 4, DVD, SVCD, VCD, DTS-CD, HD-CD,
WMA, MP3/JPEG discs)
I. When a SVCD or VCD disc is loaded and Menu Play is on, the player can play in
sequence playback mode.
II. Except for SVCD or VCD discs, in the stop state, when press Play button, the
player then enters sequence playback mode. This feature is effective to all the
compatible discs.
d) Program Play (compatible with MPEG 4, DVD, SVCD, VCD, CD, DTS-CD,
HD-CD, WMA, MP3/JPEG discs)
The Program Playback option allows to enter your programmed chapters or tracks
which you want to play, maximum to 16.
zProgram Menu:
If Menu Play is on, this operation will turn to Menu Play off while the chapters
/ tracks plays in programmed order.
zAccording to the highlight, use the Numeric buttons to enter the chapters / tracks in
the order you want them to play. Then press Play or use Arrow buttons to highlight
the “PLAY” item and press Enter. The chapters / tracks will play in the programmed
order.
You can program maximum 16 titles / chapters / tracks.
zAccording to the Direction Indicator on the menu, you can press Arrow buttons to
highlight where you want to enter.
zDuring Program Playback, if Program button is pressed, the programmed order and
the contents will be displayed on the screen, and Program Playback will be stopped;
Also you can press Stop and Play to resume normal playback.
6

Additional Operation
Chapter 2 Additional Operation
1. Selecting Tracks (compatible with MPEG 4, DVD, SVCD, VCD, CD, DTS-CD,
HD-CD, WMA, MP3/JPEG discs)
a) When playing a MPEG 4 or DVD disc, press Numeric buttons on the Menu or Title
page to select tracks; During the MPEG 4 and DVD playback, you can input desired title
number directly.
b) As a SVCD or VCD disc, during Sequence Playback, press Numeric buttons to select
tracks. (During Program Playback and Menu Play is on, you can press Prev / Next
button to select only)
c) As for CD, HD-CD, DTS-CD discs, press Numeric buttons directly to select tracks.
d) When playing WMA, MP3 / JPEG discs, press Numeric buttons to select different tracks
on current track list.
Notes: To select tracks from 1 to 10, press corresponding Numeric buttons (1-9, 10)
To select tracks above 10, press 10+ button. For example, to select the track 15,
press 10+ and 5 button.
If the selected track is not available, the input No. will be invalid.
2. Skipping Tracks (compatible with MPEG 4, DVD, SVCD, VCD, CD, DTS-CD,
HD-CD, WMA, MP3/JPEG discs)
a) To skip forward from the beginning to the next title / chapter / track on a disc, press
Next on the remote or on the front of the player
b) To skip backward from the beginning to the preceding title / chapter / track on a disc,
press Prev on the remote or the front of the player.
zWhen playing the last chapter / track on a SVCD or VCD disc with Menu Play off,
pressing Next button will stop the playback; When playing the first chapter / track.,
pressing Prev button will stop the playback; When stop, the Next / Prev button will
be invalid
zIf a MPEG 4 or DVD disc is loaded, it varies according to how the disc is
authorized.
3. Multi Speeds Fast Motion Playback (compatible with MPEG 4, DVD, SVCD,
VCD, CD, DTS-CD, WMA, MP3/JPEG discs)
4 kinds of Forward and Reverse modes during playback.
a) Press the FWD button on the remote control during playback to achieve the Fastward
playback. Press the button again to play at the next speed. Fast Forward Playback has
four speeds: ×2, ×4, ×8, ×20.With each consecutive press of the button, the
playing speed increases. If you press the button five times, Fast Forward Playback
cycles back to normal playback.
During MPEG 4 and DVD playback, when Fast Forward Playback to the beginning of
the next title / chapter, it resumes normal playback; During SVCD or VCD playback
with Menu Play on, when Fast Forward Playback gets to the beginning of the next track,
it resumes normal playback.
zPress Play button to resume normal playback.
7

Additional Operation
zFor CD, HD-CD, MP3, or WMAplayback, when proceeding the Fastward playback,
the player has audio output.
b) Press the REV button on the remote control during playback to achieve the Fast Reverse
playback. Press the button again on the remote control to play at the next speed. Fast
Reverse Playback has four speeds: ×2, ×4, ×8, ×20.With each consecutive
press of the button, the play speed increases. If you press the button five times, Fast
Reverse Playback cycles back to normal playback.
During MPEG 4 and DVD playback, when Fast Reverse Playback gets to the beginning
of the playing title / chapter, it resumes normal playback; During SVCD or VCD
playback with Menu Play on, when Fast Reverse Playback gets to the beginning of the
playing track, it resumes normal playback.
zPress Play button to resume normal playback.
zDuring CD, HD-CD, MP3, or WMA playback, when proceeding the Fast Reverse
playback, the player has audio output.
4. Multi speed Slow Motion Playback (compatible with MPEG 4, DVD, SVCD, VCD,
CD, DTS-CD, HD-CD, WMA, MP3/JPEG discs)
Press Slow button, you can enter Slow Motion Playback mode.
Press the button again on the remote control to play at the next speed. Slow Motion
Playback has six speeds: 1/2, 1/3, 1/4, 1/5, 1/6, 1/7. With each consecutive press of the button,
the play speed decreases. If you press the button seven times, Slow Motion Playback cycles
back to normal playback.
Press Play button to resume normal playback.
5. USB CD Ripping
When playing CD, insert USB, press “COPY” button on remote controller, it shows one
small frame on TV, according to frame instruction to adjust copy speed and choose favourite songs,
press “ENTER” to start copy. It is done when shows “OK” on TV.
6. Decoding function and Encoding from CD/MP3-CD to USB
When MP3, JPEG, MPEG4, WMA, Kodak playing in list status, press “COPY” on remote
controller, it shows copy progress on TV. It is done when progress shows 100%.
7. Repeat Feature (compatible with MPEG 4, DVD, SVCD, VCD, CD, DTS-CD,
HD-CD, WMA, MP3/JPEG discs)
When a disc is playing, press Repeat button once, and the repeat banner appears to show
current Repeat mode.
a) During SVCD, VCD, CD, HD-CD, DTS-CD, WMA, or MP3 / JPEG sequence playback
mode, press Repeat button again to turn on repeat mode.
Press the button again on the remote control to enter the next repeat mode. There are three
repeat options: Off, Track Repeat, and Disc Repeat. With each consecutive press of the button,
the repeat mode switches. If you press the button four times, repeat mode cycles back to Off.
b) During MPEG 4 and DVD playback, press Repeat button again to turn on repeat mode.
There are three repeat options: Off, Chapter Repeat, and Title Repeat. With each
consecutive press of the button, the repeat mode switches. If you press the button four
times, repeat mode cycles back to Off.
c) During WMA, MP3 / JPEG playback, press Repeat button again to turn on repeat mode.
8

Additional Operation
There are four repeat options: Off, Track Repeat, Directory Repeat, and Disc Repeat.
With each consecutive press of the button, the repeat mode switches. If you press the
button five times, repeat mode cycles back to Off.
8. Display Feature (OSD) (compatible with MPEG 4, DVD, SVCD, VCD, CD,
DTS-CD, WMA, MP3/JPEG discs)
a) Loading & playing MPEG 4 and DVD discs (two pages)
zPress OSD button once to show the first page:
“Disc Type, Title * / * (the playing title / total titles), Chapter * / * (the
playing chapter / total chapters), Elapsed Time of the Disc”.
zPress the button again to show the second page:
“Language * / * (the serial number of playing language / the amount of optional
languages) or Off, Language Type, Audio Type, Subtitle * / * (the serial
number of playing subtitle / the amount of optional subtitles) or Off, Angle * / *
(the serial number of playing angle / the amount of optional angles) or Off”.
zPress the button for the third time, the display menu fades out.
b) Loading & playing SVCD discs (two pages)
zPress OSD button once to show the first page:
“Disc Type, Track * / * (the playing track / total tracks), Mute, Menu Play,
Repeat Mode, Elapsed Time of the Playing Track”.
zPress the button again to show the second page:
“Language * / * (the serial number of playing language / the amount of optional
languages) or Off, Language Type, Audio Type, Subtitle * / * (the serial
number of playing subtitle / the amount of optional subtitles) or Off”.
zPress the button for the third time, the display menu fades out.
c) Loading & playing VCD discs.
zPress OSD button once to show the first page:
“Disc Type, Track * / * (the playing track / total tracks), Mute, Menu Play,
Repeat Mode, Elapsed Time of the Playing Track”.
zPress the button again, the display menu fades out.
d) Loading & playing CD, DTS-CD, HD-CD, WMA, MP3 / JPEG discs
zPress OSD button once to show the first page:
“Disc Type, Track * / * (the playing track / total tracks), Mute, Repeat Mode,
Elapsed Time of the Playing Track”.
zPress the button again, the display menu fades out.
9. Time Feature (compatible with MPEG 4, DVD, SVCD, VCD, CD, DTS-CD, HD-CD
discs)You can use Search feature to select a title / chapter / track number or go to a specific point
in a title. First, press Time button on the remote control to enter the search menu and the edit
state; Second, press Arrow buttons to highlight the title / chapter / track number or the time
option; Third, use Numeric buttons to enter the title / chapter / track you want to play or the
elapsed time you want to go to in that title; At last, press Enter button to start playback. For
example, entering 01:23:56 will start playback fifty-six second, twenty-three minute and one
9

Additional Operation
hour into the title. If the input number is illegal, the error information “INVALID KEY ” will
be displayed on the screen.
zNotes
I. This feature does not work in Program Play mode.
II. If Menu Play is on, it will turn off automatically when Search Playback starts.
III. When playing WMA, MP3 / JPEG discs, Search Feature does not work.
10. Language (compatible with MPEG 4, DVD, SVCD discs)
During the playback, press Language on the remote control once, and the language info
banner appears.
Support 8 languages: English, Spanish, French, and Portuguese. With each consecutive press
of the Language button, the language switches and the corresponding serial number appears on the
screen. For example, “Language Icon: [1 English DTS 6CH] or [Off]” (The availability of the
languages depends on the disc).
11. Subtitle-(Sub-T) (compatible with MPEG 4, DVD, SVCD discs)
Press the Subtitle button on the remote control once, and the subtitle info banner appears.
When a MPEG 4, DVD or SVCD disc is recorded with subtitles, you can use the Subtitle
feature to view the subtitles on-screen.As default, subtitles are English.
To display subtitles, press the Subtitle button again. The default language with its
corresponding serial number will be displayed in the info banner and subtitles will be displayed in
that language. For a MPEG 4 disc, it can support English, French, Spanish, Portuguese, German
and Danish. For a DVD or SVCD disc, it can support eight subtitles: English, Danish, Swedish,
French, Spanish, Portuguese, German and Italian. With each consecutive press of the Subtitle
button, the subtitle switches. For example, “Language Icon: [1 English DTS 6CH] or [Off]” (The
availability of the subtitles depends on the disc). To turn subtitles off, press the Subtitle button
until Subtitle Off is displayed.
12. Angle function. (compatible with MPEG 4 and DVD discs)
During disc playback, pressAngle on the remote control once, and the angel icon appears.
Some MPEG 4 or DVD discs contain multiple angles of a particular scene or sequence, so
you can use the Angle feature to view.
Press the Angle button again to go to the next camera angle. If multiple camera angles are
available, the Angle icon displays the current angle number and the number of angles available.
For example: “Angle Icon: [* / *] or [Off]”; 1 / 4 indicates that one angle one is displayed, and
there are total four different angles available. (This feature depends on the disc. If no additional
angles are available, the “Invalid Key” will be displayed.)
13. TV System (compatible with MPEG 4, DVD, SVCD, VCD, CD, DTS-CD, HD-CD,
WMA, MP3/JPEG discs)
Press P / N button on the remote control to display the current TV system.
Press the P / N button again to change to another TV system. There offers four systems:
NTSC, PAL60, PAL, and AUTO. With each consecutive press of the P / N button, the TV system
switches. If you press the button five times, the TV system cycles back to the default.
Notes:
zIf AUTO TV system selected, it can auto reach the highest definition depends
10

Additional Operation
on the disc.
zIf it isn’t full screen state (note: Wide Screen program would never reach full
screen state) or in black and white, press the P / N button to adapt TV System
to the TV set of NTSC or PAL.
zWhen playing in different TV system, some discs may not have their features
entirely fulfilled in some certain standard.
14. Mute Feature (compatible with MPEG 4, DVD, SVCD, VCD, CD, DTS-CD, HD-CD,
WMA, MP3/JPEG discs)
Pressing the Mute button allows you to reduce sound to an inaudible level, and “MUTE” will
be displayed on screen. Press the button again or press the Vol +/- button to return to the normal
condition.
Notes:
zWhen in the state of Mute, the microphone also has no audio output.
zIf the output is no sound, please try to press Mute button to resume.
15. Zoom In/Out the Video Image (compatible with MPEG 4, DVD, SVCD, VCD,
JPEG discs)
The Zoom Function allows you to enlarge or zoom out the video image and to pan though
the image. Press Zoom repeatedly to activate the function and choose the required zoom
factor: Zoom 2, Zoom 3, Zoom 4, Zoom 1/2, Zoom 1/3, Zoom 1/4, Zoom Off.
Notes:This feature does not work when the Disc Menu appears.
16. Repeat a Specific Segment (compatible with MPEG 4, DVD, SVCD, VCD, CD,
DTS-CD, HD-CD, WMA, MP3 discs)
a) During the normal or fast motion playback, press the A-B RPT button once, and
“REPEAT A-” will appears on the screen. This indicates the start of the loop to be
repeated.
b) Press A-B RPT again, and “REPEAT A-B” will appear on the screen. It indicates the
end of the loop.
zLooping will run from set point A to set point B until you turn off Repeat.
c) Press A-B again to cancel A-B loop mode.
zWhen playing a SVCD, VCD, or CD disc, you can repeat a specific segment only
in one track. When the next track begins,A-B Repeat turns off automatically.
zWhen playing a MPEG 4 or DVD disc, you can repeat a specific segment only in
one title / chapter.
17. Volume control (compatible with MPEG 4, DVD, SVCD, VCD, CD, DTS-CD,
HD-CD, WMA, MP3/JPEG discs)
zYou can press the Volume button on the front of TV set or the amplifier to control the
sound level.
zPressing the Vol+ button on the remote allows you to amplify the sound level; Pressing
Vol- will reduce the sound level.
Notes:
zDuring DVD PCM output playback, this feature does not work.
11

Playing WMA, MP3 and JPEG discs
Chapter 3 Playing WMA, MP3 and JPEG discs
Place a MP3 / JPEG disc into the tray, and the MPEG 4 DVD player will search the
directories automatically saved in the MP3 / JPEG files. After searching, it will go to the first
directory saved MP3 files and play the first song in the directory (“01:” is highlighted).The
screen displays as the picture below:
Current
directory
name
Current MP3/JPEG file
name. If a JPEG file
playing, the name should
be *.jpg.
The playing file is
a JPEG picture.
File Switch Region: Displays the
file type of the playing and the
switching.
The playing file
is a MP3 music.
Use the Arrow buttons to enter the Directory Region and highlight the desired directory, then
the first track under it starts playback; Also you can use the Arrow buttons to enter the File Region
and select the file you want to play.
Notes:
I. Press the Left and Right arrow buttons, you can activate Directory Region, File Region
and File Switch Region separately.
II. The highlight in Directory Region and File Region is shown as the picture above; While it
appears a transparent rectangle in File Switch Region.
12

Playing WMA, MP3 and JPEG discs
III. In File Switch Region, you can press the Left and Right arrow buttons to switch the
highlight, then press Enter; the “M”, “P”, and “G” button is illustrated in the above
picture. For example, if a disc with MP3 and JPEG files but without any NES files is
loaded, the color of the letter “M” and “P” will appear to white and “G” black. If a MP3
file playing, “M” turns darker.
IV. To the disc with WMA, MP3 and JPEG files, when playing a JPEG picture, press the
Return button to return to JPEG list.
V. You can press the Numeric buttons to select the file you want to play. For example, if you
desire the 15th track in current list, press the “10+” button once, then press “5”, the 15th
starts playback.
Notes: When playing a disc with MP3 files, video cannot be output while only digital audio
can.
VI. When playing JPEG pictures, press the Program button to choose the pictures switched
mode. There are 17 switch modes; Press Program repeatedly to activate the function and
choose the required switch mode: Spread from Up to Down, Spread from Down to Left,
Spread from Left to Right, Spread from Right to Left, Spread from Left Up to Right Down,
Spread from Right Up to Left Down, Spread Left Down to Right Up, Spread from Right
Down to Left Up, Spread from Center to Up / Down, Fold from Up / Down to Center, Fold
from Left / Right to Center, Horizontal Shutter, Vertical Shutter, Fold from the Corners to
the Center, Random Play, Off.
VII. When a picture is playing or pausing, press the Arrow buttons to change the display angle:
Up: flip vertical
Down: flip horizontal
Left: rotate 90
 counter-clockwise
Right: rotate 90
 clockwise
VIII.When a picture is playing or pausing, press the Menu button, the screen displays small
pictures. Up to 12 small pictures are displayed per screen. To view the next 12 pictures,
press the Next button to go forward and the Prev button to go to the previous page. You can
also select and play a picture in full screen by press that number on the remote.
13

Specification of the MPEG 4/MPEG 4 DVD player
Chapter 4 Setup Menu System
1. General Steps of Setup Menu
a) Press the Setup button, the main setup menu appears.
zWhen the main menu is displayed, the MPEG 4 DVD system will pause automatically.
b) Press the Left and Right arrow buttons to highlight the icon of the desired page, then
press the Down or Right arrow button to activate that page; For example, if you want to
setup the video page, press Right to highlight the video icon, the video page will be
displayed on the screen.
c) Press the Down arrow button to highlight the desired option. Press Enter or press Right
to select, the choices of that option appear on the right; For example, press the Down
arrow button to highlight the BRIGHTNESS option, then press Enter to select, the
brightness choices appear on the right.
d) Press the Arrow buttons to highlight the Exit Setup option, then press Enter or Setup
again to exit Setup Menu.
Notes:
zWhen setup, the following buttons will turn off the setup menu: P / N, Sub-T, REV, FWD,
Vol +/-, Title, Play, Stop, Resume, Pause, Next, Prev, Zoom, Preview, Program, Repeat,
A-B RPT, Angle, language, OSD, Mute.
2. Setup Items Introduction
a) SYSTEM SETUP
TV SYSTEM
zAUTO: Choose this settings if your DVD player is connected to a multi-system TV.
zNTSC: Choose this settings if your DVD player is connected to a NTSC TV.
zPAL: Choose this settings if your DVD player is connected to a PAL TV.
zPAL60: Choose this settings if your DVD player is connected to a PAL60 TV.
The default setting is PAL.
SCREEN SAVER
If the screen saver is on, when your DVD player is in Stop, Open, or No Disc state, or
there is a frame frozen for more than 15 sec, the screen saver will be displayed. This feature
can protect the screen from damage.
zON: Choose this setting to activate the screen saver.
zOFF: Choose this setting to cancel the screen saver
The default setting is ON.
VIDEO
zInterlace-YUV: Choose this setting if your DVD player is connected to a TV with Y,
Cb, Cr video cables.
zTV-RGB: Choose this setting if your DVD player is connected to a TV with an
S-Video cable or composite video cables, or Scart cable.
14

Specification of the MPEG 4/MPEG 4 DVD player
zP-SCAN: Choose this setting if your DVD player is connected to a progressive
scan TV with Y, Cb, Cr video cables.
Notes:
zWhen the MPEG 4 DVD player output is composite video, you can choose the
setting randomly.
zChoose TV-RGB / P-SCAN if the MPEG 4 DVD player is connected to a
progressive scan TV.
The default setting is S-VIDEO.
TV TYPE
z16 : 9 (Wide Screen): Choose this setting if the MPEG 4 DVD player is connected
to a wide screen TV. If you choose this setting and you don’t have a wide screen TV,
the images on the screen may appear distorted due to vertical compression.
z4 : 3 LB (Letter Box): Choosing this setting if the MPEG 4 DVD player is
connected to a normal ratio TV. Connector. You’ll see the movies in their original
aspect ratio (height-to-width ratio). You’ll see the entire frame of the movie, but it
will take up a smaller portion of the screen vertically. The movie might appear with
black bars at the top and bottom of the screen.
z4 : 3 PS (Pan & Scan): Choosing this setting if the MPEG 4 DVD player is
connected to a normal ratio TV. You can fill the movie to the entire screen of your
TV. It means that parts of the picture (the left and right edges) won’t be seen.
Notes:
zThe image display ratio is related to the recorded disc format. Some discs can not
display images in the aspect ratio you choose.
zIf you play a disc recorded in 4:3 format on a wide screen TV, black bars will
appear on the top and bottom side of the screen.
zYou must adjust the screen setting depending on the type of the television you have.
PASSWORD
The password option is initialized locked, and you cannot set the ratings limit or
change the password. In order for the Ratings feature work, the password mode must be
turned on. If you want to set the ratings limit, you will need to enter the default
password, which is 0000, then press Enter to confirm. To change the password, you will
be prompted for the old password, then be prompted for a new. Enter a 4-digit number
(this is your password).
RATING
The Rating feature is a rating limit system, like movie ratings. It works with MPEG 4
and DVD discs that have been assigned a rating. This helps you control the types of
MPEG 4 and DVD disc that your family watches.
zThere are eight rating options.
zSelect the eighth option to cancel the rating limit.
15

Specification of the MPEG 4/MPEG 4 DVD player
The default setting is eight.
Notes:
zIf the password option is locked, you cannot set the ratings limit; the rating limit
doe not work when the password option unlocked.
DEFAULT
Choose this option to resume all the setup options to default settings.
b) LANGUAGE SETUP
Highlight the OSD LANGUAGE option, and press the Arrow buttons to choose the
OSD language you prefer to. Press Enter to confirm, and it will display OSD in that
language;
Highlight the AUDIO LANG option, and press the Arrow buttons to choose the audio
language you prefer to. Press Enter to confirm. If the disc you are playing has that
language available, it will output audio in that language;
Highlight the SUBTITLE LANG option, and press the Arrow buttons to choose the
subtitle language you prefer to. Press Enter to confirm. If the disc you are playing has
that language available, it will displays subtitles in that language;
Highlight the MENU LANG option, and press the Arrow buttons to choose the menu
language you prefer to. Press Enter to confirm. If the disc you are playing has that
language available, it will displays menu in that language;
Notes:
zIf your preferred language isn’t available, the disc’s default language will be
played.
c) AUDIO SETUP
Highlight the AUDIO OUT option, and press the Arrow buttons to choose the audio
output mode you prefer to. Press Enter to confirm; There are 3 optional audio output
modes: SPDIF / OFF, SPDIF / RAW, and SPDIF/ PCM.
zSPDIF / OFF: From the Coaxial Output jack and the Optical Output jack, no signal
is output.
zSPDIF/ RAW: Choose this setting if your DVD player is connected to a power
amplifier with a coaxial cable or an optical cable; When playing a disc recorded
with Dolby Digital, DTS and MPEG audio formats, the corresponding digital
signals will be output from the Coaxial Output jack or Optical Output jack. This
player’s digital output jacks are designed for a connection to a Dolby Digital, DTS ,
or MPEG receiver or decoder.
zSPDIF / PCM: Choose this setting if your MPEG 4 DVD player is connected to a
2-channel digital stereo amplifier; When playing a disc recorded with Dolby
Digital and MPEG audio formats, audio signals will be modulated into a 2-channel
16

Specification of the MPEG 4/MPEG 4 DVD player
PCM signal, and it will be output from the Coaxial Output jack or Optical Output
jack.
d) VIDEO SETUP
BRIGHTNESS
Use the Up and Down arrow button to move the scroll and adjust the brightness.
CONTRAST
Use the Up and Down arrow button to move the scroll and adjust the contrast.
HUE
Use the Up and Down arrow button to move the scroll and adjust the hue.
SATURATION
Use the Up and Down arrow button to move the scroll and adjust the saturation.
SHRPNESS
Use the Up and Down arrow button to move the scroll and adjust the saturation.
e) SPEAKER SETUP
DOWNMIX
Use the Up and Down arrow button to move the scroll and adjust the saturation.
zLT / RT: Choose this setting, it will be sound like in a movie theatre if the original
movie the disc was recorded from was encoded in the Pro Logic Dolby Digital
format.
STEREO: Choose this setting, two channels of signals will be output from the left and
right soundtrack.
f) DIGITAL SETUP
The video setup options are illustrated below:
OP MODE
zLINE OUT: Choose this setting to line out the input signal. It will be more suitable
for playing in the night, for the output volume is low.
zRF REMOD: It will be more suitable to choose this setting for playing in the day
time, for the output volume is high.
DYNAMIC RANGE: When “LINE OUT” is selected, choose this setting to adjust the
line out ratio and get different effect. If adjusting to FULL, the audio signal peak value
will be the minimum; while adjusting to OFF, maximum.
NOTE:
This option will be valid when the DOWNMIX OFF.
DUAL MONO (LEFT + RIGHT)
Choose this option to setup the L and R mono output mode; There are four modes in this
option: STEREO, MONO L, MONO R, and MIX MONO; It is mainly used in karaoke mode.
17

Specification of the MPEG 4/MPEG 4 DVD player
REFERENCE:
zNo using for a period of time, please pull out the plug from the electronic outlet.
zThe player should be operated only on condition that the type of power supply
corresponds to the marking label. Otherwise, it doesn’t work or even be damaged.
zThe player may not be compatible with some encrypted discs.
zIf the player stops playback by accident, please power it on again.
18

Specification of the MPEG 4/MPEG 4 DVD player
Chapter 5 Specification of the MPEG 4 DVD player
1. Types of disc that the MPEG 4 DVD player can play.
Types of
Discs Diameter
Playback Time
Data Format
Remark
MPEG 4 12cm Can reach more
than 10 hours. MPEG 4 compressed discs
1 layer: 120min
12cm 2 layers: 240min
1 layer: 80min
DVD
8cm 2 layers: 180min
DVD Format Disc:
Compressed Digital Audio
Compressed Digital Video
（Moving picture）
SVCD 12cm 45min
MPEG2
Compressed Digital Audio
Compressed Digital Video
（Moving picture）
Include:
SVCD、CVD
12cm 74min
VCD
8cm 20min
MPEG1
Compressed Digital Audio
Compressed Digital Video
（Moving picture）
Include:
VCD2.0、
VCD1.1、
VCD1.0、
DVCD
12cm 74min
CD 8cm 20min
CD-DA:
Digital Audio
HD-CD 12cm 74min HD-CD:
Digital Audio
DTS-CD 12cm 74min DTS-CD:
Digital Audio
MP3/JPEG 12cm 600min Compressed Digital Audio
WMA 12cm Compressed Digital Audio
19
