LENCO TAB701 User manual

?
1
ENGLISH
NEED HELP?
As we are often updating and improving our products, your device’s software may have
a slightly different appearance or modified functionality than presented in this Quick Start Guide.
On our Website:See the Frequently Asked Questions section on www.lenco.eu/tab701

2
12 3
4 4
8
65
7
1
2
3
4
5
6
7
8
ENGLISH
DESCRIPTION OF THE DEVICE
Hardware Reset: In the event that your TAB-701 freezes operation, you can press the “pinhole reset” button,
located on the back the device, by using a sharp object such as a toothpick.
Power/Lock: slide left and hold to switch on/off. Slide right to lock the
device’s touchscreen.
When you slide left and hold, a window appears with a list of options (when the product is on).
Tap on “Power Off” to fully shut down your TAB-701.Tap on “Suspend” to put the device in
standby (and allow a quick start up when you next tap the screen).While the device is in suspend
mode, slide right to lock the device with its screen off.This can be useful if your TAB-701 is in your
backpack, for example, and you do not want to wake it up by touching the screen by accident.
Micro-SD card reader
Charging indicator: Red light: battery charging / Yellow: battery charged.
Loudspeakers
Headphone jack
Power connector: to connect the supplied power cable.
USB port:to connect your TAB-701 to your computer, using the included USB cable.
Leg stand: pull it out, and it will allow your TAB-701 to stand by itself on a flat, stable surface.

3
1
2
▲
▲
▲
!
2
1
EUR
US
UK
ENGLISH
STARTING UP
Installation Wizard
The first time you start up your TAB-701, the installation wizard will bring you through a few screens to help you set up
the principal settings: Language, country, time, etc.
Before using your TAB-701 for the fi rst time, completely charge the battery!
Charging the Battery
Connect the supplied power cable to the TAB-701 Power connector and to a wall outlet.
The TAB-701 device will turn on and start charging. The Power indicator light is red while the battery is charging. It will turn
yellow when the battery is fully charged.

4
▼
▼▼
▼
▼▼
ENGLISH
THE TAB-701 INTERFACE
Top bar of the Interface (varies according to the screen you are in)
Return to the
Home screen
Return to the
previous screen
Menu: gives menu options ac-
cording to the current screen.
Your TAB-701 device is equipped with a touchscreen. Most screen areas will react when you tap on them with your finger.
Status icons: (WiFi connection
status, battery level, etc.)
Notification icons: drag the top bar downwards
to reveal the notification messages (if any).
These are the default
Android™ shortcuts (Web
Browser, EMail, etc.). Tap on an
icon to open the correspond-
ing application.You can
customize the Home screen
by adding/removing shortcuts
and widgets, changing the
wallpaper, etc. See next page.
Home Screen
Applications Tab
Tap on this icon to reveal all the An-
droid™ applications installed on your
TAB-701 (games, various tools, etc.).
You can copy them onto the Home
screen.You can get more Android™
applications from the AppsLib which
can be found on the Home screen.
Time Volume -/+

5
ENGLISH
Customizing the Home screen items
To add a Home screen item (shortcuts, widgets, etc.), hold your finger on the screen at an empty location, then choose from-
the list.You can also tap on the Menu icon and select Add
To add a Home screen item (shortcuts, widgets, etc.), hold your finger on the screen at an empty location, then choose from
, at the bottom of the screen.
To move a Home screen item, hold your finger onto it until it gets larger, then drag it to the desired location, and release-
your finger.
To remove a Home screen item, hold your finger onto it, drag it onto the recycle bin (while you’re holding an item, the-
Applications tab, on the right side of the screen, turns into a recycle bin) and release your finger.
CUSTOMIZING YOUR PRODUCT
Changing the Settings:From the Home screen, tap on the Menu icon , tap on Settings
and choose a category: Wireless controls, Sound & display, Date & time, etc.
The extended Home screen
Slide your finger horizontally on
the screen to go to the left or right
side of the extended Home screen.
Adding more applications with APPSLIB :With the TAB-701 connected to the Internet, tap on
the AppsLib icon
Adding more applications with APPSLIB
.This online library of free and purchasable applications has thousands of
fun games and useful applications to download and use.

6
1
2
3
4
www
ENGLISH
CONNECTING TO THE INTERNET
First of all, you need to configure a WiFi network. For this procedure to work, you need to be in a WiFi zone that will
allow you to connect to it. Every time the TAB-701 is in range of a network that you have already configured once, it will
attempt to make a connection.
* For free access WiFi points, there is no need to enter any special information. For secured networks, you will need either a key (a series of numbers and/or letters)
of the type WEP, WPA, or WPA2. Check with the person who manages the WiFi network to obtain the exact connection parameters required.
To configure a new WiFi network, go on the Home screen, tap on the Menu icon , then
select Settings
To configure a new WiFi network, go on the Home screen, tap on the Menu icon
.
In the Settings screen, select Wireless controls.
If the WiFi is off, tap on the Wi-Fi line to turn it on. Then select Wi-Fi settings. The TAB-701
will scan for available WiFi networks and display them at the bottom of the screen.
Tap on the network you want to connect to, enter the required network information* and then tap on Connect.Your
TAB-701 will now attempt to establish a connection to that WiFi hot spot with the network parameters you entered.

7
1
2
3
ENGLISH
PLAYING MULTIMEDIA FILES
From the Home screen, tap on the video, audio or photo application.
The TAB-701 will display a list of fi les or folders corresponding to the selected category.
Tap on an item to start playing it.
Only inVideo and Photo modes: to display/hide the on-screen controls, tap anywhere on the screen.
To pause or resume a video, tap on the icon / (bottom of screen).To go to any particular point in the video,
slide the progression bar to the desired point.
To play the next or previous song, tap on the icons / . Use the icons / and the progression bar as
in the video player screen (see above).
To start or pause a slide show, tap on the icon / .To view the next or previous photo, tap on the icons / .
Video
Music

8
2
3
4
1
USB
1
32
ENGLISH
TRANSFERRING MEDIA TO YOUR TAB-701
COMPUTER
TURNED ON
Connect the supplied USB cable to the TAB-701 and to a running computer.
The TAB-701 will turn on and ask you if you want to connect it. Tap on “Mount” to connect it. Within a few seconds the
TAB-701 will appear as an icon on your computer.
You can transfer your media files to the TAB-701 either by copy/pasting them into the respective folders using Win-
dows® Explorer (or the Finder on a Mac®), or by using Windows Media® Player. Open Windows Media Player® and then
use the Sync tab to synchronize your music, videos, and photos onto your TAB-701. See Windows Media Player®’s Help
to learn more about this.
Once all your file transfers are finished, closeWindows® Explorer and any other program that may have read or written to
the TAB-701. Click on the ‘safely remove’ icon in the system tray, next to the clock.You can now unplug the USB cable.

?
9
FRANÇAIS
BESOIN D’AIDE ?
Comme nous mettons à jour et améliorons régulièrement nos produits, le logiciel de votre appareil peut présenter une
interface ou des fonctionnalités légèrement différentes de celles décrites dans ce guide.
Sur notre site Web:Consultez la Foire Aux Questions (FAQ) sur www.lenco.eu/tab701

10
12 3
4 4
8
65
7
1
2
3
4
5
6
7
8
FRANÇAIS
DESCRIPTION DE L’APPAREIL
Réinitialisation de votre appareil : Si votre TAB-701 venait à se bloquer totalement, vous pouvez appuyer sur
le bouton reset, situé au dos du produit, en utilisant un objet pointu tel qu’un trombone.
Marche/Arrêt/Verrouillage : Faites glisser vers la gauche et maintenez pour
allumer/éteindre. Faites glisser vers la droite pour verrouiller l’écran tactile.
Lorsque vous faites glisser ce bouton vers la gauche et le maintenez, une fenêtre apparaît avec une liste
d’options (lorsque le produit est en marche).Appuyez sur “Eteindre” pour éteindre votre TAB-701 com-
plètement.Appuyez sur “Mettre en veille”(Suspend) pour mettre l’appareil en veille (et permettre un
redémarrage plus rapide en touchant l’écran).Lorsque l’appareil est en veille,faites glisser le bouton vers
la droite pour verrouiller l’appareil avec l’écran éteint. Cela peut s’avérer utile si votre TAB-701 se trouve
dans votre sac à dos, par exemple, et que vous ne voulez pas le réveiller en touchant l’écran par accident.
Lecteur de cartes Micro-SD
Témoin de charge - rouge : batterie en charge / jaune : batterie chargée
Haut-parleurs
Prise casque
Connecteur d’alimentation :pour connecter le câble d’alimentation fourni.
Port USB : pour connecter votre TAB-701 à un ordinateur, à l’aide du câble USB fourni.
Béquille : sortez-la, et elle vous permettra de faire tenir votre TAB-701 sur une surface plane et stable.
