Lennox MPD35ST-NM-B User manual

1
NOTE: DIAGRAMS & ILLUSTRATIONS ARE NOT TO SCALE.
CARE AND OPERATION
INSTRUCTIONS
DIRECT VENT MULTI-OPEN
MERIT®PLUS SERIES
DIRECT-VENT GAS FIREPLACE HEATERS
A French manual is available upon request. Order P/N 875,025CF
Ce manuel d’installation est disponible en francais, simplement en
faire la demande. Numéro de la pièce 875,025CF
P/N 875,025M REV. C 06/2009
MODELS
WARNINGS
• Hot! Do not touch! The glass and
surfaces of this appliance will be hot
during operation and will retain heat
forawhileaftershuttingofftheappli-
ance. Severe burns may result.
• Carefully supervise children in the
same room as appliance.
• If small children are present in the home, it is
recommendedthatthisappliancebefittedwith
a screen door or screen panel kit. See Page 13
for ordering information.
US
Portland
INSTALLER: Leave this manual with the appliance.
CONSUMER: Retain this manual for future reference.
INSTALLATEUR: Laissez cette notice avec l'appareil.
CONSOMMATEUR: Conservez cette notice pour con-
sultation ultérieure.
WARNING:IFTHEINFORMATIONINTHISMANUAL
IS NOT FOLLOWED EXACTLY, A FIRE OR EXPLO-
SIONMAYRESULTCAUSINGPROPERTYDAMAGE,
PERSONAL INJURY OR LOSS OF LIFE.
Do not store or use gasoline or other flammable
vapors or liquids in the vicinity of this or any
other appliance.
WHAT TO DO IF YOU SMELL GAS:
• Do not light any appliance.
• Do not touch any electrical switch; do not
use any phone in your building.
• Immediately call your gas supplier from a
neighbor’s phone. Follow your gas supplier's
instructions.
• If your gas supplier cannot be reached, call
the fire department.
Installation and service must be performed by
a qualified installer, service agency or the gas
supplier.
AVERTISSEMENT: ASSUREZ-VOUS DE BIEN
SUIVRE LES INSTRUCTIONS DONNÉES DANS
CETTE NOTICE POUR RÉDUIRE AU MINIMUM LE
RISQUE D'INCENDIE D'EXPLOSION OU POUR
ÉVITER TOUT DOMMAGE MATÉRIEL, TOUTE
BLESSURE OU LA MORT.
Ne pas entreposer ni utiliser d'essence ni d'autre
vapeursouliquidesinflammablesdanslevoisinage
de cet appareil ou de tout autre appareil.
QUE FAIRE SI VOUS SENTEZ UNE ODEUR DE
GAZ:
• Ne pas tenter d'allumer d'appareil.
• Ne touchez à aucun interrupteur. Ne pas vous
servir des téléphones se trouvant dans le báti-
ment où vous vous trouvez.
• Appelez immédiatement votre fournisseur de
gaz depuis un voisin. Suivez les instructions
du fournisseur.
• Si vous ne pouvez rejoindre le fournisseur de
gaz, appelez le service des incendies.
L'installation et l'entretien doivent être assurés
par un installeur ou un service d'entretien qualifié
ou par le fournisseur de gaz.
MPD35ST-NM-B MPD35ST-NE-B
MPD35ST-PM-B MPD35PF-NE-B
MPD35PF-NM-B
MPD35PF-PM-B
Millivolt Models Electronic Models
OTL Report No. 116-F-28-5

2NOTE: DIAGRAMS & ILLUSTRATIONS ARE NOT TO SCALE.
CONGRATULATIONS!
In selecting this LENNOX Direct-Vent Gas Appliance you have chosen the finest and most
dependable fireplace to be found anywhere. Its a beautiful, prestigious alternative
to a wood burning fireplace. Welcome to a Family of tens of thousands of satisfied
LENNOX Fireplace Owners.
Please carefully read and follow all of the instructions found in this manual. Please
pay special attention to the safety instructions provided in this manual. The Care
and Operation Instructions included here will assure that you have many years of
dependable and enjoyable service from your LENNOX product.
INTRODUCTION
The Fireplace models covered in this manual
areDirect-Ventsealedcombustiongasfireplace
heaters designed for residential application.
Direct-Vent appliances operate with the com-
bustion chamber completely isolated from the
indoor environment. All air for combustion is
brought in from the outside and exhaust gases
areventedthroughthesamedirectvent,co-axial
(intake/exhaust) vent system.
The Millivolt appliances have a millivolt gas
controlvalvewithpiezoignitionsystemprovides
safe, efficient operation. If any optional acces-
sories which require electrical power are being
installed, the electrical power must be provided
at the time of appliance installation.
The Electronic appliances have an electronic
intermittentpilotsystemprovidessafe,efficient
operation. External electrical power is required
to operate these appliances.
These appliances comply with National Safety
Standards and are tested and listed by OMNI-
TestLaboratories,Inc. (Report No.116-F-28-5)
to ANSI Z21.88a (in Canada, CSA-2.33a), and
CAN/CGA-2.17-M91 in both USA and Canada,
as vented gas fireplace heaters.
The Installation must conform to local codes
or, in the absence of local codes, with the
National Fuel Gas Code, ANSI Z223.1/NFPA
54-latest edition, or the Natural Gas and
Propane Installation Code, CSA B149.1-latest
edition. The appliance, when installed, must
be electrically grounded in accordance with
local codes or, in the absence of local codes,
thelatest editionoftheNationalElectrical Code,
ANSI/NFPA70, ortheCanadianElectricalCode,
CSA C22.1 - latest editions.
GENERAL INFORMATION
Note: Installation and repair should be per-
formed by a qualified service person. The
appliance should be inspected annually by a
qualified professional service technician. More
frequent inspections and cleanings may be
required due to excessive lint from carpeting,
bedding material, etc.
It is imperative that the control compartment,
burners and circulating air passage ways of
appliance be kept clean. See Maintenance
instructions on Page 4.
TABLE OF CONTENTS
Introduction ......................................Page 2
General Information..........................Page 2
Gas Controls Access.........................Page 3
Operation / Care of Your Appliance ...Page 3
Variable Flame Adjustment................Page 4
Maintenance......................................Page 4
Front Glass Enclosure Panel,
Removal and Installation.................Page 6
Install Grate, Vermiculite
Embers & Logs.................................Page 7
Burner Flame Appearance & Sooting Page 9
Burner Flame Adjustments................Page 9
Millivolt Appliance Checkout.............Page 10
Electronic Appliance Checkout..........Page 10
Wiring Diagrams...............................Page 11
Warranty ...........................................Page 11
Product Reference Information.........Page 11
Accessory Components ....................Page 12
Lighting Instructions – Millivolt ........Page 16
Lighting Instructions – Electronic .....Page 18
Maintenance Schedule......................Page 20
Troubleshooting Guide – Millivolt......Page 21
Troubleshooting Guide – Electronic ..Page 22
Replacement Parts List.....................Page 23 Electronic Models -
Electronic models have a fixed rate gas valve.
The BTU Input for electronic models is shown
in Table 2:
Gas Pressure -
Tables 3, 4 and 5 show the appliances' gas
pressure requirements.
Theseappliancesaredesignedtooperateonnatural
gas or propane gas only.Theuseofother fuelsor
combinationoffuelswilldegradetheperformance
of this system and may be dangerous.
Millivolt Models - BTU Input
Millivolt models come standard with the manu-
ally-modulated gas valve; flame appearance and
heat output can be controlled at the gas valve.
The BTU Input for millivolt models is shown
in Table 1:
Due to high temperatures the appliance should
belocatedoutoftrafficandawayfromfurniture
and draperies. Locate furniture and window
coverings accordingly.
These fireplaces are designed as supplemen-
tal heaters. Therefore, it is advisable to have
an alternate heat source when installed in a
dwelling.
Input (BTU) Manually-Modulated Gas
Valves (millivolt models)
Models Fuel
Type
Input Rate
(BTU / HR)
MPD35ST/PF-NM Natural 30,000 high
23,000 low
MPD35ST/PF-PM Propane 28,000 high
22,000 low
Table 1
Input (BTU) - Fixed Rate
(electronic models)
Models Fuel
Type
Input Rate
(BTU / HR)
MPD35ST/PF-NE Natural 30,000
MPD35ST/PF-PE
(if field converted)
Propane 28,000
Table 2
S'assurer que le brùleur et le compartiment des
commandes sont propres. Voir les instructions
d'installation et d'utilisation qui accompagnent
l'appareil.
Provide adequate clearances around air open-
ings and adequate accessibility clearance for
service and proper operation. Never obstruct
the front openings of the appliance.
This manual is part of a set of two supporting
this product. Refer to manual 850,024M for
Installation Instructions.

3
NOTE: DIAGRAMS & ILLUSTRATIONS ARE NOT TO SCALE.
Inlet Gas Supply Pressure
(all models)
Fuel # Minimum Maximum
Natural Gas 5.0" WC
(1.24 kPa)
10.5" WC
(2.61 kPa)
Propane 11.0" WC
(2.74 kPa)
13.0" WC
(3.23 kPa)
Table 3
Manifold Gas Supply Pressure
(millivolt models)
Fuel # Low High
Natural
Gas
(Lo) 2.2" WC
(.55 kPa)
(Hi) 3.5" WC
(.87 kPa)
Propane (Lo) 6.3" WC
(1.57 kPa)
(Hi) 10.0" WC
(2.49 kPa)
Table 4
Test gauge connections are provided on the
front of the millivolt gas control valve, identi-
fied IN for the inlet and OUT for the manifold
side (see Figure 2 on Page 4). A 1/8" NPT Test
gauge connection is provided at the inlet and
outlet (manifold) ports on the electronic gas
control valve (see Figure 3 on Page 4).
Manifold Gas Supply Pressure
(electronic models)
Fuel # Fixed
Natural Gas 3.5" WC
(.87 kPa)
Propane 10.0" WC
(2.49 kPa)
Table 5
Burn-in Period
During the first few fires of this appliance there
will be some odor due to the curing of the
paint and burning off of lubricants used in the
manufacturing process.
Depending on your use, the burn-in period may
take a few hours or a few days.
KEEP YOUR HOUSE WELL VENTILATED
DURING THE CURING PROCESS. THE ODOR
AND HAZE EMITTED DURING THE CURING
PROCESS CAN BE QUITE NOTICEABLE AND
MAY SET OFF A SMOKE DETECTOR.
If an optional blower is installed, Do not turn it
on during the Burn-In period.
A white film may develop on the glass front
during the first few fires as part of the curing
process. The glass should be kept clean during
thefirsttwoweeksofusetopreventthefilmfrom
baking on (making it very difficult to remove).
See Cleaning Glass on Page 5.
Orifice Sizes - Sea Level to High Altitude
(All Models)
These appliances are tested and approved for
installationsatelevationsof0-4500feet(0-1372
meters)abovesealevelusingthestandardburner
orifice sizes (marked with an "*" in Table 6). At
the time of installation, it must be determined
if the appliance needs to be derated. Contact
yourlocalgassupplierforderationrequirements
for your area.
Theseappliancesandtheir individual shut-off
valves must be disconnected from the gas
supply piping system during any pressure
testing of that system at pressures greater
than 1/2 psig (3.5 kPa).
These appliances must be isolated from the
gas supply piping system (by closing their
individual manual shut-off valve) during any
pressure testing of the gas supply piping
systemattestpressuresequalto orlessthan
1/2 psig (3.5 kPa).
Control
Compartment Access panel
Gas Control Compartment Access
The gas controls can be found behind the
control compartment access panel. To open
the control compartment access panel, actuate
the spring-loaded magnetic catches securing
the panel.
First, depress the outer top right corner of the
panel until the catch "pops" the door free. Then,
gently pull the door forward until the left top
corner "pops" free, allowing the panel to swing
out and down to open.
On millivolt systems, the piezo igniter, HI/LO
flame adjustment knob, and pilot and main
gas OFF/ON control knob are located below
the glass panel enclosure. The gas valve for
electronic systems is also located below the
glass enclosure panel. See Figure 1.
To ease door closure, depress the catches to
place them in their retracted position, then
close the door.
OPERATION AND CARE OF YOUR
APPLIANCE
The standard controls for appliance operation
are located behind the hinged drop-down panel
belowtheappliance front glass enclosurepanel
(see Figure 1). Optional control switches are
also available (see Page 12 - Remote Wall
Switch, Remote Control or Wall Thermostat).
Operation of millivolt and electronic gas con-
trol systems are different. Before lighting and
operatingyourappliancedetermineifyouhave
a millivolt or electronic appliance. Familiarize
yourself with the gas control valve that your
appliance uses. Refer to Figure 1 for access
to the gas control valve.
Figure 1 - Gas Control Compartment Access
HI/LO (flame height
control knob)
OFF/PILOT/ON (gas control knob)
Gas Flex Line
Gas Valve
Piezo Igniter
OFF/ON Switch
Hinge Pin
Note:The gas supply
line must be installed
in accordance with
building codes by a
qualified installer
approved and/or
licensed as requed
by the locality. In
the Commonwealth
of Massachusetts,
installation must
be performed
by a licensed
plumber or gas
fitter.
Deration - At higher elevations, the amount of
BTU fuel value delivered must be reduced by
eitherusinggasthathasbeenderatedbythegas
company or by changing the burner orifice to a
smallersize asregulatedbythelocal authorities
having jurisdiction and by the (USA) National
Fuel Gas Code NFPA 54 / ANSI Z223.1 - latest
edition or, in Canada, the CAN1-B149.1 and .2
codes - latest edition.
Burner Orifice Sizes (all models)
Elevation
Feet (meters)
Natural
Gas
drill size (inches)
Propane
Gas
drill size (inches)
0-4500
(0-1372) #37 (.104") *
24M1001 •
1.55 mm (.061")*
42M7901 •
Table 6 * Standard size installed at factory
• Part /Cat. Number

4NOTE: DIAGRAMS & ILLUSTRATIONS ARE NOT TO SCALE.
TPTH TP TH
Note: The piezo igniter and burner
OFF/ON switch are located below
glass panel (see Figure 1).
H
I
LO
W
H
TPT
HT
P
T
P
I
L
O
T
P
I
L
O
T
O
N
it
O
F
F
IN OUT
Manifold Pressure Tap
Inlet Pressure Tap
SIT Millivolt Gas Valve
Main Gas
Control Knob
OFF/PILOT/ON
HI/LO Variable
Flame Height
Adjustment
Gas
Outlet
Gas
Inlet
Pilot Adjustment
Screw
Terminals
TPTH,TP & TH
HI/LO Variable
Flame Height
Adjustment
Main Gas
Control Knob
OFF/PILOT/ON
Figure 2
OFF/ON
(burner)
OFF
ON
IGNITER
Figure 3
Honeywell Electronic Gas Valve
F
F
O
N
I
PSI
NO
L
O
R
T
N
O
C
G
INT
IER
Manifold Pressure
Port ON / OFF Switch
Inlet
Pressure
Port
Electronic Gas
Control Valve
If your millivolt appliance is equipped with an
optional remote switch kit (wall switch, remote
control or wall thermostat) and the pilot is lit,
the appliance main burner may be turned on
and off using the optional switch. When using
anoptionalremote switch, turn offthestandard
OFF/ON switch.
Note: Topreventexcessiveresistance inburner
circuit(whichcancauseburneroperationprob-
lems),onlyoneburnercontrolswitchshouldbe
wiredtovalve.Therefore,ifanoptionalcontrol
switch is installed, the standard Off/On switch
and wires should be removed.
Electronic Appliances -
Tolightelectronicappliancesrefertothedetailed
lighting instructions found on Page 19.
Electronic appliance lighting instructions may
alsobefoundonthepullout lightinginstruction
labels attached to the gas control valve.
Oncethepilotislit,ifyourelectronicapplianceis
equippedwithanoptionalburnercontrolswitch
kit the appliance main burner may be turned on
and off using the optional switch (See optional
accessories on Page 12 - Wall Switch, Wall
Thermostat Or Remote Control Receiver).
Variable Flame Height Adjustment
(Millivolt Appliances only)
1. All Millivolt appliances are equipped with a
variable gas control valve. Flame height for
these models may be adjusted through a
range between fixed low and high settings
while the appliance is in operation. Adjust
the flame height as desired after lighting the
appliancebyrotatingthevariableadjustment
control knob (HI/LO) located on the front of
the valve (refer to Figure 2).
Before re-lighting the fireplace, refer to the
lighting instructions in this manual. Instruc-
tions are also found on pull-out panels
located below the glass door in the control
compartment.
WARNING: Turn off gas and
electricalpowerbeforeservicing
the appliance.
CAUTION: Wear gloves and
safety Glasses for protection
while doing required mainte-
nance.
Important: Aways verify proper
operation after servicing.
MAINTENANCE
(See Maintenance Schedule, Page 20)
Refertothemaintenancescheduleformaintenance
tasks, procedures, periodicity and by whom they
shouldbeperformed. Alwaysverifyproperopera-
tion of the appliance after servicing.
Millivolt Appliances - Appliances with
Millivolt systems will be fitted with the gas
control valve shown in Figure 2.
Electronic Appliances - Appliances with
electronic systems will be fitted with the
electronic valve shown in Figure 3.
Millivolt Appliances -
To light millivolt appliances refer to the detailed
lightinginstructionsfoundonPage16. Millivolt
appliance lighting instructions may also be
foundonthepulloutlightinginstructionlabels
attached to the gas control valve.
Millivolt appliances are fitted with an OFF/ON
Rocker Switch located behind the control
compartment access panel, below the appli-
ance front glass enclosure panel (see Figure 1
for location). Once the pilot is lit, the OFF/ON
rockerswitchwill control the appliance OFF/ON
burneroperation. Tooperate: Toggletheswitch
between its ON and OFF positions.
2. During the first initial burns of these appli-
ances, there will be some odor emitted (see
Burn-In Period on Page 3).
3. Keep the lower control compartment clean
by vacuuming or brushing at least twice a
year. Morefrequentcleaningmayberequired
duetoexcessivelintfromcarpeting,bedding
materials, pet hair, etc. It is very important
that the control compartments, burners
and circulating air passageways of the
appliance are kept clean.
4. Always turn off gas to the pilot (millivolt
appliances) and let the appliance cool down
before cleaning. Before re-lighting, refer
to the lighting instructions in this manual.
Lighting instructions may also be found
on the pull out lighting instruction labels
attached to the gas control valve.
5. Always keep the appliance area clear and
free from combustible materials, gasoline
and other flammable liquids.
6. Remember,Millivoltapplianceshaveacontinu-
ousburningpilotflame. Exercisecautionwhen
using products with combustible vapors.

5
NOTE: DIAGRAMS & ILLUSTRATIONS ARE NOT TO SCALE.
Important: It is imperative that
the control compartment, burn-
ers and circulating air passage
ways of the appliance be kept
clean.
Cleaning Glass
(see Front Glass Enclosure Panel, Removal and
Installation on Page 6 ). Note: Clean glass
after first two weeks of operation (after Burn-In
period is over) and then only when necessary
and when the fireplace is cool. Wipe surface
with clean, dampened, soft cloth. Follow with
dry, soft towel as desired. Take care not to
scratch the glass surface.
The viewing glass should be cleaned periodi-
cally to remove any build-up caused from the
following:
Important: Do not use abrasive
cleaners on glass. Never clean
the glass when it is hot.
WARNING: Label all wires prior
to disconnection when servic-
ing controls. Wiring errors can
cause improper and dangerous
operation. Verify proper opera-
tion after servicing.
Inspect and clean all wire connections. Ensure
that there is no melting or damage. Inspection
should include:
• Terminals at the Valve
• OFF/ON Switch
• (Optional Control Switch) Wall Thermostat,
Remote Control or Remote Wall Switch Kit
Inspect Burner Flame Appearance
Ensure that the burner flame appearance
resembles the flame shown in Figure 13 and
as described in Flame Appearance and Sooting
on Page 19.The Homeowner must contact
a qualified service technician at once if any
abnormal condition is observed.
Small Area Paint Touch-up
The finish of the appliance is a high qual-
ity powdercoat. Only use factory supplied
powdercoat paint kit for touch-ups. Paint is
availableatyourlocalauthorizedLennoxHearth
Productsdealer,cat. no. 90L74. Neverattempt
to paint a hot fireplace.
Do not attempt to repaint the appliance until the
finish is completely cured (see Burn-In Period
onPage 3 ).Ifthesurfacelaterbecomesstained
ormarred,itmaybelightlysanded and touched
up with spray paint.
• During start-up, it is normal for condensa-
tion to form on the inside of the glass (this
condensation and fog will usually disappear
in a few minutes). The moisture can cause
lint,dustandother airborne particles to cling
to the glass surface.
• Initial curing of the high temperature paint
and burning off of lubricants used in the
manufacturing process may result in a film
on the glass.
• A white coating may form on the glass
as a result of impurities and minerals in
the fuel.
It is recommended that the glass be cleaned
two or three times during each heating season,
depending on the circumstances present. The
following cleaning solutions are approved for
use to clean glass:
• Non-ammonia based household cleaner
• 50%-50% mix of white vinegar & water
• gas fireplace/stove glass cleaner
Inspect Glass Gasket - Visually inspect the
gasket on the backside of the glass enclosure
panels. The gasket surface must be clean, free
of irregularities and seated firmly.
Clean Logs And Burner
Carefully remove the logs (use care when han-
dlingthefiber logs,astheybecome quite fragile
after curing). Vacuum out any foreign matter
(lint, carbon, etc.) on the burner. Ensure the
burner ports are “open.” Remove any carbon
deposits from the under side of the logs using
a vacuum cleaner, or a soft bristled brush (i.e.
paint brush). Note: Improper positioning of
logs can create carbon build-up and will alter
the performance of the appliance.
Replacing Logs -
If the logs become damaged by accident or im-
properhandlingandneedreplacement,useonly
theproperreplacementlogsfrommanufacturer
(see Page 23 for ordering information).
Re-Install Embers, Logs and Vermiculite
- Carefully follow placement instructions on
Pages 7 to 9 ). All logs should fit onto cor-
responding pins and/or log stoppers. This will
ensure a proper flame and safe combustion.
Inspect Wiring
Refer to wiring diagrams on Page 11.
Inspect Venting System
The appliance and venting system should be
thoroughly inspected before initial use and
at least annually by a qualified service techni-
cian (inspection should include ensuring that
exhaust or intake passages are unobstructed
and vent components are properly assembled
and not damaged).
If the venting system is disassembled for any
reason, a qualified service technician should
follow vent installation instructions for proper
reassembly and proper sealing of the venting
system components. However, more frequent
periodic inspections and cleanings should be
performed by the homeowner.
Clean Lower Control Compartment
Keep lower control compartment clean by
vacuuming or brushing it out at least twice a
year (also clean the air venturi with a brush or
wire). More frequent cleaning may be required
due to accumulation of lint from carpeting,
bedding materials, pet hair, spider webs, etc. It
is very important that control compartments,
burners, circulating air passageways and air
venturi on the appliance are NOT obstructed
in any way.

6NOTE: DIAGRAMS & ILLUSTRATIONS ARE NOT TO SCALE.
WARNING: Handle this glass
with extreme care! Tempered
glass is susceptible to damage
– do not scratch or handle
roughly while reinstalling the
glass door frame.
Front Glass Enclosure Panel, Removal
and Installation
WARNING: Do not operate
appliance with the glass front
removed, cracked or broken.
Replacementoftheglass should
bedonebyalicensedorqualified
service technician.
WARNING: Do not attempt to
substitute the materials used on
this door, or replace cracked or
broken glass with any materials
other than those provided by the
appliance manufacturer.
WARNING: Theglass doorofthis
appliancemustonlybereplacedas
acompleteunitasprovidedbythe
manufacturer. Do not attempt to
replacebroken,crackedorchipped
glass separately.
WARNING: Do not attempt to
touch the front enclosure glass
with your hands while the fire-
place is in use.
These are direct-vent appliances. They are
designed to operate only when the front glass
enclosure panel is installed. Generally the front
glass enclosure panel should not be removed
except to gain access to the components within
the firebox, and the appliance may only be oper-
ated without the front glass enclosure panel
in place for very brief periods of time during
appliance checkout and adjustment. Note: The
flame appearance will be diminished while the
front glass enclosure panel is removed.
During this appliance checkout and adjust-
ment period, a potential safety hazard exists
- EXERCISE EXTREME CAUTION to prevent
the occurrence of any burn injuries from the
exposed flames or hot surfaces. Also note, that
while the front glass enclosure panel (or any of
the panels) is removed, the flame appearance
will appear to be smaller than normal.
Figure 4 - INSTALLING GLASS DOOR
Lower Compartment
Door and Hinge
Top Flange on
Glass Door
Bottom Vee-flange
Glass Door
Glass Door Latch
Glass Door
Firebox Floor
Removing Glass Enclosure Panels
(see Figure 4)
1. Remove the top louver assembly or radiant
panel by pulling it out and off.
2. Openthecontrolcompartmentaccesspanel.
by actuating the spring-loaded magnetic
catchessecuringthepanel(gentlydepressthe
outer top corners of the louvered or radiant
panel until the catches "pop" the door free,
allowingittoswingout anddowntothe open
position).
3. Locate the two (2) latches at the top of the
control compartment. To disengage the two
latches from the bottom vee-flange of the
glass enclosure panel, reach for the handles
located towards the back of the latches and
pull the handles down toward the front of
the appliance.
4. Swing the bottom of the door out and raise
it slightly to lift the top flange of the door
frame away from the appliance.
Installing Glass Enclosure Panels
(see Figure 4)
1. Visuallyinspectthegasketonthebacksideof
thepanels.Thegasketsurfacemustbeclean,
free of irregularities and seated firmly.
2.Positiontheglass enclosure panelinfrontof
the firebox opening at a 45 degree angle and
engage the top flange over the lip at the top
of the firebox opening. See Figure 4.
3. Swing the glass enclosure panel down and
back. Ensure the gasket seats evenly as the
panel draws shut. Engage the Vee-flange at
the bottom of the panel with the latches and
close the latches to secure the panel.
4. Close the bottom control compartment
access panel.

7
NOTE: DIAGRAMS & ILLUSTRATIONS ARE NOT TO SCALE.
LOG SET
Catalog Number H3210
* Item Description
A Log, Center
B Log, Left Rear
C Log, Left Front
D Log, Right Rear
E Log, Top Center
F Log, Front Center
* Item "letters" above correspond to photos on right
LOG SET - IDENTIFICATION
REFERENCE
Firebox Accessories / Parts
Cat. No. Model No. Description
88L53 FGE Bag of Glowing Embers
(1 oz. rockwool)
H6319 Vermiculite, Bag (2 liters)
F
D
Bottom View of Logs (in packaging)
Top View of Logs
C
E
A
B
Glowing Embers
Bag of Glowing
Embers (rockwool)
Separate into Quarter
Size (separate) Pieces
Top View of Logs - Installed
E
B
C
F
A
D
F
E
A
C
B
D
Figure 5
(Valve Access Side)
INSTALL GRATE, VERMICULITE, GLOWING EMBERS AND LOGS
WARNING: Thesizeandposition
of the log set was engineered
to give the appliance a safe,
reliable and attractive flame
pattern. Any attempt to use a
different log set in the fireplace
will void the warranty and will
result in incomplete combus-
tion, sooting, and poor flame
quality.

8NOTE: DIAGRAMS & ILLUSTRATIONS ARE NOT TO SCALE.
READ LOG WARNINGS ON PAGE 9 BEFORE PROCEEDING
1. Remove front glass enclosure panel from appliance.
a. Open Control Compartment Access Panel (see Control Compart-
ment Access Instructions on Page 3 ).
b. Removetheglasspanelenclosure(seeRemovingGlassEnclosure
Panel instructions on Page 6.
2. Remove the following from firebox; log set, embers (rockwool) and
vermiculite. Handle logs carefully to prevent breakage.
3. Ensure the Grate is properly installed in the firebox with the 4 legs
of the grate fitting into the 4 dimples on the firebox floor.
4. InstallVermiculite - Place some vermiculite on the firebox floor around
thegrate (theentirebagofvermiculite willNOTbeused).SeeFigure 13
on Page 9. DO NOT PLACE ANY VERMICULITE ON THE BURNER.
6. Placement of Glowing Embers -
Separate the Embers (rockwool) intopiecesabout thesize of a quarter
(see Figure 5 on Page 7). Keep the pieces fluffed up, not matted.
Distribute these pieces over the surface of the burner, as shown in
Figure 6. Do not use more than is necessary. Ensure that the main
burner ports remain uncovered by the ember material.
Note: This appliance is provided with enough Glowing Embers for
several applications, do not use all that is in a new bag at one time. For
best glowing effect, replace the ember material annually. Replacement
Glowing Embers are available (order Catalog Number 88L53).
B
C
D
(Valve Access Side)
(Valve Access Side)
(Valve Access Side)
8. Place Log (B) as shown in Figure 8.
Position Log (B) Against The Back Of
The Grate Here
Position Groove at The Bottom Of Log (B) Over The Grate
Here And Slide It Against The Back Of The Grate
Figure 8
Log (C) Lays Over Logs (A) and (B)
A
B
Position And Slide Log (D) Against The
Back Of The Grate
Place Log (D) Over The
Flat Spot On Log (A) Here
A
Position The Groove in The Back of Log (C)
Against The Grate
Figure 9
9. Place Log (C) as shown in Figure 9.
Figure 10
10. Place Log (D) as shown in Figure 10.
Figure 6
Place Embers on burner as shown.
DO NOT PLACE EMBERS OVER
GAS PORTS / AREAS CIRCLED
7. Place Log (A) on the grate as shown in Figure 7.
Position The Groove At The Bottom Of
Log (A) Over The Grate And Slide It
Forward Against The Grate Here
Figure 7
A
(Valve Access Side)
Position Groove At The Bottom Of
Log (A) Over The Log Support Here

9
NOTE: DIAGRAMS & ILLUSTRATIONS ARE NOT TO SCALE.
Position round end of log (E) against the notch of
log (D) here. Two charred spots face the front
Figure 11
10. Place Log (E) as shown in Figure 11.
WARNING: DO NOT attempt to
installthelogsuntiltheappliance
installation has been completed,
the gas line connected andtested
for leaks and the initial burner
operation has been checked out.
D
E
C
Position Small End of
Log (E) on The Notch of
Log (C) Here
(Valve Access Side)
11. Place Log (F) as shown in Figure 12.
(Valve Access Side)
F
Figure 12
Log (F) sits in front of the grate
WARNING: This appliance is
not designed to burn wood. Any
attempt to do so could cause
irreparable damage to appli-
ance and prove hazardous to
your safety.
WARNING: If logs are not
installed according to the log
installation instructions, flame
impingementandimpropercom-
bustion could occur andresult in
sootand/orexcessiveproduction
ofcarbonmonoxide(CO),acolor-
less, odorless, toxic gas.
WARNING: Logs get very hot and will remain hot up to one hour after
gas supply is turned off. Handle only when logs are cool. Turn off all
electricity to the appliance before you install grate and logs.
BURNER ADJUSTMENTS (QUALIFIED TECHNICIANS ONLY)
If the air shutter openings closed too far, sooting may develop. Sooting is indicated by black puffs
developing at the tips of very long orange flames. Sooting results in black deposits forming on the
logs, appliance inside surfaces and on exterior surfaces adjacent to the vent termination. Sooting is
caused by incomplete combustion in the flames and lack of combustion air entering the air shutter
opening. To achieve a warm yellowish-orange flame with an orange body that does not soot, the
shutter opening must be adjusted between these two extremes.
Air Shutter Adjustment Guidelines
• If there is smoke or soot present, first check the log set positioning to ensure that the flames are
not impinging on any of the logs. If the log set is properly positioned and a sooting condition
still exists, then the air shutter opening should be increased.
• The more offsets in the vent system, the larger the air shutter opening will need to be.
• An appliance operated with the air shutter opened too far, may have flames that appear blue
and transparent. These weak, blue and transparent flames are termed anemic.
• Propane models may exhibit flames which candle or appear stringy. If this is present and persists,
adjust the air shutter to a more closed position, then operate the appliance for a few more minutes
to ensure that the flame normalizes and the flames do not appear sooty.
Flame Appearance & Sooting
Proper flame appearance is a flame which is blue at the base and becomes yellowish-orange in
the body of the flame. When the appliance is first lit, the entire flame may be blue and will gradu-
ally turn yellowish-orange during the first 15 minutes of operation. If after period the flame stays
lowered blue, or if the flame is orange with evidence of sooting (black tip), the air shutter opening
may need to be adjusted.
Vermiculite
Figure 13 - Burner Flame Appearance

10 NOTE: DIAGRAMS & ILLUSTRATIONS ARE NOT TO SCALE.
Air Shutter Adjustment Guidelines:
Amount of
Primary Air
Flame
Color
Air Shutter
Adjustment
If air shutter is
closed too far Flame will be orange Air shutter gap should be
increased
If air shutter is
open too far Flame will be blue Air shutter gap should be
decreased
The following chart is provided to aid you in
achieving the correct air shutter adjustment
for your installation.
WARNING: Air shutter adjust-
ment should only be performed
byaqualifiedprofessionalservice
technician.
WARNING: Ensure front glass
panels are in place and sealed
during adjustment.
CAUTION: The air shutter door
and nearby appliance surfaces
are hot. Exercise caution to
avoidinjurywhileadjustingflame
appearance.
CAUTION: Carbon will be
produced if the air shutter is
closed too much. Any damage
due to carboning resulting from
improperly setting the air shut-
ter is not covered under the
warranty.
Burner Air Shutter Adjustment Procedure
1. Locateadjustmentrod and adjustairshutter
to the standard setting as shown in Figure
14 (adjustment rod is located in the lower
control compartment).
Note: Rotating the adjustment rod coun-
terclockwise decreases air and clockwise
increases air.
2. Lightappliance(followlightingprocedure on
lighting label in control compartment or see
homeowners manual).
3. Allowtheburnertooperateforatleast15min-
utes while observing the flame continuously
to ensure that the proper flame appearance
has been achieved (see Figure 13). If the
following conditions are present, adjust
accordingly.
• If flame appears weak or sooty, adjust
theairshutter,incrementally,toamore
open position until the proper flame
appearance is achieved.
• If flame stays lowered blue, adjust the
air shutter, incrementally, to a more
closed position until the proper flame
appearance is achieved.
4. Leave the control knob (off/pilot/on) in the
ON position and the burner OFF/ON switch
OFF (& remote switches, if applicable).
5. When satisfiedthattheburnerflameappear-
ance is normal, close the lower control
compartment door.
Adjustment Rod Positions
(when viewed from above)
Figure 14
Main Burner Factory Air Shutter
Opening Setting - All Models
Model Natural
Gas
Propane
Gas
MPD35ST
1/8”
3.2mm
1/4”
6.4mm
Increase Shutter Opening
In This Direction
Decrease Shutter Opening
In This Direction
Orifice
Air Shutter
Adjusting
Rod
Electronic Appliance Checkout
To light the burner, refer to the lighting instruc-
tions on Page 18. Ensure the igniter lights the
pilot. The pilot flame should engulf the flame
sensor as shown in Figure 16.
Figure 16
3/8" to 1/2"
(9 -13 mm)
Ground
Electrode
Flame Rod
Hot Surface
Igniter
Proper Flame
Adjustment
Pilot
Nozzels
Millivolt Appliance Checkout
The pilot flame should be steady, not lifting
or floating. Flame should be blue in color with
traces of orange at the outer edge.
The top 3/8" (10 mm) at the pilot generator
(thermopile) and the top 1/8" minimum (tip)
of the quick drop out thermocouple should be
engulfed in the pilot flame. The flame should
project 1" (25 mm) beyond the hood at all three
ports. See Figure 15.
To light the burner, refer to the lighting instruc-
tions on Page 16.
ELECTRONIC PILOT ASSEMBLY
Proper Pilot Flame Appearance
Figure 15
Thermocouple
Thermopile
Pilot
Nozzels
MILLIVOLT PILOT ASSEMBLY
3/8" Min.
(9 mm)
Igniter Rod
Hood
Proper Pilot Flame Appearance
Withpropercareandmaintenance, yourappli-
ance will provide many years of enjoyment. If
you should experience any problem, first refer
to the troubleshooting guide in this manual.
If problem persists, contact your Lennox
distributor.
Ref. Air shutter Patent:
U.S. Pat. 5,553,603
Note - Burners are
omitted in this
view for clarity.

11
NOTE: DIAGRAMS & ILLUSTRATIONS ARE NOT TO SCALE.
WARRANTY
Your gas appliance is covered by a limited
twenty year warranty. You will find a copy
of the warranty accompanying this manual.
Please read the warranty to be familiar with
its coverage.
Retain this manual. File it with your other
documents for future reference.
REPLACEMENT PARTS
A complete parts list is found at the end of
this manual. Use only parts supplied from the
manufacturer.
Normally, all parts should be ordered through
your Lennox distributor or dealer. Parts will be
shipped at prevailing prices at time of order.
Ifyouencounteranyproblemsorhaveanyques-
tions concerning the installation or application
of this system, please contact your distributor,
or Lennox directly:
LENNOX HEARTH PRODUCTS
1110 West Taft Avenue
Orange, CA 92865
visit us at www.Lennox.com
PRODUCT REFERENCE INFORMATION
We recommend that you record the following
important information about your fireplace.
Please contact your Lennox dealer for any
questions or concerns. For the number
of your nearest Lennox dealer, please call
1-800-9-LENNOX
Your Fireplace's Model Number________________________________________
Your Fireplace's Serial Number ________________________________________
The Date On Which Your Fireplace Was Installed___________________________
The Type of Gas Your Fireplace Uses ____________________________________
Your Dealer's Name ________________________________________________
When ordering repair parts, always give the
following information:
1. The model number of the appliance.
2. The serial number of the appliance.
3. The part number.
4. The description of the part.
5. The quantity required.
6. The installation date of the appliance.
WIRING DIAGRAMS
Wiring diagrams are provided here for refer-
ence purposes only. This information is also
provided on schematics attached directly to the
appliance on a pullout panel located within the
control compartment.
TH
TP TH
TP
Thermopile
If any of the original wire as supplied must
be replaced, it must be replaced with Type
AWM105 C - 18 gage wire.
*OptionalKitsInstalled-OFF/ONwallswitch,
wall thermostat or remote control receiver.
Note: Turn the appliance-mounted OFF/ON
burner control switch to the OFF position if
any of these kits are installed.
Millivolt Wiring Diagram
Schematic Representation Only
Field Wired
Factory
Wired
*Opt.
Switch
Standard OFF/ON Switch
CAUTION: Label all wires prior
to disconnection when servic-
ing controls. Wiring errors can
cause improper and dangerous
appliance operation.
Figure 17
Electronic Wiring Diagram (Honeywell) Showing Blower Wiring for Optional FBK-100, FBK-200 & FBK-250 Kits
Schematic Representation Only
G
BK
120
VAC
Relay Module C/W FBK-250 only. Plug blower
into J-Box receptacle for FBK-100 or FBK-200
application. View A for J-Box wiring.
Optional Blower
*OFF/ON Switch
(Integral with
Gas Valve)
Honeywell
Electronic
Gas
Valve
120 VAC
Primary
Secondary
Optional Control Switch
Junction
Box
Junction Box
Pilot Burner
Assembly
BL
BL
Wall Mounted Blower Speed Control Switch or
ON/OFF Switch for Blower Kit (optional)
Field Wired
Factory
Wired
BK = BLACK BL = BLUE
R = RED W = WHITE
G = GREEN
BK
W
BK
BK BL
R
GROUND
24 V
Transformer
Auxiliary View A
J-Box Wiring when
using unit mounted
relay module.
BK
W
G
C
AV
02
1
Igniter
Connector
W
GBK
R
* Leave the OFF/ON switch, which is
integral with the gas valve, in the ON
position.
**Optional Control Switches: Wall
Switch, Wall Thermostat or Remote
Control Receiver.
Notes:
1. If any of the original wire as supplied
must be replaced, use Type AWM 105°C
- 18 gage wire ONLY.
2. 120 VAC, 60 Hz - Less than 3 Amps.
Caution: label all wires prior to
disconnection when servicing controls.
Wiring errors can cause improper and
dangerous operation.
WhiteWire
to Opposite
Side (neutral)
Outlet Box Green
Ground Screw
Break off Tab
Hot side
of Outlet
Figure 18

Product Reference Information
Cat.
No.
Model Ship.
Weight
Ship.
Volumn
H3201 MPD35ST-NM-B 220 lbs 46W x 26D x
43H (30 cu.ft.)
H6945 MPD35PF-NM-B 225 lbs 46W x 26D x
43H (30 cu.ft.)
H3202 MPD35ST-PM-B 220 lbs 46W x 26D x
43H (30 cu.ft.)
H6946 MPD35PF-PM-B 225 lbs 46W x 26D x
43H (30 cu.ft.)
H3203 MPD35ST-NE-B 220 lbs 46W x 26D x
43H (30 cu.ft.)
H6947 MPD35PF-NE-B 225 lbs 46W x 26D x
43H (30 cu.ft.)
12 NOTE: DIAGRAMS & ILLUSTRATIONS ARE NOT TO SCALE.
Deluxe Remote Control System
The Model RCL-T (Deluxe) Remote Control System
has all of the features of the standard system along
withanaddedeasytoreadLCDscreenwhichpresents
access to many enhancements, including; battery
power level indicator, timer, mode of operation,
thermostatic display including room temperature in
either metric of English units, flame indicator and
clock. Fully programmable, the Model RCL-T allows
for virtual command over nearly all operational and
temperature variables, using the hand held remote
control transmitter.
The Model RCL-T (Deluxe) remote control system
is installed in the same manner as the standard
system, may be operated with electronic and mil-
livolt systems with either natural gas or propane gas.
The RCL-T comes complete with detailed operating
instructions.
ACCESSORY COMPONENTS
Standard Remote Control System
The Model RCL (Standard) Remote Control System,
features a simplistic OFF/ON control function for the
fireplace. Thismodelincludesahand-heldtransmitter,
a remote receiver with wall-mount cover plate and
all hardware required to install the unit. The remote
receiver can be wall or hearth mounted.
The transmitter has ON and OFF functions that are
activated by pressing either button on the face of
the transmitter. When a button on the transmitter
is pressed, a signal light illuminates briefly to verify
that a signal has been sent.
The Model RCL is designed to operate with all mil-
livolt ignition systems, as well as electronic ignition
systems. It may be installed with use for either
natural gas or propane gas appliances. The RCL
offers ease of installation and allows you to execute
on-off commands to the fireplace effortlessly with
one simple motion.
TheModelRCL comescompletewithdetailed operat-
ing instructions.
Remote Control Kit, Standard
Cat. No. Model No. Description
H0249 RCL Remote Control System
(Standard)
Remote Control Kit, Deluxe
Cat. No. Model No. Description
H0251 RCL-STAT Remote Control System
(Deluxe)
OFF/ON Wall Switch Kit
The OFF/ON wall switch kit may be used to control
the operation of the fireplace burner. Install the
OFF/ON wall switch in a convenient location near
the fireplace.
White Wall Switch Kit
Cat. No. Model No. Description
85L87 FWSK OFF/ON Wall Switch Kit
(ref. Form # 750,127M) (ref. Form # 750,129M)
Forced Air Kit
TheFBK-100blowerprovidesconstantvelocityforced
air circulation. The FBK-200 assembly with variable
speed,wall-mountableswitchprovidesvariablespeed
forced air circulation. The FBK-250 assembly with
variable speed unit-mountable switch, also provides
variable speed forced air circulation.
Forced Air Blower Kits
Cat.
No.
Model No. Description
80L84 FBK-100 Blower, Standard
(single speed)
80L85 FBK-200 Blower, Variable Speed
(w/wall-mounted switch)
80L86 FBK-250 Blower, Variable Speed
(w/unit-mounted switch)
94L89 FBK-100-36 Blower, Standard, 36 Pack
94L90 FBK-200-36 Blower Kit - Variable Speed
with Wall Switch 36 Pack
H0543 FBK-250-36 Blower Kit - Variable Speed
with Thermo Snap Switch
36 Pack
(ref. Form # 750,028M & 750,029M)
Digital Wall Thermostat
The wall thermostat kit provides temperature control
for optimum comfort.
Wall Thermostat, Millivolt
Cat. No. Model No. Description
H4635 DWTK Wall Thermostat Kit,
White

Screen Heat Guard Kit
Thiseasyto install optionalscreen heat guardinstalls
over the standard glass enclosure panel to prevent
contact with the hot glass surface. These screen
heat guard panels cannot be used in conjunction
with the arch door kits or door frame kits. Order 2
if a set is desired (for front face and rear face glass
surfaces).
*Screen Heat Guard Kit
Cat. No. Model No. Description
26M48 HG35M 35" Screen Heat Guard Kit
H7018 HG22M 22" Screen Heat Guard Kit
* Order 2 for set if desired.
(ref. Form # 750,101M)
Decorative Arch Screen Panel Kit
Cat. No. Model Description
H3593 DASPK35TI 35” Dec. Arch Screen Panel
(ref. Form # 750,199M)
Decorative Arch Screen Panel Kit
This easy to install optional screen installs over the
standard glass enclosure panel to provide protection
from direct contact with the hot glass surface. These
screen panels cannot be used in conjunction with
the arch door kits or door frame kits.
(ref. Form # 750,200M)
13
NOTE: DIAGRAMS & ILLUSTRATIONS ARE NOT TO SCALE.
Arch Design Kits
H0858 AD35C 35” Arch Doors
H0859 AD35TI 35” Arch Doors, Textured Iron
H0860 AD35SP 35” Arch Doors, Satin Pewter
H0861 AD35AB 35” Arch Doors, Antique Brass
Arch Pane Design Kits
Cat. No. Model Description
H0930 APD35C 35” Arch Pane Doors
H0931 APD35TI 35” Arch Pane Doors, Text. Iron
H0932 APD35SP 35” Arch Pane Doors, Satin Pew.
H0933 APD35AB 35” Arch Pane Doors, Ant. Brass
Square Design Kits
H0946 SD35C 35” Sq. Doors
H0947 SD35TI 35” Sq. Doors, Textured Iron
H0948 SD35SP 35” Sq. Doors, Satin Pewter
H0949 SD35AB 35” Sq. Doors, Antique Brass
Square Pane Design Kits
H0962 SPD35C 35” Sq. Pane Doors
H0963 SPD35TI 35” Sq. Pane Doors, Text. Iron
H0964 SPD35SP 35” Sq. Pane Doors, Satin Pew.
H0965 SPD35AB 35” Sq. Pane Doors, Ant. Brass
Style View Screen Doors -
These Style View screen doors come in 4 beautiful
styles. They are easy to install and will not require
hardware to attach them to the standard glass door
frame. The screens prevent direct contact with the
hot glass surface. The door includes heavy duty
magnet door latches and functional twin-pane
screen doors.
Arch
Design
Arch Pane
Design
Square
Pane
Design
Square
Design
Clean Face Charcoal Radiant Panel Kits
Cat. No. Model No. Description
88L36 RAD35C-2 Clean Face Panel Kit
H7019 RAD22C-2 Clean Face Panel Kit
Clean Face Panel Kits
Cleanfacedpanelkitsareavailabletoconvertthestan-
dard louvered fireplaces to radiant models which are
more suited for finishing around the firebox opening
with non-combustible materials, such as tile.
ACCESSORY COMPONENTS
(ref. Form # 775,169M)
(ref. Form # 504,223M)
Note: Door & Trim Kits are for 1 side only. If set is desired, order 2 kits.
Style View Tall Arch 35" Pane Screen Door Kits
Cat.No. Model Description
H3525 TAPD35C Arch Pane, Black
H3527 TAPD35SP Arch Pane, Satin Pewter
Tall Style View Doors
These decorative screen doors are offered in four
attractive finishes and fit on the face of the appliance
over the glass doorframe to prevent direct contact
with the hot glass surface. These doors replace
the bottom louver assembly and cover the control
compartment which elongates the appearance of the
height of the fireplace face.
Brickaded Wall Liner Kits
Cat. No. Model No. Description
H3207 MBLK-35ST Interior Brick Liner Kit
Brickaded Panel Liner Kit
The brickaded liner kits include ceramic panels as shown here.
The panels have brick-like features in relief.
(ref. Form # 750,160M)

14 NOTE: DIAGRAMS & ILLUSTRATIONS ARE NOT TO SCALE.
4 Piece Trim Kit
Cat. No. Model No. Description
96K17 TK35PB4 35” 4 Piece Finish Trim Kit,
Polished Brass
(ref. Form # ii-9299)
2-PiecePolishedBrassandBrushedStainless
Louvers Kits
Theselouversaredesignedtoreplaceeitherthemiddle
charcoal louver of each set or the charcoal louver in
each set closest to the glass door. These kits include
twonarrowlouvers. They provideatouchof elegance
to these appliances. These kits can be retrofitted to
previously installed appliances.
2-Piece Louver Kits
Cat. No. Model No. Description
96L05 2LVR35PB 2 Pc. Louver Kit,
Polished Brass
H7022 2LVR22PB 2 Pc. Louver Kit,
Polished Brass
96L09 2LVR35BS 2 Pc. Louver Kit,
Brushed Stainless
H7023 2LVR22BS 2 Pc. Louver Kit,
Brushed Stainless
(ref. Form # 504,224M)
Polished Brass & Brushed Stainless Louvers Kits
Decorative louvers are available for use with all
Multi-Open Series appliances.These kits include a
top3-pieceassemblyandabottom3-pieceassembly.
They provide a touch of elegance to any Multi-Open
Series appliance. These kits can be retrofitted to
previously installed appliances.
35" Assembled Louver Kits
Cat. No. Model No. Description
88L28 LVR35PB-2 Louver Kit, Polished
Brass
H7024 LVR22PB-2 Louver Kit, Polished
Brass
88L32 LVR35BS-2 Louver Kit, Brushed
Stainless
H7025 LVR22BS-2 Louver Kit, Brushed
Stainless
These kits are designed to attach directly to the front
face of the appliance at the glass enclosure panel’s
top and bottom edges.
3 Piece Trim Kit
Cat. No. Model No. Description
96K21 TK35PB3 35” 3 Piece Finish Trim Kit,
Polished Brass
H4821 TK35C3 35” 3 Piece Finish Trim Kit,
Black
2 Piece Trim Kit
Cat. No. Model No. Description
26M88 2DFK35PB 35” Door Trim Kit, Polished
Brass (2 Piece, Top and
Bottom)
H7020 2DFK22PB 22” Door Trim Kit, Polished
Brass (2 Piece, Top and
Bottom)
26M91 2DFK35BS 35” Door Trim Kit, Brushed
Stainless (2 Piece, Top and
Bottom)
H7021 2DFK22BS 22” Door Trim Kit, Brushed
Stainless (2 Piece, Top and
Bottom)
(ref. Form # 750,119M)
(ref. Form # 750,098M)
(ref. Form # 750,147M)
Polished Brass Trim Kit
This kit contains brass trim pieces used to finish the
gapsbetweenthewallboardandthefireplace,provid-
ing the appliance a brass perimeter highlight. This kit
contains the trim pieces and these instructions.
2-Piece Door Frame Kits
H3541 CUGK35C 35” Black UPPER GRILLE KITS
CRESCENTS
H3543 CUGK35SP 35” Satin Pewter
H3569 SLGK35C 35” Black LOWER GRILLE KITS
SUNRISE
H3571 SLGK35SP 35” Satin Pewter
Cat. No.#Model Description Model Series
H3565 SUGK35C 35” Black UPPER GRILLE KITS
SUNRISE
H3567 SUGK35SP 35” Satin Pewter
H3545 CLGK35C 35” Black LOWER GRILLE KITS
CRESCENTS
H3547 CLGK35SP 35” Satin Pewter
Sunrise Style (upper grille shown)
Crescent Style (lower grille shown)
(ref. Form # 750,202M)
ACCESSORY COMPONENTS Note: Door & Trim Kits are for 1 side only. If set is desired, order 2 kits.
Decorative Grille Kits
These decorative grilles are offered in two attractive finishes and fit on the
face of the appliance in place of the standard louvers.

15
NOTE: DIAGRAMS & ILLUSTRATIONS ARE NOT TO SCALE.
Polished Brass & Brushed Stainless Hood Kits
Attractive hoods are available in two styles to be used on the Multi-Open Series appliances. These hoods are
designed to be fitted to the glass viewing sides of the appliance. In addition to providing an aesthetically pleas-
ing appearance to your appliance installation, the hood reduces heat effects to decorative mantles and finish
materials located above the fireplace opening. The hood kit replaces the standard hood that comes with these
appliances and snaps into place. These kits can be retrofitted to previously installed appliances.
ACCESSORY COMPONENTS
*Eyebrow Hood Kits
Cat. No. Model No. Description
96K67 EB35PB Hood Kit, Polished
Brass
H7028 EB22PB Hood Kit, Polished
Brass
88L49 EB35BS Hood Kit, Brushed
Stainless
H7029 EB22BS Hood Kit, Brushed
Stainless
* These hood kits replace the standard hood that
comes with these fireplaces.
Door Frame Kits
A decorative door frame kit is available for use with these appliances. It is designed to attach directly to the
front face of the appliance at the four edges of the glass enclosure panel resulting in the appearance of a
picture frame.
4 Piece Door Trim Kits
Cat. No. Model No. Description
26M82 4DFK35PB Door Trim, Polished Brass
H7030 4DFK22PB Door Trim, Polished Brass
26M85 4DFK35BS Door Trim, Brushed Stainless
H7031 4DFK22BS Door Trim, Brushed Stainless
(ref. Form # 750,098M)
(ref. Form #504,142M)
Arch Door Kits
Two types of arch door kits are available for the Multi-Open Series. Both types of kits are easy to install and
do not require hardware to attach them to the standard door frame. These kits can be retrofitted to previously
installed Multi-Open Series appliances. The decorative arch kits can not be used in conjunction with the screen
panel kit.
* 35" Arch Door Kits
Cat. No. Model No. Description
26M43 ADK35CMPB Arch Door, Polished Brass
H7026 ADK22CMPB Arch Door, Polished Brass
26M44 ADK35CMBS Arch Door, Brushed Stainless
H7027 ADK22CMBS Arch Door, Brushed Stainless
* Order 2 for set if desired.
(ref. Form # 750,021M)
Touch-Up Paint Kit
Repair of minor scratches and discoloration of the
appliance charcoal painted surfaces may be accom-
plished with the touch-up paint kit.
Touch-Up Paint Kits
Cat. No. Model No. Description
90L73 TPK-B Touch-Up Paint (Black)
98K67 TPK-T Touch-Up Paint (Tan)
(TPK-C ref. Form # 504,216M)
P
A
I
N
T
Bag of Glowing Embers
Bag of Volcanic Stone
Replacement ember materials or volcanic stone are
available for use with these appliances. Order kits as
part of the periodic maintenance of the appliance.
Decorative Firebox Accessories
Cat. No. Model No. Description
88L53 FGE Bag of Glowing Embers
(1 oz. rockwool)
80L42 FDVS Bag of Decorative
Volcanic Stone
(FDVS ref. Form #750,010M)

16 NOTE: DIAGRAMS & ILLUSTRATIONS ARE NOT TO SCALE.
WARNING: IF YOU DO NOT FOLLOW THESE INSTRUCTIONS EXACTLY, A FIRE OR EXPLO-
SION MAY RESULT CAUSING PROPERTY DAMAGE, PERSONAL INJURY OR LOSS OF LIFE.
6. Wait five (5) minutes to clear out any gas. If you then smell gas,
STOP! Follow “B” in the safety information above on this page. If you
do not smell gas, go to the next step.
7. Push in gas control knob slightly and turn counterclockwise
to “PILOT.”
8. Push in control knob all the way and hold in. Immediately light the
pilot by triggering the spark igniter (pushing the button) until pilot
lights. Continue to hold the control knob in for about 1 1/2 minutes
after the pilot is lit. Release knob and it will pop back up. Pilot should
remain lit. If it goes out, repeat steps 5 through 8.
•If knob does not pop up when released, stop
and immediately call your service technician
or gas supplier.
•If pilot will not stay lit after several tries,
turn the control knob to “OFF” and call
your service technician or gas supplier.
9. Turn gas control knob counterclockwise
to “ON.”
10. Close lower control compartment.
LIGHTING INSTRUCTIONS – MILLIVOLT GAS VALVE
FOR YOUR SAFETY READ BEFORE LIGHTING
A. This appliance has a pilot which must be lit with a piezo
igniter. When lighting the pilot, follow these instructions
exactly.
B. BEFORE OPERATING smell all around the appliance area for
gas. Ensure to smell next to the floor because some gas is
heavier than air and will settle on the floor.
WHAT TO DO IF YOU SMELL GAS
•Extinguish any open flame.
•Open windows.
•Do not light any appliance.
•Do not touch any electrical switches.
TO TURN OFF GAS TO APPLIANCE
1. Turn remote wall switch “OFF.” The pilot will remain lit for
normal service.
2. For complete shutdown, turn remote wall switch to “OFF.”
3. Access the lower control compartment.
4. Depress gas control knob slightly and turn clockwise
to “OFF.” Do not force.
5. Close lower control compartment.
LIGHTING INSTRUCTIONS
1. STOP! Read the safety information above on this page.
2. Access the lower control compartment.
3. Turn OFF/ON switch to “OFF” (and remote wall switch, if appli-
cable).
4. Verify main line shut-off valve is open.
5. Push in gas control knob slightly and turn clockwise
to “OFF.”
•Do not use any phone in your building.
•Immediately call your gas supplier from a neighbor’s
phone.
•If your gas supplier cannot be reached, call the fire depart-
ment.
C. Use only your hand to push in or turn the gas control knob.
Never use tools. If the knob will not push in or turn by hand,
do not try to repair it, call a qualified service technician. Force
or attempted repair may result in a fire or an explosion.
D. Do not use this appliance if any part has been under water.
Immediately call a qualified service technician to inspect the
appliance and to replace any part of the control system and
any gas control which has been under water.
Note: Knob cannot be turned from “PILOT” to “OFF”
unless the knob is pushed in slightly. Do not force.
Millivolt Pilot
H
I
L
O
W
TPTH TP TH
P
I
L
O
T
P
I
L
O
T
O
N
it
O
F
F
OUT
IN
SIT Millivolt Gas Valve
- LO / HI + GAS CONTROL
KNOB
TP/TH
TH
TP
PIEZO
IGNITER
BURNER
OFF/ON SWITCH
OFF
ON

17
NOTE: DIAGRAMS & ILLUSTRATIONS ARE NOT TO SCALE.
AVERTISSEMENT : SI VOUS NE SUIVEZ PAS CES INSTRUCTIONS À LA LETTRE, IL POURRAIT S’EN SUIVRE UN INCENDIE OU
UNE EXPLOSION CAUSANT DES DOMMAGES MATÉRIELS, DES BLESSURES CORPORELLES OU MÊME DES PERTES DE VIE.
INSTRUCTIONS D’ALLUMAGE – VANNE GAZ MILLIVOLT
INSTRUCTIONS D'ALLUMAGE
8. Enfoncez le bouton de réglage jusqu’au fond et gardez-le enfoncé.
Allumez immédiatement la veilleuse en déclenchant l’allume-gaz
à étincelle (en poussant le bouton) jusqu’à ce que la veilleuse
s’enflamme. Continuez de tenir le bouton de réglage enfoncé
pendant environ 90 secondes après l’allumage de la veilleuse.
Relâchez le bouton et il sortira subitement. La veilleuse devrait
rester allumée. Si elle s’éteint, répétez les étapes 5 à 8 inclusive-
ment.
• Si le bouton ne sort pas automatiquement après avoir été relâché,
arrêtez immédiatement et téléphonez à votre technicien de service
ou à votre fournisseur de gaz.
• Si la veilleuse refuse de rester allumée après plusieurs tentatives,
tournez le bouton de réglage jusqu’à sa position d’arrêt “OFF” et
téléphonez à votre technicien de service ou à votre fournisseur de
gaz.
9. Tournez le bouton de réglage du gaz en sens inverse des aiguilles
d’une montre jusqu’à sa position de marche “ON”.
10. Fermez le compartiment de contrôle du bas.
11. Au besoin, rebrancher l’appareil au
courant électrique et remettre
l’interrupteur du brûleur principal
à la position “ON” ou régler le
0thermostat à la température désirée.
12. Si l’appareil ne fonctionne pas,
suivre les instructions intitulées
“Pour fermer le gaz qui alimente
l’appareil” et appeler un technicien
ou le fournisseur de gaz.
POUR VOTRE SÉCURITÉ, LISEZ CES INSTRUCTIONS AVANT L’ALLUMAGE
A. Cet appareil est muni d’une veilleuse qui doit être allumée avec un
allumeur piézo-électrique. Lorsque vous allumez la veilleuse, suivre
exactement ces instructions.
B. AVANTL’ALLUMAGE:Ensurez-vous quevousnedétectezaucune odeur
de gaz autour de l’apareil ainsi que près du sol; certains gaz, étant plus
lourds que l’air, descendent au niveau du sol.
VOICI CE QUE VOUS DEVEZ FAIRE SI VOUS DÉCELEZ UNE ODEUR
DE GAZ:
•Éteignez toute flamme visible.
•Ouvrez les fenêtres.
•N’allumez aucun appareil.
•Ne touchez à aucun commutateur électrique.
•Ne vous servez d’aucun téléphone dans votre édifice.
•Appelez immédiatement votre compagnie de gaz en utilisant le télé-
phone du voisin.
•S’il vous est impossible de contacter votre compagnie de gaz, appelez
le service des incendies.
C. N’utilisez que votre main pour manipuler le bouton de réglage du gaz.
N’utilisez jamais d’outils. Si le bouton refuse de tourner ou de bouger,
n’essayez pas de le réparer. Communiquez immédiatement avec un
technicien de service qualifié. Toute tentative pour le forcer ou le
réparer, risquerait de provoquer un incendie ou une explosion.
D. Ne vous servez pas de cet appareil si l’un de ses éléments a été
immergé dans l’eau. Appelez immédiatement un technicien compétent
pour faire inspecter l’appareil et remplacer toute pièce du système de
réglage ou commande du gaz qui a été sous l’eau.
1. ARRÊTEZ! Lisez les consignes de sécurité au verso de cette plaque.
2. Ouvrez le compartiment de contrôle du bas.
3. Tournez l’interrupteur mural à la position d’arrêt “OFF”.
4. Ensurez-vous que la soupape d’arrêt de la canalisation principale est
ouverte.
5. Enfoncez légèrement le bouton de réglage du gaz et tournez-le dans
le sens des aiguilles d’une montre jusqu’à la position
d’arrêt “OFF”.
Remarque: Il est impossible de tourner le bouton de “PILOT” à “OFF” à
moins qu’il ne soit légèrement enfoncé. Ne le forcez pas.
6. Attendez cinq (5) minutes pour l’evacuation du gaz. Si vous décelez
une odeur de gaz, ARRÊTEZ ! Retournez au point “B” des consignes
de sécurité au verso de cette plaque. Si vous ne remarquez aucune
odeur de gaz, passez à l’étape suivante.
7. Enfoncez légèrement le bouton de réglage du gaz et tournez-le en
sens inverse des aiguilles d’une montre jusqu’à la position de veil-
leuse “PILOT”.
1. Tournez l’interrupteur mural à la position d’arrêt “OFF”. La veilleuse
restera allumée jusqu’au retour du service normal.
2. Pour une fermeture complète, tournez l’interrupteur mural à la posi-
tion d’arrêt “OFF”.
3. Ouvrez le compartiment de contrôle du bas.
POUR FERMER LE GAZ QUI ALIMENTE L’APPAREIL
4. Enfoncez légèrement le bouton de réglage du gaz et tournez-le dans
le sens des aiguilles d’une montre jusqu’à la position
d’arrêt “OFF”. Ne forcez pas le bouton.
5. Fermez le compartiment de contrôle du bas.
Millivolt Pilot
BOUTON DE RÉGLAGE DU GAZ
- LO / HI + (COMMANDE
DE TAILLE DE FLAMME)
H
I
L
O
W
TPTH TP TH
P
I
L
O
T
P
I
L
O
T
O
N
it
O
F
F
OUT
IN
SIT Vanne Gaz Millivolt
TP/TH
TH
TP
ALLUMEUR
Interrupteur
(OFF/ON)
OFF
ON

18 NOTE: DIAGRAMS & ILLUSTRATIONS ARE NOT TO SCALE.
A. When lighting the appliance, follow these instructions
exactly.
B. BEFORE OPERATING smell all around the appliance area
for gas. Be sure to smell next to the floor because some
gas is heavier than air and will settle on the floor.
WHAT TO DO IF YOU SMELL GAS
•Extinguish any open flame.
•Open windows.
•Do not light any appliance.
•Do not touch any electrical switches.
•Do not use any phone in your building.
FOR YOUR SAFETY READ BEFORE LIGHTING
•Immediately call your gas supplier from a neighbor’s
phone.
•If your gas supplier cannot be reached, call the fire
department.
C. Use only your hand to turn the gas control lever. Never
use tools. If the lever will not turn by hand, do not try
to repair it, call a qualified service technician. Force or
attempted repair may result in a fire or an explosion.
D. Do not use this appliance if any part has been under
water. Immediately call a qualified service technician
to inspect the appliance and to replace any part of the
control system and any gas control which has been under
water.
LIGHTING INSTRUCTIONS — ELECTRONIC
1. For complete shut-down, turn remote wall switch to
“OFF.”
2. Open lower control compartment door.
3. Turn the OFF/ON switch to “OFF”. Do not force.
4. Close the main line shut-off valve.
5. Close lower control compartment door.
TO TURN OFF GAS TO APPLIANCE
LIGHTING INSTRUCTIONS
1. STOP! Read the safety information above on this page.
2. Turn remote wall switch to “OFF.”
3. Open lower control compartment door.
4. Verify main line shut-off valve is open.
5. Turn the OFF/ON switch to “OFF”. Do not force.
6. Wait five (5) minutes to clear out any gas. If you then
smell gas, STOP! Follow “B” in the safety information
above on this page. If you do not smell gas, go to the
next step.
7. Turn the OFF/ON switch to “ON”. Do not force.
8. Turn “ON” all electrical power to appliance (remote wall
or appliance switch).
9. Close lower control compartment door.
TO SHUT OFF
1. Turn off all electrical power to the appliance (remote wall
switch).
F
F
O
N
I
PSI
NO
L
O
R
T
N
O
C
G
INT
IER
Honeywell Electronic Gas Control Valve
ON / OFF Switch
Front View
WARNING: IF YOU DO NOT FOLLOW THESE INSTRUCTIONS EXACTLY, A FIRE OR EXPLO-
SION MAY RESULT CAUSING PROPERTY DAMAGE, PERSONAL INJURY OR LOSS OF LIFE.

19
NOTE: DIAGRAMS & ILLUSTRATIONS ARE NOT TO SCALE.
INSTRUCTIONS D’ALLUMAGE — ELECTRONIC
INSTRUCTIONS D’ALLUMAGE
POUR VOTRE SÉCURITÉ, LISEZ CES INSTRUCTIONS AVANT L’ALLUMAGE
A. Lorsquevousallumez l’appareil, suivezexactementcesinstruc-
tions.
B. AVANT L’ALLUMAGE: Assurez-vous que vous ne détectez
aucune odeur de gaz autour de l’apareil ainsi que près du sol;
certains gaz, étant plus lourds que l’air, descendent au niveau
du sol.
VOICI CE QUE VOUS DEVEZ FAIRE SI VOUS DÉCELEZ UNE
ODEUR DE GAZ
•Éteignez toute flamme visible.
•Ouvrez les fenêtres.
•N’allumez aucun appareil.
•Ne touchez à aucun commutateur électrique.
•Ne vous servez d’aucun téléphone dans votre édifice.
•Appelez immédiatement votre compagnie de gaz en utilisant
le téléphone du voisin.
•S’il vous est impossible de contacter votre compagnie de
gaz, appelez le service des incendies.
C. N’utilisez que votre main pour manipuler l'interrupteur
“OFF/ON” de la valve à gaz. N’utilisez jamais d’outils. Si
l’interrupteur ne bouge pas manuellement, n’essayez pas de
le réparer. Communiquez immèdiatement avec un technicien
de service qualifié. Toute tentative pour forcer l’interrupteur
ou le réparer, risquerait de provoquer un incendie ou une
explosion.
D. Ne vous servez pas de cet appareil si l’un de ses éléments a
été immergé dans l’eau. Appelez immédiatement un technicien
compétent pour faire inspecter l’appareil et remplacer toute
pièce du système de réglage ou commande du gaz qui a été
sous l’eau.
1. ARRÊTEZ ! Lisez les consignes de sécurité au verso de cette
plaque.
2. Tournez l’interrupteur mural à la position d’arrêt “OFF”.
3. Ouvrez la porte du compartiment de contrôle du bas.
4. Assurez-vousquelasoupape d’arrêtdelacanalisationprincipale
est ouverte.
5. Tournez la manette de réglage du gaz à la position d’arrêt
“OFF”.
6. Attendez cinq (5) minutes pour l’evacuation du gaz. Si vous
décelez une odeur de gaz ARRÊTEZ ! Retournez au point “B”
des consignes de sécurité au verso de cette plaque. Si vous ne
remarquez aucune odeur de gaz, passez à l’étape suivante.
7. Tournez la manette de réglage du gaz jusqu’à la position de
marche “ON”. Ne la forcez pas.
8. Ouvrez le courant électrique (“ON”) qui alimente l’appareil
(interrupteur mural ou l'appareil).
9. Fermez la porte du compartiment de contrôle du bas.
10. Au besoin, rebrancher l’apareil au courant électrique et
remettre l’interrupteur principal du brûleur à la position “ON”
ou régler le thermostat à la température désirée.
11. Si l’appareil ne se met pas en marche, suivre les instruc-
tions intitulées “Pour fermer le gaz qui alimente l’appareil” et
appeler un technicien ou le fournisseur de gaz.
POUR ÉTEINDRE L’APPAREIL
1. Coupez tout le courant électrique qui alimente l’appareil (inter-
rupteur mural).
POUR FERMER LE GAZ QUI ALIMENTE L’APPAREIL
3. Tournez la manette de réglage du gaz à la position d’arrêt “OFF”.
Ne la forcez pas.
4. Fermez la soupape d’arrêt de la canalisation principale.
5. Fermez la porte du compartiment de contrôle du bas.
1. Pour une fermeture complète, tournez l’interrupteur mural à la
position d’arrêt “OFF”.
2. Ouvrez la porte du compartiment de contrôle du bas.
F
F
O
N
I
PSI
NO
L
O
R
T
N
O
C
G
INT
IER
Interrupteur ON / OFF
Vue de face
Honeywell Vanne Gaz Électronique
AVERTISSEMENT : SI VOUS NE SUIVEZ PAS CES INSTRUCTIONS À LA LETTRE, IL POURRAIT S’EN SUIVRE UN INCENDIE OU
UNE EXPLOSION CAUSANT DES DOMMAGES MATÉRIELS, DES BLESSURES CORPORELLES OU MÊME DES PERTES DE VIE.

20 NOTE: DIAGRAMS & ILLUSTRATIONS ARE NOT TO SCALE.
MAINTENANCE TASK ACCOMPLISHING PERSON PROCEDURE
Inspecting/Cleaning Burner, Logs
and Controls Qualified Service Technician Inspect valve and ensure it is properly operating. Check piping for leaks. Vacuum the control compartment, fireplace logs and
burner area.
Check Flame Patterns and Flame
Height Qualified Service Technician Refer to Figure 13 on Page 9 and verify the flame pattern and
heightdisplayedbytheapplianceconformstothepicture. Flames
must not impinge on the logs. Ensure flames are steady (not
lifting or floating).
Inspecting/Cleaning Pilot and Burner Qualified Service Technician Refer to Figures 15 &16 on Page 10. Remove any surface
build-up on pilot and burner assembly. Wipe the pilot nozzles,
igniter/flame rod and hood. Ensure the pilot flame engulfs the
flame sensor as shown.
Checking Vent System Qualified Service Technician Inspect the vent system at the top and at the base (within the
firebox) for signs of blockage or obstruction. Look for any signs
of dislocation or deterioration of the vent components. Note:
Excessive condensation can cause corrosion of caps, pipe &
fittings (excessive condensation can be caused by long lateral
runs, too many elbows and/or exterior portions of the system
being exposed to cold weather). Also inspect wall straps or
plumbers's tape to ensure it is secure and in place.
Appliance Checkout Qualified Service Technician Perform the appropriate appliance checkout procedure detailed
in this manual.
Replacing Rockwool Ember Materials Homeowner/Qualified Service
Technician Remove old ember materials (rockwool) and vacuum the ember placement area. Place new embers as described in Step 6 on
Page 8.
Periodically (After the Burning Season)
MAINTENANCE TASK ACCOMPLISHING PERSON PROCEDURE
Cleaning Firebox Interior Homeowner Carefullyremove logs,rockwool,volcanicstoneand vermiculite.
Vacuum out interior of the firebox. Clean firebox walls and log
grate. Replace logs, Rockwool and volcanic stone as detailed
in this manual.
Check Flame Patterns and Flame
Height Homeowner Refer to Figure 13 on Page 9 and verify the flame pattern and
heightdisplayedbytheapplianceconformstothepicture.Flames
must not impinge on the logs.
Checking Vent System Homeowner Inspect the vent system at the top and at the base (within the
firebox) for signs of blockage or obstruction. Look for any signs
of dislocation of the vent components.
Cleaning Front Glass Enclosure Panel Homeowner Clean as necessary following the directions provided in this
manual. DO NOT TOUCH OR ATTEMPT TO CLEAN GLASS
WHILE HOT.
Annually (Before the onset of the Burning Season)
MAINTENANCE SCHEDULE
