Lennox MPB35ST-NM-B User manual

OTL Report No. 116-F-27-5
US
Portland
MODELS
INSTALLATION INSTRUCTIONS
MPB B-Vent See-Through
Gas Fireplaces
MPB35ST-NM-B
MPB35ST-PM-B
MILLIVOLT:
MPB35ST-NE-B
ELECTRONIC:
P/N 850023M REV. E 04/2013
This manual is one of a set of two supporting this product.
Refer to P/N 875024M for Care and Operation Instructions.
Ce manuel est disponible en francais, simplement
en faire la demande. Numéro de la pièce 850023CF.
INSTALLER: Leave this manual with the appliance.
CONSUMER: Retain this manual for future reference.
INSTALLATEUR : Laissez cette notice avec l’appareil.
CONSOMMATEUR : Conservez cette notice pour
consultation ultérieure.
AVERTISSEMENT : Assurez-vous de bien suivre les
instructions données dans cette notice pour réduire au
minimum le risque d’incindie ou d’explosion ou pour
éviter tout dommage matériel, toute blessure ou la mort.
WARNING: If the information in these instructions
is not followed exactly, a fire or explosion may
result, causing property damage, personal injury,
or death.
WARNING/AVERTISSEMENT/AVISO
HOT GLASS WILL
CAUSE BURNS.
DO NOT TOUCH GLASS
UNTIL COOLED
NEVER ALLOW CHILDREN
TO TOUCH GLASS.
UNE SURFACE VITRÉE CHAUDE
PEUT CAUSER DES BRÛLURES.
LAISSER REFROIDIR LA SURFACE
VITRÉE AVANT D'Y TOUCHER.
NE PERMETTEZ JAMAIS À UN ENFANT
DE TOUCHER LA SURFACE VITRÉE.
EL VIDRIO CALIENTE
CAUSARÁ QUEMADURAS.
USTED DEBE NUNCA
TOCAR EL VIDRIO CALIENTE.
LOS NIÑOS DEBEN NUNCA
TOCAR EL VIDRIO.
- Do not store or use gasoline or other flammable
vapors and liquids in the vicinity of this or any other
appliance.
- WHAT TO DO IF YOU SMELL GAS:
• Do not try to light any appliance.
• Do not touch any electrical switch; do not use any
phone in your building.
• Immediately call your gas supplier from a
neighbor’s phone. Follow the gas supplier’s
instructions.
• If you cannot reach your gas supplier, call the fire
department.
- Installation and service must be performed by a
qualified installer, service agency or the gas supplier.
- Ne pas entreposer ni utilizer d’essence ni d’autres vapeurs
ou liquides inflammables dans le voisinage de cet appareil
ou de tout autre appareil.
- QUE FAIRE SI VOUS SENTEZ UNE ODEUR DE GAZ :
• Ne pas tenter d’allumer d’appareil.
• Ne touchez à aucan interrupteur. Ne pas vous servir des
téléphones se trouvant dans le bâtiment où vous trouvez.
• Appelez immédiatement votre fournisseur de gaz depuis
un voisin. Suivez les instructions du fournisseur.
• Si vous ne pouvez rejoindre le fournisseur de gaz,
appelez le service des incindies.
- L’installation et l’entretien doivent être assurés par un
installateur ou un service d’entretien qualifié ou par le
fournisseur de gaz.
Decorative Product: Not for use as a heating appliance.
NOTICE: Fireplace is not to be operated by a thermostat.
03/27/2013

2
WARNING
B-Vent appliances are not
designedtooperateinnegatively
pressured environments (pres-
surewithinthehomeislessthan
pressures outside). Significant
negatively pressured environ-
ments caused by weather, home
design, or other devices may
impact the operation of these
appliances. Negative pres-
sures may result in poor flame
appearance,sooting,damageto
property and/or severe personal
injury. Do not operate these
appliances in negatively pres-
sured environments.
TABLE OF CONTENTS
Packaging .........................................Page 2
Introduction ......................................Page 2
General Information..........................Page 2
Requirements for the
Commonwealth of Massachusetts .Page 4
Cold Climate Insulation.....................Page 5
Location............................................Page 5
Vent Termination Clearances ............Page 6
Appliance and Vent Clearances ........Page 7
Pre-Installation Steps .......................Page 8
Typical Installation Sequence ...........Page 8
Step 1. Framing...............................Page 8
Fireplace Specifications.....................Page 9
Step 2. Routing Gas Line ................Page 10
Step 3. Install the Venting System ..Page 11
Step 4. Field Wiring.........................Page 12
Step 5. Connecting Gas Line...........Page 13
Step 6. Outside Air Kit Installation ..Page 14
Step 7. Verify Unit Operation...........Page 15
Step 8. Install Grate, Vermiculite
Embers and Logs ...............Page 15
Step 9. Installing/Removing Glass
Enclosure Panels ................Page 18
Step 10. Burner Adjustment..............Page 19
Step 11. Vent Operation Test and
Safety Limit Switch OperationPage 20
Step 12. Hood Installation.................Page 20
Finishing Requirements ....................Page 20
Step 13. Attaching Safety-in-
Operation Warnings.....................Page 21
Gas Conversion Kits.........................Page 22
Please read and understand these
instructions before beginning your
installation.
PACKAGING
The assembled vented gas fireplace is pack-
aged with:
1 - One logset, with oneplastic bagof vermicu-
lite, is packaged in a carton located within
the firebox.
2 - One plastic bag of glowing embers located
in the control compartment.
3- One envelope containing the literature
package, which consists of the care and
operation manual, installation instructions,
safetyinoperationwarninglabels, warranty,
8 nailing flanges; envelope is located in the
control area.
4 - Two hoods taped to the top of the fire-
place.
5 -One Grate, located in firebox.
6 - One Electrical Outlet Kit which consists of a
junctionbox,2screws,anreceptacleoutlet,
an OFF/ON rocker switch and a snap bush-
ing.Note: All thecomponentsinthe electrical
kit will Not be used by every model.
7. CartonSupport(must be removed fromthe
control area prior to first burning).
INTRODUCTION
The Millivolt appliances have a millivolt gas
control valve with piezo ignition system.
The Electronic appliances have an electronic
intermittent pilot ignition system. External
electrical power is required to operate these
units.
Use Only These Approved Vent Components
- These vented gas fireplaces are designed for
residential applications. They must be installed
with approved Type-B, 5" diameter double wall
vent pipe systems and a listed vent termination
routed to the outside atmosphere.
GENERAL INFORMATION
Children and adults should be alerted to the
hazards of high surface temperature and
should stay away to avoid burns or clothing
ignition.
Les enfants et les adultes devraient être infor-
mésdes dangers queposent les températures
de surface élevées et se tenir à distance afin
d’éviter des brûlures ou que leurs vêtements
ne s’enflamment.
DO NOT ATTEMPT TO ALTER OR MODIFY
THE CONSTRUCTION OF THE APPLIANCE OR
ITS COMPONENTS. ANY MODIFICATION OR
ALTERATIONMAY VOIDTHEWARRANTY,CER-
TIFICATION AND LISTINGS OF THIS UNIT.
WARNING
Young children should be care-
fully supervised when they are
in the same room as the appli-
ance. Toddlers, young children
and others may be susceptible
to accidental contact burns. A
physicalbarrierisrecommended
if there are at risk individuals in
the house. To restrict access to
a fireplace or stove, install an
adjustable safety gate to keep
toddlers, young children and
other at risk individuals out of
the room and away from hot
surfaces.
AVERTISSEMENT
Lesjeunesenfantsdevraientêtre
surveillésétroitementlorsqu’ils
se trouvent dans la même pièce
que l’appareil. Les tout petits,
lesjeunesenfantsoulesadultes
peuvent subir des brûlures s’ils
viennent en contact avec la sur-
facechaude. Ilestrecommandé
d’installerunebarrièrephysique
si des personnes à risques habi-
tent la maison. Pour empêcher
l’accès à un foyer ou à un poêle,
installez une barrière de sécu-
rité;cettemesureempêcherales
tout petits, les jeunes enfants et
toute autre personne à risque
d’avoir accès à la pièce et aux
surfaces chaudes.

3
WARNING
Improper installation, adjust-
ment, alteration, service or
maintenance can cause injury
or property damage. Refer to
this manual. For assistance or
additional information consult
a qualified installer, service
agency or the gas supplier.
WARNING
Failure to comply with these
installationinstructionswillresult
in an improperly installed and
operating appliance, voiding its
warranty. Anychangetothisappli-
ance and/or its operating controls
is dangerous.
WARNING
Clothing or other flammable
material should not be placed
on or near the appliance.
AVERTISSEMENT
On ne devrait pas placer de
vêtements ni d’autres matières
inflammables sur l’appareil ni à
proximité.
WARNING
Any safety screen or guard
removed for servicing the appli-
ance must be replaced prior to
operating the appliance.
WARNING
THISAPPLIANCEMAYONLYBEFITTED
WITH DOORS CERTIFIED FOR USE
WITH THE APPLIANCE.
AVERTISSEMENT
Tout écran ou protecteur retiré
pour permettre l’entretien de
l’appareil doit être remis en
place avant de mettre l’appareil
en marche.
The appliance, when installed, must be electri-
cally grounded and wired in accordance with
local codes or, in the absence of local codes,
with the National Electrical Code, ANSI/NFPA
70 - latest edition, or the Canadian Electrical
Code, CSA C22.1 - latest edition.
Provide adequate clearances around air open-
ings and adequate accessibility clearance for
serviceandproperoperation.Neverobstructthe
front or back viewing surfaces of the appliance.
These appliances are designed to operate on
natural or propane gas only. The use of other
fuels or combination of fuels will degrade
the performance of this system and may be
dangerous.
These 踀replaces are designed as decorative
appliances and are not intended for use as area
heaters. They must Not be equipped with wall
thermostatsorremotecontrolswiththermostat
functions.
These appliances must not be connected to a
chimney or flue serving a separate solid fuel
burning appliance.
The appliance area be kept clear and free from
combustible materials, gasoline and other
flammable vapors and liquids.
Outside Combustion Air Hook Up -
(All manufactured home installations require
the use of an Outside Combustion Air Hook-
Up Kit)
These appliances are equipped with an integral
combustion air door and actuator arm. Com-
bustion air kits are optional. Install as shown
in Step 6 on Page 14.
Millivolt Models - The millivolt appliances are
manually controlled and feature a spark igniter
(piezo) that allows the appliance's pilot gas to
be lit without the use of matches or batteries.
This system provides continued service in the
event of a power outage.
Millivoltmodelscomestandardwithamanually-
modulatedgasvalve;flameappearanceandheat
output can be controlled at the gas valve. Input
of for these models are shown in Table 1.
Note: Installation and repair should be done
by a qualified service person. The appliance
should be inspected before use and at least
annually by a professional service person.
More frequent cleaning may be required due
to excessive lint from carpeting, bedding
material,etcetera. It is imperativethatcontrol
compartments, burners and circulating air
passageways of the appliance be kept clean.
Remarque : L’installation et la réparation
devrait être confiées à un technicien qualifié.
L’appareil devrait faire l’objet d’une inspec-
tion par un technicien professionnel avant
d’être utilisé et au moins une fois l’an par la
suite. Des nettoyages plus fréquents peuvent
être nécessaires si les tapis, la literie, et
cetera produisent une quantité importante de
pous-sière. Il est essentiel que les comparti-
mentsabritantles commandes, les brûleurset
les conduits de circulation d’air de l’appareil
soient tenus propres.
Do not use this appliance if any part has
been under water. Immediately call a
qualified service technician to inspect the
appliance and to replace any part of the
control system and any gas control which
has been under water.
Nepasutilisercetappareils’ilaétéplongé,
même partiellement, dans l’eau. Ap-
peler un technicien qualifié pour inspecter
l’appareil et remplacer toute partie du
systèmedecommande et toutecommande
qui a été plongée dans l’eau.
Only trim kit(s) supplied by the manufacturer
shall be used in the installation of this ap-
pliance.
Seules les trousses de garniture fournies
par le fabricant doivent être utilisées pour
l’installation de cet appareil.
These appliances comply with National
Safety Standards and are tested and listed
by OMNI-Test Laboratories, Inc. (Report No.
116-F-27-5) to ANSI Z21.50 (in Canada, CSA
2.22),andCAN/CGA-2.17-M91inbothUSAand
Canada, as vented gas fireplaces.
Bothmillivolt andelectronic versionsofthese
appliances may be used in bedrooms (USA
only) when the room is an "unconfined space"
as defined by the National Fuel Gas Code.
Use in bedrooms may not be allowed by your
local building codes. You should obtain prior
approvalfromtheAuthorityhavingjurisdiction
prior to installation.
Misc. Codes / Standards -
TheInstallation mustconform tolocalcodes or,
in the absence of local codes, with the National
Fuel Gas Code, ANSI Z223.1/NFPA 54 - latest
edition(InCanada,thecurrentCAN/CGA-B149.1
installation code).
Input (BTU) Manually-Modulated Gas
Valves (millivolt models)
Model Natural Gas Propane Gas
BTU/HR BTU/HR
MPB35ST-B 23,000 to 30,000 22,000 to 28,000
Table 1
Electronic Models - Electronic models have a
fixed rate gas valve. Input of electronic models
is shown in Table 2.
Input (BTU) Fixed-Rate Gas Valves
(electronic models)
Model Natural Gas Propane Gas
BTU/HR BTU/HR
MPB35ST-B 30,000 28,000
Table 2

4
NOTE: DIAGRAMS & ILLUSTRATIONS ARE NOT TO SCALE.
Gas Valve Diagrams
See Figure 1 for Millivolt models and Figure 2
For Electronic Models.
Figure 2 - Honeywell Electronic Gas Valve
FFO
NI
PSI
NO
LORTNOC
GI N TI ER
Manifold Pressure
Port ON / OFF Switch
Inlet
Pressure
Port
Electronic Gas
Control Valve
H
I
LO
W
HTPTHTPT
P
I
L
O
T
P
I
L
O
T
O
N
it
O
F
F
IN OUT
Manifold Pressure Tap
Inlet Pressure Tap
Pilot Adjustment
Screw
HI/LO Variable
Flame Height
Adjustment
Main Gas
Control Knob
OFF/PILOT/ON
Burner Orifice Sizes
Elevation 0-4500 feet ( 0-1372 meters)
Model
Series Nat.Gas drill size (inches) Propane drill size (inches)
MPB35ST-B #37 (.104") *
24M10 •
1.55 mm (.061")*
42M79 •
Table 5
Orifice Sizes - Sea Level to High Altitude
(All Models)
These appliances are tested and approved for
installation at elevations of 0-4500 feet (0-1372
meters) above sea level using the standard
burnerorifice sizes (marked with an "*" in Table
5). Forelevationsabove4500feet,contactyour
gas supplier or qualified service technician.
Deration - At higher elevations, the amount
of BTU fuel value delivered must be reduced
by either:
• Using gas that has been derated by the gas
company.
• Changing the burner orice to a smaller size
as regulated by the local authorities having
jurisdiction and by the (USA) National Fuel
Gas Code NFPA 54/ANSI Z223.1 - latest
edition or, in Canada, the CAN/CGA-B149.1
codes - latest edition.
Installtheapplianceaccordingtotheregulations
of the local authorities having jurisdiction and,
in the USA, the National Fuel Gas Code NFPA
54 / ANSI Z223.1 - latest edition or, in Canada,
the CAN/CGA-B149.1 - latest edition.
NOTE: Flame appearance will diminish 4% per
thousand feet.
InCanada-CAN/CGA-2.17-M91(R2009)(high
altitude): THE CONVERSION SHALL BE CAR-
RIED OUT BY A MANUFACTURER’S AUTHO-
RIZED REPRESENTATIVE, IN ACCORDANCE
WITH THE REQUIREMENTS OF THE MANU-
FACTURER, PROVINCIAL OR TERRITORIAL
AUTHORITIES HAVING JURISDICTION AND
IN ACCORDANCE WITH THE REQUIREMENTS
OFTHECAN/CGA-B149.1ORCAN/CGA-B149.2
INSTALLATION CODES.
* Standard size installed at factory
• Part /Cat. Number
Figure 1 - SIT Millivolt Gas Valve
REQUIREMENTS FOR THE COMMON-
WEALTH OF MASSACHUSETTS
Installation of these fireplaces are approved
for installation in the US state of Massachu-
setts if the following additional requirements
are met:
• Install this appliance in accordance with
Massachusetts Rules and Regulations 248
C.M.R. Sec. 5.08 2(a) through 2(e).
• Installation and repair must be done by a
plumber or gas fitter licensed in the Com-
monwealth of Massachusetts.
• The exible gas line connector used shall
not exceed 36 inches (92 centimeters) in
length.
• The individual manual shut-off must be a
T-handle type valve.
Gas Pressure - All Models
Tables 3 and 4 show the units' gas pressure
requirements:
Inlet Gas Supply Pressure
(all models)
Fuel # Minimum Maximum
Natural Gas 5.0" WC
(1.24 kPa)
10.5" WC
(2.62 kPa)
Propane 11.0" WC
(2.74 kPa)
13.0" WC
(3.24 kPa)
Table 3
Manifold Gas Supply Pressure
(all models)
Fuel # Low
(millivolt only)
High
Natural
Gas
(Lo) 2.2" WC
(0.55 kPa)
(Hi) 3.5" WC
(0.87 kPa)
Propane (Lo) 6.3" WC
(1.57 kPa)
(Hi) 10.0" WC
(2.49 kPa)
Table 4
Test gauge connections are provided on the
front of the millivolt gas control valve, identi-
fied IN for the inlet and OUT for the manifold
side. A 1/8" NPT Test gauge connection
is provided at the inlet and outlet side of
the electronic gas control valve.
Propane tanks are at pressures that will cause
damage to valve components. Verify that the
tanks have step down regulators to reduce the
pressure to safe levels.
The appliance and its appliance main gas
valve must be disconnected from the gas
supply piping system during any pressure
testing of that system at test pressures in
excess of 1/2 psi (3.5 kPa).
The appliance must be isolated from the
gas supply piping system by closing its
equipmentshutoffvalveduringany pressure
testing of the gas supply piping system at
test pressures equal to or less than 1/2 psi
(3.5 kPa).
Burner Orifice Sizes (all models)
Elevation
Feet (meters)
Natural
Gas
drill size (inches)
Propane
Gas
drill size (inches)
0 - 4500
(0-1372) #37 * (.104") 1.55
mm *
(.061")
* Standard size installed at factory
Table 8

NOTE: DIAGRAMS & ILLUSTRATIONS ARE NOT TO SCALE.
5
COLD CLIMATE INSULATION
For cold climate installations, seal all cracks
around your appliance with noncombustible
material and wherever cold air could enter
the room. It is especially important to insulate
outside chase cavity between studs and under
floor on which appliance rests, if floor is above
ground level. Gas line holes and other open-
ings should be caulked or stuffed with unfaced
fiberglass insulation.
If the fireplace is being installed on a cement
slab in cold climates, a sheet of plywood or
otherraisedplatform canbeplaced underneath
to prevent cold transfer to the fireplace and into
the room. It also helps to sheetrock inside
surfaces and tape for maximum air tightness
and caulk firestops.
MANUFACTURED HOUSING
B-Vent Fireplaces are not approved for use in
OEMoraftermarketmanufacturedhousingbuilt
to HUD standards.
LOCATION
In selecting the location, the aesthetic and
functional use of the appliance are primary
concerns. However, vent system routing to
the exterior and access to the fuel supply are
also important.
Due to high temperatures, the appliance
should be located out of traffic and away from
furniture and draperies (Figure 3).
En raison des températures élevées,
l’appareildevrait être installédans un endroit
où il y a peu de circulation et loin du mobilier
et des tentures (Figure 3).
The location should also be free of electrical,
plumbing or other heating/air conditioning
ducting.
Be aware that this is a heat producing ap-
pliance. Objects placed above the unit are
exposed to elevated temperatures.
Do not insulate the space between the appli-
ance and the area above it.
The appliance must be mounted on a fully sup-
portedbase extendingthe fullwidth anddepthof
theunit. Theappliance maybe locatedonornear
conventional construction materials. However,
if installed on combustible materials, such as
carpeting,vinyltileorothercombustiblematerial
other than wood flooring, the appliance shall be
installed on a metal or wood panel extending the
full width and depth of the appliance.
Figure 3 - Typical Installations
** One face
flush with a
wall
* One side
(end) flush
with a wall
Offset
Venting
Vertical
Venting
Typical Installations
Locations
NOTE: When the unit is installed with one side flush with a wall, the wall on the other side of the unit
must not extend beyond the front edge of the unit.

6
NOTE: DIAGRAMS & ILLUSTRATIONS ARE NOT TO SCALE.
VENT TERMINATION CLEARANCES
These instructions should be used as a
guideline and do not supersede local codes
in any way. Install venting according to local
codes,theseinstructions,thecurrentNational
Fuel Gas Code (ANSI-Z223.1) in the USA or
the current standards of CAN/CGA-B149.1
in Canada.
GasVentRule–Gasvent capsarenotpermitted
within 8 ft. (2.4 m) of a vertical wall or similar
obstruction. Gas vent caps that are located 8
ft. or more from a portion of a building which
extends at an angle greater than 45° upward
fromthehorizontalmayterminateinaccordance
with Figure 4, provided that in no case shall
any discharge opening on the cap be less than
2 ft. (.6 m) horizontally from the roof surface
(National Fuel Gas Code ANSI Z223.1 (NFPA
54) (CAN/CGA B149.1).
Multiple Terminations
These appliances may vent adjacent to and at
the same level with any other gas appliances
(includingdirect-ventappliances)providedthat
thereisatleast2ft.(0.6m)betweentheproximal
edges of the vent caps. These appliances may
be vented adjacent to a chimney vent servicing
a solid fuel fireplace provided the B-vent cap
is at least 2 ft. (0.6m) away from the nearest
point of the chimney opening.
Termination Heights For Vents
Above Flat Or Sloped Roofs
Ref. NFPA 54 / ANSI Z223.1, 7.6
Roof Pitch Feet Meters
Flat to 6/12 1.0 0.3
6/12 to 7/12 1.25 0.38
7/12 to 8/12 1.5 0.46
8/12 to 9/12 2.0 0.61
9/12 to 10/12 2.5 0.76
10/12 to 11/12 3.25 0.99
11/12 to 12/12 4.0 1.22
12/12 to 14/12 5.0 1.52
14/12 to 16/12 6.0 1.83
16/12 to 18/12 7.0 2.13
18/12 to 20/12 7.5 2.29
20/12 to 21/12 8.0 2.44
Figure 4 - Vertical Vent Termination Clearances
Roof Pitch is X/12
Minimum Height from Roof to
Lowest Discharge Opening
X
12
1“ (25 mm)
Minimum
Multiple Terminations
2 ft.
(0.6m)
Minimum

NOTE: DIAGRAMS & ILLUSTRATIONS ARE NOT TO SCALE.
7
MINIMUM CLEARANCES TO COMBUSTIBLES
Appliance And Vent Clearances
Maintainclearancesfromappliance tocombustiblematerialsasdetailedin
Table 6 with the following exception: When the unit is installed with one
side flush with a wall, the wall on the other side of the unit must not
extend beyond the front edge of the unit. In addition, when the unit is
installed in the middle of a room, the side walls surrounding the unit must
not extend beyond the front or rear edge of the unit. See Figure 3.
*NOTE: 3" (75 mm) above any inclined vent component.
**NOTE: See Page 8, Step 1 and Figure 8 for clearance requirements
to the nailing flange located at each side of the unit and any screw
heads adjacent to it.
Hearth Extension - A hearth extension is not required with this appliance.
Ifa hearthextension isused, donotblockthecontrol compartmentaccess
panel. Any hearth extension used is for appearance only and does not
have to conform to standard hearth extension installation requirements.
Wall Finishes / Surrounds / Mantels
Note: Combustible wall finish materials and/or surround materials must
not be allowed to encroach the area defined by the appliance front face
(black sheet metal). Never allow combustible materials to be positioned
in front of or overlapping the appliance front face. See Figure 37.
Non-combustible materials, such as surrounds and other appliance trim,
may be installed on the appliance front and back faces with the following
exception: The material must NOT cover any portionof theglass, louvers
or top radiant panel (optional kit).
Vertical installation clearances to combustible mantels vary according
to the depth of the mantel. (See Figure 5). Mantels constructed of non-
combustible materials may be installed at any height above the appliance
opening; however, do not allow anything to hang below the hood.
These instructions should be used as a guideline and do not supersede
local codes in any way.
Minimumclearancerequirementsinclude anyprojectionssuchasshelves,
window sills, mantels, etc. above the appliance.
Note: We recommend the use of high temperature paint (rated 175° F
or higher) on the underside of the mantel.
Figure 5 - Minimum Mantel Clearances
inches (millimeters)
2
(51)
4
(102)
6
(152)
8
(203)
10
(254)
12
(305)
3 (76)
5 (127)
9 (289)
13 (330)
11 (279)
7 (178)
Top Of Appliance
NOTE: The side walls of mantels
may protrude beyond the front face
ofthefireplaceamaximumof5"(127
mm) at 0" clearance to the sides of
the fireplace.
MINIMUM CLEARANCES
Inches (millimeters)
Sides 1/2 (13)
Top Spacers 0 (0)
Floor 0 (0)
Bottom of Appliance
To Ceiling 72 (1829)
Vent 1 (25.4)
SERVICE CLEARANCES Feet (meters)
Front and Back Faces 3 ft. (0.9 m)
Table 6
Mantel Depth
1
(25)
2
(51)
3
(76)
1 (25)
2 (51)
3 (76)
4
(102)
4 (102)
5
(127)
5 (127)
6 (152)
7 (178)
8 (203)
9 (229)
10 (250)
Top View of
Fireplace
45o
At 5" minimum side wall clearance,
the wall (shown in dark gray) can be
any length.
Figure 6 - Minimum Distance to Unprotected Side Wall
Inches (millimeters)
Combustible materials may project
beyond one side of the fireplace open-
ing as long as they are kept within the
shaded areas illustrated here.

NOTE: DIAGRAMS & ILLUSTRATIONS ARE NOT TO SCALE.
8
Turn nailing tabs down and secure to the floor
with 8d nails or other appropriate fasteners on
both sides of appliance.
* NOTE: INSTALLATION DIAGRAMS AND
INSTRUCTIONS SHOW THE FRONT OF
THE APPLIANCE AS THE SIDE WHICH HAS
VALVE ACCESS, EXCEPT WHERE NOTED.
TYPICAL INSTALLATION SEQUENCE
The typical sequence of installation is outlined
below. However, each installation is unique
and may result in variations to the steps
described.
Seethepagenumberreferencesinthefollowing
steps for detailed procedures.
Step 1.(Page 8)- Construct the appliance
framing. Position the appliance within
the framing and secure with nailing
flanges.
Step 2.(Page 10) Route gas supply line to
appliance location.
Step 3.(Page 11)Install the vent system and
exterior termination.
Step 4.(Page 12) Field Wiring
a. Millivolt Appliances – Install the
OFF/ON burner control switch.
b. Electronic Appliances – Connect 120
VAC electrical power to the appliance
receptacle.
Step 5.(Page 13)Make connection to gas
supply.
Step 6.(Page 14) Outside Air Kit Installation.
Step 7. (Page 15)Verify appliance operation.
Step 8.(Page 15)Install grate, vermiculite,
embers and logs.
Step 9. (Page18)Installation/Removalofglass
enclosure panels.
Step 10(Page 19) Adjust burner primary air
shuttertoachieveproperflameappear-
ance.
Step 11.(Page20)Ventoperationtestand(safety
limit) switch operation.
Step 12. (Page 20)Install the decorative trims
and hoods.
Step 13. (Page 21)Attach Safety in Operation
Warnings.
Figure 7 - Unit Parts Identification
Control Compartment Access Panel
Top Louver Panel
WARNING
Failure to position the parts in
accordance with these diagrams
orfailure to useonlyparts specifi-
callyapprovedwiththisappliance
may result in property damage or
personal injury.
AVERTISSEMENT
Risque de dommages ou de
blessures si les pièces ne sont
pas installées conformément à
ces schémas et ou si des pièces
autres que celles spécifiquement
approuvéesaveccetappareilsont
utilisées.
Step 1. FRAMING
Frame these appliances as illustrated in Figure
9. Allframingdetails mustallowforaminimum
clearance to combustible framing members as
shown in Table 6 on Page 7.
If the appliance is to be elevated above floor
level, a solid continuous platform must be
constructed below the appliance.
Headers may be in direct contact with the
appliance top spacers but must not be sup-
ported by them or notched to fit around them.
All construction above the appliance must be
self-supporting, DO NOT use the appliance for
structural support.
Side Nailing Flanges
The fireplace should be secured to the side
framing members using the unit's nailing
flanges - one top and bottom on each side
of the fireplace front. See Figure 8 using the
existing screws. Position the fireplace within
the framing. When required, the tabs may be
bent 90 degrees by hand or with the assistance
of a hammer. Use wood screws to secure the
nailing flanges to the framing. See Table 6 on
Page 7 for clearances of framing members
to cabinet parts. The nailing flange itself can
directly contact framing.
Floor Nailing Tabs
Secure the fireplace to the floor as shown in
Figure 8.
Remove the screws
and use them when
installing the nailing
flanges
Nailing
Flanges
Figure 8
PRE-INSTALLATION STEPS
The appliance is shipped with all gas controls
and components installed and pre-wired.
1.Remove the shipping carton. Remove the
shipping pad, exposing the front glass
door.
2.Open the two latches (located under the fire-
box floor) securing the glass door. Remove
the door by tilting it outward at the bottom
andliftingit up. Set the door asideprotecting
it from inadvertent damage. See Removing
Glass Panels on Page 18.

NOTE: DIAGRAMS & ILLUSTRATIONS ARE NOT TO SCALE.
9
FIREPLACE SPECIFICATIONS - MPB35ST
SPECIFICATIONS
Natural Gas BTU Input 30,000
Propane Gas BTU Input 28,000
B-Vent Size 5" (127 mm)
NOTES
Diagrams, illustrations and photographs are not
toscale.Consultinstallationinstructions.Product
designs, materials, dimensions, specifications,
colors, and prices are subject to change or dis-
continuance without notice.
FRAMING SPACER
(Top and Both Sides)
Framing Specifications
Fireplace Specifications
PRODUCT REFERENCE INFORMATION
Cat.
No.
Model Ship
Weight
Ship.
Volume
H7808 MPB35ST-NM-B 200 lbs 46W x 26D x
43H (30 cu.ft.
H7809 MPB35ST-PM-B 200 lbs 46W x 26D x
43H (30 cu.ft.
H7810 MPB35ST-NE-B 200 lbs 46W x 26D x
43H (30 cu.ft.
3-1/8 (79)
6-1/4
(159)
22
(559)
20-7/8 (529)
FRAMING
35-3/8
(899)
36-3/8 (923)
11 (279)
17-3/4 (451)
35-1/8
(892)
32-5/8
(827)
3 (76)
3 (76)
3-1/8 (79)
6-1/4
(159)
6
(152)
12
(305)
19
(483)
29 1/2
(749)
TOP VIEW
FINISH WALL BRACKET
(Front and back edge of unit top)
5 (127) DIA. B-VENT
Control Switch
Wires
Knock-Out
Gas
Inlet
LEFT SIDE VIEW FRONT VIEW RIGHT SIDE VIEW
Junction Box
Knock-Out (2
places each side)
Control Switch
Wires
Knock-Out
Gas
Inlet
Outside Air
Shutter
Control
Compartment
Door
Figure 9
Notes:
• Inches (millimeters)
• Minimum Framing Stud Size is 2 x 4
• See side views of replace below for
gas line inlet location options.
**20-3/4
(527)
Gas line center is
3-1/8" (79 mm) up
from floor.
35-1/4
(895)
Gas
line
5-5/8" (143)
Front - Valve Access Side
*36-1/2
(927)
* Thisdimensiondoesnotincludethe
addition of drywall to the inside of
framing. Adjustaccordinglyforyour
installation.
**This dimension based on 5/8"
drywall. For 1/2" drywall use 21"
(533mm).Thefinisheddimension
should be 22" (558 mm).

NOTE: DIAGRAMS & ILLUSTRATIONS ARE NOT TO SCALE.
10
Notes:
• All appliances are factory-equipped with a
flexible gas line connector and 1/2" shutoff
valve (see Figure 19 on Page 14).
• See Massachusetts Requirements on Page 4
for additional requirements for installations in
the state of Massachusetts in the USA.
• The gas supply line should Not be connected
to the appliance until Step 5 (Page 13).
• A pipe joint compound rated for gas should be
used on the threaded joints. Ensure propane
resistant compounds are used in propane
applications. Be very careful that the pipe
compound does not get inside the pipe.
• It is recommended to install a sediment trap
in the supply line as close as possible to the
appliance (see Figure 19 , Page 14). Appli-
ances using propane should have a sediment
trap at the base of the tank.
• Check with local building ofcial for local code
requirements(i.e.arebelowgradepenetrations
of the gas line allowed?, etc).
IMPORTANT: If propane is used, be aware that
if tank size is too small (i.e. under 100-lbs, if
this is the only gas appliance in the dwelling.
Ref. NPFA 58), there may be loss of pressure,
resulting in insufficient fuel delivery (which
can result in sooting, severe delayed ignition
or other malfunctions). Any damage resulting
from an improper installation, such as this, is
not covered under the limited warranty.
Step 2. ROUTING GAS LINE
Route a 1/2" (13 mm) gas line along the inside
of the right side framing as shown in Figure 10.
Gaslinesmustberouted,constructedandmade
of materials that are in strict accordance with
local codes and regulations. All appliances
are factory-equipped with a flexible gas line
connector and 1/2"shutoff valve. (See Step
5 on Page 13).
Schedule 40 (black iron) Pipe
Inside Diameter (Inches)
Schedule 40 Pipe
Length (feet)
Natural
Gas
Propane
Gas
0-10 1/2 3/8
10-40 1/2 1/2
40-100 1/2 1/2
100-150 3/4 1/2
150-200 3/4 1/2
Table 7
Proper Sizing of Gas Line
Properly size and route the gas supply line
from the supply regulator to the area where the
appliance is to be installed per requirements
outlined in the National Fuel Gas Code, NFPA
54 - latest edition (USA) or CAN/CGA-B149.1
- latest edition (Canada).
Also see
Figure 9
6-1/4"
(159 mm)
3-1/8"
(79 mm)
Figure 10 - Route Gas Line
Never use galvanized or plastic pipe. Refer to
Table 7 for proper sizing of the gas supply line,
if black iron pipe is being used. Gas lines must
be routed, constructed and made of materials
that are in strict accordance with local codes
and regulations. We recommend that a quali-
fied individual such as a plumber or gas fitter
be hired to correctly size and route the gas
supply line to the appliance. Installing a gas
supplylinefrom thefuelsupply to theappliance
involvesnumerousconsiderationsofmaterials,
protection,sizing,locations,controls,pressure,
sediment,andmore.Certainly nooneunfamiliar
andunqualified shouldattemptsizingorinstall-
ing gas piping.

60 Degrees
Maximum
12 Feet (3.7 Meters)
Minimum
11
NOTE: DIAGRAMS & ILLUSTRATIONS ARE NOT TO SCALE.
1" (25 mm)
Minimum
Firestop
NOTE: Refer to the vent manufacturers instal-
lation instructions for variations of venting
techniques. If common venting of several units
is contemplated, it should be discussed with an
architect and the local Building Department.
Do not place insulation materials within 1" of
the gas vent system.
CAUTION
Thisappliance cannotbevented
horizontally.
Figure 11
Securing
Screws
Flue Outlet
Collar
Figure 12
Use only approved venting components.
See Approved Vent Components on Page 2.
Vertical
Installations
Offset
Installations
Step 3. INSTALL THE VENT SYSTEM &
EXTERIOR TERMINATION:
General Information
These instructions should be used as a
guideline and do not supersede local codes
in any way. Install venting according to local
codes,theseinstructions,thecurrentNational
Fuel Gas Code (ANSI-Z223.1) in the USA or
the current standards of CAN/CGA-B149.1
in Canada.
Ensure clearances are in accordance with
local installation codes and the requirements
of the gas supplier.
Dégagementconformeauxcodesd'installation
locaux et aux exigences du foumisseunde
gaz.
Useonlyapprovedventingcomponents.
See Approved Vent Components on
Page 2.
These fireplaces must be vented directly
to the outside.
Slipthefirst5"(127mm)sectionofB-Ventover
the fireplace flue outlet and secure with four
sheetmetal screws (# 8 or larger), and install
the remainder of the B-Vent to the outside.
Minimumoverall heightof thevent systemand
appliance must be 10' (2.54 m) vertical - no
offset (see Figure 12);or 12' (3.7 m) when
an offset up to 60 degrees from the vertical is
used - this offset may start at the fireplace flue
collar (see Figure 12). The maximum overall
heightof thevent systemand applianceshould
not exceed 40 feet.
Install the B-vent system in accordance with
the vent manufacturer's instructions.
10 Feet (3 Meters)
Minimum
The maximum overall height of the vent system
and appliance should not exceed 40 feet.

Figure 14
Thermopile
TH
TP TH
TP
White
White
Black
Spill Switch
If any of the original wire as supplied must
be replaced, it must be replaced with Type
AWM105 C - 18 gage wire.
* Optional Kits - OFF/ON wall switch or
remote control receiver.
Millivolt Wiring Diagram
Appliance mounted OFF / ON Switch
Schematic Represen-
tation Only
Field Wired
Factory
Wired
12
NOTE: DIAGRAMS & ILLUSTRATIONS ARE NOT TO SCALE.
B. Electronic Wiring
(also see Figure 18 on Page 13)
Note: The electronic appliance must be con-
nected to the main 120 VAC power supply.
1. LocatetheElectrical Outlet Kit provided(pack-
aged in firebox - contents: junction box, 2
screws, an receptacle outlet, a snap bushing
and an OFF/ON rocker switch - for millivolt
units only).
Note: The junction box can be installed in any
of the 4 outside corners of the control com-
partment (outlet installed in front left corner is
shown in Figure 17).
2. Route a 3-wire, 120 VAC, 60 Hz, 1 ph power
supply to the location on appliance where
junction box is to be installed.
3. Openthe controlcompartmentaccesspanel
(see Control Compartment Access Instruc-
tions on Page 14).
4. Wire and install the outlet receptacle to
junction box, then install into the chosen
cornerofthecontrolcompartmentasshown
in Figure 17.
5. After the receptacle/junction box wiring is
complete, install the field-provided metal
junction box cover plate (see Figure 17).
6. Install the snap bushing (provided in kit)
into the selected cabinet knockout opening
in side cabinets (see Electrical Inlets, Figure
9on Page 9). The snap bushing provides
protection for the wires (see note below)
passing through side cabinet going to an
optional burner control switch Wire in the
burner control switch tothelowvoltagecircuit
as shown in Figure 18.
Note: The supplied 15 feet of 2 conductor
wire has one end of each conductor con-
nected to the gas valve circuit and the other
end of each conductor placed loose on top
of the appliance.
Important Note: The gas valve OFF/ON switch
is shown in Figure 18 on Page 13. It is integral
with the gas valve and should be set to the ON
position.
Gas
Valve
Control Compartment
Access panel
OFF/ON
Switch
TP TH
TH
Install OFF/ON Switch
(millivolt models)
1. Connect the 2 wires (provided in Electrical
Outlet Kit) to the TP/TH and TH terminals
on valve.
2. Pass the 2 wires through the opening where
OFF/ON switch will be installed (left of piezo,
below valve).
3. Connect the two wires to the OFF/ON Switch.
OFF/ON
Switch
Connect
wires to
terminals
4. PresstheOFF/ONswitchintobracketasshown
below (it will snap into place).
Figure 13
Note: Supply wires may be alternatively con-
nected to the outlet using the screw terminals,
however the black supply wire must be wired to
a terminal that is opposite (across the outlet) the
point where the white supply wire is connected.
Bipolar
Terminal
Screw
Ground Wire
Connection
White
(supply)
Black
(supply)
Figure 15
Step 4. FIELD WIRING
CAUTION
Ground supply lead must be con-
nected to the wire attached to the
green ground screw located on the
outletbox. SeeFigure 18. Failureto
dosowillresultinapotential safety
hazard. The appliance must be
electricallygroundedinaccordance
withlocalcodesor,intheabsenceof
local codes, the National Electrical
Code,ANSI/NFPA70-latestedition.
(In Canada, the current CSA C22.1
Canadian Electrical Code).
CAUTION: Label all wires prior to disconnec-
tionwhenservicingcontrols.Wiringerrorscan
cause improper and dangerous operation.
ATTENTION: Au moment de l'entretien des
commandes, étiquetez tous les fils avant de
les débrancher. Des erreurs de cáblage peu-
vent entraîner un fonctionnement inadéquat
et dangereux.
Verify proper operation after servicing.
S'assurer que l'appareil fonctionne adé-
quatement une fois l'entretien terminé.
Refer to Section A for millivolt appliances and
Section B for electronic appliances.
A. Millivolt Wiring (See Figure 14) –
1. Install and wire in the burner control switch
(install either "a" or "b" below, NOT BOTH)
a.StandardOFF/ONSwitch-InstalltheOFF/
ONburnercontrol switch(rockerswitch)
as shown in Figures 13 and 14.
b. Optional Control Switch (OFF/ON wall
switchorremotecontrolreceiver). Install
snap bushing (provided in Electrical
Outlet Kit) into control switch knock-out
in side panel (see Figure 9 on Page 9).
Wire the optional control switch within
the millivolt control circuit (as shown in
Figure 14)using the 15 feet of 2 conduc-
tor wire supplied (route wires through
the snap bushing to the optional control
switch). Mount the optional wall switch
in a convenient location on a wall near
the fireplace.
CAUTION: DO NOT CONNECT OPTIONAL CON-
TROL SWITCH TO 120 V POWER SUPPLY.
CAUTION: REMOVE THE CARTON SUPPORT
FROMTHECONTROLCOMPARTMENTBEFORE
OPERATING THE APPLIANCE.
CAUTION: ENSURE THAT WIRES ARE POSI-
TIONED AWAY FROM HOT SURFACES AND
SHARP EDGES.

NOTE: DIAGRAMS & ILLUSTRATIONS ARE NOT TO SCALE.
13
Step 5. CONNECTING GAS LINE
All codes require a shut-off valve mounted
in the supply line. The orientation of the
shut-off valve should face the front. Figure
19 illustrates two methods for connecting the
gas supply. A Sediment Trap is recommended
to prevent moisture and debris in gas line from
damaging the valve.
The flex-line method is acceptable in the U.S.A.
where local codes permit, however, Canadian
requirementsvarydependingonlocality.Instal-
lation must be in compliance with local codes.
These appliances are equipped with a gas flex-
linefor use inconnecting theunitto thegasline.
See Figure 19 for flex-line description. The
flex-line is rated for both natural and propane
gas. A manual shut off valve is also provided
with the flex-line.
The gas control valve is located in the lower
control compartment.
To access the valve open the lower control
compartment door (see Figure 21).
* Control Switches: Wall On/Off Switch or Timer, Unit Mounted On/Off Switch, or Remote Control Switch. If an
optional control switch is installed, turn the appliance-mounted ON/OFF burner control switch to the OFF position.
Figure 18
Figure 17
Outlet Receptacle
Junction Box
Field-provided Metal Junction Box
Cover Plate With Screw
View Of Left
Bottom Corner Of Unit
Receptacle, Junction Box
and Cover Plate Installation
Fireplace
Side
Junction Box
knock-out (2
places each side)
Valve Access Side
Latching magnet
not shown
Press snap
bushing into the
knock-out for
control switch
wires.
Figure 16- J-BOX WIRING
J-BOX/RECEPTIACLE
WIRING
120V, 60HZ, 1PH
Factory Wired
Field Wired
Junction Box
Tab Intact
Tab
Intact
neerG-dnuorG
etihW-lar
t
ueN
120 VAC - Black
Green
Ground
Screw
White
Green
Neutral
Side of
Receptacle
Hot
Side of
Receptacle
Black
The millivolt control valve has a 3/8" (10mm)
NPT thread inlet port. The electronic control
valve has a 1/2" (13 mm) NPT thread inlet
port and is fitted with a 1/2" x 3/8" (13 mm x
10mm) NPT fitting.
Secure all joints tightly using appropriate
toolsandsealingcompounds(ensurepropane
resistant compounds are used in propane ap-
plications). Itisrecommendedtoseal around
the gas line to prevent cold air leakage.
Acquire the shut-off valve and gas lex line and
pull the assembly forward out of the compart-
ment. Separate the shut-off valve from the gas
flex-line. Determine the length of pipe needed
to route the gas line from the last fitting (shown
in Figure 19 on Page 14)to a point within the
control compartment that will allow the shut-
off valve to be easily attached by hand to the
gas flex-line.
Using pipe-dressing materials appropriate for
the gas type, securely affix the shut-off valve
to this determined pipe length at a convenient
location outside of the appliance lower control
compartment.
NOTES:
1. If any of the original wire as supplied must be replaced, use Type AWM 105°C - 18 gage wire ONLY.
2. 120 VAC, 60 Hz - Less than 3 Amps.
CAUTION: label all wires prior to disconnection when servicing controls. Wiring errors can cause improper and
dangerous operation. Verify proper operation after servicing.
0.375"
0.375"
0.25" Ø
NOT FOR USE WITH SOLID FUEL
CAUTION: Hot while in operation. Do not
touch. Severe Burns may result. Keep children, clothing,
furniture, gasoline and other liquids having flammable
vapors away.
CAUTION: Do not operate the appliance with
factory installed refractory panel(s) removed, cracked or
broken. Replacement of the factory installed refractory
panel(s) should be completed by a licensed or qualified
service person.
WARNING: Improper installation, adjustment,
alteration, service or maintenance can cause injury
or property damage. Refer to the owner’s information
manual provided with this appliance. For assistance
or additional information consult a qualified installer,
service agency or the gas supplier.
Due to high temperatures, keep children, and furniture
away.
Keep burner and control compartment clean. See
installation and operating instructions accompanying
appliance.
WARNING:
Do not connect 120 V AC to the control valve.
THIS APPLIANCE MUST BE INSTALLED IN ACCORDANCE
WITH LOCAL CODES, IF ANY; IF NONE, FOLLOW THE
NATIONAL FUEL GAS CODE, ANSI Z223.1, OR NATURAL
GAS AND PROPANE INSTALLATION CODE, CSA B149.1.
If not installed, and maintained in accordance with the
manufacturer's instructions, this product could expose
you to substances in fuel or fuel combustion which are
known to the state of California to cause cancer, birth
defects, or other reproductive harm.
* For a copy of the homeowner’s care and operation
manual, go to www.lennox.com or call 1-800-9-lennox.
B-VENTED APPLIANCES NEED FRESH AIR FOR SAFE
OPERATION AND MUST BE INSTALLED SO THERE
ARE PROVISIONS FOR ADEQUATE COMBUSTION AND
VENTILATION AIR.
DIRECT VENTED APPLIANCES MUST NOT BE OPERATED
WITHOUT THE FRONT GLASS PANEL(S) INSTALLED.
DO NOT OPERATE APPLIANCE WITH BROKEN,
CRACKED OR MISSING GLASS DOORS OR ENCLOSURE
PANEL(S).
ELECTRONIC IGNITION WIRING DIAGRAM
P/N 62L2701_4
Optional Blower**
OFF/ON Switch
(Integral with
Gas Valve)
Honeywell
Electronic
Gas
Valve
120 VAC
Primary
Secondary
Junction Box
Break Off Tab
Junction Box
Pilot Burner
Assembly
BL
BL
Field Wired
Factory
Wired
BK = BLACK BL = BLUE
R = RED W = WHITE
G = GREEN
BK
BK
BK
BK BL
R
GROUND
24 V
Transformer
J-Box Wiring
WITH Optional Blower Switch
J-Box Wiring
WITHOUT Optional Blower Switch
BK
W
G
CAV021
BK
W
G
CAV021
Igniter
Connector
*
**
Control Switches: Wall On/Off
Switch, Unit Mounted On/Off Switch,
Wall Thermostat (Direct-Vent Units
Only) or Remote Control Switch.
Some models are not approved for
use with an optional blower. See Care
and Operation manual for approved
accessories.
Schematic Representation Only
W
GR
BK
BK
R
Control
Switch *
DAMPER
SWITCH
HIGH LIMIT
SWITCH
B-Vent appliances only - one or both of these switches must
be factory installed in series as shown. If wires to these switches
are replaced, wires must be Type AWM 200°C - 18 gage wire ONLY.
NOTES:
1. If any of the original wire as supplied
must be replaced, use Type AWM
105°C - 18 gage wire ONLY.
2. 120 VAC, 60 Hz - Less than 3 Amps.
CAUTION: label all wires prior to
disconnection when servicing controls.
Wiring errors can cause improper and
dangerous operation. Verify proper
operation after servicing.
ELECTRONIC IGNITION WIRING DIAGRAM
0.375"
0.375"
0.25" Ø
NOT FOR USE WITH SOLID FUEL
CAUTION: Hot while in operation. Do not
touch. Severe Burns may result. Keep children, clothing,
furniture, gasoline and other liquids having flammable
vapors away.
CAUTION: Do not operate the appliance with
factory installed refractory panel(s) removed, cracked or
broken. Replacement of the factory installed refractory
panel(s) should be completed by a licensed or qualified
service person.
WARNING: Improper installation, adjustment,
alteration, service or maintenance can cause injury
or property damage. Refer to the owner’s information
manual provided with this appliance. For assistance
or additional information consult a qualified installer,
service agency or the gas supplier.
Due to high temperatures, keep children, and furniture
away.
Keep burner and control compartment clean. See
installation and operating instructions accompanying
appliance.
WARNING:
Do not connect 120 V AC to the control valve.
THIS APPLIANCE MUST BE INSTALLED IN ACCORDANCE
WITH LOCAL CODES, IF ANY; IF NONE, FOLLOW THE
NATIONAL FUEL GAS CODE, ANSI Z223.1, OR NATURAL
GAS AND PROPANE INSTALLATION CODE, CSA B149.1.
If not installed, and maintained in accordance with the
manufacturer's instructions, this product could expose
you to substances in fuel or fuel combustion which are
known to the state of California to cause cancer, birth
defects, or other reproductive harm.
* For a copy of the homeowner’s care and operation
manual, go to www.lennox.com or call 1-800-9-lennox.
B-VENTED APPLIANCES NEED FRESH AIR FOR SAFE
OPERATION AND MUST BE INSTALLED SO THERE
ARE PROVISIONS FOR ADEQUATE COMBUSTION AND
VENTILATION AIR.
DIRECT VENTED APPLIANCES MUST NOT BE OPERATED
WITHOUT THE FRONT GLASS PANEL(S) INSTALLED.
DO NOT OPERATE APPLIANCE WITH BROKEN,
CRACKED OR MISSING GLASS DOORS OR ENCLOSURE
PANEL(S).
ELECTRONIC IGNITION WIRING DIAGRAM
P/N 62L2701_4
Optional Blower**
OFF/ON Switch
(Integral with
Gas Valve)
Honeywell
Electronic
Gas
Valve
120 VAC
Primary
Secondary
Junction Box
Break Off Tab
Junction Box
Pilot Burner
Assembly
BL
BL
Field Wired
Factory
Wired
BK = BLACK BL = BLUE
R = RED W = WHITE
G = GREEN
BK
BK
BK
BK BL
R
GROUND
24 V
Transformer
J-Box Wiring
WITH Optional Blower Switch
J-Box Wiring
WITHOUT Optional Blower Switch
BK
W
G
CAV021
BK
W
G
CAV021
Igniter
Connector
*
**
Control Switches: Wall On/Off
Switch, Unit Mounted On/Off Switch,
Wall Thermostat (Direct-Vent Units
Only) or Remote Control Switch.
Some models are not approved for
use with an optional blower. See Care
and Operation manual for approved
accessories.
Schematic Representation Only
W
GR
BK
BK
R
Control
Switch *
DAMPER
SWITCH
HIGH LIMIT
SWITCH
B-Vent appliances only - one or both of these switches must
be factory installed in series as shown. If wires to these switches
are replaced, wires must be Type AWM 200°C - 18 gage wire ONLY.
NOTES:
1. If any of the original wire as supplied
must be replaced, use Type AWM
105°C - 18 gage wire ONLY.
2. 120 VAC, 60 Hz - Less than 3 Amps.
CAUTION: label all wires prior to
disconnection when servicing controls.
Wiring errors can cause improper and
dangerous operation. Verify proper
operation after servicing.
J-Box Wiring

CONTROL COMPARTMENT ACCESS INSTRUCTIONS (Ref. Figure 20)
Opening Control Compartment Door: Gently depress the outer top corners of the louvered Control
Compartment Access Panel until the spring-loaded magnetic catches "pop" it free, allowing it to
swing out and down to open.
Removing Control Compartment Door: With the panel in the open position, depress the spring-
loaded hinge pin on left side until it disengages from the left cabinet panel hole. Pull panel away
from fireplace.
14
NOTE: DIAGRAMS & ILLUSTRATIONS ARE NOT TO SCALE.
Step 6. OUTSIDE AIR KITS
Optional outside make-up air kits, Model
FOAK-4 or FAOK-4LD (see Figure 22 on Page
15), may be used with these appliances. Refer
to the installation instructions packaged with
the air kits for specific installation information.
If used, the outside air kit must be installed
before the fireplace is framed and enclosed in
the finished wall.
Outside air drawn into the fireplace supplies air
to the fire for combustion. Only one outside air
ductisnecessary,ifinstalled.SeeFigure9,Page
9 for the location of the units outside air inlet.
If additional length of duct is necessary, pur-
chase locally available U.L. Class 0 or Class 1
metallic ducting. The duct may extend up to 50'
(15.24 m) in any direction.
Note: When installing the air duct vertically,
DO NOT terminate the duct closer than 3 feet
below the chimney top.
Outside combustion air ducting may be run
upwards or vertically through framing and
ceiling joists, with the hood installed through
an outside wall and 3 feet (1 m) below the ter-
mination. Ducting may also be run downward
through floor Joists and under the home to a
ventilated crawlspace not considered part of
the living area of the home.
Note: Do not terminate outside air kit in attic
space under any circumstances.
Aftercompletingtheinstallation of the optional
outside air vent system, the outside air control
lever must be put in service and tested to
ensure proper operation before completing
any enclosure around the firebox. Failure to do
so may result in extensive and costly rework.
Before the operation of the vent system can
be tested, the lever securing screw must be
removed. See Figure 21 on Page 15.
The hand operated outside air control lever
is located on the right side of the fireplace
opening. See Figure 21.
Toopenthe outsideair, openthebottom control
access panel, reach into the gap between the
firebox bottom and pull the outside air control
lever all the way out.
CAUTION
Never locate inlet where it can be
blocked by shrubs, snow drifts,
etc. Never locate inlet in garage
or any area where there is another
fuel burning appliance or products
emitting combustible gases such
as paint, gasoline, etc. In cold
climates, it is recommended the
outside air duct be insulated.
Turn on gas supply and test for gas leaks us-
ing Turn on gas supply and test for gas leaks,
using a gas leak test solution (also referred to
as bubble leak solution). Note: Using a soapy
water solution is an effective leak test solution
but it is not recommended, because the soap
WARNING
Never use an open flame to
check for leaks.
TEST ALL CONNECTIONS FOR GAS LEAKS
(FACTORY AND FIELD):
residue that is left on the pipes/fittingscan result
in corrosion over time.
A. Light the appliance (refer to the lighting
instructionslabelinthecontrolcompartment
or in the Care and Operation Instructions
manual).
B. Brush all joints and connections with the gas
leak test solution to check for leaks. If bubbles
are formed, or gas odor is detected, turn the
gas control knob (off/pilot/on) to the “OFF”
position. Either tighten or refasten the leaking
connection, then retest as described above.
C. When the gas lines are tested and leak free,
be sure to rinse off the leak testing solution.
Hinge Pin
Gas Valve
Piezo Igniter
Latch for
Glass Door
Figure 20
HI/LO (flame height
control knob)
OFF/PILOT/ON (gas control knob)
Gas Flex Line
(with shut-off valve)
Control Compartment
Access panel
OFF/ON Switch
Note: The gas supply line
must be installed in accor-
dance with building codes
by a qualified installer
approved and/or licensed
as required by the locality.
In the Commonwealth of
Massachusetts, installa-
tion must be performed
by a licensed plumber or
gas fitter.
Gas
Valve
3/8" NPT x
Flare Fitting
3/8" Flex Tubing
3/8" Nipple
3/8" Union
3/8" Close
Nipple 3/8" Shut-off Valve
1/2" x 3/8"
Reducer
Gas
Stub
1/2" x 3/8" Flare
Shut-off Valve
Gas Solid Line Connector
Gas Flex Line Connector
*Sediment
Trap
3"
Min
Figure 19 - GAS CONNECTION

15
NOTE: DIAGRAMS & ILLUSTRATIONS ARE NOT TO SCALE.
Theoutsideair shuttershouldbe fullyopenwhen
the fireplace is in use and completely closed
when the fireplace is not being used. Closing
it when not in use will prevent outside cold air
from entering the dwelling.
Operate the actuator through several cycles
including the closed position. Ensuring proper
operation and freedom of movement. Return
the actuator arm to the closed position.
Observe the individual tongues of flame on
the burner. Make sure all ports are open and
producing flame evenly across the burner. If
any ports are blocked, or partially blocked,
clean out the ports.
Electronic Appliance Checkout
To light the burner, turn ‘ON’ the OFF/ON switch
(located below valve) and turn the gas control
switch to the “ON” position. Ensure the igniter
lights the pilot. The pilot flame should engulf
the flame rod as shown in Figure 24.
Step 8. INSTALL GRATE, VERMICULITE,
GLOWING EMBERS AND LOGS
WARNING
• DO NOT attempt to install the
logsuntiltheapplianceinstal-
lationhasbeencompleted,the
gas line connected and tested
for leaks and the initial burner
operation has been checked
out.
•
Thesizeandpositionofthelog
setwas engineeredto givethe
appliance a safe, reliable and
attractive flame pattern. Any
attempt to use a different log
set in the fireplace will void
the warranty and will result in
incompletecombustion,soot-
ing, and poor flame quality.
•
Logs get very hot and will
remain hot up to one hour
after gas supply is turned off.
Handle only when logs are
cool. Turn off all electricity
to the appliance before you
install grate and logs.
•
Thisapplianceisnotdesigned
to burn wood. Any attempt
to do so could cause irrepa-
rabledamagetotheappliance
and prove hazardous to your
safety.
•
If logs are not installed
according to the log instal-
lation instructions, flame
impingement and improper
combustion could occur and
resultinsootand/orexcessive
productionofcarbonmonoxide
(CO), a colorless, odorless,
toxic gas.
Outside Combustion Air Kits
Cat. No. Model No. Description
81L87 FOAK-4 Combustion Air Kit (w/duct)
81L88 FOAK-4LD Combustion Air Kit (w/o duct)
(ref. Form # 750,008M)
Outside Air Kits - Outside Air kits are avail-
able with duct (FOAK-4) and without duct
(FOAK-4LD) for use if outside combustion air
is required or desired. If model FOAK-4LD is
used it must be used in conjunction with locally
purchased, non-combustible Class 1 or Class
0 flexible duct.
Step 7. VERIFY APPLIANCE OPERATION
With gas line installed run initial system check-
outbeforeclosingupthefrontoftheunit. Follow
the pilot lighting instructions provided in the
Care and Operation Instructions manual. For
piezo igniter location see Figure 20 on Page
14 (millivolt appliances only).
Note:The(pull-out) Lighting instructions label
can be found in the control compartment
(see Figure 20).
When first lighting the appliance, it will take
a few minutes for the line to purge itself of
air. Once purging is complete, the pilot and
burner will light and operate as indicated in
the instruction manual. Subsequent lightings
of the appliance will not require such purging.
Inspect the pilot flame.
Millivolt Appliance Checkout
The pilot flame should be steady and, not lifting
or floating. Flame should be blue in color with
traces of orange at the outer edge.
The top 3/8" (10 mm) at the pilot generator
(thermopile) and the top 1/8" min (tip) of the
quickdropoutthermocoupleshouldbeengulfed
in the pilot flame. The flame should project 1"
(25 mm) beyond the hood at all three ports
(Figure 23).
To light the burner; rotate the gas valve control
knob counterclockwise to the “ON” position
then turn “ON” the OFF/ON switch (installed at
Step 4, Page 12).
Figure 23
Proper Pilot Flame Appearance
Thermocouple
Thermopile
Pilot
Nozzels
3/8" Min.
(9 mm)
1/8" Min.
(3 mm)
Igniter Rod
Hood
Figure 24
3/8" to 1/2"
(9 -13 mm)
Ground
Electrode
Flame Rod
Hot Surface
Igniter
Proper Flame
Adjustment
Pilot
Nozzels
ELECTRONIC
MILLIVOLT
Glass Front
Figure 21
Control Compartment Access Panel
Outside Air Control Lever
with Stop Behind
Securing Screw
Outside Air Control Lever
and Securing Screw Location
Figure 22

16
NOTE: DIAGRAMS & ILLUSTRATIONS ARE NOT TO SCALE.
LOG SET
Catalog Number H3210
* Item Description
A Log, Center
B Log, Left Rear
C Log, Left Front
D Log, Right Rear
E Log, Top Center
F Log, Front Center
* Item "letters" above correspond to photos on right
LOG SET - IDENTIFICATION
REFERENCE
Firebox Accessories / Parts
Cat. No. Model No. Description
88L53 FGE Bag of Glowing Embers
H6319 Vermiculite, Bag (2 liters)
F
D
Bottom View of Logs (in packaging)
Top View of Logs
C
E
A
B
Glowing Embers
Bag of Glowing
Embers (rockwool)
Separate into Quarter
Size (separate) Pieces
Top View of Logs - Installed
E
B
C
F
A
D
F
E
A
C
B
D
Figure 25 (Valve Access Side)

17
NOTE: DIAGRAMS & ILLUSTRATIONS ARE NOT TO SCALE.
Position The Groove At The Bottom Of
Log (A) Over The Grate And Slide It
Forward Against The Grate Here
Figure 27
READ WARNINGS ON Page 15 BEFORE PROCEEDING
1. Remove the front glass enclosure panel (see Glass Enclosure Panel
Removal Instructions, Page 18)
2. Remove the following from firebox; log set, bag of embers and bag
of vermiculite. Handle logs carefully to prevent breakage.
3. Ensure the Grate is properly installed in the firebox with the 4 legs
of the grate fitting into the 4 dimples on the firebox floor.
4. InstallVermiculite-Place somevermiculite on thefirebox floor around
thegrate(the entirebagof vermiculitewillNOT beused).See Figure 34
on Page 19. DO NOT PLACE ANY VERMICULITE ON THE BURNER.
5. Placement of Glowing Embers -
Separatethe Embers (rockwool)intopieces about thesize ofaquarter
(see Figure 25). Keep the pieces fluffed up, not matted. Distribute
these pieces over the surface of the burner, as shown in Figure 26.
Do not use more than is necessary. Ensure that the main burner ports
remain uncovered by the ember material.
Note: This appliance is provided with enough Glowing Embers for
several applications, do not use all that is in a new bag at one time. For
best glowing effect, replace the ember material annually. Replacement
Glowing Embers are available (order Catalog Number 88L53).
INSTALLATION STEPS:
B
C
D
A
(Valve Access Side)
(Valve Access Side)
(Valve Access Side)
(Valve Access Side)
Position Groove At The Bottom Of
Log (A) Over The Log Support Here
7. Place Log (B) as shown in Figure 28.
Position Log (B) Against The Back Of
The Grate Here
Position Groove at The Bottom Of Log (B) Over The Grate
Here And Slide It Against The Back Of The Grate
Figure 28
Log (C) Lays Over Logs (A) and (B)
A
B
Position And Slide Log (D) Against The
Back Of The Grate
Place Log (D) Over The
Flat Spot On Log (A) Here
A
Position The Groove in The Back of Log (C)
Against The Grate
Figure 29
8. Place Log (C) as shown in Figure 29.
Figure 30
9. Place Log (D) as shown in Figure 30.
Figure 26
Place Embers on burner as shown.
DO NOT PLACE EMBERS OVER
GAS PORTS / AREAS CIRCLED
6. Place Log (A) on the grate as shown in Figure 27.

NOTE: DIAGRAMS & ILLUSTRATIONS ARE NOT TO SCALE.
18
E
F
(Valve Access Side)
(Valve Access Side)
Position The Round End Of Log (E) Against The Notch Of
Log (D) Here. Two Charred Spots Face The Front
D
Position Small End of Log
(E) on The Notch of Log
(C) Here
C
Log (F) Sits in
Front of The Grate
Figure 31
10. Place Log (E) as shown in Figure 31.
11. Place Log (F) as shown in Figure 32.
Figure 32
Step 9. INSTALLING/REMOVING GLASS ENCLOSURE PANELS Lower Compartment
Door & Hinge
Glass Door (Enclo-
sure Panel)
Top Flange
Glass Door
Figure 33
Firebox Floor
Glass Door Latch
Bottom Vee-flange
Glass Door
Only doors certified with the appliance shall be used.
Seules des portes certifiées pour cet appareil doivent être
utilisées.
WARNING:DONOTabuseglassdoorbystrikingorslammingshut.
These are B-vent appliances. They are designed to operate only when
the glass enclosure panels are installed. Generally the glass enclosure
panels should not be removed except to gain access to the components
within the firebox.
1. Visually inspect the gasket on the backside of the panels. The gasket
surface must be clean, free of irregularities and seated firmly.
2. Position the glass enclosure panel in front of the firebox opening at
a 45 degree angle and engage the top flange over the lip at the top of
the firebox opening. See Figure 33.
3. Swing the glass enclosure panel down and back. Ensure the gasket
seats evenly as the panel draws shut. Engage the Vee-flange at the
bottom of the panel with the latches and close the latches to secure
the panel.
4. Reinstallthebottomcontrolcompartmentaccesspanel(ifnecessary)by
inserting the right side locating pin into the right side cabinet panel and
then the left side spring-loaded pin into the left side cabinet panel.
Glass Enclosure Panel Removal Instructions (see Figure 33)- Locate
the two (2) latches at the top of the control compartment. Open the two
latches from the bottom vee-flange of the glass enclosure panel (reach for
the handles located towards the back of the latches and pull the handles
down toward the front of the appliance).
WARNING
•Do not attempt to substitute the materials used on
these doors, or replace cracked or broken glass.
• Handle this glass with extreme care! Glass is
susceptible to damage – Do not scratch or handle
roughly while reinstalling the glass door frame.
• The glass door(s) of this appliance must only be
replaced as a complete unit as provided by the
manufacturer. Do not attempt to replace broken,
cracked or chipped glass separately.
•Do not attempt to touch the front enclosure glass
with your hands while the fireplace is in use.
WARNING
Do not operate appliance with the glass front
removed, cracked or broken.
AVERTISSEMENT
Ne pas utiliser l'appareil si le panneau frontal en
verre n'est pas en place, est craqué ou brisé.

19
NOTE: DIAGRAMS & ILLUSTRATIONS ARE NOT TO SCALE.
WARNING
•Air shutter adjustment should
only be performed by a quali-
fiedprofessionalservicetech-
nician.
•Ensureglassenclosurepanels
areinplaceandsealedduring
adjustment.
CAUTION
•Soot will be produced if the
airshutterisclosedtoomuch.
Any damage due to carboning
resulting from improperly
setting the air shutter is not
covered under the warranty.
• Theairshutterdoorandnearby
appliance surfaces are hot.
Exercise caution to avoid
injury while adjusting flame
appearance.
Burner Air Shutter Adjustment Procedure
Adjustment Rod Positions
(when viewed from above)
Figure 35
Main Burner Factory Air Shutter
Opening Setting - All Models
Model Natural
Gas
Propane
Gas
MPB35ST
1/8”
3.2mm
1/4”
6.4mm
Air Shutter
Adjusting Rod
Increase Shutter Opening
In This Direction
Decrease Shutter Opening
In This Direction
NOTE: Burners are omitted in this view for clarity.
Orifice
Burner Air Shutter Adjustment Procedure
1. Locateadjustmentrod andadjustair shutter
to the standard setting as shown in Figure
35 (adjustment rod is located in the lower
control area).
Note: Rotating the adjustment rod coun-
terclockwise decreases air and clockwise
increases air.
2. Lightappliance(followlightingprocedureon
lighting label in control compartment or see
care and operation instructions manual).
3. Allowtheburnertooperateforatleast15min-
utes while observing the flame continuously
to ensure that the proper flame appearance
has been achieved (see Figure 34).
Figure 34 - Burner Flame Appearance
Vermiculite
If the following conditions are present, adjust
accordingly.
• If ame appears weak or sooty, adjust the
air shutter, incrementally, to a more open
positionuntiltheproperflameappearance
is achieved.
• If ame stays lowered blue, adjust the air
shutter, incrementally, to a more closed
positionuntiltheproperflameappearance
is achieved.
4. Leave the control knob (off/pilot/on) in the
ON position (millivolt appliances) and the
burner OFF/ON switch OFF (and remote
switches, if applicable).
5. Whensatisfied thatthe burnerflame appear-
ance is normal, close the lower control
compartment door then proceed to finish
the installation.
Air Shutter Adjustment Guidelines:
Amount of
Primary Air
Flame
Color
Air Shutter
Adjustment
If air shutter is
closed too far Flame will be orange Air shutter gap should be
increased
If air shutter is
open too far Flame will be blue Air shutter gap should be
decreased
Step 10. BURNER ADJUSTMENTS
Flame Appearance and Sooting
Proper flame appearance is a flame which is
blueatthe base and becomes yellowish-orange
in the body of the flame.
When the appliance is first lit, the entire flame
may be blue and will gradually turn yellowish-
orange during the first 15 minutes of operation.
After 15 minutes of operation, if the flame is
blue, or if the flame is orange with evidence of
sooting (black tip), the air shutter opening may
need to be adjusted.
If the air shutter opening is closed too far,
sooting may develop. Sooting is indicated by
black puffs developing at the tips of very long
orangeflames. Sootingresultsinblackdeposits
forming on the logs, appliance inside surfaces
and on exterior surfaces adjacent to the vent
termination.
Sooting is caused by incomplete combustion
in the flames and lack of combustion air enter-
ing the air shutter opening. To achieve a warm
yellowish-orange flame with an orange body
that does not soot, the shutter opening must be
adjusted between these two extremes.
Air Shutter Adjustment Guidelines
• If there is smoke or soot present, rst check
the log set positioning to ensure that the
flames are not impinging on any of the logs.
If the log set is properly positioned and a
sooting condition still exists, then the air
shutter opening should be increased.
•Themoreoffsetsinthe ventsystem,thelarger
the air shutter opening will need to be.
• An appliance operated with the air shutter
opened too far, may have flames that appear
blue and transparent. These weak, blue and
transparent flames are termed anemic.
• Propane models may exhibit flames which
candle or appear stringy. If this is present
and persists, adjust the air shutter to a more
closed position, then operate the appliance
for a few more minutes to ensure that the
flame normalizes and the flames do not
appear sooty.
The following chart is provided to aid you in
achieving the correct air shutter adjustment
for your installation.

NOTE: DIAGRAMS & ILLUSTRATIONS ARE NOT TO SCALE.
20
17
Combustible
Wall
Framing
Combustible
Finished Wall
Materials
Drywall
Bracket/Spacer
Top of Appliance
Louvers
Top of Door
Frame
Hood must be
installed as shown.
1 in. Min.
(25 mm)
Top
Spacers
Top of Appliance
Radiant panel
Top of Door Frame
Hood must be
installed as shown.
IF OPTIONAL RADIANT
PANELS ARE INSTALLED
6. Take a smoke producing device and move
it along the bottom edge of the glass door
(where it is cracked open). If smoke is
drawn into the firebox, the vent operation
is adequate.IF THE SMOKE IS NOT
DRAWN INTO THE FIREBOX, TURN THE
APPLIANCEOFFANDCALLAQUALIFIED
SERVICE TECHNICIAN.
Manual-Reset (safety limit) Spill Switch
This appliance is equipped with a (safety limit)
spill switch thatisdesigned to "trip" anddiscon-
nect the burner circuit if flue spillage occurs
(because of improper venting of combustion
productsorvent blockage). If,duringappliance
operation, the burner flame goes out (indepen-
dently of the burner OFF/ON wall switch), it may
be due to the operation of this (safety limit) spill
switch. If this switch "trips" it will need to be
manually reset by pressing the reset button on
switch (see Figure 36).
Procedure to Reset (safety limit) Spill Switch
ALLOW APPLIANCE TO COOL COMPLETELY
BEFORE ACCESSING AND RESETTING
To access the spill switch:
1. Pull off the top louvered panel.
2. Locate and press the red reset button on
the switch (it will click and lock in).
The appliance should then relight and remain
lit. Ifthisdoes not occur,turn off the appliance
and call a qualified service technician.
Step 12. HOOD INSTALLATION
All of these appliances must have hoods
installed prior to operating on all sides with
glass enclosure panels.
On all clean face units (with optional radiant
panels),slidethehoodsintotheslotsonthelower
edges of the radiant panel (Figure 37).
FINISHING REQUIREMENTS
(Wall Details)
Complete finished interior wall. To install the
appliance facing flush with the finished wall,
position framework to accommodate the thick-
ness of the finished wall (Figure 37)
See Page 5 for Cold Climate Insulation and
Page 7 for Clearances.
Step 11. VENT OPERATION TEST
A vent operation test is required as part of the
installationtoverifythat properventingcondi-
tions exist and should be done periodically to
ensure nothing has changed that would affect
proper venting of the appliance.
Procedure:
1. ENSURE APPLIANCE IS OFF (PILOT ONLY)
AND COOL.
2. Open both latches on one of the glass enclo-
sure doors and slightly prop it open at the
bottom (approx. 1/4” gap). See Figure 33
on Page 18.
3. Turn on all the exhaust fans in the dwelling
(and any other appliances which remove
air from the dwelling, such as a furnace or
clothes dryer, etc)..
4. Ensure that all the doors and windows in
the room where the fireplace is located are
closed.
5. Light the appliance (see Lighting Instruc-
tions in Control Compartment or Care and
Operation Instructions Manual). Adjust
flame height to highest setting and operate
for approximately 5-10 minutes. Do not
leave appliance unattended.
SPILL SWITCH
Press Reset
Button on Spill
Switch
Remove Top Louvered
Panel(oroptionalradiant
panel, if applicable)
Figure 36 Figure 37 - FINISHING REQUIREMENTS
