Lenovo USB Portable DVD Burner User manual

LenovoUSBPortableDVD
Burner
Quick Start Guide

First Edition (January 2010)
© Copyright Lenovo 2010.
LENOVO products, data, computer software, and services have been developed
exclusively at private expense and are sold to governmental entities as
commercial items as defined by 48 C.F.R. 2.101 with limited and restricted rights
to use, reproduction and disclosure.
LIMITED AND RESTRICTED RIGHTS NOTICE: If products, data, computer
software, or services are delivered pursuant a General Services Administration
″GSA″contract, use, reproduction, or disclosure is subject to restrictions set forth
in Contract No. GS-35F-05925.

Contents
Online safety information resources ........v
General safety guidelines ............vii
Service ...................vii
Heat and product ventilation ............vii
Important information about the product CD .....ix
Quick installation instructions ..........1-1
Product description ...............1-1
Locating the controls...............1-2
System requirements ...............1-3
Software description ...............1-4
Connecting the drive...............1-5
Installing software ...............1-5
Native operating system support ...........1-6
Product specifications ............2-1
Service and Support .............A-1
Online technical support .............A-1
Telephone technical support ............A-1
Lenovo Limited Warranty - Customer Notice.....B-1
Notices ..................C-1
Recycling information ..............C-3
Trademarks .................C-3
Electronic emission notices ..........D-1
Restriction of Hazardous Substances Directive (RoHS) E-1
© Copyright Lenovo 2010 iii

China RoHS .................E-1
Turkish statement of compliance ...........E-2
iv Lenovo USB Portable DVD Burner Quick Start Guide

Online safety information resources
For tips to help you use your computer safely, go to:
http://www.lenovo.com/safety
Para obter dicas para ajudá-lo a usar o computador com segurança,
acesse:
http://www.lenovo.com/safety
Pour obtenir des astuces pour utiliser votre ordinateur en toute
sécurité, consultez le site :
http://www.lenovo.com/safety
Tipps zum sicheren Umgang mit dem Computer finden Sie unter:
http://www.lenovo.com/safety
Per suggerimenti su un utilizzo sicuro del computer, visitare il sito
all’indirizzo:
http://www.lenovo.com/safety
Para obtener consejos sobre cómo utilizar el sistema de forma segura,
vaya a:
http://www.lenovo.com/safety
Bilgisayarınızı güvenle kullanmanıza ilişkin ipuçları için lütfen aşağıdaki adrese bakın:
http://www.lenovo.com/safety
© Copyright Lenovo 2010 v

vi Lenovo USB Portable DVD Burner Quick Start Guide

General safety guidelines
Always observe the following precautions to reduce the risk of injury
and property damage.
Service
Do not attempt to service a product yourself unless instructed to do so
by the Customer Support Center. Use only a service provider who is
approved to repair your particular product.
Note: Some parts can be upgraded or replaced by the customer. These
parts are referred to as Customer Replaceable Units, or CRUs.
Lenovo expressly identifies CRUs as such, and provides
documentation with instructions when it is appropriate for
customers to replace those parts. You must closely follow all
instructions when performing such replacements. The Off state of
a power indicator does not necessarily mean that voltage levels
inside a product are zero. Always make sure that the power is
turned off and that the product is unplugged from any power
source before you attempt the replacement. If you have any
questions or concerns, contact the Customer Support Center.
Heat and product ventilation
Computers, ac power adapters, and many accessories can generate heat
when turned on and when batteries are charging. Always follow these
basic precautions:
vDo not leave your computer, ac power adapter, or accessories in
contact with your lap or any part of your body for an extended
period when the products are functioning or when the battery is
charging. Your computer, ac power adapter, and many accessories
produce some heat during normal operation. Extended contact with
the body could cause discomfort or, potentially, a skin burn.
© Copyright Lenovo 2010 vii

vDo not charge the battery or operate your computer, ac power
adapter, or accessories near flammable materials or in explosive
environments.
vVentilation slots, fans, and heat sinks are provided with the product
for safety, comfort, and reliable operation. These features might
inadvertently become blocked by placing the product on a bed, sofa,
carpet, or other flexible surface. Never block, cover, or disable these
features.
viii Lenovo USB Portable DVD Burner Quick Start Guide

Important information about the product CD
The User Guide is available in multiple languages on the product CD.
Insert the CD into the CD or DVD drive and select a language.
Le guide d’utilisation est disponible en plusieurs langues sur le CD du
produit. Insérez le CD dans l’unité de CD ou de DVD, puis
sélectionnez une langue.
Das Benutzerhandbuch ist in mehreren Sprachen auf der Produkt-CD
verfügbar. Legen Sie die CD in das CD- oder DVD-Laufwerk ein, und
wählen Sie eine Sprache aus.
La Guida per l’utente è disponibile in più lingue sul CD del prodotto.
Inserire il CD nell’unità CD o DVD e selezionare la lingua.
En el CD del producto, encontrará la guía del usuario en distintos
idiomas. Inserte el CD en la unidad de CD o DVD y seleccione un
idioma.
O Guia do Usuário está disponível em vários idiomas no CD do
produto. Insira o CD na unidade de CD ou DVD e selecione um
idioma.
Brugervejledningen findes på flere sprog på produkt-CD’en. Læg CD’en
i CD- eller DVD-drevet, og vælg sprog.
Tuotteen CD-tietolevyssä on usealle eri kielelle käännetty käyttöopas.
Aseta levy CD- tai DVD-asemaan ja valitse haluamasi kieli.
Het Handboek voor de gebruiker is in verschillende talen beschikbaar
op de product-CD. Plaats de CD in het CD- of DVD-station en kies een
taal.
Brukerhåndboken finnes på flere språk på produkt-CDen. Sett CDen
inn i CD- eller DVD-stasjonen og velg et språk.
© Copyright Lenovo 2010 ix

O Manual do Utilizador está disponível em vários idiomas no CD do
produto. Introduza o CD na unidade de CD ou DVD e seleccione um
idioma.
Användarhandboken finns på flera språk på produkt-CDn. Sätt in CDn
i CD- eller DVD-enheten och välj språk.
xLenovo USB Portable DVD Burner Quick Start Guide

Kasutusjuhend on toote CD-l saadaval mitmes keeles.
Sisestage CD oma arvuti CD- või DVD-seadmesse ja valige soovitud keel.
Produkto kompaktiniame diske rasite vartotojo vadovà ávairiomis kalbomis.
Ádëkite kompaktiná diskà á kompaktiniø ar DVD diskø árenginá ir pasirinkite
savo kalbà.
Produkta lietotâja rokasgrâmata ir pieejama vairâkâs valodâs kompaktdiskâ.
Ievietojiet to kompaktdiska vai DVD diskdzinî un izvçlieties valodu.
Important information about the product CD xi

На компактдиске продукта есть переводы Руководства пользователя
на несколько языков. Вставьте компактдиск в или дисковод
и выберите язык.
CD DVD
xii Lenovo USB Portable DVD Burner Quick Start Guide

Quick installation instructions
This chapter provides essential information to set up and prepare the
Lenovo®USB Portable DVD Burner (hereafter called the drive) for use.
For more information on how to work with the drive, refer to the
Lenovo USB Portable DVD Burner User Guide.
Product description
The Lenovo USB Portable DVD Burner is a portable DVD and CD
recordable drive that easily attaches to two USB 2.0 connectors on your
computer through a USB Y cable. The drive conforms with industry
standard specifications for CD-R, CD-ROM, CD-RW, DVD-R, DVD-R
(dual layer), DVD-RAM, DVD-ROM, DVD-RW, DVD+R, DVD+R
(double layer), and DVD+RW media.
The drive package includes:
vLenovo USB Portable DVD Burner
vUSB Y cable
vSoftware and User Guide CD
vLenovo USB Portable DVD Burner Quick Start Guide
vLaser Safety Manual
Contact your place of purchase if an item is missing or damaged. Be
sure to retain your proof of purchase and packing material. They might
be required to receive warranty service.
© Copyright Lenovo 2010 1-1

Locating the controls
The following figure shows the locations of the controls on the drive.
1 Disc tray Used to firmly seat the medium with the label facing
up on the disc tray.
Attention: Push the CD/DVD medium down until it
clicks and is secured in the center.
1-2 Lenovo USB Portable DVD Burner Quick Start Guide

2 LED indicator The LED indicates the status of the drive.
vLED is flashing: indicates that the drive is reading
or writing.
vLED is off: indicates that the drive is not reading or
writing.
3 Eject button Press this button to open the disc tray.
Attention: An electrical locking mechanism is used in
this drive so that an erroneous operation does not
open the disc tray during write. Make sure that the
power is on and the drive is not in operation before
pressing the Eject button to open the disc tray.
If the disc tray cannot be opened when you press the
Eject button, or if the disc tray needs to be opened
when the power is not supplied from the USB Y
connector, use the emergency eject hole 4 in the front
panel of the drive.
Check that nothing is placed in front of the disc tray
when ejecting.
4 Emergency eject The emergency eject is used for ejecting the medium in
an emergency when the drive is powered off. Insert a
paper clip into the emergency eject hole to open the
disc tray.
5 USB 2.0 Mini B
receptacle connector
Used to connect the USB Y cable.
System requirements
To use the drive, your computer must meet the following requirements:
vTwo available USB 2.0 connectors
Quick installation instructions 1-3

vMicrosoft®Windows®XP, Microsoft Windows Vista®, or Microsoft
Windows 7 operating system
Software description
The Software and User Guide CD contains the following software:
vMyDVD
This software enables you to create DVD-RAM, DVD-RW, DVD-R,
DVD+RW, and DVD+R media that can be played in most stand-alone
DVD players. You can add your own videos and create custom
menus for DVD videos that you create. You can also use this
software to edit and modify your own video assets prior to
recording. If you have an analog, USB, or IEEE 1394 capture device
installed in your computer, you can use this software to record
videos from a camera.
vCreator Business Edition
This software enables you to copy CDs, create audio CDs, create MP3
CDs, and author data CDs. You can also use Creator Business Edition
to write data to DVD-RAM, DVD-RW, DVD-R, DVD-R DL,
DVD+RW, DVD+R DL, and DVD+R media for use in other
computers or compatible consumer electronics products. You can also
create bootable CDs and save CD images for later recording. With
the Express Labeller that is included in Creator Business Edition, you
can print paper labels.
Note: It will take approximately 30 minutes to install Creator
Business Edition depending on your system configuration.
vIntervideo WinDVD
This software enables you to play back DVD videos on your
computer or to play video files from your hard disk drive.
Note: Creator Business Edition and MyDVD are installed and
uninstalled together.
1-4 Lenovo USB Portable DVD Burner Quick Start Guide

Connecting the drive
This section provides instructions to connect the drive to your
computer with the provided USB Y cable.
To connect the drive to your computer , do the following:
1. Turn on your computer.
2. Connect both USB A connectors of the USB Y cable, 1 and 2,to
you computer.
3. Connect the USB Mini B connector 3 of the USB Y cable to the
USB 2.0 Mini B receptacle connector 4 on the drive.
Installing software
After you have connected the drive to your computer, you can install
the software on the Software and User Guide CD. For the detailed
software descriptions, see “Software description” on page 1-4.
1. Save any open documents and exit all applications.
2. Insert the Software and User Guide CD and do one of the following:
vIf the CD starts automatically, go to step 3.
vIf the AutoPlay window opens, click Run start.bat. Then, go to
step 3.
Quick installation instructions 1-5

vIf the CD does not start automatically, go into My Computer or
Computer, browse the CD/DVD drive, and double-click
Start.bat.
3. At the prompt of the Internet Explorer®warning message, click Yes
to allow the CD to run active content.
4. Select your language.
5. On the left side of the window, click Software.
6. Follow the instructions on the screen.
Native operating system support
Your drive is compatible with the native CD burning and CD/DVD
playback functions of the Windows XP, Windows Vista, and Windows 7
operating systems. You can perform these tasks without installing the
software on the Software and User Guide CD:
vUsing Windows Explorer, you can record data on DVD-RW, DVD-R,
CD-R and CD-RW media.
vUsing Windows Media®Player, you can burn audio CDs from your
own audio files.
vFor the Windows Vista and Windows 7 users, depending on your
Windows settings, you can use Windows Media Player to view
DVDs even if the software on the Software and User Guide CD is not
installed.
vWindows Vista and Windows 7 users can use Movie Maker to create
DVD videos.
vSystems equipped with Windows Media Center can use it to record
CDs and DVDs.
vWindows 7 users can record ISO CD images using Windows
Explorer.
1-6 Lenovo USB Portable DVD Burner Quick Start Guide

Product specifications
This appendix includes the following information for the Lenovo USB
Super Multi-Burner Drive:
vPhysical specifications
vEnvironmental requirements
vRead speeds
vWrite speeds
Physical specifications
The physical specifications1of the drive are listed in this table:
Physical specifications
Height 21 mm (0.83 in)
Width 145 mm (5.71 inches)
Length 155 mm (6.10 inches)
Weight 350 g (0.77 lb)
Environmental requirements
Specifications Operational Non-operational
Temperature +5°Cto+35°C(30°C
per hour maximum)
-40°Cto+65°C(30°C
per hour maximum)
Relative humidity 10% to 80% (20% per hour
maximum)
10% to 90% (20% per hour
maximum)
1. Product-description data represents Lenovo’s design objectives and is provided
for comparative purposes; actual results might vary based on a variety of
factors. This product data does not constitute a warranty. Data is subject to
change without notice.
© Copyright Lenovo 2010 1-7

Read speeds
Disc Maximum speed
CD-R 24X CAV
CD-RW 24X CAV
DVD-R 8X CAV
DVD-RW 8X CAV
DVD-R DL 8X CAV
DVD+R 8X CAV
DVD+RW 8X CAV
DVD+R DL 8X CAV
DVD-RAM 5X CAV
DVD-ROM SL 8X CAV
DVD-ROM DL 8X CAV
Write speeds
Media Maximum speed
CD-R 24X PCAV
CD-RW 24X ZCLV
DVD-R 8X PCAV
DVD-RW 6X ZCLV
DVD-R DL 4X ZCLV
DVD+R 8X ZCLV
DVD+RW 8X ZCLV
1-8 Lenovo USB Portable DVD Burner Quick Start Guide
