Lenovo 0769AKU User manual

Lenovo recommends Windows Vista™ Business. 1.866.426.1316 |LENOVO.COM
NEW WORLD. NEW THINKING.™
powerful proDuCTIVITY
Latest Intel®Centrino®Duo processor technology
powerful CapabIlITY
Integrated wireless and available Bluetooth®technology
powerful SImplICITY
One-button system recovery and automated software updates*
LENOVO 3000 N200 WIDESCREEN PROVES
AFFORDABLE CAN BE POWERFUL.

Lenovo recommends Windows Vista™ Business.
© 2007 Lenovo. Produced in the USA, 05-07. All rights reserved. *Virus recovery button: can help restore system to previously saved uninfected state; does not include anti-virus software. Availability: All offers subject
to availability. Lenovo reserves the right to alter product offerings and specifications at any time without notice. Lenovo is not responsible for photographic or typographic errors. Warranty information: For a copy of
applicable product warranties, write to: Warranty Information, P.O. Box 12195, RTP, NC 27709, Attn: Dept. ZPYA/B676. Lenovo makes no representation or warranty regarding third-party products or services. Footnotes:
[1] Limited warranty: Support unrelated to a warranty issue may be subject to additional charges. [2] Mobile processors: Power management reduces processor speed when in battery mode. [3] Operating system:
Level of support varies by operating system. Operating systems not preloaded on the system may not provide full feature functionality. Refer to lenovo.com/pc/support and enter your machine type and model number
for more information. [4] Hard disk drive: GB=1,000,000,000 bytes. Accessible capacity is less; up to 4GB is service partition. [5] Memory: For PCs without a separate video card, memory supports both system and
video. Accessible system memory is up to 64MB less than the amount stated, depending on video mode. [6] Models with 4GB memory: Total accessible memory will be less and will vary depending on the system
configuration. Maximum capacity may require purchase of optional component. [7] Wireless 11a, 11b and 11g wireless: are based on IEEE 802.11a, 802.11b and 802.11g, and 802.11n respectively. The 802.11n
standard is in draft and is not due for final approval until March 2008. An adapter with 11a/b, 11a/b/g or 11a/b/g/n can communicate on any of its supported formats; the actual connection will be based on the access
point to which it connects. Wireless upgradeable models can be wireless enabled with the addition of an optional wireless LAN Mini PCI card. These systems are designed to operate only with wireless LAN Mini PCI
options sold by Lenovo. [8] The Bluetooth word mark and logos: are owned by Bluetooth SIG, Inc. and any use of such marks by Lenovo is under license. [9] Weight: includes battery and standard optical drive;
weight may vary due to vendor components, manufacturing process and options. [10] Thinness: may vary at certain points on the system. [11] Included software: may differ from its retail version (if available) and may
not include user manuals or all program functionality. License agreements may apply. [12] Battery: Battery life (and recharge times) will vary based on many factors including system settings and usage. A description of
the environment under which the test was performed is available upon request. See www.pc.ibm.com/ww/thinkpad/batterylife/ for details. The following are trademarks or service marks of Lenovo: Lenovo and the
Lenovo logo, Lenovo Care, ThinkPad and ThinkVantage. Microsoft and Windows Vista are trademarks of Microsoft Corporation. Intel, Celeron, and Core are trademarks of Intel Corporation in the U.S. and other countries.
Other company, product and service names may be trademarks or service marks of others.
Visit lenovo.com/safecomputing periodically for the latest information on safe and effective computing. LVDN100-0107-WWEN-03
PROCESSOR2(SPEED, L2 CACHE, FSB)
Intel®Core®2 Duo T7500 (2.2GHz, 4MB, 800MHz)
Intel Core 2 Duo T7300 (2.0GHz, 4MB, 800MHz)
Intel Core 2 Duo T7100 (1.8GHz, 2MB, 800MHz)
Intel®Celeron®540 (1.86GHz, 1MB, 533MHz,
July availability)
PRELOADED OPERATING SYSTEM3
Genuine Windows VistaTM Ultimate 32
Genuine Windows Vista Business 32
Genuine Windows Vista Home Premium 32
Genuine Windows Vista Home Basic 32
DISPLAY/RESOLUTION
14.1" widescreen WXGA VibrantView or anti-glare (1280x800),
15.4" widescreen WXGA VibrantView (1280x800) or
15.4" widescreen WSXGA+ VibrantView (1680x1050)
VIDEO GRAPHICS
Intel Graphics Media Accelerator X3100 (up to 256MB)
NVIDIA GeForce Go 7300 (128MB or 256MB)
SERIAL ATA HARD DRIVE4
80, 120, 160GB 5400rpm
MEMORY5
Up to 4GB PC2-5300/667MHz (3GB addressable with
32-bit OS)6
OPTICAL DRIVE
CD-RW/DVD Combo or Dual Layer DVD Recordable
CAMERA
1.3 megapixel integrated camera (select models)
INTEGRATED COMMUNICATIONS
Modem, 10/100 Ethernet, Lenovo 11b/g Wireless
LAN7 , Lenovo 11a/b/g/n Wireless LAN, Intel PRO/
Wireless 3945ABG, Intel Wireless WiFi Link 4965AGN,
Bluetooth®8 (select models)
SECURITY
Client Security Solution and Norton Internet Security
software
Integrated fingerprint reader (select models)
WEIGHT9
14.1": Starting at 2.4kg (5.3 lb)
15.4": Starting at 2.8kg (6.2 lb)
DIMENSIONS10
14.1": 335 x 247 x 30-36 mm (13.2 x 9.7 x 1.18-1.42")
15.4": 360 x 267 x 31.4-38.6 mm
(14.2 x 10.5 x 1.24-1.52")
LIMITED WARRANTY1
1yr system (3yr upgrade available)/1yr battery
INCLUDED SOFTWARE11
Lenovo CareSM tools; Adobe Reader; Diskeeper Home;
Corel Small Business Center, featuring WordPerfect Office
12 (includes full versions of WordPerfect and Photo Album
6 Starter); Picasa from Google; Microsoft®Windows Live
Toolbar & Windows Live Search; InterVideo InstantON;
Lenovo Multimedia Center; Norton Internet Security (90
days of virus definitions); PC Doctor; Quickbooks Financial
Center (U.S. only); Network Magic (AG & EMEA only);
LANDesk Starter Pack for ThinkVantage Client License
(license only), Microsoft Office 2007 Professional (60-day
trial, select models)
LI-ION BATTERY LIFE12
Windows Vista battery life pending.
Performance expected similar to N100 (4hr+).
ACCESSORIES
Lenovo Carrying Case—Top Loader (40Y8601)
Lenovo USB Headset by Sennheiser (40Y8518)
N200 9-Cell Li-Ion Battery:
14.1" (41U5026)
15.4" (41U5027)
We created the Lenovo 3000 N200 widescreen
for upstart entrepreneurs— and anybody who
needs a notebook that does a lot but doesn’t
cost a lot. Lenovo CareSM tools simplify things like
network connections and regular maintenance.
Norton Internet Security protects against spyware
and viruses. And Intel®Centrino®Duo processor
technology makes it one highly mobile multitasker.
Even better, it’s one you can actually afford. From
the world’s best engineers come the world’s
best-engineered PCs.
LENOVO 3000 N200 IS ALL ABOUT CAN-DO RELIABILITY.
A choice of 14.1" or 15.4" VibrantView widescreen displays
Integrated camera, 5-in-1 card reader, ExpressCard 54
Worldwide, round-the-clock service and support
An outstanding limited warranty1
The N200 widescreen notebook is a product of Lenovo, a global company incorporating
the former IBM PC division.
LENOVO3000N200SPECIFICATIONS
LENOVO USB PORT REPLICATOR WITH VIDEO
AMPLE DESKTOP EXPANSION WITH STANDARD
AND POWERED USB 2.0 PORTS,
PLUS A VGA MONITOR OUTPUT (40Y8132)
NEW WORLD. NEW THINKING.™
