Chapter 1. Getting to know your computer
Top view ---------------------------------------------------------------------------------------------------
Note: Thedashedareasindicatepartsthatarenotvisiblefromoutside.
Attention:
Donotopenthedisplaypanelbeyond130degrees.Whenclosingthedisplaypanel,becareful
nottoleavepensoranyotherobjectsinbetweenthedisplaypanelandthekeyboard.
Otherwise,thedisplaypanelmaybedamaged.
1
4
5
2
3
7
6


2
Chapter 1. Getting to know your computer
Integrated
camera
Usethecameraforvideocommunication.
Built-in
microphone
Capturessound,whichcanbeusedforvideo
conferencing,voicenarration,oraudiorecordings.
Multi-touch
display
TheLCDdisplaywithLEDbacklightprovidesbrilliant
visualoutput.Multi‐touchfunctionisavailableonthis
display.
Power button
Pressthisbuttontoturnonthecomputer.
Touchpad
Thetouchpadfunctionsasaconventionalmouse.
TouchpadTomovethecursoronthescreen,slideyour
fingertipoverthepadinthedirectioninwhichyouwant
thecursortomove.
TouchpadbuttonsThefunctionsoftheleft/rightside
correspondtothoseoftheleft/rightmousebuttonona
conventionalmouse.
Notes:
•Youcanenable/disablethetouchpadbypressingF6().
•IfyouchangetheHotKeyModefromEnabledtoDisabledintheBIOSsetuputility,
youneedtopresstheFnkeyincombinationwiththeappropriatehotkey.
Ventilation slots
Dissipateinternalheat.
Attention:
Makesurethatnoneoftheventilationslotsareblockedotherwiseoverheatingofthe
computermayoccur.
Wireless
antennas
Connecttothewirelessadaptertoreceiveandsend
wirelesssignal.
a
b
c
d
e
f

g

Chapter 1. Getting to know your computer
3
Hotkeys
Youcanaccesscertainsystemsettingsquicklybypressingtheappropriate
hotkeys.
: Mutes/unmutesthesound. : Enables/disablesAirplane
mode.
: Decreasesthevolumelevel. : Switchestheactiveprogram.
: Increasesthevolumelevel. : TurnstheLCDscreenback‐
lighton/off.
: Closesthecurrentlyactive
window. : Projectstoaconnected display.
: Refreshesthedesktoporthe
currentlyactivewindow. : Decreasesdisplay brightness.
: Enables/disablesthe
touchpad. : Increasesdisplaybrightness.
Note: IfyouchangetheHotKeyModefromEnabledtoDisabledintheBIOSsetuputility,
youneedtopresstheFnkeyincombinationwiththeappropriatehotkey.

4
Chapter 1. Getting to know your computer
Function key combinations
Throughtheuseofthefunctionkeys,youcanchangeoperationalfeatures
instantly.Tousethisfunction,pressandholdFn;thenpressoneofthe
functionkeys.
Thefollowingdescribesthefeaturesofeachfunctionkey.
Fn + Home: Activatethepausefunction.
Fn + End: Activatethebreakfunction.
Fn + PgUp: Enable/disablethescrolllock.
Fn + PgDn: Activatetheinsertfunction.
Fn + Space : Turnthekeyboardbacklighton/off.
a
b
Insert PrtSc Delete Home End PgUp PgDn
Pause Break ScrLk SysRq
Fn
2
1

Chapter 1. Getting to know your computer
5
Left-side view --------------------------------------------------------------------------------------
Novo button
Whenthecomputerisofforinhibernationmode,press
thisbuttontostarttheLenovoOneKeyRecoverysystem
ortheBIOSsetuputility,ortoenterthebootmenu.
Notes:
•Fordetails,see“Chapter3.LenovoOneKeyRecoverysystem”onpage22.
•IfyourcomputerispreinstalledwithaLinpusoperatingsystem,OnekeyRecovery
systemisnotavailable.
RJ-45 port
ConnectsthecomputertoanEthernetnetwork.
HDMI port
ConnectstodeviceswithHDMIinputsuchasaTVora
display.
USB port
ConnectstoUSBdevices.
Notes:
•TheportsupportsUSB3.0.
•Fordetails,see“ConnectingUSBdevices”onpage6.
Combo audio
jack
Connectstoheadsets.
Notes:
•Atthedefaultsetting,thecomboaudiojackdoesnotsupportconventionalmicrophones.
•Therecordingfunctionmaynotbesupportedifthird‐partyheadphonesorheadsetsare
connected,duetodifferentindustrystandards.
1 2 3 4 5
a
b
c
d
e

6
Chapter 1. Getting to know your computer
Connecting USB devices
ConnectaUSBdevicetoyourcomputerbyinsertingtheUSBplug(TypeA)
intotheUSBportonyourcomputer.
ThefirsttimeyouplugaUSBdeviceintoaparticularUSBportonyour
computer,Windowsautomaticallyinstallsadriverforthatdevice.Afterthe
driverisinstalled,youcanreconnectthedevicewithoutperformingany
additionalsteps.
BeforedisconnectingaUSBstoragedevice,makesureyourcomputerhas
finishedtransferringdatatoorfromthatdevice.ClicktheSafelyRemove
HardwareandEjectMediaiconinthenotificationareaoftheWindows
desktopscreentoremovethedevicebeforedisconnecting.
Note: Typically,Windowsdetectsanewdeviceafterconnectingit,andtheninstallsthe
driverautomatically.However,somedevicesmayrequireyoutoinstallthedriver
beforeconnecting.Checkthedocumentationprovidedbythedevice’smanufacturer
beforeconnectingthedevice.
Notes:
•IfyourUSBdeviceusesapowercord,connectthedevicetoapowersourcebefore
connectingit.Otherwise,thedevicemaynotberecognized.
•ToconnectordisconnectaUSBdeviceinsleepmode,wakeupyourcomputerfirst.

Chapter 1. Getting to know your computer
7
Connecting a Bluetooth device
IfyourcomputerhasanintegratedBluetoothadaptercard,itcanconnectto
andtransferdatawirelesslytoorfromotherBluetoothenableddevices,such
asnotebookcomputers,PDAs,andcellphones.Youcantransferdata
betweenthesedevicesatarangeofupto10metersinopenspace.
Enabling Bluetooth and WLAN communications on your computer
PressF7()todisableairplanemode.
Note: Theactualmaximumrangemayvaryduetointerferenceandtransmissionbarriers.
Forthebesttransferspeed,placethedeviceasneartoyourcomputeraspossible.
Notes:
•WhenyoudonotneedtousetheBluetoothfunction,turnitofftosavebatterypower.
•YouneedtopairtheBluetoothenableddevicewithyourcomputerbeforeyoucantransfer
databetweenthem.ReadthedocumentationsuppliedwiththeBluetoothenableddevice
fordetailsonhowtopairthedevicewithyourcomputer.

8
Chapter 1. Getting to know your computer
Right-side view ----------------------------------------------------------------------------------
System status
indicators
Powerindicator
Batterystatusindicator
Symbol Indicator status Meaning
On(solidwhite) Thecomputerispowered
on.
Blinking Thecomputerisinsleep
mode.
Off Thecomputerispowered
off.
On(solidwhite) Thebatteryhasmorethan
20%charge.
Solidamber Thebatteryhasbetween5%
and20%charge.
Fastblinkingamber Thereisaproblemwiththe
batteryorthebatterycon‐
nection.
Slowblinkingamber Thebatteryisbeing
charged.Whenbattery
chargereaches20%,the
blinkingcolorchangesto
white.
Slowblinkingwhite Thebatteryhasbetween
20%and80%chargeandis
stillcharging.Whenthebat‐
teryreaches80%charge,the
lightwillstopblinking,but
chargingwillcontinueuntil
thebatteryisfullycharged.
bc
ad
a

Chapter 1. Getting to know your computer
9
Memory card slot
Insertmemorycards(notsupplied)here.
Note: Fordetails,see“Usingmemorycards(notsupplied)”onpage10.
USB port
ConnectstoUSBdevices.Fordetails,see“Connecting
USBdevices”onpage6.
Note: Ifthebatteryismorethan20%charged,theUSBportwithamarksupportsthe
chargingofanexternalUSBdevice,evenwhenthecomputeristurnedoff.
AC power adapter
jack
ConnectstheACpoweradapter.
b
c
d

10
Chapter 1. Getting to know your computer
Using memory cards (not supplied)
Yourcomputersupportsthefollowingtypesofmemorycard:
•SecureDigital(SD)card
• MultiMediaCard(MMC)
Inserting a memory card
Toinsertamemorycard,dothefollowing:
1 Pushthedummycardinuntilyouhearaclick.
2 Gentlypullthedummycardoutofthememorycardslot.
3 Slideamemorycardinuntilitclicksintoplace.
Removing a memory card
Toremoveamemorycard,dothefollowing:
1 Pushthememorycardinuntilyouhearaclick.
2 Gentlypullthememorycardoutofthememorycardslot.
Notes:
•Insertonlyonecardintheslotatatime.
•ThiscardreaderdoesnotsupportSDIOdevices(e.g.,SDIOBluetooth,etc.).
Note: Thedummycardisusedforpreventingdustandsmallparticlesfromenteringthe
insideofyourcomputerwhenthememorycardslotisnotinuse.Retainthedummy
cardforfutureuse.
Attention:
Beforeremovingamemorycard,disableitthroughSafelyRemoveHardwareandEject
Mediatoavoiddatacorruption.


Chapter 1. Getting to know your computer
11
Bottom view ------------------------------------------------------------------------------------------
Louvers
Allowairtoenterthecomputerforcooling.
Speakers
Provideaudiooutput.
1
2 2
a
b

12
Chapter 2. Starting to use Windows 8
Configuring the operating system for the first
time --------------------------------------------------------------------------------------------------------------
Youneedtoconfiguretheoperatingsystemwhenitisfirstused.The
configurationprocessmayincludetheproceduresbelow:
• Acceptingtheenduserlicenseagreement
• ConfiguringtheInternetconnection
•Registeringtheoperatingsystem
•Creatingauseraccount
Operating system interfaces --------------------------------------------------
Windows8comeswithtwomainuserinterfaces:theStartscreenandthe
Windowsdesktop.
ToswitchfromtheStartscreentotheWindowsdesktop,dooneofthe
following:
•SelecttheDesktoptileontheStartscreen.
•PresstheWindowskey+D.
ToswitchfromthedesktoptotheStartscreen,dooneofthefollowing:
•SelectStartfromthecharmsbar.
•Movethecursortothelower‐leftcorner,andthenselecttheStartscreen
thumbnailwhenitisdisplayed.
Start screen Desktop

Chapter 2. Starting to use Windows 8
13
Charms and the charms bar ---------------------------------------------------
Charmsarenavigationbuttonsthatletyouaccessbasictasksquickly.
Charmsinclude:Search,Share,Start,Devices,andSettings.Thecharmsbar
isthemenuthatcontainsthecharms.Todisplaythecharmsbar,dooneof
thefollowing:
•Movethecursortotheupper‐rightorlower‐rightcorneruntilthecharms
barisdisplayed.
•PresstheWindowskey+C.
•Useafingertoswipeinfromtherightedgeofthescreenuntilthecharms
barisdisplayed.
Search charm
TheSearchcharmisapowerfulnewwaytofindwhatyouarelookingfor,
includingapps,settings,andfiles.

14
Chapter 2. Starting to use Windows 8
Share charm
TheSharecharmletsyousendlinks,photos,andmoretoyourfriendsand
socialnetworkswithoutleavingtheappyouarein.
Start charm
TheStartcharmisaquickwaytogototheStartscreen.
Devices charm
TheDevicescharmallowsyoutoconnectorsendfilestoconnectedexternal
devices,includingdigitalcameras,TVs,andprinters.
Settings charm
TheSettingscharmletsyouperformbasictasks,suchassettingthevolume
orshuttingdownthecomputer.Also,youcangettotheControlPanel
throughtheSettingscharmwhenontheDesktopscreen.

Chapter 2. Starting to use Windows 8
15
Putting the computer to sleep or shutting it
down ------------------------------------------------------------------------------------------------------------
Whenyouhavefinishedworkingwithyourcomputer,youcanputittosleep
orshutitdown.
Putting your computer to sleep
Ifyouwillbeawayfromyourcomputerforashorttime,putthecomputerto
sleep.Whenthecomputerisinsleepmode,youcanquicklywakeitto
resumeuse,bypassingthestartupprocess.Toputthecomputertosleep,do
oneofthefollowing:
•Closethedisplaypanel.
•Press
thepowerbutton.
•Openthecharmsbar,andthenselectSettingsPowerSleep.
Towakeupthecomputer,dooneofthefollowing:
•Pressanykeyonthekeyboard.
•Pressthepowerbutton.
Attention:
Waituntilthepowerindicatorlightstartsblinking(indicatingthatthecomputerisinsleep
mode)beforeyoumoveyourcomputer.Movingyourcomputerwhiletheharddiskis
spinningcandamagetheharddisk,causinglossofdata.


16
Chapter 2. Starting to use Windows 8
Shutting down the computer
Ifyouarenotgoingtouseyourcomputerforalongtime,shutitdown.
Toshutdownyourcomputer,dothefollowing:
1 Openthecharmsbar,thenselectSettings.
2 SelectPowerShutdown.
