Lenovo ThinkPad X1 Carbon User manual

Carbon
Setup Guide
Panduan Persiapan

Printed in China
PN: SP40Q51785

E-manual | E-manual |
Unpack | Isi Kemasan |
Standard items | Item standar | 
Optional accessories | Aksesori opsional |

ThinkPad Ethernet Extension Adapter
Gen 2＊
Lenovo HDMI to VGA Adapter＊
Lenovo USB-C to VGA Adapter＊
＊Available on some models |Tersedia pada beberapa model |


Initial setup | Persiapan awal |
Features | Fitur |
Infrared camera＊|Kamera inframerah＊|＊
Securely sign in to your computer with face
authentication.
Masuk dengan aman ke komputer Anda
menggunakan autentikasi wajah.


USB-C connectors | Konektor USB-C | USB-C
Both USB-C (ThunderboltTM 3 compatible)
connectors can work as power connectors.
The connectors support data-delivery with
faster rate, bi-directional power delivery, and
video output.
Kedua konektor USB-C (kompatibel dengan
ThunderboltTM 3) tersebut dapat berfungsi
sebagai konektor daya. Konektor mendukung
pengiriman data dengan laju lebih cepat,
penghantaran daya dua arah, dan output
video.
USB-C (ThunderboltTM 3)
 

 
＊Available on some models |Tersedia pada beberapa model |

Overview | Ikhtisar |
HDMI
5
6
7
8
9
14
13
1112
15
19
18
17 10
20
21
22
2
141
1
3
16

[English]
1. Microphones 2. Infrared camera＊
3. Conventional camera (available
on models with IR camera) 4. Conventional camera with
ThinkShutter＊
5. Power button 6. Fingerprint reader
7. Mini security-lock slot 8. Always On USB 3.1 connector
Gen 1
9. Fan louvers 10. Audio connector
11. Nano-SIM-card slot＊12. MicroSD card slot (a dummy
microSD card is preinstalled)
13. NFC mark＊14. TrackPad
15. TrackPoint®buttons 16. TrackPoint pointing stick
17. HDMI connector 18. USB 3.1 connector Gen 1
19. Docking-station connector 20. Ethernet extension connector
Gen 2
21. USB-C™ connector
(Thunderbolt™ 3 compatible) /
power connector
22. Screen
＊Available on some models
[Bahasa Indonesia]
1. Mikrofon 2. Kamera inframerah＊
3. Kamera konvensional (tersedia
pada model dengan kamera IR) 4. Kamera konvensional dengan
ThinkShutter＊
5. Tombol daya 6. Pembaca sidik jari
7. Slot kunci pengaman mini 8. Konektor Always On USB 3.1
Gen 1
9. Kisi-kisi kipas 10. Konektor audio
11. Slot kartu nano-SIM＊12. Slot kartu MicroSD (kartu
microSD dummy terpasang)
13. Tanda NFC＊14. TrackPad
15. Tombol TrackPoint®16. Stik penunjuk TrackPoint
17. Konektor HDMI 18. Konektor USB 3.1 Gen 1
19. Konektor stasiun dok 20. Konektor ekstensi Ethernet
Gen 2
21. Konektor USB-C™ (kompatibel
dengan Thunderbolt™ 3) /
konektor daya
22. Layar
＊Tersedia pada beberapa model

[]
1.  2. ＊
3.  ( IR) 4.  ThinkShutter＊
5. / 6. 
7.  8. Always On USB 3.1 Gen 1
9.  10. 
11.  Nano-SIM＊12.  MicroSD
( microSD
)
13.  NFC＊14. 
15.  TrackPoint®16. TrackPoint
17. HDMI 18. USB 3.1 Gen 1
19. 20.  Gen 2
21. USB-C™ (
Thunderbolt™ 3) / 
22. 
＊

Regulatory labels
Depending on your country or region, you can find the
government-required regulatory information through one
of the following methods:
On a physical label attached to the outside of your
computer shipping carton
On a physical label attached to your computer
Through an electronic-label screen (E-label screen)
preinstalled on your computer
To access the E-label screen, do one of the following:
Restart the computer. When the logo screen is
displayed, press F9. The E-label screen is displayed.
Restart the computer. When the logo screen is
displayed, press Enter or tap the prompt to enter the
Startup Interrupt menu. Then press F9 or tap the
Regulatory Information option. The E-label screen is
displayed.
Label pengaturan
Tergantung negara atau kawasan, Anda dapat
menemukan informasi pengaturan yang disyaratkan
pemerintah melalui salah satu metode berikut:
Pada label fisik yang ditempel pada bagian luar kardus
pengiriman komputer
Pada label fisik yang ditempel di komputer
Melalui layar label elektronik (layar E-label) yang
diprainstal pada komputer
Untuk mengakses layar E-label, lakukan salah satu
langkah berikut:
Aktifkan ulang komputer. Saat layar logo ditampilkan,
tekan F9. Layar E-label ditampilkan.
Aktifkan ulang komputer. Saat layar logo ditampilkan,
tekan Enter atau ketuk perintah untuk membuka menu
Startup Interrupt. Kemudian tekan F9 atau ketuk
pilihan Informasi Pengaturan. Layar E-label
ditampilkan.
 

 :





:

 F9 

 Enter Startup
Interrupt Menu  F9 
 
Compliance with the EU Radio Equipment
Directive
The following applies to models with a radio device.
Hereby, Lenovo (Singapore) Pte. Ltd., declares that the
radio equipment type ThinkPad X1 Carbon is in
compliance with Directive 2014/53/EU.
For further information about EU regulatory compliance,
refer to the Safety and Warranty Guide that comes with
your computer.
Specific Absorption Rate (ICNIRP)
YOUR DEVICE MEETS INTERNATIONAL GUIDELINES
FOR EXPOSURE TO RADIO WAVES.
Your device is a radio transmitter and receiver. It is
designed not to exceed the limits for exposure to radio
waves (radio frequency electromagnetic fields)
recommended by international guidelines. The guidelines
were developed by an independent scientific organization
(ICNIRP) and include a substantial safety margin
designed to assure the safety of all persons, regardless of
age and health.
The radio wave exposure guidelines use a unit of
measurement known as the Specific Absorption Rate, or
SAR. The Europe 10g SAR limit for mobile devices is
2.0 W/kg. Tests for SAR are conducted using standard
operating positions with the device transmitting at its
highest certified power level in all tested frequency bands.
The highest SAR values under the ICNIRP guidelines for
your device are as follows:
Maximum body-worn SAR with 0 mm separation
distance: 1.514 W/kg
During use, the actual SAR values for your device are
usually well below the values stated. This is because, for
purposes of system efficiency and to minimize
interference on the network, the operating power of your
mobile device is automatically decreased when full power
is not needed for the data connection. The lower the
power output of the device, the lower its SAR value.
If you are interested in further reducing your RF exposure
then you can easily do so by limiting your usage or simply
keeping the device away from the body.
Second Edition (January 2018)
© Copyright Lenovo 2018.
LIMITED AND RESTRICTED RIGHTS NOTICE: If data or software is delivered pursuant to a General Services
Administration “GSA” contract, use, reproduction, or disclosure is subject to restrictions set forth in Contract
No. GS-35F-05925.
