Lenovo ThinkPad X395 User manual

Printed in China
PN: SPXXXXXXXX
X395
Setup Guide

Unpack
*ThinkPad Ethernet
Extension Adapter
Gen 2
*Lenovo HDMI to VGA
Adapter
*Lenovo USB-C to
DisplayPort Adapter
*Lenovo USB-C to
VGA Adapter
*For selected models

Initial Setup

Overview
HDMIHDMI
5
6
7
8
9
11
15
16
17
12
10
13
14
3 34 2
31 3
2
19
18
20

* 1. Infrared camera
*2. ThinkShutter
*3. Microphones
*4. Camera
*5. Multi-touch screen
6. Power button
7. Security-lock slot
8. Always On USB 3.1 connector
Gen 1
9. TrackPoint pointing stick
*10. Fingerprint reader
*11. Smart card slot
12.Nano-SIM-card and microSD-card
slot
13.Trackpad
14. TrackPoint® buttons
15.Audio connector
16. HDMI™ connector
17. USB 3.1 connector Gen 2
18. Docking station connector
19.Ethernet extension connector Gen 2
20. USB-C™ connector (USB 3.1 Gen 2)
*For selected models
Read the statement on USB transfer rate in the User Guide. Refer to the Safety and
Warranty Guide for accessing the User Guide.

Customer Replacement Units (CRUs)
• ac power adapter
• Power cord
*• Base cover assembly
• M.2 solid-state drive
*• Wireless-WAN card
• Wireless-LAN card
• Pointing-stick nonslip cap
• Nano-SIM-card and microSD-card
tray
• Always On USB 3.1 connector Gen
1 board cable
Refer to the User Guide for CRU definition
* For selected models

Additional information
European Union — compliance with the
Radio Equipment Directive
Hereby, Lenovo (Singapore) Pte. Ltd., declares that
the radio equipment type ThinkPad X395 is in
compliance with Directive 2014/53/EU.
The full text of the system EU declaration of
conformity and the EU wireless module
declarations are available at the following Internet
addresses:
•For notebook computers:
https://www.lenovo.com/eu-doc-notebooks
•For tablets:
https://www.lenovo.com/eu-doc-tablets
This radio equipment operates with the following
frequency bands and maximum radio-frequency
power:
Technology
Frequency
band [MHz]
Maximum
transmit
power
WLAN
802.11b/g/n
2400 - 2483.5 < 20 dBm
WLAN
802.11a/n/ac
5150 - 5725 < 23 dBm
WLAN
802.11a/n/ac
5725 - 5875
< 13.98
dBm
WWAN
UMTS
1/8
< 24.5
dBm
WWAN LTE
1/3/7/8/20/28
< 24 dBm
Bluetooth
BR/EDR/LE
2400 - 2483.5 < 20 dBm
