Lenovo ThinkPad Yoga 14 User manual

Safety, Warranty, and Setup Guide
Brief user notices
ThinkPad Yoga 14
http://www.lenovo.com/support
Lenovo®electronic manuals... for a greener planet!
Refer to the electronic User Guide for detailed product information:
http://www.lenovo.com/UserManuals
Unpack
ThinkPad®
computer
Power cord ac power adapter Documentation
Initial setup
1. Connect to power. Ensure that all power cord connectors are securely and completely
plugged into receptacles.
2. Press the power button to turn on the computer. Then follow the on-screen instructions
to complete the initial setup.
Controls and indicators
Attention: Do not force the display open beyond 135 degrees from the relative position of
the keyboard. Forcing the display beyond this point can cause damage.
Microphones
Camera
Ambient light sensor
(for Windows®8.1 only)
Multi-touch screen
Windows Start screen control
Power button
TrackPoint®pointing stick
System-status indicator
Trackpad
Fn key with the Fn Lock
indicator
Function keys
Read the following descriptions to help you use the function keys.
: Volume controls
: Microphone mute
: Change display brightness
: Change display settings
: Manage wireless connections
: Open the Settings charm (Windows 8.1) or open Control Panel (Windows 7)
: View the programs that you have opened
: View all the programs (Windows 8.1) or open Computer (Windows 7)
Using the trackpad
The whole trackpad is an active area sensitive to finger movement. The left click zones
and right click zones work as the left and right mouse buttons on a conventional mouse.
The scroll zone enables you to scroll Web pages or documents in any direction, with the
use of the ThinkPad TrackPoint pointing stick.
You also can control your computer by using the following simple gestures.
Click Right click Scroll left or right
Scroll up or down Zoom in or out Rotate
*Some apps do not support rotation.
More information about the trackpad gestures is provided in the User Guide for your product.
See “Accessing your User Guide” for additional information.
A word about recovery solutions
Recovery discs are not provided. Instead, everything needed for recovering factory-installed
files and applications is provided in the Lenovo_Recovery partition on your hard disk drive.
You also can create recovery media as backups or replacement for the recovery partition.
For details, see “Recovery information” in the electronic User Guide.
Accessing your User Guide
Your User Guide contains detailed information about your computer. To access your User
Guide, do the following:
Microsoft®Windows®8.1 operating system:
1. Go to the Start screen.
2. Click the arrow icon in the bottom-left corner of the screen to go to the Apps screen. If you
are using a touch screen, swipe up to go to the Apps screen.
3. Click or tap Help and Support. The Windows Help and Support window opens.
4. Click or tap Lenovo User Guide.
Microsoft Windows 7 operating system:
1. From the Windows desktop, click Start and then click Help and Support. The Windows
Help and Support window opens.
2. Click Lenovo User Guide.
Lenovo makes constant improvements to the User Guide of your computer. To ensure that
you have the up-to-date information of your computer, see “Downloading publications” for
information about downloading the latest User Guide.
Downloading publications
The latest electronic versions of your computer publications are available from the Lenovo
Support Web site. To download the publications for your computer, go to:
http://www.lenovo.com/UserManuals
Downloading drivers
The latest drivers for your computer are available from the Lenovo Support Web site. To
download the latest drivers for your computer, go to http://www.lenovo.com/drivers.
Read this documentation
before using your computer
This documentation provides critical safety
and regulatory information for Lenovo
computers.
Safety information
Plastic bag notice
DANGER
Plastic bags can be dangerous. Keep
plastic bags away from babies and
children to avoid danger of
suffocation.
Polyvinyl Chloride (PVC) cable
and cord notice
WARNING:Handling the cord on this
product or cords associated with
accessories sold with this product will
expose you to lead, a chemical known
to the State of California to cause
cancer, and birth defects or other
reproductive harm. Wash hands after
handling.
General battery notice
DANGER
Batteries supplied by Lenovo for use
with your product have been tested for
compatibility and should only be
replaced with approved parts. A
battery other than the one specified by
Lenovo, or a disassembled or
modified battery is not covered by the
warranty.
Battery abuse or mishandling can
cause overheat, liquid leakage, or an
explosion. To avoid possible injury, do
the following:
•Do not open, dissemble, or service
any battery.
•Do not crush or puncture the battery.
•Do not short-circuit the battery, or
expose it to water or other liquids.
•Keep the battery away from children.
•Keep the battery away from fire.
Stop using the battery if it is damaged,
or if you notice any discharge or the
buildup of foreign materials on the
battery leads.
Store the rechargeable batteries or
products containing the rechargeable
batteries at room temperature,
charged to approximately 30 to 50% of
capacity. We recommend that the
batteries be charged about once per
year to prevent overdischarge.
Do not put the battery in trash that is
disposed of in landfills. When
disposing of the battery, comply with
local ordinances or regulations.
Notice for built-in rechargeable
battery
DANGER
Do not attempt to replace the built-in
rechargeable battery. Replacement of
the battery must be done by a
Lenovo-authorized repair facility or
technician.
Only recharge the battery strictly
according to instructions included in
the product documentation.
The Lenovo-authorized repair facilities
or technicians recycle Lenovo
batteries according to local laws and
regulations.
Notice for non-rechargeable
coin-cell battery
DANGER
If the coin-cell battery is incorrectly
replaced, there is danger of an
explosion. The battery contains a small
amount of harmful substance.
Do not heat to more than 100
°
C (212
°
F).
The following statement applies to
users in the state of California, U.S.A.
California Perchlorate Information:
Products containing manganese
dioxide lithium coin-cell batteries may
contain perchlorate.
Perchlorate Material - special handling
may apply, See
www.dtsc.ca.gov/hazardouswaste/perchlo
rate
Using headphones or
earphones
CAUTION:
Excessive sound pressure from
earphones and headphones can cause
hearing loss. Adjustment of the
equalizer to maximum increases the
earphone and headphone output
voltage and the sound pressure level.
Therefore, to protect your hearing,
adjust the equalizer to an appropriate
level.
Excessive use of headphones or
earphones for a long period of time at high
volume can be dangerous if the output of
the headphone or earphone connectors do
not comply with specifications of EN
50332-2. The headphone output
connector of your computer complies with
EN 50332-2 Sub clause 7. This
specification limits the computer’s
maximum wide band true RMS output
voltage to 150 mV. To help protect against
hearing loss, ensure that the headphones
or earphones you use also comply with EN
50332-2 (Clause 7 Limits) or a wide band
characteristic voltage of 75 mV. Using
headphones that do not comply with EN
50332-2 can be dangerous due to
excessive sound pressure levels.
If your Lenovo computer came with
headphones or earphones in the package,
as a set, the combination of the
headphones or earphones and the
computer already complies with the
specifications of EN 50332-1. If different
headphones or earphones are used,
ensure that they comply with EN 50332-1
(Clause 6.5 Limitation Values). Using
headphones that do not comply with EN
50332-1 can be dangerous due to
excessive sound pressure levels.
Regulatory information
Computer models equipped with wireless
communications comply with the radio
frequency and safety standards of any
country or region in which it has been
approved for wireless use.
Ensure that you read the Regulatory
Notice for your country or region before
using the wireless devices contained in
your computer. To obtain a PDF version of
the Regulatory Notice, see “Downloading
publications” in this document.
Brazil regulatory notice
Ouvir sons com mais de 85 decibeis por
longos periodos pode provocar danos ao
sistema auditivo.
Mexico regulatory notice
Advertencia: En Mexico la operación de
este equipo está sujeta a las siguientes
dos condiciones: (1) es posible que este
equipo o dispositivo no cause interferencia
perjudicial y (2) este equipo o dispositivo
debe aceptar cualquier interferencia,
incluyendo la que pueda causar su
operación no deseada.
Service, support, and
warranty information
The following information describes the
technical support that is available for your
product during the warranty period and
throughout the life of your product. Online
technical support is available during the
lifetime of a product
at http://www.lenovo.com/support.
If you purchased Lenovo services, refer to
the following terms and conditions for
detailed information:
•For Lenovo Warranty Service
Upgrades or Extensions, go to:
http://support.lenovo.com/lwsu
•For Lenovo Accidental Damage
Protection Services, go to:
http://support.lenovo.com/ladps
Warranty Information
Lenovo provides a warranty period for
your computer. To check the warranty
status of your computer, go
to http://www.lenovo.com/warranty-status,
and then follow the instructions on the
screen.
Your computer is covered by the terms of
the Lenovo Limited Warranty (LLW),
version L505-0010-02 08/2011. The LLW
is displayed on your computer during the
initial setup. After the initial setup has been
completed, you can view the warranty
information from your computer by doing
the following:
Windows 8.1:
1. Go to the Start screen.
2. Click the arrow icon in the bottom-left
corner of the screen to go to the Apps
screen. If you are using a touch screen,
swipe up to go to the Apps screen.
3. Click or tap Warranty Information.
Windows 7:
From the Windows desktop, click Start →
All Programs → Lenovo Device
Experience → Lenovo Warranty.
If you cannot view the LLW either from
your computer or from the Web site
(http://www.lenovo.com/warranty/llw_02),
contact your local Lenovo office or reseller
to obtain a printed version.
Customer Replaceable Units
Customer Replaceable Units (CRUs) are
parts that can be upgraded or replaced by
the customer. To view the instructions on
replacing the CRUs, see the respective
section in the User Guide.See “Accessing
your User Guide” for additional
information.
The following table lists the CRUs for your
computer.
The CRUs for your computer are listed as
the following:
Self-service CRUs
•ac power adapter and power cord
•Base cover assembly
•Button I/O card
•Coin-cell battery
•Hard disk drive, solid state drive, or
hybrid drive
•Memory module
•TrackPoint cap
•Wireless LAN card
Optional-service CRUs
•Audio/USB//OneLink/ac power card
•Keyboard
•Speakers
Worldwide telephone
technical support
This section lists Lenovo Support
telephone numbers. If you cannot find the
support telephone number for your country
or region, contact your Lenovo reseller or
Lenovo marketing representative.
Before contacting a Lenovo technical
support representative, have the following
information available: model and serial
number, the exact wording of any error
message, and a description of the
problem.
Important: Telephone numbers are
subject to change without notice. The
most up-to-date telephone list for the
Customer Support Center is always
available
at: http://www.lenovo.com/support/pho
ne
Country or
region
Telephone number
Africa South Africa: 0800110756
(English, Afrikaans)
Central Africa: Contact the
nearest Lenovo Business
Partner
Algeria
[phone] (French,
English)
Argentina
0800-666-0011 (Spanish)
Australia
1800 041 267 (English)
Austria
01-24592-5901 (German)
Bahrain
Kanoo IT: 00 973 1771 1722
Bahrain Business Machine
LLC: 00 973 1758 4302
Belgium [phone]
(Warranty service and
support) (Dutch, French)
Bolivia
0800-10-0189 (Spanish)
Brazil Calls made from within the
Sao Paulo region:
(11) 3889-8986
Calls made from outside the
Sao Paulo region:
0800-701-4815
(Brazilian Portuguese)
Brunei
Dial 800-1111, then dial
866-273-5446
PN: SP40F12296
Printed in China

Country or
region
Telephone number
(English and Bahasa
Melayu)
Canada
1-800-565-3344 (English,
French)
Caribbean
(Bermuda,
Jamaica,
Tortola)
1-800 426 7378 (English)
Chile
800-361-213 (Spanish)
China Technical Support Line
800-990-8888,
86-10-58851110 (Mandarin)
Colombia
1-800-912-3021 (Spanish)
Costa Rica
0-800-011-1029 (Spanish)
Croatia
0800-0426, [phone]
(calls out side of Croatia)
Cyprus
80092537 (Greek)
Czech
Republic
800-353-637
Denmark 4520-8200
7010-5150 (Warranty
service and support)
(Danish)
Dominican
Republic
1-866-434-2080 (Spanish)
Ecuador 1-800-426911 OPCION 4
(Spanish)
Egypt
800-0000-418 (Toll free)
002-02-2594-8500
(Standard charges apply)
(English, Arabic)
El Salvador
800-6264 (Spanish)
Estonia
[phone], +372
6776793
Finland 09-459-6960
358-800-1-4260 (Warranty
service and support)
(Finnish)
France
Hardware: 0810-631-213
(Warranty service and
support)
(French)
Germany 0800-5004618
(Gebührenfrei)
(Garantieservice und
Support)
Greece
Contact the nearest Lenovo
Business Partner (Greek)
Guatemala
1800-624-0051 (Spanish)
Honduras
Tegucigalpa: 232-4222
San Pedro Sula: 552-2234
(Spanish)
Hong Kong (852) 3071-3561
(Cantonese, English,
Mandarin)
Hungary
[phone]
[phone]
Country or
region
Telephone number
(English, Hungarian)
India
1800 3000 THINK (1800
3000 8465) (Reliance)
1800-419-4666 (Tata)
Email:
[email protected]m
(English and Hindi)
Indonesia 001-803-442-425
(English, Bahasa
Indonesia)
Ireland
01-881-1444 (Warranty
service and support)
(English)
Israel Givat Shmuel Service
Center:
[phone]
(Hebrew and English)
Italy
39-800-820094 (Warranty
service and support)
(Italian)
Jamaica
1-800 426 7378 (English)
Japan
0120-000-817 (Japanese,
English)
Jordan Jordan Business Systems:
00 962 6 5000999 (ext.
713/127)
General Computer &
Electronic (GCE):
00 962 6 551 3879 (English,
Arabic)
Kazakhsta
n
[phone] (Standard
Charges Apply)
(Russian, English)
Korea 080-513-0880 (Toll free)
(Korean)
Kuwait
Easa Hussain Al Yousifi: 00
965 2244 5280
AM. KHORAFI: 00 965 2200
1100 1127
Khorafi Business Machines
(KBM): 00 965 2259 4611
Diyar United Company: 00
965 4378 383
Redington Kuwait: 00 965
2433 3203, 25456250 /
25456251
Latvia
[phone]
Lebanon
Quantech: 00 961 1999 500
Computer Business Machine
(CBM): 00 961 1680 180
El Haceb S.A.L: 00 961
1771 300
Lithuania
[phone]
Libya
[phone] (French,
English)
Luxembour
g
[phone]
(French)
Macau
0800-807 /
Country or
region
Telephone number
(852) 3071-3559
(Cantonese, English,
Mandarin)
Macedonia
1800-88-0013 (English,
Bahasa Melayu)
Malaysia 1800-88-0013
(English, Bahasa Melayu)
Malta
[phone]
Mexico 001-866-434-2080
(Spanish)
Middle
East
[phone]
Morocco [phone]
[phone]
(Arabic)
Netherland
s
[phone] (Dutch)
New
Zealand
0508 770 506 (English)
Nicaragua
001-800-220-1830
(Spanish)
Norway 8152-1550 (Warranty
service and support)
(Norwegian)
Oman
Khimji Ramdas Computer
Communication Systems:
00 968 2469 6255
Overseas Business
Machines (OBM):
00 968 2460 1072, 2460
5018
Gulf Business Machines
Services (GBMS):
00 968 2455 9831
Pakistan International Office Products
(pvt) Ltd.:
00 92 212 422 569, 00 92
213 241 2023
Selling Business Systems:
00 92 21 568 9823
Panama
206-6047
001-866-434-2080 (Lenovo
Customer Support Center -
Toll free)
(Spanish)
Paraguay 009-800-52-10026
(Spanish)
Peru
0-800-50-866 OPCION 2
(Spanish)
Philippines 180089086454 (GLOBE
subscribers)
180014410719 (PLDT
sbuscribers)
(Tagalog, English)
Poland
[phone] (Polish)
Portugal [phone]
(Portuguese)
Qatar
Al Mana Computer Services:
Country or
region
Telephone number
00 974 4489 966 (ext. 1992)
Qatar Computer Services
W.L.L: 00 974 4441 212
Romania
[phone]
Russia 8-800-555-0317 (Toll free
number)
(Russian, English)
Saudi
Arabia
800 85 000 52 (Standard
Charges Apply)
(English, Arabic)
Singapore 1-800-818-5219 (English,
Mandarin, Bahasa Malaysia)
Slovakia
[phone]
Slovenia [phone]
(Slovenian)
Spain
[phone] (Spanish)
Sri Lanka [phone], +9411
2493548 (English)
Sweden
08-477-4420
077-117-1040 (Warranty
service and support)
(Swedish)
Switzerland
0800-55-54-54 (Warranty
service and support)
(German, French, Italian)
Taiwan
0800-000-702 (Mandarin)
Thailand 001 800 4415 734
(Thai, English)
Turkey
0212 336 03 66
00800 448 825 165 (Turkce)
(Turkish)
Ukraine 044 362 42 81 (Standard
Charges Apply)
(Ukrainian, Russian,
English)
United
Arab
Emirates
800 035702810 (Standard
Charges Apply)
(English, Arabic)
United
Kingdom
08705-500-900 (Standard
warranty support)
(English)
United
States
1-800-426-7378
(English)
Uruguay 000-411-005-6649
(Spanish)
Venezuela
0-800-100-2011 (Spanish)
Vietnam 120-11072 (Toll Free)
+(84) 8 3521 8000
(Standard Charges Apply)
(Vietnamese, English)
Yemen
Al Khirbash and Agencies:
00 967 1209 8278
Yemen Business Machines
(YBM):
00-967 3 213324
00-967 3 214655
00-967 3 213909
Lenovo product service
information for Taiwan
Electronic emission
notices
This device has been tested and found to
comply with the limits for a Class B digital
device. The User Guide for this product
provides the complete Class B compliance
statements that are applicable for this
device. See “Accessing your User Guide”
for additional information.
Korean Class B compliance
statement
European Union conformity
EU contact: Lenovo, Einsteinova 21, 851
01 Bratislava, Slovakia
Radio and
Telecommunications
Terminal Equipment Directive
This product is in compliance with the
essential requirements and other relevant
provisions of the Radio and
Telecommunications Terminal Equipment
Directive, 1999/5/EC. The Declaration of
Conformity information is located in the
Regulatory Notice, which you can
download from the Lenovo Support Web
site. See “Downloading publications” for
additional information.
Recycling and
environmental information
Lenovo encourages owners of information
technology (IT) equipment to responsibly
recycle their equipment when it is no
longer needed. Lenovo offers a variety of
programs and services to assist
equipment owners in recycling their IT
products. For information on recycling
Lenovo products, go to:
http://www.lenovo.com/recycling
Important WEEE information
Electrical and electronic
equipment marked with the
symbol of a crossed-out
wheeled bin may not be
disposed as unsorted
municipal waste. Waste of
electrical and electronic
equipment (WEEE) shall be
treated separately using the
collection framework
available to customers for the
return, recycling, and
treatment of WEEE.
Country-specific information
is available at:
http://www.lenovo.com/recycl
ing
Recycling information for
Japan
Recycling information for
China
Additional recycling
statements
Additional information about recycling
computer components and batteries is in
your User Guide. See “Accessing your
User Guide” for details.
Restriction of Hazardous
Substances Directive (RoHS)
European Union RoHS
Lenovo products sold in the European
Union, on or after 3 January 2013 meet
the requirements of Directive 2011/65/EU
on the restriction of the use of certain
hazardous substances in electrical and
electronic equipment (“RoHS recast” or
“RoHS 2”).
For more information about Lenovo
progress on RoHS, go to:
http://www.lenovo.com/social_responsibilit
y/us/en/RoHS_Communication.pdf
China RoHS
The information in the following table is
applicable for products manufactured on
or after March 1, 2007 for sale in the
People’s Republic of China.
Turkish RoHS
The Lenovo product meets the
requirements of the Republic of Turkey
Directive on the Restriction of the Use of
Certain Hazardous Substances in
Electrical and Electronic Equipment
(EEE).
Ukraine RoHS
India RoHS
RoHS compliant as per E-Waste
(Management & Handling) Rules, 2011.
Eurasian compliance mark
California BC mark
ENERGY STAR
Select models conform to
ENERGY STAR®
requirements. Additional
ENERGY STAR information is
in your User Guide. See
“Accessing your User Guide”.
First Edition (October 2014)
© Copyright Lenovo 2014.
LIMITED AND RESTRICTED RIGHTS NOTICE: If data or software is delivered pursuant a General Services Administration “GSA” contract, use, reproduction, or disclosure is subject to restrictions set forth in Contract No. GS-35F-05925.
Lenovo, For Those Who Do., the Lenovo logo, ThinkPad, and TrackPoint are trademarks of Lenovo in the United States, other countries, or both. Microsoft and Windows are trademarks of the Microsoft group of companies.
Other company, product, or service names may be trademarks or service marks of others.
