Lenovo Qreator 27 User manual

Lenovo
Qreator 27
User Guide

Product numbers
A20270DL0
66B7-RCC1-WW
66B7-RBC1-WW
66B7-RAC1-WW
First Edition (July 2020)
© Copyright Lenovo 2020.
LENOVO products, data, computer software, and services have been developed exclusively at private expense
and are sold to governmental entities as commercial items as dened by 48 C.F.R. 2.101 with limited and
restricted rights to use, reproduction and disclosure.
LIMITED AND RESTRICTED RIGHTS NOTICE: If products, data, computer software, or services are
delivered pursuant a General Services Administration "GSA" contract, use, reproduction, or disclosure is subject
to restrictions set forth in Contract No. GS-35F-05925.
i

Contents
Safety information.......................................................................................... iv
General Safety guidelines..............................................................................................iv
Chapter 1.Getting started ............................................................................1-1
Shipping contents ........................................................................................................1-1
Notice for use................................................................................................................1-2
Product overview..........................................................................................................1-2
Setting up your monitor ...............................................................................................1-4
Chapter 2.Adjusting and using your monitor ............................................2-1
Comfort and accessibility ............................................................................................2-1
Arranging your work area ............................................................................................2-1
Positioning and viewing your monitor .......................................................................2-1
Quick tips for healthy work habits ..............................................................................2-2
Adjusting your monitor image.....................................................................................2-3
Selecting a supported display mode ........................................................................2-17
Understanding power management..........................................................................2-18
Caring for your monitor .............................................................................................2-19
Detaching the monitor base and stand ....................................................................2-19
Wall Mounting (Optional) ...........................................................................................2-19
Chapter 3.Reference information................................................................3-1
Monitor specications..................................................................................................3-1
Troubleshooting............................................................................................................3-3
Manually installing the monitor driver........................................................................3-5
Appendix A. Service and Support.............................................................. A-1
ii

Registering your option .............................................................................................. A-1
Online technical support............................................................................................. A-1
Telephone technical support ..................................................................................... A-1
Appendix B.Notices..................................................................................... B-1
Recycling information ................................................................................................. B-2
Trademarks................................................................................................................... B-3
Power cords and power adapters .............................................................................. B-3
iii

Safety information
General Safety guidelines
For tips to help you use your computer safely, go to:
http://www.lenovo.com/safety
Before installing this product, read the Safety Information.
DANGER
To avoid shock hazard:
• Do not remove the covers.
• Do not operate this product unless the stand is attached.
• Do not connect or disconnect this product during an electrical storm.
• The power cord plug must be connected to a properly wired and grounded power outlet.
• Any equipment to which this product will be attached must also be connected to properly
wired and grounded power outlets.
• To isolate the monitor from the electrical supply, you must remove the plug from the
power outlet. The power outlet should be easily accessible.
To take special precautions to avoid the introduction of hazards when operating, installing,
servicing, transporting or storing equipment, the necessary instructions shall be made
available.
To reduce the risk of electric shock, do not perform any servicing other than that contained
in the operating instructions unless you are qualied to do so.
Handling:
• If your monitor weighs more than 18 kg (39.68 lb), it is recommended that it be moved or
lifted by two people.
iv

Chapter 1.Getting started
This User’s Guide provides detailed operation instructions for the user. For quick instruction
overview, please see the Setup Poster for brief information.
Shipping contents
The product package should include the following items:
■Information Flyer
■Lenovo Limited Warranty Booklet
■Stand
■Base
■Flat Panel Monitor
■Power Cord
■Adapter
■USB Type C Cable
■HDMI Cable
■DisplayPort Cable
■Screw x 2pcs
■Screwdriver
Lenovo
Limited Warranty
HDMI
1-1 Qreator 27 Flat Panel Monitor User’s Guide

Notice for use
To set up your monitor, please see the illustrations below.
Note: Do not touch the monitor within the screen area. The screen area is glass and can be
damaged by rough handling or excessive pressure.
1
2
1. Place your monitor with the screen face down on a soft at surface.
2. Insert the base towards the stand until it locks in place.
3. Align the stand assembly bracket to the monitor.
Note: To install a VESA mount, please see "Wall Mounting (Optional)" on page 2-19.
Product overview
This section will provide information on adjusting monitor positions, setting user controls,
and using the cable lock slot.
Types of adjustments
Tilt
Please see the illustration below for an example of the tilt range.
22°
-5°
0°
Chapter 1.Getting started 1-2

Monitor controls
The keypad controls on the panel frame are accesses to various functions.
For information on how to utilize these keypad controls, please see “Adjusting your monitor
image” on page 2-3.
Cable lock slot
Your monitor is equipped with a cable lock slot located on the rear of your monitor
1-3 Qreator 27 Flat Panel Monitor User’s Guide

Setting up your monitor
This section provides information on how to set up your monitor.
Connecting and turning on your monitor
Note: Be sure to read the Safety information on page iv before carrying out this
procedure.
1. Power off your computer and all attached devices, and unplug the computer power cord.
2. Connect the cables according to below icon indication.
HDMI1 HDMI2 10
Chapter 1.Getting started 1-4

3. For computer in DP connecting.
4. For computer in HDMI connecting.
Note: For other regions Lenovo recommends that customers who require to use the
HDMI input on their monitor purchase the "Lenovo HDMI to HDMI cable OB47070"
http://www.lenovo.com/support/monitoraccessories
HDMI
HDMI
1-5 Qreator 27 Flat Panel Monitor User’s Guide
