Lenovo RackSwitch G8296
ONIE Quick Start Guide
for Lenovo Network Operating System

Note: Before using this information and the product it supports, read the general information in the
Safety information and Environmental Notices and User Guide documents on the Lenovo Documentation CD,
and the Warranty Information document that comes with the product.
Second Edition (February 2017)
© Copyright Lenovo 2017
LIMITED AND RESTRICTED RIGHTS NOTICE: If data or software is delivered pursuant a General
Services Administration “GSA” contract, use, reproduction, or disclosure is subject to restrictions set
forth in Contract No. GS-35F-05925.
Lenovo and the Lenovo logo are trademarks of Lenovo in the United States, other countries, or both.

© Copyright Lenovo 2017 Contents 3
Contents
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Connecting to the G8296 . . . . . . . . . . . . . . . . . . . . . 6
Switch Unit. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Mini-USB Serial Console Port . . . . . . . . . . . . . . . . . . . . . 7
Geographic Layout of the Temperature Sensors . . . . . . . . . . . . . 8
ONIE on the G8296 . . . . . . . . . . . . . . . . . . . . . . . 11
Installing the ONIE FoD License Key . . . . . . . . . . . . . . . . . . 12
Obtaining the ONIE License Key . . . . . . . . . . . . . . . . . . 12
Installing the ONIE License Key on CNOS . . . . . . . . . . . . . . 13
Uninstalling the ONIE License Key on CNOS . . . . . . . . . . . 13
Installing ONIE. . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Installing ONIE on CNOS . . . . . . . . . . . . . . . . . . . . . 14
Booting in ONIE Mode . . . . . . . . . . . . . . . . . . . . . . . . 16
Booting in ONIE Install Mode. . . . . . . . . . . . . . . . . . . . 16
Booting in ONIE Uninstall Mode . . . . . . . . . . . . . . . . . . 17
Booting in ONIE Update Mode . . . . . . . . . . . . . . . . . . . 18
Booting in ONIE Rescue Mode . . . . . . . . . . . . . . . . . . . 18
The Boot Management Menu . . . . . . . . . . . . . . . . . . . . . . 19
Uninstalling the Lenovo Network OS . . . . . . . . . . . . . . . . . . 20
Using ONIE without Lenovo Network OS . . . . . . . . . . . . . . . . 21

4 Lenovo ONIE Quick Start Guide for G8296

© Copyright Lenovo 2017 5
Overview
The Open Network Install Environment (ONIE) is a small Linux-based operating
system that provides an open install environment for network switches without
operating systems.
ONIE enables a network switch ecosystem where end-users can choose among
different Network Operating Systems (NOS). Practically, ONIE boots on a switch,
discovers NOS installer images available on the local network or USB drive, copies
the chosen image to the switch, and provides an environment where the installer
can load the NOS onto the switch.
ONIE is classified as free software, meaning it can be redistributed and/or modified
under the terms of version 2 of the GNU General Public License as published by the
Free Software Foundation. To read the license, visit the following link:
https://github.com/opencomputeproject/onie/blob/master/COPYING
For more details about ONIE, go to onie.org .
Lenovo ONIE Image
To download the Lenovo ONIE image, visit the following website:
http://support.lenovo.com/
The ONIE images for the G8296 have the [ONIE] tag in their name, as follows:
for Lenovo Cloud Network OS:
Lenovo Rackswitch G8296 [ONIE] 10.x.x.0

6 Lenovo ONIE Quick Start Guide for G8296
Connecting to the G8296
This section describes how to connect to the Lenovo RackSwitch G8296. For more
details about the switch and on how to install the switch hardware, consult the
Lenovo RackSwitch G8296 Installation Guide .
Switch Unit
The G8296 is a 2U GbE switch and it can be rack-mounted in a horizontal position.
The following illustrations show the features on the front and rear panels of the
switch:
Figure 1. G8296 front panel
Figure 2. G8296 management panel detail
Figure 3. G8296 rear panel
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
80
81
82
83
84
85
86
93 95
94 96
87
88
89 91
90 92
SFP+ Ports QSPF+ Ports
Management Panel
SFP+ Ports QSPF+ Ports
Reset Button
Mini-USB
Serial Console Port
USB Port
RJ-45
Management Port
Status LEDs
Fan Modules Power Supply Modules

© Copyright Lenovo 2017 Connecting to the G8296 7
Mini-USB Serial Console Port
The mini-USB port on the front management panel is available for switch console
management. The port operates using RS-232 serial communications. A compatible
console cable kit is included with the switch.
To connect a computer or terminal to the switch using the included kit, first connect
the console cable to the mini-USB port on the front panel. Connect one end of the
Category 5 patch cable to the RJ-45 port on the console cable and the other end of
the patch cable to the RJ-45-to-DB9 adapter (see the following illustration).
Figure 4. Console cable connections
The computer or terminal must run a terminal emulator (for example, SecureCRT,
HyperTerminal, or PuTTY). The console port terminal emulation requirements are
as follows:
• Default baud rate: 9,600 bps
• Character size: 8 characters
• Parity: none
• Stop bits: 1
• Data bits: 8
• Flow control: none
To PC
Terminal
To
Switch
RJ-45 Adapter
Category 5
Patch Cable
Switch
Console Cable

8 Lenovo ONIE Quick Start Guide for G8296
Geographic Layout of the Temperature Sensors
The following illustrations show the location of the temperature sensors (pointed
out with red arrows) on the main and CPU boards.
Figure 5. G8296 CPU Board Temperature Sensors
Ambient U8, I2C @ 1001.101x on CH0 of PCA9546, P4040 I2C Bus 3

© Copyright Lenovo 2017 Connecting to the G8296 9
Figure 6. G8296 Main Board Temperature Sensors
Front of the card U5, I2C @ 1001.001x on CH0 of PCA9548, P4040 I2C Bus 1
Close to switch ASIC U16, I2C @ 1001.010x on CH0 of PCA9548, P4040 I2C Bus 1
Rear of the card U38, I2C @ 1001.000x on CH0 of PCA9546, P4040 I2C Bus 2

10 Lenovo ONIE Quick Start Guide for G8296
Figure 7. G8296 Daughter Card Temperature Sensors
Front of the card U10, I2C @ 1001.100x on CH1 of PCA9548, P4040 I2C Bus 1
Rear of the card U17, I2C @ 1001.101x on CH1 of PCA9548, P4040 I2C Bus 1
