Lenovo ThinkSystem DB610S 32Gb FC SAN Switch
Product Guide
The Lenovo ThinkSystem DB610S FC SAN Switch provides exceptional price/performance value by
delivering market-leading 32 Gb Gen 6 Fibre Channel technology and combining flexibility, simplicity, and
enterprise-class functionality to meet the demands of growing flash-based storage environments.
Designed to enable maximum flexibility and reliability, the ThinkSystem DB610S is a compact, 1U rack-
mount FC switch that offers low-cost access to industry-leading Storage Area Network (SAN) technology
while providing “pay-as-you-grow” scalability to meet the needs of an evolving storage environment.
The DB610S FC SAN Switch offers 24x SFP+ ports that support 4/8/16/32 Gbps speeds. The DB610S FC
SAN switch provides easy integration into the existing SAN environments while realizing the benefits of
Gen 6 Fibre Channel connectivity, and the switch offers a rich set of standard software features with the
options to expand its capabilities as needed.
The DB610S FC SAN Switch features the EZSwitch Setup wizard and can be configured in Access
Gateway Mode to simplify deployment. The switch provides full non-blocking performance with Ports On
Demand scalability to support SAN expansion and enable long-term investment protection.
The following figure shows the Lenovo ThinkSystem DB610S 32Gb FC SAN Switch.
Figure 1. Lenovo ThinkSystem DB610S 32Gb FC SAN Switch
Did you know?
The DB610S FC SAN Switch leverages storage connectivity technologies from Brocade, a leader in Fibre
Channel networking.
The DB610S FC SAN Switch offers dual functionality as either a full-fabric SAN switch or as an N_Port ID
Virtualization (NPIV)-enabled Access Gateway that simplifies server connectivity.
Fabric Vision technology, an extension of Gen 6 Fibre Channel, provides unprecedented insight and
visibility across the SAN with powerful built-in monitoring, management, and diagnostic tools.
With Lenovo FC SAN Switch offerings, Lenovo can be your trusted partner that offers "one stop shop" and
single point of contact for delivery of leading edge technologies and innovations from Lenovo and other
leading IT vendors. These offerings can satisfy the wide range of your end-to-end IT infrastructure needs,
including end-user devices, servers, storage, networking, services, management software, and financing.
Lenovo ThinkSystem DB610S 32Gb FC SAN Switch 1

Key features
The ThinkSystem DB610S FC SAN Switch offers the following features and benefits:
Provides an affordable enterprise-class 32 Gb FC solution with 24 SFP+ ports to support flash-
based storage environments.
Increases performance for demanding workloads with support for 32 Gbps FC links.
Simplifies configuration and management with easy-to-use EZSwitch Setup.
Enables “pay-as-you-grow” scalability from single-switch fabric to full-fabric enterprise capabilities
with Ports On Demand scalability.
Optimizes fabric behavior and ensure sufficient bandwidth for mission-critical applications with
advanced traffic management capabilities and adaptive networking.
Provides proactive, non-intrusive, real-time monitoring and alerting of VM health and performance
with VM Insight through integrated network sensors.
Offers dual functionality as either a full-fabric SAN switch or as an NPIV-enabled Access Gateway
(requires 24 SFP+ ports be licensed) that enhances fabric scalability and simplifies management.
Protects existing device investments with auto-sensing 4, 8, 16, and 32 Gbit/sec capabilities and
native operation with Brocade fabrics.
Runs Fabric OS, which delivers distributed intelligence throughout the network and enables a wide
range of value-added features.
Leverages Fabric Vision technology’s powerful monitoring, management, and diagnostic tools to
simplify administration, increase uptime, and reduce costs.
Supplies a rich set of standard features at no extra cost, including fabric services, advanced zoning,
adaptive networking, full fabric and access gateway operations, and diagnostic tools.
Expands fabric capabilities with optional licensed functions, including trunking, advanced
monitoring and alerting, and long-distance fabrics.
Allow organizations to seamlessly integrate Gen 6 Fibre Channel networks with the next generation
of flash storage – NVMe over Fibre Channel – by being NVMe-ready, without a disruptive rip and
replace, to achieve faster application response times and harness the performance of solid state
drives for better scalability across virtual data centers with flash storage.
Accelerates troubleshooting with built-in advanced diagnostics tools featuring ClearLink
Diagnostics with D_Ports and select adapters from QLogic and Emulex, which helps ensure optical
and signal integrity for 16 Gb and 32 Gb Fibre Channel optics and cables.
Components and connectors
The following figure shows the port-side view of the DB610S FC SAN Switch.
Figure 2. DB610S FC SAN Switch port-side view
Lenovo ThinkSystem DB610S 32Gb FC SAN Switch 2

The following figure shows the non-port side view of the DB610S FC SAN Switch.
Figure 3. DB610S FC SAN Switch non-port-side view
System specifications
The following table lists the ThinkSystem DB610S system specifications.
Table 1. System specifications
Component Specification
Form factor Standalone or 1U rack mount (Machine Type 6559)
Ports 24x SFP+ ports:
Model HC1: 24 ports activated and 24x 16 Gb FC SWL SFP+ transceivers included.
Model HC2: 8 ports activated and 8x 16 Gb FC SWL SFP+ transceivers included.
Model HC3: 8 ports activated and no transceivers included.
Up to two optional 8-port activation license packs or bundles (8-port license pack and 8x 16
Gb FC SWL SFP+ transceivers) for Models HC2 and HC3.
Media types 32 Gb FC SFP+ transceivers: short wavelength (SWL), long wavelength (LWL).
16 Gb FC SFP+ transceivers: SWL, LWL, extended long wavelength (ELWL).
Port speeds 32 Gb FC SFP+ transceivers: 32/16/8 Gbps auto-sensing.
16 Gb FC SFP+ transceivers: 16/8/4 Gbps auto-sensing.
FC port types Full Fabric mode: F_Port, M_Port (Mirror Port), E_Port, D_Port (Diagnostic Port).
Access Gateway mode: F_Port and NPIV-enabled N_Port.
Data traffic types Unicast (Class 2 and Class 3), multicast (Class 3 only), broadcast (Class 3 only).
Classes of service Class 2, Class 3, Class F (inter-switch frames).
Standard
software
Full Fabric mode, Access Gateway, Advanced Zoning, Fabric Services, Adaptive Networking,
Advanced Diagnostic Tools.
Optional software Enterprise Bundle (ISL Trunking, Fabric Vision, Extended Fabric).
Performance Non-blocking architecture with wire-speed forwarding of traffic:
4GFC: 4.25 Gbit/sec line speed, full duplex
8GFC: 8.5 Gbit/sec line speed, full duplex
10GFC: 10.51875 Gbit/sec line speed, full duplex
16GFC: 14.025 Gbit/sec line speed, full duplex
32GFC: 28.05 Gbit/sec line speed, full duplex
Aggregated throughput: 768 Gbps
Up to 0.9 µs local switching latency
Scalability Maximum number of switches in the fabric: 239
Maximum frame size: 2,112-byte payload
Maximum number of frame buffers per switch: 2,000
Maximum number of ports per ISL trunk: 8x SFP+ (ISL Trunking license is included in
the Enterprise Bundle)
Cooling Four fixed fans with N+1 cooling redundancy. Non-port to port side airflow.
Power supply One fixed 150 W AC (100 - 240 V) power supply (IEC 320-C14 connector).
Hot-swap parts SFP+ transceivers.
Lenovo ThinkSystem DB610S 32Gb FC SAN Switch 3

Management
ports
One 10/100/1000 Mb Ethernet port (UTP, RJ-45); one RS-232 port (RJ-45); one USB port (for
additional firmware/log/configuration files storage).
Management
interfaces
EZSwitch Setup; Web-based GUI (Web Tools); Command Line Interface (CLI); SMI-S; SNMP;
REST API. Optional Brocade Network Advisor.
Security features Secure Socket Layer (SSL); Secure Shell (SSH); Secure Copy (SCP); Secure FTP (SFTP); user
level security, Role-based Access Control (RBAC); LDAP, RADIUS, and TACACS+
authentication; access control lists (ACLs); IP security (IPsec)
Hardware
warranty
One-year customer-replaceable unit limited warranty with 9x5 next business day parts
delivered. Optional warranty service upgrades are available through Lenovo: on-site coverage
(technician installed parts), 24x7 coverage, 2-hour or 4-hour response time, 6-hour or 24-hour
committed repair, up to 5 years of warranty coverage, 1-year or 2-year warranty extensions,
Remote Technical Support, hardware installation services.
Software
maintenance
Three-year software support and subscription license is included. Optional 1-year and 2-
year software support extension licenses are available through Lenovo.
Dimensions Height: 43 mm (1.7 in.); width: 429 mm (16.9 in.); depth: 307 mm (12.1 in.)
Weight Empty: 4.2 kg (9.3 lb); Fully configured: 5.8 kg (12.7 lb).
Component Specification
Models
The following table lists the ThinkSystem DB610S FC SAN Switch models.
Table 2. Lenovo ThinkSystem DB610S FC SAN Switch models
Description
Part
number
Machine
Type-Model
Feature
code
Lenovo ThinkSystem DB610S, 24 ports activated, 24x 16Gb SWL SFPs,
1 PS, Rail Kit, Enterprise SW
6559D1Y 6559-HC1 AVPQ
Lenovo ThinkSystem DB610S, 8 ports activated, 8x 16Gb SWL SFPs,
1 PS, Rail Kit
6559D2Y 6559-HC2 AVPR
Lenovo ThinkSystem DB610S, 8 ports activated, 1 PS, Rail Kit 6559D3Y 6559-HC3 AVPS
The DB610S FC SAN Switch part numbers include the following items:
One FC SAN Switch
Model HC1: With 24 ports activated and 24x 16 Gb FC SWL SFP+ transceivers included
Model HC2: With 8 ports activated and 8x 16 Gb FC SWL SFP+ transceivers included
Model HC3: With 8 ports activated and no transceivers included
Serial cable (DB-9/RJ-45 to RJ-45)
Fixed rack mount kit
EZSwitch Setup web pointer card
Online Documentation web pointer card
Network Advisor web pointer card
Note: The switch comes standard without a power cord; one power cable must be purchased together
with the switch (see Power supplies and cables for details).
Port activation licenses
Lenovo ThinkSystem DB610S 32Gb FC SAN Switch 4

Port activation licenses
The DB610S FC SAN Switch model HC1 comes standard with 24 licensed ports and with 24x 16 Gb FC
SWL SFP+ Transceivers. The DB610S FC SAN Switch model HC2 comes standard with 8 licensed ports
and with 8x 16 Gb FC SWL SFP+ Transceivers. The DB610S FC SAN Switch model HC3 comes standard
with 8 licensed ports and without any transceivers.
The remaining 16 SFP+ unlicensed ports on the Models HC2 and HC3 can be activated by purchasing
and installing the Ports on Demand (POD) software licenses that are available with or without
SFP+ transceivers in 8-port increments.
The following table lists additional POD options for the DB610S FC SAN Switch.
Table 3. POD options for Models HC2 and HC3
Description
Part
number
Feature
code
Maximum
quantity
supported
Lenovo DB610S 8-Port SW POD License (no transceivers) 01KP845 AX4C 2
Lenovo DB610S 8-Port SW POD License (with 8x 16 Gbps SWL SFP+
transceivers)
01KP846 AVUK 2
Transceivers and cables
With the flexibility of the DB610S FC SAN Switch, customers can choose the following connectivity:
For 32 Gb FC links, customers can use 32 Gb FC SFP+ SWL optical transceivers for distances up to
100 meters on 50 µ OM4 multimode fiber optic cables. For longer distances, the 32 Gb FC LWL
SFP+ optical transceivers can support up to 10 kilometers on single-mode fiber optic cables.
These transceivers can operate at 32 Gbps, 16 Gbps, or 8 Gbps speeds.
For 16 Gb FC links, customers can use 16 Gb FC SFP+ SWL optical transceivers for distances up to
125 meters on 50 µ OM4 multimode fiber optic cables. For longer distances, the 16 Gb FC LWL
SFP+ optical transceivers can support up to 10 kilometers on single-mode fiber optic cables. For
extended distances, the 16 Gb FC ELWL SFP+ optical transceivers can support up to 25 kilometers
on single-mode fiber optic cables. These transceivers can operate at 16 Gbps, 8 Gbps, or 4 Gbps
speeds.
For the 1 GbE RJ-45 management port, customers can use UTP cables for distances up to 100
meters.
The DB610S FC SAN Switch comes with 24x (Model HC1) or 8x (Model HC2) 16 Gb FC SWL SFP+
transceivers or without any transceivers (Model HC3). Additional SWL, LWL, and ELWL SFP+ transceivers
can be ordered for the switch, if needed.
The following table lists the supported SFP+ options and cables.
Table 4. SFP+ transceivers and cables
Description
Part
number
Feature
code
Maximum
quantity
supported
32 Gb FC SFP+ transceivers
Brocade 32Gb SWL SFP+ Transceiver 01KN789 AVGC 24
Brocade 32Gb SWL SFP+ Transceiver (8-pack) 01KN793 AVGD 3
Brocade 32Gb LWL SFP+ Transceiver 01KN795 AVGE 24
Brocade 32Gb LWL SFP+ Transceiver (8-pack) 01KN799 AVGF 3
Lenovo ThinkSystem DB610S 32Gb FC SAN Switch 5

16 Gb FC SFP+ transceivers
Brocade 16Gb SWL SFP+ Optical Transceiver 88Y6393 A22R 24
Brocade 16Gb 10km LWL SFP+ Transceiver 00MY768 ASK2 24
Brocade 16Gb 25km ELWL SFP+ Transceiver 00MY770 ASK3 24*
OM3 optical cables for 16 Gb and 32 Gb FC SW SFP+ transceivers
Lenovo 0.5m LC-LC OM3 MMF Cable 00MN499 ASR5 24
Lenovo 1m LC-LC OM3 MMF Cable 00MN502 ASR6 24
Lenovo 3m LC-LC OM3 MMF Cable 00MN505 ASR7 24
Lenovo 5m LC-LC OM3 MMF Cable 00MN508 ASR8 24
Lenovo 10m LC-LC OM3 MMF Cable 00MN511 ASR9 24
Lenovo 15m LC-LC OM3 MMF Cable 00MN514 ASRA 24
Lenovo 25m LC-LC OM3 MMF Cable 00MN517 ASRB 24
Lenovo 30m LC-LC OM3 MMF Cable 00MN520 ASRC 24
OM4 optical cables for 16 Gb and 32 Gb FC SW SFP+ transceivers
Lenovo 0.5m LC-LC OM4 MMF Cable 4Z57A10845 B2P9 24
Lenovo 1m LC-LC OM4 MMF Cable 4Z57A10846 B2PA 24
Lenovo 3m LC-LC OM4 MMF Cable 4Z57A10847 B2PB 24
Lenovo 5m LC-LC OM4 MMF Cable 4Z57A10848 B2PC 24
Lenovo 10m LC-LC OM4 MMF Cable 4Z57A10849 B2PD 24
Lenovo 15m LC-LC OM4 MMF Cable 4Z57A10850 B2PE 24
Lenovo 25m LC-LC OM4 MMF Cable 4Z57A10851 B2PF 24
Lenovo 30m LC-LC OM4 MMF Cable 4Z57A10852 B2PG 24
UTP Category 6 cables (Green) for the 1 GbE RJ-45 management port
0.75m CAT6 Green Cable 00WE123 AVFW 1
1.0m CAT6 Green Cable 00WE127 AVFX 1
1.25m CAT6 Green Cable 00WE131 AVFY 1
1.5m CAT6 Green Cable 00WE135 AVFZ 1
3m CAT6 Green Cable 00WE139 AVG0 1
10m CAT6 Green Cable 90Y3718 A1MT 1
25m CAT6 Green Cable 90Y3727 A1MW 1
UTP Category 5e cables (Blue) for the 1 GbE RJ-45 management port
0.6m Blue Cat5e Cable 40K5679 3801 1
1.5m Blue Cat5e Cable 40K8785 3802 1
3m Blue Cat5e Cable 40K5581 3803 1
10m Blue Cat5e Cable 40K8927 3804 1
25m Blue Cat5e Cable 40K8930 3805 1
Description
Part
number
Feature
code
Maximum
quantity
supported
* When using ELW SFP+ transceivers over distances over 10 km, the Extended Fabric feature that is available in the Enterprise
Bundle is required on a SAN switch to drive the maximum bandwidth over the extended links.
Lenovo ThinkSystem DB610S 32Gb FC SAN Switch 6

The following table lists the cabling requirements for the switch.
Table 5. DB610S FC SAN Switch cabling requirements
Transceiver Standard Cable Connector
32 Gb Fibre Channel
32 Gb FC SWL SFP+
(01KN789, 01KN793)
FC-PI-6 Up to 30 m with fiber optic cables supplied by Lenovo (see
Table 4).
850 nm 50 µ multi-mode fiber optic cable:
32GFC: Up to 100 m (OM4) or up to 70 m (OM3)
16GFC: Up to 125 m (OM4) or up to 100 m (OM3)
8GFC: Up to 190 m (OM4) or up to 150 m (OM3)
LC
32 Gb FC LWL SFP+
(01KN795, 01KN799)
FC-PI-6 1310 nm 9 µ single-mode fiber optic cable:
32GFC, 16GFC, 8GFC: Up to 10 km
LC
16 Gb Fibre Channel
16 Gb FC SWL SFP+
(88Y6393)
FC-PI-5 Up to 30 m with fiber optic cables supplied by Lenovo (see
Table 4).
850 nm 50 µ multi-mode fiber optic cable:
16GFC: Up to 125 m (OM4) or up to 100 m (OM3)
8GFC: Up to 190 m (OM4) or up to 150 m (OM3)
4GFC: Up to 400 m (OM4) or up to 380 m (OM3)
LC
16 Gb FC LWL SFP+
(00MY768)
FC-PI-5 1310 nm 9 µ single-mode fiber optic cable:
16GFC, 8GFC: Up to 10 km
4GFC: Up to 30 km
LC
16 Gb FC ELWL
SFP+ (00MY770)
FC-PI-5 1310 nm 9 µ single-mode fiber optic cable:
16GFC: Up to 25 km
LC
Management ports
10/100/1000 Mb
Ethernet port
1000BASE-T Up to 25 m with UTP cables supplied by Lenovo (see Table 4).
UTP Category 5, 5E, and 6 up to 100 meters
RJ-45
Serial port RS-232 DB-9/RJ-45-to-RJ-45 console cable (comes with the switch) RJ-45
Lenovo ThinkSystem DB610S 32Gb FC SAN Switch 7

Software
The DB610S FC SAN Switch comes standard with the following software features (based on Fabric OS
version 8.1):
Advanced Fabric Services
Full Fabric mode: Enables high performance 16 Gb or 32 Gb switching in multi-switch fabric.
Advanced Zoning (default zoning, port/WWN zoning, broadcast zoning)
Dynamic fabric provisioning (DFP): Fabric-assigned port World Wide Names (FA-PWWNs).
Dynamic path selection (DPS): Distributes input traffic across multiple paths proportionally to
the bandwidth of each path.
Dynamic load sharing (DLS): Distributes traffic across multiple equal paths between
switches.
Fabric Shortest Path First (FSPF)
Buffer-to-Buffer (BB) credit flow control
Buffer credit recovery
Forward error correction (FEC)
Fabric Device Management Interface (FDMI)
Frame order delivery
Frame redirection
FC login services
Registered State Change Notification (RSCN)
Reliable Commit Service (RCS)
Simple Name Server (SNS)
Fibre Channel Authentication Protocol (FCAP) switch authentication
Management Server (MS): Assists in the auto-discovery of switch-based fabrics.
Adaptive Networking
Traffic isolation zoning (TIZ): Creates a dedicated path for traffic flowing from a specific set
of source ports (F_Ports).
Quality of Service (QoS): SID/DID pair traffic prioritization (high, medium, low).
Virtualization
N_Port ID virtualization (NPIV): Enables a single FC port to appear as multiple, distinct ports
with separate port identification within the fabric.
Access Gateway: Leverages NPIV to connect to any fabric without adding switch domains to
reduce management complexity.
Management
IPv4 and IPv6 addressing
Firmware upload and download
Network Time Protocol (NTP) v3
EZ Switch Setup Wizard
Command line interface (CLI)
Web Tools
Brocade Network Advisor (purchased separately)
SNMPv1, SNMPv3, and MIBs
SMI-S compliant
Syslog
Lenovo ThinkSystem DB610S 32Gb FC SAN Switch 8

Security
Local switch user accounts
LDAP, RADIUS, TACACS+ user authentication
Role-based access control (RBAC)
IP Security (IPsec)
IP filtering
HTTPS
Secure Copy (SCP)
Secure RPC
Secure FTP (SFTP)
Secure Shell (SSH) v2
Secure Sockets Layer (SSL)
Advanced Diagnostic Tools
Power-on self-test (POST)
Event logging
Environmental monitoring
FCping
Pathinfo (FC traceroute)
Non-disruptive daemon restart
Flow mirroring
RAS trace logging
ClearLink Diagnostics with Diagnostic Port (D_Port)
SFP and cable health assessment
Power monitoring
Rolling Reboot Detection (RRD)
The following software features are available for the DB610S FC SAN Switch in the optional Enterprise
Bundle:
ISL Trunking (TRK): Allows frame-based consolidation of up to 8 inter-switch links (ISLs) into fault-
tolerant and load-balanced trunks with bandwidth of up to 256 Gbps.
Fabric Vision (FV)
Monitoring and Alerting Policy Suite (MAPS): Provides a policy-based, fabric-wide threshold
monitoring and alerting tool.
Flow Vision: Allows to identify, monitor, and analyze specific application flows.
VM Insight: Allows to monitor health and performance of individual Virtual Machines (VMs) to
quickly identify abnormal VM behavior and enable administrators to proactively facilitate
troubleshooting and fault isolation, helping to ensure performance and operational stability.
Extended Fabric (EF): Extends Fibre Channel SANs beyond 10 km distance limitations for replication
and backup at full bandwidth.
The following table lists ordering information for the optional software features for the DB610S FC SAN
Switch (one license per switch).
Table 6. Optional software features
Description
Part
number
Feature
code
Lenovo DB610S S/W, Enterprise Bundle (TRK, FV, EF) 01KP848 AVUL
Software subscription and maintenance is included with the DB610S FC SAN Switch and provides 3-year
software support, including firmware downloads and fixes. Software subscription and maintenance can
be extended up to 7 years in 1-year or 2-year increments.
Lenovo ThinkSystem DB610S 32Gb FC SAN Switch 9

The software maintenance extension options are listed in the following table.
Table 7. Software maintenance extension options
Description
Part
number
Feature
code
DB610S FC SAN FW Renewal, 1yr 4ZN7A08472 B0R0
DB610S FC SAN FW Renewal, 2yr 4ZN7A08473 B0R1
Lenovo offers optional Brocade Network Advisor, a fabric management application, to efficiently manage
the network operations lifecycle, including monitoring, diagnostics, change management, and
troubleshooting.
Lenovo offers the following Brocade Network Advisor editions:
Brocade Network Advisor Professional Plus: A SAN management application designed for mid-sized
SANs for managing up to 36 physical or virtual fabrics and up to 2,560 switch ports.
Brocade Network Advisor Enterprise: A SAN management application designed for enterprise-class
SANs for managing up to 100 physical or virtual fabrics and up to 15,000 switch ports.
Brocade Network Advisor supports a wide variety of Brocade SAN offerings, including Lenovo B300,
B6505, B6510, DB610S, DB620S, DB400D, DB800D, FC5022, and more. For a complete list of supported
products and edition features, refer to the Brocade Network Advisor Installation and Migration Guide:
http://www.brocade.com/en/support/document-library/dl-segment-products-os-detail-
page.bna.product.html
The following table lists ordering information for the optional Brocade Network Advisor management
application.
Table 8. Brocade Network Advisor licenses
Description
Part
number
Feature
code
Brocade Network Advisor Professional Plus License 01KP108 AVK4
Brocade Network Advisor SAN Enterprise License 01KP105 AVK3
Brocade Network Advisor SAN Upgrade Professional Plus to Enterprise License 01KP111 AVK5
Fibre Channel standards
The DB610S FC SAN Switch supports the following standards:
FA FCMGMT-MIB
FC-BB-2 INCITS 372-2003
FC-BB-3 INCITS 414-2006
FC-BB-4 INCITS 419-2008
FC-BB-5 INCITS 462-2010 + Amendment 1
FC-BB-6 INCITS 509-2014
FC-DA INCITS TR-36-2004
FC-DA-2 INCITS TR-49-2012
FC-FS INCITS 373-2003
FC-FS-2 ANSI/INCITS 424-2006
FC-FS-3 INCITS 470-2011
FC-FS-4 INCITS 488 rev 1.41
FC-GS-4 ANSI INCITS 387-2004
FC-GS-5 ANSI INCITS 427-2007
Lenovo ThinkSystem DB610S 32Gb FC SAN Switch 10

FC-GS-6 INCITS 463-2010
FC-GS-7 INCITS 510
FC-GS-8 INCITS 548 rev 11.01
FC-IFR INCITS 475-2011
FC-LS INCITS 433: 2007
FC-LS-2 INCITS 477-2011
FC-LS-3 INCITS 487
FC-MI-2 ANSI/INCITS TR-39-2005
FC-MI-3 INCITS TR-48-2012
FCP ANSI X3.269-1996
FCP-2 INCITS 350-2003
FCP-3 INCITS 416-2006
FCP-4 INCITS 481-2012
FC-PI-3 INCITS 460-2012
FC-PI-4 INCITS 450-2009
FC-PI-5 INCITS 449-2011
FC-PI-6 INCITS 512-2015
FC-SB ANSI X3.271-1996
FC-SB-2 INCITS 374-2001
FC-SB-3 INCITS 374-2003 + Amendment 1
FC-SB-4 INCITS 466-2011
FC-SB-5 INCITS 485-2014
FC-SB-6 INCITS 544
FC-SP INCITS 426-2007
FC-SP-2 INCITS 496-2012 + Amendment 1
FC-SW-3 INCITS 384-2004
FC-SW-4 INCITS 418-2006
FC-SW-5 INCITS 461-2010
FC-SW-6 INCITS 511
FC-SW-7 INCITS 547 rev 1.04
FC-TAPE INCITS TR-24-1999
FC-VI INCITS 357-2002
MIB-FA INCITS TR-32-2003
RFC 2837 Fabric Element MIB
RFC 4338 Transmission of IPv6, IPv4, and ARP over FC
SNIA Storage Management Initiative Specification (SMI-S) Version 1.03 ISO standard IS24775-2006
(replaces ANSI INCITS 388: 2004)
SNIA Storage Management Initiative Specification Version 1.1
SNIA Storage Management Initiative Specification Version 1.2
SNIA Storage Management Initiative Specification Version 1.4
SNIA Storage Management Initiative Specification Version 1.5
SNIA Storage Management Initiative Specification Version 1.6
Power supplies and cables
Lenovo ThinkSystem DB610S 32Gb FC SAN Switch 11

Power supplies and cables
The DB610S FC SAN Switch ships with one fixed 150 W AC power supply that has an IEC 309-C14
connector.
The switch comes standard without a power cord; two rack power cables or country-specific line cords
must be ordered together with the switch (see the following table).
Table 9. Power cord options
Description
Part
number
Feature
code
Rack power cables
1.5m, 10A/100-250V, C13 to IEC 320-C14 Rack Power Cable 39Y7937 6201
1.8m, 10A/100-250V, 2xC13PM to IEC 320-C14 Rack Power Cable None* 6568
2.8m, 10A/100-250V, C13 to IEC 320-C14 Rack Power Cable 4L67A08366 6311
2.8m, 10A/100-250V, C13 to IEC 320-C20 Rack Power Cable 39Y7938 6204
4.3m, 10A/100-250V, C13 to IEC 320-C14 Rack Power Cable 39Y7932 6263
Country-specific line cords
10A/125V C13 to NEMA 5-15P 4.3m line cord 39Y7931 6207
10A/250V C13 to NEMA 6-15P 2.8m line cord 46M2592 A1RF
Argentina 10A/250V C13 to IRAM 2073 2.8m line cord 39Y7930 6222
Australia/NZ 10A/250V C13 to AS/NZ 3112 2.8m line cord 39Y7924 6211
Brazil 10A/125V C13 to NBR 6147 2.8m line cord 39Y7929 6223
China 10A/250V C13 to GB 2099.1 2.8m line cord 39Y7928 6210
Denmark 10A/250V C13 to DK2-5a 2.8m line cord 39Y7918 6213
European 10A/230V C13 to CEE7-VII 2.8m line cord 39Y7917 6212
India 10A/250V C13 to IS 6538 2.8m line cord 39Y7927 6269
Israel 10A/250V C13 to SI 32 2.8m line cord 39Y7920 6218
Italy 10A/250V C13 to CEI 23-16 2.8m line cord 39Y7921 6217
Japan 12A/125V C13 to JIS C-8303 2.8m line cord 46M2593 A1RE
Korea 12A/250V C13 to KETI 2.8m line cord 39Y7925 6219
South Africa 10A/250V C13 to SABS 164 2.8m line cord 39Y7922 6214
Switzerland 10A/250V C13 to SEV 1011-S24507 2.8m line cord 39Y7919 6216
Taiwan 10A/250V C13 to CNS 10917-3 2.8m line cord 00CG265 A53E
Taiwan 15A/125V C13 to CNS 10917-3 2.8m line cord 00CG267 A53F
United Kingdom 10A/250V C13 to BS 1363/A 2.8m line cord 39Y7923 6215
* Available for factory-built custom configurations and solutions only.
Rack installation
Lenovo ThinkSystem DB610S 32Gb FC SAN Switch 12

Rack installation
The DB610S FC SAN Switch comes standard with the fixed rack mount kit that can be used for 4-post
rack installations. If needed, the DB610S FC SAN Switch can be mounted in a 2-post rack cabinet by
using the optional mid-mount rack kit that is listed in the following table.
Table 10. Rack-mount options
Description
Part
number
Feature
code
Maximum
quantity
supported
Lenovo DB610S Mid-mount (Telco) Rack Kit 01KP847 AX4D 1
The optional mid-mount rack kit for the DB610S FC SAN Switch is shown in the following figure.
Figure 4. Lenovo DB610S Mid-mount (Telco) Rack Kit
Physical specifications
The DB610S FC SAN Switch has the following dimensions and weight (approximate):
Height: 43 mm (1.7 in.)
Width: 429 mm (16.9 in.)
Depth: 307 mm (12.1 in.)
Weight:
Empty: 4.2 kg (9.3 lb)
Fully configured: 5.8 kg (12.7 lb)
Operating environment
The DB610S FC SAN Switch is supported in the following environment:
Air temperature:
Operating: 0°C to 40°C (32°F to 104°F)
Non-operating: -25°C to +70°C (-13°F to 158°F)
Maximum altitude:
Operating: 3,000 m (9,842 ft)
Non-operating: 12,000 m (39,370 ft)
Humidity:
Operating: 10% to 85% non-condensing
Non-operating: 10% to 90% non-condensing
Lenovo ThinkSystem DB610S 32Gb FC SAN Switch 13

Electrical power:
Voltage range: 100 V AC - 240 V AC (nominal)
Frequency: 50 Hz / 60 Hz (nominal)
Power consumption:
Idle: 56 watts
Typical: 64 watts
Maximum: 77 watts
Heat dissipation:
Idle: 191 BTU per hour
Typical: 216 BTU per hour
Maximum: 262 BTU per hour
Acoustical noise emission (maximum): 64 dB
Hardware warranty
The DB610S FC SAN Switch has a one-year customer-replaceable unit (CRU) limited warranty with
standard call center support during normal business hours and 9x5 Next Business Day Parts Delivered.
Some countries might have different warranty terms and conditions than the standard warranty. This is due
to local business practices or laws in the specific country. Local service teams can assist in explaining
country-specific terms when needed. Examples of country-specific warranty terms are second or longer
business day parts delivery or parts-only base warranty.
If warranty terms and conditions include onsite labor for repair or replacement of parts, Lenovo will
dispatch a service technician to the customer site to perform the replacement. Onsite labor under base
warranty is limited to labor for replacement of parts that have been determined to be field-replaceable units
(FRUs). Parts that are determined to be customer-replaceable units (CRUs) do not include onsite labor
under base warranty.
If warranty terms include parts-only base warranty, Lenovo is responsible for delivering only replacement
parts that are under base warranty (including FRUs) that will be sent to a requested location for self-
service. Parts-only service does not include a service technician being dispatched onsite. Parts must be
changed at customer’s own cost and labor and defective parts must be returned following the instructions
supplied with the spares parts.
Also available are Lenovo Services warranty maintenance upgrades and post-warranty maintenance
agreements, with a well-defined scope of services, including service hours, response time, term of service,
and service agreement terms and conditions.
Lenovo warranty service upgrade offerings are country-specific. Not all warranty service upgrades are
available in every country. For information about Lenovo warranty service upgrade offerings that are
available in your country or area, refer to the following resources:
Service part numbers in Lenovo Data Center Solution Configurator (DCSC):
http://lesc.lenovo.com/#/services
Lenovo Services Availability Locator
https://lenovolocator.com/
Lenovo ThinkSystem DB610S 32Gb FC SAN Switch 14

In general, the following Lenovo warranty service upgrades are available:
Warranty and maintenance service upgrades:
1, 3, 4, or 5 years of warranty service coverage
1-year or 2-year post-warranty extensions
Foundation Service: 9x5 service coverage with next business day onsite response
Essential Service: 24x7 service coverage with 4-hour onsite response or 24-hour committed
repair (available only in select countries)
Advanced Service: 24x7 service coverage with 2-hour onsite response or 6-hour committed
repair (available only in select countries)
Basic Hardware Installation Services
Lenovo experts can seamlessly manage the physical installation of your server, storage, or
networking hardware. Working at a time convenient for you (business hours or off shift), the
technician will unpack and inspect the systems on your site, install options, mount in a rack
cabinet, connect to power and network, check and update firmware to the latest levels, verify
operation, and dispose of the packaging, allowing your team to focus on other priorities.
For service definitions, country-specific details, and service limitations, please refer to the following
documents:
Lenovo Statement of Limited Warranty for Data Center Group (DCG) Servers and System Storage
http://pcsupport.lenovo.com/us/en/solutions/ht503310
Lenovo Data Center Services Agreement
http://support.lenovo.com/us/en/solutions/ht116628
Regulatory compliance
The DB610S FC SAN Switch conforms to the following regulations:
Electromagnetic compatibility
CISPR 22
CNS 13438
EN 55024
EN 55032
EN 61000-3-2
EN 61000-3-3
FCC Part 15, Subpart B
GB 9254
ICES-003
KN 32
KN 35
VCCI
Safety
CNS 14336-1
EN/UL/CSA/IEC 60950-1
GB 4943.1
Environmental: RoHS
Fibre Channel SAN switches
Lenovo ThinkSystem DB610S 32Gb FC SAN Switch 15

Fibre Channel SAN switches
The following table lists the FC SAN switches that are offered by Lenovo that can be used in Lenovo FC
SAN solutions.
Table 11. FC SAN switches
Description
Part
number
Rack-mount switches - 8 Gb FC
Lenovo B300, 8 ports activated, 8x 8Gb SWL SFPs, 1 PS, Rail Kit 3873AR3
Lenovo B6505, 12 ports activated, 12x 8Gb SWL SFPs, 1 PS, Rail Kit 3873AR4
Lenovo B6510, 24 ports activated, 24x 8Gb SWL SFPs, 2 PS, Rail Kit 3873BR2
Rack-mount switches - Gen 5 16 Gb FC
Lenovo B6505, 12 ports activated, 12x 16Gb SWL SFPs, 1 PS, Rail Kit 3873AR5
Lenovo B6510, 24 ports activated, 24x 16Gb SWL SFPs, 2 PS, Rail Kit 3873BR3
Rack-mount switches - Gen 6 32 Gb FC
Lenovo ThinkSystem DB620S, 24 ports activated, 24x 32Gb SWL SFPs, 2 PS, Rail Kit 6415G11
Lenovo ThinkSystem DB620S, 48 ports activated, 48x 32Gb SWL SFPs, 2 PS, Rail Kit, Enterprise SW 6415G2A
Rack-mount FC SAN Directors - Gen 6 32 Gb FC
Lenovo ThinkSystem DB400D 32Gb FC Director, Up to 192 ports, 8U, Enterprise SW 6684B2A
Lenovo ThinkSystem DB800D 32Gb FC Director, Up to 384 ports, 14U, Enterprise SW 6682B1A
Embedded switches - Gen 5 16 Gb FC
Lenovo Flex System FC5022 16Gb SAN Scalable Switch 88Y6374
Lenovo Flex System FC5022 24-port 16Gb SAN Scalable Switch (includes two 16 Gb SFPs) 00Y3324
Lenovo Flex System FC5022 24-port 16Gb ESB SAN Scalable Switch 90Y9356
For more information, see the list of Product Guides in the following categories:
Rack-mount SAN switches:
http://lenovopress.com/storage/switches/rack?rt=product-guide
Blade Storage Modules:
http://lenovopress.com/servers/blades/storagemodule?rt=product-guide
External storage systems
The following table lists the external storage systems that are offered by Lenovo that can be used in
Lenovo FC SAN solutions.
Note: Information provided in this section is for ordering reference purposes only. End-to-end storage
configuration support must be verified through the interoperability matrix for a particular storage system
that can be found on the Lenovo Data Center Support web site:
http://datacentersupport.lenovo.com
Table 12. External storage systems
Description
Part
number
Lenovo ThinkSystem DS Series Storage
Lenovo ThinkSystem DS2200 LFF FC/iSCSI Dual Controller Unit (US English documentation) 4599A31*
Lenovo ThinkSystem DB610S 32Gb FC SAN Switch 16

Lenovo ThinkSystem DS2200 LFF FC/iSCSI Dual Controller Unit (Simplified Chinese documentation) 4599A3C^
Lenovo ThinkSystem DS2200 LFF FC/iSCSI Dual Controller Unit (Japanese documentation) 4599A3J**
Lenovo ThinkSystem DS2200 SFF FC/iSCSI Dual Controller Unit (US English documentation) 4599A11*
Lenovo ThinkSystem DS2200 SFF FC/iSCSI Dual Controller Unit (Simplified Chinese documentation) 4599A1C^
Lenovo ThinkSystem DS2200 SFF FC/iSCSI Dual Controller Unit (Japanese documentation) 4599A1J**
Lenovo ThinkSystem DS4200 LFF FC/iSCSI Dual Controller Unit (US English documentation) 4617A31*
Lenovo ThinkSystem DS4200 LFF FC/iSCSI Dual Controller Unit (Simplified Chinese documentation) 4617A3C^
Lenovo ThinkSystem DS4200 LFF FC/iSCSI Dual Controller Unit (Japanese documentation) 4617A3J**
Lenovo ThinkSystem DS4200 SFF FC/iSCSI Dual Controller Unit (US English documentation) 4617A11*
Lenovo ThinkSystem DS4200 SFF FC/iSCSI Dual Controller Unit (Simplified Chinese documentation) 4617A1C^
Lenovo ThinkSystem DS4200 SFF FC/iSCSI Dual Controller Unit (Japanese documentation) 4617A1J**
Lenovo ThinkSystem DS6200 SFF FC/iSCSI Dual Controller Unit (US English documentation) 4619A11*
Lenovo ThinkSystem DS6200 SFF FC/iSCSI Dual Controller Unit (Simplified Chinese documentation) 4619A1C^
Lenovo ThinkSystem DS6200 SFF FC/iSCSI Dual Controller Unit (Japanese documentation) 4619A1J**
Lenovo Storage DX8200 Series (FC connectivity requires an optional FC HBA and a software license)
Lenovo Storage DX8200D ServerSAN Entry, 8TB, 3yr SW S&S 5135D2x#
Lenovo Storage DX8200D ServerSAN Entry, 8TB, 4yr SW S&S 5135N2x#
Lenovo Storage DX8200D ServerSAN Entry, 8TB, 5yr SW S&S 51354Vx#
Lenovo Storage DX8200D ServerSAN Mid, 16TB, 3yr SW S&S 5135F2x#
Lenovo Storage DX8200D ServerSAN Mid, 16TB, 4yr SW S&S 5135P2x#
Lenovo Storage DX8200D ServerSAN Mid, 16TB, 5yr SW S&S 51355Vx#
Lenovo Storage DX8200D ServerSAN High, 32TB, 3yr SW S&S 5135G2x#
Lenovo Storage DX8200D ServerSAN High, 32TB, 4yr SW S&S 5135Q2x#
Lenovo Storage DX8200D ServerSAN High, 32TB, 5yr SW S&S 51356Vx#
Lenovo Storage DX8200D Storage Virtualization Entry, 4TB, 3yr SW S&S 5135A2x#
Lenovo Storage DX8200D Storage Virtualization Entry, 4TB, 4yr SW S&S 5135J2x#
Lenovo Storage DX8200D Storage Virtualization Entry, 4TB, 5yr SW S&S 51351Vx#
Lenovo Storage DX8200D Storage Virtualization Mid, 16TB, 3yr SW S&S 5135B2x#
Lenovo Storage DX8200D Storage Virtualization Mid, 16TB, 5yr SW S&S 51352Vx#
Lenovo Storage DX8200D Storage Virtualization Mid, 16TB, 4yr SW S&S 5135L2x#
Lenovo Storage DX8200D Storage Virtualization High, 64TB, 3yr SW S&S 5135C2x#
Lenovo Storage DX8200D Storage Virtualization High, 64TB, 4yr SW S&S 5135M2x#
Lenovo Storage DX8200D Storage Virtualization High, 64TB, 5yr SW S&S 51353Vx#
Lenovo Storage DX8200N with 1x N2226 HBA (Requires a supported external drive enclosure) 5128A1x#
Lenovo Storage DX8200N with 2x N2226 HBAs (Requires a supported external drive enclosure) 5128A2x#
Lenovo Storage V Series
Lenovo Storage V3700 V2 LFF Control Enclosure 6535C1D
Lenovo Storage V3700 V2 LFF Control Enclosure (Top Seller) 6535EC1
Lenovo Storage V3700 V2 SFF Control Enclosure 6535C2D
Lenovo Storage V3700 V2 SFF Control Enclosure (Top Seller) 6535EC2
Description
Part
number
Lenovo ThinkSystem DB610S 32Gb FC SAN Switch 17

Lenovo Storage V3700 V2 XP LFF Control Enclosure 6535C3D
Lenovo Storage V3700 V2 XP LFF Control Enclosure (Top Seller) 6535EC3
Lenovo Storage V3700 V2 XP SFF Control Enclosure 6535C4D
Lenovo Storage V3700 V2 XP SFF Control Enclosure (Top Seller) 6535EC4
Lenovo Storage V5030 LFF Control Enclosure 3Yr S&S 6536C12
Lenovo Storage V5030 LFF Control Enclosure 5Yr S&S 6536C32
Lenovo Storage V5030 SFF Control Enclosure 3Yr S&S 6536C22
Lenovo Storage V5030 SFF Control Enclosure 5Yr S&S 6536C42
Lenovo Storage V5030F SFF Control Enclosure 3Yr S&S 6536B1F
Lenovo Storage V5030F SFF Control Enclosure 5Yr S&S 6536B2F
Lenovo Storage V7000 SFF Control Enclosure 3Yr S&S PRC 6538R11^
Lenovo Storage V7000 SFF Control Enclosure 5Yr S&S PRC 6538R21^
Lenovo Storage V7000F SFF Control Enclosure 3Yr S&S PRC 6538R1G^
Lenovo Storage V7000F SFF Control Enclosure 5Yr S&S PRC 6538R2G^
IBM Storwize for Lenovo
IBM Storwize V3500 3.5-inch Dual Control Storage Controller Unit 6096CU2^
IBM Storwize V3500 2.5-inch Dual Control Storage Controller Unit 6096CU3^
IBM Storwize V7000 SFF Control Enclosure, 3YR SWMA 6195C32†
IBM Storwize V7000 SFF Control Enclosure, 3YR SWMA, LA 6195C3L‡
IBM Storwize V7000 SFF Control Enclosure, 5YR SWMA 6195C52†
IBM Storwize V7000 SFF Control Enclosure, 5YR SWMA, LA 6195C5L‡
Description
Part
number
* Available worldwide (except China and Japan).
^ Available only in China.
** Available only in Japan.
# x represents a geo-specific letter (for example: U = North America, G = EMEA). Ask a Lenovo representative for specifics.
† Available worldwide except Latin America.
‡ Available only in Latin America.
For more information, see the list of Product Guides in the following categories:
Lenovo DS Series and V Series storage:
http://lenovopress.com/storage/san/lenovo#rt=product-guide
IBM Storwize for Lenovo storage:
http://lenovopress.com/storage/san/ibm#rt=product-guide
Lenovo Software Defined Storage (DX8200 Series):
http://lenovopress.com/storage/sds#rt=product-guide
External backup units
Lenovo ThinkSystem DB610S 32Gb FC SAN Switch 18

External backup units
The following table lists the external backup options that are offered by Lenovo that can be used in Lenovo
FC SAN solutions.
Note: Information provided in this section is for ordering reference purposes only. End-to-end LTO Ultrium
configuration support for a particular tape backup unit must be verified through the System Storage
Interoperation Center (SSIC):
http://www.ibm.com/systems/support/storage/ssic
Table 13. External backup options
Description
Part
number
External tape backup libraries - TS3100 and TS3200
IBM TS3100 Tape Library Model L2U 61732UL
IBM TS3200 Tape Library Model L4U 61734UL
Fibre Channel backup drives for TS3100 and TS3200 Tape Libraries
6173 LTO Ultrium 5 Fibre Channel Drive 00NA107
6173 LTO Ultrium 5 Half High Fibre Drive Sled 00NA113
6173 LTO Ultrium 6 Fibre Channel Drive 00NA115
6173 LTO Ultrium 6 Half High Fibre Drive Sled 00NA119
6173 LTO Ultrium 7 Fibre Channel Drive 00WF765
6173 LTO Ultrium 7 Half High Fibre Drive Sled 00WF769
For more information, see the list of Product Guides in the Backup Units category:
http://lenovopress.com/servers/options/backup
Rack cabinets
The following table lists the rack cabinets that are offered by Lenovo that can be used in Lenovo FC SAN
solutions.
Table 14. Rack cabinets
Description
Part
number
25U S2 Standard Rack (1000 mm deep; 2 sidewall compartments) 93072RX
25U Static S2 Standard Rack (1000 mm deep; 2 sidewall compartments) 93072PX
42U S2 Standard Rack (1000 mm deep; 6 sidewall compartments) 93074RX
42U 1100mm Enterprise V2 Dynamic Rack (6 sidewall compartments) 93634PX
42U 1100mm Enterprise V2 Dynamic Expansion Rack (6 sidewall compartments) 93634EX
42U 1200mm Deep Dynamic Rack (6 sidewall compartments) 93604PX
42U 1200mm Deep Static Rack (6 sidewall compartments) 93614PX
42U Enterprise Rack (1105 mm deep; 4 sidewall compartments) 93084PX
42U Enterprise Expansion Rack (1105 mm deep; 4 sidewall compartments) 93084EX
For more information, see the list of Product Guides in the Rack cabinets category:
https://lenovopress.com/servers/options/racks
Lenovo ThinkSystem DB610S 32Gb FC SAN Switch 19

Power distribution units
The following table lists the power distribution units (PDUs) that are offered by Lenovo that can be used in
Lenovo FC SAN solutions.
Table 15. Power distribution units
Description
Part
number
0U Basic PDUs
0U 36 C13/6 C19 24A/200-240V 1 Phase PDU with NEMA L6-30P line cord 00YJ776
0U 36 C13/6 C19 32A/200-240V 1 Phase PDU with IEC60309 332P6 line cord 00YJ777
0U 21 C13/12 C19 32A/200-240V/346-415V 3 Phase PDU with IEC60309 532P6 line cord 00YJ778
0U 21 C13/12 C19 48A/200-240V 3 Phase PDU with IEC60309 460P9 line cord 00YJ779
Switched and Monitored PDUs
0U 20 C13/4 C19 Switched and Monitored 24A/200-240V/1Ph PDU w/ NEMA L6-30P line cord 00YJ781
0U 20 C13/4 C19 Switched and Monitored 32A/200-240V/1Ph PDU w/ IEC60309 332P6 line cord 00YJ780
0U 18 C13/6 C19 Switched / Monitored 32A/200-240V/346-415V/3Ph PDU w/ IEC60309 532P6 cord 00YJ782
0U 12 C13/12 C19 Switched and Monitored 48A/200-240V/3Ph PDU w/ IEC60309 460P9 line cord 00YJ783
1U 9 C19/3 C13 Switched and Monitored DPI PDU (without line cord) 46M4002
1U 9 C19/3 C13 Switched and Monitored 60A 3Ph PDU with IEC 309 3P+Gnd cord 46M4003
1U 12 C13 Switched and Monitored DPI PDU (without line cord) 46M4004
1U 12 C13 Switched and Monitored 60A 3 Phase PDU with IEC 309 3P+Gnd line cord 46M4005
Ultra Density Enterprise PDUs (9x IEC 320 C13 + 3x IEC 320 C19 outlets)
Ultra Density Enterprise C19/C13 PDU Module (without line cord) 71762NX
Ultra Density Enterprise C19/C13 PDU 60A/208V/3ph with IEC 309 3P+Gnd line cord 71763NU
C13 Enterprise PDUs (12x IEC 320 C13 outlets)
DPI C13 Enterprise PDU+ (without line cord) 39M2816
DPI Single Phase C13 Enterprise PDU (without line cord) 39Y8941
C19 Enterprise PDUs (6x IEC 320 C19 outlets)
DPI Single Phase C19 Enterprise PDU (without line cord) 39Y8948
DPI 60A 3 Phase C19 Enterprise PDU with IEC 309 3P+G (208 V) fixed line cord 39Y8923
Front-end PDUs (3x IEC 320 C19 outlets)
DPI 30amp/125V Front-end PDU with NEMA L5-30P line cord 39Y8938
DPI 30amp/250V Front-end PDU with NEMA L6-30P line cord 39Y8939
DPI 32amp/250V Front-end PDU with IEC 309 2P+Gnd line cord 39Y8934
DPI 60amp/250V Front-end PDU with IEC 309 2P+Gnd line cord 39Y8940
DPI 63amp/250V Front-end PDU with IEC 309 2P+Gnd line cord 39Y8935
Universal PDUs (7x IEC 320 C13 outlets)
DPI Universal 7 C13 PDU (with 2 m IEC 320-C19 to C20 rack power cord) 00YE443
NEMA PDUs (6x NEMA 5-15R outlets)
DPI 100-127V PDU with fixed NEMA L5-15P line cord 39Y8905
Line cords for PDUs that ship without a line cord
DPI 30a Line Cord (NEMA L6-30P) 40K9614
DPI 32a Line Cord (IEC 309 P+N+G) 40K9612
Lenovo ThinkSystem DB610S 32Gb FC SAN Switch 20
