Lenovo YOGA Tab 3 Pro 10" YT3-X90F User manual

YOGA Tab 3 Pro 10"
User Guide
Lenovo YT3–X90F
Lenovo YT3–X90L
Lenovo YT3–X90X

Basics
Notes: Before using this information and the product it supports, be sure to read the following:
Safety, Warranty & Quick Start Guide
Regulatory Notice
“Important safety and handling information” in "Appendix".
The Safety, Warranty & Quick Start Guide and the Regulatory Notice are available on the
website at http://support.lenovo.com.
Technical specifications
Model Lenovo YT3–X90F Lenovo YT3–X90L Lenovo YT3–X90X
CPU Intel® Atom™ x5-
Z8500 Processor
Intel® Atom™ x5-Z8500
Processor
Intel® Atom™ x5-
Z8500 Processor
Battery 10200 mAh 10200 mAh 10200 mAh
Wireless
communication
Bluetooth 4.0;
WLAN;
GPS/GLONASS
Bluetooth 4.0; WLAN;
GPS/GLONASS;
LTE/WCDMA/TDSCDMA/GSM
Bluetooth 4.0;
WLAN;
GPS/GLONASS;
LTE/WCDMA/GSM
NOTE: Lenovo YT3–X90L supports LTE Band 1, 2, 3, 4, 5, 7, 8, 9, 12, 17, 18, 19, 20, 25, 26,
38, 39 and 40. Lenovo YT3–X90X supports LTE Band 1, 2, 3, 4, 5, 7, 8, 9, 18, 19, 21, 25, 26,
28a, 28b, 40 and 41. But In some countries, LTE is not supported. To know if your device
works with LTE networks in your country, contact your carrier.
Home screen
The home screen is the starting point for using your device. For your convenience, the home
screen is already set up with some useful apps and widgets.

NOTE: Your device features and the home screen may be different depending on your
location, language, carrier, and device model.
You can customize your own home screen at any time.
Home screen
On the first home screen, there is a Google Search bar, a video widget and a Lenovo
Weather widget.
Preview screen
Tap and hold anywhere on the home screen except the icons.
At the bottom of the screen are WALLPAPERS, WIDGETS and SETTINGS.
Add a widget to a home screen
Tap at the bottom of the preview screen, tap and hold the widget you want to add,
then drag to where you want to place it and release.
Change the wallpaper
Go to Settings > Display > Wallpaper and choose the wallpaper that you like.
Tap and hold anywhere on the home screen except the icons, select Wallpaper at the
bottom of the screen, and then choose the wallpaper that you like.
Move an app to another screen
Tap and hold an app that you want to move, drag it to the left or right side of the
screen, then release it where you want to place it.
Uninstall an app
1. Tap , and then tap and hold an app that you want to uninstall.
2. Drag to at the top of the screen until the app turns red, and then release and tap
OK.
Screen buttons
There are three buttons at the bottom of the home screen.
Back button: Tap to return to the previous page.

Home button: Tap to return to the default home screen.
Recent button: Tap to see recent apps. Then you can do the following:
Tap an app to open it.
Swipe an app window downwards to lock or unlock it.
Swipe an app window up to close it.
Tap to stop running all the apps except the locked ones.
Notifications and Quick Settings
Swipe down from the top of the screen to view system notification messages and quick
settings. By tapping on a switch, you can quickly turn a number of frequently used functions on
or off.
Force shutdown
Press and hold the On/Off button for more than 10 seconds until the screen goes dark.

Camera
To open the Camera app, go to Camera.
Taking photos and videos
You can take photos and record videos with your device's built-in camera.
By swiping on the right side of the screen you can switch between photo, video, panorama,
action shot and smart capture.
Tap to take a photo.
Tap to record a video.
Tap to switch between the front and the back camera.
Tap to choose the scene mode.

Tap to adjust the exposure.
Tap to configure the other camera settings.
Taking screenshots
Press and hold the On/Off button and the Volume down button at the same time.
Viewing pictures and videos
Photos and videos are stored in your device's internal storage. You can view your photos and
videos by using the following methods:
Tap the photo review icon when using the Camera app.
Go to Gallery.
Go to File Browser.
Screenshots are stored in your device's internal storage. You can view your screenshots by
using the following methods:
Go to Gallery.
Go to File Browser.

Network
You need to set up a wireless network before connecting to the Internet.
Setting up a WLAN network
Go to Settings > WLAN.
Turn on the WLAN block and tap one WLAN hotspot in the list, then you can connect to the
Internet.
When you access a secure link, you need to input your login name and password to connect.
NOTE: You need to have a valid WLAN hotspot to link to.
Setting up a VPN network
VPNs used within organizations allow you to communicate private information securely over a
non-private network. You may need to configure a VPN, for example, to access your work
email. Ask the network’s administrator for the settings necessary to configure a VPN for your
network. When one or more VPN settings are defined you can:
Go to Settings > More > VPN.
Tap to edit the VPN profile, including the server name, the type and the server
address, and then tap SAVE.
Tap the VPN server name, input the username and password, and then tap CONNECT
to connect to the VPN network.
Tap and hold the VPN server name to edit or delete the VPN.

Network
You need to set up a wireless network before connecting to the Internet.
Set up a WLAN network
Set up a mobile network
Set up a VPN network
You can also set up a hotspot to share your mobile network with others.
Setting up a WLAN network
Go to Settings > WLAN.
Turn on the WLAN block and tap a WLAN hotspot in the list to connect to the Internet.
When you access a secure link, you need to enter your login name and password to connect.
NOTE: You need to have a valid WLAN hotspot to connect to.
Setting up a mobile network
Go to Settings > More > Cellular networks > Data enabled.
NOTE: You need a valid SIM card with a data service. If you don't have a SIM card, contact
your carrier.
Setting up a VPN network
VPNs used within organizations allow you to communicate private information securely over a
non-private network. You may need to configure a VPN, for example, to access your work
email. Ask the network’s administrator for the settings necessary to configure a VPN for your
network. When one or more VPN settings are defined you can:
Go to Settings > More > VPN.
Tap to edit the VPN profile, including the server name, the type and the server
address, and then tap SAVE.
Tap the VPN server name, input the username and password, and then tap CONNECT
to connect to the VPN network.
Tap and hold the VPN server name to edit or delete the VPN.

Setting up a hotspot
You can use Personal hotspot to share an Internet connection with a computer or other device.
Go to Settings > More > Tethering & portable hotspot and do the following:
Turn on Portable WLAN hotspot.
Tap Set up WLAN hotspot to configure the hotspot.
You can also use Bluetooth tethering and USB tethering.
NOTE: Tell your friends the Network SSID and password, and then they can share your
mobile network.

Internet
You can browse the web if your device is connected to a wireless network.
To open the browser app, go to Chrome.
Visiting websites
You can use the Chrome app to visit websites.
Type web address
You don't need to type the full web address of an "http://" website to access it.
To visit "http://www.lenovo.com", simply type "www.lenovo.com" into the address bar
and tap .
Search keywords
You can also type keywords into the address bar to search for webpages.
You can set a search engine in > Settings > Search engine.
Add a new webpage
Tap the blank tab on the top, or tap > New tab to add a new webpage tab.
Tap > New incognito tab to visit a website without leaving a trace.
Close a webpage
Tap to close a webpage tab.

Refresh a webpage
Tap to refresh a webpage.
Tap to return to the previous webpage.
Tap to go forward to a recent webpage.
Saving webpages
You can save images and webpages in your device's internal storage.
Save images
Tap and hold the image, then tap Save image.
Bookmark webpages
Tap , then tap Save to add a webpage to Bookmarks.
Tap > Bookmarks, to view Mobile bookmarks.
Setting accessibility preferences
Tap > Settings > Accessibility to set the text scaling and the webpage zoom.

Email
You can receive and send emails if your device is connected to a wireless network.
To access the Google Email app, go to Gmail.
Setting up an Email account
You can sign into Email if you have an email account. If not, you will need to create an email
account.
You need to set up an email account the first time you use the Gmail app.
Tap Add an email address, select the type of email you want to add, and tap NEXT. Set up
according to the page prompts.
Using Email
After setting up an email account you can use the Gmail app to send and receive emails.

Maps
You need to select the following settings before you use Maps.
Go to Settings > Location and enable location access for Google apps.
Finding a location
Type the address that you want to find, then tap .
You can also tap , then speak.
Current location
Tap to see your current location.
Then tap Explore around you to check what's nearby.
Planning a route
Tap and type in the "from" and "to" addresses or just keep it as "Your location".

Choose the travel mode, by car, by bus, or on foot.

Communication
You can manage contacts with the Contacts app. You can create a contact, and import and
export contacts.
Creating a contact
Go to Contacts.
Tap to create a contact.
Enter the contact information, such as "Name", "Mobile", "Home" and so on.
You can save it in the tablet or Micro SIM card. When you're done, tap Save.
Importing and exporting contacts
Go to Contacts.
Tap > More features and settings > Import/Export contacts.
Select Import from storage. Choose the vCard files to be imported, then tap Import.
Or select Export to storage, and tap OK.

Communication
You can use your device to send a message and manage contacts.
Managing contacts
You can manage contacts with the Contacts app. You can create a contact, and import and
export contacts.
Creating a contact
Go to Contacts.
Tap to add a contact.
Enter the contact information, such as "Name", "Mobile", "Home" and so on.
You can save it in the tablet or SIM card. When you're done, tap Save.
Importing and exporting contacts
Go to Contacts.
Tap > More features and settings > Import/Export contacts.
Select Import from storage. Choose the vCard files to be imported, then tap Import.
Or select Export to storage, and tap OK.
Sending a message
Go to Contacts, choose a name, then tap the phone number to write a new message.

Sync
You can transfer data between your device and computer. Transfer music, pictures, videos,
documents, Android application package (APK) files, and so on.
Connecting your device and computer
Connect your device and computer with a data line.
Slide down from the top of the screen, you will see "USB connected" in the notification bar.
Tap USB connected for other options.
Selecting computer connection mode
You can select one of the following options
Media device (MTP): Select this mode if you want to transfer media files such as
photos, videos, and ringtones between your tablet and the computer.
Camera (PTP): Select this mode if you want to transfer only photos and videos
between your tablet and the computer.
USB debugging (ADB): Select this mode to enable debugging. You can then use tools

such as Idea Tool on the computer to manage your tablet's data.
Installing APK
Follow these steps:
You need to set the device to allow installation of apps obtained from unknown
sources.
Go to Settings > Security, select Unknown sources and tap OK.
Copy the APK file from the computer to the device in "Media device (MTP)" mode.
Open the apps category in the File Browser.

Projector
To use the projector app, go to Projector.
Turning On/Off
Hold the Projector On/Off button down for a few seconds.
Tap Projector in quick settings.
Go to Settings > Projector, tap the projector switch.
Tap Projector in Smart Side Bar.
Projected Scene
Cinema/Pictures/Documents
Cinema, Pictures or Documents: You can view local video, images and documents easily
through projector. Hold down a document to delete it and select multiple operations.
Favorites List: You can bookmark documents you like. Bookmarked documents will be
marked with a in their upper right corner.
Cinema Applications List: You can play videos using the applications on this list.
Story
You can create your own unique photo story in the Story Scene. Press to set titles,
projector photos, music, playing duration and photo story covers, then press Save. Next
time, you will be able to directly view your personal photo stories.
Split-screen/full-screen projector
Go to the projector application and press , you can switch between split-screen and full-
screen projector, so you can handle different tasks at the same time.
When split-screen projector is selected, only the current image content within the projector
application is projected.
When full-screen projector is selected, all current image content on the device's screen is
