Lenovo YOGA Tablet 2-830LC How to use

YOGA Tablet 2-830F
YOGA Tablet 2-830L
YOGA Tablet 2-830LC
YOGA Tablet 2-1050F
YOGA Tablet 2-1050L
YOGA Tablet 2-1050LC
English/Deutsch/Français/Italiano
Safety, Warranty & Quick Start Guide

English
Electronic emission
notices
Learn more
Legal notices Lenovo and the Lenovo logo are trademarks of Lenovo in
the United States, other countries, or both.
Other company, product, or service names may be
trademarks or service marks of others.
Manufactured under license from Dolby Laboratories.
Dolby and the double-D symbol are trademarks of Dolby
Laboratories.
LIMITED AND RESTRICTED RIGHTS NOTICE: If data or
software is delivered pursuant a General Services
Administration “GSA” contract, use, reproduction, or
disclosure is subject to restrictions set forth in Contract
No. GS-35F-05925.
Getting support For support on network service and billing, contact your
wireless network operator. For instructions on how to
use your YOGA Tablet 2, go to:
http://support.lenovo.com/.
To learn more information about your YOGA Tablet 2 and
obtain the latest manuals, go to:
http://support.lenovo.com/.
Read this guide carefully before using your YOGA Tablet 2.
All information labeled with * in this guide refers only to the LTE model
(YOGA Tablet 2-830L/YOGA Tablet 2-830LC/YOGA Tablet
2-1050L/YOGA Tablet 2-1050LC).
Radio and Telecommunications Terminal Equipment
Directive
This product is in compliance with the essential
requirements and other relevant provisions of the Radio
and Telecommunications Terminal Equipment Directive,
1999/5/EC.
European Union conformity

Approx. 419 g
*Approx. 429 g
Intel®Atom™ Processor Z3745
(2M Cache, 4 cores, up to 1.86 GHz)
6400 mAh (NOM)
Model & version
①Weight
Camera
Battery
Display
Wireless
communication
8 megapixels AF (back) + 1.6 megapixels HD (front)
Size: 8 inches
Resolution: 1920 × 1200
Bluetooth WLAN 802.11 a/b/g/n, 2.4GHz & 5GHz Dual Band
GPS+GLONASS *LTE, WCDMA, GSM
①Depending on the measuring method, the weight might vary slightly.
* Your YOGA Tablet 2 supports LTE Band 1, 2, 3, 4, 5, 7, 8, 19, and 20. But In
some countries, LTE is not supported. To know if your YOGA Tablet 2 works
with LTE networks in your country, contact your carrier.
*Version: LTE
CPU
YOGA Tablet 2
Version: WLAN
Android
*Model: YOGA Tablet 2-830L
Model: YOGA Tablet 2-830F
System
Version: WLAN
Model: YOGA Tablet 2-1050F
*Version: LTE
*Model: YOGA Tablet 2-1050L
Approx. 619 g
*Approx. 629 g
9600 mAh (NOM)
Size: 10.1 inches
Resolution: 1920 × 1200
*Version: LTE (Voice)
*Model: YOGA Tablet 2-830LC
*Version: LTE (Voice)
*Model: YOGA Tablet 2-1050LC
Technical specifications

5
10
Micro USB
2
6
3
789
4
1
11
On/Off button/
Flashlight
Speakers Microphone
Volume button
Earphone jack Kickstand
Back camera microSD card slot
*Micro SIM card slot 12
Hanging hole
① This dimension only refers to YOGA Tablet 2-830F/YOGA Tablet 2-830L/YOGA
Tablet 2-830LC.
② This dimension only refers to YOGA Tablet 2-1050F/YOGA Tablet 2-1050L/YOGA
Tablet 2-1050LC.
The WLAN model (YOGA Tablet 2-830F/YOGA Tablet 2-1050F) does not have a
Micro SIM card slot.
!!! DO not insert your finger into the hanging hole. Doing so might hurt your finger.
①
210.4 mm
②
255.4 mm
1
3
4
5
①148.9 mm
②
183.3 mm
5
2
6
78
10
121
11
21 mm
②
7.2 mm
①
7.0 mm
②
3.0 mm
①
2.7 mm
9
First glance
Front camera

You can use cellular services with the LTE model (YOGA Tablet 2-830L/YOGA Tablet
2-830LC/YOGA Tablet 2-1050L/YOGA Tablet 2-1050LC) by inserting the Micro SIM card
provided by your carrier.
Install the Micro SIM card and the microSD card as shown.
Step 1. Lift the kickstand.
Step 2. Open the card slot cover.
Insert the Micro SIM card
and microSD card and then
install the card slot cover back.
Step 3. Push back the kickstand.
Only Micro SIM card works with your YOGA Tablet 2.
!!! DO not insert or remove the Micro SIM card while your YOGA Tablet 2 is turned
on. Doing so can permanently damage your Micro SIM card or YOGA Tablet 2.
Preparing your YOGA Tablet 2
