Lenox LX User manual
335 CROOKED HILL RD.,
BRENTWOOD, NY 11717
1.631.243.3336
LENOXPEDICURECHAIR.COM
1.631.243.5300
WWW.PEDISPAFIX.COM
LENOX SERVICE & ORDER PARTS
Copyright 2010 by LENOX
Printed in USA
USER MANUAL
LENOX LX
TABLE OF CONTENTS
Safety Instruction
User Recommendation
Limited Warranty
Maintenance and Cleaning
Spa Information
Specication
Identication
Dimension
Drain Instruction
Optional Discharge Pump
Motors
Standard Motor
Optional Motor
Optional Auto-Fill
Chair Installation
Massage Mechanism
Remote Instructions
Troubleshooting
Back Flow Protection Device
Registration
3
6
7
9
12
14
15
16
17
18
19
21
22
23
25
26
27
28
LENOX.,
THE SOURCE FOR PEDICURE SPAS
WELCOME
Here at LENOX., We’re committed to making OUR VALUES come alive in the
work that we do and the products we create. That said, every LENOX Pedicure
Spamakesastrikingrstimpression-designedtobeasfunctionalastheyare
beautiful. It’s important to note that our pedicure spa units must be installed,
handled and cared for by licensed professionals, in whichever respective
eld.Whetheritbeplumbing,electrical,and/orbeauty,thepedicurespaunits
should in no circumstance ever be handled by an unlicensed professional.
We sincerely thank you for your support.
IMPORTANT USER INSTRUCTION & SAFETY NOTICE.
KEEP SAFE!
• The maximum recommended weight of LENOXPedicure Spas is 250 LBS.
• Keep all ELECTRICAL DEVICES away from the pedicure spa.
• Enter and exit the pedicure spa with caution.
• Do not stand in the pedicure basin
• The water temperature should never exceed 105 F (41 C)
• The supply water temperature should never exceed 140 F (60 C)
• Always refer to state or local code to verify maximum supply temperature.
WARNING!!
SAFETY INSTRUCTION
This product in whole is in compliance with applicable UL
LISTED standards and requirements for the U.S and Canada
By Underwritters Laboratories Inc.
Some of the components of this product are also in
compliance with applicable safety standards of following:
-4-
IMPORTANT USER INSTRUCTION & SAFETY NOTICE.
KEEP SAFE!
ELECTRICAL NOTICE
In order to ensure proper use, a separate 120v 60HZ 15amp(per dedicated outlet)
GFCI protected grounded circuit must be used to supply power to each pedicure spa.
Failure to do so renders the Limited Warranty void.
**PEDICURE SPAS outside the US must be in accordance with the respective country’s
rules and regulations. For example, if installed in Canada, the pedicure spa must be in
accordance with the Canadian Electrical Code Part1.
GROUNDING AND GFCI NOTICE
STOP! PLEASE READ PRIOR TO INSTALLATION AND USE!
When using electrical products, basic precautions should be followed:
1. Risk of electrical shock. Connect the pedicure spa only to a circuit protected by a ground-fault circuit-inter-
rupter.GFCI)
2. Every EMPRESS Pedicure Spa must be installed by your local, licensed plumber and licensed electrician
to install your new spa. Installation MUST be in compliance with all local and state building codes.
3. Yourpedicurespacannotoperateefcientlyorsafelyunlessitisprovidedwithadequateelectricalpower,
sufcientwaterpressure,properwatertemperature,andrequireddrainagecapabilities.
4. Contact your local building inspector for information and local code compliance procedure that need to be
followed when having your new pedicure spa installed.
5. Subsequent inspections and approvals that may be required are the responsibility of the purchaser.
STOP! PLEASE READ PRIOR TO INSTALLATION AND USE!
TO REDUCE THE RISK OF BURNS, ELECTRIC SHOCK, FIRE OR INJURY:
1. Only authorized operators are permitted to use the pedicure spa.
2. If the pedicure spa has a damaged cord or plug, do not use.
3. Keep all electrical cords away from heated surfaces.
4. Do not operate outdoors.
5. You are responsible to ensure that all plumbing connections meet national, state and local code.
6. Shut-off valves are strongly recommended.
7. The water temperature should be adjusted accordingly.
Shipment Inspection
Examine the components immediately upon arrival to make sure no damages to the pedicure spa base and
chair during the shipment. It is very important that you notify the driver directly and notation should be on the
face of the freight bill or bill of lading of any damage. Failure to note damage on the bill of lading may prevent
any claims you may have against the carrier.
If concealed or damage is found, you MUST notify the carrier at once and request an inspection. DO NOT DIS-
CARD THE SHIPPING CARTON If receiver sign the carrier clean receipt of goods that have been damaged in
transit .Do so at your own risk and expense.
Please print this page for your review and reminder.
SAFETY INSTRUCTION
Important Installation Considerations
Electrical Service
110V, 60Hz, 15Amp GFCI protected grounded circuit MUST be used to supply power each individual
pedicure spa. And the main circuit breaker MUST be at 25Amp. For maximum of two units per each
electrical outlet.
Water Supply
All plumbing connections must conform to local, state, federal codes.
Water supply to the spa should be provided with adequate water pressure and water temperature.
Water Pressure
Tollthebasincorrectlyuptolevel,Normalwaterpressureof30to80P.S.Iisrequired.
Water temperature
The hot water supply temperature must not exceed 140 . Adjust your hot water accordingly. For hot
andcoldwatersupplyttingsanddrainttingslocation,seedraindiagram.Carefullyconnectthewater
supplylinetotheappropriatettingslocatedontherearofthepedicurespa.
Pressure / Temperature
Maximum Pressure: 150 psi (10 bars)
Minimum Pressure: 10 psi (69kPa)
Working Temperature: 33F to 140F constant; intermittent to 180f
(0.6C to 60C sustained; intermittent to 82.2C)
Recommended Flow: 1.5gpm .
UL LISTED / CE CERTIFIED
Compliance with following Code (s): Uniform Plumbing Code, National Plumbing Code of Canada
andinternationalPlumbingCode.Also,CompliancewithfollowingStandard(s):ASMEA112.18.3M/
A112.18.1M,CSAB125,NSF/ANSI61/372
All EMPRESS USA products has been investigated for compliance with the requirements for water
retentionforWhirlpoolbathtubappliancescontainedinASME/ANSIA122.19.7M(1995),CSAC22.2
No. 68-69
ANSI - American National Institute, ASME - American Society of Mechanical Engineers, CSA - Canadian
StandardAssociationIAPMO- InternationalAssociationofPlumbing andMechanical Ofcials,UL-
Underwriters Laboratory
** Back ow Protection Device
DuetoTownand/orStaterequirement/sarevariesinbuildingcode,iftheTownand/orStaterequires
specicVacuumBreaker,AsthePlumberMUSTprovideVacuumBreakeraccordingtobuildingcode
Installation Summary
Alicensedplumber/ElectricianMUSTinstallthePedicureSpaconformandcomplywithlocal,State
and Federal building code. where applicable.
Note: Failure to comply with federal, state, or local codes and ordinances will result in warranty
being nullied and void.
Drain Facilities
The pedicure spa Drain must meet local plumbing codes. Check valve for Drain (not Provided) Must
be installed by a licensed plumber.AlsoPedicurespamustbesecurelyfastentotheoor.
Please print this page for your review and reminder.
SAFETY INSTRUCTION
(Utility Valves)
Check and
-6-
PLEASE READ THE MANUAL THROUGHLY BEFORE USE TO ENSURE CORRECT OPERATION.
THOSE UNDER A DOCTOR CARE OR WHO ARE EXPERIENCING
ONE OR MORE OF THE FOLLOWING CONDITION SHOULD
CONSULT THEIR DOCTOR BEFORE USE.
- You are receiving medical treatment or are feeling ill.
- Your body shows any cute symptoms.
- You have heart disease.
- You are pregnant or having a menstrual period.
- Your doctor has ordered you to rest.
- You have a back disorder resulting from an accident or disease
- You have high fever.
- You have sensory disorders.
- You have medical electrical device (e.g. pacemaker).
- You have service interruption in the circulation of the legs.
- You have an open wound.
- You are diabetic.
User Recommendation
FAILURE TO DO SO MAY RESULT IN ACCIDENTS AND HEALTH PROBLEMS.
LENOX PEDICURE SPAS Limited Warranty (1/2)
To validate the limited warranty, The Limited Warranty Registration Form MUST be lled out
completely and return to LENOXwithin 30 days of original purchased date. This Limited Warranty
is valid if LENOXreceived registration form.
LENOX. Pedicure Spas has designed and manufactured with the highest standards and expressly
warrant the pedicure spa as follows:
To the original owner of the LENOX. Pedicure Spa may repair or replace, at its option, any pedicure
spa found to be defective in material or workmanship upon inspection by a authorized representative of
LENOX. This limited warranty covers the following:
Base - Twenty four (24) month from date of shipment from LENOX facility.
Components / Parts - Twenty four (24) month from date of shipment from LENOX facility.
Stool - Ninety (90) days from date of shipment from LENOX facility.
Shipping Costs - Twenty four (24) month from date of shipment. LENOX will cover normal
shipping costs associated with replacement parts. Expedited shipping cost will incur an additional
charge.
Labor - Twelve (12) month from date of shipping, LENOX will cover reasonable labor costs
associated with the installation of replacement parts found to be defective in material or
workmanship upon inspection by authorized representative of LENOX.
No labor cost or replacement parts will be covered under this limited warranty if at the
sole discretion of LENOX. It is determined a failure was caused by negligence, accident or
improper use, improper installation or lack of proper maintenance as in the Owner’s Manual.
NO CONSEQUENTIAL, INCIDENTAL, CONTINGENT, INDIRECT, SPECIAL OR OTHER
DAMAGES WILL BE ALLOWED.
This warranty is null and void if the pedicure spa is removed from its original installation or is not
installedaccordancewithspecicationsofpedicurespaornational,stateorlocalcodes,regulation
and ordinances. Furthermore, this limited warranty is null and void if the pedicure spa is subjected
to improper installation or maintenance, negligence, improper cleaning or any other circumstance
beyond J&A’s control. To validate limited warranty, pedicure spa must be installed by a licensed
plumberand/orelectricianinaccordancewithlocaland/orStatecodeandpedicurespainstallation
instructions.
Warranty Exclusion
1-Unauthorizedrepairsand/ormodicationortamperedinanyway.
2-Damageduetofreight,accident,naturaldisasterand/orabuseormisuse
3- Stain, fading or discoloration of seat, back cover, armrests ( Upholsteries), Tray or Footrest
4- Fading, discoloration or staining of basin or Any portion of surface of pedicure spa caused by
wateradditiveorimproperWatertreatment(suchcalciumbuiltup)and/orcleaningagents/s
5- Damage or malfunction due to improper installation including but not limited to, failure to comply
with all national, state and local plumbing, electrical and building codes.
6- Magnetic jet assembly (base, impeller and cover) due to LENOXprovided an extra jet assembly
to accommodates wear-tear.
7-Damagedrainpumpduetoresiduebuiltupindrainpipeand/orduetothelackofmaintenance.
IMPORTANT
LIMITED WARRANTY
USER RECOMMENDATION
-8-
Partsforwhichlabor/Serviceis NOT COVERED - Following components
are simple to replace and DO NOT require a service technician. Therefore,
though the part is covered under the guidelines of the warranty agreement.
1- Panel
2-Jetcover,impellerand/orjetassembly
3- Faucet Cartridge, Shower Head
4- Footrest
5-AiractuateOn/OffButton
6- Drain Plug
7- Remote control
During the Limited Warranty period, LENOX will, at its sole discretion, repair or replace any defective
component. All component parts removed under this Limited Warranty become property of LENOX.
Andallreplacementcomponent/sMUSTbereturntoLENOX.Within20daysofreplacement.Ifnot,
replacedcomponent/swillbechargeasitscost/s.
This limited warranty is for the original owner and not transferable. The original owner agrees by using
pedicure spa the obligation of LENOX shall not extend to indirect or contingent damage or injury.
Furthermore, the obligations of LENOX are limited to those set forth herein. The limited warranty is the
exclusive remedy and is in lieu of all other warranties, express or limited, including but not limited to,
anyimpliedwarrantyoftnessormerchantabilityforaparticularpurpose.Nodistributororotherperson
has the right or authority to bind LENOX to changes to this limited warranty. Consequently, LENOX is
not responsible for such warranties or representations.
TO THE EXTENT ALLOWED BY LOCAL LAW, EXCEPT FOR THE OBLIGATIONS SPECIFICALLY
SET FORTH IN THIS WARRANTY STATEMENT, IN NO EVENT WILL LENOXOR ITS THIRD PARTY
SUPPLIERS BE LIABLE FOR ANY DAMAGED CAUSED BY LENOX’S PEDICURE SPA OR THE
FAILURE OF LENOXPEDICURE SPA INCLUDING ANY LOST PROFIT OR SAVINGS, BUSINESS
INTERRUPTION, LOSS OF USE OR ANY OTHER COMMERCIAL OR ECONOMIC LOSS OF ANY
KIND, OR SPECIAL, INCREMENTAL, OR CONSEQUENTIAL DAMAGES. THIS LIMITATION OF
LIABILITY APPLIES WHETHER DAMAGES ARE SOUGHT, OR A CLAIM MADE, UNDER THIS
LIMITED WARRANTY OR AS A TORT CLAIM, A CONTRACT CLAIM OR ANY OTHER CLAIM.
Limitation of liability
LENOX PEDICURE SPAS Limited Warranty (2/2) USER MAINTENANCE INSTRUCTIONS CLEANING AND
DISINFECTING YOUR PEDICURE SPA
Note: Please be advised that it is responsibility of purchaser/user to adhere strictly to the
following procedure. Any non-compliance will be considered negligence of the purchaser/user.
The Bureau of barbering and cosmetology requires that salons using whirlpool pedicure spas use
the following disinfecting Procedures to ensure proper cleaning and maintenance of the equipment,
and to prevent bacterial infection. For your clients safety, always use the regulations as a minimum
standard for cleaning and disinfecting.
Chair maintenance: Please see chair manual for Do and Don’t
A SPECIAL NOTE PERTAINING TO BLEACH
While bleach seems to be used extensively for cleaning and disinfecting of pedicure chair ba-
sins, it is NOT recommended nor is it effective. Moreover, excessive use of bleach may greatly
reduce the longevity of your pedicure chair internal components (i.e. pumps, jet waste assem-
bly, etc.). Excessive and repeated use of bleach may also void your warranty. As always, you
are required to check with your state board for mandatory cleaning and disinfecting require-
ments and procedures.
At the end of the day:
1. Remove the intake suction screen, All debris trapped behind the screen of each pedicure spa must
be removed. And the screen and the inlet shall be washed with soap or detergent and water
2. Before replacing the screen, Totally immersed the screen into an EPA- registered disinfectant with
bactericidal, Fungicidal, and virucidal activity.
3. Finally,ush thewhirlpool system withlow-sudsing detergentand warmOR anEPA -registered
cleanser for 10 minutes. Rinse with clean fresh water and drain.
Note:
Cleaning or sanitizing is NOT disinfecting. According to the CDC and EPA, disinfecting occurs only
when there is a reduction of pathogenic microbes at 99.999%. Sanitizing is a only reduction of 99.9%.
Cleaning of whirlpool pedicure spa requires surfactant and chelating detergents that are low foaming
and have ability to remove body oils, organic oil additives, mineral oil, skin cell, nail clippings, etc.. That
can accumulate both in the basin and the jets which may become fertile area for micro organism to
grow.
Note:
The use of oil based products can build up in the whirlpool system causing clogging in the jet and
build up onto the surface of the basin. Adherence to the above cleaning will minimize build up thus the
manufacturer recommend not to use mineral oil based product.
MAINTENANCE & CLEANING
LIMITED WARRANTY
-10-
Maintenance and Cleaning of PU Synthetic Leather
PU synthetic leather is made from polyurethane resin after coating, dry-
ing and curing. Compared with the genuine leather, PU synthetic leather
is more resistant to acid, alkali, heat and sunshine. However, because
of its own physical and chemical properties, it should not be put at the
place where there is dust, high temperature, high humidity, low tem-
perature or strong sunshine and the environment containing acid and
alkali agent and solution. Otherwise, it will be easily cracked, quickly
aging and hydrolyzed.
Cleaning methods of PU synthetic leather and precautions:
Maintenance methods of PU synthetic leather and precautions:
1. Good room ventilation should be ensured because too dry or too wet environment will fasten the
aging of leather.
2. Leather sofa should avoid direct exposure to sunshine or air-conditioner wind; otherwise the leather
surface will become hard. Direct exposure to sunshine will make the leather with color faded.
3. There is more sweat on body during the summer the hole of the leather will absorb the sweat. The
organic matter in the sweat and the leather will have a chemical reaction during high temperature
and wet environment, and there will be peculiar smell. For this, wettish soft cloth should be used for
wiping frequently.
4. While wiping the sofa, the alkali cleaner should not be used because there is acid treatment during
leather making and the alkali will decrease the pliability of the leather and there will be crack if the
alkali cleaner is used for wiping the sofa.
1. Organic agent, grease solution and compounds, especially the strong solvent, e.g. alcohol,
turpentine, thinner can not be used for cleaning the PU surface and otherwise the PU surface will be
easily corrosive.
2. Fresh water or washing powder can not be used for cleaning the PU surface or there will be cracks.
3. Environment-friendly detergent which is containing no abradant and with a PH value of 5-7 should
be used for cleaning the PU surface.
4. For the quite dirty PU surface, use a soft cloth with egg white to wipe the dirt, brush should not be
used for cleaning the surface.
5. The more popular detergents in the market are: Meipingwang leather detergent and protective
agent; Amway leather detergent, etc.
6. For the best result for maintaining your PU synthetic leather please inquire Empress for Spa
Leather Cleaner.
7. Fabric inside liner and fabric padding MUST be check quarterly for the best result. In case of
warn out please contact service department for replacement.(Worn and tear is not covered under
warranty)
Glass Bowl Care and Cleaning
Care and Cleaning
Clean the surface of your JSG Oceana glass product with mild soap and warm water. Wipe the entire
surface completely dry with a clean, soft cloth.
MANUFACTURER’S RECOMMENDED DRAIN INSTALLATION
Drain installation requirements will vary by supplier basin and unit. Manufacturer’s drain installation
instructions suggest to apply plumber’s putty under rim of drain and hand-tighten drain only.
DO NOT OVER - TIGHTEN.
JSG Oceana Glass products are warranted free of manufacturing defects. JSG Oceana LLC will, at
its election, repair, replace, or make appropriate adjustment where JSG Oceana LLC inspection
discloses any such defects occurring in normal usage within one year after installation. JSG Oceana
is not responsible for installation or removal costs. Proof of purchase requires the original sales receipt
from the original consumer purchaser and must accompany all warranty claims.
Implied warranties, including that of merchantability or ttness for a particular purpose, are
expressly limited in duration to the duration of this warranty. JSG Oceana LLC disclaims any
liability for special , incidental or consequential damages.
**Some States do not allow limitation on how long an implied warranty lasts or the exclusion or limitation
or special, incidentals, or consequential damages, so these limitations and exclusions may not apply to
you.Thiswarrantygivesyouspecicrights.Youmayalsohaveotherrightswhichvary
state to state.
ThislimitedwarrantyprovidesspeciclegalrightsastheyapplywithinU.S.A,andotherrightsmaybe
available, but may vary fro country to country.
Crystalline material and air bubbles are a unique characteristic of art glass. They are an inherent
part of the glass making process and are not detrimental to the mechanical strength or function
of the glass basins. Each piece of JSG Oceana is individually inspected for durability and
superior performance.
MAINTENANCE & CLEANING
EXCLUSIVE WRITTEN WARRANTY
LIMITED ONE - YEAR WARRANTY
MAINTENANCE & CLEANING
Lenox
bold and capital
-12-
Capacity of Tub 5 US Gallon
Power Source
115Vac. 3.2 Amp, 60Hz.
120Vac. 3.12 Amp. 60Hz. 75W
Dedicated 15Amp GFCI Protected Ground Outlet
Magna-Jet Pipeless
Massage System
Plumbing Hot Water
Cold Water
Drain
0.5inches (Fitting Provided)
0.5inches (Fitting Provided)
1.5inches (See Plumbing Instruction)
See detail in warranty page.
Warranty
Switch On/OffAirActivatedSwitch
Dimension & Weight
(Shipping)
Lenox Pedicure Spa
Stool
37”W x 67”L x 40”H
27.25”W x 20.25”L x 17”H
285 lbs
20lbs
Lenox LX: Specication
Wall
** All LENOXproducts are equipped with Back Flow Prevention Device Dual Check Valve
••Duetocontinuousimprovementonallourproducts,followingsaresubjecttochangewithoutnotice:specication,characteristics,packing,information,coloranddesign
WARNING: Failure to comply with federal, state or local codes and ordinances will result in
warranty being null and void.
As stated, the pedicure spa installation must comply with all plumbing and electrical codes. A licensed
plumber and licensed electrician MUST complete the applicable connections of the pedicure spa.
Location and support: Selectalevellocation.Theoorstructurebeneaththepedicurespamustbe
capable of supporting the occupied pedicure spa.
For the seat back to fully recline, the pedicure spa base must be mounted as follow from the wall as
shown below:
Installation Specications Summary
**Due to continuous improvements on all our products, specication, characteristics, packing, color, designs
are subject to change without notice.
**When chair slide all the way back - would require 14 inches from the wall
Wall
See detailed info
on top of the page
SPA SPECIFICATION
SPA SPECIFICATION
-14-
Lenox LX: Identication
Drain Handle
Sequential Light
Drain Plug
Sequential Light
Folding Manicure Tray
Magnetic Pipeless Whirlpool Pump
Replaceable Backrest
Embedded Remote Control
Pillow
BASIN
Independent Height Adjustable
Footrest Cushion
Borosilicated Glass Bowl
On/OffPresstoAirCompress
Activated Power Switch
Easy Access
Up & Down Armrest
Independently Operate
Slide/Recline(2ndRemote)
Single Lever Faucet
Pull to Ajusted Height
Dual Functional
Shower Sprayer
**Due to continuous improvements on all our products, specication, characteristics, packing, color, designs
are subject to change without notice.
AUTO
HIGH
MID
LOW
FULL
PARTIAL
SPOT
30
20
10
POSITION
RANGE
MANUAL
MASSGAE
INTENSITY
WHEE L
DN
AUTO
KNEAD
COMB
TAP
VIB
KNOCK
MSG
WIDT H
VIBRATION
INTENSITY
UP
Wall
81/2” 211/2”
LENOX. /Side LENOX LX LENOX.
Manufactured by: Prepared by:Model & Dimension:
Lenox LX: Dimensions
SPA DIMENSION
81/2”
24”
261/2”
31/2”
3/4”
13”
15”
27”
131/2”
411/4”
16”
54”
15”
63/4”
121/8”
SPA IDENTIFICATION
-16-
Rear View
Lenox LX: Drain
Basement Connection
(NOT recommended
onoordrain)
Power Drain
(See detailed power drain pump)
Wall Drain
Hot&ColdWaterInlet:1/2”
Drain Outlet: 1 1/2” PVC Pipe
Drain
Cold
Hot
Drain outlet MUST be 1/2”
or 3/4” for efcient drainage.
Check Valve Required
PLUMBER MUST BE UTILIZED TO INSTALL
CHECK VALVE
Pipeless Motor
Power Plug
(Small Rubber Coupling)
3/4”Elbow
3/4PVCPipe
3/4”PVCPipe
Hanning DPO 40-020
Air Check Valve
Elbow
Rubber Gasket
ClearTubing3/4OD1/2”ID
Large Rubber Coupling
PolyInsert90Elb1/2”
Tee3/4x3/4x1/2
3/4”PVCPipe
(Large Rubber Coupling)
3/4Slipx1/2”MaleAdapter
Light
Transformer
Part Time
Part Time
Full Time
3/8”Cleartubefromon/offforD/P
pump insert into 2 Min. Timer.
Make sure to push in tightly.
2 Min. Timer
(D.pump)
Installation Instruction:
1. Makeahole(size1-3/8”)fortheOn/Offswitchasshown(seeg1).Pre-dril
required.
2. Placeda1/8”clearhoseintotherearoftheswitchandon/offswitchintothe
hole.
3. Thedischargepumpkitismadetotontothepedicureunit.(Seeg2)
4. Connect E-Z connector onto the drain elbow.
5. Plug discharge pump outlet into the two minute timer outlet
6. Plug two minute timer into the wall outlet.
7. It is very important that tip of the clear tub remain above the water Level with
one loop as shown.
Operation Instruction:
Warning ! DO NOT RUN DRY
1. Turn to open drain plug. 3 to 5 second for air to release from the pipe
2. PressOn/Offswitchtoactivatetimer.
3. At any time, water drain completely from the basin. Press
On/Offswitchtostoporbuiltintwominutetimer.
Lenox LX: Discharge Pump (Optional)
Up to 4ft @ +/- 39 sec. with 1/2” Connection to main drain
Power Plug
Fastener
On/Off
Switch
1-3/8”Hole
forOn/OffSwitch
Figure 1
Figure 2
OPTIONAL DISCHARGE PUMP
Power Plug to
Wall Outlet
DRAIN INSTRUCTION
Air breather(check Valve)Must be
above the water level.
-18-
Safety Instructions:
When using electrical equipment, basic safety precautions should always be followed to
reduce the risk of re, electrical shock, and injury to persons, including the following:
1. Read and follow all instructions before using the equipment.
2. Keepthecordoutofheavytrafcarea.ToavoidrehazardNEVERputthecordundertherugs,nearheatgenerating
devices.
3. Always turn off the equipment before servicing.
4. Do not drop or insert any object into any openings.
5. Do not operate any equipment with a damage parts.
6. Any other use not recommended by the manufacturer may electrical shock or injury to persons.
7. Never use outdoors
8. Do not attempt to repair or adjust any electrical or mechanical functions on the unit.
Features:
1. Dual powerful massage jet-streams
2. Jet assembly can be attached from the pump for
quick cleaning and sanitizing.
3. Thermally Protected
4. AC motor (long life)
5. Extremely low power consumption .
Cleaning Instruction:
1. Turn the unit off and wait until the motor is fully stops.
2. Remove the front jet cover and notice the locking screw in the center
3. Remove the locking center screw (Indicated an Arrow) and pull out impeller from housing.
4. UseAnti-Bacterialsolution(EPARegistered)tocleanallpart/s.
5. After sanitization, place impeller onto the motor shaft and fasten with center locking screw ( Opposite arrow)
Ultra Pipeless Jet Whirlpool Motor Specications:
Model: CS-0216A-MT
Rating:120VAC/60Hz,0.4A-thermallyProtected
Pump: Dual whirlpool Jet Flow
Mounting:Single3.5”holeDiameter
Auto tighten Mounting screws(4)
Ultra Jet Whirlpool Motor
TOP
TOP
Close Jet Cover
1. Align an arrow line
2.Turn to right (Top indicated)
Safety Instructions:
When using electrical equipment, Basic safety precautions must be followed to reduce the
risk of re, electrical shock, and injury to Persons.
1. Read and follow all instructions before using the equipment.
2. Keepelectricalcordoutofheavytrafcarea.ToavoidrehazardNEVERplaceelectricalcordundertherug,nearheat
Generating devices.
3. Always turn power off the equipment before service.
4. Do not drop or insert any object into any openings.
5. Do not operate any equipment with damaged parts.
6. Anyotherusenotrecommendedbythemanufacturermaycauseelectricalshockorcauseinjurytoperson/s.
7. Never use it outdoors
8. Do not attempt to repair or adjust any electrical or mechanical.
MAGNA JET Features:
1. Hydro dual massage jet stream
2. Magnetic whirlpool jet cover can be remove for
quick cleaning and sanitizing.
3. Built-In electronic sensor for pump control.
4. AC Whirlpool motor (long life)
5. Very low power consumption (27W)
6. Manufactured in USA.
Cleaning Instruction:
1. Turn off the unit and wait until the motor is fully stops.
2. Holdhydrowhirlpooljetcoverrmlyandpulltoseparatefromtheroundmagneticeld.
3. Turn hydro whirlpool jet cover to left to open and pull out impeller.
4. Use Anti - Bacterial solution (EPA Registered) to clean all parts.
5. After sanitize all parts, place impeller and close hydro whirlpool jet cover to turn right to lock
6. Holdrmlythewhirlpoolcoverjetandgentlyplaceitontotheroundmagneticeld.Donotreleasethehydrowhirlpooljet
cover until jet cover is on the round magnetic housing.
MAGNA-JET Specications:
Model:MAGNA-JET-120 VAC, 60HZ, 1.0Amp
Pump: Hydro-Massage Dual Air Jet Flow
Mounting:Single3.5”HoleDiameterAutoTightenMountingScrews(4)
Motor
Round Magnetic Field (housing)
Magnetic
Jet Base
Magnetic
Impeller Magnetic
Whirlpool Jet Cover
Magna-Jet (Optional)
OPTIONAL MOTOR
STANDARD MOTOR
-20-
WARNING: DO NOT RUN DRY, BASIN MUST FILLED WITH WATER TO LEVEL INDICATOR.
CAUTION: MAGNETIC JET COVER ASSEMBLY MUST ALIGN WITH DISCHARGE PORT
POSITIONED AT 3/9 O’CLOCK.
When Ready to use, MAKEsurejetcoverispositionedat3/9O’clockforproperwhirlpool
actioninthebasin.Ifjetcoverisnotalignat3/9O’clock,waterwillsplashoutsideofthe
basin.
Proper way to use Magnetic Jet System:
1. Fill the water to water level indicator.
2. HoldMagneticJetrmlytobringclosertotheroundmagneticledanddonotreleasetheMagneticJetprematurelyor
thiswillcauseimpactsonthejetcoverandtheroundmagneticeld(housing)shorteningthelifeexpectancyofthejetcover.
Whenthejetcovernearstheroundmagneticeld,placejetcoverontothefourdimplearea(seediagram).Thejetcover
mustalignwithdischargeportspositionedat3/9O’clock.
3. Whennishedwithclient,DONOTremoveMagneticJetuntilmotorisfullystopped.
4. When motor is fully stopped, remove Magnetic Jet cover from the motor and remove jet cover and impeller for sanitation.
Motor
Round Magnetic Field (housing)
Magnetic
Jet Base
Magnetic
Impeller
Magnetic
Whirlpool Jet Cover
Bottom View of
Magnetic Jet Base
How to USE Magnetic Jet!
a. Automaticspallswithintelligentandreliablelevelsensor.
b. Time delay setting
c. Dualswitchedoutlets/Controlbox
d. Dual continuous outlets
e. Single drain pump controlled outlet with 3 minute timer (If drain pump requested as an option)
f. Heavy duty water valve
g. Operated in automatic or manual mode
i. Built in LED light power supply
j. Audibleoverowwarninginmanualllmode
J&A US A
iFill-Auto
Auto Fill System (Optional)
Feature & Operation
Dura Jet III Built - in
Electrodes Water Sensor
PressiFIll-Autotostartllthebasinand
once reaches water level
Whirlpool/lightwillbeactivated.
ManualOn/OffWater
ManualOn/OffSwitch
for Jet & Light
Time Delay Setting
Power On Indicator
Continuous Outlet (2 Amp)
ALL WIRES ARE INDICATED AS IT SHOWN
Drain Air Switch
Key Pad
Level Sensor
water Valve
12 AC Light Auto Fill
Delay
Setting
Key Pad
Level
Sensor
Water
Valve
12 VAC
Light
Cont (2A)
iFill Delay
Setting
Power Cord
Power
LED
Drain (2A)Jet (2A)Light (2A)
Power Cord
Cont (2A)
INSTRUCTION
Water faucet MUSt be ON and desirable
temperature must be set with faucet handle before
using AUTO-FIll System.
1-PresstheiFill-Autobuttonwillllthebasinwith
water automatically.
Water valve will shutoff when water level is above the
sensor.
2-ProcesstheJETbuttonwillturnOn/OfftheJETand
LED light manually.
3-ProcessingthevalvebuttonwillturnOn/Offthe
water manually.
OPTIONAL AUTO FILL
OPTIONAL MOTOR
-22-
Detachment of Backrest
• Pull latch lever upward to release from recliner piston.
• As arrow indicates, bring backrest to fold onto the seat.
• Disconnect all cables (recliner, slider).
Attachment of Backrest
• On the lower portion of both side of the backrest, there are pivots.
• Alignbothpivotscorrectlysotheyrestperfectlyontothe“U”pivotframe.
• Oncebothpivotssitsnuglyonthe“U”pivotframe,alignthereleaselatchwiththe
recliner piston and snap close.
Before operating the chair upon attachment, check following items to
ensure proper operation
Figure1:Showspivotand“U”pivotframeatcorrectalignment/besuretoclearwire
Figure 2: Close-up view of pivot and “U’ pivot frame.
Figure 3: Shows correct pivot alignment.
Pull latch upward to release
Unlock the hook by pressing latch
from recliner piston to pull out insert
The pivot of back insert is removable
Placing Backrest in Correct Position Lenox LX: Massage Mechanism
MASSAGE MECHANISM
Chair Main Frame
Massage Mechanism Frame
Mechanism Limited Frame Bar
Kneading Belt
Belt Pulley
DC Motor(Kneading)
Massage Arm Extenstion
Tapping Belt
Belt Pulley
DC Motor (Travel)
DC Motor (Tapping)
Rodw/ballExtension
CASED Main PCB
Power Converter
Backrest Pivot Fastener
Philip Screws
Mechanism
Track
Guide Roller
Travel Signal
Sensor
Massage Mechanism
Frame Fasteners
(3/ea.side)
Bracket for Recline Piston
Up & Down Gear Box
Travel Belt
CHAIR INSTALLATION
-24-
HIGH
MID
LOW
FULL
PARTIAL
SPOT
30
20
10
POSITION
RANGE
MANUAL
MASSGAE
INTENSITY
WHEEL
DN
AUTO
KNEAD
COMB
TAP
VIB
KNOCK
MSG
WIDTH
VIBRATION
INTENSITY
UP
Lenox LX: Remote Control Functions
SHIATSU
1. PressManual/TimertochooseShiatsu
massage time selection.
2. Press massage range to select FULL or
PARTIAL travel position.
3. Presstappingwidthtonetunecomfort.
POWER
On/Off
BACKWARD
Press hold to move chair to
desirable position
RECLINE
Press hold to move chair to
desirable position
MANUAL
Press hold to move chair to
desirable position
WHEEL
Adjust massage wheels
up and down to desirable
position.
DN
U
P
COMB
Kneading/Tapping/Knocking
combinations.
DN
UP
TAP
3 selections of tapping
intensity.
TAP
VIB
Adjust massage wheels
up and down to desirable
position.
VIB
INCLINE
Press down to move chair to
desirable position.
FORWARD
Press down to move chair to
desirable position.
AUTO
Pre-Programed automatic
maassage with 2 selection.
POSITION
User’s height
(HIGH/MID/LOW)
RANGE
User’s height
(HIGH/MID/LOW)
KNEAD
3 Selections of kneading
intensity.
KNOCK
Impulse tapping massage.
2 selections of knocking
intensity
MSG WIDTH
Adjust massage wheels
up and down to desirable
position.
KNOCK
KNEAD
MSG
WIDTH
REMOTE INSTRUCTION
AUTO
2nd Remote Control Connetion to Main PCB
Board Holders
Travel Sensor
D/CMotors
2nd Remote to PCB
Red (Recliner)
White (Slider)
Vibration(Grn/Yel) PCB Fuse
Female Receptacle
(From PCB)
(male Receptacle) Connection
2nd Remote Control
*Installed in Front of Pedicure Spa
*Independent Operation From Primary (hand
hald) Remote
*Press Button for Desire Chair Position
* LED as Pressing Butto
Remote Control
REMOTE INSTRUCTION
-26-
Troubleshooting Guide
If there is still a problem after trying the solutions given in the troubleshooting guide, stop using the product
immediately so as to prevent accident or injury and unplug the product from the wall outlet. For technical
service, please contact LENOXtechnical support at 631-243-5300 with any issue that cannot be resolved
using troubleshooting guide.
• No water movement
•On/Offbutton-Noclicksound
•On/Offbutton-Clicksound
1-Verify unit is plugged in to live wall outlet.
2- Press reset button on the wall outlet.
3- Verify air activated tube is plugged in to black control box.
4- Ensure that the magnetic jet assembly is properly and securely attached to the basin.
• Water not Draining
• Not Draining properly
• Not Draining properly with PDP
(Power Discharge Pump)
1- Be sure Drain plug is set high enough to allow water to pass through (Gravity Drain)
2- Check for plugged drain and clear if clog is found.
3- If pump is heard, Check for plugged drain and clear if clog is found.
4- If pump is heard , Check for air lock ( see PDP in manual) follow instruction.
5- If pump is not heard, verify discharge pump is properly connected to two minute timer and to black control box.
6- If pump is not heard, verify two minute timer.
•WaterPressureislowand/ornotcomingout.
• The water sprayer is not working or very little
water comes out of the sprayer.
1- Verify if water utility valve is on.
2- Check for loose water connections under the basin and at the rear of the basin
3- Check if sprayer screen is clear.
4- Verify if water supply breaded hoses are snug and not twisted on the faucet.
• Losing water
• The basin continually loses water either quickly
or slowly
1- Check drain plug for tears in rubber gasket
2- Check drain plug height is correct and bolt below plug is tight.
3- Verify drain strainer is tight.
4- Verify if water level is correct.
• Noise during operation
• During tapping and kneading.
• Sound of roller squeaky rubbing against cover.
• Clatter during normal operation.
• Vibrating mechanism noise.
• Sound of recline or slide mechanism.
These noises are a normal part of the product’s operation and do not effect its performance in any way.
• Remote control do not work properly.
• Remote control working with out power light.
• Remote control with power light and not working
properly
1- Verify connection if fully plugged in.
2- If chair is not return to normal, stop using the chair and unplug it from the wall outlet.
Contact the vendor or LENOXservice for assistance.
• Massage stops in the middle of the program Reset the main power switch located at the rear of the chair to OFF and back ON after about 5 second.
1- if the chair return to normal, No further action is required.
2- if the chair does not return to normal, stop using the chair and unplug it from the wall
outlet. Contact the vendor or LENOXservice for assistance.
• The roller stop during the massage Sometimes when the speed is slow than a normal and there is too much pressure to the
rollers, it may stop moving temporarily.
This is not breakage. Just release pressure by lift body weight.
• The roller moved up or down and then stop. Auto timer will cause the rollers to move up to the top of the chair and sometimes roller pass secondary stopper and
causes mis-alignmentation of the roller.
1- contact vendor or LENOXservice for assistance.
• The right and left rollers are out of alignment. The rollers are designed to provide for alternating tapping function, So in the stopped position it seems they are out of
sync. This is part of the design, and there is nothing wrong with product.
• Reclining and sliding cannot be perform Check to be sure there are no objects between the seat back, where moving mechanism .
This unit has maxium weight capacity of 225 lbs.
Back Flow Protection Device
(Dual Check Valve)
J&A USA Inc.
335 Crooked Hill Road
Brentwood, NY 11717
Tel: 631.243.3336
Fax: 631.243.3339
www.jausainc.com
May.1.2014
In accordance with applicable Local or State regulations,
J&A USA Inc., The manufacturer of the pedicure whirlpool spa certifies that the following models are
equipped with factory installed Dual Check Valve back flow preventer:
** Lenox Series
** Cleo Series
** Episode Series
** Pacific Series
** Petra Series
** Toepia Series
The specification of the installed device is as follows:
DEVICE NAME DUAL CHECK VALVE BACKFLOW PROTECTION
DEVICE
MANUFACTURER
NEOPERL INC.
Waterbury CT.
DEVICE MODEL Dual Check Valve 1/2” x /2”NPT
DEVICE
SPECIFICATION
TESTED AND CERTIFIED TO MEET NSF/ASSI 61
Complies with ANSI/ASME A112.18.3M, A112.18.1M
AND CSA B125
DEVICE
PRESSURE
MAXIMUM PRESSURE: 150 PSI (10 BAR)
SERVICE PRESSURE : 80 PSI
DEVICE
TEMPERATURE
MAXIMUM TEMPERATURE : 150F
SERVICE TEMPERATURE : 90F
ALL MODELS OF PEDICURE SPAMENTIONED ABOVE ARE EQUIPPED WITH THE SUBJECT DEVICE
AS STANDARD FEATURE. As for your information, indicated State requires Vaccum Breaker.
** Effective April 01 2005:
ARIZONA, CALIFORNIA, NEBRASKA, NEVADA, OREGON,
TEXAS AND WASHINGTON
** Effective June 15 2005:
ILLINOIS, MINNESOTA, WISCONSIN, MICHIGAN
** Effective May 01 2007:
CONNECTICUT
For additional information, Please contact us at 631-243-5300
Very Truly yours,
Technical Support
BACK FLOW PROTECTION DEVICE
TROUBLESHOOTING
-28-
Yes: No:
Yes: No: Year/s
Brand Design Function
Year/s
Year/s
Yes: No:
Yes: No:
Limited Warranty Registration From
Important
Tovalidatethelimitedwarranty,TheLimitedWarrantyRegistrationFromMUSTbelledoutcompletely
and return to LENOXwithin 30 days of original purchased date. This Limited Warranty is valid if LENOX-
received registration from.
Serial No Salon Phone Number
Salon E-Mail Address Cell Phone Number
First Name Last Name Date of Purchase (mm/dd/yyyy)
Salon Address
City State Zip Code
Name of Distributor
City State Zip Code
Completed Warranty Registration Form to:
LENOX Mail: 335 Crooked Hill Road,Brentwood N.Y 11717
Fax: 631.243.3339
Email: Info@lenoxpedicurechair.com
Questionnaires (We value your voice!)
1. Are you satisfy with Pedicure Spa received?
2.AreyoucurrentlyusingLENOXproduct/s?Ifso,Howlong?
3. If not, What other product?
4. What is the most important features in choosing pedicure Spa?
5. How long in business?
6. How often are you remodel you Salon?
7. Would you purchase LENOX product in the future?
8. Do you want to receive a promotion by email?
9. Any suggestion or Comment
Service Price Other
REGISTRATION
335 CROOKED HILL RD., BRENTWOOD, NY 11717
LENOX.
1.631.243.3336 WWW.LENOXPEDICURECHAIR.COM
1.631.243.5300 WWW.PEDISPAFIX.COM
SERVICE & ORDER PARTS
Table of contents
