Lenoxx DSP-26A User manual

IB-DSP26A-WC-E-072005
DIGITALACTIVESPEAKERSYSTEM
OPERATINGINSTRUCTIONS
1.5WATTS RMS PER CHANNELFOR
RICH STEREOSOUND
DIGITALCLASS DAMPLIFIER
ROTARYVOLUME CONTROL
3.5MM STEREO INPUTPLUG WITH
1.3METERSCABLE
LED POWER ONINDICATOR
POLYFOAM ROLLEDSPEAKEREDGE
FOREXTRA BASS
MODEL DSP-26A
3/4" MYLARELECTROPLATEDVOICECOILS
MAGNETICALLYSHIELDED SPEAKER
ELEMENTS
USES 4 AA”SIZE BATTERIES(NOT
INCLUDED)
AC ADAPTOR 9V 750mA(INCLUDED)
LINE INJACK- CONNECTSTOYOURCD
PLAYER,MP3 PLAYER, COMPUTER OR
ANY AUDIO DEVICE
PLEASE READ CAREFULLYBEFORE USE
IB-DSP26A-WC-E-072005.pmd 10/18/2006, 4:35 PM1

IB-DSP26A-WC-E-072005
1
1
2
6
7
89
1.ADJUSTABLE STAND
2.POLYFOAM ROLLED SPEAKER(L)
3.LED POWER ONINDICATOR
4.VOLUME CONTROL
5.POLYFOAMROLLED SPEAKER (R)
6.LINE INJACK (for CD player/MP3player/Computer)
7.POWER ON/OFFSWITCH
8.AC ADAPTOR JACK
9.BATTERYDOOR
LOCATIONOF CONTROLS
34
5
IB-DSP26A-WC-E-072005.pmd 10/18/2006, 4:35 PM2

IB-DSP26A-WC-E-072005
2
REPLACEMENTOF BATTERIES MUST BE DONE BYADULTFORSAFETY
INSERT 4SIZE AA”
ALKALINEBATTERIES
1.BATTERYINSTALLATION(batteriesnot included)
1.Slide the BATTERYDOOR out.
2.Insert 4size AA”alkaline batteries, according to the +and markings in the
battery compartment.
3.Werecommend alkaline batteriesforlongerlife.
4.Close the BATTERYDOOR.
•Donotmixoldandnew batteries.
•Donotmixalkaline,standard(Carbon-Zinc)orrechargeable(Nickel-Cadmium)
batteries.
POWER SOURCE
Power your speaker system by inserting 4size AA”fresh alkaline batteriesor by
connecting thesupplied AC ADAPTOR.
BOTTOM OF SET
SLIDETHEBATTERY
DOOROUT
CLOSETHEBATTERY
DOOR
BATTERYREPLACEMENT
Exhaustedbatteries mayleak and damagethe set, or cause weak or distorted
sound.Replacebatteries when required.
When thesetisnotto be used for an extended period, removethebatteries from the
battery compartment.
IB-DSP26A-WC-E-072005.pmd 10/18/2006, 4:35 PM3

IB-DSP26A-WC-E-072005
2.ACADAPTOR(included)
The ACadaptor suitableforthisspeakersystem isDC 9V 750mA, with positive center
polarity . If you want to replace your adaptor,please choose only thistype.
Insert the adaptor plug to adaptor jack of the speaker system and connect adaptor to
power 120V/60Hz.
3
SPEAKERSYSTEMOPERATION
1.Insert the included audio cablewith3.5mm plugson eachendintotheLINE OUT jack
orPHONESjackofyourCDplayerorMP3 playerorcomputer,andtheotherend
intotheLINE INjack of the speaker system.
2.Slide the POWERswitchof speaker system totheON position(theLED indicator turnsblue).
3.TurnonyourCDplayer or MP3 playerorcomputer,adjusttheVOLUMEcontrol of the
CD player/MP3 player/computer and the speakersystemto the desired levels.
SUPPLIED
AUDIO CABLE
LINE INJACK
TO HOUSEHOLDOUTLET
OR
OR
CDPLAYER
IB-DSP26A-WC-E-072005.pmd 10/18/2006, 4:35 PM4

IB-DSP26A-WC-E-072005
FIG.1 FIG.2
FIG.3
NOTE
•Do not playthissystem at maximumvolume or too close to your ears for hearing
safety.
•This digital activespeakersystemis alow powersystem,it’ssuitablefor your CD player/
MP3player/computer.Weadvisenotto connect it toyour home theater system orhigh
powerdevices!
•Remember toslide the POWERswitchto OFF positionafter use.
4
(You can play thisspeakersystem in any ofthe4positionsshown above.)
5.Slide the POWER switchofspeakersystemtoOFFposition afteruse(the LED
indicator turns off).
4.Adjustspeakersystem to the best positionforlistening.
FIG.4
IB-DSP26A-WC-E-072005.pmd 10/18/2006, 4:35 PM5

IB-DSP26A-WC-E-072005
Nopower.
1.Istheadaptorcordfirmlypluggedinto theadaptorjack?
Insert the AC adaptor plug securely into speaker.
2.Isthepower switchedtotheOFF position?Slide ittoON.
3.Werethebatteries insertedcorrectly? Please make sure4size
AA”alkalinebatteriesare inserted into batterycompartment
according tothe +and –markings inthebatterycompartment.
Distortedsound. 1.Reduce inputsource volume or the speaker volume.
2.The batteries are weak, pleasereplace thebatteriesor
usethesuppliedACadaptor.
TROUBLE SHOOTING
Symptom Remedy
5
The POWER LED
indicator blinks or
gets dim.
The batteriesareweak, pleasereplace thebatteries oruse
the suppliedAC adaptor.
Reduce inputsourcevolume or thespeakervolume,then turn
offthe speaker andturnit onagain.
Onlyonechannel has
sound.
No sound or onlya
verylow-level sound
isheard.
1.Check thatthespeakerLINE INcableis connectedsecurely
andcorrectly.Makesure the cableis insertedwell.
2.Make sure yourspeakerhaspower and POWER switch is
in the ON position.
3.Make sure the input sourceCD player/MP3 player/computer
works well.
4.Adjustthespeakersystem andCD player/MP3 player/computer
volumecontrol.
5.Thebatteries are weak, pleasereplace thebatteriesor
usethesuppliedACadaptor.
IB-DSP26A-WC-E-072005.pmd 10/18/2006, 4:35 PM6

IB-DSP26A-WC-E-072005
SAFETYINFORMATION
1.Batteries should only be installed by adult for safety.
2.Donotloadbatteries withpolarities (–/+)reversed.
3. Do notforce batteriesintothebatterycompartment.
4.Donotshort-circuit the battery with metallicobjectssuchaskeyholdersor jewellery.
This may damagethebattery.
5.Whennotinuseforan extendedperiod of time, or whileinternalbatteries willnotbe
used, please remove them to prevent possible battery acid leakage or corrosion.
6.Clean only withadry orvery slightly dampcloth.
7.Donotusethis setnear water,donotexpose thisappliance torain ormoisture.
8.Tominimizerisk ofpossible overheating, do not blocktheventilationholes attherear
cabinet.
WARNING:
Topreventfireorshockhazard,do notexpose this
appliance torain ormoisture.
Donot blockorobstruct theventilation holesatthe
rearofthe set.
6
This Class Bdigital apparatuscomplieswith CanadianICES-003.
NOTICEFORCANADA: Thisapparatuscomplies with theClass B”limitsforradio
interference asspecified in theCanadian Department ofCommunications Radio
InterferenceRegulations.
IB-DSP26A-WC-E-072005.pmd 10/18/2006, 4:35 PM7

IB-DSP26A-WC-E-072005
7
FCCNOTES:
NOTICEFOR USA: Thisequipmenthasbeen testedandfoundtocomplywith thelimits for aClass
Bdigitaldevice, pursuantto Part 15of theFCCrules. These limits aredesignedto providereasonable
protectionagainstharmful interferenceinaresidential installation.This equipment generates, uses
andcan radiateradio frequencyenergyand, if not installed andused in accordancewiththe
instructions, maycauseharmfulinterferencetoradio communications. However,thereisnoguarantee
that interference will notoccurinaparticularinstallation.Ifthis equipment doescauseharmful
interference to radioortelevisionreception, which can be determined by turning the equipment off
andon, the user isencouraged to try tocorrectthe interference by oneor moreofthe following
measures.
-Reorientorrelocatethereceivingantenna.
-Increasetheseparationbetween the equipmentandreceiver.
-Connectthis equipmentintoanoutletonacircuit differentfromthattowhichthe
receiver is connected.
-Consult thedealeror an experiencedradio/TV technicianforhelp.
CAUTION: Tocomply with thelimitsforthe ClassBdigital services,pursuant to Part15of theFCC
Rules, this device must be installedwith computer equipment certified to comply with the Class B
limits.
Modifications
Anychanges or modificationsnotexpresslyapprovedby the granteeofthisdevice could void the
user’sauthoritytooperatethedevice.
Thisdevice complies with part 15 of theFCC Rules. Operation is subject tothefollowing two
conditions:(1) This devicemaynotcause harmfulinterference,and(2)this devicemustacceptany
interferencereceived, includinginterferencethatmay causeundesiredoperation.
SPEAKERSPECIFICATIONS
PowerSupply
AC Adaptor :Input120V/60Hz,Output9V750mADC(included)
DC :6V,using 4size AA”alkaline batteries(notincluded)
Power Output :1.5W/channel
Dimension :6”(W) X23/4”(H) X25/8”(D)
Weight :9.5oz.(without batteries)
IB-DSP26A-WC-E-072005.pmd 10/18/2006, 4:35 PM8

IB-DSP26A-WC-E-072005
8
LIMITED WARRANTY
Wewarrant thisproducttobefreefrom defectsinmaterialandworkmanshipunder normalusefor
aperiod of 1yearafterpurchase and we willrepairit freeof chargeor replaceit at no charge, should it
becomedefectiveunderthiswarranty,providing you submitproof ofpurchase(sales slip)withtheset.
Duringtheinitial1yearperiodafteroriginalpurchase,wewill servicethesetthatisreturnedto
LENOXXELECTRONICS CORP,prepaid,atnocharge.Aftertheinitial 1yearperiodexpires,wewill
exchange, at no charge,any part that is defective, but will charge forthe cost oflabor, return postage paid
by Lenoxx.
Thiswarranty does not apply toany products which have been subject to misuse, neglector accident.
Thiswarranty does not coverbrokencordor cabinet. UNDERNOCIRCUMSTANCES WILLLENOXX
ELECTRONICS CORP.BE LIABLEFOR ANYINCIDENTALORCONSEQUENTIALDAMAGES.Some
statesdonotallow theexclusion or limitation of incidental or consequentialdamages,so theabove
limitations orexclusions maynot apply toyou.
Thiswarranty givesyouspecificlegal rights, and you may alsohaveother rights whichvary from
stateto state. The following chargesapplyto repairs beyond the warranty period:$6.00.Be sure to pack
carefully and return postage paidinsuredtogetherwith yourmoney order(personal checks will not be
accepted) and sales receipt to:
LENOXX ELECTRONICSCORP.,35 BRUNSWICKAVENUE,EDISON, N.J.08817, USA
We reservethe righttomakedesign andspecification changesfor product improvement.
Thedescriptionsandcharacteristicsgiven inthis documentaregivenasageneralindicationandnot
as aguarantee.In order toprovide thehighest quality productpossible, wereserve therightto make
anyimprovementormodification withoutprior notice.The Englishversion serves as the final reference
on all product andoperation details should anydiscrepanciesarise inotherlanguages.
©2006 LENOXXELECTRONICSCORP.
35BRUNSWICK AVENUE
EDISON,N.J. 08817, USA
MADE &PRINTED INCHINA
For customer service
Dial: 1-800-315-5885 (MONDAY-THURSDAY8:00AM-5:00PM,FRIDAY8:00AM-1:30PMEST)
orVisit Our Website: http://www.lenoxx.com
orEmail: [e-mail]
