Leonard LMS-188-4P-SM User manual

LMSOperatingManualPage1
LMS-188-4P-SM
4 POINT DIGITAL MONITOR/ALARM
OPERATING INSTRUCTIONS


1360 Elmwood Avenue
Cranston, RI 02910
Tel [phone] Fax [phone]
Toll-free [phone] www.leonardvalve.com
G‐LMS‐188‐4P‐SM
January5,2018

LMSOperatingManualPage2
TableofContents

FrontPanel....................................................................................................................................................3
SensorProbe.................................................................................................................................................3
ProbeInstallation..........................................................................................................................................4
Power‐up.......................................................................................................................................................4
Power‐downSequence.................................................................................................................................4
RuntimeDisplay............................................................................................................................................4
AlarmConditions..........................................................................................................................................5
TemperatureAlarms.................................................................................................................................5
Low/HighAlarmLimits................................................................................................................................5
Min/MaxReadings........................................................................................................................................5
LMSEmailNotificationFeature....................................................................................................................6
LMSOverview.............................................................................................................................................11
RDUOptionInstallationInstructions……………………………………………………………………..………………………………12
SolenoidValveControl
ACPoweredSolenoidControlOption(SCO)……………….………………….……….….………………………………..….14
DCPoweredSolenoidControl……………………………………………………………………………..…………………………..15



LMSOperatingManualPage3
FrontPanel
The Multi-Probe Alarm System front panel consists of the following:
Graphic LCD
Channel Status LEDs (STATUS)
Alarm LED (ALARM)
Audible alarm indicator (buzzer)
Buttons
oTest & Reset (TEST/RESET)
oStep button (STEP)
oAlarm Limits & decrement button (vv)
oMin/Max & increment button (^^)
oMute & Menu increment button (MUTE/MENU)
SensorProbe
The probes supplied with the Multi-Probe Alarm System are highly accurate temperature
sensors. The sensor may be put in water or other mild aqueous solutions from -100°C to 100°C.
NOTE: Avoid submerging the probe in solvents or harsh chemicals. Use protective thermowells
when monitoring such materials.
NOTE: The warranty does NOT cover damage to probes or electronics that is caused by
exceeding temperature limitations, or damage to probes caused by using them in solvents
or other unsuitable environments.
NOTE: If the displayed temperature shows a consistent high (> 100°C) or low (< -100°C) value,
most likely, the probe has failed.

LMSOperatingManualPage4
ProbeInstallation
RTD sensors supplied with the LMS-188-4P-SM should be installed on the pipe surface using
the supplies included with the alarm box. For proper installation, follow the instructions below.
1. Find an appropriate location for the sensor. It will need at least a 12” section for proper
installation.
2. Clean the pipe surface with the abrasive cloth and brush on a thin layer of dielectric
grease onto the cleaned surface.
3. Strap the sensor lengthwise to the pipe. Leave 5-6” of exposed pipe on either side of
sensor. Brush an additional thin layer of dielectric grease onto sensor surface.
4. Wrap pipe and sensor with insulation (supplied by others). Strap the insulation to the
pipe.
Power‐up
Shows LMS startup screen.
NO BATTERY
Power Down + Install Battery
The unit will run without a backup battery but will show “NoBatt!” on the display to indicate
lack of backup battery.
When a battery is properly installed battery status is shown on the display
up arrow charging
solid block full charge
flashing block or
block with blank lines battery problem
Power‐downSequence
To shut off the battery to allow complete power down:
Tap the TEST/RESET button to enter relay test, then unplug unit.
Alternately you may Press-and-Hold the TEST/RESET button to trigger a hardware reset, and
while the screen is blank unplug the unit and then Release the button.
RuntimeDisplay
The runtime display shows the current readings of 2, 3 or 4 probes.

LMSOperatingManualPage5
AlarmConditions
TemperatureAlarms
If the readings are within the alarm limits, the STATUS LED will blink green.
When the temperature reading meets or exceed the temperature limits the STATUS LED will
blink red.
After the probe’s alarm delay time is exceeded the unit will blink the ALARM LED and beep the
buzzer.
The user can MUTE the buzzer by tapping the MUTE/MENU button. The unit will reduce the
audible signal from a loud beep, to a quieter and less frequent chirp. It will remain muted until
MUTE time expires or a different probe goes into alarm.
Once the Alarm state has been signaled the unit will wait the appropriate Relay Delay(s) time
before tripping the appropriate Relay(s). Units with individual channel relays, have individual
Relay Delay times. Units with a single relay have one Relay Delay time that applies to any
alarm condition.
Limit Parameters
1 Low, 1 High, 2 Low, 2 High, 3 Low, 3 High, 4 Low, 4 High
Time Parameters
1AlarmDelay, 2AlarmDelay, 3AlarmDelay, 4AlarmDelay
Single Relay Units
RelayDelay
Individual Channel Relays
1RelayDelay, 2RelayDelay, 3RelayDelay, 4RelayDelay
Low/HighAlarmLimits
For a quick view the Low and High Alarm Limits tap the DOWN ARROW.
1 AlarmLow 2.0’C
AlarmHigh 8.0’C
2 AlarmLow 2.0’C
AlarmHigh 8.0’C
3 AlarmLow 2.0’C
AlarmHigh 8.0’C
4 AlarmLow -40’C
AlarmHigh -20’C
Min/MaxReadings
To view the Min/Max readings since power up or user commanded reset, tap the UP ARROW.
1 ActualMin 3.1’C
ActualMax 6.8’C
2 ActualMin 3.6’C
ActualMax 6.6’C
3 ActualMin 3.0’C
ActualMax 7.2’C
4 ActualMin -38’C
ActualMax -32’C

LMSOperatingManualPage6
To manually reset the Min/Max readings, while the Min/Max readings are shown on the display,
tap the TEST/RESET button. You will be asked to repeat TEST/RESET to confirm.
LMSEmailNotificationFeature
The LMS sends email on unit reset, alarm, continued alarm and recovery from alarm.
The unit sends email 5 minutes after email failure and repeats every 10 minutes after that.
Once daily, it sends a report of the last 24 hours that includes temperatures on the hour and alarms to
contact #1.
The email subject line identifies the unit and reports the current temperature. The message reports the
last 10 minutes of data. The unit is identified by the name ID001, where 001 is the unit number
assigned by the user as an LMS parameter. All mail settings are setup using web pages accessed by the
IP assigned to the unit.
LMS EMAIL SETUP PARAMETERS -- IP, Setup Web Page Passcode
Factory
NAME Description Explanation Set
IP1 IP 1 First number of IP (1.2.3.4) 192
IP2 IP 2 Second number of IP 168
IP3 IP 3 Third number of IP 0
IP4 IP 4 Fourth number of IP 141
NetworkCode PassCode 5 digit PassCode for Setup web page access
(-30000 to 30000) -22718

Depending on the Network being utilized, the factory setting on the alarm unit for IP1, IP2
and IP3 may need to be changed to match the corresponding settings of the network. IP4
may also need to be changed if another device is using the default number.

Mainpage:
Access by entering IP address on your browser’s URL.
Main page displays
the designated email server and the email address
the last 10 minutes of data from the LMS
the contact list of up to 8 email addresses
Main page has links to
edit the contact list *
send a test email to all contact list addresses
view a log of alarm emails and test emails
clear the email log *
retry getting date & time from nist server
* requires list name/password
Setup page:
Requires the Master name "setupadmin", and the LMS five digit passcode.
Allows specification of Subnet Mask, Gateway, DNS Server, SMTP Server, SMTP auth user, SMTP
password, List Administrator Name, List Password, Time zone [EST: -5, CST: -6, MST: -7, PST –8],
Daylight Savings start and end, and the time the daily report should be sent [0-23].

LMSOperatingManualPage7
Edit contact link:
Requires the List User Name and List Password for access.
Allows specification of up to 8 email contact addresses.
Protonode Option
If the Protonode option has been installed with the alarm unit, please contact Leonard Valve for complete
interface instructions.
Resetting Computer IP Address
If LMS-188-4P is not communicating with your computer, your computer’s IP address may need to be
manually set. Use the following directions: 1) Get to the ‘Network and Sharing Center’ section either
through ‘Control Panel’ or the internet connection icon on your taskbar. 2) Click on ‘Local Area
Connection’ to bring up the status page. 3) Click properties and then highlight ‘Internet Protocol Version
4 (TCP/IPv4)’ and click ‘Properties’. 4) In this new window, click the option ‘Use the Following IP Address’
and enter the numbers for IP1, IP2 and IP3 from the LMS unit. For IP4, enter any combination of
numbers, 1-3 digits long. Just be sure it is not the same as LMS-188-4P-SM. Subnet Mask is
255.255.255.0 and the Default Gateway is left blank.
Web Pages:
[Main Page]
[Access by entering the IP in browser address bar]

LMSOperatingManualPage8

LMSOperatingManualPage9
[Setup page – "initial setup"]
[Access by adding "setup.html" to the IP]
[ User: setupadmin (not editable, case sensitive) Password:<5-digit code from LMS>]
Gateway on Setup Page MUST match the Gateway of the network that is utilized. See Network
administrator for DNS Server & SMTP information. If these parameters are unavailable, use 8.8.8.8 for
DNS Server, smtp.1and1.com for SMTP Server, [email protected] for SMTP auth
user, and D41yR757368 for SMTP password. Note that these parameters are for test purposes
only!
[Contact List Page for maintaining contact list]
[Access via link from main page]
[ User: <as defined by Setup> Password:<as defined by Setup> ]

LMSOperatingManualPage10
Defaults:
Web Setup Administrator setupadmin *this is coded into the firmware and is not editable
Setup Password -22718 *use LMS NetworkCode as password
Web List Administrator listadmin
List Password idoemaillist
Please define:
LMS: IP (IP1, IP2, IP3, IP4)
NetworkCode: number –30000 to 30000
Web Setup: Subnet Mask SMTP Server
Gateway SMTP auth user
DNS Server SMTP password
Contacts: At least 1 email contact
Installation Instructions:
#1 – Set Your IP
From the LMS front panel: Tap Menu to ender Edit.
Tap Test and Menu simultaneously, to switch to the *SETUP* group of parameters.
Use Step to advance to IP1,IP2,IP3,IP4 and set them accordingly.
If desired modify your Unit ID and NetworkCode.
Tap Menu 3 times to advance out of Edit and back to the runtime temperatures.
Hold Reset until the display goes blank, then release.
#2 -- Define your network and email settings
Using your web browser enter the IP address to access the unit.
After reviewing main web page, add "/setup.html" to the IP, to access the Setup Info.
Name: setupadmin (unchangable, case sensitive) Passcode: -22718
Enter your Subnet Mask, Gateway, DNS Server.
Enter your SMTP server, SMTP auth user, and SMTP password.
Submit.
Back at the main page verify server and address at top of page, then click "Edit Contact List"
Name: listadmin Passcode: idoemaillist
Please add one contact email address.
Submit.
#3 -- Test
Back at main page click "Send test email", and wait.
Click "View Test/Email Failure Log".
Success: "Admin Test 1sent"
Failure: “Admin Test 1fail”
Check your email for message received
After Daylight Savings Time ends in November, and before it begins in March, please update the Setup
Parameters DST start and end to ensure proper date/time.
DST Start DST End
Sunday March 13, 2016 Sunday November 6, 2016
Sunday March 12, 2017 Sunday November 5, 2017
Sunday March 11, 2018 Sunday November 4, 2018
Sunday March 10, 2019 Sunday November 3, 2019
Sunday March 8, 2020 Sunday November 1, 2020
Sunday March 14, 2021 Sunday November 7, 2021
Sunday March 13, 2022 Sunday November 6, 2022


11

LMSOverview
Buttons: TEST/RESET, STEP, DOWN, UP, MUTE/MENU
Runtime Display
1: 8.9'C
2: 8.4'C
Edit Parameters
At Runtime tap MENU Repeat MENU,MENU,.. To Edit Limits , Edit Times ,
Return to Runtime
Edit Limits or while in Edit tap MENU AND RESET simultaneously to access
*SETUP* group
1 Low
-30.3 To step through parameters in group use STEP
To STEP BACK tap TEST To modify parameter values use DOWN , UP
To step out of edit and back to runtime screen use MENU
Group 1 Limits
1 Low, 1 High, 2 Low, 2 High
Group 2 Times
1AlarmDelay, 2AlarmDelay, DoorAlrmDly,
1RelayDelay, 2RelayDelay, Mute
Special Group *SETUP*
1 Offset, 2 Offset,
# channels,
1 Define, 0:tenthC 1:wholeC 2:tenthF 3:wholeF 4:wholeRH
2 Define,
Relay Def, 0:single unit relay 1:individual channel relays
DoorAlarm -1:AlarmOnContactClosed 0:NoAlarm 1:AlarmOnContactOpen
Unit ID -1:AlarmOnContactClosed 0:NoAlarm 1:AlarmOnContactOpen
IP1, IP2, IP3, IP4, IP 1.2.3.4
NetworkCode -30,000 to 30,000 Setup Web Page Password
Door Status Display
Upon Door Alarm, the Door Status Displays until user responds, OR By User command at
Runtime tap STEP
Door Door Door
Closed Open Open <DoorStatus:
Open/Closed>
Ok Delay Alarm <AlarmStatus:
Ok/Delay/Alarm>
Low/High Alarm Setpoint Display
At Runtime tap DOWN
1 AlarmLow 2.0’C
AlarmHigh 8.0’C
2 AlarmLow 2.0’C
AlarmHigh 8.0’C


12

Min/Max Temperatures Display Min/Max Reset *while viewing Min or Max
At Runtime tap UP tap RESET
1 ActualMin 3.1’C
ActualMax 6.8’C
2 ActualMin 3.6’C
ActualMax 6.6’C
Min & Max
Reset
RESET to confirm
STEP to cancel
Relay Test
At Runtime tap TEST
Relay Test Relay Test
Rly1 15 Rly2 15 * seconds counting down
To Step, tap STEP To Step, tap STEP
To Hold, hold STEP To Hold, hold STEP
ALARM DELAY MODULE (RDUOption)
INSTALLATION INSTRUCTIONS
IDescription:
The Alarm Delay Module is designed to accept dry contact inputs, either Normally Open
(N.O.) or Normally Closed (N.C.), and to delay the transmission of the contact change
information to another device.
IIApplication:
The primary application is in alarm systems where it is desirable to insert a fixed time
interval between the detection of an alarm condition and the transmission of the alarm
information to monitoring systems, telephone dialers, external services, etc.
Such delay is particularly important in areas where short power interruptions are
frequent, or where transitory alarm conditions are likely to occur. The user can select a
time period of delay that results in the minimum number of "false" (self-correcting) alarm
transmissions while still providing the degree of safety required.
IIIInstallation:
1. Remove the plastic case cover by removing the 2 Phillips screws from the
back. Apply light pressure on the face plate, the cover and face plate will
come off together.
2. Locate the ALARM INPUT switch on the circuit board. Move the switch
to the condition of the contacts in the alarm sending device when in the
NON-ALARM condition. The unit is shipped with the switch in the
N.O. (Normally Open) position, this will be correct for the majority of
installations, however, if your alarm device opens its contacts when it
alarms, simply slide the switch to the N.C. position.
3. Locate the row of pins on the short edge of the board labeled "minutes". A
shorting clip will be at the 8 minute position. In this position the alarm
delay module will require 8 minutes of CONTINUOUS incoming alarm
indication before sending the alarm status on to the next system. Move
the jumper to the set of pins marked either 0.5, 1, 2, 4, 8, 16, or 32
minutes, as your needs require. The pair of pins marked "T" are for test
purposes and should not be used.
4. Install the signal wires from your alarm. Route the wires through the
drilled hole at the bottom of the case and to the terminals marked 1 & 2.
5. Install the output wires to your output device, route the wires through the
drilled hole at the bottom of the case and to the terminals marked 4 & 5 if


13

it requires contact closure for operation or to terminals 3 & 4 if it requires
contact opening for operation.
6. Install a 9 volt rechargeable battery in the holder provided if you desire
the battery back up function AND you have the 120 Volt adapter. If you
do not have the 120 Volt adapter you may use any 9Volt battery, we
recommend Alkaline.
7. Check the system for proper operation and reassemble.
8. Using the peel-and-stick Velcro provided, mount the RDU where the
LED indicators can be easily seen.
IVOperation
When the unit is monitoring there are no LEDs lit, pressing RESET will
light the green LED to indicate OK.
• A flashing yellow light indicates that an alarm condition is being timed.
• A flashing red light means that an alarm condition has persisted for the
set time and has been transmitted to the monitoring device, this LED
will continue to flash even if the alarm condition has corrected itself.
• Pressing RESET will cause the red LED to stop flashing and reset the
output contacts to their normal non-alarm state, if the alarm condition
persists the yellow LED will again flash to indicate timing and, after
timing out, will light the red LED and change the output contacts.
NOTE It is important that the battery condition be checked regularly by pressing
RESET. A dead battery may prevent proper operation of the Alarm Delay
Module.
This is the hookup from a relay (contact) output of an LMS-188-4P-SM, or other device,
to the RDU.
Use the slide switch on the main board to choose N.O. or N.C. input.
On the output side, the RDU offers Normally Open (4, 5) or Normally Closed (3, 4)
contacts, and may be connected to a dialer, beeper, strobe light, etc.



LMSOperatingManualPage14
SOLENOID CONTROL OPTION
PROVIDED BY LEONARD VALVE
Description:
The Solenoid Control Option (SCO) is designed to accept dry contact inputs, either Normally Open
(N.O.) or Normally Closed (N.C.), in order to switch an AC powered solenoid opened or closed. Solenoid valve
and associated power supply are to be provided by others.
Application:
The primary application is in systems where it is desirable to control an AC powered solenoid in the event that
the alarm on the LMS-188-4P-SM is active. When in non-alarm condition the relay is in a N.O. state and the
solenoid will allow water to flow through it freely. Once the alarm is active, the relay on the LMS-188-4P will
switch to N.C. and the solenoid will shut down. Solenoid valve and associated power supply are to be
provided by others.
Installation:
Included with every SCO is a 12 VDC/600 mA power source with a 10’ lead that requires a dedicated 110 VAC
outlet to plug into. See wiring diagram below for reference. Do Not Energize SCO, LMS-188-4P-SM, or
solenoid valve until wiring is complete. Solenoid valve and associated power supply are to be provided by
others.
1. Connections from the power source to the SCO (+ side to terminal 7), terminal to solid state relay
(terminals 3+ to 8), and power source to solid state relay (- side to terminal 4-) have been made at the
factory.
2. Properly ground the SCO by using the screw provided inside of the enclosure and connect to suitable
earth ground
3. Connect terminal 5(12VDC) to the COMMON ‘C’ terminal (9) of the LMS-188-4P relay switch.
4. Connect either terminal 9 or 11 from the LMS-188-4P-SM relay switch to terminal 6on the terminal
strip. Use terminal 9with N.C. solenoids; use terminal 11 with N.O. solenoids.
5. Connect the positive side of the solenoid power supply to terminal 1 on the solid state relay.
6. Connect terminal 2on the sold state relay to the positive side of the solenoid valve. Complete the circuit
by connecting the neutral side of solenoid to the neutral side of power supply.



LMSOperatingManualPage15
DC POWERED SOLENOID CONTROL
HARDWARE SUPPLIED BY OTHERS

Description:
This solution is for systems that utilize a DC powered solenoid valve and want to make use of the SPDT relay
switch included with LMS-188-4P-SM. Solenoid valve and associated power supply are to be provided by
others.

Application:
The primary application is in systems where it is desirable to control a DC powered solenoid in the event that
the alarm on the LMS-188-4P-SM is active. When in non-alarm condition the relay is in a N.O. state and the
solenoid will allow water to flow through it freely. Once the alarm is active, the relay on the LMS-188-4P-SM
will switch to N.C. and the solenoid will shut down. Solenoid valve and associated power supply are to be
provided by others.

Installation:
Solenoid power supply is to be supplied by others and is not available from Leonard Valve. The relay contacts
are rated up to 30 V/1A. See wiring diagram below for reference. Do Not Energize LMS-188-4P-SM or
solenoid valve until wiring is complete. Solenoid valve and associated power supply are to be provided by
others.

1. Connect positive side of power supply to the COMMON terminal (2).
2. Connect either terminal 1 or 3 from LMS-188-4P-SM relay switch to positive side of DC solenoid. Use
terminal 1with N.C. solenoids; use terminal 3with N.O. solenoids.
3. Connect neutral side of power supply directly to neutral side of DC solenoid.
