HFU 4520D
combined mobile RFID- and 1D / 2D
Code- hand held reader with
Bluetooth
Short Description
Version V 2.01
5
0
1
1
9
3
4
4

Short description HFU 4520D Leuze electronic Page 2
Note
This document is just for information about how to use the mobile combi device HFU 4520D from Leuze
electronic. All important details about the functionality and the handling were described further on. In addition
the typical connections together with the modular connector units (MA) are in this manual, too.
Content
DELIVERY CONTENTS .............................................................................................................................................. 3
SAFETY NOTICES ....................................................................................................................................................... 4
G ENERAL S AFETY N OTICES ........................................................................................................................................... 4
A PPROVED PURPOSE ...................................................................................................................................................... 4
W ORKING SAFELY ......................................................................................................................................................... 4
INSTALLATION............................................................................................................................................................ 5
C ONNECTING THE DEVICE ............................................................................................................................................. 5
H OW IS THE BEST WAY TO SCAN OR READ ?.................................................................................................................... 6
TECHNICAL DATA...................................................................................................................................................... 7
R EAD C HARACTERISTICS ............................................................................................................................................... 8
USING THE HFU 4520D............................................................................................................................................... 9
F UNCTIONS .................................................................................................................................................................... 9
D EVICE RESET / F ACTORY DEFAULT ............................................................................................................................ 11
P ARAMETER S ETTING .................................................................................................................................................. 11
T ELEGRAM - / C OMMAND STRUCTURE ......................................................................................................................... 12
M ENU STRUCTURE ....................................................................................................................................................... 13
HFU 4520D AT SERIAL PC-I NTERFACE ....................................................................................................................... 16
HFU 4520D WITH MA 204 I , MA208 I OR MA248 I ...................................................................................................... 17
HFU 4520D WITH MA 21 ( MULTINET )........................................................................................................................ 17
HFU 4520D WITH USB (COM-P ORT -E MULATION ).................................................................................................... 18
T RIGGERING /A CTIVATION .......................................................................................................................................... 18
D IAGNOSTICS AND TROUBLE SHOOTING ...................................................................................................................... 19
TYPE OVERVIEW ...................................................................................................................................................... 20
ACCESSORIES ............................................................................................................................................................ 20
C ONNECTION TO L EUZE MULTINET P LUS .................................................................................................................... 21

Short description HFU 4520D Leuze electronic Page 3
C ONNECTION TO P ROFIBUS DP.................................................................................................................................... 21
C ONNECTION TO P ROFINET RT I/O ............................................................................................................................. 21
C ONNECTION TO E THERNET TCP/IP ........................................................................................................................... 22
Delivery contents
HFU 4520D
1. Mobile combi RFID + 1D/ 2D code-Hand held reader
2. pre mounted battery in handle
3. Bypack paper

Short description HFU 4520D Leuze electronic Page 4
Safety Notices
General Safety Notices
All entries in this technical description must be needed, in particular the present chapter „General Safety
Notices“. Keep this technical description in a safe place.
Safety regulations
Observe the locally applicable regulations and the rules of the employee´s liability insurance association.
Repairs
Repairs must only be carried out by the manufacturer or an authorized representative.
Approved purpose
Attention! The protection of personnel and the device cannot be guaranteed if the device is operated in a
manner not complying with its intended use.
Combined mobile Barcode and RFID readers of the HFU 45x0D series are conceived as mobile devices
With integrated decoder for manual object identification with typical barcodes and UHF transponders.
In particular unauthorized uses include:
Rooms with explosive athmosphere
Operation for medical purposes
Areas of application
The combined mobile devices HFU 45x0D are designed for the following areas of application:
Storage and conveying technologies for manual object identification
Manual commisioning areas
Working safely
Attention! Access to or changes on the device, except where expressly described in this document, are not
authorized.
Qualified personnel
Mounting, commissioning and maintenance of the device must only be carried out by qualified personnel.
Electrical work must only be carried out by a certified electrician.

Short description HFU 4520D Leuze electronic Page 5
Installation
Connecting the device
The following paragraph describes all steps to get the device connected. The RS232-cable is fixed at the
device.
Switch off of computer or PLC
Information about switching and shut down the computer /PLC correctly you´ll find inside the manual. This
should always been done because of safety reasons before a new device is going to be installed.
Connecting the device cable to the PC/PLC
1. Connect the 9pin SUB-D to the interface cable to the suitable socket of the PC/PLC. If you are using a
RS232-USB-cable converter, the converter cable is just plugged into the 9-pin Sub D of the standard
RS232-cable.
2. The Standard RS232-cable allows either to use a separate Power supply (NT Hx5x0, 50110676), or using
via PIN9 of the cable a power supply inside the PLC.
3. Plug in the power supply into a power socket 110-230VAC (not necessary when PIN9 is used).
4. To switch „On“ the device please press the ‚OK‘ key. As soon the display shows the functions selection
the device is ready to use. The GREEN LED (above left edge of display) is ON, too.
5. With the black marked keys the function is selected and with the yellow marked key activated. Settings for
data output, code types etc. can be set in the ‚system‘ area (right yellow key).

Short description HFU 4520D Leuze electronic Page 6
How is the best way to scan or read?
Here we give you some advices for best case scan or read operations:
The Scanner should be held with alight angle to the code. (Don´t used it in 90°to the Code, because you get
total reflexion and read failure.)
The red LED-Line is an aimer and should be held onto the code. The Scanner cannot identify the label
correctly, if it´s not complete within the red line.
The red LED-Line is smaller and narrow if the device is close to the code. Codes with small and thin bars
should be read with a smaller distance, for larger codes the distance should be bid enough to have the
Complete code within the red line.
For reading the RFID tag, the environment should have less possible metal and the device should be held
very close above the tag.
The antenna of the device should cover over 70%.of the tag to have good conditions for reading it.
The read characteristics are printed on page 8
Test barcode
The printed code is to test the functionality of the scanner, module(bar)
width is 0.5 mm (20 mil)
Code 39 Bar Code Sample

Short description HFU 4520D Leuze electronic Page 7
Technical Data
Electrical Data
RFID
Frequency UHF (868MHz/915Mhz)
Transponder protocol EPC1Gen2
Read-/Write range max. 450mm*
Antenna size 120x70mm
Optical CODE reader
Opt.System Imager, int. LED
Code types 1D / 2D Codes
Range 1D max. 350mm**
2D max. 150mm**
Module 0.2 to 1mm
Cell size 0.2 to 0.9mm
Power Supply 3.7VDC, rechargeable battery 1500mAh
Code and Transponder types
2D Codes ECC200, QR, PDF417, ECC200
GS1-Databar-family
1D Codes Code 39 /128, Code 93 , 2/5 Interleaved ,EAN 8/13,UPC
readable Transponders EPC1Gen2 ( NXP G2XM/,G2Xl,Alien Higgs)
Interface
Interface type Bluetooth V1.2
RS232, 9pol Sub-D via Base
Emulation USB-COM-Port with
Converter cable
Mechanical Data
Display OLED (128x64)
Key board 19 keys
Weight 380 g (without battery)
Dimensions 135 x 104 x 145 mm
Material ABS, silver grey
Environmental Data
Valid Standards EN 301489-3
EN 302208-1
Protection class IP54
Temperature (operation) -20 to 50 °C
(storage) -20 to 50°C
* depends on used Transponder
**depends on used optical 1D / 2D code type

Short description HFU 4520D Leuze electronic Page 8
Read Characteristics
Working area imager 1D / 2D
Resolution 1D 2D
0.15 30-70mm -
0.25 30-150mm 10-50mm
0.5 30-250mm 10-100mm
1.0 50-350mm 20-150mm
Readable Barcode-Types (Release per selecting, * factory set)
Code 39*, Code 128*, EAN-13*, UPC-A,EAN-8*, UPC-E, Interleaved 2/5*
Codabar, Code 93*, Chinese 2/5, Codablock F*, ITF-6, ITF-14,
No of digits: range 1-255
Module: recommended 0.2 to 1.0mm
Readable 2D-Codes: (Release per selecting, factory set all )
ECC200, PDF, QR, Maxicode, GS1-codabar Familiy
Cell size: 0.21 to 0.9mm,
Working area RFID Antenna
0 250 450mm
Readable Transponder-Types: EPC1Gen2 (NXP G2XM, GSXL, Alien Higgs3
Out of ISO18000-6C)
TFU10
TFU05
HFU

Short description HFU 4520D Leuze electronic Page 9
Using the HFU 4520D
Keys for operation
key
Function
OK ON/OFF/ACK Switching Device On / Off, Acknowledge
parameter settings
<7> yellow pick / select pick / select menu /function
< > black arrows Movement between Menu parts
C cancel Cancel / Back
0-9/ABC Character / No keys Keys for Data input, first characters
green Pre select Pre select code lists (* in display)
With the built in menu structure and the display you can pick and select functions and menu parts to do
Parameter setting or activation of functions. In the upper level after switching ON the functions or the systems
menu are to choose. The device returns automatically after 1min (starting with last pressed key) from the
Systems menu back to the function select (RUN-Mode) .
Functions
Function SCAN Barcode
The device reads and decodes 1D / 2D Codes of the released types in a distance up to 350mm after
activation (Press Button) and displays the info. Depending on the setting an output via interface of the code
information is possible, too. 1D / 2D codes are printed typically in ASCII and read so as well. A data output is
possible in HEX-format too, with the suitable parameter. All parameter settings can be found in the sub menus
inside the system area/barcode (see menu structure). The configuration can be done alternatively with the pre
defined codes (see configuration).
Function SCAN RFID
The device reads transponder in distances up to 450mm after activation (Press Button) und displays the Info.
Depending on the setting an output via interface of the information is possible, too. The data is always stored
in hexadecimal format on the transponder. A data output is possible in ASCII-format too, but Data / Serial no.
only. Error messages are shown in the display and (Parameter) possibly transmitted via interface. Up to
32Bytes (depends on tag!) of data (8Blocks) can be read in one operation. All parameter settings can be
found in the sub menus inside the system area/RFID (see menu structure).
Function EDIT RFID
The device allows you to write data to transponders up to 400mm after input via key board or via telegram
from Host, but always after Activation (Press Button). Parameter dependent an output via interface is
possible. Messages and errors are shown in the display. The max. amount of data for writing is similar to read
max. 32Byte (8Blocks), depends on tag. The input can be (parameter!) either in ASCII or HEX-Format. All
parameter settings can be found in the sub menus inside the system area/RFID (see menu structure).

Short description HFU 4520D Leuze electronic Page 10
Function SCAN Barcode and EDIT RFID
This special and unique function reads a released Barcode /2D (3 trials) per activation (Trigger button) and
writes the read information to the next Transponder into the defined memory slot(parameters). Start of Write
op again with trigger button. In any case the device comes back with a message (success/ failure) onto
Display / Interface. The sequence is fixed, an interrupt is only possible with C. All parameter settings can be
found in the sub menus inside the system area/barcode and RFID (see menu structure).
Function SCAN ALL
This function is a combination of the functions READ Barcode and READ RFID.
The device tries after activation first to read a released transponder, 3 trials (Info on Display) and
after that without a success a released Barcode. Again the info is on the display and on the interface.
After the 3 trials without any success an error message (NoRead) is shown on Display / interface.
After a successful read (Transponder or Barcode) the operation is finished and can be started again with
activation. All parameter settings can be found in the sub menus inside the system area/barcode and RFID
(see menu structure)
Further supported possibilities for interaction with the PLC system via command and interface
1. Text message onto Display
With the command “MD“ and directly attached ASCII-characters you can send a message with 16
characters onto the display of the device. The message has to be receipt at the device with pressing the
Trigger button/OK before the device is back in work mode
2. Accoustic signal
With the command „BP1“ / „BP2“ you can activate a deep /high acoustic signal for 1s, for an easy feed
back from PLC to device
3. Function pre select
All provided functions of the device can be pre selected from the PLC with the command „FC“(with
acknowledge from user) or “FCx”(without any action from user) , e.g. to proceed application dependent
process steps.
The command “FC1(x)” selects function“SCAN Barcode“, “FC2(x)” function „SCAN Barcode-EDIT RFID“;
“FC3(x)” the function“SCAN RFID“, “FC4(x)” function“EDIT RFID“ and “FC5(x)” the function“SCAN All“.
The selection is shown on the display and when using “FC” activated with the Trigger button.
4. Pre defined Data for writing onto Transponders
With the command “W“ you can send Data for Writing onto any transponder via interface to the HFU,
reasonable in combination with the function selection FC4 (x).
Pressing the Trigger button activates the Write operation directly.
The command structure of the W- command is the same as known from the fix mounted RFID-devices.
5. Ready signal / alive sign
With the command “?” a ready signal and the state of the device can be detected. The device comes
back (activate Messages) with “SFC0” when no function is selected, “SFC1” with selected function 1
(SCAN Barcode) etc. (see no 3.)
Note: Please combine Commands and Data (characters or numbers) directly (without space between) into
One single telegram, enclosed of the telegram prefix/suffix

Short description HFU 4520D Leuze electronic Page 11
Systems menu
Run Program Start of function selection
RFID Parameter Setting for Transponder Start block and number of blocks separate for
READ and WRITE op. Input via keys, OK for acknowledge
BarCode Pre select of Barcode(Symbology), with No of digits,
Choice with Green (* as character on Display)
Data output Prefix/Suffix, preset STX(02)/CRLF(0D0A)
Data format: Select HEX/ASCII for all functions, pre set ASCII
Data output:: Full/ DATA only / OFF, pre set Full
full means complete telegram (RFID)
Interface Baud rate and Databits can be set between 4800Bd and 115kBd ,
pre set 9600Bd, 8N1
Keyboard Password via Com/Password ON/OFF
MoreMessages: activation of different messages, select with Green (* as character in Display)
Device Settings Pre setting Region (UHF-Band) and power level
The complete menu structure is in the chapter menu.
Device reset / Factory default
With selecting the menu point “Reset device” in the System menu the device can be reset to factory default.
Note: All individual settings are lost then!!!
Parameter Setting
All parameters are available and can be set via key board in different sub menus within the system menu. No
separate or special software tool is needed.

Short description HFU 4520D Leuze electronic Page 12
Telegram- / Command structure
The factory presets are similar to the other available fix mounted RFID- devices from Leuze electronic. The
Standard telegram structure is shown below, with 9600Bd, 8Databits , N,1 :
STX Command CR LF
02h ASCII-Character 0Dh 0Ah
For this device you can change the telegram frame and the Baudrate.
With the following commands via the serial interface (within the upper shown frame) the functions selection or
other operations can be set and with activated messages (systems menu) you receive responses:
? State check, gives back a Ready sign (S) followed by the selected function (e.g. SFC1)
FC(1-5) Function change with response (FC3-OK), function active through User (Triggerbutton)
(device ready for use after pressing trigger!)
FC(1-5)x Function change with response (FC2x-OK) directly without activation through user
(device ready at once after response)
BP(1/2) Activation of device beeper with high / low Beep
MDTEXT Text on display for process control
W0100020002000000xxxxxxxx Datapreset for writing onto Transponder, Blockwise, look on settings
With 01 = bank for writing into,
0002 = Block starting with for Writing,
0002 = No of blocks to write (2-20 possible)
000000 = Tag Type universal (Tag Type prefix, adaption possible)
(xxxxxxxx = Data (complete Block)
For writing always a complete Block means 4 characters (hex) at 2 Byte/Block. The response on
W-command after a trigger is 'Q5' on the interface and Message on Display “Write successful“
Data can be written into EPC Bank (01 ) and User bank (03), depending on tag type
Within any bank the counting of Bytes starts at 00 and is transmitted in the telegram (Full).

Short description HFU 4520D Leuze electronic Page 13
Menu structure
Switch ON device with ‘Ok’
Yellow key LEFT starts Functions (Select with black keys),
yellow key RIGHT opens SYSTEM-Menu, Cancel with ‘C’
Device returns after 1min (starting with last pressed key) to function selection
Back to Functions selection
List of Barcode/ 2D code types, release with Green key
Select code Start/Stop character
Preamble set via key board
Postamble set via key board
Select sequence Postamble, Terminator
Telegram contains set type, factory 00
Select EPC, Serial number(TID), Data*; factory EPC
for Data input Startblockno. and No of Blocks
Type in Start block no. and No of Blocks, factory 05
Type in Telegram-Start character, factory STX
Type in Telegram-End character , factory 0D,0A
Select ASCII / HEX, ab Werk ASCII
Select FULL (compl. Telegram (RFID!)), factory full
Data only
OFF (no Data output via interface)
Select System
Barcode
Run Program
RFID
Barcode
Data output
PREfix
SUFfix
Data send
Symbologies
Terminator
Preamble
Postamble
Post/Termformat
RFID Read
RFID Write
RFID Type prefix
Data format

Short description HFU 4520D Leuze electronic Page 14
Select Baudrate (4800-115200), factory 9600
Select Parity (None, Even, Odd), factory None
Select No of Datenbits (7,8), factory 8
Select No of Stoppbits(1,2); factory 1
Select device interface (no change!!), COM1
Key board protection ON / OFF , factory OFF
Type password via keyboard
Activation of Messages (select with green key)
ON/OFF for Send Messages via Interface, factory OFF
ON/OFF for Send NORead Message, factory OFF
ON/OFF for Input line for type in Quantity, factory OFF
Select separator for amount in telegram,
Interface
Baudrate
Parity
Databit
Stopbit
Def.COMport
Key board
Messages
Password via COM
Password
Activation
Send
NO Read
BT Warning
USE Qty
Qty separator

Short description HFU 4520D Leuze electronic Page 15
Settings for bluetooth, MAC adresses, Access key,
and Bluetooth reset , Shows BT State, ON / OFF
Activates Search process for BT Base
Shows actual MAC address
Manual Set ting of MAC address
Manual Setting of Device Name
BT PIN: Factory 1234
Usage of BT PIN ON / OFF
Reset and start of Bluetooth connection
Set Device Date+time via Key board
Set contrast and orientation of display
Set Bieper volume, key click
shows supply Voltage, select auto power off time
shows Version of Hardware / Firmware of device
select sets device to factory defaults, for BT please use twice
select Region (UHF-Band), power level
Region EUROPE, USA,Korea, China; factory EUROPE
Gen2 Session:(filtering time of recognized tags)
(0-no filter, 1-5sec, 2-10sec, 3-15sec), factory 1
power: 10mW to 200mW(value 1000-2300), factory 2300
recommended min 1700 (with reset this point is first)
* Note: The availability of the memory banks TID (serial number), EPC and User block depends on the used
transponder chip and may be not always available. The EPC bank is typically available with 8 – 12 characters
and 4-6 blocks at any chip type.
Date & Time
Display
Sound
Power
Reset Device
Version
Device Settings
Bluetooth
Bluetooth: ON
Search Device
Show local
Set Remote
Set Device
Set
AccessKey
Set Securitystat
Reset BT

Short description HFU 4520D Leuze electronic Page 16
HFU 4520D at serial PC-Interface
With Power supply via separate power plug NT Hx5x0, Art-Nr. 50110676
necessary parts:
1x 50114138 HFU 4520D, incl. battery
1x 5011 0676 NT Hx5x0, Power supply (100-240VAC/6VDC)
1x 50110672 Base Hx520, Bluetooth base
1x 50110675 KB-RS232-Base Hx520, RS232 cable, 2m length
Pinning of the 9 Pinl- D-Sub (female)
PIN
-
No
Signal
Description
2 TX Transmit Data (-5 to +5V)
3 RX Receive Data (-5 tos +5V)
5 GND Signal Ground
9
Signal
4,5 - 6 VDC, external Via Connector
or direct

Short description HFU 4520D Leuze electronic Page 17
HFU 4520D with MA 204i, MA208i or MA248i
RS 232 with 9600 Baud, 8 Data bits, 1 Stoppbit, No Parity, Postfixes CR/LF.
Necessary parts:
1x 50114138 HFU 4520D, incl. battery
1x 50110672 Base Hx520, Bluetooth base
1x 50110675 KB-RS232-Base Hx520, RS232 cable, 2m length
1x 50110676 NT Hx5x0, Power supply (100-240VAC/6VDC)
1x 50113397 KB JST-HS-300, 5VDC at PIN9
1x 50112891 MA 248i for Profinet RT I/O
(for Ethernet: 50112892 MA 208i or Profibus: 50112893 MA 204i)
Please connect the HFU to the 9-pin Sub-D.
HFU 4520D with MA 21 (multinet)
Separate power supply needed.
Note: The RS 232 of the MA21 is set to 9600 Baud, 7 Databits, 1 Stoppbit, Parity Even, Postfixes CR/LF.
Please change at HFU for proper functionality.
Necessary parts:
1x 50114138 HFU 4520D, incl. battery
1x 50110676 NT Hx5x0, Power supply (100-240VAC/6VDC)
1x 50110672 Base Hx520, Bluetooth base
1x 50110675 KB-RS232-Base Hx520, RS232 cable, 2m length
1x 50035421 KB 021 Z
1x 50030481 MA 21100
Pinning KB021 Z
Colour: Signal Clamp in MA 21:
Brown (RXD) 26
White (TXD) 27
Blue (GND) 28
Red (VCC) 30
Black (GND) 31
blank (Shield) (PE) 21

Short description HFU 4520D Leuze electronic Page 18
HFU 4520D with USB (COM-Port-Emulation)
To use the HFU 45xxD with USB you use the standard RS232 cable and connect the
USB Converter cable. The data is sent to the new COM-Port. The necessary driver is available on
www.leuze.de. the interface is set to 9600,8,N,1.Separate power supply needed.
Necessary parts:
1x 50114138 HFU 4520D, incl. battery
1x 50110676 NT Hx5x0, Power supply (100-240VAC/6VDC)
1x 50110672 Base Hx520, Bluetooth base
1x 50110675 KB-RS232-Base Hx520, RS232 cable, 2m length
1x 50110677 KB-USB-RS232, converter cable, 1m length
USB-converter cable KB-RS232-USB, Length 1m Art-No. 50110677
Pinning of the USB-connector, 9 pin Sub-D like above
Note: Operation with external power supply recommended
USB
-
Type A
-
Plug
Signal
Description
1 VCC IN 5 VDC
2 Data - Data -
3 Data - Data +
4 GND Signal Ground
Triggering /Activation
For starting the SCAN operation / activation signal (trigger) you use the Trigger button at the handle of the
device.

Short description HFU 4520D Leuze electronic Page 19
Diagnostics and trouble shooting
Typical errors and their possible causes are described in the following list as well as tips for their elimination:
1. Is the device connected to a suitable power supply from the PC– means device and PC/PLC should be
connected to each other before switch ON. The external power supply should have 6VDC/1A
2. If you use the separate Power plug please check the connections
3. Make sure the interface cable is fixed correctly at the PC/PLC. Details for the interface are printed usually
in the manual of the PLC/PC.
4. If you checked all steps before and the device is still not ready, change the power supply to another one.
5. Please check the used interface at the device and your PC/PLC are compatible. Information about that is
printed in the PC´s /PLC´s manual.
6. 1D / 2D Code: Please check the quality of the Barcode / 2D Labels, and the correct symbologies are
released. Damaged labels (scratched, dirty or crinkled) can cause hardly readable or not readable codes.
7. RFID: Please check the settings for RFID and check the transponder type with your supplier. If the
settings are correct the transponder can be defect as well- try another one if possible.
8. Now you checked most possibilities. For further support please contact the Leuze Service.

Short description HFU 4520D Leuze electronic Page 20
Type overview
HFU 45xx – Series
Art-No. Description Interface Picture
50114138 HFU 4520D, incl. battery
TTL RS232
Accessories
Accessories for HFU 45xx
Art-No. Discription
50110672 Base Hx520, Bluetooth base and charging
station for Hx520D, RS232
50110675 KB-RS232-Base Hx520, RS232-cable for
Base, 2m length
50103403 NT Hx5x0, external Power supply for HFM/HFU,
Base Hx520 (100-240VAC/6VDC)
50110677 USB-converter cable for HFM/HFU,
Base Hx520
50111928 Rechargeable battery 3.7VDC, 1500mAh
